NuWave Brio 36101 User manual

NuWave Brio®
4.5-Qt Healthy Digital
Air Fryer
Owner’s Manual & Complete Recipe Book

13
Owner's Manual
IMPORTANT SAFEGUARDS
READ ALL INSTRUCTIONS
When using electrical units, basic safety precautions should always be
followed including the following:
1. Do not touch hot surfaces Use handles or knobs.
2. To protect against electrical shock, do not immerse cord, plugs, or the Brio
in water or other liquids.
3. Do not operate any appliance with a damaged cord or plug or after the
appliance malfunctions or has been damaged in any manner. Return appliance
to the nearest authorized service facility for examination, repair, or adjustment.
4. If the power cord is damaged, do not attempt to operate the Brio.
5. Close supervision is necessary when any appliance is used near children.
This appliance is not intended for use by persons (including children) with
reduced physical, sensory or mental capabilities, or lack of experience
and knowledge, unless they have been given supervision or instruction
concerning use of the appliance by a person responsible for their safety.
6. The use of other accessories that are not intended to be used with
the Brio is not recommended. Doing so may damage the Brio and can
cause accidents.
7. NOT INTENDED FOR OUTDOOR USE.
8. Do not use appliance for other than intended use.
9. Do not let cord hang over edge of table or counter or touch hot surfaces.
10. Do not place on or near a hot gas, electric burner, and/or in a heated oven.
11. Extreme caution must be used when moving the Brio containing hot oil or
other hot liquids.
12. To disconnect, turn the Brio “OFF”, then remove plug from the wall outlet.
13. During air-frying, hot steam is released from the air outlet vent. Keep
hands and face at a distance from the steam and from the air outlet vent.
Also, be careful of hot steam and air when removing Fry Pan Basket.
14. Make sure the ingredients prepared in the Brio come out golden brown
instead of dark brown and not burnt. Remove any burnt remnants from Fry
Pan Basket during cleaning and before each use.
15. Never put the Brio against the wall or other appliances. There should be
at least 3 inches of free space for the back side, left/right sides, and the
upper side of the Brio. Do not place anything on top of the Brio.
16. Unplug the Brio from outlet when not in use and before cleaning. Allow the
Brio to cool before cleaning, putting on or taking off parts.
1 7. The Brio is not intended to be operated by means of an external timer or
separate remote-control system.
18. INTENDED FOR HOUSEHOLD USE ONLY.
19. Keep manual handy for future reference.

14 Owner's Manual
IMPORTANT SAFEGUARDS (Continued)
SAVE THESE INSTRUCTIONS
Read and understand the entire manual before using the Brio.
DO NOT USE THE UNIT FOR OTHER THAN INTENDED USE.
Note: Put the Brio on a surface that is horizontal, even, and stable.
This appliance is intended for normal household use. It is not intended to be
used in environments such as a kitchen staff of shops, offices, farms, or other
work environments. Nor is it intended to be used by clients in hotels, motels,
bed and breakfasts, and non-residential environments.
NOTICE: THE FAILURE TO FOLLOW ANY OF THE IMPORTANT
SAFEGUARDS, ADDITIONAL SAFEGUARDS, OR THE INSTRUCTIONS
FOR SAFE USE IS A MISUSE OF YOUR BRIO THAT CAN VOID YOUR
WARRANTY AND CREATE THE RISK OF SERIOUS INJURY.
Electrical Information
A short power-supply cord (or detachable power-supply cord) is
provided to reduce the risk resulting from becoming entangled in or
tripping over a longer cord. Longer detachable power-supply cords
or extension cords are available and may be used if care is exercised
in their use. If a longer detachable power-supply cord or extension
cord is used:
1. The marked electrical rating of the extension cord should be at least as
great as the electrical rating of the appliance.
2. The longer cord should be arranged so that it will not drape over the
countertop or tabletop where it could be pulled on or tripped over
unintetionally. The Brio should be operated on a separate electrical
outlet from other operating appliances due to wattage limitations. The
appliance has a polarized plug (one blade is wider than the other).
To reduce the risk of electric shock, this plug is intended to t into a
polarized outlet only one way. If the plug does not t fully into the outlet,
reverse the plug. If it still does not t, contact a qualied electrician. Do
not attempt to modify the plug in any way.
3. If the appliance is of the grounded type, the cord set or extension cord
should be a grounding-type 3-wire cord.
SEE OPERATING INSTRUCTIONS BEFORE USE
WARNING
In case of other problems, immediately unplug and contact
Customer Service Department.
1-877-689-2838 • help@nuwavenow.com

15
Owner's Manual
CAUTION
• Always put the ingredients to be fried in the Fry Pan Basket to
prevent direct contact with the heating components.
• Do not cover the air inlet and outlet openings while the
appliance is operating.
• Do not pour oil into the Base Tray or Fry Pan Basket, as this may
create a re hazard.
• Never touch the insides of the appliance while it is operating.
ADDITIONAL SAFEGUARDS
1. Do not place the Brio close to ammable materials, heating units,
or wet environments.
2. Height of ingredients placed in the Fry Pan Basket should comply with the
directions listed under “Operating Instructions”.
3. Do not put any other cooking pans in the Fry Pan Basket. Do not replace
any parts with other containers.
4. It is normal for some smoke to escape the Brio when heating for the
rst time.
5. If a lot of smoke is escaping from the air vent during operation, unplug the
Brio immediately and contact Customer Service.*
6. Do not move the Brio while in operation. Only after the Brio has completely
cooled should moving be attempted. Always wait for the Air Fryer to cool
down prior to handling it.
7. Children should be supervised to ensure that they do not play with
the appliance.
8. Never use a towel or other material or object to block the air vents.
9. If any trouble arises during operation, any service MUST be done by
NuWave, LLC or authorized by the manufacturer for repairs.
10. The appliance is not intended to be operated by means of an external
timer or separate remote-control system.
11. Do not disassemble the Brio or replace any parts without prior written
consent from the manufacturer.
12. Do not use metal utensils with the coated Fry Pan Basket or Fry Pan
Basket Net as this can damage the surface.
13. Make sure the Brio is always clean prior to cooking.
*Customer Service Department: 1-877-689-2838 • help@nuwavenow.com

16 Owner's Manual
PARTS DESCRIPTION
1
2
1. Air Fryer Power Base
Part #: 36256
2. Fry Pan Basket
Part #: 36252
3. Fry Pan Basket Net
Part #: 36253
4. Base Tray
Part #: 36251
4
START
PAUSE
PRE-
HEAT
ON
OFF
MENUWATTS
600 900 1500
PROG
COOK
TEMP
COOK
TIME
STAGEWARM
preh sear
redy wrm dly stg
temp
open
1 2
SEAR
DELAY
menu
time
prog
3

17
Owner's Manual
OPERATING INSTRUCTIONS
Before Use:
1. Remove all the packaging materials.
2. Remove the glue and labels on the Brio.
3. Clean the Base Tray and Fry Pan Basket with Fry Pan Basket Net
thoroughly with hot water, a nonabrasive sponge, and a mild dish detergent,
or in the dishwasher, top rack only.
4. Wipe the insides and outside of the Brio with a wet cloth. Do not immerse
the Brio in water.
Note: This appliance cooks using hot air. DO NOT ll the Fry Pan Basket
with oil.
Operation Preparation:
1. Place the Brio on a level, even, and stable heat-resistant surface.
2. Place the Base Tray and Fry Pan Basket in the Brio.
3. Plug the Brio into a standard wall socket. The power plug is included
in the package.
Note: Do not cover or block the vent located on the back of the Brio. Doing so
can prevent proper ventilation and will adversely affect the cooking results.
Operation Functions -
On/Off Function
1. Press "ON/OFF" once to turn the Brio on.
• The control panel will display “360F”, and "temp" indicating the
Brio is powered on. 360°F is the default temperature setting.
2. Press "ON/OFF" again to turn the Brio off. The LED light indicator
will remain lit above the last wattage used.
Wattage Function
The default wattage of the Brio is 1500 watts.
1. Press "ON/OFF".
2. To change the wattage, press "WATTS" once. The blue light will
illuminate above “600”, indicating that the Brio is now set
to 600 watts.
3. Press "WATTS" once more and the blue light above “900” will
illuminate. The Brio is now set to 900 watts.
4. Press "WATTS" again and the blue light above “1500” will
illuminate, indicating that the Brio is now set to the default
1500 watts.
Note: If the wattage is changed from the default 1500W to either
600W or 900W and the Brio is unplugged, the appliance will
remember the last wattage setting when plugged back in.
ON
OFF
WATTS

18 Owner's Manual
OPERATING INSTRUCTIONS (Continued)
Easy Start/Pause Function
1. Press "ON/OFF".
2. Press "START/PAUSE" once to begin cooking. The LED display
will show “00:15” and “time”. The “:” will ash to indicate that the
Brio is now cooking and a 15-minute countdown has begun.
The default is 360°F for 15 minutes.
3. To interrupt the cooking process, press "START/PAUSE" again.
4. To resume cooking or preheating, press "START/PAUSE" again.
Adjusting Temperature
The Brio is set to cook at 360°F by default.To set a different
cooking temperature:
1. Press "COOK TEMP" then use "+" or "-" to adjust the temperature
higher or lower. The LED display will show “temp” and the set
cooking temperature.
• The temperature will increase and decrease in
5°F increments.
2. To quickly adjust the temperature in larger increments, hold down
"+" or "-".
• The cooking temperature can be adjusted at any time during
the cooking process.
3. When "COOK TEMP" is pressed, the LED display will continue
to show the cooking temperature. To see the remaining or set
cooking time, simply press "COOK TIME".
Adjusting Time
The Brio is set to cook for 15 minutes by default.To set a different
cooking time:
1. Press "COOK TIME" then use "+" or "-" to adjust the time.
The LED display will show “time” and the set cooking time.
• The time will increase and decrease in 1-minute increments.
• To quickly adjust the time in larger increments, hold down "+"
or "-".
• The maximum selectable cooking time differs depending on
the selected cooking temperature.
• 100°F - 345°F: maximum cooking time is 99 hours,
59 minutes (99:59).
• 350°F - 400°F: maximum cooking time is 1 hour (01:00).
• The cooking time can be adjusted at any time during the
cooking process.
START
PAUSE
COOK
TEMP
COOK
TIME

19
Owner's Manual
OPERATING INSTRUCTIONS (Continued)
2. When "COOK TIME" is pressed, the LED display will continue
to show the cooking time with countdown. To see the set cooking
temperature, simply press "COOK TEMP".
Note: When the timer reaches 1 minute in the countdown, the LED
display will begin showing the remaining time in seconds (“:59”,
“:58”, etc).
Delay Function
The Delay Function is used to delay the cooking start time of the
Brio.The default delay time is 1 hour (01:00).
1. Press "ON/OFF".
2. Press "DELAY". The LED display will show “01:00”,
“time”, and “dly”.
• To adjust the delay time, press "+" or "-" until the desired delay
time is reached.
• The time will increase and decrease in 1-minute increments.
• To quickly adjust the time in larger increments, hold down "+"
or "-".
• The maximum time is 99 hours, 59 minutes (99:59).
3. Press "START/PAUSE" to begin delay time countdown.
• The set delay time will be displayed with countdown.
• The LED display will show “time”, “dly”, and “:” will ash,
indicating the Brio has started the delay countdown.
4. Once the delay countdown is complete, the Brio will begin
cooking at set cooking temperature and time (default is 360°F for
15 minutes).
Using DELAY with cooking function:
Example #1 Delay cooking 40 minutes, cook at 360°F
for 20 minutes:
1. Press "ON/OFF".
2. Press "COOK TIME", adjust to 20 (00:20) minutes.
3. Press "DELAY", adjust time to 40 (00:40) minutes.
4. Press "START/PAUSE".
Example #2 Delay cooking 60 minutes, cook at 400°F
for 10 minutes:
1. Press “COOK TIME”. Adjust time to 10 minutes (00:10) by
pressing “+” or “-“.
2. Press “COOK TEMP”. Adjust cooking temperature to 400F by
pressing “+” or “-“.
3. Press “DELAY”.
4. Press “START/PAUSE”.
DELAY

20 Owner's Manual
OPERATING INSTRUCTIONS (Continued)
Preheat Function
The Preheat function ensures that the Brio reaches the desired
temperature before cooking begins.The Preheat function is
perfect for food that require a crisper nish, such as, frozen
appetizers, French fries, or chicken wings. The Brio will preheat
to the temperature that is set for the function that follows the
preheat function.
1. Press [ON/OFF]. The LED display will show “360F” and “temp”.
2. Press [COOK TEMP] then use the [+] or [-] buttons to adjust the
temperature up or down. The LED display will show “temp” and
the set cooking temperature.
3. Press [COOK TIME] then use the [+] or [-] buttons to adjust the
time. The LED display will show “time” and the set cooking time.
4. Press [PREHEAT]. The LED display will show the set cooking
temperature, “temp” & “preh”.
5. Press [START/PAUSE]. The Brio will begin to preheat to the set
cooking temperature. The LED display will show the set cooking
temperature and will ash during preheating.
6. Once the preheat temperature is reached, the Brio will start a
5-minute countdown.
• The LED display will show “ready” and “5” will ash in the LED
display to indicate there are 5-minutes to place food in the Fry
Pan Basket.
• The Brio will maintain the preheat temperature during the
5-minute countdown. If the 5-minute countdown ends, the Brio
will turn off.
7. Open the Fry Pan Basket and place the food into the Basket. The
LED display will show “open”, indicating that the Fry Pan Basket
and Base Tray have been removed from the Brio.
8. Return the Fry Pan Basket and Base Tray to the Brio. This will
automatically start the Brio and begin the cooking process at the
set temperature and time.
Note:
• If the Fry Pan Basket and Base Tray are removed during
preheating, the Brio will automatically pause and start the
5-minute countdown.
• Replace the Fry Pan Basket and Base Tray to resume preheating.
Sear
Default - 400°F, 5 minutes.
PRE-
HEAT
SEAR

21
Owner's Manual
OPERATING INSTRUCTIONS (Continued)
Sear 1: Sear 1 will ALWAYS be the stage BEFORE the regular
cooking stage.
1. Press "ON/OFF".
2. Press "SEAR" one time. “sear”, “temp”, and “400F” will show on the
LED display and “1” will ash.
3. Press "START/PAUSE".
• The Brio will cook at 400°F for 5 minutes and then cook at
360°F for 15 minutes (default).
• When the Brio is nished cooking, the LED display will
show “End”.
To adjust the regular cooking temperature and time:
1. Press "ON/OFF".
2. Press "+" or "-" and adjust to the desired temperature.
3. Press "COOK TIME" and "+" or "-" to adjust the desired time.
4. Press "SEAR" one time.
5. Press "START/PAUSE". The Brio will:
• Sear at 400°F for 5 minutes.
• Cook at selected temperature and time.
• Finish cooking and display “End”.
Sear 1 2: Default - 400°F, 5-minutes.
1. Press "ON/OFF".
2. Press "SEAR" twice. “sear”, “temp”, and “400F” will be displayed
and “1” and “2” will ash.
3. Press "START/PAUSE".
• The Brio will sear at 400°F for 5 minutes (sear 1), then cook at
360°F for 15 minutes (default). Next, it will sear again at 400°F
for 5 minutes (sear 2).
4. When the Brio is nished cooking, it will display “End”.
To adjust the regular cooking temperature and time:
1. Press "ON/OFF".
2. Press "+" or "-" and adjust to the desired temperature.
3. Press "COOK TIME" and "+" or "-" to adjust the desired time.
4. Press "SEAR" twice.
5. Press "START/PAUSE". The Brio will:
• Sear at 400°F for 5 minutes (sear 1).
• Cook at selected temperature and time.
• Sear again at 400°F for 5 minutes (sear 2).
• Finish cooking and display “End”.

22 Owner's Manual
OPERATING INSTRUCTIONS (Continued)
Sear 2: Default - 400°F, 5 minutes.
1. Press "ON/OFF".
2. Press "SEAR" three times. “sear”, “temp”, and “400F” will be
displayed and “2” will ash.
3. Press "START/PAUSE".
• The Brio will cook at 360°F for 15 minutes (default), then sear
at 400°F for 5 minutes (sear 2).
• When the Brio is nished cooking, it will display “End”.
To adjust the regular cooking temperature and time:
1. Press "ON/OFF".
2. Press "+" or "-" and adjust to the desired temperature.
3. Press "COOK TIME" and "+" or "-" and adjust to the desired time.
4. Press "SEAR" three times.
5. Press "START/PAUSE". The Brio will:
• Cook at selected temperature and time.
• Sear at 400°F for 5 minutes.
• Finish cooking and display “End”.
Stage Function
A maximum of 5 stages can be programmed into the Brio.
1. Press "ON/OFF".
• The Brio LED display will show the default cooking
temperature ("360F") and “temp”. This is stage 1 cooking.
• Adjust cooking temperature by pressing "+" or "-" to reach the
desired temperature.
• Adjust cooking time by pressing "COOK TIME" and "+" or "-"
to reach the desired cooking time.
2. Press "STAGE". The LED display will show default cooking
temperature ("360F"), “temp”, and “stage 2”.
• To adjust the cooking temperature for stage 2, press "+" or "-"
to reach the desired temperature.
• Adjust cooking time by pressing "COOK TIME". The LED
display will show “time”, “stage 2", and “00:00”. Press "+" or "-" to
reach the desired cooking time.
3. Press "STAGE" again to program a third stage of cooking.
The LED display will show default cooking temperature ("360F"),
“temp”, and “stage 3”.
• To adjust the cooking temperature for stage 3, press "+" or "-"
to reach the desired temperature.
STAGE

23
Owner's Manual
4. Adjust cooking time by pressing "COOK TIME". The LED display
will show “time”, “stage 3", and “00:00”. Press "+" or "-" to reach the
desired cooking time.
• A maximum of 5 stages can be programmed.
5. Press "START/PAUSE" to begin cooking. The Brio will cook,
following the stages programmed.
Example: Cook Stage 1 at 300°F for 17 minutes » Cook Stage 2 at
360°F for 30 minutes » Cook Stage 3 at 400°F for 5 minutes.
1. Press "ON/OFF". Press "+" or "-" to adjust cooking temperature
to “300F”.
2. Press "COOK TIME". Press "+" or "-" to adjust cooking time
to “00:17”.
3. Press "STAGE". Press "+" or "-" to adjust cooking temperature
to “360F”.
4. Press "COOK TIME". Press "+" or "-" to adjust cooking time
to “00:30”.
5. Press "STAGE". Again, press "+" or "-" to adjust cooking
temperature to “400F”.
6. Press "COOK TIME". Again, press "+" or "-" to adjust cooking
time to “00:05”.
7. Press "START/PAUSE".
Menu Function
The Brio comes with 20 menu selections already
pre-programmed for quick and easy cooking. Cooking times
listed are suggestions, but may need to be adjusted depending
on desired preferences.
1. Press "MENU". The LED display will show “menu” and “01”.
• Continue to press "MENU" until the number of the desired
menu shows in the LED display.
2. Press "START/PAUSE". The Brio will cook the chosen menu at
the preset temperature and time.
Note: Temperature and time can be adjusted during cooking by
pressing "COOK TEMP" and "COOK TIME", and pressing "+" or "-".
MENU
OPERATING INSTRUCTIONS (Continued)

24 Owner's Manual
OPERATING INSTRUCTIONS (Continued)
Program Function
Preset Programs: Preset Programs given numbers 1~100. The
user CANNOT adjust these programs.
1. Press "ON/OFF". The LED display will show “360F” and “temp”.
2. Press "PROG". The LED display will show “prog” and “1”.
• Preset program numbers can be chosen between 1 and 100.
• Continue to press "+" or "-" until the desired number is
reached.
3. Press "START/PAUSE". The Brio will begin cooking following the
programmed recipe.
Note: Refer to Program Menu Items for preprogrammed recipes
1-100.
Store 101-200 presets. Option 1: Enter cooking recipe rst.
1. Press "ON/OFF". The LED display will show “360F” and “temp”.
2. Press "COOK TEMP". Press "+" or "-" to adjust the temperature
higher or lower. The LED display will show “temp” and the set
cooking temperature.
3. Press "COOK TIME". Press "+" or "-" to adjust the time.
The LED display will show “time” and the set cooking time.
4. Press "STAGE". The LED display will show default cooking
temperature ("360F"), “temp” and “stage 2”.
• To adjust the cooking temperature for stage 2, press "+" or "-"
to reach the desired temperature.
• Adjust cooking time by pressing "COOK TIME". The LED
display will show “time”, “stage 2", and “00:00”. Press "+" or "-"
to reach the desired cooking time.
5. Press "STAGE" again to program a third stage of cooking.
The LED display will show default cooking temperature ("360F"),
“temp”, and “stage 3”.
• To adjust the cooking temperature for stage 3, press "+" or "-"
to reach the desired temperature.
• Adjust cooking time by pressing "COOK TIME". The LED
display will show “time”, “stage 3", and “00:00”. Press "+" or "-"
to reach the desired cooking time.
• A maximum of 5 stages can be programmed.
6. Press "PROG". The LED display will show “prog” and “101”.
7. Press "+" or "-".
• Program numbers can be chosen between 101 and 200.
• Continue to press "+" or "-" until the desired number
is reached.
PROG

25
Owner's Manual
8. Press "PROG" again to save the recipe to the desired
program number.
9. Press "START/PAUSE". The Brio will begin cooking following the
programmed recipe.
Option 2. Save the program after cooking has completed.
After completing a cooking cycle, it can be saved as a program.
1. When cooking is complete, press "PROG". The LED display will
show “prog” and “000”.
2. Press "+" or "-". The LED display will show “101”.
Program numbers can be chosen between 101 and 200.
• Continue to press "+" or "-" until the desired number
is reached.
3. Press "PROG" again to save the recipe to the desired
program number.
Memory Recall
1. Press "PROG". The LED display will show “prog” and “000”.
2. Press "+" or "-". The LED display will show “101”.
Program numbers can be chosen between 101 and 200.
• Continue to press "+" or "-" until the desired saved program
number is reached.
3. Press "START/PAUSE". The Brio will cook following the
programmed recipe.
Editing and Modifying a Saved Program
1. Recall the program to edit. Press "STAGE" until the stage to edit
is reached.
2. Press "COOK TEMP". Press "+" or "-" to adjust the temperature
higher or lower. The LED display will show “temp” and the new
set cooking temperature.
3. Press "COOK TIME". Press "+" or "-" to adjust the time. The LED
display will show “time” and the new set cooking time.
• If another cooking stage needs to be edited, press "STAGE"
until the stage to edit is reached then repeat steps above.
• To save the edited program, press "START/PAUSE", or
press "PROG" and follow the programmed recipe steps
mentioned earlier.
OPERATING INSTRUCTIONS (Continued)

26 Owner's Manual
Note: If a program number is chosen to save a recipe that has
already been programmed with another recipe, the new program will
override the previous recipe.
Warm Function
The Warm function is used to keep food items warm.
1. Press "ON/OFF".
2. Press "WARM". The LED display will show “wrm”, “temp”, and
“140F” (default warm temperature).
• To adjust the warm temperature, press "+" or "-" to reach the
desired warming temperature.
• To adjust the amount of time the Brio will keep food warm,
press "COOK TIME" and then press "+" or "-" to reach the
desired warming time. The default warm time is 30 minutes
(00:30). The maximum warming time is 12 hours (12:00).
Note: 12 hours for temperatures under 140˚F.
3. Press "START/PAUSE" to begin cooking. The Brio will go into
warm mode.
4. To leave the warm function, press "WARM" and “warm” will no
longer show on the LED display.
Note: To add warm function after cooking, set the cooking
instructions the press "WARM" and adjust warm temperature and
time as needed. The Brio will cook at set instructions then warm
after cooking.
WARM
OPERATING INSTRUCTIONS (Continued)

27
Owner's Manual
OPERATING INSTRUCTIONS (Continued)
Removing the Fry Pan Basket
To remove the Fry Pan Basket from the BaseTray:
1. Push the demounting button forward.
2. Lift the Fry Pan Basket up off the Base Tray while holding the handle.
This will reduce the extra weight of the Base Tray and makes it easier
to pour smaller foods, such as French fries.
Fry Pan
Basket
Base Tray
1
Air Fryer 2
Fry Pan
Basket
Base Tray
Basket Net
For Best Results
After selecting cooking time and temperature, and ready to add ingredients to
the Brio, pull out the Base Tray and Fry Pan Basket from the Air Fryer. (Fig. 1)
Note: Do not ll more than 4⁄ 5full. Slip the Fry Pan Basket in place in the
Brio. Do not use the Base Tray without the Fry Pan Basket in it. (Fig. 2.)
Do not touch the insides of the Base Tray immediately after cooking, as the
Base Tray, Fry Pan Basket, and Fry Pan Basket Net can become very hot.
Only hold the Base Tray and Fry Pan Basket by the handle.
3
1 2

28 Owner's Manual
OPERATING INSTRUCTIONS (Continued)
DO NOT PUSH THE
DEMOUNTING
BUTTON FORWARD
WHILE SHAKING.
X
Shaking Food:
Some foods require shaking halfway
through cooking. To properly shake the
food, hold the handle, remove the Base
Tray from the appliance, and shake.
Once the food has been adequately
shaken, slide the Base Tray and Fry Pan
Basket back into the Brio.

29
Owner's Manual
CARE & MAINTENANCE
Cleaning
Clean the appliance after every use or in between a number of large batches.
The Fry Pan Basket and the Base Tray have a non-stick coating with a
stainless steel Basket Net. Do not use metal utensils or harsh abrasives when
cleaning as this can damage the coating.
1. Unplug the appliance and make sure it cools completely.
Note: Remove the Base Tray and Fry Pan Basket and place on a heat-
resistant surface to help cool the appliance quicker.
1. Use a damp cloth to wipe the outside of the appliance.
2. Clean the Fry Pan Basket and inside components with a nonabrasive
sponge, hot water, and mild detergent.
Note: If using the dishwasher for the Base Tray, Fry Pan Basket, and Fry Pan
Basket Net, it is recommended to use top rack only.
Tip: If there is residual food in the Base Tray and Fry Pan Basket, add some
hot water and let it soak separately for about 10 minutes for easier cleaning.
1. Clean the insides of the appliance with a nonabrasive sponge and
hot water.
2. Once cooled completely, clean the Fry Pan Basket, Fry Pan Basket Net, and
Base Tray with a soft cleaning brush to remove any lingering food.
Storage:
1. Unplug the appliance and let it cool down completely.
2. Make sure that all the parts are cleaned and dry.
3. Push the power cord into the storing capsule.
Fix the cord by inserting it into the cord
xing unit.
IMPORTANT - Do not immerse unit in water
or attempt to cycle through dishwasher.
The outer surface may be cleaned by wiping
carefully with a damp dishcloth or sponge.
Make sure unit has cooled completely prior
to cleaning.
WARNING
Any other servicing should be performed by an authorized
service representative.

30 Owner's Manual
TROUBLESHOOTING GUIDE
PROBLEM: POSSIBLE CAUSE(S): RESOLUTION(S):
The Brio does
not work.
The appliance is not
plugged in.
Did not press "ON/
OFF" button.
Fry Pan Basket is not
in the Brio.
Insert the plug into an
appropriate grounded power
socket. Press "ON/OFF"
button after settings are
selected. Place the Fry Pan
Basket in the Brio.
The ingredients
fried in the Fry Pan
Basket are not
completely cooked.
Too many ingredients
were used. The cooking
temperature is too low.
The cooking time is
too short.
Remove some ingredients
from the Fry Pan Basket;
smaller batches are fried
more evenly. Fry at a higher
temperature. Set the Brio to
air-fry for a longer time.
The food is
fried unevenly.
Certain types of
ingredients need to be
shaken halfway through
the cooking time.
Ingredients that are on
the top need to be shaken
halfway through the
cooking time.
Fried snacks are not
crispy when they
come out of the Brio.
You used a type of
snack meant to be
prepared in a traditional
deep fryer.
Use snacks designed to
be baked in a traditional
oven, or lightly brush some
olive oil onto the snacks
beforehand for a
crispier result.
Cannot slide the Fry
Pan Basket into the
appliance properly.
The Fry Pan Basket is
overlled. The Fry Pan
Basket is not placed in
the Base Tray correctly.
Do not ll the Fry Pan
Basket more than 4/5 full.
Push the Fry Pan Basket
down into the Base Tray until
you hear a click.

31
Owner's Manual
PROBLEM: POSSIBLE CAUSE(S): RESOLUTION(S):
White smoke is
coming out of
the product.
You are frying greasy
foods.The Fry Pan
Basket Net contains
greasy residue from
previous uses.
When preparing greasy
ingredients in the Air
Fryer, large amounts
of oil can smoke and
inltrate Fry Pan Basket.
The oil will produce
white smoke and the
Fry Pan might become
hotter than usual. This
will not affect the nal
cooking effect. White
smoke is caused by
grease heating up in the
Fry Pan Basket.
Make sure you clean Fry
Pan Basket properly
after use.
French fries are fried
unevenly in the Brio.
You did not soak the
potato sticks properly
before you fried them.
You did not use the
right potato type or
they were not fresh.
Soak potato sticks in a
bowl of water for at least 30
minutes, take them out, and
dry with paper towels.
Use fresh potatoes and make
sure they stay rm during
frying.
French fries are not
crispy when they
come out of the Brio.
The crispiness of the
fries depends on the
amount of oil and water
in the fries.
Dry the potato sticks
properly before adding the
oil and placing in the Brio.
Cut the potato sticks smaller
for a crispier result. Add
slightly more oil to potatoes
before placing in Brio for a
crispier result.
If the unit needs to be replaced or returned to the manufacturer,
please contact our Customer Service Department at: 1-877-689-2838
or help@nuwavenow.com
TROUBLESHOOTING GUIDE (Continued)
Contact Customer Service if any of these errors occur:
Code
Error
E1 E2 E3
Sensor open
ended
Sensor short
circuit Overheat
Table of contents
Other NuWave Fryer manuals

NuWave
NuWave Brio 14Q User manual

NuWave
NuWave BRIO User manual

NuWave
NuWave Brio 15.5Q User manual

NuWave
NuWave Brio 37001 User manual

NuWave
NuWave Brio 10Q User manual

NuWave
NuWave Brio 14Q User manual

NuWave
NuWave BRIO Quick guide

NuWave
NuWave Brio 36001 User manual

NuWave
NuWave NuWave Brio 3Q User manual

NuWave
NuWave Brio 36102 User manual

NuWave
NuWave Brio 37380 User manual

NuWave
NuWave Brio 8Q User manual

NuWave
NuWave BRAVO XL SMART OVEN User manual

NuWave
NuWave Bravo XL User manual

NuWave
NuWave Brio 14Q Quick guide

NuWave
NuWave BRIO User manual

NuWave
NuWave Brio 4.5Q User manual

NuWave
NuWave Bravo XL User manual

NuWave
NuWave Brio 7.25Q User manual

NuWave
NuWave Brio 15.5Q User manual
