Oakton EcoTestr CTS1 User manual

Operating Manual
EcoTestr CTS1 Pocket Tester
•The batteries have been pre-installed. Please pull out the
insulating paper before first-time use. When replacing batteries,
the positive side (+) of every single battery must face up. Please
check the detail in "Battery Installation" section.
• Before shipment, the factory adds in some water droplets to the
tester's cap. This ensures that the probe keeps its sensitivity. This
practice of adding several drops of water into the cap to keep
sensor activation is highly recommended when storing the tester.
Calibration
1. The tester only needs to be calibrated for conductivity, then
press to switch to Conductivity → TDS→ Salinity.
2. Press and switch to conductivity mode, rinse the probe in
distilled water and shake off excess water.
3. Long press to enter calibration mode; short press to exit.
4. Dip the probe into 1413 μS/cm calibration solution. Stir gently,
leave it to stand. Wait for the measurement stability icon () to
appear and stay on the display, then short press to complete
the 1st calibration. Tester returns to measurement mode, and
calibration icon “M” appears on the bottom left side of display.
5. Rinse probe in distilled water and shake off excess water. Repeat
#3 and #4 to complete 2nd calibration in 12.88 ms/cm calibration
solution. Tester returns to measurement mode, and calibration
icon “M” and “H” will appear on the bottom left side of display.
1. Short press to turn on the tester, short press to switch to
the desired measurement mode (Conductivity, TDS or salinity).
Rinse probe in distilled water and shake off excess water.
2. Stir the probe in the sample solution gently, leave it to stand. Wait
for the stability icon () to stay on screen, then take the reading.
3. Rinse off the probe thoroughly in distilled water after each test.
• If probe response is slow, we recommend soaking the probe in
12.88 mS/cm solution for 15 to 30 minutes to restore its
sensitivity. Re-calibrate the tester after rinsing. Please add
several drops of water into the cap to keep sensor activation
when storing the tester.
• The tester adopts 1413 μS/cm and 12.88 mS/cm standard
calibration solutions. User can use 1 or 2 point calibrations as
needed. For most circumstances, calibrating in 1413 μS/cm to
• Restore to factory default (P5) description: Select "Yes" in P5 to
restore the calibration to the theoretical values and parameter
setting to original values. When tester's calibration or
measurement performs abnormally, this function can be adopted
so the tester returns to factory default setting and then users can
conduct calibration or take measurements again.
Conductivity of the solution TDS factor (P2)
0to 100 µS/cm 0.60
100 to 1000 µS/cm 0.71
1 to 10mS/cm 0.81
10to 100 mS/cm 0.94
• Conductivity range (P1) description: Aut - all ranges: 0~2000
μS/cm, 0.01~20.00mS/cm. Once the readings are greater than
2000 μS/cm, the unit will automatically become mS/cm.
1 mS/cm = 1000 μS/cm. μS - only μS/cm range: 0~2000 μS/cm;
mS/cm - only mS/cm range: 0.01~20.00 mS/cm.
• TDS factor (P2) description: User can adjust TDS factor by
experimental data or experience. The following chart lists some
commonly used TDS factors for reference:
Symbol Menu setting Selection Factory default
P1 Select conductivity range* Aut* – μS – mSAut
P2
Select TDS factor
0.40~1.00
0.71
P3 Select salinity unit ppt – g/L ppt
P4 Select temperature unit ℃– ℉/
P5 Restore to factory default
No – Yes
No
When test is off, long press to enter setup mode → short
press to switch P1-P2...P5, short press and parameter will
flash →press to choose desired parameter → short press to
confirm parameter selection → long press to return to
measurement mode.
Keypad Functions
Short press =< 2 seconds
Long press => 2 seconds
CAL
MODE
1. Short press to turn on; long press to turn off.
2. When turned off, long press to enter setup mode.
3. In mode setting , short press to change parameter.
1. In measurement mode, long press to enter calibration mode,
short press to switch Conductivity, TDS and Salinity.
2. In calibration mode, short press to confirm calibration.
3. In mode setting, short press to confirm parameter selection.
MEAS
complete 1st point calibration will meet testing requirements.
• The tester has already been calibrated before leaving factory.
User can use the tester immediately or can test it in the standard
calibration solutions to evaluate its accuracy. If error is large,
calibrate the tester before using.
• We recommend replacing the calibration solution after 5 to 10
calibrations to maintain accuracy.
• The surface coating of probe sensor bar is firm platinum black
processed with special techniques. It improves measuring
performance and coating firmness. If the probe is contaminated. it
can be gently brushed with a soft brush in warm soap water or
alcohol.
Self-Diagnostic Messages
Symbol Self-diagnosis
information How to fix
• Check if calibration solution is
correct.
• Check if probe is damaged.
is pressed
before measurement
is stable (appears
and stays)
Wrong calibration
solution, or measured
value is not within the
range of the tester
Wait for the measurement stability
icon () to appear and stay,
then press
TM
Special Notes
Measurement (Conductivity, TDS & Salinity)
Notes:
Setting the Parameter
Notes:

Cap Lock Clip Battery Lid
Lift the clip to unlock
4×AAA
Batteries
Push the clip to open the battery lid
①
②
③
④
⑤
⑥
⑦
www.coleparmer.com
Ordering Information
Model Product description
CTS1
EcoTestr pocket
conductivity/TDS/salinity tester
Conductivity
Range
0~200.0µS/cm,
0~2000µS/cm, 0~20.00mS/cm
Resolution
0.1/1µS/cm
，
0.01 mS/cm
Accuracy
±1%FS
Calibration points
1~2 points; auto standard
recognition
Automatic temperature
compensation
3 to 122 （0~50℃）
TDS
Range
0~100.0ppm,
0~1000ppm, 0~10.00ppt
Accuracy ±1%FS
Automatic temperature
compensation
32 to 122 0~50℃）
Salinity
Range
0~10.00ppt
（
ppm
）
Accuracy ±1%FS
Automatic temperature
compensation
32 to 122 0~50℃）
Temperature
Range
32 to 122 0~50℃）
Resolution
0.1
/
Accuracy
±0.9 0.5
℃）
10650101_MAN_CTS1_35462-11 March 2021
+
-
+
-
+
-
+
-
℃
Power: four AAA batteries (included); >400 hours of continuous
operation
Low-voltage warning: battery status icon flashes
Auto power-off: tester automatically turns off after 8 minutes of
nonuse
IP rating: IP67 (waterproof), floats on water when sensor cap is on
Dimensions (L x W x H): 7" x 1.5" x 1.25" (17.8 x 4 x 3.1 cm)
Weight: 3.8 oz (107 g)
Battery Installation
The tester uses four AAA batteries. Please install batteries
according to the following steps. Note the correct direction of battery
installation: the positive side (+) of every single battery must face
up. Incorrect installation of batteries will cause damage to the tester
and create a potential hazard.
1. Pull the battery cap up.
2. Slide the battery cap along the direction of arrow.
3. Open the battery cap.
4. Insert the batteries (ALL POSITIVE SIDES FACING UP).
5. Close the battery cap.
6. Slide and lock the battery cap along the direction of arrow.
7. Fit the tester’s cap while making sure to push all the way down.
The tester’s waterproof design may be compromised if the cap is
not fitted correctly.
Warranty
We warrant this instrument to be free from defects in material and
workmanship and agrees to repair or replace free of charge, at
option of Oakton Instruments, any malfunctioned or damaged
product attributable to responsibility of Oakton Instruments, for a
period of two years from the delivery (a six-month limited warranty
applies to probes). This warranty does not apply to defects resulting
from actions such as misuse (violation of the instructions in this
manual or operations in the manner not specified in this manual),
improper maintenance, and unauthorized repairs. Warranty period is
the time limit to provide free service for the products purchased by
customers, not the service life of the tester or probe.
Oakton Instruments reserves the right to update the information in
this manual without giving notice in advance.
Specification
35462-11
Catalog
number
00653-18
00606-10
－
－
1413 μS Conductivity Standard 500 mL
12.88 mS conductivity standard 500 mL
