Okina USA EIR48-42VF Quick start guide

EIR48-42VF_rev041820081
Operational Manual
IR Day & Night Weatherproof Color Camera
1/3” Sony Super HAD CCD
420 TV Lines
48 IR LED
3.5mm~8.0mm Vari-Focal Lens
1. Drill the installation holes for the screws on the wall. Please refer to the mounting guide sticker.
2. Loosen the screw to adjust the bracket.
FEATURES
Please read the Operational Manual
before attemptin
g
to use this product.
0.1 Lux @ F2.0 / 0 Lux @ IR “on”
IR Distance 100~130ft / 30~40m
Weatherproof IP65 Rating
90~110mA @ IR “off” / 390~470mA @ IR “on”
12V DC
INSTALLATION
NOTE 1: Due to the heavy weight of
the camera, please use all 4 screws to
mount the camera.
NOTE 2: Please use the appropriate
screws for your wall mount application.
EIR48-42VF
EIR48-42VFP

EIR48-42VF_rev041820082
3. Place the video/power cable through the bracket.
4. Connect the bracket to the camera.
5. Fix the bracket into the wall with the screws provided.
6. Loosen the screws and adjust the camera to the desired angle.

EIR48-42VF_rev041820083
7. Connect the video/power cable to the correct connector.
Model EIR48-42VF EIR48-42VFP
TV System NTSC PAL
Image Sensor 1/3” Sony Super HAD CCD
DSP Sony
Total Pixels 500(H) x 582(V) 500(H) x 492(V)
Video Output Composite Video Output
1 Vp-p 75 Ω
Resolution 420 TV Lines
Minimum Illumination 0.1 Lux @ F2.0 (0 Lux @ IR “on”)
S/N Ratio More than 52dB
Electronic
Shutter Speed 1/60 ~ 1/100,000 sec 1/50 ~ 1/100,000 sec
Synchronization Internal
Gain Control Auto
White Balance Auto
IR LED 48 IR LED
IR Wavelength 850nm
IR LED Life 20,000 Hours
View Angle 60
IR Working Distance 100~130ft / 30~40m
Lens 3.5mm~8.0mm Vari-Focal Lens
IP Rating Weatherproof IP65
Power Supply 12V DC
Power Consumption 90~110mA @ IR “off” / 390~470mA @ IR “on”
Operation Temperature -20oC ~ +50oC / -4oF ~ 122oF
Humidity RH95% Max.
Dimension 266(L) x 106.3(W) x 225.95(H) mm
Weight 2.8 lbs / 1270g (with bracket)
SPECIFICATIONS

EIR48-42VF_rev041820084
One (1) EIR48-42VF/EIR48-42VFP Camera with video/power cable
Four (4) Mounting Screws
Four (4) Wall Anchors
One (1) Allen Wrench
One (1) Operational Manual
*For any returns, please include all components listed above with original packaging in Resalable Condition. Absolutely No Returns will be accepted if any
component is missing/damaged or if any cable is cut or tampered with.
This product is covered under warranty for one year from the date of purchase. The warranty will automatically be voided if any of the following
occurs:
1.
Camera sticker is removed
If the camera sticker is removed, we will not be able to confirm any information regarding when and where the product was purchased. We
have no other way to verify the purchase record without the serial number on the camera sticker; therefore, it should not be removed.
2.
Camera is modified in any way
If the camera is scratched, damaged, or modified in a manner not described in this manual, the warranty will be voided immediately. It is the
customer’s responsibility to keep the camera in good condition.
3.
Video or power cable is cut
The video cable and the power cable should not be tampered with. Cutting or modifying of the cables will result in termination of the warranty.
1. Never point the camera toward the sun
Do not expose the lens directly to the sun or to strong light as this may damage the pick-up device.
2. Handle this camera with care
Avoid any shock or bumping of the camera. Improper handling could damage the camera.
3. Requires a proper operating environment
This camera is designed for outdoor or indoor use. The allowable temperature range for operation of this camera is between -20C ~ 50C and
the allowable humidity is 85%RH maximum.
4. Clean the front face to the pick-up device
It is recommended that the pick-up device surface be cleaned before lens installation or whenever the lens is changed. Cleaning should be done
by using a chamois, a very fine soft cloth, lens tissue, or cotton tipped applicator and ethanol to carefully remove any fingerprint or dust.
5. Check the power source voltage
The power source voltage should be within the specified range. (Camera must meet the specifications). Camera must be connected to a surge
protector at all times.
6. Objects and liquid entry
Never push objects of any kind into this camera as this may touch dangerous voltage points of short out parts that could result in a fire or
electric shock. Never spill any kind of liquid on the video product.
7. Servicing
Do not attempt to service this video product by yourself as opening or removing covers may expose you to dangerous voltage or other hazards.
Refer all service to qualified servicing personnel.
8. Damage requiring service
Unplug this video product from the wall outlet and refer service to qualified servicing personnel under the following conditions:
a. When the power supply cord or plug is damaged.
b. If liquid has been spilled, or objects have fallen into the video product.
c. If the video product has been dropped or the cabinet has been damaged.
d. When the video product exhibits a distinct change in performance.
P
A
CKAGE CONTENTS
WARRANTY
CAUTIONS
