The coin validator system G-13.6000
The advantages at a glance:
• 2devicesinone,duetothe2x12configuration
• greatfunctionalvariety
• measuringsystemwithreliablerejectionoffalsecoins
• highprotectionagainstmanipulation
• awake-upmode enables operationwitha battery oran
accumulator
Preface Thisdescriptiongivesyouasurveyofthemostimportantfeatures
oftheprovencoinvalidatorsystemG-13.6000includingitsvariants.
Theappendixcontainsthetechnicaldata,electriccircuitdiagrams
andviewsofthedevices.
Ifyouhaveanyquestionspleasedonothesitatetocontactus.Our
salesstaffwillprovideanyinformation.
NationalRejectors,Inc.GmbH

3
NationalRejectors,Inc.GmbH,Buxtehude
G-13.6Tableofcontents
Table of contents
1 Generalinformation........................................ 4
Interesting facts about the coin validator system
G-13.6000 ................................................................ 4
Variants.................................................................... 5
2 Characteristic features of the system ........... 6
Measuring system.................................................... 6
Adjustment of the channels...................................... 6
Singleblocking ......................................................... 7
Sorting outlets .......................................................... 7
String recognition ..................................................... 7
TeachMode ............................................................. 8
Block switch-over................................................... 10
3 Description of the variants .......................... 11
Standard coin validator........................................... 11
Casino variant ........................................................ 11
Totalizers ............................................................... 12
Timer variant .......................................................... 13
2-price totalizer ...................................................... 15
TVtotalizer ............................................................. 16
APPENDIX ................................................................ 19
Cleaning.............................................................................. 20
Technical Data.................................................................... 21
Assignment of pins, standard coin validators......... 22
Assignment of pins, totalizer.................................. 22

4
NationalRejectors,Inc.GmbH,Buxtehude
1 General information
Interesting facts about the coin validator system
G-13.6000
ThevalidatorG-13.6000isaworldwideestablishedproductforthe
machineindustryinstandardized3 1/2"format.Duetoitsmodular
designandthecompactconstructionthevalidatoristheoptimum
solutionfortheamusementandservicesindustry.
Dueto the CMOSprocessor and an electronic system that isdone
completelyinSMDtechniqueagreater functional variety,an
improved measuring system and a greater protection against
manipulationarepossible.Apartfromthatthesystemnowprovides
2x12 coin channels.
Startingwithnumber/1(markingwithinthemodelnumber)theG-
13.6000offersthepossibilitytochoosefromtwoconfigurations
(blocks)with12coinchannelseach.Theseblocksmaybe
programmedinadifferentwayandthuscanobtaindifferentcoin
combinations.Thisfeatureisparticularlysuitableforflexibleswitching
overfromonecurrencytotheother.
Duetotheshortswitching-ontimeoperationinaso-calledwake-up
mode is possible. A sensor located in front of the coin slot switches
thecoinvalidatingsystemon.Thefeatureisofgreatadvantagefor
devicesthatareoperatedwithabatteryoranaccumulator.
Theteachmode offersmoreflexibilitytotheoperatorwhenselecting
coinsandtoken.Withoutanyadditionalhelponlybyusingtheteach
modeyoucanprogrammequicklycoinsortokenonsite.
Likeallelectroniccoinvalidatorsystems fromNRIthedevicesofthe
seriesG-13.6000/G-13.7000 can be adjusted by means of a
programming station.Forthis youneed an IBM compatible PC and
theadjustmentprogramme KUNEMP.(Formore information referto
NRI.)
Before changing the device take care that the supply
voltage is switched off.
G-13.6Generalinformation

5
NationalRejectors,Inc.GmbH,Buxtehude
Variants
TheseriesG-13.6xxxcombinesallvariantswithout afrontplate,
whereastheseriesG-13.7xxxcombines allvariants with a front
plate.
Wedistinguishbetweentwoproductserieswiththreeresp.four
variants
1. Standard coin validator G-13.6000/G-13.7000
6paralleloutputlines
2. Casino variant G-13.6100
– fastcoinacceptance
– V2Aenforcement
3. Timervariant G-13.6200/G-13.7200
– adjustablelengthofthe
outputpulse
4. 2 - price totalizer G-13.6300/G-13.7300
– handlingoftheremainingcredit
– salescounter
5. TV totalizer G-13.6400/G-13.7400
– forvideogames/pinballmachines
– serialpulseoutput
– discountspossible
G-13.6Generalinformation

6
NationalRejectors,Inc.GmbH,Buxtehude
G-13.6Characteristicfeaturesofthesystem
2 Characteristic features of the system
Measuring system
Thefeaturesoftheinsertedcoins arerecognizedbysixmeasuring
probesthatareinstalledinsuccessiveorder.Amongothersthe
measuringparametersarethediameter,thethickness,thealloyand
forcertaincoinsalsotheembossingfeatures.
Theobtainesmeasurementvaluesarecompareswiththeacceptance
bandsstoredwithinthe12channels.Iftheycorrespondcompletely
withachannelthevalidatorvaluestheinsertedcoincorrespondingto
theprogrammeddenominationoroutputinformationrespectively,
unlessthechannelisinhibitedbytheappropriateDILswitchorthe
appropriateinputline.
Aftersuccessfulmeasurementalightbarrierintheareaofthe
acceptancegatecheckswhethertheinsertedcoinsfallunhindered
intothecashchannel.Withinvalidatorscontainingasortingthe
'acceptedcoinsensor'iscompletedbya'sortingcontrol'.Onlyafter
passing this additional sensor is the appropriate coin signal given.
Thusthewholeacceptanceareaincludingthefallingdirectionis
supervised,thuspreventingmanipulations.
Adjustment of the channels
12channelsareprovidedinthecoinvalidatorstoprogrammeall
requiredtypesofcoins.Apartfromthenormalbandwidthformany
types of coins a narrow bandwidthcan be adjusted. Fortypes of
coins that are likely to be forged a super narrow channel can be
adjustedtoprovidethegreatest possible protectionagainstmisuse.
Severalchannelscanhavethesamecoinvalue.Thecorresponding
settingsaregivenonthelabel(upperrow:channels1–6,lowerrow:
channels 7–12).

7
NationalRejectors,Inc.GmbH,Buxtehude
G-13.6Characteristicfeaturesofthesystem
Single blocking
Twoblockswith six DILswitches each areinstalledon the backside
ofthecoinvalidator.Theycan be usedtoblockindividualcoin
cannels.Todothisthecorrespondingswitchmustbesetto the upper
position. (If more than one channel is assigned to one type of coin,
e.g. for old and new coins or for different bandwidths all the switches
must be set to the upper position.)
Sixoutput linesare assignedto the12 coinchannels (notvalid for
totalizers).Ifaninsertedcoinisrecognizedthecorrespondingchannel
receivesasignal.Ifonetypeofcoinisblockedexternallythe
correspondingoutputlineisset to ground potential.Line6canbe
used to block the whole acceptance (all types of coins).
Sorting outlets
A JST plug is installed on the pc-board. Hoppers or sorting gates can
becontrolledby means ofthis plug. Signalscanalso be received
sincethese are bidirectional lines . If e.g.a hoppersends a "Full"
signalthecoinsaredirectedintothecash-box.
ThevalidatorscanalsobeadjustedbyNRIinthatwaythatthereturn
line sendsasortingsignalontothe10-poleconnectingcable.
String recognition
Asaprotectionagainstmanipulationwithstringsthecoinvalidators
are equipped with a directional accept sensor. That means that a
coinsignalis only givenwhena coin passesthelight barrier coming
fromthe coininsert. Topull coinsback outof thedevice isalso made
moredifficultbyadditionaldesignmeasures.
For devices without a front plate the accept sensor is located on the
left side whereas it is located on the right side for devices with a
frontplate.
Apartfromthatstandardcoinvalidatorsof the series G-13.6000 can
beequipped with a spring foradditional supportof this safety device.

8
NationalRejectors,Inc.GmbH,Buxtehude
Teach Mode
Byusingtheteachmodeyoucanprogrammecoinsortokenin
channel10and11.InallversionsoftheG-13.validatortheteach
modeisprogrammable. However, acombinationofthe 2-price-
totalizerwithsalescounterandtheteachmodedoesnotmakesense
asthetasksoftheswitchforsinglecoininhibitforthe12thchannel
wouldoverlapeachother.
Usingtheteachmode:
Thevalidatorremainsconnectedinthevendingmachine.
•OntherearofthevalidatortwoDual-In-Lineswitchesare
positioned.Switchno.12ON.
•Dependingontheintentiontoteachchannel10or11,please
switchONtheappropriateswitch.
•Insertcoinsortoken.
Afterinsertionofthe10thcoin(token)thevalidatorgivesan
acousticsignal(clickoftheacceptancegate).Themeasured
valuesarenowregistered.
•Turnswitchno.12OFF.
•Alsoturnappropriateswitchforchannel10or11OFF.
Onceagain the acceptance gate gives an acousticsignal (1time),
i.e.theprogramminghasbeenfinishedsuccessfully.
G-13.6Characteristicfeaturesofthesystem
12345 6 7 8 9 10 11 12 13 14
ON
OFF

9
NationalRejectors,Inc.GmbH,Buxtehude
G-13.6Characteristicfeaturesofthesystem
Incasetheacceptance rate foracoin or token programmedbyteach
modeisnotsufficient,you canprogrammethecoinortokenwithwider
acceptancebandwidths.Thereforepleasedothefollowing:
•DIL-switchno.12ON.Teachmodeisnowactive.
•Turnswitchfordesiredchannel10or11ON.
•Insertnewcoinortokenatleast10times.
Theacceptancegategivesan acoustic signal(1time).Coinvalues
are registered.
•Turnchannelno.10and11ON.
Wideacceptancebandwidthsarenowcalculated.
•Turnswitchno.12OFF.
•Turnswitch10and11OFF.
Coinor tokenis nowprogrammed. The teach mode has now be
finishedandthechannel10 and11areenabled.
Incasetheacceptancegatesgivesanacousticsignaltwice,the
followingreasonscouldbepossible:
•coincouldnotbeprogrammed.Itexistanoverlappingofthe
acceptance limitswithalreadyprogrammedcoins/token.
•anerrorhashappendduringmeasurement.
•theprogramminghasbeeninterrupted.
•theacceptancelimitscouldnot be assigned toachannelasswitch
no.10or 11 wasturnedONfirst instead ofswitchno. 12.
Ifacoinortokencouldnotbeprogrammedtheexistingvaluesremain
storedinanycase.

10
NationalRejectors,Inc.GmbH,Buxtehude
G-13.6Characteristicfeaturesofthesystem
Block switch-over
Startingwithmodelno.G-13/1thevalidatoroffersthepossibilityto
havetwoconfigurations,independentfromeachother.Toeachof
these'blocks'12individualcoinchannelsareassignedwith
appropriatetables(signals,denominations,sortinginformation).The
programmingisdoneeitheratNRIorataservicestation.Although
bothblocksareprogrammedyoucanonlyworkwithoneofthem.
Thistypeofvalidatorcanberecognizedbythelabelwiththeextended
indications.
Thisfunctionisidealforstoringadditionallytotheactualcurrencyase-
condcoincombinationwithindividualinterfaceinformation(table).For
exampleincaseofacurrencyconversiontheactualsettingsare
deactivatedandthenewonesareactivated.Afurtherapplicationcan
beifindependentfromcurrencyanalternativevendingmachine
interfaceisselected.
Forstandarddevicestheswitch-overisdonebyonlyoneDILswitch!
OntherearoftheG-13twoswitcharrangementsarepositioned.For
switchingoverfromblock 0 to block 1pleaseuseswitch no. 8ofthe
right-handswitcharrangement.Pleaseproceedasfollows:
•Switchoffpowersupply.
•Switchonswitchno.8oftheright-handswitcharrangement
– lowerposition= block 0activeonly (leftsideon label)
– upperposition = block 1 activeonly (rightside on label)
•Switchonpowersupply.
•Checkcoin acceptance (pleaserefer to label).
ON
OFF
blockswitch-over
1 2 3 4 5 6 7 8

11
NationalRejectors,Inc.GmbH,Buxtehude
G-13.6Descriptionofthevariants
3 Description of the variants
Standard coin validator
Eachinserted coinis checked for its type and genuiness and
assignedtothecorrespondingchannel.Assoonasthecoinhas
passed the light barrier a pulse signal (100 ms) is given onto the
correspondingoutputlineandtheoutputissettogroundpotentialvia
anopen-collector-transistor.Ifthelightbarrierisalreadyblockedwhen
the coin is inserted the coin is rejected.
SincethechannelcanbeassignedtodifferentoutletsbyNRIitis
possible to transmit coin signals in a binary code or assign more than
oneline toa typeof coin.
Casino variant
TheCasinovarianthastwospecialfeatures:
1. Fast coin acceptance
Thecoin insert speed can beup to6 coins/second without any
malfunctionsoccurringortransmittingofwrongsignals.
2. V2A enforcement
Thisenforcementintheslotareareducesthewearandtearthat
appearsinslotmachinesbecauseoftheusuallyfrequentcoinflow.
To provide additional protection an accept sensor signal can be
transmittedonthecoinreturnline(line5)asanoption.Thecoinsignal
andtheacceptsensorsignalaregivenindependentlyofeachother.
Since the acceptance gate is triggered at the same time the next coin
can be tested without causing problems (a continuous signal at the
acceptance gate will not cause a problem).

12
NationalRejectors,Inc.GmbH,Buxtehude
G-13.6Descriptionofthevariants
Totalizers
Atotalizerisacoinvalidatorwithacredit function.Theseunitshave
nochannelallocation.Insteadthevalueoftheinsertedcoinsis
determinedandaddedupuntilanadjustablecomparisonvalue(price)
isreached.As soon asthe pre-set valuehasbeen reached the
totalizertriggersafunction.Thereisatotaloftwo output lines that
canbeadjustedindenpentlyofeachother.IntheTimervariantthese
arefunctionallines,whereastheyarepricelinesinthe
2-pricetotalizer.
AdditionallyalltotalizersareequippedwithtwoDILswitch
arrangementswitheightswitcheseach.Theyservetoadjustthe
sales price (not valid for Timer variant/TV totalizer). The adjustment
isdone in a binary code.The value of each switchis indicated below
theswitch.Byselectingacombinationoftheseeightswitchesany
valuebetween1and255canbeadjusted.Thestepnumberservesas
amultiplierforthelowestcoinvaluewhencalculatingtheprice.The
acceptance limit is 230.
Ifoneofthe two pricesissetto 0 thecorrespondingfunctionalline is
alwaysactivatedandcannotbeerased.Thisistheso-calledfree
sales mode.
Tokenscanbeusedtoactivatethefunctionallinedirectlyand
simultaneouslyincreasethecreditbytheadjustedvalueoftheprice
switch.
Multiplesales
Incaseofinsertingtoomuchmoneytherearethreepossibilities
concerningthe remainingcreditwhichcanbeadjustedbytheNRI:
•Variant A:
2-pricevariant
– The remaining credit is erased after a sale.
– Multiplesalesarenotpossible.
– Both prices can be used.
– Acceptance is blocked as soon as the higher price has been
reached.

13
NationalRejectors,Inc.GmbH,Buxtehude
G-13.6Descriptionofthevariants
•Variant B:
Multiplesales-type1
– Theremainingcreditremainsvalidafterthefirstpricehasbeen
erased.
– Multiplesalesarepossible.
– Onlythefirstpricecanbeused.
– Thesecond switch is set tothe freesales mode.
•Variant C:
Multiplesales-type2
– Theremainingcreditiserasedafter2minutes.Wheninsertinga
furthercoininthisperiodthe erasingprocedureiscancelled.
– Onlythefirstpricecanbeused.
– Thesecond switch is set tothe freesales mode.
Timervariant
Thetimerfunctionmeansthatthe credit is erasedorafunctional line
is deactivated after a pre-set time.
Thetimeunitisnormallyset to60sec.,butitcanbeadjustedbyNRI
toanyvaluebetween1and255.
Thetimeunitisdeterminedbythevalueoftheinsertedcoin.Usethe
upperswitcharrangementtodefinehowmuch a timeperiodcosts
(see fig. 2).
e.g.: lowest coin = 0.10 DM / adjusted multiplier = 10 (2 + 8)
∅price/min. = 1.00 DM
Fig. 2: Setting the price for one time unit
1
1
2
2
3
4
4
8
Switch block 1
5
16
6
32
7
64
8
128
ON
OFF
Value

14
NationalRejectors,Inc.GmbH,Buxtehude
G-13.6Descriptionofthevariants
Witheach inserted cointhe credit isincreased bythe corresponding
value.Thecurrentcreditcanbedisplayed.
Thelowerswitcharrangementisusedtodefinetheamountofcreditat
whichthetimeunitstarts(seefig.3).
e.g.: lowest coin = 0.10 DM / adjusted multiplier = 20 (4 + 16)
∅amountofcredit for thestart= 2.00 DM
Fig. 3: Adjusting the amount of credit for the start
Assoon asthe credit adjusted with switch block 2has been
exceeded,thedisplaywillstopshowingthecreditbutwillinstead
showthetimeunit.Aflashingpointindicatestherunningtime.
Simultaneouslythefunctionalline1istriggered.Itremainsactivated
duringthewholetime.
Iftheline for totalblocking has notbeenactivated it isstill possible to
insertfurthercoins.Thetimeonthedisplayisincreased
correspondingly.
Functional line 2 isadditionallyactivatedwhenthelast time unit is
running.Thissignalcanbeusedforawarningsound.Whenthetime
hasrunoutthisisindicatedinthedisplay.Thefunctionallines1and2
aredeactivated.
Fromthemachinethetimecountingcanalwaysbeinterrupted(high
signal) or started (low signal) via line 8 (reset line) .
Theremainingcreditisdisplayedwhenpressingthereturnbutton.
1
1
2
2
3
4
4
8
Switch block 2
5
16
6
32
7
64
8
128
ON
OFF
Value

15
NationalRejectors,Inc.GmbH,Buxtehude
G-13.6Descriptionofthevariants
Application of tokens
When inserting a token that is allocated to switch block 1 thecredit
isincreased by theprice of one time unit.
When inserting a token that is allocated to switch block 2 thecredit
isincreasedbythevalueadjustedatswitchblock2.Thenumberof
timeunitsisincreasedcorrespondingly.
2-price totalizer
Thistotalizervariantisalsoequippedwithtwoswitcharrangements
foradjustingthesalesprices.Theupperswitcharrangementservesto
adjustthefirstprice,thesecondpriceisadjustedatthelowerswitch
arrangement.
e.g.: lowest coin = 0.10 DM / adjusted value = 6 (2 + 4)
∅price = 0.60 DM
Fig. 4: Adjusting the 1st price
e.g.: lowestcoin =0.10 DM / adjusted value = 8
∅price = 0.80 DM
Fig. 5: Adjusting the 2nd price
1
1
2
2
3
4
4
8
Switch block 2 (2nd price)
5
16
6
32
7
64
8
128
ON
OFF
Value
1
1
2
2
3
4
4
8
Switch block 1 (1st price)
5
16
6
32
7
64
8
128
ON
OFF
Value

16
NationalRejectors,Inc.GmbH,Buxtehude
G-13.6Descriptionofthevariants
Thevaluesoftheinsertedcoinsareaddedupuntilthe adjustedprice
has been reached or is exceeded. The corrsponding output line is
activated.Whenthehigherpricehasbeenreachedbothoutputlines
areactivated.
Whena salesprocedure has been completed the blocking resp.
reset line mustbe activated for50msec. to reset the credit and to
deactivatetheoutputlines.Inthestandardadjustmenttheblockingline
isalsousedforreset.NRIcanchangeitoverto the reset line.
Thecreditcan be shownbymeansof a display.
Sales counter
Onrequestthetotalizerscanbeequippedwithasalescounter.With
thisnewfunctionthecoinacceptancecanbeblockedafterapre-set
amountofsales.Theblocking canonlybereleasedbyinserting a
reset-token.Byinsertingthistokenthesalescounterisre-
programmed.Itisprogrammedwiththenumberofsalesthatare
adjustedatthesecond price switch.Thistokenis programmed in
channel12andcanonlybeusedbyauthorizedpersonnel.Whenthe
blockingis released thepre-set number ofsales can becarried out
again.
TV totalizer
Thisvariantisa totalizerwithaserialpulseoutput.Thevalueofthe
coins is added up until the pre-set price has been reached. For two
types of coins a discount canbe allowed, this is done by higher pulse
numbers.
Forthe TVtotalizer acredit does not have to be reset.
Thetwoswitcharrangmentsservetoadjustthepulsenumbersresp.
theprice.Thefirstsixswitchesoftheupperswitcharrangementserve
to adjust the price (e.g. for a game). Here the multiplier (max. 63) is
adjustedforthelowestcoinvaluethatisrequiredforreachingthe
gamepriceandfortransmittinga pulse. When thepricehasbeen
reachedoutputline1isactivated.Thecreditcanbeshownbymeans
ofadisplay.Thelasttwoswitchesareusedtochangethepulse
frequency:

17
NationalRejectors,Inc.GmbH,Buxtehude
G-13.6Descriptionofthevariants
Switch 7 Switch 8 Pulse frequency (pulse-pause relation)
down down 20 msec. pulse /80 msec. pause
up down 50 msec. pulse /200 msec. pause
down up 100 msec. pulse /400 msec. pause
up up 200 msec. pulse /800 msec. pause
e.g.: lowest coin = 0.10 DM / adjusted value = 10 (2 + 8)
∅price = 1.00 DM
pulse-pauserelation= 20 msec.pulse / 80msec.pause
Fig. 6: Adjusting the price and the pulse frequency
Bymeansofthesecondswitcharrangementthediscountscanbe
adjustedforthosetypesofcoinsthatareindicatedonthelabelofthe
totalizer.Thisisdonebymeansoffourswitchesthatservetoenterthe
pulse number (0 - 15).
e.g.: pulsenumber for coin A =3 /pulse number for coin B= 7
Fig. 7: Adjusting the pulse number
1
1
2
2
3
4
4
8
Switch block 1
5
16
6
32
7
pulse length
8
ON
OFF
Value
1
1
2
2
3
4
4
8 248
Switch block 2
5
1
678
ON
OFF
Value

18
NationalRejectors,Inc.GmbH,Buxtehude
IfrequiredtheTVtotalizercanalsotransmitaso-calledinventory
pulse (mustbe adjusted byNRI).It meansthat directly afterinserting
acoinanumberofpulsesistransmittedtooutputline2.Thenumber
ofpulsescorrespondswiththevalueofthecoin.Whentransmittingthe
pulsesthe coinacceptance is blocked.
Asfar as theremaining credit isconcerned the three variants A - C
described in chap. 3.2 Totalizers are available.
It is also possible to connect a 4- or 5-digit display to this device.
G-13.6Descriptionofthevariants

19
NationalRejectors,Inc.GmbH,Buxtehude
APPENDIX
G-13.6Appendix

20
NationalRejectors,Inc.GmbH,Buxtehude
Cleaning
Onlythecoinvalidator'sflightdeckmustbewipedclean fromtimeto
timewithdampcloth(lukewarmwaterwithsomewashingupliquid).
Overandabovethereisnofurthermaintenanceworktodo.
Under no circumstances may the cloth be so wet that fluid
runs into the device. Other the PCB will be damaged.
Do not use any solvents or scouring agents which attack
the plastic of the device.
1. Pullthevendingmachine'smainsplug.
2. Carefullyopentheflightdeck1ontheleft-hand sideandkeepit
open(Fig. 8).
3. Wipethecoinrunwayinsidethecoinvalidatorclean.
4. Closethe flight deckagain.
5. Reconnectthevendingmachinetothemainssupply.
Fig. 8: Open the coin validator's flight deck
1
G-13.6 Appendix
