UNPACKING
After unpacking the unit, inspect carefully for any damage
that may have occurred during transit. Check for loose,
missing, or damaged parts. If any damage is observed, a
shipping damage claim must be filed with the carrier. DO
NOT use the OEMTOOLS™Rechargeable Slim Inspection
Light if broken, bent, cracked or damaged parts (including
labels) are noted. Any Inspection Light that appears
damaged in any way, operates abnormally or is missing
parts should be removed from service immediately. If you
suspect that the Inspection Light was subjected to shock
load (a load that was dropped suddenly, unexpectedly,
etc.), immediately discontinue use until it has been
checked by a factory authorized service center.
Please read and save these instructions. Read through this owner’s manual carefully before using product. Protect yourself and
others by observing all safety information, warnings, and cautions. Failure to comply with instructions could result in personal
injury and/or damage to product or property. Please retain instructions for future reference.
The following safety information is provided as a guideline to help you operate your OEMTOOLS™Rechargeable Slim
Inspection Light under the safest possible conditions. Any tool or piece of equipment can be potentially dangerous to
use when safety or safe handling instructions are not known or not followed. The following safety instructions are to
provide the user with the information necessary for safe use and operation. Please read and retain these instructions
for the continued safe use of your OEMTOOLS™Rechargeable Slim Inspection Light. Failure to follow instructions listed
below may result in serious injury. In addition, make sure that anyone who uses the equipment understands and follows
these safety instructions as well.
Operating Instructions and Parts Manual 24646
FOR CUSTOMER SERVICE
Technical Question?
CALL 1-866-458-2472
[email protected]
Thank you very much for choosing an OEMTOOLS™Product!
For future reference, please register your new tool at www.oem-tools.com and complete the owner’s record below:
Model: _______________ Purchase Date: ___________
Save the receipt, warranty and these instructions. It is important that you read the entire manual to become familiar with this product
before you begin using it. This product is designed for certain applications only. OEMTOOLS™cannot be responsible for issues
arising from modification. We strongly recommend this product is not modified and/or used for any application other than that for
which it was designed. If you have any questions relative to a particular application, DO NOT use the product until you have first
contacted customer service to determine if it can or should be performed on the product.
WARNING:This product can expose you to chemicals, including DEHP, which are known to the State of California to
cause cancer and birth defects or other reproductive harm. For more information, go to www.P65Warnings.ca.gov.
Explanation of Safety Signal Words
WARNING:Indicates a potentially hazardous situation which, if not avoided, could result in death or serious injury.
CAUTION:Indicates a potentially hazardous situation which, if not avoided, may result in minor or moderate injury.
CAUTION:Used without the safety alert symbol indicates a potentially hazardous situation which, if not avoided, may
result in property damage.
NOTES:Provide clarity and helpful information.
RECHARGEABLE SLIM
INSPECTION LIGHT
1
5/19
2019 OEMTOOLS™
WARNING
10m
BEAM DISTANCE
2.5h
MAX RUNTIME
700
LUMENS
MAX OUTPUT

2
Operating Instructions and Parts Manual 24646
5/19
2019 OEMTOOLS™
RECHARGEABLE SLIM
INSPECTION LIGHT
IMPORTANT INSTRUCTIONS
AND SAFETY RULES
1. Know your product. Read this manual carefully. Learn
the product’s applications and limitations, as well as
potential hazards specific to it.
2. Keep work area clean and well lit. Cluttered or dark
work areas invite accidents.
3. Keep children away. All children should be kept away
from the work area. Never let a child handle tools or
equipment without strict adult supervision.
4. DO NOT use the work light if the switch does not turn it
on and off. Any tool that cannot be controlled with the
switch is dangerous and must be repaired.
5. Although eye damage from the OEMTOOLS™Light is
unlikely, never stare directly into the beam.
6. DO NOT attempt to recharge the battery by any other
means than USB, via the cable provided.
7. DO NOT use this product if under the influence of
alcohol or drugs. Read warning labels on prescriptions
to determine if your judgment or reflexes are impaired
while taking drugs. If there is any doubt, DO NOT
attempt to operate.
8. DO NOT overreach. Keep proper footing and balance
at all times when operating this product.
9. Check for damage. Check equipment regularly. If part of
the product is damaged, it should be carefully inspected
to make sure that it can perform its intended function
correctly. If in doubt, discontinue use of the product.
10. Keep this product dry and clean.
11. Use only accessories that are recommended by the
manufacturer for your model. Accessories that may be
suitable for one product may become hazardous when
used on another product.
12. Service must be performed only by qualified repair
personnel. Service or maintenance performed by
unqualified personnel could result in a risk of injury.
13. When servicing a product, use only identical
replacement parts. Use of unauthorized parts or
failure to follow maintenance instructions may create
a risk of injury.
14. Maintain a safe working environment. Keep the work
area well lit. Make sure there is adequate surrounding
workspace. Keep the work area free of obstructions,
grease, oil, trash, and other debris. DO NOT use this
product in a damp or wet location.
15. Maintain labels and nameplates on this product. These
carry important information. If unreadable or missing,
contact OEMTOOLS™for a replacement.
16. Keep this product dry, clean, and free from brake fluid,
oil, and grease.
17. Avoid accidental fire. DO NOT smoke near this product.
18. We believe the information contained herein to be
reliable. However, general technical information is given
by us without charge and the user shall employ such
information at their own discretion and risk. We assume
no responsibility for results or damages incurred from
the use of such information in whole or in part. Always
refer to specific instructions and technical information
supplied by vehicle manufacturer.
19. The procedures documented in this manual are to
serve as guidelines for the use of this equipment.
20. The use of this equipment is simple and straightforward
if you follow the instructions. When operating this
equipment, use common sense, and only use this
equipment for its intended purpose.
21. DO NOT submerge this product in water or other
liquids.
22. Keep the light away from medical and electronic
devices. Strong magnets in light could cause damage
to some devices.
NOTE: The manufacturer declines any and all
responsibility for damage to vehicles or components if
said damage is the result of unskillful handling by the
operator or of failure to observe the basic safety rules set
forth in the instruction manual.
WARNING:Carefully read Rules for Safe Operation
and Instructions.
IMPORTANT SAFETY INSTRUCTIONS
The warnings, precautions, and instructions discussed
in this manual cannot cover all possible conditions
and situations that may occur. The operator must
understand that common sense and caution are factors
which cannot be built into this product but must be
supplied by the operator.
DISPOSAL
At the end of the useful life of the OEMTOOLS™
Rechargeable Slim Inspection Light, dispose of the
components according to all state, federal and local
regulations.
BATTERY DISPOSAL
Exposure to high temperatures can cause the batteries
to explode; DO NOT dispose of in a fire. Some countries
have regulations concerning battery disposal. Follow
all applicable regulations. Return used batteries to a
collection location for recycling. Call 800-822-8837 or
visit www.call2recycle.org to find a collection location.
CHARGING
Fully charge the battery before first use.
PURPOSE
The OEMTOOLS™24646 Rechargeable Slim Inspection
Light is designed to light work areas, provide temporary
lighting for outdoor recreation activities such as camping,
and offer emergency lighting in a power outage situation.

3
Operating Instructions and Parts Manual 24646
5/19
2019 OEMTOOLS™
RECHARGEABLE SLIM
INSPECTION LIGHT
PRODUCT SPECIFICATIONS
Mode 100% 50%
Output (Lumens) 700 350
Max Run Time* 2.5 Hrs. 10 Hrs.
Power Source 2600mA Rechargeable lithium battery
(18650 type)
Voltage 5V
Power 10W
Beam Distance 10 m
Impact Resistant 1 m
Dimensions 14.7" length x 1.4" diameter
Weight 6.6 Oz.
*Run Time may vary depending on dial position.
CONTENTS
(1) Inspection light, (1) instruction manual, (1) USB mini
charging cord.
OPERATION
1. Rotate variable dial clockwise to increase lumen (light)
output; rotate counter-clockwise to decrease lumen
(light) output.
2. To adjust Magnetic Swivel Base, turn the plastic
tension ring to increase or decrease tightness once
desired angle is found.
3. Mount in desired work location using either the folding
loop or Magnetic Swivel Base.
PRODUCT MAINTENANCE
WARNING:This product has no serviceable parts.
If you suspect the product is damaged, discontinue use
and contact customer service for further support.
WARNING:DO NOT attempt to modify this product.
The product has been designed for very specific use.
INSTRUCTIONS FOR CHARGING
1. Plug Mini USB into charging port on light.
2. Indicator light will shine red while charging and shine
blue when fully charged.
3. Unplug from power source once charged.
Figure Description Qty.
A Slim inspection light 1
B Magnetic 360° swivel base 1
C Tension lock 1
D Variable light dial 1
E USB charging port 1
F USB charging cord (not pictured) 1
G Hook 1
H18650 Rechargeable lithium battery
(not pictured) 1
PRODUCT LAYOUT
G
A
B
C
D
E
NOTE: Not all components of the product are
replacement items but are illustrated as a convenient
reference for location and position in the assembly
sequence.
OEMTOOLS™ and/or its distributors have provided the
parts list and assembly diagram as a reference only.
Neither OEMTOOLS™ and/or its distributors make any
representation or warranty of any kind to the buyer and/
or user of this tool that he or she is qualified to do any
repairs or replace any parts of this product. OEMTOOLS™
and its distributors expressly state that all repairs or parts
replacement should be done by certified or licensed
technicians. The buyer assumes all risk and liability
arising out of his or her repairs or parts replacement to
the original production.

4
Operating Instructions and Parts Manual 24646
5/19
2019 OEMTOOLS™
RECHARGEABLE SLIM
INSPECTION LIGHT
CONTACT US
3580 E. Raines Road, Suite 3, Memphis, TN 38118
Tel: [phone]
www.oem-tools.com
OEMTOOLS™LIMITED LIFETIME WARRANTY
For as long as you own this OEMTOOLS™product, if you find any defect in material or workmanship, through normal
usage, return it to the place of purchase or to OEMTOOLS™for repair or replacement at our discretion. In order to
obtain this service, send your tool and proof of purchase (transportation pre-paid) to:
OEMTOOLS™Q.A. Dept., 3580 E. Raines Road #3, Memphis, TN 38118.
We will not be responsible for lost or damaged goods during transportation; please insure your package. If our
inspection verifies the defect, we will either repair or replace the product, or we may elect to refund the purchase price
if we cannot readily and quickly provide you with a replacement. We will return repaired products at our expense, but if
we determine there is no defect, or that the defect resulted from causes not within the scope of our warranty, then you
must bear the cost of returning the product.
OEMTOOLS™does not provide warranty for products labeled other than OEM®or OEMTOOLS™. OEMTOOLS™will
not provide any warranty for products subjected to abnormal use. Abnormal use includes (but is not limited to) abuse,
accident, alteration, neglect, and unauthorized or unreasonable use or repairs. This warranty does not cover bits,
blades, files, batteries, or calibration. We recommend that you maintain your tools and sharpen or replace blades, bits,
files, and batteries as necessary. OEMTOOLS™reserves the right to make any changes in construction or design at
any time without any obligation in incorporating such changes to tools or equipment previously sold.
OEMTOOLS™ makes every effort to ensure that its products meet high quality and durability standards, and warrants
to the original purchaser that this product is free from defects in materials and workmanship for the period of one
year from the date of purchase. This warranty does not apply to damage due directly or indirectly to misuse, abuse,
negligence or accidents, repairs or alterations outside our facilities, criminal activity, improper installation, normal wear
and tear or to lack of maintenance.
We shall in no event be liable for death, injuries to persons or property, or for incidental, contingent, special or
consequential damages arising from the use of our product. Some states do not allow the exclusion or limitation of
incidental or consequential damages, so the above limitation of exclusion may not apply to you. THIS WARRANTY
IS EXPRESSLY IN LIEU OF ALL OTHER WARRANTIES, EXPRESS OR IMPLIED, INCLUDING THE WARRANTIES OF
MERCHANTABILITY AND FITNESS. This warranty gives you specific legal rights, and you may also have other rights,
which vary from state to state.
Don’t forget to register your new OEMTOOLS™product at www.oem-tools.com.
