Olympia PS-35CC User manual

PS-35CC
Automatic Paper Shredder
OPERATING INSTRUCTIONS
[ENGLISH]
03.2004

Important safety rules
Please read the instructions thoroughly before using the device to make sure that you
are able to use all of its functions.
Keep children and pets away from the device. The device may only be used by adults.
The device can only be used by one person at a time. Do not conduct any other activi-
ties on the device (e.g. cleaning) when it is in use.
Have any necessary repairs performed by qualified specialist personnel.
Protect the device against direct sunshine, extreme heat and moisture.
The following warning sign is attached to the bottom of the device.
Achtung
Gefahr eines elektrischen Schlages!
Gerät nicht öffnen!
Keinerlei vom Benutzer austauschbare Teile inseitig.
Gerät nur von geschultem Fachpersonal öffnen lassen.
Failure to observe this warning sign can lead to injuries.
Safety symbols
Do not reach into the infeed slot. Do not insert paper clips or
staples into the infeed slot.
Keep ties, scarves, loose cloth-
ing and long necklaces or
bracelets out of the area around
the infeed slot.
Keep long hair out of the area
around the infeed slot.
Caution: failure to observe these safety symbols can lead to serious injuries.
If an object (sleeve, tie, etc.) is inadvertently fed into the infeed slot, pull out the
mains plug immediately.
Electrical safety guidelines
- Pull out the mains plug before emptying the paper collecting basket, cleaning the
device or if the device is not going to be used for a long time.
- If the mains cable, mains plug or the device itself is damaged do not operate the
device any longer (danger of injuries).
- Do not overload the recommended capacity of the mains socket.
- Do not make any alterations to the mains cable as it has been designed for the spe-
cified mains voltage.
Operating elements
The sliding switch (OFF / ON/AUTO / REVERSE) on the device has the following
functions.
OFF position: the device is switched off.
ON/AUTO position: the device is ready for operation.
REV position: the cutting unit runs in reverse. To hold the rest of the paper back, you
can push the sliding switch in the REV position. The cutting unit runs backwards and
pushes the paper back.
The device also has a microswitch:
shredding starts as soon as paper in inserted in the infeed slot.
Materials suitable for destruction
Only use the PS-35CC paper shredder to shred paper. The paper must be dry and
must correspond to the specifications listed in the technical data. Shredding other
materials can lead to injuries (for example, if solid material splinters) or damage to the
device (destruction of the cutting unit, etc.).
Do not shred endless paper documents with this device. Remove all paper clips and
staples before feeding paper into the device.
Starting up
- Take the device carefully out of the packaging and place it on the paper collection
basket. The bulge in the paper collection basket must point to the front. The device
can only be operated when it has been put properly in place (contact switch).
- Plug the mains cable into the socket. Please observe the energy supply specificati-
ons on the back of the device in your safety measures.
- The socket and the mains connection of the device must be freely accessible for
safety reasons so that the power supply can be disconnected in emergencies.
Paper supply
- Switch the device on with the sliding switch (ON/AUTO position).
- Feed the paper to the cutting unit through the infeed slot.
- The device runs forwards and draws the paper in.
- The device switches off automatically after the shredding cycle. The motor carries on
running for another 2-3 seconds to remove the remaining paper from the cutting unit.
Caution: the sheet capacity given in the technical data may not be exceeded as oth-
erwise a paper jam will occur. Remember that the thickness of the paper increases
when it is folded and the recommended sheet capacity may be exceeded in this way.
Reduce the quantity of paper fed if it is coarse fibre paper.
it is recommended not to fill the paper collection basket up to the cutting unit. This
prevents cut material becoming jammed in the cutting unit.
Empty the paper collection basket at regular intervals.
Caution
Danger of electric shocks!
Do not open the device.
Device contains no user-serviceable parts.
Device should only be opened by trained
specialist personnel.

Remedying a paper jam
If too much paper is fed into the cutting unit, a paper jam occurs.
Proceed as follows:
- Push the sliding switch to the REV position.
- The cutting unit runs backwards and pushes the excess paper back.
- Reduce the paper quantity and slide the switch to ON/AUTO again. The cutting unit
runs forward again and the paper still in the cutting unit is shredded.
If the backwards and forwards movement does not remedy the paper jam, pull out the
mains plug and remove the remaining paper manually from the cutting unit.
Motor protection
The motor switches off automatically in the event of overloading. Pull out the mains
plug from the socket and allow the motor to cool down to room temperature. Plug the
mains cable back in and then continue operation.
Notes on care and maintenance
Caution: maintenance work may only be performed when the mains plug is pulled
out.
For you to be able to continue using your paper shredder for as long as possible, clear
residual paper from the cutting unit at regular intervals and apply special oil for paper
shredders to the cutting unit. This special oil is available from specialist dealers or di-
rectly from our service centre in Hattingen. This will extend the service life of the device.
Technical data
Model: PS-35CC
Power supply: 230V / 50Hz
Cutting width: 4 x 40 mm (cross-cut particles)
Cutting power: max. 3 DIN A4 sheets (70 g/m2)
Security level: 3
Max. power consumption: 0.8 A
Size (W x H x D): 302 x 312 x181 mm
Weight: 3288 g
Device malfunctions
Problem Cause Remedy
Is the mains cable plugged
properly in the socket?
Plug the mains cable into the
socket properly.
Is the sliding switch set to
ON/AUTO?
Set the sliding switch to ON/AUTO.
Does the motor not start
when paper is fed in?
Push the paper into the infeed slot
so that it touches the sensor in the
centre.
Device does not
work
Has the device been placed
the right way round and in
the correct position on the
paper collection basket?
Place the device on properly so
that the contact switch is activated.
Problem Cause Remedy
Device does not
work after lengthy
operation or
stops during
operation
Was the device in constant
operation for some time?
Is the surface of the device
warm?
Pull out the mains plug from the
socket and allow the motor to cool
down to room temperature.
Paper jam Have you inserted more
than 3 sheets of paper (70
g/m²)?
Has the paper not been
inserted straight in the in-
feed slot?
Set the sliding switch to REV to
push back the paper. Switch the
device to ON/AUTO again to shred
the paper remaining in the cutting
unit.
If you cannot rectify the fault yourself, contact your dealer or call the Olympia hotline.
Guarantee
ATTENTION!
INPORTANT GUARANTEE DOCUMENTS
PLEASE STORE IN A SAFE PLACE.
Dear Customer,
Thank you for buying a quality product from . In the unlikely event that
the device should develop a technical problem please observe the following
points:
¾The guarantee period for the device is 24 months.
¾Make sure that you store the purchasing receipt and the original packaging.
¾Should a problem occur, please call our hotline first:
+ 49 (0) 180/500 7514
(Fee for connections outside Germany: additional Euro 0.12
per call for the connection within Germany.)
Our personnel are often able to provide helpful advice over the phone.
¾If it is not possible to clear up the problem over the phone, please send the
device back to the following address:
Service-Center Hattingen
Weg zum Wasserwerk 10
45525 Hattingen, Germany
Guarantee repairs will only be performed if the purchase receipt is enclosed with
the device.
Thank you for your understanding.
Yours faithfully,
Your Olympia Business Systems partner
