NSS eForce User manual

OPERATION MANUAL
eForce™ Burnisher
Original Instructions

2
SAVE THESE INSTRUCTIONS
IMPORTANT SAFETY INSTRUCTIONS
WARNING: Failure to observe these instructions can cause
personal injury to the machine operator, and/or bystanders.
INTENDED USE
This machine is intended for commercial use, for
example in hotels, schools, hospitals, factories,
shops, offices and rental businesses.
This machine is intended for buffing and burnishing
dry hard floors in an indoor environment only.
This machine is intended for dry use only.
This machine is not intended for spray burnishing.
This machine is not intended for use by persons
(including children) with reduced physical, sensory or
mental capabilities, or lack of experience and
knowledge.
WARNING: Fire or explosion hazard.
NEVER operate this machine in an explosive atmosphere for
example near grain dust, flammable liquids or fumes, etc.).
NEVER use flammable liquids (for example gas,
kerosene, solvents, or thinners, etc.) to clean or
burnish floors.
WARNING: This product contains a chemical
known to the state of California to cause cancer and
birth defects or other reproductive harm.
FOR SAFETY
ALWAYS read and understand all instructions
before operating or servicing this machine.
ALWAYS use or service this machine ONLY as
described in this manual.
ALWAYS operate this machine sitting in the seat
and always fasten the seat belt for safety.
NEVER attempt to operate this machine unless you
have been trained in its operation or allow an
untrained person to operate this machine.
ALWAYS ensure that bystanders, particularly
children, are not endangered when operating this
machine. CAUTION: This machine makes wide
turns.
NEVER leave the machine unattended without first
turning off the key switch (O) and removing the key.
ALWAYS turn off the key switch (O) when
attaching or changing pads or opening any access
panels.
ALWAYS supervise children to ensure they do not
play with the machine. This machine is not a toy.
NEVER attempt to operate this machine on a
grade/slope of 9% (5.14 degrees) or climb a ramp
or incline of more than 13% (7.41 degrees).
ALWAYS burnish dry hard floors going up and
down inclines.
NEVER burnish floors going across inclines.
NEVER expose the machine to temperatures
above 60° C (140° F) or below 0° C (32° F).
ALWAYS be sure that any ramp is secured to the
vehicle / pallet before attempting to load / unload.
ALWAYS use extreme caution when operating
the machine on a ramp or loading / unloading this
machine into or out of a truck or trailer.
NEVER use the machine on any surfaces that are
wet, oily, or covered with cleaning chemicals
including any ramps or inclines.
NEVER stop or turn the machine on a ramp or
incline.
ALWAYS park or store this machine indoors in a
dry, cool area away from any furnace, boiler, open
flame, or other high heat source.
ALWAYS use extreme caution when using this
machine near stairs or open stairways.
ALWAYS wear clean tennis shoes or “non-slip”
shoes. Leather soled shoes will be extremely
slippery.
ALWAYS keep face, fingers, hair or any other body
part or loose clothing away from any machine
opening or moving part for example the revolving
pad driver. NEVER attempt to operate this machine
if it is not working properly or has been damaged in
any way.
NEVER disconnect or modify any switches or
safety devices for example the circuit breaker or
seat belt.
NEVER drop or insert any object into any machine
opening for example the battery compartment.
NEVER operate this machine with any air opening
blocked. Keep all air openings free of dust, lint, etc.
NEVER pick up anything that is burning or
smoking, for example cigarettes, matches or hot
ashes.
NEVER spray this machine with water or any
liquids.
NEVER allow the battery charging plug to get wet
or a short may occur.
NEVER operate this machine when the battery
charger is plugged in.
NEVER operate the machine outdoors or expose
the machine to rain or snow.
NEVER allow the machine to freeze.
NEVER store any items on the machine.

3
IMPORTANT SAFETY INSTRUCTIONS
BATTERY POWERED EQUIPMENT
WARNING: Failure to observe these instructions can cause personal
injury to machine operator or bystanders.
GENERAL
ALWAYS read and understand all instructions before
installing or charging batteries.
NEVER attempt to install or charge batteries unless
you have been trained to do so or allow an untrained
person to install or charge batteries.
ALWAYS remove all jewelry when working on or
near the batteries and electrical system components.
ALWAYS turn off all switches during installation and
service.
ALWAYS disconnect the battery disconnect before
performing any service or repair. See
ALWAYS wear eye protection, rubber gloves and
protective clothing to avoid contact with battery acid.
NEVER lay anything on top of batteries as arcing
may occur.
IF CONTACT WITH BATTERY ACID OCCURS,
follow these instructions:
SKIN – rinse area with water.
EYES – Flush with water for 15 minutes.
INTERNAL – Drink water or milk. Follow with Milk
of Magnesia, beaten egg or vegetable oil. Call a
physician immediately.
BATTERY INSTALLATION
ALWAYS use an overhead hoist or two people to
install batteries, as the batteries are heavy.
ALWAYS disconnect battery pack from machine.
ALWAYS position batteries as shown on the
machine installation decal to maintain machine
balance.
ALWAYS connect batteries as shown on the
machine installation decal to avoid shorting out the
batteries and the electrical system.
BATTERY CHARGING
ALWAYS read the instructions on charger carefully.
ALWAYS use the NSS supplied charger with proper
voltage rating.
ALWAYS study battery manufacturers’ specific
precautions such as recommended rates of charge.
NEVER charge a frozen battery.
ALWAYS plug the charger into an earthed socket-
outlet.
NEVER touch uninsulated portion of output connector
or uninsulated battery terminal.
ALWAYS disconnect the AC supply before making or
breaking the connections to the battery while
charging.
NEVER open or disassemble the battery charger.
NEVER operate charger if the AC supply cord is
damaged or if the charger has received a sharp blow,
been dropped, or otherwise damaged in any way.
FOR LEAD ACID BATTERIES ONLY
Does not apply to gel or maintenance free batteries.
ALWAYS check to ensure the battery water level
covers the battery plates before charging.
ALWAYS check water level after charging and add
only distilled water only if necessary to bring level to
the bottom of the fill hole.
NEVER
overfill batteries as
battery
and machine damage may
result.
ALWAYS reattach caps to batteries. Do not charge
with caps loose or removed.
ALWAYS wipe any acid from the top of batteries
using a soap solution.
Read and understand all
instructions before installing
or charging batteries.
No smoking, open
flames, or sparks while
working with batteries.
Contains acid.
Avoid contact Poison. Causes
severe burns. Avoid
contact.
WARNING: Batteries emit hydrogen, which can cause fire or explosion.
NEVER smoke, light a match, or cause a spark during operation or charging.
ALWAYS char
g
e in a well-ventilated area awa
y
from o
p
en flame.
ALL REPAIR SERVICE MUST BE PERFORMED BY AN NSS AUTHORIZED DISTRIBUTOR/
SERVICE STATION USING ONLY NSS ORIGINAL EQUIPMENT PARTS

4
TableofContents
IMPORTANT SAFETY INSTRUCTIONS..................................................................................................................... 2
INTENDED USE........................................................................................................................................................... 2
FOR SAFETY........................................................................................................................................................... 2
IMPORTANT SAFETY INSTRUCTIONS..................................................................................................................... 3
BATTERY POWERED EQUIPMENT....................................................................................................................... 3
GENERAL................................................................................................................................................................. 3
BATTERY INSTALLATION....................................................................................................................................... 3
BATTERY CHARGING............................................................................................................................................. 3
FOR LEAD ACID BATTERIES ONLY...................................................................................................................... 3
MACHINE INSPECTION.............................................................................................................................................. 5
MACHINE COMPONENTS LIST ................................................................................................................................. 5
MACHINE COMPONENTS Figures 1 - 4..................................................................................................................... 6
MACHINE COMPONENTS Figures 5 - 6..................................................................................................................... 7
Joystick Control ........................................................................................................................................................ 7
Horn.......................................................................................................................................................................... 7
Master Key Switch.................................................................................................................................................... 7
E-Stop Switch........................................................................................................................................................... 7
Circuit Breaker.......................................................................................................................................................... 7
Touch Pad Screens.................................................................................................................................................. 8
Pop Up Warnings...................................................................................................................................................... 9
Touch Screen Calibration......................................................................................................................................... 9
MACHINE SET UP..................................................................................................................................................... 10
MACHINE OPERATION............................................................................................................................................. 10
Floor Preparation.................................................................................................................................................... 10
Pre-Operation Check List ....................................................................................................................................... 10
Operating the Machine ........................................................................................................................................... 10
MAINTENANCE......................................................................................................................................................... 11
Daily Maintenance.................................................................................................................................................. 11
Charge the Batteries........................................................................................................................................... 11
Empty and Clean Filter Bag................................................................................................................................ 12
Pad Installation / Changing................................................................................................................................. 12
Weekly Maintenance (Every 25 Hrs)...................................................................................................................... 12
Check the water level in batteries....................................................................................................................... 12
Inspect Flexiwall shield ....................................................................................................................................... 13
Monthly Maintenance (Every 100 Hrs)................................................................................................................ 13
Equalize your batteries (Flooded only)........................................................................................................... 13
Clean the Burnishing Head and Motor................................................................................................................ 13
Inspect the machine............................................................................................................................................ 13
Drain the Battery Tray......................................................................................................................................... 13
90 Day Maintenance (Every 300 Hrs) .................................................................................................................... 14
Lubrication........................................................................................................................................................... 14
Every 6 Months (Every 600 Hours) ........................................................................................................................ 14
Inspect Brush Motor carbon brushes for wear.................................................................................................... 14
Check the condition of the batteries.................................................................................................................... 14
Every 12 Months (Every 1200 Hours) .................................................................................................................... 15
Inspect Drive Motor carbon brushes for wear..................................................................................................... 15
Machine Jacking......................................................................................................................................................... 15
Gas Spring Service .................................................................................................................................................... 15
Pad Pressure Adjustment........................................................................................................................................... 16
Pushing Machine/Parking Brake................................................................................................................................ 17
Storing Machine ......................................................................................................................................................... 17
Transporting the Machine........................................................................................................................................... 17
Battery Installation...................................................................................................................................................... 18
Battery charger ....................................................................................................................................................... 18
Battery Replacement Notes.................................................................................................................................... 19
SPECIFICATIONS...................................................................................................................................................... 22
Machine Dimensions/Capacities/Performance ....................................................................................................... 22

5
MACHINE INSPECTION
Now that the machine is unpacked remember to recycle all packing materials.
Inspect the machine for damage or missing components.
If damage is found, contact the freight company to file a freight claim.
MACHINE COMPONENTS LIST
ITEM#DESCRIPTIONFIGURE
1JOYSTICK1,2,4
2ARMREST1,2
3HORNBUTTON1,2
4SNAPSTUDFORHEADRETAININGSTRAP1
5DRIVEWHEEL1,2
6CASTER1,2
7ATTACHMENTPOINTFORHEADRETAININGSTRAP1
8PADMOTOR1
9HEADLIFTHANDLE1
10FLEXIWALLSHIELD1,4
11FILTERMEDIABAGCOVER1,2
12PADMOTORCOVER1
13FOOTPLATE1
14SEATSLIDEADJUSTMENT1,2
15KEYSWITCH1,2
16SEATWITHSAFTEYSWITCH1,2,4
17E‐STOPSWITCH1,2
18SEATBELT2
19WIRINGDIAGRAM2
209%INCLINE2
21CIRCUITBREAKER2
22NAMEPLATE2
23PROP65WARNING 2
24FILTERMEDIABAG2
25HEADRETAININGSTRAP2
26FLASHINGWARNINGLIGHT1
27BATTERYDISCONECT3
28BATTERYCHARGINGPLUG3
29BATTERYWARNING 3
30SEATPLATELIFTHANDLE3
31PADHOLDER4
32PAD4
33BATTERYTRAYDRAINTUBING5
34BRAKERELEASELEVER5
35TUBINGCONTROLVALVE5
36TOUCHPAD2
PROTECT THE ENVIRONMENT
Please dispose of packaging materials
and used machine components such
as batteries in a safe environmentally
way according to your local waste
disposal regulations.
Always remember to recycle.

6
MACHINE COMPONENTS Figures 1 - 4

7
MACHINE COMPONENTS Figures 5 - 6
Joystick Control
The joystick (Fig. 6 - Detail A - Item 1) controls the direction and speed of the machine.
The joystick also activates the Brush Motor so it is only on when the machine is moving.
The joystick has a safety feature that returns the joystick to the neutral position when the joystick is released.
Horn
The Horn Button (Fig. 6 - Detail A - Item 3) is located in front of the joystick. It is a momentary switch that
activates the horn.
Master Key Switch
The Master Key Switch (Fig. 6 - Detail A - Item 15) is located on the top left side of the control panel and it turns
the machine on and off.
The control system will automatically turn the machine off if it sets idle for 10 minutes. Turned off the master and
brush switch and then turn the master switch back on to restart.
E-Stop Switch
The red E-Stop Switch (Fig. 6 - Detail A - Item 17) is located on the top right side of the control panel and it turns
off all power to the machine in the event of an emergency. The electromagnetic braking system will immediately
engage.
Only use this button in the event of an emergency. It is not intended for routine machine shut down and brake
damage could occur.
Twist the E-Stop and it will pop up and turn the machine on.
Circuit Breaker
There is one master circuit breaker (Fig. 2 Item 21) located below the foot plate.

8
Touch Pad Screens
Splash Screen. Stays on the
screen for nominally two seconds
and then switches to the next
screen.
Seat belt Screen. Always wear
your seat belt when using this
machine. Push OK to continue to
the next screen.
Take care of your batteries
screen. Push OK to continue to
the Main or Home screen.
Main screen.
The service codes will be
displayed under the wrench.
The battery charge level is
represented by the battery. As the
battery is depleted, the number of
colored bars on the battery meter
decreases.
In the pad motor section, there is
a button that turns on and off the
pad motor. The amp meter
correlates to the amp motor
current. Always run in green area.
In the pad pressure section, there are three buttons.
The current setting is indicated by displaying the
button green.
In the drive speed section, there are three buttons.
The current setting is indicated by displaying the
button green.
The buttons at the bottom are the navigation buttons
Home, Clock and Help sections.
Hour Meter screen. This screen
is accessed by touching the clock
icon on the navigation bar at the
bottom. There are three hour
meters. The hour meter values
will be displayed to the right of the
icons.
Push the button with the gears on
it to go to the Supervisor Mode
access screen.
Supervisor Mode Access
screen. Enter the Passcode 1911
to access the Supervisor Mode
screen.
Supervisor Mode screen. The
purpose of this screen is to turn
off buttons not to be used by
operators. When turned off the
button will not appear on the Main
screen. Green buttons will appear
on the Main screen and grey
buttons will be removed from the
Main screen. After the selections
are made push the save button.
The Main screen will appear with
the new settings.
Help screen. This screen is
accessed by touching the help
icon on the navigation bar at the
bottom.
There are three buttons in the
middle of the screen. The Safety
button will take you to the Safety
section, the Operation button will
take you to the Operation section
and the Maintenance button will
take you to the Maintenance
section.
The four buttons at the bottom are the language
buttons. EN for English, ES for Spanish, FR for
French, CN for Chinese.

9
The Safety section appears after
pushing the Safety button on the
Help screen. There are 5 pages
of information. To navigate
through the pages push the arrow
on the right for next page and the
arrow on the left for previous
page. Push the Safety button at
the top to return to the Help
screen. Push any button on the
navigation bar to go to that
screen.
The Operation section appears
after pushing the Operation
button on the Help screen. There
are 14 pages of information. To
navigate through the pages push
the arrow on the right for next
page and the arrow on the left for
previous page. Push the
Operation button at the top to
return to the Help screen. Push
any button on the navigation bar
to go to that screen.
The Maintenance section appears
after pushing the Maintenance
button on the Help screen. There
are 14 pages of information. To
navigate through the pages push
the arrow on the right for next
page and the arrow on the left for
previous page. Push the
Operation button at the top to
return to the Help screen. Push
any button on the navigation bar
to go to that screen or section.
Pop Up Warnings
When the machine is turned on
and any of the following four
functions are out of place, a pop
up warning will appear on the
main Screen.
Pad motor in the up position. No power is
supplied to the pad motor or the drive
motors. The pad motor must be lowered
before the machine will move. This icon will
not appear when the pad motor is lowered.
The electric brakes are not engaged. No
power is supplied to the pad motor or the
drive motors. The electric brakes must be
engaged before the machine will move. This
icon will not appear when the electric brakes
are engaged.
The joystick is not in the center position at
start up. No power is supplied to the pad
motor or the drive motors. The joystick must
be in the center position before the machine
will move. This icon will not appear when the
joy stick is in the center position at start up.
No operator in seat. No power is supplied to
the pad motor or the drive motors. The
operator must be in the seat before the
machine will move. This icon will not appear
when the operator is in the seat.
Touch Screen Calibration
Tap on any screen with two
fingers very quickly until a beep is
heard and the touch screen turns
blue. The first blue screen will
read “Press The Cross Dot
Left_Top”. Tap the +. The next
blue screen will read “Press The
Cross Dot Right_Top”. Tap the +.
The next blue screen will read
“Press The Cross Dot
Right_Bottom”. Tap the +. The
touch screen will be calibrated
and return to the last screen you
were on.

10
MACHINE SET UP
Connecting Battery Pack to Machine
When the machine is shipped with batteries, the
machine will arrive with the battery pack
disconnected from the machine.
Lift up on the back of the seat plate to expose the
battery pack. See Fig. 3 Item 30.
Connect the cable with the Anderson connector
from the battery pack into the Anderson connector
mounted to the inside of the control panel. See Fig.
3 Item 27.
For machines shipped without batteries
See Battery Installation in the Maintenance Section
later in this manual.
Raising and Lowering the Pad
The Foot Plate (Fig. 1 Item 13) must be in the up
position to raise the pad head into the pad change
position. See Fig. 4.
Move the front of the machine from/to pad
changing position or operating position by grasping
the handle (Fig. 1 Item 4) on the front and moving
it to the desired position.
Pad Installation / Changing
See daily maintenance for Pad Installation and
Changing.
Empty and Clean Filter Bag
See daily maintenance for Filter Bag maintenance.
Seat Slide Adjustment
Grasp the lever (Item 14) on the left side of the seat
(Item 16) and move it towards the outside of the
machine to move the seat.
Position the seat in a comfortable operating
position and release the lever to lock the seat in
place.
Seat Belt
The seat belt on the left side of the seat is
retractable and the seat belt on the right side is
stationary. (Item 18)
Grasp the left side and pull out and fasten into the
right side.
Push the button to release.
MACHINE OPERATION
Floor Preparation
Make sure the floor has adequate floor finish.
Burnishing results will be poor if the floor finish is in
poor condition.
Dust mop and scrub the floor before burnishing.
Check that floor surface is clean and dry.
Pre-Operation Check List
Be sure you understand the operator controls and
their functions. See the Machine Components and
Touch pad sections of this manual.
Make sure all safety devises and machine controls
are working correctly.
Check that the battery pack is connected to the
machine.
Check that a new or clean pad is installed.
Check that the filter bag is clean, zipped all the
way up and installed properly.
Operating the Machine
Step onto the machine from the right side and sit in
the seat.
Adjust the seat to a comfortable operating position.
Fasten the seat belt.
Turn the key switch to the ON (I) position. Wait
until you hear a click, and the Fasten the Seat Belt
screen is shown. Push OK and the Battery Screen
is shown. Push Ok and the main screen will
appear.
Main Screen The service codes will be
displayed under the wrench.
The battery charge level is
represented by the battery. As the
battery is depleted, the number of
colored bars on the battery meter
decreases.
In the pad motor section, there is
a button that turns on and off the
pad motor. The amp meter
correlates to the amp motor
current. Always run in green area.
In the pad pressure section, there are three buttons.
The current setting is indicated by displaying the
button green.
In the drive speed section, there are three buttons.
The current setting is indicated by displaying the
button green.
The buttons at the bottom are the navigation buttons
Home, Clock and Help sections.
Check that the battery meter is reading in the high
or green range. The machine should be put on
charge if not in the high range. See Daily
Maintenance, Charge the Batteries for more
information.

11
Turn on brush switch located in the Pad Motor
Section of the main screen.
Select pad pressure. The pad pressure will be set
on low when the machine is first turned on. Always
start in low pressure and add pressure as
necessary.
Select the desired burnishing or drive speed. The
drive speed will be on low when the machine is first
turned on. NSS recommends using slow or
medium speed for burnishing. High speed is for
transporting the machine only.
Burnishing the floor
Move the joystick forward to activate the Pad and
Drive Motors. Note: The further the joystick is
moved from center the faster the machine will go.
Always move the joystick slowly to avoid sudden
machine movements.
To maneuver the machine, point the joystick in the
desired direction.
Drive the machine at a speed that produces your
desired burnishing results. Note: It is possible to
drive too fast and reduce the machines
performance.
Drive the machine in a straight path and overlap
the burnishing path by a few inches.
Avoid any floor fixtures or uneven floor transitions
that may damage the pad, pad driver or dust skirt.
Avoid bumping the machine into posts or walls.
For heavily scuffed floors reduce the speed to
ensure optimum burnishing performance.
Pay attention to the AMP meter in the Pad Motor
section of the Main screen. Always run the pad
motor in the middle of the green area. Never run in
the red area.
Bring the machine to a complete stop before getting
off. Operator injury and or machine damage could
occur.
Always remove the key when leaving the machine
unattended.
CAUTION: This Machine must be moving
at all times when the pad is rotating or the
floor may be damaged.
MAINTENANCE
ALWAYS turn OFF the Key Switch and
remove the key before performing any
maintenance or repairs to this machine.
FOR SAFETY: When servicing equipment,
wear appropriate personal protection
equipment as needed.
FOR SAFETY: When servicing batteries,
wear appropriate personal protection
equipment as needed. Avoid contact with
battery acid.
If contact with battery acid occurs:
Skin – Rinse with cold water for 15 minutes.
Eyes – Flush with cold water for 15 minutes.
Internal – Drink lots of water or milk. Seek medical
attention immediately.
Daily Maintenance
Charge the Batteries
Park the machine in a well ventilated area.
Recharge the batteries every day or when
indicated by the Battery Meter.
NEVER let the batteries sit overnight after the
machine has been run for 1hr or more.
NEVER let the electrolyte level fall below the tops
of the plates. This will damage the batteries
immediately, and void the warranty.
Check charger cords for exposed wires and
damaged plugs before using.
To recharge the batteries, connect the charger cord
with the Anderson connector into the Anderson
connector on the machine under the seat plate.
Plug the battery charger into an electrical outlet.
Charge the batteries with the Seat Plate open.
Important: It can take up to 16 hours to charge the
batteries. Be sure to allow plenty of time for
charging to avoid damaging your batteries.
See charging instructions for more details.

12
Empty and Clean Filter Bag
Tilt the filter bag cover forward to expose the filter
bag. (See Fig 2 Item 11.)
Remove the filter bag. (See Fig 2 Item 24.)
Empty the filter bag daily or when it is
approximately one-half (1/2) full.
Pad Installation / Changing
There is a wide range of pads available for many
different burnishing applications. Consult your local
NSS authorized distributor for application
recommendations.
Park the machine on a level surface.
Lift the front of the machine up to the 90 degree
position to view the pad driver and pad.
Make sure that the correct pad (15/16" to 1" [22mm
to 25.4mm]) X 27" [68.6 cm] is being installed.
Remove the center hole of the pad and place the
pad flat on the floor. Step on the center of the pad
to compress the edges around the center hole.
This allows for easier installation of the pad
centering cup.
With the machine in the pad changing position,
carefully center the pad on the driver.
Caution: Pads must be installed concentric
(evenly aligned) with the outside edge of the
pad driver. Failure to follow these
precautions will cause excessive machine
vibration, a reduction in pad life and produce
unsatisfactory burnishing results.
Place the pad grabber in the center hole of the pad
and push on the pad grabber until the spring clip
has clicked twice.
Caution: Failure to install the pad grabber
tightly may allow the pad grabber and/or pad
to be thrown from the driver.
Never: Leave the machine sit with a
used pad installed. This can cause the
pad driver to warp.
Weekly Maintenance (Every 25 Hrs)
Verify all daily maintenance has been performed.
Check the water level in batteries
Check the water level in each of the three cells in
each battery and add distilled water as required to
level specified by battery manufacturer.
Check and verify that all battery connections are
clean and tight.
Wipe machine down with a damp cloth.
NEVER spray this machine with water or any
liquids.

13
Inspect Flexiwall shield
Inspect the Flexiwall Shield for dents around the
outside edge and cracks in the plastic.
Check that the Brush and Retaining Band are
properly installed.
Remove dirt build up on the brush along the
bottom of the Flexiwall Shield.
A damaged Flexiwall Shield Assembly will greatly
reduce dust control capabilities of the machine.
Monthly Maintenance(Every 100 Hrs)
Verify that all daily and weekly maintenance has
been performed.
Equalize your batteries (Flooded only).
The batteries should be equalized once every 30
days for maximum battery runtime and life.
To equalize the batteries:
Plug in the charger, and fully charge the batteries.
Unplug the charger from the wall outlet, then plug it
back in.
The charger will run holding the batteries at a
constant voltage, and equalizing each cell.
Clean the Burnishing Head and Motor
With compressed air, blow any dust and buildup
from the burnishing head and motor.
Maximum air pressure 100 PSI.
Wipe down with damp cloth.
Inspect the machine
Inspect the machine components for wear, loose
fasteners, or damage. Pay special attention to all
pivot points and moving parts.
Call an authorized NSS service center for repairs.
Drain the Battery Tray
Check the Battery Tray Drain Hose located under
the machine for liquid level on a monthly basis.
Spilled liquids from the battery compartment area
are collected in a tray under the batteries. The tray
can be drained using the hose under the machine
as shown above.
IMPORTANT: Drain all liquids into an approved
container and dispose of according to your local
and federal regulations.

14
90 Day Maintenance (Every 300 Hrs)
Verify that all daily, weekly and monthly
maintenance has been performed.
Lubrication
Lubricate the caster swivels with an industrial
grade bearing grease. Failure to lubricate casters
will cause the machine to maneuver with difficulty.
The caster wheel has a sealed bearing and does
not need to be greased.
Lubricate all moving parts as required with a small
amount of grease.
DO NOT lubricate the Gas Spring shaft, it does not
require lubrication as it is self-lubricating.
Every 6 Months (Every 600 Hours)
Call your Authorized NSS Distributor / Service
Station to have the following services performed.
Verify that all daily, weekly, monthly and quarterly
maintenance has been performed.
Inspect Brush Motor carbon brushes for
wear.
Using compressed air, blow the accumulated
carbon brush dust out of the motor.
Replace carbon brush when they measure ½”
[12.7mm] or less in length.
Failure to replace carbon brushes will cause poor
machine performance and possible motor damage.
Check the condition of the batteries.
A battery may be checked using a Hydrometer to
check the specific gravity (strength) of the acid in
each cell. Variations in readings occur due to the
chemical reaction taking place during use.
Always check the specific gravity when the battery
is fully charged.
Replace batteries as needed.

15
Every 12 Months (Every 1200 Hours)
Call your Authorized NSS distributor / Service
Station to have the following services performed.
Verify that all daily, weekly, monthly and quarterly
maintenance has been performed.
Inspect Drive Motor carbon brushes for wear.
This will require removing the drive motor from the
machine and should only be done by an authorized
NSS Service Station.
Using compressed air, blow the accumulated
carbon brush dust out of the motor.
Replace carbon brush when they measure ½”
[12.7mm] or less in length.
Failure to replace carbon brushes will cause poor
machine performance and possible motor damage.
Machine Jacking
Use the jacking locations as shown in the pictures
above. Use a jack and or jacks capable of supporting
the weight of the machine. Position the machine on a
flat level surface and block the wheels. Two jacks are
required for rear wheel removal, one on each side.
Gas Spring Service
ALWAYS secure Brush Head in the pad change
position using the strap provided before
attempting any maintenance or repairs to the gas
spring or coil spring assemblies.
Remove the spring clip that secures the gas spring
to the machine. Then pull the gas spring off of the
ball stud. There is a clip and ball stud at each end.
Place one end of the gas spring against a hard
surface and push on it. If you can compress it, it
must be replaced. If you cannot compress it, it is
most likely OK.

16
Pad Pressure Adjustment
The NSS eForce Burnisher is preset at the factory
for medium duty applications. It can be tuned to
your specific application for optimum
performance.
ONLY an authorized NSS Service Station should
perform this adjustment.
Tools required for Pad pressure adjustment
1) ¾ open end wrench
Set the pad pressure in
the middle of the amp
meter
Checking the Pad Motor Amperage
First install a new pad on the pad driver.
Caution: Checking the Amps with a used
pad will cause the machine to have high
amps when a new pad is installed.
Lower the Pad Motor into the operating position.
Turn on the Pad Motor switch and leave the Pad
Pressure on the low setting.
While running the machine, read the amp meter in
the Pad Motor section on the Main screen. The
amp meter should be reading in the middle of the
green area of the amp meter.
If adjustment is required, follow these
instructions.
It will be easier to access the lock nut and spring
guide rod assembly with the machine in the pad
change position.
First loosen the lock nut on the spring guide. With
the lock nut loose, the spring guide rod assembly
will be easily turned by grasping the set collar on
the spring guide rod.
Turn the spring rod guide assembly ½ to 1 turn at a
time. A little adjustment goes a long way.
Thread the spring guide rod assembly out of the
ball joint to decrease the pad pressure. Thread the
spring guide rod assembly into the ball joint to
increase the pad pressure.
Every time an adjustment is made check the amps.
This may require a few tries to get the Pad
Pressure were it should be.
After the adjustment is made tighten the lock nut
and redo the test. If it has not changed the process
is complete.
Fall back setting 
If your machine has come totally out of adjustment, or
you need to replace the Spring Rod Guide Assembly
you may need to start from the beginning.
The factory starting setting for the pad pressure is
3/4 of an inch [19mm] from the set collar to the lock
nut.
From this setting, proceed with the Pad Pressure
Adjusted.

17
Pushing Machine/Parking Brake
In the event the eForce Burnisher needs to be
pushed, the brakes need to be released. At the rear
of the machine, reach under the drive motor mount
and find two openings. In the left opening, reach
inside and pull the lever back. In the right opening,
push the lever forward. Now the machine can be
pushed.
If the operator tries to drive the machine with
the brakes disengaged the machine will not
move. The brake icon will appear in the pad
motor section of the main screen along with a
3A code in the service box.
To engage the brakes, push the lever forward in the
left opening, pull the lever back in the right opening.
Turn the machine off then back on the clear the
service code. The machine is now ready for use.
Storing Machine
The following steps should be taken when storing the
machine for extended periods of time.
Park the machine on a flat level surface.
Park the machine in a cool, dry area. Do not
expose to rain. Store indoors.
Raise the burnishing head into the pad change
position.
Remove the batteries, or charge them every three
months.
Transporting the Machine
When transporting the machine by use of trailer or
truck, carefully follow the loading and tie down
procedures:
Raise the burnishing head to the transport position
and secure the strap. Caution: Be sure the pad
motor is in the off position before moving the
machine. The pad motor can run in this position.
Load the machine using a ramp that can support
the weight of the machine and operator. Caution:
Do not attempt to climb a ramp or incline that
exceeds a 13% (7.41 degrees) grade level. A
winch must be used when incline exceeds a 13%
grade level.
Once loaded, turn off the key switch.
Block the rear wheels front and back.
Secure the front and back of the machine with tie
down straps. Put the tie down straps in the pallet
bracket holes on each side and run them forward
to prevent the machine from twisting in transit.
From the rear of the machine, run one tie down
strap around the machine just above the foot plate
and back behind the machine. This will prevent the
machine from moving forward and backward
during transit.

18
Battery Installation
FOR SAFETY: When servicing batteries,
wear appropriate personal protection
equipment as needed. Avoid contact with
battery acid.
Turn off all switches. Disconnect battery pack from
the machine.
Remove the rear panel.
There are two nuts (one in each corner) on top of
the rear panel inside the battery compartment and
three screws at the outside bottom of the cover.
Tip the cover back and then lift up on an angle.
Batteries are heavy – ALWAYS use two people to
install batteries into machine.
Refer to wiring diagram located on the underside of
the seat plate. Align batteries in compartment the
same as the old batteries or as shown on diagram.
Install battery cables the same as they were on the
old batteries or as shown on wiring diagram.
NSS recommends replacing the battery cables
when replacing batteries.
Tighten bolts and hex nuts with a wrench.
Install terminal boots over terminals to complete
installation.
CAUTION: Do not short across two terminals
with a wrench.
CAUTION: Loose or improper battery
connections will cause battery or machine
damage and possible personal injury.
Battery charger
The battery charger supplied with this machine is
capable of charging lead acid batteries from 350 to
435 ah capacity.
Your machine may have been ordered with batteries
installed at the NSS factory. The standard battery
type, normally supplied by NSS, is the Flooded (wet)
cell lead acid battery. AGM sealed batteries may also
be available at customer request.
Flooded (wet) batteries can be easily identified by the
removable cell caps. Removing the caps allows
inspection of the liquid electrolyte (sulfuric acid) level
in each cell.
AGM (Absorbed Glass Mat) batteries are sealed,
maintenance free batteries. They do not have cell
caps intended for removal. Look for “AGM” printed
on the tops or sides of the batteries.
Gel (gelled electrolyte) batteries are not
recommended for use with this machine.

19
Operating the Battery Charger
The battery charger is fully automatic. Simply plug
the charger into a suitable wall outlet, and the
charger will charge the batteries. The amp meter on
the right side will start with high amp output and drop
to 0 when complete.
A bubbling, or boiling sound coming from the
batteries during the last few hours of the charge is
normal. The batteries may be warm, but not too hot
to touch.
Equalizing the batteries (Flooded only)
The batteries should be equalized once every 30
days for maximum battery runtime and life.
To equalize the batteries:
Plug in the charger, and fully charge the batteries.
Unplug the charger from the wall outlet, then plug it
back in.
The charger will run holding the batteries at a
constant voltage, and equalizing each cell.
Opportunity Charging
Opportunity charging is charging the batteries when
an opportunity presents itself, such as during breaks,
and is done in addition to a full charge cycle. This
extra charging time will help raise the operating
voltage of the batteries, and will help ensure
maximum runtime and cycle life.
See Operating Battery Charger Instructions or
Monthly Maintenance for equalizing your
batteries especially if you have been opportunity
charging your machine.
Battery Replacement Notes
Entire Pack.
oIt is always recommended to replace all batteries
in the pack at the same time.
Replacing just one or two batteries out of the pack
can lead to the following:
Overcharging the new, or the remaining
original, batteries.
Undercharging the new, or remaining
original, batteries.
Over discharging either the new or the
remaining original batteries.
oIf you wish to only replace some of the batteries
in the pack, follow these steps for best results:
Replacement batteries must always be of the
same battery manufacturer, model and amp-
hour rating, as the remaining batteries in the
pack.
Never mix batteries from different
manufacturers in the same pack.
Fully charge both the new battery, and the
remaining original batteries. (s.g. = 1.265
minimum, use a hydrometer)
Use a replacement battery that is close to the
same age as the remaining original ones.
Do not run the machine as long for about 20
cycles. For example, if you used to get 3 hrs.
run time, only run it for 2 hrs., and then
charge the batteries completely.
Opportunity charge whenever possible.
Equalize after 30 days (Flooded only).
The above steps will provide the best
opportunity for the new battery(s) to join the
pack.
Battery Do’s and Don’ts:
a. You do not have to fully discharge the batteries
before charging. They do not have a “memory”.
b. Plug the charger in anytime the machine is not in
use.
c. NEVER let the electrolyte level fall below the tops
of the plates (flooded cell batteries). This will
damage your batteries almost immediately, and
void the battery warranty. They can tell if this
happened.
d. NEVER refill the batteries with well or tap water
(flooded cell batteries).
e. NEVER overfill the batteries (flooded cell
batteries).
f. NEVER let the batteries sit discharged overnight
(or between shifts).
g. ALWAYS check the electrolyte level about every 3
or 4 charge/discharge cycles BEFORE
CHARGING.
h. ALWAYS refill the batteries with distilled water (if
needed) AFTER CHARGING.
i. ALWAYS fully recharge the batteries after use.
j. ALWAYS equalize the batteries (Flooded only)
every 30 days.
k. NEVER OVER DISCHARGE!
l. NEVER charge GEL batteries.
If contact with battery acid occurs:
Skin – Rinse with cold water for 15 minutes.
Eyes – Flush with cold water for 15 minutes.
Internal – Drink lots of water or milk. Seek medical
attention immediately.

20
TROUBLE SHOOTING CHART
Problem Cause Solution
Machine will not turn on.
Battery pack is not plugged into machine. Open the battery cover and plug the battery
pack into the machine.
Battery charger is plugged into AC outlet. Unplug the battery charger.
The 2 amp fuse is missing or blown. Replace 2 amp fuse.
Circuit breaker is tripped. Reset circuit breaker.
Brush motor will not run
or stopped running.
Current over load of brush motor has exceeded
set parameters in control system.
Turn off all switches and then turn on the
master switch to reset the control system. If the
problem continues check battery meter for fault
code F42.
Tilt switch failure. Check tilt switch operation. Replace tilt switch if
test failed.
Carbon Brushes worn or not making contact. Have an authorized NSS Service Station check
carbon brushes and replace if necessary.
Brush motor will not turn
off when joystick is in
neutral.
The potentiometers are set on the threshold of
neutral or potentiometer has failed. Have an authorized NSS Service Station reset the potentiometer to neutral or replace joystick.
Machine vibrates. Pad not centered or torn. Center pad. Change torn and worn pad.
Low Run Time
Damaged or defective battery or battery pack. Have an authorized NSS Service Station check
the batteries and replace as necessary.
Batteries are not fully charged Charge batteries until the charge cycle is
complete.
Running machine with pad pressure too high. Reduce pad pressure when running pad motor.
Battery charger will not
turn on.
Battery charger cord damaged. Check for cord damage and replace if
necessary. DO NOT try to repair it.
Connection not made between battery charger
and battery pack. Check connections at battery pack for corrosion and loose or broken wires.
The battery charger is damaged. Have an authorized NSS Service Station check and replace if necessary. DO NOT try to repair
it.
Pad will not stay in the
pad change position. Weak or missing gas spring(s). Check and replace if necessary.
Pad will turn on in the
pad changing position. Tilt switch failure. Replace tilt switch as necessary.
Circuit breaker trips.
Spray Buffing. DO NOT spray buff.
Pad pressure to heavy. Check gas springs for failure and replace as
necessary.
Pad pressure collars out of adjustment. Readjust pad pressure collars as required by
your burnishing conditions.
Front of machine does
not move down to the
floor when turned on. Spring guides sticking in slides.
Check spring guides for proper operation.
Replace if bent. Lubricate if necessary. Loosen
bolts in spring guide mounting bracket, it will
self-align, retighten bolts.
