olympia electronics BS-506/LITHIUM User manual

BS-506/LITHIUM
BATTERY OPERATED
SMOKE ALARM
Thank you for your trust in our products
Olympia Electronics - European manufacturer
921506001_09_007
4 5
European
manufacturers
Signaling Overview
1 Red per 344 sec None Device
functioning properly
1 Red per sec Alarm pattern Device under test
1 Red per sec Alarm Pattern Smoke detected
1 Red per 10 sec None 9 min
decreased sensitivity
3 Yellow per 43 sec None Exited an
alarm mode
None Replace batteries
None 3 short signals
per 43 sec
Replace the
smoke alarm
1 short signal
per 43 sec
ALARM
TEST
HUSH
ALARM MEMORY
LOW BATTERY
FAULT WARNING
NORMAL
5. Test the correct operation of your smoke alarm as described in Device Test
paragraph. If no sound is generated, the smoke alarm must be replaced
immediately!
3. Replace the old batteries by a new pair. Use recommended batteries for
more reliable operation.
2. Clean the device as described in maintenance paragraph.
1. Remove smoke alarm from mounting plate following Step 1 of the
installation instructions.
4. Place the smoke alarm on the Mounting plate and secure it by turning it
clockwise.
The WEEE symbol means that this product and batteries must be disposed
separately from other household waste. When they reach their end of
life, take them to a designated waste collection point in your area to
guarantee a safe disposal or recycling. Protect the environment, human
health and natural resources!
False alarm is often caused by dust or steam.
After a batteries replacement, the device performs an auto-adjusting process
in 8 hours period to establish its operation. If false alarm happens within this
period, it is important to clean the smoke alarm as described in maintenance
paragraph.
Battery Replacement
Recycling and Desposal
Troubleshooting
921506001_09_007
Visible indication
(flashes)
Operating Mode Acoustic Signal Comment
IP20 10 years
Battery
Life
Optical 85dB
EN14604
2008
BS-506/LITHIUM
10 years
Technical Characteristics
0.110 dB/m
Optical and Acoustic > 85dB (A) at 3 m
Yes
Yes
Yes
Ceiling
No
Optical
IP20
EN14604-2008
o
0 to 45 C
Up to 93%
ABS/PC, PC
Ø130 x 43 mm
185gr.
3 years (1 year for the battery)
SMOKE CONCENTRATION SENSITIVITY
INDICATORS
ALARM SILENCE FACILITY
LOW BATTERY WARNING
LOW BATTERY SILENCE FACILITY
MOUNTING LOCATION
INTERCONNECTABLE
DETECTION METHOD
PRODUCED IN ACCORDANCE WITH
OPERATION TEMPERATURE RANGE
DEGREES OF COVER PROTECTION
RELATIVE HUMIDITY
CONSTRUCTION MATERIAL
EXTERNAL DIMENSION
WEIGHT
GUARANTEE
POWER SUPPLY
BATTERY LIFE
Replaceable batteries: 2x AA Lithium FR6 (L91)
Olympia Electronics guarantees the quality, condition and operation of the
goods. The period of warranty is specified in the official catalogue of Olympia
Electronics and also in the technical leaflet, which accompanies each product.
This warranty ceases to exist if the buyer does not follow the technical
instructions included in official documents given by Olympia Electronics or if the
buyer modifies the goods provided or has any repairs or re-setting done by a third
party, unless Olympia Electronics has fully agreed to them in writing. Products
that have been damaged can be returned to the premises of our company for
repair or replacement, as long as the warranty period is valid.
Olympia Electronics reserves the right to repair or to replace the returned goods
and to or not charge the buyer depending on the reason of defection. Olympia
Electronics reserves the right to charge or not the buyer the transportation cost.
Warranty
72nd km. O.N.R. Thessaloniki-Katerini
P.C. 60300 P.O. Box 06 Εginio Pierias Greece
www.olympia-electronics.com
[e-mail]
BS-506/LITHIUM
Battery Operated
Smoke Alarm 1922
21
EN 14604:2008
DoP: 921506001_59_001
EGINIO
PIERIAS
60300
GREECE

B
C
A
ŸBatteries should be protected from excessive heat, such as direct light beams or
fire.
ŸDo not install the smoke alarm in direct sunlight. Keep at least 0.5m from light
sources.
ŸDue to the loudness of the alarm, make sure that you always stand at arm's
length distance from the unit when you are testing.
ŸDo not charge batteries
The BS-506 is a battery operated smoke alarm with an optical sensor for installation
in residential buildings, apartments and rooms. Smoke alarms are designed to
provide an early warning of fire events giving enough time for people to evacuate
the building/room. Always consult local regulations for smoke alarms.
CAUTION!!
ŸTo prevent injury, the device must be securely attached to the ceiling in
accordance with the installation instructions.
ŸDo not paint or cover the smoke alarm.
ŸConsult the manufacturer's advice if the device doesn't work properly.
ŸDo not install the smoke alarm close to ventilation points.
ŸDo not install the smoke alarm in leisure accommodation vehicles
ŸDo not mix new and used batteries or batteries of different types or brands
ŸExhausted batteries should be immediately removed from equipment and
properly disposed of
ŸDo not deform batteries
ŸA lithium battery with a damaged container should not be exposed to water
ŸReplace all batteries of a set at the same time.
ŸClean the battery contacts and also those of the equipment prior to battery
installation
ŸEnsure that the batteries are installed correctly with regard to polarity (+ and –)
ŸRemove exhausted batteries promptly
DEVICE TEST
A Device Test is performed when the TEST button is pressed for more than 1
second. If the device works properly it will produce a loud alarm sound. When the
TEST button is released, the alarm sound will stop and the device enters the Hush
mode. After a time of 9 minutes returns to normal (stand by) operation.
LOW BATTERY MODE
ŸDo not dismantle batteries
If the battery's level is low, the horn will sound as a short pulse every 43 seconds
which continues until the batteries are replaced. If a low battery condition exists, a
Low Battery Hush mode can be selected by pressing the TEST button, the Red LED
will turn on to indicate the low battery condition. After the TEST button is released,
the unit enters Low Battery Hush mode and the device is silenced for 8 hours. At
the end of the 8 hours, the audible indication will resume. The activation of the
TEST button will also initiate the 9 minutes Hush mode.
HUSH
When the device is in Alarm condition, every Device Test will initiate the Hush
mode. When Hush mode is started, the unit immediately resets out of Alarm
ŸStore unused batteries in their original packaging away from metal objects. If
already unpacked, do not mix or jumble batteries
FAULT WARNING
ALARM MEMORY
The Alarm Memory allows easy identification of any unit that had previously been in
Alarm. When a smoke alarm exits an Alarm condition, the Yellow LED flashes three
times and this pattern repeats every 43 seconds. This visual indication will stop after
a period of 24 hours. The user will still be able to identify a unit that had previously
been in Alarm, by pressing the TEST button, the horn will sound in short pulses and
the Alarm memory resets. The initial 24 hour visual indication is not displayed when
a low battery condition exists.
When the smoke alarm is not functioning properly, it will turn into the Fault warning
mode and produces three short acoustic signals every 43 seconds. Try cleaning the
smoke alarm (see paragraph maintenance) otherwise replace it!
condition and the horn is silenced. The Hush mode duration is 9 minutes and the
Red LED flashes faster, after this period expires, the unit goes back to its normal
operation. During Hush mode, the device's sensitivity is reduced and a higher Smoke
concentration is needed, to place the unit again into an Alarm condition. Also, Hush
mode can be canceled from the user by performing a new Device Test.
—Test the smoke alarm weekly for correct operation using the Device Test
facility. If the smoke alarm functions correctly, it will generate a loud beep
otherwise must be replaced immediately!
—Use a vacuum cleaner with a soft brush and vacuum all sides and covers of
the smoke alarm. Do not remove the top cover of the smoke alarm to clean
it inside.
—Clean the smoke alarm once per month to remove dirt, dust or debris.
—Do not attempt to repair this smoke alarm. If the smoke alarm shows a
damage it must be replaced!
—In accordance with EN14604 standard, is recommended to replace the
device after 10 years of operation.
1
2
1
1
Smoke alarm
AA Batteries (installed)
Mounting accessories
Manual
Package Contents
Maintenance
General
Installation instructions
1 2 3
1
5
6
2
3
4
6 mm
If no sound is generated, the smoke alarm is not functioning properly and
should not be used!
NOTE!!!
921506001_09_007 921506001_09_007 921506001_09_007
B
C
A
