NTI XTENDEX ST-C5USBVA-1000S User manual

MAN063 Rev 10/13/15
ST-C5USBV-1000S
ST-C5USBVA-1000S
ST-C5USBVU-1000S
ST-C5USBVUA-1000S
HI-RES VGA USB KVM EXTENDERS
With Optional Audio Support and Additional USB Port
for CAC Card Reader, Touch Screen Monitor, SMART
Board™Interactive Whiteboard and USB Printer
Installation and Operation Manual
XTENDEX®Series
ST-C5USBVUA-1000S
Remote and Local Units

i
TRADEMARK
XTENDEX is a registered trademark of Network Technologies Inc in the U.S. and other countries.
COPYRIGHT
Copyright © 2010, 2015 by Network Technologies Inc, all rights reserved. No part of this publication may be reproduced, stored in
a retrieval system, or transmitted, in any form or by any means, electronic, mechanical, photocopying, recording, or otherwise,
without the prior written consent of Network Technologies Inc, 1275 Danner Drive, Aurora, Ohio 44202. For more information
please contact Network Technologies Inc at [phone] (800-RGB-TECH) or [phone].
CHANGES
The material in this guide is for information only and is subject to change without notice. Network Technologies Inc reserves the
right to make changes in the product design without reservation and without notification to its users.
Current Firmware Versions
Local Controller Version 1.12
Local Port Controller Version 1.4
Remote Controller Version 1.12.
Note: CAT5 connection cable used between NTI XTENDEX Series Local and Remote or any XTENDEX Series products
should not be run underground, outdoors or between buildings.
WARNING: Outdoor or underground runs of CAT5 cable could be dangerous and will void the warranty.
!

ii
Table of Contents
Introduction....................................................................................................................................................................1
Types of User Input Devices Supported......................................................................................................................1
Operating Systems Supported ....................................................................................................................................2
Limitations....................................................................................................................................................................2
Materials.........................................................................................................................................................................2
Features and Functions................................................................................................................................................3
Preparation for Installation...........................................................................................................................................4
Installation......................................................................................................................................................................5
The Local Unit..............................................................................................................................................................5
Connect to the CPU..................................................................................................................................................5
Connect the Local Devices.......................................................................................................................................6
The Remote Unit..........................................................................................................................................................7
Connect the CAT5 Cable.............................................................................................................................................8
Plug-in and Boot Up.....................................................................................................................................................9
Configuration and Command Mode ..........................................................................................................................10
Command Mode........................................................................................................................................................10
Adjust Brightness....................................................................................................................................................10
Automatic Video Quality Adjustment ......................................................................................................................10
Fine Video Quality Adjustment ...............................................................................................................................11
General Video Quality Adjustment......................................................................................................................11
Color Skew Adjustment.......................................................................................................................................11
Test Patterns .......................................................................................................................................................11
Update DDC............................................................................................................................................................11
Toggle MAC Mode..................................................................................................................................................12
Exit Command Mode ..............................................................................................................................................12
Common Applications................................................................................................................................................13
Firmware Upgrade Procedure....................................................................................................................................14
Requirements ............................................................................................................................................................14
Prepare to Upgrade the Firmware.............................................................................................................................15
Upgrade Procedures..................................................................................................................................................16
Start the Bootloader................................................................................................................................................16
Upgrade the Local Controller Firmware..................................................................................................................16
Upgrade the Local Port Controller Firmware..........................................................................................................17
Upgrade the Remote Controller Firmware..............................................................................................................17
Technical Specifications ............................................................................................................................................19
Interconnection Cable Wiring Method ......................................................................................................................20
Keyboard Translation .................................................................................................................................................20
Key Equivalents.........................................................................................................................................................20
SUN’s 16 Extra Keys.................................................................................................................................................21
Troubleshooting..........................................................................................................................................................23
Index.............................................................................................................................................................................24
Warranty Information..................................................................................................................................................24
Table of Figures
Figure 1- Connect the Local Unit to a CPU........................................................................................................................................5
Figure 2- Connect local user devices to the Local Unit......................................................................................................................6
Figure 3- Connect the Monitor and Devices to the Remote Unit........................................................................................................7
Figure 4- Connect the CAT5 cable to the Local Unit..........................................................................................................................8
Figure 5- Connect AC adapter to Remote Unit..................................................................................................................................9
Figure 6- MAC Mode LED................................................................................................................................................................12
Figure 7- Examples of common applications...................................................................................................................................13
Figure 8- Connect PC for firmware upgrade....................................................................................................................................15
Figure 9- Pin positions in female RJ45 connector............................................................................................................................20
Figure 10- Keyboard Layouts...........................................................................................................................................................22

1
INTRODUCTION
The ST-C5USBV-1000S HI-RES VGA USB KVM Extender (XTENDEX) is designed to enable the relocation of a monitor, USB
keyboard, and USB mouse from a USB CPU or NTI USB KVM switch by as much as 1000 feet via CAT5/5e/6 cable. The option
to extend stereo audio speakers, USB touch screen monitor, CAC card reader, or SMART Board is also available. Additionally,
all extended components can be connected locally. It is extremely simple to install and has been thoroughly tested to insure
reliable performance. Through the use of Category 5/5e/6 shielded or unshielded twisted-pair cable (STP/UTP) it is possible to
economically increase the flexibility of a computer system.
Features
•Allows the placement of a monitor, USB keyboard, and USB mouse in a location where only these parts are needed
without having the CPU there too, taking up valuable space and adding to room noise.
•Provides crisp and clear resolution up to 1920 x 1200 /60Hz @ 1000 feet (see chart on page 19)
•Industry-leading ultra-high resolutions up to 2048x1536
•Video quality adjustment is automatic providing optimum image quality for varying lengths of cable. Manual fine
adjustments are made via keyboard commands.
•Installation can be between a CPU and devices (keyboard, mouse, and monitor), between a CPU and NTI USB switch,
or between a NTI USB switch and devices.
•Allows hot-plugging of keyboards and mice
•DDC2B support for local or remote monitor (user selectable)
•Available with optional stereo audio and/or additional USB port for remote and local user.
•For the additional USB port on the local unit, connect any type of USB device (fully transparent USB connection)
•For the additional USB port on the remote unit, use to connect a USB touch screen monitor, CAC
card reader, or SMART Board™ Interactive Whiteboard
•Firmware is field upgradeable via serial port (models with additional USB support only)
•USB ports support USB 2.0 (low/full speed) devices
Models Available:
MODEL AUDIO
SUPPORT ADDITIONAL USB SUPPORT FIELD UPGRADEABLE
ST-C5USBV-1000S N N N
ST-C5USBVA-1000S Y N N
ST-C5USBVU-1000S N Y Y
ST-C5USBVUA-1000S Y Y Y
Types of User Input Devices Supported
•XGA, VGA, and SVGA systems
•All NTI USB switches
•Microsoft, Logitech or Kensington Wheelmouse or Trackball on MAC CPUs with manufacturer's drivers
•USB keyboard with Windows®layout
•USB keyboard with SUN layout
•USB keyboard with MAC layout
•USB Mouse - (up to 3 buttons)
•USB IntelliMouse®(scrollwheel)
•Logitech Cordless Elite Duo keyboard and mouse
•Crystal Vision keyboard with touchpad
•Gyration keyboard and mouse
•NTI USB-PS/2 Adapter
•NTI USB-SUN Adapter
•USB touch screen monitor (models with additional USB support only)
•SMART Board™ Interactive Whiteboard (models with additional USB support only)
•USB CAC card reader (models with additional USB support only)
•NEC Multisync E222W (firmware version 1.5 and later)
•Motorola Symbol LS3408 Bar Code Scanner (firmware version 1.3 and later)
•Smart Podium monitors (tested with ID422W and ID370) (firmware version 1.3 and later)
•USB Printers (models with additional USB support only- firmware version 1.12 and later)

2
Operating Systems Supported
•Windows 95,98 •Windows 2000 •Windows ME •MAC OS 9.1 or greater
•Window XP •Windows Vista •Windows 7
•Linux 7.1 or greater •Sun-Solaris •Windows 8/8.1
Limitations
•PS/2 devices can be connected to the XTENDEX through an NTI USB-PS/2 adapter, however the translation keys described
on page 12 will not function in this application.
•The XTENDEX can be used between a cascadable NTI switch and a CPU although the cascading features will not function.
•When a USB printer is connected to the Remote Unit, if more than 3 pages are printed at a time or if the printer runs out of
paper while printing, performance may become unreliable and the Remote Unit may need to be power-cycled to resume
operation.
•A ST-C5USBV(U)(A)-1000S XTENDEX Local must be used with a ST-C5USBV(U)(A)-1000S Remote. The ST-C5USBV(A)-
1000S XTENDEX Local and Remote are not compatible with the ST-C5USBV(A)-300(M) Local and Remote (300 foot
version).
MATERIALS
Materials supplied with this kit:
9NTI XTENDEX Local Unit
9NTI XTENDEX Remote Unit
92-120VAC or 240VAC 50 or 60Hz-5VDC/3A AC Adapters
9CD with a pdf file of this owner's manual
Models with additional USB support (ST-C5USBVU/C5USBVUA-1000S) also include:
91- DB9 Female-to-RJ45 Female adapter
91- 5 foot RJ45-to-RJ45 CAT5 patch cable
Additional materials may need to be ordered, depending upon the configuration :
¾USBVEXT-3/6/10 (15HD Male-to-Female and USB Type A Male-to-Female Extension cable) if the Local Unit will be located
further than 15" from the CPU or KVM switch
¾CAT5/5e/6 shielded/unshielded twisted-pair cable(s) terminated with RJ45 connectors wired straight thru- pin 1 to pin 1, etc.
(see pg. 13 for proper EIA/TIA 568B wiring method)
Contact your nearest NTI distributor or NTI directly for all of your KVM needs at 800-742-8324 (800-RGB-TECH) in US & Canada
or 330-562-7070 (Worldwide) or at our website at http://www.networktechinc.com and we will be happy to be of assistance.

3
FEATURES AND FUNCTIONS
1. Video Cable- 15HD male for connection to video connector of CPU
2. Audio Cable- 3.5mm plug- for connection to audio connector of CPU
3. Devices Cable- USB Type A male connector for connection to CPU
4. USB DEVICES- USB Type A female for connection of local user USB device(s)
5. USB DEVICE- USB Type A female for local connection of additional USB device (any)
6. 5VDC- connection jack for Local Unit AC adapter
7. RS232 Control - for connection of terminal to update program (models with Additional USB Support only)
8. Audio Out ( )- 3.5mm Stereo Jack- for local connection of self-powered stereo speakers
9. CATx- RJ45 female for connection of CAT5/5e/6 cable between Local Unit and Remote Unit
10. Monitor ( )- 15HD female for connection of video cable from local monitor
11. MAC LED- for visual indication that the Local Unit is configured for connection to a MAC CPU
12. USB DEVICES- USB type A female for connection of remote user USB device(s)
13. USB DEVICE- USB Type A female for remote connection touch screen, CAC reader, or SMART Board™ only
14. 5VDC- connection jack for Remote Unit AC adapter
15. Audio Out ( )- 3.5mm Stereo Jack- for remote connection of self-powered stereo speakers
16. Monitor ( )- 15HD female for connection of video cable from remote monitor
17. Yellow LED- traffic indicator- blinks when there is valid communication between the Local and Remote Units.
18. Green LED- power indicator- illuminates when power has been supplied to the unit
1
23
456 78 910
15 916
ST-C5USBVUA-1000S Local Unit Front View
ST-C5USBVUA-1000S Remote Unit
Rear View
Front View
11 12 13 14
Rear View
17 18
VGA
VGA

4
PREPARATION FOR INSTALLATION
•A location should be chosen for the monitor, mouse, and keyboard that also has space to mount the Remote Unit within the
distance provided by the cables from the monitor, mouse, and keyboard. If extension cables are needed, contact NTI for the
cables required. If a local user will be connected, a proper location must be chosen for these devices too.
•The CAT5 cable(s) must be run to the locations where the Remote and Local Units will be placed. Be careful to route the
cables away from any sources of magnetic fields or electrical interference that might reduce the quality of the video signal
(i.e. AC motors, welding equipment, etc.). NOTE: If CAT5 cable is already installed in the wall and there are RJ45 wall
outlets, it will be necessary to obtain male-to-male straight through connection cables long enough to reach from the wall
outlets to the mounting locations of the Remote and Local Units.
•A properly grounded, polarized, and preferably surge-protected 120V or 240V electrical outlet (depending on the AC adapter
being used) must be installed close enough to the mounting location of the Remote Unit and monitor to plug them into.
•All cables should be installed in a fashion that will avoid stress on their connections to the equipment. Extended lengths of
cable hanging from a connection may interfere with the quality of that connection. Secure cables as needed to prevent this.
•Properly shut down and disconnect the power of the CPU and monitor. Disconnect the monitor, keyboard, and mouse. If
other equipment is involved whose connections are being interrupted, be sure to refer to the instruction manuals for that
equipment for proper disconnection and re-connection procedures before proceeding.
Note: CAT5 connection cable used between NTI XTENDEX Series Local and Remote or any XTENDEX Series products
should not be run underground, outdoors or between buildings.
WARNING: Outdoor or underground runs of CAT5 cable could be dangerous and will void the warranty.
!

5
INSTALLATION
The Local Unit
Connect to the CPU
1. Plug the cables of the Local Unit into the back of the CPU. (See Fig. 1.)
a) Connect the blue 15HD cable from the Local Unit to the female VGA port on the back of
the CPU.
b) Connect the USB Type A cable from the Local Unit to a female USB Type A port on the back of the CPU.
c) If the extender model includes audio support, connect the 3.5mm stereo plug to the audio port on the back of
the CPU.
Figure 1- Connect the Local Unit to a CPU
USB-A - Male
3.5mm Stereo Plug
15HD Male
Video Connector
USB
CPU
USB Keyboard
VGA
Multi-Scan
Monitor
USB Mouse
Stereo
Speakers
Self-Powered
Amplifier
CAC
Reader
3.5mm
Stereo Plug
USB-A - Male
15HD Male
Video
Connector
ST-C5USBVUA-1000S Local Unit
Rear View Front View
USB Type A male

6
Connect the Local Devices
If desired, connect the local user devices to the Local Unit as shown in Fig. 2.
1. Connect a USB keyboard and mouse to the USB type A female connectors on the Local Unit.
2. Connect a monitor to the 15HD female connector on the Local Unit.
3. If the unit has audio support, connect self-powered stereo speakers to the audio out port ( ) on the Local
Unit.
4. If the unit has additional USB support, connect any USB device (supports USB 2.0 (low/full speed)) to the
additional USB type A female connector on the Local Unit.
Figure 2- Connect local user devices to the Local Unit
USB Type A male
15HD Male
Video Connector
USB Keyboard
VGA
Multi-Scan
Monitor
USB Mouse
Stereo
Speakers
Self-Powered
Amplifier
CAC
Reader
3.5mm
Stereo Plug
ST-C5USBVUA-1000S Local Unit
Rear View Front View

7
The Remote Unit
Position the Remote Unit such that each cable to be connected to it can reach the Remote Unit comfortably.
1. Connect a USB keyboard and mouse to the USB type A female connectors on the Remote Unit.
2. Connect the monitor cable to the 15HD female connector on the back of the Remote Unit. (See Fig. 3)
3. If the unit has audio support, connect self-powered stereo speakers to the audio out port ( ) on the Remote
Unit.
4. If the unit has additional USB support, connect a CAC card reader, SMART Board™, or the USB serial connector
from a touch screen monitor to the additional USB type A female connector on the Local Unit.
Figure 3- Connect the Monitor and Devices to the Remote Unit
Note: When a USB printer is connected to the Remote Unit, if more than 3 pages are printed at a time or if the printer
runs out of paper while printing, performance may become unreliable and the Remote Unit may need to be power-cycled
to resume operation.
USB Keyboard
VGA
Multi-Scan
Monitor
USB Mouse
Stereo
Speakers
Self-Powered
Amplifier
CAC
Reader
3.5mm
Stereo Plug
ST-C5USBVUA-1000S Remote Unit
Rear View Front View
USB Type A male
15HD Male
Video Connector

8
Connect the CAT5 Cable
Make sure the CAT5/5e/6 cable has been installed in accordance with the “Preparation for Installation” instructions on page 4.
Connect one end of CAT5 cable to the “CATx” port on the back of the Remote Unit, and the other end to the “CATx” port on the
Local Unit. When properly inserted the CAT5 cable ends should snap into place.
WARNING: Never connect the ST-C5USBV-1000S Extender to an Ethernet card, Ethernet router, hub or
switch or other Ethernet RJ45 connector of an Ethernet device. Damage to devices connected to the
Ethernet may result.
Figure 4- Connect the CAT5 cable to the Local Unit
!
Front View
ST-C5USBVUA-1000S Local Unit ST-C5USBVUA-1000S Remote Unit
Front View
CAT5/5e/6 cable
Up to 1000 feet
RJ45 Connector RJ45 Connector
RJ45 female
CAT5 connector
Green Power LED
Yellow Traffic LED

9
Plug-in and Boot Up
1. Plug the power cord from the monitor into the power outlet.
2. Connect one AC adapter power connector to the 5VDC port on the back of the Local Unit. (AC adapter shown in Fig. 5)
3. Plug the AC adapter into a power outlet. The green “Power” LED on the Local Unit should illuminate, indicating that a proper
power connection has been made to the Local Unit.
4. Connect the other AC adapter power connector to the 5VDC port on the Remote Unit.
5. Plug the AC adapter into a power outlet. The green “Power” LED on the Remote Unit should illuminate, indicating that a
proper power connection has been made to the Remote Unit.
6. Turn ON the monitor, then the CPU. The CPU and monitor should each react as if they were directly connected to each
other. The yellow traffic LEDs on the Remote and Local Units (see fig. 3) should blink indicating there is proper
communication between them.
Note: A loss of signal (blank screen) may be experienced for an instant during the auto-compensation process after
powering-up. This may also occur if the XTENDEX senses a loss of or weak signal connection in the CAT5 cable.
Figure 5- Connect AC adapter to Remote Unit

10
CONFIGURATION AND COMMAND MODE
Command Mode
All models are enabled with a Command Mode feature to perform the following:
¾fine adjustment of the general video quality
¾fine adjustment of color skew (alignment of red, green, and blue signals on the monitor)
¾update DDC information between the monitor(s) and CPU
¾toggle between MAC mode and non-MAC mode
Command Mode can be enabled by two keys at the same time; <LEFT SHIFT> + <RIGHT SHIFT>. Press <Esc> at any time
to exit Command Mode.
The three keyboard LEDs (NumLock, CapsLock, and ScrollLock) will blink at the same time to indicate entrance into Command
Mode.
Commands available in Command Mode:
Key press Effect Extra Control
<Up Arrow> increases brightness
<Down Arrow> decreases brightness
<A> forces Auto Video Quality
Adjustment
<Left Arrow> Decreases fine video adjustment
<Right Arrow> Increases fine video adjustment
<R> Enable Red Color Skew Adjustment
Mode Use <Left Arrow> or <Right Arrow> to adjust
<G> Enable Green Color Skew
Adjustment Mode Use <Left Arrow> or <Right Arrow> to adjust
<B> Enable Blue Color Skew Adjustment
Mode Use <Left Arrow> or <Right Arrow> to adjust
<D> DDC Update Mode
<V> Returns to General Video Quality
Adjustment Mode from DDC Update
Mode or Color Skew Adjustment
Modes
<M> Enable MAC Mode
<W> Disable MAC Mode
<Esc> Exits Command Mode
Adjust Brightness
The brightness of the extended image can be increased or decreased by pressing the <Up Arrow> or <Down Arrow>
(respectively) while in Command Mode. This adjustment is in addition to any adjustments made possible by controls on your
monitor.
Automatic Video Quality Adjustment
Video quality is broken down into “general video quality” for brightness and sharpness of the images, and “color skew” for how the
colors align with each other on the monitor. Both general video quality and color skew adjustments are done automatically any
time the XTENDEX is powered ON or if the CATx cable is disconnected and then reconnected. These adjustments can also be
forced by pressing the <A> key while in Command Mode.
The automatic video adjustments are calibrated for unshielded twisted pair cable. For shielded cable fine adjustment may be
necessary and this can be done from keyboard keys using Command Mode. Video Quality Adjustment settings are automatically
stored in the XTENDEX. Settings will be restored each time the XTENDEX is powered-ON. Test patterns for color skew
adjustment are provided on the CD.
Note: If the cable is changed after making manual video adjustments, the XTENDEX will restore these settings to factory
default and fine adjustments with the new cable may be necessary.

11
Fine Video Quality Adjustment
General Video Quality Adjustment
Command Mode opens into General Video Quality Adjustment mode. To fine tune the general video quality, press the <Left
Arrow> or <Right Arrow> keys until the desired improvement in the display has been achieved.
Color Skew Adjustment
If a specific color appears to be skewed and is in need of fine adjustment, the user can switch to Red, Green, or Blue Skew
Adjustment mode by pressing <R>, <G> or <B> respectively. The keyboard LEDs will identify the mode as indicated in the table
below. Press the < Left Arrow> or <Right Arrow> keys until the desired improvement in the color alignment has been
achieved. Press <V> to return to General Video Quality Adjustment mode.
Test Patterns
To verify the need for and effect of color skew adjustment using a test pattern specifically designed for your display setting,
browse the CD this manual was found on and click on the “test-pattern-nXm.pdf” file that matches your current video resolution.
Follow the instructions above to make adjustments as needed.
Note: For additional quality adjustment, it may be necessary to adjust the brightness and contrast settings of the
monitor.
Keyboard LEDs Indications:
Adjustment Mode NumLock CapsLock ScrollLock
Command Mode ON Blink Blink Blink
Red Skew Blink Solid Solid
Green Skew Solid Blink Solid
Blue Skew Solid Solid Blink
DDC Update Off Solid Off
Command Mode OFF Normal state Normal state Normal state
Update DDC
DDC information allows the CPU to automatically select the optimal resolution for your monitor. The procedure to update DDC
information (below) must be performed only once at initial setup through Command Mode (provided the monitor is not changed).
Both the Local and Remote Units must be powered in order to update the DDC information. The DDC information will be based
on the monitor connected to the Remote Unit.
To update DDC information (from Command Mode);
1. press <D> to enter DDC Update mode. (See chart above for LED indications.)
2. press the < Left Arrow> + <Right Arrow> keys simultaneously to cause DDC information to be updated
3. press <V> to return to General Video Quality Adjustment mode.
4. press <Esc> to exit Command Mode
5. Restart the CPU.
Note: It is recommended that the monitors connected to the Remote and Local units be of the same make and model.
Attention: Some graphics cards will not send a video signal to the monitor until it has received the DDC information from the
monitor. In this case, the monitor may not display anything until the DDC information is read. This may occur if this is the first
time the monitor is being connected to the XTENDEX. The DDC information must be updated in the XTENDEX to achieve video
using the procedure outlined above.
If the monitor is changed to a different model than was initially installed, the update procedure must be repeated through
Command Mode.

12
Toggle MAC Mode
MAC Mode enables the user to connect the Local Unit to a MAC CPU. MAC Mode configures the Local Unit for passing mouse
information to the MAC CPU. This is useful when the user wants to use mouse drivers provided by the mouse vendor, which
allows the use of programmable functions for each mouse button. The Local Unit can be configured whenever necessary.
In the default setting (non-MAC Mode), the XTENDEX is configured for connection to a SUN or Windows CPU. To toggle
between non-MAC Mode and MAC Mode, press <M> while in Command Mode. The “MAC Mode” LED on the Remote Unit will
illuminate when the XTENDEX is in MAC Mode.
NOTE: When the port is connected to a PC or SUN CPU, MAC Mode (and the MAC Mode LED) should be OFF.
To do this;
1. Enter Command Mode. (Simultaneously press the left and right <Shift> keys on the keyboard connected to the Remote
Unit. The keyboard LEDs will illuminate. )
2. If a MAC CPU is connected, press the <M> key. The keyboard LEDs will momentarily flash and the “MAC” LED on the
Remote Unit will illuminate to indicate MAC Mode is ON.
To reconnect the XTENDEX to a SUN or Windows CPU (the default setting) , press the <M> key once again and the “MAC” LED
will go OFF.
Figure 6- MAC Mode LED
Exit Command Mode
Press the <Esc> key to exit Command Mode and return to normal operation. All keyboard LEDs will return to current keyboard
LED state.
FYI: Video quality will be limited by several factors. Some factors include the quality and type of CAT5 cable being
used, the length of cable run, the quality of the monitor, the resolution setting of the monitor, and the quality of the video
card used in the video source. If the desired level of image clarity cannot be achieved by making the adjustments
described in this section, consider the following possible adjustments that can be made:
•Improve the quality of cable used -CAT5,5e,or 6 (CAT5e unshielded (UTP) cable will provide the best
performance)
•Use unshielded cable (UTP) instead of shielded cable (STP)
•Shorten the length of the cable between the remote and local
•Reduce the resolution setting on the monitor used
•Use a higher quality video card in the video source
MAC port configuration LED
ST-C5USBVUA-1000S Remote Unit
Rear View

13
COMMON APPLICATIONS
Figure 7 (below) illustrates three common applications for the ST-C5USBV-1000S USB KVM Extender.
Figure 7- Examples of common applications
VGA
Multi-Scan
Monitor
XTENDEX
REMOTE UNIT
CAT5 Cable
VGA
Multi-Scan
Monitor
NTI USB
KVM MATRIX
SWITCH
(UNIMUX-nXm-U)
VGA
Multi-Scan
Monitor
NTI USB
KVM
SWITCH
(UNIMUX-xU)
BETWEEN CPU AND
MULTI-USER MATRIX
SWITCH
STANDARD APPLICATION
BETWEEN USERS AND CPU
BETWEEN SINGLE-
USER KVM SWITCH
AND USERS
USB Mouse USB Keyboard
USB Mouse USB Keyboard USB KeyboardUSB Mouse
USBVEXT-xx-MM
Existing Local Unit Cable Existing Local Unit Cable
Existing Local Unit Cable
CAT5 Cable
CAT5 Cable
USBVEXT-xx-MM
VGA
Multi-Scan
Monitor
USB Mouse USB Keyboard
VGA
Multi-Scan
Monitor
USB Mouse USB Keyboard
Local User Local User
VGA
Multi-Scan
Monitor
USB Mouse USB Keyboard
Local User
XTENDEX
REMOTE UNIT
XTENDEX
LOCAL UNIT
XTENDEX
LOCAL UNIT
XTENDEX
REMOTE UNIT
XTENDEX
LOCAL UNIT

14
FIRMWARE UPGRADE PROCEDURE
This procedure describes how to upgrade the firmware in this XTENDEX. Only models with Additional USB Support can be
upgraded. If you are not certain whether this XTENDEX has the most up-to-date firmware available, simply download the latest
version and follow the upgrade procedure. All versions of firmware can be downloaded from
http://www.networktechinc.com/usbkvm.html.
The XTENDEX has 3 types of micro-controllers:
1. Local Controller – the Local Controller will be upgraded with a binary file named c5usbvu-lcsx-x.bin. (where x-x is the rev
number)
2. Local Port Controller – the Local Port Controller will be upgraded with a hex file named c5usbvu-lcpx-x.hex.
3. Remote Controller – the Remote Controller will be upgraded with a bin file named c5usbvu-rcsx-x.bin.
The XTENDEX firmware has a bootloader which can be used for firmware upgrades. The bootloader resides in a protected area
of Flash memory, so that if the upgrade fails for any reason, the bootloader will still be available to be used to re-program the
entire unit.
Upgrades are made to the Local Controller, Local Port Controller, or Remote Controller separately. Not all Controller firmware is
updated with each revision, however it is highly recommended that if you upgrade one piece of firmware, you upgrade each
controller segment to make sure your Local and Remote are both at current versions.
Requirements
¾CAT5 Patch Cable (supplied with XTENDEX)
¾RJ45-DB9 or DB25 Adapter (supplied with XTENDEX)
¾Computer with a Terminal Console (for example, HyperTerminal in Windows, or any similar program able to send files using
Xmodem protocol)
¾Firmware files for the XTENDEX on the computer with the Terminal Console.

15
Prepare to Upgrade the Firmware
With the power to the PC and XTENDEX OFF, connect a PC to the XTENDEX using the supplied 5 foot patch cable and 9DB-to-
RJ45 adapter. Connect the patch cable to the “FIRMWARE UPGRADE” port on the Local Unit, attach the supplied 9DB-to-RJ45
adapter to the patch cable, and connect the 9DB adapter to an available COM port on the PC.
Figure 8- Connect PC for firmware upgrade
2. Power ON the computer only. Open the terminal console and apply the following settings to the terminal console for the port
connected to the XTENDEX:
Baud rate: 57600
Data bits: 8
Parity: none
Stop bits: 1
Flow control: none
ST-C5USBVUA-1000S Local Unit
Front View
VGA
Multi-Scan
Monitor
Control Terminal
RJ45-to-DB9 Adapter
(supplied)
CAT5 Patch Cable
(supplied)

16
Upgrade Procedures
Start the Bootloader
In the HyperTerminal window on the attached computer, press and hold the <Tab>key and power ON the XTENDEX.
The following message (or one similar) will be displayed on the screen:
ST-C5-USBVA Bootloader
Revision: 1.1
Date: 2010/01/11 15:40:16
Copyright (C) Network Technologies Inc.
Press <H> for help…
>
Release the <Tab> key.
The “>”prompt indicates that the bootloader is waiting for commands. The available commands are composed by sending one
ASCII character. To send a command to the bootloader, type the key in the terminal window that corresponds to the desired
command. The available commands, listed below, can be viewed by typing <h> or <H> (the Help command) from the keyboard.
Note: Commands can be typed using upper or lower case letters.
Local Bootloader List of Commands:
h, H - Display list of commands
x, X - Exit Bootloader
u, U - Upgrade Local controller firmware
p, P - Upgrade Local port controller firmware
r, R - Upgrade Remote controller firmware
s, S - Read Checksum of the Local port controller firmware
Upgrade the Local Controller Firmware
The Local controller firmware comes as a file in binary format and has the extension .bin. (i.e. filename.bin). To upgrade the
Local controller to this file, press <u> from Terminal window. The following message should appear on the screen:
Erasing flash memory…
Memory successfully erased
Send .bin file using Xmodem protocol..
At this point the binary file c5usbvu-lcsx-x.bin must be sent. To do this, from HyperTerminal:
1. go to “Transfer” menu in the Menu Bar of the HyperTerminal window
2. click the item “Send File …”
3. in the dialog box which pops up on the screen, browse for the file to be sent and select it
4. select “Xmodem” from the Protocol drop-down menu
5. press “Send” button
The transmission will start shortly. Wait until the transmission is finished. There will be some pauses during transmission, since
the processor writes blocks of 4KB.
When the transmission is complete, the HyperTerminal window should show the following status message and return to the menu
prompt:
Device successfully programmed!
>
To exit from the bootloader, press <x>.

17
Upgrade the Local Port Controller Firmware
The Local port controller firmware comes as a file in Intel Hex format and has the extension .hex (i.e. filename.hex). To upgrade
any of Local Port controller with this firmware, press <p> from the terminal window. The following message should appear on the
screen:
Send .hex file using XModem protocol...
At this point, the hex format file c5usbvu-lcpx-x.hex has to be sent, using HyperTerminal and the same procedure as before.
When the transmission is done, the following message will be shown in the HyperTerminal window:
File transfer OK!
Please, type <A> to program chip or <X> to exit
To program the chip, just press <a>).
The following message will be shown on the screen (it may take about 12 seconds to program):
Programming device, please wait...
Device ID: 0x001E
Device successfully programmed!
To exit from the bootloader, press <x>.
Note: The Local port controller firmware will rarely, if ever, need to be updated. The firmware download package will
include both of the current Local and Remote controller firmware versions, but will only include the Local port controller
firmware if it has changed.
Upgrade the Remote Controller Firmware
The Remote controller firmware comes as a file in binary format and has the extension .bin. (i.e. filename.bin). To upgrade the
Remote controller to this file, press <r> from Terminal window. The following message should appear on the screen:
The Local Unit bootloader will now pass control
to the Remote Unit bootloader
Please, check that the Remote Unit is powered off
Please, type <Y> to continue or <X> to cancel
If you type <Y> to continue you get the following message:
To enter into Remote Unit bootloader, power on the unit
while keeping the <TAB> key pressed
Remote Bootloader List of Commands:
h, H - Display list of commands
x, X - Exit Bootloader
r, R - Upgrade Remote controller firmware
To proceed to upgrade the Remote controller, press <r> from Terminal window. The following message should appear on the
screen:
Erasing flash memory…
Memory successfully erased
Send .bin file using Xmodem protocol..
