NTI XTENDEX 600 Foot HDMI and IR Extender
2
ST-C64K-300 Features:
•Transmits an uncompressed high speed HDMI signal over one CATx cable.
•Supports Ultra HD 4Kx2K resolutions to 3840x2160(30Hz) 2K resolutions to 2048x1080, HDTV resolutions to 1080p and
computer resolutions to 1920x1200.
•Supports embedded digital audio through HDMI compatible TV’s or audio receivers.
•HDMI features supported:
oHDMI 1.4
ox.v.Color, sYCC601 color, Adobe RGB Color and Adobe YCC601 color
oDolby TrueHD, DTS-HD Master Audio, Dolby Digital, and DTS
oBandwidth up to 340MHz (10.2Gbps)
oSupport for CEC (consumer electronic control) compatible devices.
oLip Sync
•HDCP compliant.
•Supports the DDC2B protocol.
•High quality, rugged steel construction with durable powder coat finish.
•Only one power supply is necessary. (Power supply can be connected to either the local or remote unit.)
•Full Infrared Remote (IR) control of HDMI source from remote HDTV using existing source remote control.
MATERIALS
Materials Included with ST-C6HD-HDBT/ST-C64K-300 kit:
9NTI XTENDEX Local Unit
9NTI XTENDEX Remote Unit
91-HD-3-MM 3 foot male-to-male HDMI video cable
91-RCA-3-MM 3 foot male-to-male RCA cable (ST-C6HD-DA-HDBT and ST-C6HDA(E)-HDBT models only)
91- SA-3-MM 3 foot male-to-male 3.5mm stereo audio cable (ST-C6HDA(E)-HDBT models only)
91-100VAC to 240VAC at 50 or 60Hz-24VDC/1.0A AC Adapter (NTI#PS4202) (NOT included with ST-C6HD-HDBT-12VNPS)
91- Power Cord- country specific (NOT included with ST-C6HD-HDBT-12VNPS)
93 Foot IR-EMITTER (IR-EMTR-3)
93 Foot IR-RECEIVER (IR-RCVR-3)
92.1x.5.5mm DC Plug with 36” Lead (ST-C6HD-HDBT-12VNPS only)
9This manual
Additional Materials Included with ST-C6HDE-HDBT kit:
9CT6182 DB9 Female-to-RJ45 Female adapter
9CT6488 DB9 Male-to-RJ45 Female adapter
92-CB4352 5 foot RJ45-to-RJ45 CAT5 patch cable
Additional materials may be required but are not supplied:
¾CAT5e solid UTP ; 6/6a solid UTP; CAT6a solid UTP 23AWG; /CAT7 solid STP 23AWG (CATx) twisted-pair cables
terminated with RJ45 connectors wired straight thru- pin 1 to pin 1, etc. (see page 14 for proper EIA/TIA 568 B wiring method)
¾HDMI male-male cable to connect a HDMI source or display (Order NTI # HD-xx-MM where xx=3, 6, 9,14,20,30, 50 and 100
foot cable).
¾DVI-D male to HDMI-A male single link cable to connect a DVI source or display (Order NTI # DVI-HD-xx-MM where xx=3, 6,
10, or 15 foot cable)
