Olivetti d-Color MF1600 plus Installation and maintenance instructions

Network Guide
C3520 / C3530MFP
Code: 557007en
d-Color MF1600 plus
d-Color MF2000 plus

PUBLICATION ISSUED BY:
Olivetti S.p.A.
Gruppo Telecom Italia
Via Jervis, 77 - 10015 Ivrea (ITALY)
www.olivetti.com
Copyright © 2010,
The manufacturer reserves the right to carry out modifications to the product described in this manual at any time
and without any notice.
Your attention is drawn to the following actions which could compromise the conformity attested to above, as well as
the characteristics of the product:
• incorrect electrical power supply;
• incorrect installation, incorrect or improper use or use not in compliance with the warnings provided in the
User’s Manual supplied with the product;
• replacement of original components or accessories with others of a type not approved by the manufacturer, or
performed by unauthorised personnel.
All rights reserved. No part of this material may be reproduced or transmitted in any form or by any means,
electronic or mechanical, including photocopying, recording or by any information storage and retrieval
system, without permission in writing from the Publisher.
The markaffixed to the product certifiesthatthe
product satisfies the basic quality requirements.
Olivetti Allrightsreserved

Preface > 2
P REFACE
Every effort has been made to ensure that the information in this document is complete,
accurate, and up-to-date. The manufacturer assumes no responsibility for the results of
errors beyond its control. The manufacturer also cannot guarantee that changes in software
and equipment made by other manufacturers and referred to in this guide will not affect
the applicability of the information in it. Mention of software products manufactured by
other companies does not necessarily constitute endorsement by the manufacturer.
While all reasonable efforts have been made to make this document as accurate and helpful
as possible, we make no warranty of any kind, expressed or implied, as to the accuracy or
completeness of the information contained herein.
Oki is a registered trademark of Oki Electric Industry Company, Ltd.
Oki Printing Solutions is a registered trademark of Oki Data Corporation.
Energy Star is a trademark of the United States Environmental Protection Agency.
Microsoft, MS-DOS and Windows are registered trademarks of Microsoft Corporation.
Apple, Macintosh, Mac and Mac OS are registered trademarks of Apple Computer.
Other product names and brand names are registered trademarks or trademarks of their
proprietors.

Contents > 3
C ONTENTS
Preface . . . . . . . . . . . . . . . . .. . . . . . . . . . . . . . . . . . . . . . . . . . . .. . . . . .2
Contents . . . . . . . . . . . . . . . .. . . . . . . . . . . . . . . . . . . . . . . . . . . .. . . . . .3
Notes, cautions and warnings. . . . . . . . . . . . . . . . . . . . . . . . . . . .. . . . . .4
Network configuration. . . . .. . . . . . . . . . . . . . . . . . . . . . . . . . . .. . . . . .5
Introduction .. . ... . ... . .. . ... . ... . .. . ... . ... . .. . ... . ... . .5
Specification.. . ... . ... . .. . ... . ... . .. . ... . ... . .. . ... . ... . .5
Self-diagnostic test . . ... . .. . ... . ... . .. . ... . ... . .. . ... . ... . .5
Configurationutilities.... . .. . ... . ... . .. . ... . ... . .. . ... . ... . .6
Network card setup utility... . ... . ... . .. . ... . ... . .. . ... . ... . .6
Using a web browser.... . .. . ... . ... . .. . ... . ... . .. . ... . ... . .7
Default user name and password .. . ... . .. . ... . ... . .. . ... . ... . .7
Adjusting printer settings .. . ... . ... . .. . ... . ... . .. . ... . ... . .7
Using SNMP .. . ... . ... . .. . ... . ... . .. . ... . ... . .. . ... . ... . .9
Management utility - PrintSuperVision (Windows only) .. . .. . ... . ... . .9
LPR printing utility (Windows only) .. . .. . ... . ... . .. . ... . ... . .10
System requirement .. . .. . ... . ... . .. . ... . ... . .. . ... . ... . .10
Installing the LPR utility .... . ... . .. . ... . ... . .. . ... . ... . .10
Uninstalling the LPR utility .. . ... . .. . ... . ... . .. . ... . ... . .11
Windows. . . . . . . . . . . . . . . .. . . . . . . . . . . . . . . . . . . . . . . . . . . .. . . . .12
Overview . . .. . ... . ... . .. . ... . ... . .. . ... . ... . .. . ... . ... . .12
Installing a network printer .. . ... . ... . .. . ... . ... . .. . ... . ... . .12
Using the driver installer.... . ... . .. . ... . ... . .. . ... . ... . .12
Using the add printer wizard . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
Configuring the network printer IP address. . . . . . . . . . . . . . . . . . . . . . . .14
Launching the network card setup utility . . . . . . . . . . . . . . . . . . . . . . .14
Starting the network card setup utility . . . . . . . . . . . . . . . . . . . . . . . . .15
Manually configuring the IP address . . . . . . . . . . . . . . . . . . . . . . . . . .15
Changing the admin password . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
Enable/disable the printer web page . . . . . . . . . . . . . . . . . . . . . . . . . .15
Updating environment settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
Viewing the printer web page . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
Uninstalling the network card setup utility . . . . . . . . . . . . . . . . . . . . . .16
Mac OS X . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
Printing the configuration page . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
Installation instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
Launching the network card setup utility . . . . . . . . . . . . . . . . . . . . . . .17
Setting the printer discovery settings. . . . . . . . . . . . . . . . . . . . . . . . . .18
Changing the password . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
Enable/disable the printer web page . . . . . . . . . . . . . . . . . . . . . . . . . .19
Quitting the network card setup utility . . . . . . . . . . . . . . . . . . . . . . . . .19
Configuring the network interface card . . . . . . . . . . . . . . . . . . . . . . . . . .19
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20
Self-diagnostic test . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20
Printer does not print . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20
NG is printed in the self-diagnostic test . . . . . . . . . . . . . . . . . . . . . . . .20
TCP/IP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20
Computer cannot find the network interface card . . . . . . . . . . . . . . . . .20
Cannot print with lpr . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20
Web browser . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21
Microsoft Internet Explorer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21
Mozilla Firefox. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21

Notes, cautions and warnings > 4
N OTES , CAUTIONS AND WARNINGS
NOTE
A note provides additional information to supplement the main text.
CAUTION!
A caution provides additional information which, if ignored, may
result in equipment malfunction or damage.
WARNING!
A warning provides additional information which, if ignored, may
result in a risk of personal injury.

Network configuration > 5
N ETWORK CONFIGURATION
I NTRODUCTION
Your machine incorporates a fast 100BASE-TX/10BASE-T network interface. This guide
explains the functionality of the built in network interface. Access for interconnection and
producing self-diagnostic test and configuration printouts is provided via an interface panel
located at the rear of the machine.
This network interface supports IEEE802.2, IEEE802.3, Ethernet-II and SNAP, and can
detect those frame types automatically. The network interface also supports TCP/IP
protocols.
This guide details the network interface specification and several software utilities.
S PECIFICATION
S ELF - DIAGNOSTIC TEST
With the machine power switched on, press the TEST button located on the network
interface panel (at the rear of the machine) for more than three seconds and then release.
The self-diagnostic test results and configuration settings are printed.
On the first page of the Network Information that is printed out, under the heading “General
Information” the MAC or Ethernet Address is given. For example:
MAC Address 00:80:87:D4:FA:00
The Ethernet address is therefore 00:80:87:D4:FA:00
NOTE
Not all utilities, features or protocols are supported by every operating
system. Please check with your User’s Guide and support website for latest
information.
ITEM SPECIFICATION
Frame Types IEEE 802.2
IEEE 802.3
Ethernet-II, SNAP, AUTO
Network Interface 100BASE-TX
10BASE-T
Network Protocols TCP/IP:
Network layer ARP
Session layer TCP, UDP
Application layer LPR, HTTP, BOOTP, DHCP, SNMP, DNS.
Functions Self-diagnostic test printing
Monitoring and configuration by Web browser

Network configuration > 6
C ONFIGURATION UTILITIES
You can configure the network interface card (NIC) by using one of the following methods:
N ETWORK CARD SETUP UTILITY
The Network Card Setup utility allows you to carry out the following:
>Set IP address, Subnet Mask and Gateway for TCP/IP manually or by using DHCP.
>Launch the Printer Web Page.
>Enable/disable the Printer Settings Web Page.
>Restart your printer to ensure settings have been saved.
For full configuration options for your printer, access the Printer Web Page. For information
on the Printer Web Page, see “Using a web browser” on page 7.
This utility can only be used on a computer that can be connected to the network with TCP/
IP and located on the same segment as the printer. Refer to the table above for system
requirements.
To install and configure the Network Card Setup utility, see
>Windows: “Launching the network card setup utility” on page 14.
>Mac OS X: “Installation instructions” on page 17.
UTILITY FEATURES SYSTEM REQUIREMENTS
Network Card Setup Configure the NIC by
launching or installing
the Network Setup
utility. This utility allows
you to:
Enable/disable the
Printer settings Web
Page.
Set IP address, Subnet
Mask and Gateway for
TCP/IP manually or by
using DHCP.
Windows:
Windows 2000
Windows XP Home/Professional
Windows XP Professional x64 Edition
Windows Server 2003
Windows Server 2003 x64 Edition
Windows Server 2008
Windows Server 2008 x64 Edition
Windows Vista 32-bit
Windows Vista 64-bit
Mac:
Mac OS X 10.3.0 or greater
Web Browser Configure the NIC and
printer by using a Web
browser such as
Microsoft Internet
Explorer or Mozilla
Firefox.
Microsoft Internet Explorer or similar.
Operating system that supports Web
browser.
SNMP The machine and
network card can be
controlled using third-
party vendor developed
SNMP application.
Third-party vendor developed SNMP
application.

Network configuration > 7
U SING A WEB BROWSER
If you do not wish to launch or install the Network Card Setup utility, you can access the
printer Web Page directly through a web browser.
If the printer is connected to the network using TCP/IP, its settings and the printer menu
settings can be configured using a web browser. Refer to the relevant manuals for details
of how to launch and use the browser. Refer also to “Web browser” on page 21 for
instructions on how to prevent your browser caching the printer web pages.
D EFAULT USER NAME AND PASSWORD
To apply configuration changes using a web browser, you will be prompted for a username
and password. The username is root and the default password is the last six characters of
the Ethernet (MAC) address, e.g. D4FA00 (any alpha characters must be in upper case).
You can change the root password to allow you to change settings and configure the printer
through the web browser. Refer to “Changing the admin password” on page 15 for Windows
and “Changing the password” on page 18 for Mac OS X.
A DJUSTING PRINTER SETTINGS
The network addresses used in this manual are shown as examples only. Network
addresses used in your installation must be generated from your own network.
1. Launch the Web browser and enter the IP Address of the network interface card in
Address (Location/Position) and press the Enter key.
You can find the IP Address on the Self-Diagnostic Test printout, refer to “Self-
diagnostic test” on page 5.
The printer Web Page is displayed.
2. To access and adjust printer control settings, such as printer, network, security and
maintenance, click the Administrator Login button in the left-hand pane.
3. Enter the username, “root” and password as the last six digits of the MAC address
(uppercase).
4. As this is the first time logging into the Printer Web Page, the Printer Identification
(basic setup) page is launched. You have two options:
>You can enter the printer location, asset number, administrator name and select
“Do not show this page again”. Click OK to save these details. Allow a few
seconds for the settings to save and the printer to restart automatically.
>If you do not wish to enter any details, click SKIP.
5. The Printer Web Page with full menu options opens up. Browse the menu and update
information as appropriate.
NOTE
On the web page you can view printer status, job lists and links. You can also
configure the IP Address, Subnet Mask and Gateway for the network card.
However, to configure printer settings, you need to log in as “root” and enter
the correct password to be able to configure all items.

Network configuration > 8
The following table outlines the menu options for the printer Web Page.
MENU OPTION DESCRIPTION
View Information
Status
Count
Supplies Life
Network
System
View information relating to your printer status,
consumables and network settings.
Print Information
Configuration
Network Information
Demo Page (Select demo page)
MFP Usage Report
Supplies Status Report
Scan to Log
Fax Activity Report
Fax Protocol Dump
Print configuration and report information.
Admin Setup
System Setup
PIN ID
Network Setup
Printer Setup
Scanner Setup
Mail Server Setup
LDAP Server Setup
Fax Setup
Memory Setup
Change Password
Reset Settings
Scanner Counter Clear
View and adjust any admin settings relating to your
machine.
Change your password and apply access restrictions for
your printer network.
Reset your printer and restore default settings for your
printer and Network Interface Card.
Printer Menu
Tray Configuration
Printer Adjust
Print Position Adjust
Drum Cleaning
View and adjust printer settings.
Copy Menu
Copies
Reduce/Enlarge
Mode
Density
Input Tray
Collate
N-up
Edge Erase
Margin Shift Right
Margin Shift Bottom
View and adjust copy settings.
Scanner Menu
Scan to Email
Scan to Network PC
Scan to USB Memory
View and adjust scan settings.
Fax Menu
Auto Receive
Mode
Density
Document Size
View and adjust fax settings.
Calibration
Adjust Color Density
Adjust Color Registration
View and adjust colour density and registration modes.
Job List
Settings
Allows you to manage pending jobs for your printer.

Network configuration > 9
U SING SNMP
The machine and network card can be managed via a standard SNMP management station.
The network card supports SNMPv1, MIB-II andPrivate MIB. To enable correct
management from an SNMP management station, the Private MIB needs to be
added to that management station. Please refer to the SNMP manager documentation for
more information on adding MIBs to SNMP management stations.
The printer’s trap address can be set in five places using TCP/IP.
Printer trap settings can be made through the web browser.
M ANAGEMENT UTILITY - P RINT S UPER V ISION (W INDOWS ONLY )
PrintSuperVision is a Windows server application designed for managing and monitoring
printing devices connected to a network. The core application is server-based and is
accessible from any browser enabled device connected to the network.
For full details of how to install and use PrintSuperVision, please refer to the
PrintSuperVision Configuration Guide which is available on the support website.
Links
Links
Edit Links
Add links for easy access to customer support and on-
line information.
NOTE
Not all utilities, features or protocols are supported by every product. Please
check with your User’s Guide and support website for latest information.
NOTE
The Private MIB file can be found in the Misc\ASN folder on the
DVD-ROM or support website. Please refer to the readme file for further
information.
NOTE
Not all utilities, features or protocols are supported by every product. Please
check with your User’s Guide and support website for latest information.
MENU OPTION DESCRIPTION

Network configuration > 10
LPR PRINTING UTILITY (W INDOWS ONLY )
The LPR Utility isautility that allows printing data to printers connectedto thenetwork
viaTCP/IP. It is an alternative method of connecting printers instead of using the Microsoft
TCP/IP port; however, the LPRutility offers some additional and very useful features:
>Displays printer status - print job status can be viewed, paused orcancelled.
>Download files directly to the printer -send PRN or PostScript files directly to
the printer.
>Redirect print jobs-send print jobs toother printers if theoriginalprinter is busy
or has an error.
>Multicast printing - send the same print job to many printers simultaneously1.
S YSTEM REQUIREMENT
Operating systems with TCP/IP support and the printers that support TCP/IP.
I NSTALLING THE LPR UTILITY
1. Insertthe DVD-ROM into theDVD-ROM drive. The Setup Utility starts automatically.
If it does not start, double-clicksetup.exe on the DVD-ROM.
2. Select the appropriate setuplanguage and clickI agree to accept the terms of the
Software Licence Agreement.
3. SelectSoftware Utilities > Install LPR utility.
4. In the Choose Setup Language dialog, select the appropriate language and click
OK.
The LPR utility is displayed.
5. Click Next.
6. Click Yestoaccept the Software Licence Agreement.
7. Verify Destination Folder and Spool Folder andclick Next.
8. SelectRegister in Startup if you want automatic startup as Windows boots up.
Select Launch as minimized if you want to startup in the Icon state. Click Next.
9. Verify the program folder name and click Next.
The installation starts.
10. When the installation ends, the Setup complete screen is displayed. Check Yes, I
want to launch LPR Utility now and click Finish.
11. Check Yes, I want to view the ReadMe File.
The LPR utility starts.
NOTE
Not all utilities, features or protocols are supported by every product. Please
check with your User’s Guide and support website for latest information.
1. The printers all have to be of the same model.
NOTE
SomeOperating Systems require administrator privileges in order to make
changes.

Network configuration > 11
12. You may be asked whether it is OK to change write permissions for the spool
directory. Click Yes to allow the utility to be correctly installed.
13. Select Remote Print > Add Printer.
14. Click Discover… to search for the IP address of a suitable machine on your
network.
15. Highlight the machine you will use and click OK.
16. If your machine is not discovered, click Cancel and type the IP address directly at
IP Address:.
17. Click OK. A machine is added to the main window.
Refer to the On-line Help for information on how to use the utility.
U NINSTALLING THE LPR UTILITY
1. To exit the LPRUtility,select File > Exit.
2. SelectStart > Programs > Okidata> LPR Utility > Uninstall LPR
Utility.
You may find this under Start > All Programs on Windows XP.
3. Click Yes when the “Confirm File Deletion” dialog is displayed.
Deletion of the LPR utilitystarts.
4. You may be asked whether you want to remove shared files. Click Yes.
5. When the deletion has finished, the “Uninstall Successfully Completed” screen is
displayed. Click OK.
If a file that has been added after installation exists in the folder to install the LPR utility
or the folder to spool, you cannot delete the folder. Delete any unwanted files before
running Uninstall LPR Utility.

Windows > 12
W INDOWS
O VERVIEW
This chapter provides guidelines on how toprint over the network from various Microsoft
Windows platforms. There are numerous ways of printing from Windows and the exact set-
up will vary depending upon your environment. There are also numerous versions of
Windows, which can be configured as either a client, server or both.
Although there are many variants of Windows, the principles of network printing remain
the same. Microsoft provides on-line help withallof their operatingsystems and this is a
good referencepoint for the exact details of each configuration option within Windows.
The network printer supportsTCP/IP protocolsthat can be used inconjunctionwith the
Windows operating system.
I NSTALLING A NETWORK PRINTER
There aretwo waysto set upa Network Printer:
>Install automatically,using the Driver Installer
>Install it yourself using the Add PrinterWizard
U SING THE DRIVER INSTALLER
The Driver Installerprogram searches for compatibleprinters on the Network, then
installs and configures the printer drivers withthe correct port settings automatically.
Usingthe Driver Installerprogram, you can install to the following connected printer
types:
>Locally connected printers
>USB port
>Parallel port
>Networkedprinters
>Directlyconnected (peer-to-peer) printers via TCP/IP The Microsoft standard TCP/
IP isinstalled and configured to use Port 9100 with the printer’s IP address.
>Printers not directly connected, but shared viaa PC (Client Server)
Why use the driver installer?
>Automatically discovers printers on the Network (TCP/IP)
>Installs driver and correctly assigns the appropriate port and IP address
>Allows easy configuration and sharing of the printer with other Network users

Windows > 13
U SING THE ADD PRINTER WIZARD
Method summary:
The following table shows the different ways to connect to the printer (port types).
About thedifferent methods
Windows standard TCP/IP port
The standard TCP/IP port simplifies connecting to remote printers using the TCP/IP
protocol.A computer that acts as a print server must run the TCP/IP protocol in order to
print.
Can be configured to use either LPR or RAW (e.g. Port9100).
LPR
LPR also includes useful tools enabling you todownload PS and PRN files directly to your
printer and automatically redirect jobs to other printers on the network.
WINDOWS
2000
WINDOWS
XP
WINDOWS
VISTA
WINDOWS
SERVER 2008
Windows
standard TCP/IP
YES YES YES YES
LPR YES YES NONO
Used to connect your printer over TCP/IP using LPR port.

Windows > 14
C ONFIGURING THE NETWORK PRINTER IP ADDRESS
The Network Card Setup utility allows you to configure the network printer IP address and
to view the Printer Web Page.
L AUNCHING THE NETWORK CARD SETUP UTILITY
The following steps describe how to launch and install the Network Card Setup utility:
1. Ensure that the printer is switched on and connected to the network.
2. Insert the Software DVD-ROM into the DVD-ROM drive. The Setup Utility starts
automatically. If it does not start, double-click setup.exe (in the root directory) on
the DVD-ROM.
3. Select the appropriate language option and click I Agree to accept the terms of the
Software Licence Agreement.
4. Select Software Utilities > Install Network Card Setup. The Network Card
Setup Installshield Wizard is displayed.
5. Click Next.
6. Select “I accept the terms of the licence agreement” and click Next.
7. On the “Select Launch Method” dialog, chose whether to “Launch it now without
installing” or “Install now to use it” and the click Next. If you select “Install now to
use it”:
(a) Click Next again.
(b) Click Install.
8. When the “InstallShield Wizard Complete” dialog displays, click Finish.
9. Select Start > All Programs > Okidata > Network Setup Card > Network
Setup Card.
The “Printer Discovery” message is displayed. When the printer is detected, the
Network Card Setup utility launches, displaying the printer status and network
information.
Now that both Windows and the printer have been configured to use TCP/IP, the next step
is to configure Windows to print to the network printer.
NOTE
In the “Network Card Setup”, the “IP Acquisition Method” may display as
“Manual”. This is because, when using the TCP/IP protocol in an environment
without a DHCP server, you must assign the IP address manually. For
instructions on how to do this, see “Manually configuring the IP address” on
page 15.
2
2

Windows > 15
S TARTING THE NETWORK CARD SETUP UTILITY
Once installed, you can launch the Network Card Setup utility by selecting Start >
Programs > Okidata > Network Card Setup.
M ANUALLY CONFIGURING THE IP ADDRESS
If there is no DHCP protocol to automatically assign IP addresses to devices on your
network, you might want to set the IP Address, Subnet Mask and Default Gateway Address
for your printer manually.
1. In the “Network Card Setup” pane, click to select the printer.
2. Click the Printer Setting icon. The Printer Settings dialog displays.
3. Select Manual. In the Details section, you can now edit the IP Address, Subnet
Mask and Default Gateway Address.
4. Click Apply. The “Setting Password” dialog displays.
5. Enter the password. The default password is the last 6 digits of the MAC Address
(upper case).
6. Click OK. Allow a few seconds for the changes to save and the printer to
automatically restart before the “Setup Complete” message box appears.
C HANGING THE ADMIN PASSWORD
To change the Admin Password for your printer:
1. Select Settings > Change Password.
2. Enter and verify the new password as requested.
3. Click OK. Allow a few seconds as the settings are saved and the printer
automatically restarts.
E NABLE / DISABLE THE PRINTER WEB PAGE
To enable/disable access to the Printer Web Page from the Network Card Setup utility:
1. Select Settings > Printer Settings.
2. Select the “Web Page Setting” tab and select Enable Web Page Setting or Disable
Web Page Setting.
3. Click Apply. The “Setting Password” dialog box displays.
4. Enter the admin password as requested and click OK.
5. The “Setup Complete” message is displayed.
If you now try to view the Printer Web Page, an error message is displayed (containing
instructions on how to enable the Printer Web Page again).
NOTE
If your printer stops at any time, you can restart it by selecting Printer >
Restart Printer in the “Network Card Setup pane”.

Windows > 16
U PDATING ENVIRONMENT SETTINGS
To change how the Network Card Setup utility searches for printers. You can update the
environment settings or the display options on the Network Card Setup utility:
1. Select Options > Environmental Settings.
2. You can apply the following changes:
>Enter the IP Broadcast Setting and click Add.
>Select or clear the Search Local Subnets check box.
>Under the “Time Out” tab, modify the Discover Printer(s) and Setting
intervals.
>Under the “Display Item(s)” tab, you can clear Display Item Settings check
boxes to prevent them from appearing in the main “Network Card Setup” pane.
3. You can restore default settings by opening this dialog and clicking Default.
V IEWING THE PRINTER WEB PAGE
To view the printer web page, click on the “Display Web Page” icon.
U NINSTALLING THE NETWORK CARD SETUP UTILITY
To uninstall the Network Card Setup utility:
1. Select Start > Control Panel.
2. Select Add or Remove Programs.
3. Select Network Card Setup and click Remove. This removes the Network Card
Setup utility from your computer.
4. Restart your computer to ensure that the utility has been fully removed.

Mac OS X > 17
M AC OS X
O VERVIEW
This guideis for administrators and it should beused in conjunction withthe relevant Mac
OS X manual.Please ensure your Mac has the latest Mac OS X updatesinstalled.
P RINTING THE CONFIGURATION PAGE
The printer’s configuration pagereports information that is required for Macintosh
configuration. Refer to“Self-diagnostic test” on page 5for details on how toprint a
configuration page.
The first six characters of the Ethernet address are the samefor all LAN type network
cards. The lastsix characters of the Ethernet address are unique to each card.
I NSTALLATION INSTRUCTIONS
You can start the utility directly from the DVD or if you plan touse the utility later, copy it
to your Mac'shard disk.
You can use the Network Card Setup Utility (Macintosh) to assign an IP address and
configure the network interface card. For more background information on the Network
Card Setup Utility, refer to the “Network card setup utility” on page 6 and, on installation,
the Network Card Setup utility On-line Help.
L AUNCHING THE NETWORK CARD SETUP UTILITY
Complete the following steps to launch the Network Card Setup utility on Mac OS X:
1. Ensure that the printer is switched on and connected to your computer and the
network.
2. Insert the Software DVD-ROM into the DVD-ROM drive and click on the DVD icon on
your desk-top.
3. Double-click on Utilities > Network Card Setup > English.
4. Double-click on the Network Card Setup icon. The “Discovering printers...” message
displays. Once the printer is detected, the “Network Card Setup” pane launches,
displaying the printer name and network information.
5. For more information about the Network Card Setup, follow the instructions outlined
below or click the Help button in the “Network Card Setup” pane.
MC360
MC360

Mac OS X > 18
S ETTING THE PRINTER DISCOVERY SETTINGS
To set the printer discovery search scope:
1. In the “Network Card Setup” pane, click to select the printer.
2. From the main menu, click Options > Preferences.
3. Under “Printer Discovery Settings” enter the “IP Broadcast Settings” and click Add.
4. Ensure that “Search local subnets” is selected.
5. You can modify the “Timeout Settings” for the search scope. If you want to restore
the original settings at any time, click the Defaults button.
6. Click Save.
7. To begin searching for printers, click File > Discover Printers.
C HANGING THE PASSWORD
Complete the following steps to change the password for updating printer settings:
1. In the “Network Card Setup” pane, click to select the printer.
2. From the main menu, select Printer > Change password. The “Change Password”
dialog is displayed.
3. Enter the new password as requested and click Save. The new password is saved
and the printer automatically restarts.
NOTE
If your printer stops at any time, you can restart it by selecting Printer >
Restart Printer in the “Network Card Setup pane”.
MC360
MC360

Mac OS X > 19
E NABLE / DISABLE THE PRINTER WEB PAGE
To enable/disable access to the Printer Web Page:
1. In the “Network Card Setup” pane, click to select the printer.
2. From the main menu, select Printer > Web Page Settings.
3. Select Enable or Disable and click Save.
4. Enter your password and click OK. The “Settings updated successfully” message is
displayed.
5. Click OK. The printer automatically restarts.
If you now try to view the Printer Web Page, an error message is displayed. If the Printer
Web Page is disabled, this error message gives you the option to enable it.
Q UITTING THE NETWORK CARD SETUP UTILITY
In the main menu, select File > Quit.
C ONFIGURING THE NETWORK INTERFACE CARD
You can configure the Network Interface Card, view your printer status and adjust printer
settings through the Printer Web Page. To access the web page, ensure that your printer
is connected to the network and type the printer IP address into a web browser.
Alternatively, you can access the Printer Web Page through the Network Card Setup utility
as follows:
1. In the “Network Card Setup” pane, click to select the printer.
2. From the main menu, select Printer > View Printer Web Page. The Printer Web
Page opens up in your default web browser.
3. On the Printer Web Page, click on Administrator Login.
4. Enter your username (‘root’) and password (last six digits of the Mac address, upper
case).
5. You can either enter the user details, click OK and select “Do not show this page
again” or click Skip.
6. Browse through the menu on the left. To configure the Network Interface Card
settings through the web browser, see “Using a web browser” on page 7.
