OEM Tools 25982 Service manual

UNPACKING
After unpacking the product, inspect carefully for any damage
that may have occurred during transit. Check for loose, missing
or damaged parts. If any damage is observed, a shipping
damage claim must be filed with the carrier. DO NOT use the
OEMTOOLS™Magnetic Rechargeable LED Work Light if broken,
bent, cracked or damaged parts (including labels) are noted.
Please read and save these instructions. Read through this owner’s manual carefully before using product. Protect yourself and others by
observing all safety information, warnings and cautions. Failure to comply with instructions could result in personal injury and/or damage
to product or property. Please retain instructions for future reference.
Operating Instructions and Parts Manual 25982
FOR CUSTOMER SERVICE
Technical Question?
CALL 1-866-458-2472
[email protected]
80
MAX OUTPUT MAX RUNTIME BEAM DISTANCE
15m
IMPACT RESISTANCE
1.5m
WATER RESISTANT
210
LUMENS
MAX RUNTIME
25982
100
LUMENS
MAX OUTPUT
5h
MAX RUNTIME BEAM DISTANCE
50m
IMPACT RESISTANCE
1.5m
WATER PROOF
IPX-6
Work Light
MAX OUTPUT
Work Light Flashlight
MAX RUNTIME
3h 9h
MAX RUNTIME
Work Light Flashlight
MAX OUTPUT
400
LUMENS
120
LUMENS
MAGNETIC RECHARGEABLE
LED WORK LIGHT
5/19
2019 OEMTOOLS™
Thank you very much for choosing an OEMTOOLS™Product!
For future reference, please register your new product at www.oem-tools.com and complete the owner’s record below:
Model: _______________ Purchase Date: ___________
Save the receipt, warranty and these instructions. It is important that you read the entire manual to become familiar with this product
before you begin using it. This product is designed for certain applications only. OEMTOOLS™cannot be responsible for issues arising
from modification. We strongly recommend this product is not modified and/or used for any application other than that for which it was
designed. If you have any questions relative to a particular application, DO NOT use the product until you have first contacted customer
service to determine if it can or should be performed on the product.
WARNING:This product can expose you to chemicals, including DEHP and lead, which are known to the State of California to cause cancer and
birth defects or other reproductive harm. For more information, go to www.P65Warnings.ca.gov.
The following safety information is provided as guidelines to help you operate your Magnetic Rechargeable LED Work Light under the
safest possible conditions. Any tool or piece of equipment can be potentially dangerous to use when safety or safe handling instructions
are not known or not followed. The following safety instructions are to provide the user with the information necessary for safe use and
operation. Please read and retain these instructions for the continued safe use of your product. Failure to follow instructions listed below
may result in serious injury. In addition, make sure that anyone that uses the product understands and follows these safety
instructions as well.
WARNING
Explanation of Safety Signal Words
WARNING: Indicates a potentially hazardous situation which, if not avoided, could result in death or serious injury.
CAUTION: Indicates a potentially hazardous situation which, if not avoided, may result in minor or moderate injury.
CAUTION: Used without the safety alert symbol indicates a potentially hazardous situation which, if not avoided, may
result in property damage.
NOTES: Provide clarity and helpful information.

2
Operating Instructions and Parts Manual 25982
MAGNETIC RECHARGEABLE
LED WORK LIGHT
5/19
2019 OEMTOOLS™
IMPORTANT INSTRUCTIONS
AND SAFETY RULES
1. Know your work light. Read this manual carefully. Learn the
work light’s applications and limitations, as well as, potential
hazards specific to it.
2. Keep children away. All children should be kept away from
the work area. Never let a child handle a tool without strict
adult supervision.
3. Do not use the work light if the switch does not turn it on
and off. Any tool that cannot be controlled with the switch is
dangerous and must be repaired.
4. Keep away from flammables. Do not attempt to operate this
work light near flammable materials or combustibles. Failure
to comply may cause serious injury or death.
5. Although eye damage from the OEMTOOLS™Work Light is
unlikely, never stare directly into the beam.
6. Do not attempt to recharge the battery by any other means
than USB, via the cable provided.
7. When servicing a tool, use only identical replacement parts.
Use of unauthorized parts or failure to follow maintenance
instructions may create a risk of injury.
8. The warnings, precautions, and instructions discussed in this
manual cannot cover all possible conditions and situations
that may occur. The operator must understand that common
sense and caution are factors which cannot be built into this
product, but must be supplied by the operator.
DISPOSAL
At the end of the useful life of the Work Light, dispose of the
components according to all state, federal and local regulations.
BATTERY DISPOSAL
Exposure to high temperatures can cause the batteries to
explode; do not dispose of in a fire. Some countries have
regulations concerning battery disposal. Follow all applicable
regulations. Return used batteries to a collection location for
recycling. Call 800-822-8837 or visit www.call2recycle.org to
find a collection location.
CHARGING
Fully charge the battery before first use.
OPERATION
The OEMTOOLS™Rechargeable Work Light features a super
bright 3W COB for use as an inspection lamp and an ultra-bright
LED flashlight for use as a directional light. A push On/Off button
is located on the front of the light. A magnetic 180ºadjustable
base and two super strong magnets on the back allow the user to
mount to any ferrous metal surface. Two 360ºswivel hooks are
provided to hang the light from a hood or other object. The Li-Ion
long life battery is rechargeable via the included USB cord.
MAINTENANCE
1. Always store the OEMTOOLS™Work Light in a well-protected
area where it will not be exposed to inclement weather,
corrosive vapors, abrasive dust or any other harmful
elements.
2. Keep the Work Light clean by wiping with a
damp cloth.
3. Inspect cable periodically, and if damaged, replace.
4. Recharge periodically when not in use.
PRODUCT SPECIFICATIONS
Work Light : 400 Lumens
Top Light : 120 Lumens
Runtime: 3 Hrs. (work light), 9 Hrs.
(flashlight)
Charge Time: 4 Hrs.
Lightweight: 0.7 Lbs.
FEATURES:
• Two Powerful magnets on back
• On/Off button for work light and flashlight
• Indicator lights: green when fully charged and red when
charging
• High impact, rubberized ABS case for durability
• Two Nylon hooks swivel 360º
• Magnetic 180ºadjustable base
• Over charge and over discharge protection
• Ergonomic hand grip for comfort

3
Operating Instructions and Parts Manual 25982
MAGNETIC RECHARGEABLE
LED WORK LIGHT
5/19
2019 OEMTOOLS™
NOTE
Not all components
of the Work Light are
replacement items,
but are illustrated as a
convenient reference for
location and position in
the assembly sequence.
Figure Description Quantity
(A) 3W COB LED Light 1
(B) On/Off Button 1
(C) LED Flashlight 1
(D) Magnetic 180ºAdjustable Base 1
(E) Charging Port 1
(F) 360ºSwivel Nylon Hooks 2
(G) Powerful Magnets 2
USB Charging Cord (Not Shown) 1
Adapter (Not Shown) 1
FRONT BACK
NOTE
OEMTOOLS™and/or its distributors have provided the parts list and assembly diagram as a reference only. Neither OEMTOOLS™and/or
its distributors make any representation or warranty of any kind to the buyer and/or user of this tool that he or she is qualified to do any
repairs or replace any parts of this product. OEMTOOLS™and its distributors expressly state that all repairs or parts replacement should
be done by certified or licensed technicians. The buyer assumes all risk and liability arising out of his or her repairs or parts replacement
to the original product.
(C) LED
Flashlight
(A) 3W
COB LED
Light
(B) On / Off
Button
(E) Charging
Port
(G) Powerful
Magnets
(D) Magnetic
180°
Adjustable
Base
(F) 360°
Swivel
Hooks

4
Operating Instructions and Parts Manual 25982
MAGNETIC RECHARGEABLE
LED WORK LIGHT
5/19
2019 OEMTOOLS™
CONTACT US
3580 E. Raines Road, Suite 3, Memphis, TN 38118
(1-866-458-2472)
email: [email protected]
OEMTOOLS™ONE YEAR WARRANTY
For up to one year from the date of purchase of this OEMTOOLS™product you find any defect in material or workmanship, through
normal usage, return it to the place of purchase or to OEMTOOLS™for repair or replacement at our discretion. In order to obtain this
service, send your tool and proof of purchase, transportation pre-paid, to OEMTOOLS™Q.A. Dept., 3580 E. Raines Road #3, Memphis, TN
38118. We will not be responsible for lost or damaged goods during transportation; please insure your package. If our inspection verifies
the defect, we will either repair or replace the product at our election, or we may elect to refund the purchase price if we cannot readily
and quickly provide you with a replacement. We will return repaired products at our expense, but if we determine there is no defect, or
that the defect resulted from causes not within the scope of our warranty, then you must bear the cost of returning the product.
OEMTOOLS™does not provide warranty for products labeled other than OEM®or OEMTOOLS™. OEMTOOLS™will not provide any
warranty for products subjected to abnormal use. Abnormal use includes, but is not limited to, abuse, accident, alteration, neglect, and
unauthorized or unreasonable use or repairs. This warranty does not cover bits, blades, files, batteries, or calibration. We recommend
that you maintain your tools and sharpen or replace blades, bits, files, and batteries as necessary. OEMTOOLS™reserves the right to
make any changes in construction or design at any time without any obligation in incorporating such changes to tools or equipment
previously sold.
OEMTOOLS™makes every effort to ensure that its products meet high quality and durability standards, and warrants to the original
purchaser that this product is free from defects in materials and workmanship for the period of one year from the date of purchase. This
warranty does not apply to damage due directly or indirectly to misuse, abuse, negligence or accidents, repairs or alterations outside our
facilities, criminal activity, improper installation, normal wear and tear or to lack of maintenance.
We shall in no event be liable for death, injuries to persons or property, or for incidental, contingent, special or consequential damages
arising from the use of our product. Some states do not allow the exclusion or limitation of incidental or consequential damages, so the
above limitation of exclusion may not apply to you. THIS WARRANTY IS EXPRESSLY IN LIEU OF ALL OTHER WARRANTIES, EXPRESS OR
IMPLIED, INCLUDING THE WARRANTIES OF MERCHANTABILITY AND FITNESS. This warranty gives you specific legal rights, and you may
also have other rights, which vary from state to state.
