C7000 & C9000 SERIES V2 COLOUR AND MONO PRINTERS

success is a colourful business
oki’s 2-in-1 colour and mono printers have changed the workplace they are fast, they are flexible and – vitally
– they are affordable to run they make it easy for every member of the team to produce high quality results
every time And in doing so, they answer a real commercial need: to make every piece of printed communication
work harder for your business
Following the success of the C7000 and C9000 Series network printers for workgroups,
the enhanced C7000 and C9000 Series V2 boast a number of additional features and useful functions. hese include:
l Support for Macintosh Rendezvous™– Apple’s new network configuration software
lImproved USB2 support; faster CPU and network performance
lA multi-purpose paper tray supporting duplex printing
l ‘Ask Oki’ – a brand new, user-friendly function that gives a direct link from your printer driver screen to a dedicated
web site specific to the exact model you are using. his is where you’ll find all the advice, assistance and support you
could need to help you get the best possible results from your Oki printer
l Chromability™ – in-house colour printing made easy, only from Oki. Chromability™is about making it easy for
everyone in your office to produce professional results in colour
2
colour printers fax/mfp mono printers dot matrix printers
why oki?
We believe that effective printed communications are fundamental to successful businesses. hat’s why we focus purely on
understanding their diverse printing requirements. hrough our considerable technological resources we develop fast, high
quality, cost-effective printing solutions that will benefit businesses today and long into the future.
It is the same progressive spirit that drove Kibataro Oki to found Oki Electric in 1881, and which helped his company to become
the global, multi-billion Euro business that it is today. A business whose people share one single-minded purpose: helping
other businesses grow and prosper by enabling them to create the best possible impression with their printed communications.
Oki has led the way in making in-house colour printing fast and affordable. We now lead the way in making it easy. his
means more than providing unique technologies and in-built functions like fast, single-pass colour, double-sided printing,
and banner printing: it means making those functions as easy to use as possible – first time, every time. We call this
Chromability™ – in-house colour printing made easy, only from Oki. In short, it’s about you getting the most from your Oki
– and yourself.
Our colour-coded product segments below are designed to help you save time. When you want to add another Oki product
to your range, or check out the latest advances in technology on our website, simply use the following colour guide.

contents
fast, affordable 2-in-1 printing for workgroups 04
ask oki’ 05
total professional quality 08
cost-effective to use, manage and maintain 09
in-house colour printing made easy 10
making the most of the oki colour revolution 11
more than 25 major industry
awards have established oki as
a serious player in the global
colour printer market.
3

how our new network colour generation goes further
before oki’s range of 2-in-1 printers was introduced, business professionals had long been waiting for colour and
mono printing from one machine that delivered high speed, high quality and genuine affordability – whether printing
colour or mono all too often the only options available were expensive ink-jet printers, slow laser printers, being
networked to a high-end colour printer inconveniently located in another department, or simply taking the job to a
high street print shop
imes have changed. he launch of Oki’s colour printers made life in the modern office
easier and more productive. For the first time a colour printer could meet all your colour
and mono printing needs – without compromise on speed, quality or cost.
With the enhanced C7000 and C9000 Series V2 network colour printers, Oki has gone
even further with colour printing applications that are even more flexible, easier to use,
easier to manage, easier to network and far more productive.
Oki has invested in the development of features that are essential to today’s office
users. Now, just one reliable printer can handle the most demanding workload. here’s
no cost penalty for printing mono, but there is the option to inject glorious colour
where it really makes a difference. he C7000 and C9000 Series V2 colour printers can
be reliably employed at the heart of any business.
4

look what you can do – with ease
Because the new C7000 and C9000 Series V2 are from Oki,
you don’t just get a great colour and mono printer packed
with user friendly features, you also get plenty of help to
make the most of them. We call this Chromability™
– in-house colour printing made easy, only from Oki.
wo examples of Chromability™ include our simple to use
emplate Manager software and ‘Ask Oki’ support service,
both of which demonstrate our commitment to helping you
get the most from your Oki printer.
emplate Manager allows you to quickly and confidently
create a
range of impressive documents – from 1.2m long
banners to business
cards. You can also easily print PDF files,
transparencies, spreadsheets and colourful PowerPoint
presentations. Most importantly, your results will look as
professional as today’s business world demands.
And if you ever need advice on getting the most out of your
printer then just ‘Ask Oki’. You’ll find the ‘Ask Oki’ button on
your printer’s driver screen; it will take you straight to a
dedicated web site specific
to your C7000 Series V2 or
C9000 Series V2
to help you unlock your printer’s true potential.
template manager
ask oki’
5

20ppm colour and 24ppm mono
paper trays capacity of 530 sheets
maximum paper input capacity of 1690 sheets
with additional trays (optional)
single-pass Digital LED Technology delivers high speed and superb reliability
prints paper weights up to 203gsm
optional integrated
duplex unit for
double-sided printing
(standard on C7300dn
and C7300hdn)
time to first print 12 secs colour and 10 secs mono
high capacity toner cartridges deliver 10,000 printed pages
at 5% coverage per A4 page
up to 1200 x 1200
dpi resolution
the new C7000 Series V2 features at a glance C7300 V2C7300n V2C7300dn V2C7500hdn V2
20ppm colour • • • •
24ppm mono • • • •
Printer language PCL5c/PCL6/ PCL5c/PCL6/ PCL5c/PCL6/ PCL5c/PCL6/
Adobe PostScript®3 Adobe PostScript®3 Adobe PostScript®3 Adobe PostScript®3
Auto Colour Balance • • • •
Integrated Networking + USB 2.0 Optional network • • •
Resolution 1200 x 600 1200 x 600 1200 x 600 1200 x 1200
10GB Hard Disk Drive Optional Optional Optional •
Memory 64MB 64MB 128MB 256MB
Processor speed 450MHz 450MHz 450MHz 450MHz
Automatic double-sided printing Optional Optional • •
Second paper tray Optional Optional Optional Optional
• Standard
C7000 SERIES V2
6

30ppm colour and 37ppm mono
paper trays capacity of 550 sheets
maximum paper input capacity of 2850 sheets
with additional tray (optional)
and high capacity feeder (optional)
single-pass Digital LED Technology delivers high speed and superb reliability
prints paper weights up to 203gsm
time to first print 11.5 secs colour and 10 secs mono
high capacity toner cartridges deliver 15,000 printed pages
at 5% coverage per A4 page
up to 1200 x 1200
dpi resolution
7
the new C9000 Series V2 features at a glance C9300n V2 C9300dn V2 C9300hdn V2 C9500dn V2 C9500hdn V2
30ppm colour/37 mono • • • • •
A3 Printing • • • • •
Printer language PCL5c/PCL6/ PCL5c/PCL6/ PCL5c/PCL6/ PCL5c/PCL6/ PCL5c/PCL6/
Adobe PostScript®3 Adobe PostScript®3 Adobe PostScript®3 Adobe PostScript®3 Adobe PostScript®3
Auto Colour Balance • • • • •
Integrated Networking + USB 2.0 • • • • •
Resolution 1200 x 600 1200 x 600 1200 x 600 1200 x 1200 1200 x 1200
10GB Hard Disk Drive Optional Optional • Optional •
Memory 128MB 192MB 192MB 320MB 320MB
Processor speed 450MHz 450MHz 450MHz 600MHz 600MHz
Automatic double-sided printing Optional • • • •
Second paper tray + High Capacity Feeder Optional Optional Optional Optional Optional
C9000 SERIES V2
optional integrated
duplex unit for
double-sided printing
(standard on C9300dn,
C9300hdn, C9500dn,
C9500hdn)

total professional quality
oki’s reputation for building printers that last is now matched by the advantage of easy to use features that meet all the
demands of a professional environment
8
up to 1200 x 1200 dpi at full print speed
With the C9500 V2, Oki has doubled the CPU cache from 256KB to 512KB, enabling
the printer to comfortably handle 30 pages per minute even when printing graphics
intensive files at A3 size. his keeps workflow smooth and productivity high, and
makes the whole C7000 and C9000 Series V2 ideal for producing colourful,
customer-facing documents such as brochures, public accounts, mailers and highly
personalised direct marketing pieces.
excellent media flexibility
Users can put any paper type in any paper tray, or add additional trays and the printer
gets on with the job automatically. Ultra wide paper range capability – from 60 to
203gsm and from A6 to A3+. Each paper tray can take a full ream of paper and extra
trays can be added – all of which can handle media up to 203gsm and up to A3+ on
the C9000 V2 from transparencies to business cards and large formal banners.
quality finishing made easy
he C9300/9500 V2 Finisher increases productivity in the office by offering full
control and management of office printed documents. It can stack large volume print
jobs, hole-punch and staple with no compromise on speed (30 pages per minute
colour, 37ppm mono) or quality. It is fully integrated with the printer driver, which
enables users to easily set print jobs with little intervention.

9
cost-effective to use, manage & maintain
At Oki, we believe that well-printed material is fundamental to business success,
So the C7000 and C9000 Series V2 printers are created to deliver the kind of
performance and features that make printing high quality documents fast and easy.
Just as importantly – for any business – they are cost-effective, too. hey come with
low cost of ownership, that eliminates the need for investment in separate colour
and mono printers, and there’s no cost penalty for printing mono.
shared printer costs
When everyone in the workgroup or department can be easily networked to the same
hardworking printer – for both colour and mono printing – you make an instant and
substantial reduction in printing costs. With the C7000 Series V2 for 2-10 users
and the C9000 Series V2 for 5-20 users, there’s no longer a need for a collection
of separate mono laser printers or expensive colour inkjets for individual desks.
And with performance like 20ppm (pages per minute) colour and 24ppm mono for
the C7000 Series V2 and 30ppm colour and 37ppm mono for the C9000 Series V2,
you can significantly increase output and at the same time significantly decrease costs.
he unique print control software that is supplied with the printer enables you to limit
end-users volume, restrict the use of colour and lock out unauthorised users when the
printer is connected across the network (or via the parallel or USB port). Unlike many
printers, Oki toners and drums are replaced independently and are therefore less
wasteful. Each component part can be used to its maximum life and you don’t need
to replace parts unnecessarily.

10
one source for printing and copying
With Oki’s new S900 Scancopier for C9000 Series V2 and S700 Scancopier for C7000
Series V2 there’s no need for an expensive separate photocopier. It is the ideal partner for
the C7000 and the C9000 Series V2 colour printers, offering high quality A3 and A4 colour
and mono copying – at a cost far below a standard copier. Users can scan multi-page
documents at a fast 11ppm (pages per minute) colour and 27ppm mono or print multiple
copies of a single page document at up to 30ppm colour and 37ppm mono. Supplied with
advanced Unimessage Pro software that allows scan to PC, scan to e-mail, and scan to fax,
the S700 and S900 make your Oki printer as versatile as it is productive.
the oki pledge: no penalty for printing mono
Oki has pioneered fast, affordable 2-in-1 printing for workgroups with no compromise on
speed, quality – or cost. he C7000 and C9000 Series V2 printers will help every user to
produce professional quality results easily, confidently and at speed – whether printing
colour or mono. And what’s more, printing mono pages will cost no more than the average
mono desktop printer.
in-house colour printing made easy
Oki make printers that make colour printing easy. he C7000 and C9000 Series V2
network printers come with intelligent features and functions that help every user
to produce professional looking documents first time, every time, whatever their
skill level.
user friendly colour
Oki’s 2-in-1 printers make printing colour as easy as printing mono. Colour calibration
is done automatically with Auto Colour Balance ensuring that colour is consistent on
every page, every day of the week. Oki Auto Media Detect reduces paper wastage,
paper jams and frustrating downtime caused by the wrong type of media being
selected or different settings required for different papers. It measures the weight of
each piece of paper to ensure the correct settings are made. And with the option to
print double-sided you can reduce your paper consumption considerably.
Also, Oki Auto Rgistration ensures that print output is sharp and of consistent quality.

11
intelligent networking
Your new Oki colour printer is ready to run right out of the box. Just plug it in and it will
automatically locate and link up to your network and be ready to start work immediately.
Oki PrintSuperVision network management software ensures that new users are
recognised immediately and the necessary drivers are downloaded automatically,
ensuring the management of your Oki colour printer is as painless as possible.
As well as recognising new users, the drivers in Oki network colour printers also update
themselves to new configurations without any intervention if new options are added.
making the most of the oki colour revolution
By making high speed, consistent colour printing so easy to achieve while cutting the
cost of ownership, Oki does more than eliminate the need for separate colour and mono
printers in the workplace. Our enhanced C7000 and C9000 Series V2 of network
printers gives you the kind of innovative functions that can turn office printing into a
tangible asset for your business.

Oki Europe, part of Oki Electric
Oki Europe Limited
Central House, Balfour Road,
Hounslow, Middlesex TW3 1HY
United Kingdom
Tel: [phone]
Fax: [phone]
www.okieurope.com
Only use genuine Oki Original consumables to ensure the best quality and performance from your hardware.
Non Oki Original products may damage your printer’s performance and invalidate your warranty. Specifications
subject to change without notice. All trademarks acknowledged.
© 2004 Oki Europe Ltd.
C7300 V2 C7500 V2 C9300 V2 C9500 V2
A4 print speed
C7300: 01132401
C7300n: 01132501
C7300dn: 01132601
C7500hdn: 01132801 C9300n: 01132901
C9300dn: 01133001
C9300hdn: 01133101
C9500dn: 01133301
C9500hdn: 01133401
20ppm colour, 24ppm mono 20ppm colour, 24ppm mono 30ppm colour, 37ppm mono 30ppm colour, 37ppm mono
8ppm 10ppm
16ppm colour, 20ppm monoN/A
11.5 seconds colour, 10 seconds mono
90 seconds 160 seconds
450MHz 450MHz 600MHz
1200 x 600 dpi 1200 x 1200 dpi 1200 x 600 dpi
1200 x 1200 dpi
Automatic colour balance ensures consistent colour at power on and at installation of new toner or drum; Auto Registration occurs on power up,
when the cover is opened and after 400 printed pages (not in middle of printed job) oner Save mode.
Oki Colour Matching; ICC-compliant colour profiles for ColorSync and ICM; EuroScale and SWOP commercial press simulations; Pantone Certification
Windows 95, Windows 98, Windows 98 SE, Windows ME, Windows N 4 Workstation, Windows N 4 Server, Windows 2000 Workstation, Windows 2000 Professional, Windows 2000 Server,
Windows 2000 Advanced Server, Windows XP Professional, Windows XP Home, Windows N erminal Server Edition and Windows 2000 erminal Server with Citrix Metaframe 1.8
or Citrix Metaframe XP 1.0. Mac OS 8.6 (or higher), Mac OS X (10.1 or higher), Variants of Unix and Linux via PPDs
80 scaleable PCL fonts, 1 bitmap font, 10 rue ype fonts, 136 Adobe ype 1 fonts, OCR A/B, USPS Barcode
A4 OHP colour
A3 print speed
ime to first print
Speed &
throughput
Part nos
ypefaces
Single Pass Digital LED electrophotographic page printer with four image drum cartridges
Adobe Postscript®3 with direct pdf printing and PCL5c and PCL6; Automatic emulation switching; Epson FX and IBM ProPrinter Dot Matrix emulations
Printing process
Print quality
Compatability
Memory
Warm up time
Processor speed
Resolution
Enhancements
Colour matching
Printer fonts
Printer languages
RAM
Max RAM
64MB C7300, C7300n
128MB C7300dn
256MB 128MB C9300n
192MB C9300dn
192MB C9300hdn
320MB
Paper handling Internal tray capacity
(tray 1) and paper
weight
530 sheets, 60–176gsm, 200 sheets OHP 550 sheets, 64–203gsm, 200 sheets OHP
Operating
conditions
emperature/
Humidity (operating)
Storage
10°C – 32°C (17°C – 27°C recommended) / 20% to 80% RH (50% to 70% RH recommended)
-10°C – 43°C, 10% to 90% RH
Power
requirements
Noise level
Power supply
Power consumption
Printer duty (max)
Single phase 220-240VAC, frequency 50Hz +/- 2Hz
Operating: 56dBA, Standby: 45dBA, Power save: 43dBA Operating: 55dBA, Standby: 45dBA, Power save: 43dBA
Dimensions (HxWxD) 430 x 430 x 620 mm 460 x 666 x 626 mm
Weight 47.5kg approx 72kg approx
Duty Cycle 100,000 pages/month 150,000 pages/month
onerConsumables life 10,000 pages at 5% coverage per colour
(printers are shipped with 5 000 pages worth of each toner at 5% coverage)
15,000 pages at 5% coverage per colour (printers are shipped with
7,500 pages worth of each toner at 5% coverage)
Drum 23,000 page average life 30,000 page average life
Fuser 60,000 pages 80,000 pages
ransport belt 60,000 pages @ 3P/J 80,000 pages @ 3P/J
Warranty Pan European 1 year on-site
ypical 500W, Peak 1350W, Idle 150W (average), Power Save < 45W ypical 800W, Peak 1400W, Idle 200W (average), Power Save < 75W
Optional 2nd tray 530 sheets, 60–176gsm 550 sheets, 64–203gsm
Optional 3rd tray 530 sheets, 60–176gsm 550 sheets, 64–203gsm
Optional High
Capacity Feeder (HCF)
Paper size (any tray)
N/A 3 x 550 sheets, 64 - 203 gsm (max 4 additional trays including HCF)
10GB Hard Disk Drive Option Standard Option C9300n
Option C9300dn
Standard C9300hdn
Option C9500dn
Standard 9500hdn
IEE 1284 Bi-directional Parallel and USB High Speed 2.0; 10/100- X Ethernet card (optional on C7300)
Connectivity
OS Compatibility
10/100 Base X Ethernet Card with internal Web Server for printer and network card set-up and management.Includes POP3 and SM P Mail client for submission of print jobs and for alerts.
ALL major network protocols supported - CP/IP, Netware, Ethertalk and NetBEUI. CP/IP :-ARP, RARP, IP, ICMP, CP, UDB, LPR, F P, ELNE , H P(IPP), BOO P, DHCP, SNMP, DNS, JetDirect protocols.
Netware 3.x, 4.x, 5.x and 6 with full NDS and NDPS support:- PServer, RPrinter, NDPS supported via dedicated OKI NDPS Gateway. Ether alk:- ELAP, AARP, DDP, AEP, NBP, ZIP, R MP, A P, PAP.
NetBEUI:- SMB, NetBIOS.
Network and
Protocols
Print Control software allows ability to manage and control colour printing on the network; PrintSuperVision: Web-based software printer management tool; Oki emplate Manager:
easy-to-use software that enables simple creation of templates for printing business cards, banners and bar-coded documents; Storage Device Manager*: stores and manages forms, letterheads
logos and fonts. *Hard Disk Drive required
A4 , A5, B5 , A6 (tray 1 only), Legal13, Legal13.5, Legal14, Letter, Executive A3, A3Nobi, abloid Extra, A3wide, A4, A4-L, A5, B4, B5, B5-L, A6 (tray 1 only), abloid,
Legal13, Legal13.5, Legal14, Letter, Letter-L, Executive
Multi-purpose tray A4, A5, B5, A6, C5, DL, Com-9, Com-10, Monarch, Custom Size (up to 1200mm length),
Legal13, Legal13.5, Legal14, Letter, Executive
A3, A3Nobi, abloid Extra, A3wide, A4, A4-L, A5, A6, B4, B5, B5-L, C5, DL, C4, Com-9,
Com-10, Monarch, Custom Size (up to 1200mm length), abloid, Legal13, Legal13.5,
Legal14, Letter, Letter-L, Executive
Multi-purpose paper
weight
64 – 203gsm (max capacity 100 sheets of 80gsm paper)
Duplex paper weight 75 – 105gsm
Paper feeding Auto Media Detect (automatic paper weight detection), Auto Paper ray Select (automatically detect paper size up to A3), ray Empty Sensor
Paper output 500 sheets face down, 100 sheets face up
N/A 2-tray stacker/puncher/stapler (Lower tray only) output device with 100 + 1000 A4 sheet output
capacity. Upper tray: 64gsm to 200 gsm face up, lower tray: 64gsm to 104gsm face down.
Finishing
Copying options S700 Scancopier offers high quality A4 colour and mono copying at up to 3ppm colour and
10ppm mono. Supplied with Uni Message Pro for scan to PC and scan to email.
Automatic Document Feeder optional.
S900 Scancopier offers high quality A3 & A4 colour and mono copying at up to 11ppm colour and
27ppm mono. Supplied with Uni Message Pro for scan to PC and to email.
Automatic Document Feeder optional.
1024MB (optional 64MB, 128MB, 256MB, 512MB DIMMs)
Utilities
12 seconds colour, 10 seconds mono
®
As an ENERGY S AR Partner, Oki Europe Ltd has
determined that this product meets the
ENERGY S AR guidelines for energy efficiency.
Oki is proud to sponsor the Oki European
Challenge 2005. For more information visit
www.okieuropeanchallenge.com
2005
european challenge
C7000 & C9000 SERIES V2 COLOUR AND MONO PRINTERS
