OEM Tools 24383 Service manual

UNPACKING
After unpacking unit, inspect carefully for any damage that may
have occurred during transit. Check for loose, missing, or damaged
parts. If any damage is observed, a shipping damage claim must be
filed with carrier. Do not use the Video Borescope if broken, bent,
cracked or damaged parts (including labels) are noted. Any Video
Borescope that appears damaged in any way, operates abnormally
or is missing parts should be removed from service immediately.
If you suspect that the Video Borescope was subjected to a
shock load (a load that was dropped suddenly, unexpectedly, etc.)
immediately discontinue use until it has been checked by a factory
authorized service center.
Please read and save these instructions. Read through this owner’s manual carefully before using product. Protect
yourself and others by observing all safety information, warnings, and cautions. Failure to comply with instructions
could result in personal injury and/or damage to product or property. Please retain instructions for future reference.
Operating Instructions and Parts Manual 24383
FOR CUSTOMER SERVICE
Technical Question?
CALL 1-866-458-2472
[email protected]
VIDEO BORESCOPE
The following safety information is provided as a guideline to help you operate your Video Borescope under the
safest possible conditions. Any tool or piece of equipment can be potentially dangerous to use when safety or
safe handling instructions are not known or not followed. The following safety instructions are to provide the
user with the information necessary for safe use and operation. Please read and retain these instructions for the
continued safe use of your tool. Failure to follow instructions listed below may result in serious injury. In addition,
make certain that anyone who uses the equipment understands and follows these safety instructions as well.
Thank you very much for choosing an OEMTOOLS®Product!
For future reference, please register your new tool at www.oem-tools.com and complete the owner’s record below:
Model: _______________ Purchase Date: ___________
Save the receipt, warranty and these instructions. It is important that you read the entire manual to become
familiar with this product before you begin using it. This product is designed for certain applications only.
OEMTOOLS®cannot be responsible for issues arising from modification. We strongly recommend this
product is not modified and/or used for any application other than that for which it was designed. If you have any
questions relative to a particular application, DO NOT use the product until you have first contacted customer
service to determine if it can or should be performed on the product.
WARNING
Explanation of Safety Signal Words
WARNING: Indicates a potentially hazardous situation which, if not avoided, could result in death or serious injury.
CAUTION: Indicates a potentially hazardous situation which, if not avoided, may result in minor or moderate injury.
CAUTION: Used without the safety alert symbol indicates a potentially hazardous situation which, if not avoided,
may result in property damage.
NOTES:Provide clarity and helpful information.
11/16
2016 OEMTOOLS®

2
Operating Instructions and Parts Manual 24383
VIDEO BORESCOPE
11/16
2016 OEMTOOLS®
IMPORTANT INSTRUCTIONS
AND SAFETY RULES
1. Know your tool. Read this manual carefully. Learn
the tool’s applications and limitations, as well as,
potential hazards specific to it.
2. Keep work area clean and well lit. Cluttered or dark
work areas invite accidents.
3. Keep children away. All children should be kept
away from the work area. Never let a child handle
a tool without strict adult supervision.
4. Do not operate this tool if under the influence
of alcohol or drugs. Read warning labels on
prescriptions to determine if your judgment or
reflexes are impaired while taking drugs. If there is
any doubt, do not attempt to operate.
5. Use safety equipment. Eye protection should be
worn at all times when operating this tool. Use ANSI
approved safety glasses. Everyday eyeglasses are
NOT safety glasses. Dust mask, non-skid safety
shoes, hard hat or hearing protection should be used
in appropriate conditions.
6. Wear proper apparel. Loose clothing, gloves, neck-
ties, rings, bracelets or other jewelry may present a
potential hazard when operating this tool. Keep all
apparel clear of the tool.
7. Don’t overreach. Keep proper footing and balance
at all times when operating this tool.
8. Check for damage. Check your tool regularly. If
part of the tool is damaged it should be carefully
inspected to make sure that it can perform its
intended function correctly. If in doubt, the part
should be repaired. Refer all servicing to a qualified
technician. Consult your dealer for advice.
9. Keep away from flammables. Do not attempt
to operate this tool near flammable materials
or combustibles. Failure to comply may cause
serious injury or death.
10. Store idle tools out of the reach of children and
untrained persons. Tools may be dangerous in the
hands of untrained users.
11. Maintain tools with care.
12. Keep tools dry and clean.
13. Properly maintained tools are less likely to
bind and are easier to control. Do not use a
damaged tool. Tag damaged tools “Do not
use” until repaired.
14. Check for misalignment or binding of moving
parts, breakage of parts, and any other condition
that may affect the tool’s operation.
15. If damaged, have the tool serviced before
using. Many accidents are caused by poorly
maintained tools.
16. Use only accessories that are recommended by
the manufacturer for your model. Accessories
that may be suitable for one tool may become
hazardous when used on another tool.
17. Tool service must be performed only by qualified
repair personnel. Service or maintenance
performed by unqualified personnel could result in
a risk of injury.
18. When servicing a tool, use only identical replacement
parts. Use of unauthorized parts or failure to follow
maintenance instructions may create a risk of injury.
19. Maintain a safe working environment. Keep the
work area well lit. Make sure there is adequate
surrounding workspace. Keep the work area free
of obstructions, grease, oil, trash, and other debris.
Do not use this product in a damp or wet location.
20. Maintain labels and nameplates on this product.
These carry important information. If unreadable or
missing, contact OEMTOOLS®for a replacement.
21. Before use, read and understand all warnings,
safety precautions, and instructions as outlined
in the vehicle manufacturer’s service manual. It
is beyond the scope of this manual to properly
describe the correct procedure and test data for
each vehicle.
22. Always perform vehicle service in a properly
ventilated area. Never run an engine without proper
ventilation for its exhaust. Stop work and take
necessary steps to improve ventilation in the work
area if you develop momentary eye, nose, or throat
irritation as this indicates inadequate ventilation.
23. Engine parts that are in motion and unexpected
movement of a vehicle can injure or kill. When
working near moving engine parts, wear snug fit
clothing and keep hands and fingers away from
moving parts. Keep hoses and tools clear of
moving parts. Always stay clear of moving engine
parts. Hoses and tools can be thrown through the
air if not kept clear of moving engine parts.
24. The unexpected movement of a vehicle can injure
or kill. When working on vehicles always set the
parking brake and chock the wheels.

3
Operating Instructions and Parts Manual 24383
VIDEO BORESCOPE
11/16
2016 OEMTOOLS®
25. Avoid accidental fire and/or explosion. Do not
smoke near engine fuel and battery components.
26. The warnings, precautions, and instructions
discussed in this manual cannot cover all
possible conditions and situations that may
occur. The operator must understand that
common sense and caution are factors which
cannot be built into this product, but must be
supplied by the operator.
27. For safety purposes and the prevention of
damage to expensive components it is advised
that the user have an understanding of basic
automotive repair and a working knowledge of
automotive systems.
28. We believe the information contained herein to be
reliable. However, general technical information
is given by us without charge and the user shall
employ such information at their own discretion
and risk. We assume no responsibility for results or
damages incurred from the use of such information
in whole or in part. Always refer to specific
instructions and technical information supplied by
vehicle manufacturer.
29. The manufacturer declines any and all responsibility for
damage to vehicles or components if said damage
is the result of unskillful handling by the operator
or of failure to observe the basic safety rules set
forth in the instruction manual.
30. This equipment is intended only for professional
use by personnel trained in performing the service
functions for which it is has been designed.
31. This equipment is designed for servicing a variety
of vehicles in a safe, convenient manner. However,
differences in vehicle makes and models may make
it impossible to use this equipment as it is intended.
Do not attempt to force the use of this equipment on
an application for which it is not designed to perform.
32. The procedures documented in this manual are to
serve as guidelines for the use of this equipment.
33. In addition to these guidelines, always follow the
manufacturer’s recommended procedures when
servicing each unique vehicle.
34. The use of this equipment is simple and
straightforward if you follow the instructions. When
operating this equipment, use common sense, and
always stop to think before using this tool.
DISPOSAL
At the end of the useful life of the Video Borescope,
dispose of the components according to all state,
federal and local regulations.
PURPOSE
The OEMTOOLS®Video Borescope is an ideal tool
for inspecting difficult-to-reach areas normally hidden
from sight. This ergonomic Video Borescope features
a 2.4" full color LCD screen, auto focus and viewing
capacity as close as 1" with crystal clear output.
The multipurpose Video Borescope is suitable for
internal inspection of cylinder bores and vehicle
compartments/components. Ideal for the inspection of
engines, machinery, buildings and infrastructure.
PRODUCT SPECIFICATIONS
Display: 2.4" TFT LCD
320 x 240 Pixels
Interface: AV Out
Imager Head Diameter: 9 mm
Imager Head Cable Length: 1 Meter
Frame Rate: -30 FPS
Field of View (FOV): 57 Degree
Depth of Field (DOF): 3 cm - 7 cm
Light Source: 4 Adjustable LED
Power Supply: 4 AA Battery
Image Sensor: 1/6” VGA Sensor
Resolution (Dynamic/Static): 640 (H) x 480 (V)
Waterproof Rating: IP 67
TV Out: NTSC and PAL
Useful Tools: Magnet, Mirror and Hook

4
Operating Instructions and Parts Manual 24383
VIDEO BORESCOPE
11/16
2016 OEMTOOLS®
NOTE
Not all components of the Video Borescope are
replacement items, but are illustrated as a convenient
reference for location and position in the assembly
sequence.
(A)
9 mm
Imager
Head and
Cable
Figure Description Quantity
A 9 mm Imager Head and Cable 1
B Magnet, Hook and Mirror 1
C Video-Out Cable (TV-Out Cable) 1
D Carrying Case (Not Shown) 1
E Manual (Not Shown) 1
NOTE
Not all components of the Video Borescope are
replacement items, but are illustrated as a convenient
reference for location and position in the assembly
sequence.
(B)
Magnet, Hook
and Mirror
(C)
Video-Out Cable
(TV-Out Cable)
(1)
LCD Screen
(2)
Power Button
(3)
LEFT/
Dimming
Button
(4)
RIGHT/
Brightening
Button
(5)
Rotation
Figure Description Use
1 LCD Screen
2 Power Button Use to turn on/off
the Video Borescope.
Press and hold 3
seconds to start
3 LEFT/
Dimming Button
Use to decrease
LED brightness
4 RIGHT/
Brightening Button
Use to increase
LED brightness
5 Picture Rotation Use to rotate the
real-time image
WARNING
Always wear safety glasses and gloves.
OPERATING INSTRUCTIONS
1. Never insert probe into a space known or
suspected to contain live electric wiring.
2. The Video Borescope is intended for industrial
applications only. DO NOT use it for personal or
medical use in any way.
3. Never insert an attached probe into any flammable
gas or liquid including in any storage container or
fuel tank designed to store flammable gas or liquid.
4. DO NOT disassemble the instrument. Doing so
creates a potentially fatal electrical hazard (and
voids the warranty as well).
5. DO NOT expose the tool to rain or wet conditions.
Water entering the tool will increase the risk of
electric shock.
6. Keep cord away from heat, oil, sharp edges or
moving parts.
WARNING
SETUP AND CONNECTION
To use the Video Borescope, the imager head and
cable must be connected to the display unit. To
connect the cable of the display unit, align the key
and slot, slide them together, and finger-tighten the
knurled knob to hold the connection firmly in place.

5
Operating Instructions and Parts Manual 24383
VIDEO BORESCOPE
11/16
2016 OEMTOOLS®
ACCESSORIES INSTALLATION
The three accessories include magnet, hook and
mirror. All are attached to the imager head in the
same manner. Hold the accessory and the imager
head and slip the end of the accessory over the tip
of the imager head.
Video-Out (TV-out) Cable Connection
Insert the video-out cable into the video-out port of the
Video Borescope and the other end of the cable into
the video-in port of a TV, the LCD screen will output a
high quality real-time image.
Basic Operation
IMPORTANT: Always wear safety eye protection to
protect your eyes against dirt and other objects. Follow
operation instructions to reduce the risk of injury from
electric shock, entanglement and other causes.
FOR WALLS:
For inspecting the inside walls, be sure to shut off the
circuit breaker to the whole house before using the
Video Borescope.
FOR PIPES:
If you suspect a metal pipe could contain an electric
charge, have a qualified electrician to check the pipe
before using.
FOR AUTOMOBILES:
Be sure the automobile is not running during
inspection. Metal and liquid under the hood may be
hot. Don’t get oil or gas on the imager head.
Set up the Video Borescope and work area according
to these procedures to reduce the risk of injury from
electric shock, entanglement, and other causes and
prevent Video Borescope damage.
1. Check work area for:
a. Sufficient lighting.
b. DO NOT work in area until flammable sources
have been identified and corrected. The Video
Borescope is not explosion proof and can
cause sparks.
c. DO NOT use the Video Borescope while
standing in water.
2. Check the area and determine if the Video
Borescope is the correct Video Borescope
for the job.
a. Check the access points to the area.
b. Check if there is any electric power supplied to
the area to be inspected.
c. Check if the any liquids will be occurred during
the inspection. The Image head and cable were
waterproof to a depth of 10’. Greater depths may
cause leakage into the imager head and cable
and cause electric shock or damage the Video
Borescope. The display unit is not waterproof
and should not be exposed to wet conditions.
d. Check if any chemicals are present, especially
in the case of drains. Chemicals may damage
the Video Borescope.
e. Check the temperature of the area. The
working temperature of the Video Borescope is
between 32°F and 113°F.
f. Check if any moving parts are present in
the area.
3. Make sure the Video Borescope has been
properly inspected.
4. Install the correct accessories for use in the
appropriate application.
NOTE: When in operation, the cable can be bent into a
certain shape. (DO NOT kink the cable) This may help
you operate the cable in confined areas.
1. Hold the Video Borescope with LCD screen facing
you and press Power button to turn it on. Wait for
two seconds, the first screen – a splash screen is
booting up, and then the live screen will display.
2. Press LEFT and RIGHT arrow buttons to decrease or
increase screen backlighting. You will see a brightness
indicator bar as you adjust LED light intensity.
3. Press Picture Rotation button to rotate the real-
time image.
4. Use the supplied accessories as required.
5. Connect the supplied video-out (TV-out) cable to
the video-out port of the Video Borescope and the
other end of the cable to the video-in port of a TV
to view a high quality real-time image.
Operating Precautions
1. Use the Video Borescope only as directed. Do not
operate the Video Borescope unless the user’s
manual has been read thoroughly and proper
training has been completed.
2. The display unit is not waterproof. The imager
head and cable are waterproof, but not acid-proof
or fireproof. Avoid submerging the imager head
and cable into corrosive, oily places and be sure
to keep the imager head and cable away from
high temperature objects.
3. DO NOT immerse the Video Borescope and
display unit in water.
4. DO NOT use excessive force to insert or
withdraw the imager head and cable. This may
result in damage to the Video Borescope or
inspection area.

6
Operating Instructions and Parts Manual 24383
VIDEO BORESCOPE
11/16
2016 OEMTOOLS®
5. DO NOT use the imager head and cable to move
items, clear pathways or clogged areas.
6. DO NOT eat or smoke while operating the Video
Borescope. Use hot, soapy water to wash hands
and other body parts exposed to drain contents
after using the Video Borescope to inspect drains
and other areas that may contain chemicals or
bacteria, which will help prevent contamination
with toxic or infectious material.
7. When the inspection is completed, carefully
withdraw the imager head and cable from the
inspection area, and take out the 4 AA dry
batteries.
8. Maintain the Video Borescope with care. A
properly maintained Video Borescope is less likely
to cause injury.
9. DO NOT drop the Video Borescope. If the Video
Borescope is dropped accidently, check for damage
and any other condition that may affect its operation.
10. Dry your hands before operating the Video
Borescope.
11. Use appropriate personal protective equipment
while handling and using the Video Borescope.
Appropriate personal protective equipment
always includes safety glasses and gloves, and
may include latex or rubber gloves, face shields,
goggles, protective clothing, respirators and steel
toed footwear.
12. Protect against excessive heat. Keep the Video
Borescope away from heat sources such as
radiators, stoves or others that produce heat.
Do not use the Video Borescope near moving
machinery or areas where the temperature will
exceed 113°F.
13. Store the Video Borescope and all cables in
a locked area out of the reach of children and
people unfamiliar with Video Borescope.
MAINTENANCE
1. Make sure the power is OFF.
2. Clean any oil, grease or dirt from the Video
Borescope, especially on the buttons and ports.
This helps prevent the Video Borescope from
slipping from your hands.
3. Inspect the imager head lens for condensation. To
avoid damaging the Video Borescope, do not use
the Video Borescope if condensation forms inside
the imager head. Let the water evaporate before
using again.
4. Inspect the full length of the cable for cracks or
damage. A damaged cable could allow water to
enter the Video Borescope and increase the risk
of electric shock.
5. Make sure the connections between the display
unit and imager head and cable are tight. All
connections must be properly assembled for the
cable to be waterproof.
6. Check if the warning label is present, firmly
attached and readable. Do not operate the Video
Borescope without the caution label.
7. Turn on the power and make sure the splash
screen and then the live screen are displayed.
8. If the Video Borescope does not work properly
after being turned on, please have the Video
Borescope checked by a qualified technician.
Any Video Borescope that cannot be controlled
with the power button is dangerous and must be
repaired.
9. Always store the Video Borescope in a well-
protected area where it will not be exposed to
inclement weather, corrosive vapors, abrasive
dust, or any other harmful elements.
10. When maintaining, use only identical replacement
parts. Use of unauthorized parts or failure to
follow maintenance instructions may create a risk
of electric shock or injury.
11. DO NOT use acetone to clean the Video
Borescope. Instead, use an alcohol swab. Avoid
rubbing too hard on the LCD screen. After using,
wipe the display unit clean gently with a dry cloth.
12. DO NOT disassemble the tool beyond what is
shown in the manual. Doing so will void your
warranty.

7
Operating Instructions and Parts Manual 24383
VIDEO BORESCOPE
11/16
2016 OEMTOOLS®
Figure Description Use
1 Handheld Display Unit Comfortable pistol grip design
2 Imager Head and Cable Connects to the Video Borescope while in use to view
images
3 Cable Connector Connects the handheld display unit to the Imager Head
and Cable
4 Battery Indicator Light Turns red when battery needs to be replaced
5 Power Button Turns the Video Borescope on/off
6 Video-Out Port Connects the Video Borescope to a TV with the
supplied Video-Out Cable to view the real-time image
7 Battery
Compartment Cover
Protects batteries from dust and debris
8 Accessory
Magnet
Picks up small metal objects such as dropped rings or
screws on the floor
9 Accessory Hook Unclogs obstacles and picks up wires in the pipes or
confined areas
10 Accessory Mirror Use to look around corners
NOTE
Not all components of the Video Borescope are replacement items, but are illustrated as a
convenient reference for location and position in the assembly sequence.
(1)
Handheld
Display
Unit
(7)
Battery
Compartment
Cover
(2)
Imager
Head and
Cable
(3)
Cable
Connector
(4)
Battery
Indicator Light
(5)
Power Button
(6)
Video-Out
Port
(9)
Accessory
Hook
(8)
Accessory
Magnet
(10)
Accessory
Mirror

8
Operating Instructions and Parts Manual 24383
VIDEO BORESCOPE
11/16
2016 OEMTOOLS®
3580 E. Raines Road, Suite 3, Memphis, TN 38118
Tel: [phone]
www.oem-tools.com
CONTACT US
OEMTOOLS®ONE YEAR WARRANTY
If for up to one year from the date of purchase of this OEMTOOLS®product you find any defect in material
or workmanship, through normal usage, return it to the place of purchase, or to OEMTOOLS®for repair
or replacement at our discretion. In order to obtain this service, send your tool and proof of purchase,
transportation pre-paid, to OEMTOOLS®Q.A. Dept, 3580 E. Raines Road #3, Memphis, TN 38118. We will not
be responsible for lost or damaged goods during transportation; please insure your package. If our inspection
verifies the defect, we will either repair or replace the product at our election, or we may elect to refund the
purchase price if we cannot readily and quickly provide you with a replacement. We will return repaired products
at our expense, but if we determine there is no defect, or that the defect resulted from causes not within the
scope of our warranty, then you must bear the cost of returning the product.
OEMTOOLS®does not provide warranty for products labeled other than OEM®or OEMTOOLS®. OEMTOOLS®
will not provide any warranty for products subjected to abnormal use. Abnormal use includes, but is not limited
to, abuse, accident, alteration, neglect, and unauthorized or unreasonable use or repairs. This warranty does not
cover bits, blades, files, batteries, or calibration. We recommend that you maintain your tools and sharpen or
replace blades, bits, files, and batteries as necessary. OEMTOOLS®reserves the right to makes any changes in
construction or design at any time without any obligation in incorporating such changes to tools or equipment
previously sold.
OEMTOOLS®makes every effort to ensure that its products meet high quality and durability standards, and
warrants to the original purchaser that this product is free from defects in materials and workmanship for
the period of one year from the date of purchase. This warranty does not apply to damage due directly or
indirectly to misuse, abuse, negligence or accidents, repairs or alterations outside our facilities, criminal
activity, improper installation, normal wear and tear or to lack of maintenance.
We shall in no event be liable for death, injuries to persons or property, or for incidental, contingent, special or
consequential damages arising from the use of our product. Some states do not allow the exclusion or limitation
of incidental or consequential damages, so the above limitation of exclusion may not apply to you. THIS
WARRANTY IS EXPRESSLY IN LIEU OF ALL OTHER WARRANTIES, EXPRESS OR IMPLIED, INCLUDING THE
WARRANTIES OF MERCHANTABILITY AND FITNESS. This warranty gives you specific legal rights, and you may
also have other rights, which vary from state to state.
Don’t forget to register your new OEMTOOLS®product at www.oem-tools.com.
