8x8 Garden in a Box with
Greenhouse Cover
Assembly Manual
Version #2.1
July 22, 2020
1-888-658-1658 www.outdoorlivingtoday.com [e-mail]
Page 1
In the event of a missing or broken piece, call the Outdoor Living Today Customer Support Line @ 1-888-658-1658 with-
in 30 days of the delivery of your purchase. It is our commitment to you to courier replacement parts, free of charge,
within 10 business days of this notification. Replacement parts will not be provided free of charge after the 30 day
grace period.
All structures purchased from Outdoor Living Today are covered for a period of one year for defects in manufacturing
and workmanship. Costs incurred for customer installations are not included.
Failure to use supplied parts included in this kit could result in poor product performance and may void your warranty.
Please contact Outdoor Living Today’s Customer Toll Free Line if you plan to deviate from our written instructions.
Thank you for purchasing a
8x8 Garden in a Box with Greenhouse
Cover. Please take the time to identify
all the parts prior to assembly.
In colder climates, please remove your Garden in a Box
Plastic Cover during the winter months and store in
included bag in a dry warm location.
Do not leave cover on during any large snow storms or
extreme weather phenomenon such as hurricanes,
tornadoes or heavy wind storms.
Cover can easily be taken off in minutes if such weather
patterns are forcast in your area.
We recommend once a year in the early spring to check
that all fasterners are snug and to tighten if loose.
Plastic cover can be cleaned with a mild soap and a cloth.
Customer agrees to hold Outdoor Living Today
and any Authorized Dealers free of any liability
for improper installation, maintenance and
repair.

Toll Free 1-888-658-1658 www.outdoorlivingtoday.com [e-mail]
Page 2
Thank you for purchasing our 8x8 Garden in a Box with Greenhouse Cover.
Please take the time to identify all the parts prior to assembly.
Part 1 x 10
Part 2 x 5
Part 3 x 10
Part 4 x 5
Part 5 x 5
Part 6 x 8
Part 7 x 2
Part 8 x 2
Part 9 x 3
Part 10 x 2
Part 11 x 3
Pliers
Phillips Screwdriver
Tools Required
(Not Provided)
Hardware
& Miscellaneous
Screw Gun/Drill
1 x BR1 - Square Drive Bit
20 x Y34 - Pipe Clamps
8 x M6x35
23 x M6x55
2 x M6x60
Storage Bag
44 x S2 - 1 1/4” Screws
18 x Velcro
Patches - Male
33 x Screw Caps
Greenhouse Cover
18 x Velcro
Patches - Female

Exploded View
Toll Free 1-888-658-1658 www.outdoorlivingtoday.com [e-mail]
Page 3
1
1
1
1
1
1
1
1
1
1 2
3
3
4
5
5
5 5
6
7
6
6
6
6
7
6
6
6
2
3
3
4
2
3
3
4
11
10
11
10
11
9
8
8
5
9
2
3
3
4 4
3
3
2
Front
9

1 x M6x55
1 x Part 9
1 x Part 111 x Part 4
Parts & Hardware
Step
1
Toll Free 1-888-658-1658 www.outdoorlivingtoday.com [e-mail]
Page 4
Tighten
until snug.
Part 9
Start with top
rear connection.
M6x55
Part 4
Part 11
Rear
Rear
1 x Screw Cap
Note: Attach Screw Caps as shown
below before installing. These will
prevent the Greenhouse Cover from
ripping on the screw heads.
Screw Caps not shown in Manual
diagrams.

2 x M6x35
1 x Part 5
Parts & Hardware
Step
2
Toll Free 1-888-658-1658 www.outdoorlivingtoday.com [e-mail]
Page 5
M6x35
M6x35
Part 5
Tighten
until snug.
Rear
Rear
2 x Screw Caps

1 x M6x55
1 x Part 8
1 x Part 101 x Part 3
Parts & Hardware
Step
3
Toll Free 1-888-658-1658 www.outdoorlivingtoday.com [e-mail]
Page 6
Part 10
M6x55
Part 3
Part 8
Rear
Rear
1 x Screw Cap

3 x M6x55
1 x Part 8 1 x Part 10
1 x Part 3
Parts & Hardware
Step
4
Toll Free 1-888-658-1658 www.outdoorlivingtoday.com [e-mail]
Page 7
1 x Part 2
2 x Part 9 2 x Part 11
2 x Part 5
4 x M6x35
M6x55
M6x35
M6x55
M6x35
M6x35
M6x55
M6x35
Front
Rear
Part 8
Part 5
Part 11
Part 3
Part 9
Part 2
Part 5
Part 9
Part 11
Part 10
7 x Screw Caps

4 x Part 6
1 x Part 4
Parts & Hardware
Step
5
Toll Free 1-888-658-1658 www.outdoorlivingtoday.com [e-mail]
Page 8
Rear
1 x Part 7
1 x Part 3
1 x Part 2 2 x Part 5
M6x35
M6x60
M6x55
M6x55
M6x55
M6x55
1 x M6x35 4 x M6x55 1 x M6x60
Part 6
Part 5
Part 2 Part 3 Part 3
Part 4
Part 6
Part 6
Part 6
Part 7
Start with rear
connection and
work towards front.
6 x Screw Caps

1 x M6x35
4 x Part 6
1 x Part 4
Parts & Hardware
Step
6
Toll Free 1-888-658-1658 www.outdoorlivingtoday.com [e-mail]
Page 9
1 x Part 7
1 x Part 3
1 x Part 2 2 x Part 5
4 x M6x55 1 x M6x60
M6x35
M6x60
M6x55
M6x55
M6x55
M6x55
Front
Front
Rear
Part 6
Part 5
Part 7
Part 2
Part 3
Part 3
Part 6
Part 6
Part 6
Part 4
Step 6 - Complete opposite
side as per Step 5.
6 x Screw Caps

Parts & Hardware
Step
7
Toll Free 1-888-658-1658 www.outdoorlivingtoday.com [e-mail]
Page 10
2 x Part 2
4 x M6x55
Front
M6x55
M6x55
M6x55
4 x Part 1
2 x Part 4
M6x55
Part 1
Part 2
Part 4
Part 1
Part 1
Part 4
Part 1
Part 2
Front
These connections will
be attached in Step 8.
4 x Screw
Caps

6 x M6x55
Parts & Hardware
Step
8
Toll Free 1-888-658-1658 www.outdoorlivingtoday.com [e-mail]
Page 11
M6x55
M6x55
M6x55
6 x Part 1
4 x Part 3
Part 3
Part 3
Part 1
Part 1
Part 1
M6x55
M6x55
M6x55
Front
Front
6 x Screw
Caps

Step
9
Toll Free 1-888-658-1658 www.outdoorlivingtoday.com [e-mail]
Page 12
Rear
Optional: Your Raised Garden Bed will have
an extra Part H - Bed Rib Frame (Rear). This
piece can be used as a support to turn your
Rear Trellis into a shelf.
Be careful not to load anything too heavy onto
this shelf if you choose to use the Rear Trellis
this way.
Attach shelf support with 3 - 2 1/2” Screws left
over from your Raised Bed kit.
Note: Pre-drill
pilot holes to
prevent splitting.

Parts & Hardware
Step
10
Toll Free 1-888-658-1658 www.outdoorlivingtoday.com [e-mail]
Page 13
20 x Y34 - Pipe Clamps
Attach clamps on
left and right side
of garden bed.
40 x S2 - 1 1/4” Screws
Note: Pre-drill
pilot holes to
prevent splitting.

Toll Free 1-888-658-1658 www.outdoorlivingtoday.com [e-mail]
Page 14
Step
11
Note: To fit the Greenhouse Cover
on the frame, you will need to
open the doorway of the cover.
*Greenhouse Cover is
not actually rigid.
Unzip inner flap
and reach through
to roll up roof vent.
You may need a
step ladder to reach
the roof vents.

Parts & Hardware
Step
12
Toll Free 1-888-658-1658 www.outdoorlivingtoday.com [e-mail]
Page 15
4 x Velcro Patches - Female
Attach Velcro patches with adhesive backing to exterior
of garden bed and interior of greenhouse cover.
One Female Velcro patch centered
under each side vent.
One Male Velcro patch centered
under each side vent.
Interior of Greenhouse Cover
4 x Velcro Patches - Male
Right Side of Unit

Parts & Hardware
Step
13
Toll Free 1-888-658-1658 www.outdoorlivingtoday.com [e-mail]
Page 16
14 x Velcro Patches - Female
Attach Velcro patches as per Step 12.
14 x Velcro Patches - Male
Rear of Unit
Attach Velcro patches as per Step 12.
Left Side of Unit
Attach Velcro patches as per Step 12.
Front of Unit

Congratulations on assembling your 8x8
Garden in a Box with Greenhouse Cover!
We value your feedback and
would like to hear back from you
on how well we are doing in the
following areas:
1. Customer Service
2. On Time Shipping
3. Motor Freight Delivery
4. Quality of Materials
5. Assembly Manual
6. Overall Satisfaction.
Toll Line: 1.888.658.1658 | Fax: [phone] | [e-mail]
The materials contained in this
Assembly Manual may be downloaded
or copied provided that ALL copies
retain the copyright and any other
proprietary notices contained on the
materials. No material may be
modified, edited or taken out of context
such that its use creates a false or
misleading statement or impression as
to the positions, statements or actions.
Canadian Address
9393 287th Street
Maple Ridge, British Columbia
Canada V2W 1L1
United States Address
P.O. Box 96
Sumas, Washington
USA 98295
Outdoor Living Today
Please call, write or email us at:
We hope your experience
assembling your 8x8 Garden
in a Box with Greenhouse
Cover has been both positive
and rewarding.
