OWNER’S MANUAL
The Ultimate Air Fryer Oven & Grill

Open your mobile app store
(App Store, Google Play).
Search for "QR code readers."
Simply download the QR code reader to your phone,
open it, scan the code and you are ready to go.
NOTE: You may need to open your downloaded QR
code reader each time you want to scan a QR code.
nuwavenow.com
2 3
nuwavenow.com
2 3
REGISTER
NOW!
3
for an additional
months
warranty!
As a special thank-you for registering your NuWave
unit, you’ll automatically receive an additional 3 months
added to your limited manufacturer’s warranty!*
All you have to do is follow these simple steps.
Using your smartphone or
smart device, scan the QR code
located on the unit label on the
back of the unit.
You will be directed to NuWave’s
product registration page with
your unit’s unique serial number
automatically entered in the
appropriate eld.
NOTE: If you do not have a
web-enabled smart device,
simply visit nuwavenow.com/QR
and manually enter in your unit’s
serial number.
Fill out the remaining information
and complete the optional survey.
Once you submit your
information, you will receive
a conrmation email containing
your extended warranty details.
1
2
3
4
*Register your product within 1 year of date of purchase for
a free 3-month extension of your limited warranty.
1
2
3
DOWNLOAD THE QR CODE
APP TO YOUR MOBILE DEVICE
QR code readers

table of contents nuwavenow.com
4 5
ENGLISH
nuwavenow.com
TABLE OF CONTENTS
4 5
OWNER’S MANUAL
Important Safeguards ....................................................... 5-8
Parts & Accessories.......................................................... 8-9
Assembly Guide............................................................ 10-13
Quickstart...................................................................... 14-15
Instructions.................................................................... 16-28
Cleaning & Maintenance................................................ 29-30
Troubleshoot Guide........................................................ 31-32
Limited Warranty ............................................................ 33-35
Replaceable Parts........................................................... 36-37
IMPORTANT SAFEGUARDS
HOUSEHOLD USE ONLY • READ ALL INSTRUCTIONS BEFORE USE
WARNING: When using the
Brio, basic safety precautions
should always be followed:
1. Do not touch hot surfaces.
Use handles.
2. To protect against electrical
shock, do not immerse cord,
plugs, or the Brio in water or
other liquids.
3. Do not operate the Brio
with a damaged cord or
plug or after the appliance
malfunctions or has been
damaged in any manner.
Return appliance to the
nearest authorized service
facility for examination,
repair, or adjustment.
4. Close supervision is
necessary when any
appliance is used near
children. This appliance
is not intended for use
by persons (including
children) with reduced
physical, sensory or mental
capabilities, or lack of
experience and knowledge,
unless they have been
given supervision or
instruction concerning use
of the appliance by a person
responsible for their safety.
5. The use of other accessories
that are not intended to be
used with the Brio is not
recommended. Doing so
may damage the Brio and
can cause accidents.
6. NOT INTENDED FOR
OUTDOOR USE. FOR
HOUSEHOLD USE ONLY.
7. Do not let the cord hang
over the edge of table
or counter or touch hot
surfaces, including a
stovetop.
8. Do not place on or near a
hot gas or electric burner
or on a heated oven or on
a stovetop.
9. During air-frying, hot
steam is released from the
air outlet vent. Keep hands
and face at a distance
from the steam and from
the air outlet vent. Also,
be careful of hot steam
and air when removing
accessories.
10. Never put the Brio
against the wall or other
appliances. There should
be at least 3 inches of free
space for the back side,
left/right sides, and the
upper side of the Brio.
11. Do not place objects on
top of the Brio.
12. Unplug the Brio from
outlet when not in use and
before cleaning. Allow
the Brio to cool before
cleaning, putting on or
taking off parts.
13. Oversized foods or metal
utensils must not be
inserted in the Brio, as they
may create a re or risk of
electric shock.
14. A re may occur if the Brio
is covered or touching
ammable materials
including curtains,
draperies, walls, etc., when
in operation.
www.nuwavenow.com

nuwavenow.com 7
ENGLISH
nuwavenow.com
IMPORTANT SAFEGUARDS
HOUSEHOLD USE ONLY • READ ALL INSTRUCTIONS BEFORE USE
7
important safeguards
66
Electrical Information
A short power-supply cord
is provided to reduce the
risk resulting from becoming
entangled in or tripping
over a longer cord. Longer
detachable power-supply
cords or extension cords are
available and may be used if
care is exercised in their use.
If a longer detachable power-
supply cord or extension
cord is used:
1. The marked electrical
rating of the extension
cord should be at least
as great as the electrical
rating of the appliance.
2. The longer cord should be
arranged so that it will not
drape over the countertop
or tabletop where it could
be pulled on or tripped
over unintentionally. The
Brio should be operated
on a separate electrical
outlet from other operating
appliances due to wattage
limitations. The appliance
has a polarized plug (one
blade is wider than the
other). To reduce the risk
of electric shock, this
plug is intended to fit into
a polarized outlet only
one way. If the plug does
not fit fully into the outlet,
reverse the plug. If it still
does not fit, contact a
qualified electrician. Do
not attempt to modify the
plug in any way.
3. If the appliance is of the
grounded type, the cord
set or extension cord
should be a grounding-
type 3-wire cord.
SEE ASSEMBLY GUIDE
BEFORE USE
SAVE THESE INSTRUCTIONS
Read and understand the entire
manual before using the Brio.
DO NOT USE THE UNIT FOR
OTHER THAN ITS INTENDED USE
Note: Put the Brio on a surface
that is horizontal, even, and
stable. This appliance is intended
for normal household use. It
is not intended to be used in
environments such as staff
kitchens/cafeterias of shops,
ofces, farms, or other work
environments, nor is it intended
to be used by clients in hotels,
motels, bed and breakfasts, and
non-residential environments.
NOTICE: THE FAILURE
TO FOLLOW ANY OF THE
IMPORTANT SAFEGUARDS,
ADDITIONAL SAFEGUARDS, OR
THE INSTRUCTIONS FOR SAFE
USE IS A MISUSE OF YOUR
BRIO THAT CAN VOID YOUR
WARRANTY AND CREATE THE
RISK OF SERIOUS INJURY.
ADDITIONAL SAFEGUARDS
1. Do not place the Brio close to
ammable materials, heating
units, or wet environments.
2. Do not put any cooking
pan sizes other than 8x6x2
inches up to 8x8 inches (2
quarts) in the Brio. Do not
replace any parts with other
containers.
15. Do not clean with metal
scouring pads. Pieces can
break off the pad and touch
electrical parts, involving a
risk of electric shock.
16. Extreme caution should
be exercised when using
containers constructed of
material other than metal or
glass.
17. Do not store any materials
other than manufacturer’s
recommended accessories in
the Brio when not in use.
18. Do not place any of the
following materials in the Brio:
paper, cardboard, plastic, or
any ammable materials.
19. Do not cover any part of the
Brio with aluminum foil. This
will cause overheating.
20. Use extreme caution when
removing accessories or
when disposing of oil or hot
grease.
21. Extreme caution must be
used when moving the Brio
containing hot oil or other hot
liquids.
22. To disconnect, turn the Brio
OFF, then remove plug from
the wall outlet.
23. Always remove plug by the
head not the cord.
24. Press ON/OFF to turn the
Brio off.
25. Keep manual handy for
future reference.
WARNING
In case of other problems,
immediately unplug and
contact Customer Service
Department.
1-877-689-2838
[e-mail]
3. It is normal for some smoke
to escape the Brio when
heating for the rst time.
4. If a lot of smoke is
escaping from the air vent
during operation, unplug
the Brio immediately and
contact Customer Service.*
5. Extreme caution must be
exercised when operating
the Brio or any other
appliance.
6. Do not move the Brio while
in operation. Only after
the Brio has completely
cooled should moving be
attempted. Always wait for
the Brio to cool down prior
to handling it.
7. Never use a towel or other
material or object to block
the air vents.
8. Children should be
supervised to ensure
that they do not play
with the Brio.
9. Discard the protective
plastic covering the power
plug before use.
10. If any trouble arises during
operation, service MUST
be done by NuWave
LLC or authorized by the
manufacturer for repairs.
11. The Brio is not intended
to be operated by means
of an external timer or
separate remote-control
system.
12. Do not disassemble
the Brio or replace
any parts without prior
written consent from the
manufacturer.

important safeguards nuwavenow.com
8 9
ENGLISH
nuwavenow.com
IMPORTANT SAFEGUARDS
HOUSEHOLD USE ONLY • READ ALL INSTRUCTIONS BEFORE USE
8 9
13. Do not use metal utensils
with the Tray, Racks, Grill/
Griddle Plate as this can
damage the surface.
14. Make sure the Brio is always
clean prior to cooking.
*Customer Service Department:
1-877-689-2838
[e-mail]
8
PARTS &
ACCESSORIES
3
2
5
4


 
 


 



 











1800
1500
900

1
(2x)
Power Base
Part #: 38005
Stainless Steel
Mesh Tray
Part #: 38202
Stainless Steel
Mesh Racks (2x)
Part #: 38203
Drip Tray
Part #: 38204
Grill/Griddle Plate
Part #: BRI14-A8
Rotisserie Basket
Part #: BRI14-A12
Rotisserie Skewer
Part #: BRI14-A13
Digital Temperature
Probe
Part #: 38207
Door
Part #: 38208
Light Bulb
Part #: 38209
Light Bulb Cover
Part #: 38211
Non-Stick Baking Pan
Part #: 37212
Silicone Cupcake
Liners (6x)
Part #: 22113
1
2
3
4
5
6
7
8
9
10
11
12
13
6
7
8
To order replaceable parts refer to the Replaceable Parts section or
visit nuwavenow.com.
CAUTION
• Always put the ingredients
to be cooked in the Tray
or on the Racks, or Grill/
Griddle Plate to prevent
direct contact with the
heating components.
• Do not cover the air inlet
and outlet openings while
the appliance is operating.
• Do not pour oil into the
Tray, Racks, Grill/Griddle
Plate, Rotisserie Basket, or
on the Rotisserie Skewer,
as this may create a re
hazard.
• Never touch the insides of
the appliance while
it is operating.
9
10
11
13
13 (6x)

assembly guide nuwavenow.com
10 11
ENGLISH
nuwavenow.com
ASSEMBLY GUIDE
10 11
Notes:
• For better results use kitchen
twine around chicken or
other meats.
• Always check that there is
sufcient space above and
below food so it can rotate
freely without obstruction.
• When using Rotisserie
Skewer, place Drip Tray on
the bottom.
2. Place food in Basket.
3. Adjust top lid to t over food:
Place ends of top lid into
slots above where top of
food ends. Squeeze prongs
on outside of top lid and
slide down into position and
place prongs into correct
position.
• Position of prongs should
be lined up and opposite
of slot holes on other side.
• Make sure top lid lies at
on food and t is snug.
4. After placing food into the
Basket and securing, take
the Basket and slide in
between Position 2 and
Position 3 inside the Brio.
The rectangular end without
grooves should be on the
left. Keep the right side
slightly tilted upward while
sliding in.
Rotisserie Basket Assembly
To assemble the Rotisserie
Basket into the Brio, follow the
steps and illustrations below:
1. Remove top lid from Rotisserie
Basket: Squeeze prongs
on outside of top lid toward
middle and lift up. Remove
other end from holes.
3. Place the second Rotisserie
Skewer fork onto the other
end of the Skewer and
push the fork forward until it
pierces the end of the meat.
Tighten the screw of the
fork. If necessary, loosen
screw and move the rst fork
forward until it pierces the
other end of the meat then
retighten. Make sure both
screws are tight and in place.
4. After placing food onto
the Rotisserie Skewer and
securing, slide between
Position 2 and Position
3 inside the Brio. The
rectangular end of the spit
should be on the left when
sliding in. Keep the right
side slightly tilted upward
while sliding in.
5. Bring down the right side
of the spit into the Shaft
Bracket, then insert the left
spit (bar) of the Skewer
into the hole (Shaft Support
Hole) in the inner wall.
Rotisserie Skewer Assembly
To assemble the Rotisserie
Skewer with poultry and other
meats, follow the steps below:
1. Screw one Rotisserie
Skewer fork onto the end
of the Skewer with the
rectangular end.
2. Push the Skewer through the
center of the meat until the
Skewer pierces the food all
the way through and out the
other side.
4
3
2
1
4
3
2
1
CAUTION
Rotisserie Skewer parts will be
hot during and after use. Use
oven gloves.
USE THE DRIP TRAY AT
ALL TIMES.
Left Right
Screw
Left
Right
Left Right
Before Use
1. Remove all the packaging
materials.
2. Remove the glue and labels
on the appliance.
3. Clean all removable parts
thoroughly with hot water,
a nonabrasive sponge, and
mild dish detergent, or in the
dishwasher, top rack only.
4. Wipe the insides and outside
of the Brio with a wet cloth.
Do not immerse the Brio in
water. Dry thoroughly.

assembly guide nuwavenow.com
12 13
ENGLISH
nuwavenow.com
ASSEMBLY GUIDE
12 13
5. Bring down the right side of
the bar of Basket into the
bracket, then insert the left
bar of the Basket into the
hole in the inner wall.
Notes:
• Always check that there is
sufcient space above and
below food so it can rotate
freely without obstruction.
• When using Rotisserie Basket,
place Drip Tray on the bottom.
Left
Right
CAUTION
Rotisserie Basket parts will be
hot during and after use. Use
oven gloves.
CAUTION
Accessories and contents will
be HOT. Use oven gloves.
Grill/Griddle Plate Assembly
4
3
2
1
Position:
Griddle
Grill
The Grill/Griddle Plate can be
used in Position 1-3. For crispier
results it’s recommended to use
Position 3.
Position 4 is mostly used for
dehydrating foods using the
Mesh Rack.
Silicone Cupcake Liners
3
2
1
Position:
Place the Silicone Cupcakes on
the Mesh Rack in Position 1, 2,
or 3.
To Remove Door
1. Make sure your Brio has
completely cooled. Open the
Door down partially (opened
about down 1 inch).
2. Holding the Door handle
securely, lift up the right Door
side rst from the hinge and
then the left side to remove.
3. Place the Door back into the
hinge slots and press down.
Open and close Door to
ensure it’s secure.
CAUTION
If you have trouble removing
the door do not force; door is
being opened at the wrong
angle. Door should be opened
1 inch down.
1 inch down
lift up
Non-Stick Baking Pan
With the Mesh Rack in either
Position 1 or 2, place the
Baking Pan on top of the Rack.
• You can also place the
Pan on the very bottom
without a Rack.
• The pan holds up to 2
quarts (litres).
2
1
Position:

quickstart nuwavenow.com
14 15
ENGLISH
nuwavenow.com
QUICKSTART
14 15


 
 


 



 











1800
1500
900

date name doc#
01-18-19 Control Panel 24
14L AIRFRYER
CONTROL PANEL
LED screen
80mmx40mm
Arrows - pantone metallic 877C
Button text is white
ON/OFF
Press ON/OFF to turn the Brio OFF and stop the cooking process.
START/PAUSE
Select a cooking function, press START/PAUSE to begin cooking. To
mute/unmute the beep from the unit, press and hold down START/
PAUSE for 2 seconds.
WARM
Press and hold down WARM for 2 seconds, if using independently,
the Brio will automatically begin.
PREHEAT
Press PREHEAT. The temp and time is adjustable using up and
down arrows. To begin, press START/PAUSE. Once it has reached
the set temperature the Brio will beep and a 5-minute countdown
will begin. Place your food into the Brio. The Brio will begin
automatically when closed.
SEAR
Press SEAR. If preferred, adjust Sear temp and time and press
START/PAUSE.
PROBE
Plug the Probe into Brio unit (Jack). Press PROBE and set Probe
target internal temperature for food using the up and down arrows.
Insert the other end of the Probe into your food. Press START/PAUSE
to begin cooking.
ROTISSERIE
After placing food on Skewer, in Basket and into the Brio, press
ROTISSERIE. Use the up and down arrows to adjust temp and time.
Press START/PAUSE to automatically turn spit and begin cooking.
PROGRAM
Press PROGRAM and press up or down arrows to choose preset
items (1-100) to cook. Press up or down arrows when in each cooking
function to adjust temps and times. Press START/PAUSE to begin the
chosen program.
DELAY
Set your temp and time. Press DELAY and press up or down arrows
to adjust Delay time. Adjustable up to 24 hours. After setting cooking
function and Delay time, press START/PAUSE. Press DELAY at any
time to cancel Delay.
STAGE
To add a cooking stage press STAGE once and adjust by pressing the
up or down arrows.
WATTS
Controls the power consumption of your Brio. The default wattage on
the Brio is 1800W. The lower wattage will consume less energy, ideal
if your home does not take 1800 watts. Press WATTS to adjust from
1800W to 900W to 1500W.

instructions nuwavenow.com
16 17
ENGLISH
nuwavenow.com
INSTRUCTIONS
16 17
Note: Preset temperatures
and times may need minor
adjustments to achieve your
desired results.
CAUTION: This appliance
cooks using hot air. DO NOT
ll the Baking Pan with oil.
Operation:
1. Place the Brio on a level,
even, and stable heat-
resistant surface.
2. Plug the Brio into a standard
wall socket. The power plug is
included.
Note: Do not cover or block the
vent located on the top or the
back of the Brio. Doing so can
prevent proper ventilation and
will adversely affect the cooking
results.
Probe Temp Guide
Meats Temp. Rare Med
Rare Med Med Well Well Time Min.
Chicken, breast
Turkey, breast
Duck, breast
360˚F 165*
6 - 8 per lb
7 - 9 per lb
5 - 7 per lb
Chicken, whole
Turkey, whole
Duck, whole
360˚F 165*
8 - 10 per lb
11 - 13
per lb
10 - 13
per lb
Chicken, thigh
Turkey, thigh
Duck, thigh
360˚F 165*
14 - 16
per lb
14 - 16
per lb
9 - 11 per lb
Steak 1" thick 350˚F 125˚F 135˚F 145˚F* 150˚F* 160˚F* 3 - 8
Burgers ½ lb 350˚F 125˚F 135˚F 145˚F* 155˚F* 160˚F* 5 - 7
Roast Beef
(bone-in)
Roast Beef
(boneless)
325˚F 125˚F 135˚F 145˚F* 150˚F* 160˚F*
15 - 20
per lb
10 - 15
per lb
Lamb (bone-in)
Lamb (boneless) 325˚F 125˚F 135˚F 145˚F* 150˚F* 160˚F*
15 - 20
per lb
10 - 15
per lb
Pork (bone-in)
Pork (boneless) 350˚F 145˚F* 150˚F* 160˚F*
15 - 20
per lb
10 - 15
per lb
Salmon,
Tuna, Halibut,
Swordfish
145˚F* 150˚F* 160˚F* 2 - 3
Fish Steaks 1"
thick 350˚F 145˚F* 150˚F* 160˚F* 5 - 7
Sausage 360˚F 160˚F* 4 - 5
Note: Times may vary. Consuming raw or undercooked meats, poultry, or seafood
may increase your risk of food borne illness. *To reduce the risk, cook your food to
USDA-safe temperatures.

instructions nuwavenow.com
18 19
ENGLISH
nuwavenow.com
INSTRUCTIONS
18 19
Getting Started
Press the up or down arrows
to adjust the temperature and
time.
1. Press ON/OFF to turn your
Brio on and off.
2. To adjust the cooking time,
press TIME.
• The default cooking time
is 15 minutes.
3. Press START/PAUSE to
begin cooking. The (:) will
ash, indicating your Brio is
now cooking.
• To pause cooking, press
START/PAUSE. The (:) will
no longer ash, indicating
the unit is now paused.
• To resume cooking
(unpause) press START/
PAUSE once again.
Note: Opening the door will
pause cooking, closing the door
will resume cooking. The light will
turn on automatically when the
door is open.
4. Once the Brio nishes
cooking, End will be
displayed and the unit will
beep three times.
• To mute/unmute the beep
from the unit, press and
hold down START/PAUSE
for 2 seconds.

1800

 
36 0F
LIGHT
Press LIGHT once to turn the
light on. Press again to turn off.
To change light bulb in oven, see
Light Bulb Replacement under
“Cleaning and Maintenance.”
WATTS
The default wattage of the Brio is
1800 watts.
1. To change the wattage,
press WATTS once. 900 will
illuminate, indicating the Brio
is now set to 900 watts.
2. Press WATTS again and
1500 will illuminate. The Brio
is now set to 1500 watts.
3. Press WATTS once more
and 1800 will illuminate,
indicating the Brio is now set
to the default of 1800 watts.
Note: If the wattage is changed
from 1800W to either 900W or
1500W and the Brio is unplugged,
the unit will remember the last
wattage setting when plugged
back in and turned on.
DELAY
Delay function is used to delay
your cooking start time.
Press the up or down arrows
to adjust the temperature and
time.
1. Press ON/OFF.
2. Press DELAY.
3. Delay time can be adjusted
up to 24 hours (24:00).


1800
0 1 00
:

• During delay the (:) will
ash, indicating the delay
time countdown has started.
4. To stop the Delay function at
any time press DELAY. The
unit will end the delay cycle
and move on to the next
cooking function.
• After delay time has
elapsed the unit will
automatically move on to
the next cooking function.
5. Once the Brio nishes
cooking your food, End will
be displayed and the unit will
beep three times.
TEMP
Press the up or down arrows
to adjust the temperature and
time.
1. Press TEMP to see or adjust
your cooking temperature.
2. Press START/PAUSE
to begin cooking at set
temperature.
TIME
Press the up or down arrows
to adjust the temperature
and time.

1800
36 0F


1800
00 15
:

1. Press TIME to see or adjust
cooking time.
2. Press START/PAUSE to
begin cooking at set time.
Notes: The following are
temperature and time ranges:
• 60˚F~200˚F: 00:00-99:99
(0 minutes to 99 days, 99
hours)
• 205˚F~ 275˚F: 00:00-99:00
(0 minutes to 99 hours)
• 280˚F~345˚F: 00:00-10:00
(10 hours)
• 350˚F~400˚F: 00:00-01:00
(1 hour)
STAGE
Stage cooking is used to
cook your foods at different
temperatures and times
throughout the cooking process.
Up to 5 stages of cooking
can be set. Delay, Preheat,
Sear 1, Sear 2, and Warm are
NOT considered stages in the
cooking process.
Press the up or down arrows
to adjust the temperature
and time.
1. Stage 1: Press ON/OFF.
• Default temperature and
time for Stage 1 cooking
is 360°F for 15 min.
2. Press TIME.

1800

36 0F 2

