OEM Tools 26028 Service manual

UNPACKING
After unpacking unit, inspect carefully for any damage that
may have occurred during transit. Check for loose, missing, or
damaged parts. If any damage is observed, a shipping damage
claim must be filed with carrier. DO NOT use OEMTOOLS™
26028 Slim Folding Rechargeable Work Light if broken, bent,
cracked or damaged parts (including labels) are noted. Any
Work Light that appears damaged in any way, operates
abnormally or is missing parts should be removed from
service immediately. If you suspect that the Work Light was
subjected to a shock load (a load that was dropped suddenly,
unexpectedly, etc.), immediately discontinue use until it has
been checked by a factory authorized service center.
Please read and save these instructions. Read through this owner’s manual carefully before using product. Protect yourself and
others by observing all safety information, warnings, and cautions. Failure to comply with instructions could result in personal
injury and/or damage to product or property. Please retain instructions for future reference.
The following safety information is provided as a guideline to help you operate your Slim Folding Rechargeable Work Light
under the safest possible conditions. Any tool or piece of equipment can be potentially dangerous to use when safety or
safe handling instructions are not known or not followed. The following safety instructions are to provide the user with the
information necessary for safe use and operation. Please read and retain these instructions for the continued safe use of your
Slim Folding Rechargeable Work Light. Failure to follow instructions listed below may result in serious injury. In addition, make
sure that anyone who uses the equipment understands and follows these safety instructions as well.
Operating Instructions and Parts Manual 26028
FOR CUSTOMER SERVICE
Technical Question?
CALL 1-866-458-2472
[email protected]
Thank you very much for choosing an OEMTOOLS™Product!
For future reference, please register your new tool at www.oem-tools.com and complete the owner’s record below:
Model: _______________ Purchase Date: ___________
Save the receipt, warranty and these instructions. It is important that you read the entire manual to become familiar with this product
before you begin using it. This product is designed for certain applications only. OEMTOOLS™cannot be responsible for issues
arising from modification. We strongly recommend that this product is not modified and/or used for any application other than that
for which it was designed. If you have any questions relative to a particular application, DO NOT use the product until you have first
contacted customer service to determine if it can or should be performed on the product.
Explanation of Safety Signal Words
WARNING:Indicates a potentially hazardous situation which, if not avoided, could result in death or serious injury.
NOTES:Provide clarity and helpful information.
SLIM FOLDING
RECHARGEABLE WORK LIGHT
1
10/18
2018 OEMTOOLS™
WARNING
MAX RUNTIME
High Low
MAX RUN TIME
2h 4h
MAX RUNTIME
High Low
MAX OUTPUT
350
LUMENS
175
LUMENS

2
Operating Instructions and Parts Manual 26028
10/18
2018 OEMTOOLS™
SLIM FOLDING
RECHARGEABLE WORK LIGHT
IMPORTANT INSTRUCTIONS
AND SAFETY RULES
1. Know your work light. Read this manual carefully.
Learn the light’s applications and limitations, as well as
potential hazards specific to it.
2. Keep work area clean and well lit. Cluttered or dark
work areas invite accidents.
3. Keep children away. All children should be kept away
from the work area. Never let a child handle tools or
equipment without strict adult supervision.
4. DO NOT use the work light if the switch does not turn it
on and off. Any tool that cannot be controlled with the
switch is dangerous and must be repaired.
5. Although eye damage from the OEMTOOLS™ Work
Light is unlikely, never stare directly into the beam.
6. DO NOT attempt to recharge the battery by any means
other than USB, via the cable provided.
7. Check for damage. Check your product regularly. If
part of the product is damaged, it should be carefully
inspected to make sure it can perform its intended
function correctly. If in doubt, discontinue use of the
product.
8. Store idle tools out of the reach of children and
untrained persons. Tools may be dangerous in the
hands of untrained users.
9. Keep work light dry and clean.
11. DO NOT use this product in a damp or wet location.
12. DO NOT submerge this product in water or other liquids.
13. Use only accessories that are recommended by the
manufacturer for your model. Accessories that may be
suitable for one product may become hazardous when
used on another product.
14. Maintain labels and nameplates on this product. These
carry important information. If unreadable or missing,
contact OEMTOOLS™ for a replacement.
15. Avoid accidental fire. DO NOT smoke near this product.
16. Keep away from flammables. DO NOT attempt to
operate this work light near flammable materials or
combustibles. Failure to comply may cause serious
injury or death.
17. Maintain a safe working environment. Keep the work
area well lit. Make sure there is adequate surrounding
workspace. Keep the work area free of obstructions,
grease, oil, trash, and other debris.
18. Keep the work light away from medical and electronic
devices. Strong magnets in the light may cause
damage to some devices.
19. We believe the information contained herein to be
reliable. However, general technical information is given
by us without charge and the user shall employ such
information at their own discretion and risk. We assume
no responsibility for results or damages incurred from
the use of such information in whole or in part.
20. The procedures documented in this manual are to
serve as guidelines for the use of this equipment. The
use of this equipment is simple and straightforward
if you follow the instructions. When operating this
equipment, use common sense, and only use this
equipment for its intended purpose.
WARNING:Cancer and Reproductive Harm
www.P65warnings.ca.gov
NOTE:The manufacturer declines any and all
responsibility for damage to vehicles or components if said
damage is the result of unskillful handling by the operator
or of failure to observe the basic safety rules set forth in the
instruction manual.
WARNING:
Carefully read Rules for Safe Operation and Instructions.
IMPORTANT SAFETY INSTRUCTIONS:
The warnings, precautions, and instructions discussed in this
manual cannot cover all possible conditions and situations
that may occur. The operator must understand that common
sense and caution are factors which cannot be built into this
product but must be supplied by the operator.
PURPOSE
The OEMTOOLS™ Slim Folding Rechargeable Work Light
incorporates a small compact design and features super
bright COB LED light that provides light where needed.
A push On/Off button is located on the front of the light.
A magnetic base allows the user to mount to a metal
surface.
PRODUCT SPECIFICATIONS
Mode High Low
Output (Lumens) 350 175
Max Runtime 2 Hrs. 4 Hrs.
Power Source 3.7V 2200 mAh 18650 Lithium-ion Battery
Charge Time 4 Hrs.
Voltage 3.7V
Power 3W
Beam Distance 85 Ft. (26 m)
Impact Resistant 3.2 Ft. (1 m)
Dimensions 13.25" x 1.31" x 1.31"
Weight 0.25 Lbs.

3
Operating Instructions and Parts Manual 26028
10/18
2018 OEMTOOLS™
SLIM FOLDING
RECHARGEABLE WORK LIGHT
FEATURES
• High/Low/Off button for work light
• 360° Adjustable light with 180° swivel head
• Powerful magnetic base
• Comes with a USB charging cord
• Bonus carabiner for belt mounting
• Indicator Lights: Green when fully charged and red
when charging
CONTENTS
Work Light (1), Instruction Manual (1), USB charging
cord (1) and Carabiner (1).
NOTE:Fully charge the battery before first use.
OPERATION
The OEMTOOLS™ Slim Folding Rechargeable Work
Light incorporates a small compact design and features
a super bright COB LED light that provides light where
needed. A push On/Off button is located on the front of
the light. A magnetic base allows the user to mount to a
metal surface. The Li-ion long life battery is rechargeable
via the included USB cord.
PRODUCT MAINTENANCE
1. Always store the OEMTOOLS™ Work Light in a
well-protected area where it will not be exposed to
inclement weather, corrosive vapors, abrasive dust or
any other harmful elements.
2. Keep the work light clean by wiping with a damp cloth.
3. Inspect cable periodically and, if damaged, replace.
4. Recharge periodically when not in use.
DISPOSAL
At the end of the useful life of the OEMTOOLS™ Work
Light, dispose of the components according to all state,
federal and local regulations.
BATTERY DISPOSAL
Exposure to high temperatures can cause the batteries
to explode; DO NOT dispose of in a fire. Some countries
have regulations concerning battery disposal. Follow
all applicable regulations. Return used batteries to a
collection location for recycling. Call 800-822-8837 or
visit www.call2recycle.org to find a collection location.
NOTE:OEMTOOLS™ and/or its distributors have
provided the parts list and assembly diagram as a
reference only. Neither OEMTOOLS™ nor its distributors
make any representation or warranty of any kind to the
buyer and/or user of this tool that he or she is qualified
to do any repairs or replace any parts of this product.
OEMTOOLS™ and its distributors expressly state that all
repairs or parts replacement should be done by certified
or licensed technicians. The buyer assumes all risk and
liability arising out of his or her repairs or parts replacement
to the original product.
Figure Description
A
COB LED Light
B On/Off Button
C Battery Power Indicator
D Magnetic Base
E Charging Port (Not shown)
F USB Charging Cord (Not shown)
G Carabiner (Not shown)
PARTS LIST
A
B
C
D

4
Operating Instructions and Parts Manual 26028
10/18
2018 OEMTOOLS™
SLIM FOLDING
RECHARGEABLE WORK LIGHT
CONTACT US
3580 E. Raines Road, Suite 3, Memphis, TN 38118
Tel: [phone]
www.oem-tools.com
OEMTOOLS™ ONE YEAR WARRANTY
For up to one year from the date of purchase of this OEMTOOLS™ product, if you find any defect in material or
workmanship (through normal usage), return it to the place of purchase or to OEMTOOLS™ for repair or replacement
at our discretion. In order to obtain this service, send the product and proof of purchase (transportation pre-paid) to:
OEMTOOLS™ Q.A. Dept, 3580 E. Raines Road #3, Memphis, TN 38118.
We will not be responsible for lost or damaged goods during transportation; please insure your package. If our
inspection verifies the defect, we will either repair or replace the product, or we may elect to refund the purchase price
if we cannot readily and quickly provide you with a replacement. We will return repaired products at our expense, but if
we determine there is no defect, or that the defect resulted from causes not within the scope of our warranty, then you
must bear the cost of returning the product.
OEMTOOLS™ does not provide warranty for products labeled other than OEM®or OEMTOOLS™. OEMTOOLS™ will
not provide any warranty for products subjected to abnormal use. Abnormal use includes (but is not limited to) abuse,
accident, alteration, neglect, and unauthorized or unreasonable use or repairs. This warranty does not cover bits,
blades, files, batteries, or calibration. We recommend that you maintain your tools and sharpen or replace blades, bits,
files, and batteries as necessary. OEMTOOLS™ reserves the right to make any changes in construction or design at
any time without any obligation in incorporating such changes to tools or equipment previously sold.
OEMTOOLS™ makes every effort to ensure that its products meet high quality and durability standards, and warrants
to the original purchaser that this product is free from defects in materials and workmanship for the period of one
year from the date of purchase. This warranty does not apply to damage due directly or indirectly to misuse, abuse,
negligence or accidents, repairs or alterations outside our facilities, criminal activity, improper installation, normal wear
and tear, or to lack of maintenance.
We shall in no event be liable for death, injuries to persons or property, or for incidental, contingent, special or
consequential damages arising from the use of our product. Some states do not allow the exclusion or limitation of
incidental or consequential damages, so the above limitation of exclusion may not apply to you. THIS WARRANTY
IS EXPRESSLY IN LIEU OF ALL OTHER WARRANTIES, EXPRESS OR IMPLIED, INCLUDING THE WARRANTIES OF
MERCHANTABILITY AND FITNESS. This warranty gives you specific legal rights, and you may also have other rights,
which vary from state to state.
