NSS PREDATOR CXC100 User manual

PREDATOR CXC100
IMPORTANT SAFETY INSTRUCTIONS
READ AND UNDERSTAND ALL INSTRUCTIONS
BEFORE OPERATING OR SERVICING MACHINE
DANGER!
Failure to ObserveThese Instructions Can Cause Personal Injury
to Machine Operator, By-standers or Possible Machine Damage.
SAVE THESE INSTRUCTIONS
•NEVER attempt to service or perform maintenance functions while machine is plugged into an electrical
outlet.
•ALWAYS unplug machine before attempting to service the motorized brush attachment.
•NEVER operate in standing water. NEVER expose to rain. ALWAYS store indoors.
•NEVER overfill recovery tank or allow water to enter vacuum standpipe.This will cause damage to the
vacuum motor and possible electrocution.
•NEVER operate machine with a cut, abraded or taped cord.
•NEVER operate machine with a broken grounding blade on the plug.
•ALWAYS replace the entire cord when the cord or plug is damaged in any manner.
•NEVER handle the machine, cord or plug with wet hands.
•NEVER drop or insert any object into any machine opening.
•ALWAYS keep face, fingers, hair or any other body part, or loose clothing away from any machine
opening or any moving part, particularly the revolving brush.
•NEVER leave the machine unattended when plugged in. Unplug the machine from the electrical outlet
when not in use.
•ALWAYS turn the machine off before unplugging it from the electrical outlet.
•NEVER operate this machine in the presence of flammable or combustible liquids or fumes.
• When any electrical motor, switch, cord or plug service is required, maintenance should only be done by
an authorized service station, an electrician or other qualified persons.
•NEVER operate this machine if it is not working properly, if it as been dropped, damaged, exposed to
weather, or dropped into water. Return the machine to a service center for examination and repair.
•NEVER operate this machine with any air opening blocked. Keep all air openings free of dust, lint, hair,
ect.
•NEVER operate this machine without solution tank filter screens or vacuum standpipe filter screen in
place or if they are clogged. Clean all filter screens after every use.
•ALWAYS store this machine indoors. Protect it from rain or snow.
•NEVER spray the top of the machine with liquids.
•DO NOT pull or carry this machine by the electrical supply cord, use the cord as a handle, close a door on
the cord, pull the cord around sharp edges or corners, or expose to heated surfaces.
•NEVER disconnect the plug by pulling on the cord.To disconnect the cord from the outlet grasp the plug,
not the cord.
•ALWAYS unplug this machine before attempting to service.
•ALWAYS use a defoamer which will prevent a buildup of foam in the recovery tank. If a defoamer is not
used, the motor can be damaged from shampoo being pulled into the vacuum motor.
https://harrissupplyind.com-ToOrderPartsCall608-268-8080

INFORMATION & OPERATING INSTRUCTIONS
DO NOT OPERATE MACHINE UNTIL YOU HAVE READ THIS SECTION
IMPROPER USE OF THE PREDATOR CXC100 WILL VOID THE WARRANTY
1. Always use defoamer when foaming occurs to prevent vac motor damage.
2. To keep fitting and lines from damage during freezing conditions, use an
anti-freeze in the pump or keep equipment inside heated areas.
3. All extension cords must be at least size #12 (12/3) and no longer than 50 ft.
4. Do not let pump run dry.
5. Use neutral pH, water-based products only - NO SOLVENTS!
INSPECTION:
Carefully unpack and inspect the PREDATOR CXC100 for shipping damage. Each unit is tested
and inspected before shipment. Any damage incurred during shipping is the responsibility of
the carrier, who should be notified immediately.
CLEANING SOLUTIONS:
We recommend liquid cleaning chemicals. Powders may be used, but unless mixed very
thoroughly, they could cause build-up in the lines, pump, quick-disconnects, etc. A pH of 7-9 is
strongly recommended to avoid premature pump wear, which would void the warranty.
MAINTENANCE:
For optimum performance, flush the machine with clear water at the end of each working day.
Once a month, minimum, run a flushing compound through the machine to cut any alkaline
build-up that may have formed.
Lubricate wheels, casters and hinges as needed. The pump and vacuum motors do not require
any maintenance.
The body can be cleaned with a general all-purpose detergent and protected with a silicone
type product like Armor All®.The quick-disconnects should be lubricated with silicone, also.
Prior to each job, inspect the holding tank filter and the recovery tank float filter for hair and dirt.
The drain valve should also be inspected regularly and kept free of any debris or build-up.
https://harrissupplyind.com-ToOrderPartsCall608-268-8080

SET-UP:
Fill the holding tank with clear water and add the detergent of your choice. Mix well. Plug in the
electrical cord and turn on the pump and vacuum switches.You are now ready to begin cleaning.
PUMP OPERATION:
The 100 PSI-pump is a "demand" type design. The pump runs only when you depress the lever
on your wand. When you release the lever the pump shuts off.
VACUUM OPERATION:
A switch is provided for each vacuum motor.The machine can operate on either one or two vac
motors. A patented vacuum manifold reduces the oscillations between the two vacuum motors in
series, thereby increasing the efficiency and life of the vacuum motors.
BALL FLOAT VAC SHUTOFF:
When the recovery tank is full, the float system will shut off the incoming air flow and prevent
water from entering the vacuum motors. The float may not work properly if the float filter is
clogged or if there is heavy foam in the tank.
CAUTION:To avoid vac motor damage, a
lways make sure the float filter is clean and the ball
travels freely before turning on the machine. U se a defoamer whenever foam is present.
DOME (RECOVERY TANK)
VAC INTAKE
DRAIN VALVE
LIFT HANDLE
QUICK-DISCONNECT
LATCH (2)
3" CASTORS
8" WHEELS
HOLDING TANK LID
VENT
SWITCH PLATE
https://harrissupplyind.com-ToOrderPartsCall608-268-8080

ITEM # PART # DESCRIPTION ITEM # PART # DESCRIPTION
#1 4091011 Metal “T”Handle
#1A 4091231 Drain Gate
#2 4090581 Screw, 10-32 X 5/8, S/S
#3 4091251 Latch
#4 4091161 O-Ring, Thin
#4A 4091171 O-Ring, Thick
#4B 4090701 Nut, Cast Aluminum
#5 4091661 Vacuum Tank, Black, specify model
#6 4091241 Hose Barb, 1-1/2”
#7 4091291 PVC Elbow, 1-1/2”
#8 4091391 Gasket, for Vacuum Dome
#9 4091581 Vacuum Dome
#10 4091571 Vac Shut-off, manifold Assy.
#10A 4091501 Ball & Cage
#11 4090701 Nut, Cast Aluminum
#12 4091171 O-Ring, Thick
#13 4091291 PVC Elbow, 1-1/2”
#14 4091121 Hose Clamp, size 28
#15 4091551 Hose, Rubber, 2”X 20”
#15A 4091561 Hose, Rubber, 2”X 16”
#16 4091211 Vacuum Motor, 2-stage, 120V
4092101 Vacuum Motor, 2-stage, 240V
#16A 4091431 Gasket, Vac Motor
#17 9120900 1/4-20 Hex Nut w/ Ny-Lok
#18 9120930 3/16 Flat Washer, ZP
#19 4090621 1-1/4-20 X 3-1/2”Hex Bolt
#19A 9120920 1/4”Hex Nut, Finish
#19B 9120880 1/4 Split Lock Washer
#20 4091181 Split Ring
#21 4091631 Stop Chain, 13”
#22 4091651 Manifold, Vacuum, #3 or #4
#22A 4091651 Manifold, Vacuum, #3 or #4
#23 4091411 Exhaust Flange
#24 4090601 1/4-20 X 3/4”Screw, Flathead Phillips
#25 4091401 Handle, Chrome
#26 4091031 Quick Disconnect, male, 1/4 p.t.
#27 9122470 Washer, Brass, 1”X 9/16 ID X 1/16”
#28 4091311 Louver, 3”(includes 3 screws)
#29 4091261 Latch Strike
#30 4091511 Base, CXC & CXH (specify)
#31 4091351 Castor, 3”Swivel
#31A 9120900 1/4 Hex Nut, Ny-Lok, ZP
#32 4090611 1/3-20 X 3/4”Hex Bolt, ZP
#33 4091141 Axle Bracket
#34 9120900 1/4 Hex Nut, Ny-Lok, ZP
#35 4091361 Wheel, 8 inch, non-marking
#36 4091021 Axle Cap
#37 4091271 Axle, 1/2”X 18-13/16”
#38 4091331 PVC Reducer
#39 4091641 Holding Tank
#40 4091191 Filter, Pump Inlet, 40 Mesh, S/S
#41 4091601 Lid, with hinges and Label
#42 4090101 Switch Plate, (empty) CXC100
#42A 4090511 #4 X 3/8”Screw, Panhead, S/S
#43 4091041 Switch, SPST, Covered, w/light
#43A 4091041 Switch, SPST, Covered, w/light
#43B 4091041 Switch, SPST, Covered, w/light
#44 4091381 Pump, 100 PSI, 120V
4092121 Pump, 100 PSI, 240V
4091481 Rebuild Kit for 100 PSI pump
#45 4091131 Hose Clamp, 3/8-7/8
#46 4091101 Hose Barb & Elbow, plastic
#47 4091531 Hose, Rubber, 3/8 X 13”
#48 4092041 Hose, Rubber, 3/8”X 22”
#49 4091441 Fan, Cooling, 100CFM, 120V
4092131 Fan, Cooling, 100CFM, 240V
#50 4091451 Fan Guard
#51 4090541 6-32 X 2”Screw, Panhead, S/S
#52 4090531 6-32 Hex Nut, Ny-Lok, ZP
#53 4091521 Cord Wrap, Black
#54 1391161 Washer, Plastic, 5/8OD X3/8ID X 1/16
#55 4090671 3/8 Acorn Nut, Nickel Plated
#56 4090061 Label, CXC100, NSS
#57 4091081 Elbow, Brass, Street
#58 4093011 Hose Barb, 1/4 mpt X 3/8 hose
#59 4091611 Gasket
NOT SHOWN
4090251 Power Cord, 120V
4090261 Power Cord, 240V
PREDATOR CXC100
PARTS LIST
https://harrissupplyind.com-ToOrderPartsCall608-268-8080

PREDATOR CXC100
PREDATOR CXC100
4A
5
7
8
9
12
14 15
14
15A
21
14
20
18
17
16
16A
22
19
19B
19A
19
16A
22A
19B
19A
18
17
16
25
24
26 27
28
29
37
35
36
34 33
32
32
30
31
31A
23 14
41
42
42A
43A
43B
43
52
56
59
64B
1A
14
4B
2
3
51
50
49
39
40
54
55
13
10 11
10A
53
38
57
45
45
44
46
46
47
48
58
28
28
https://harrissupplyind.com-ToOrderPartsCall608-268-8080

COMMON STAINS AND CLEANINGTREATMENTS
TREATMENT METHODS
First: Remove excess material by blotting to absorb liquids, or by scraping with a dull edge
(butter knife) is a solid.
Second: Clean the remaining stain as directed by the chart below. Always follow the direction
on the container. Apply the cleaning material directly to the stain (avoid over wetting
the carpet or upholstery), then remove the loosened stain material with a white ab-
sorbent cloth or tissue.
Third: When the carpet is dry, gently brush the carpet pile to restore its appearance.
Note: Treat unknown stains with a volatile solvent first and follow with other agents as re-
quired. If you are uncertain of the effect of the cleaning agent on the carpet fiber or
dye, test on an inconspicuous area first.
STAINTYPE TREATMENT MATERIAL
Asphalt Volatile solvent/detergent
Beer Liquid detergent, White vinegar
Berry stain Liquid detergent, Ammonia 3-6%, Water
Bleach Liquid detergent, Water
Blood (dried) Warm detergent, Ammonia 3-6%, Water
Blood (wet) Liquid detergent, Water
Butter Volatile solvent
Catsup or Mustard Liquid detergent
Chewing gum Volatile solvent
Chocolate Liquid detergent, Ammonia water
Coffee Detergent, White vinegar, Volatile solvent
Cola drink Liquid detergent
Creme de Menthe (green) Liquid detergent
Egg (raw) Liquid detergent
Food dye Liquid detergent, Water
Furniture dye or polish Paint/Oil/Grease remover, Detergent
Gravy Liquid detergent
Lipstick Paint/Oil/Grease remover
Mascara Paint remover, Volatile solvent, Detergent, Water
Milk Liquid detergent
Orange drink Liquid detergent, Water
Shoe polish Heated iron into clean towel, Volatile solvent
Tea Liquid detergent
Tomato Juice Liquid detergent
Urine Liquid detergent, Water
Vomit Warm detergent, Water, White vinegar
Wine Liquid detergent, Ammonia 3-6%, Water,Vinegar
https://harrissupplyind.com-ToOrderPartsCall608-268-8080

PREDATOR CXC100
WIRING DIAGRAM
120V & 240V
()
6/13/01
FAN
SW
SW
BLACK
BLUE
WHITE
VAC 2
VAC 1 SW
ORANGE
ORANGE
WHITE
BLACK
GROUND
WHITE
VACUUM
VACUUM
PUMP
CORD 1
*NOTE: Switches
sit upside down in
switch plate.
https://harrissupplyind.com-ToOrderPartsCall608-268-8080

NSS Enterprises, Inc.
3115 Frenchmens Road, Toledo, Ohio 43607
PHONE [phone] •FAX [phone]
NSS®Enterprises, Inc. European Distribution Centre
Unit II, Pinfold Trading Estate 55 Nottingham Road
STAPLEFORD, NOTTINGHAM NG9 8AD ENGLAND U.K.
PHONE: [phone] FAX: [phone]
PREDATOR CXC100 ORIG. 05-00 9094002 WHW REV. B 08-01
