Novra S75 Receiver
4.3 Content Configuration
The Content Configuration Window can be opened with the tool bar button
or by selecting "Actions" then "Content Configuration" from the drop down menu.
The DVB signal from the satellite has Program IDentification (PID) numbers that are used to select
desired portions of the DVB data stream.
Enter the PID value in decimal
format.
The entered PID value is then
added to the Selected Contents
list and converted to Hex by the
system. (Displayed in brackets.)
Up to 16 PIDs can be listed at
once.
The "Delete" button will remove
a highlighted PID from the list while
"Delete All" will erase the entire list.
Notes: - There is no UNDO available. If "Delete All" was asserted in error then select "Cancel" to
abort the operation before the changes are applied to the S75.
- With this version of S75 De-encapsulation of the IP data is always selected.
(Selection of "Extract IP Data" is grayed out with a check mark.)
- The green check indicates that the system will de-encapsulate the Multi-Protocol
Encapsulation (MPE) associated with the DVB stream.
Push "Send" (or Enter) to assert the new settings or "Cancel" to exit this window without asserting the
changes. Once the changes have been successfully applied, the Content Configuration window is
closed by selecting the "Cancel" button.
