Olympic HD3 User manual

Olympic Drives & Equipment Sales Ltd.
1
Olympic Azimuth Drive HD3 & SD1
360 Degree Marine Propulsion Drive
Table of Contents
1.0 MOUNTING THE OLYMPIC AZIMUTH DRIVE....................................................................2
2.0 INPUT SHAFT ..............................................................................................................................3
3.0 LUBE OIL SYSTEM:.....................................................................................................................3
4.0 STEERING HYDRAULICS FOR ENGINE DRIVEN PUMPS.................................................4
5.0 STEERING HYDRAULICS, POWER UNIT..............................................................................5
6.0 REMOTE STEERING CONTROL, MECHANICAL LINKAGE SYSTEM .............................6
7.0 REMOTE STEERING CONTROL, ELECTRICAL CONTROL SYSTEM..............................6
8.0 PROPELLER..................................................................................................................................6
The Olympic HD3 & SD1 allows for
positive propeller thrust in a full 360-degree
arc. The direction of rotation can be changed
quickly, and a full rotation can be achieved
in as fast as 3 seconds, allowing maximum
maneuverability of the vessel.
Specifically designed for rugged commercial
use, the Olympic HD3 & SD1is backed by a
limited warranty.

Olympic Drives & Equipment Sales Ltd.
2
INSTALLATION INSTRUCTIONS:
1.0MOUNTING THE OLYMPIC AZIMUTH DRIVE
1.1 Check strength of the hull where the Olympic Drive is to be mounted. Careful
consideration must be given to thrust force that will be applied in all directions to
hull bottom. Some form of reinforcing must be built into the hull around the
“Olympic” mounting ring to spread thrust force and reduce any “oil can”
movement in bottom plate. Reinforcing, of course, will depend on design of
vessel but has in the past taken the form of extra structural stiffeners and frames
built in around drive ring or extra heavy bottom plates installed between frames
where mounting ring is positioned
1.2 Locate exact position of mounting ring in hull. First, bolt mounting ring to the
Olympic flange (leave out neoprene gasket) and lower the whole assembly into
the hull. Position the Olympic Drive assembly so the drive input shaft is: (1)
parallel with engine PTO output shaft and (2) centered slightly offset from engine
PTO output shaft. The best offset dimension range will give a universal drive
shaft angle of 3 degree or less (a slight angle is required to allow the universal
roller bearings to roll and self lubricate). The drive shaft will efficiently work with
an angle up to 5 degrees, but its life span will be reduced.
Tack weld ring in position, unbolt and remove the Olympic Drive and complete
welding of the ring to the hull using good welding practice to ensure the ring does
not warp.
Note: refer to attached drawing (B-0440) on the drive shaft alignment
1.3 Fit neoprene seal (supplied with the “Olympic Drive”) to drive mounting flange
using a good grade of bedding compound.
1.4 Carefully lower the Olympic Drive into mounting ring so that bolt holes line up
and input drive shaft lines up with the center line of engine crank shaft.
1.5 Bolt the Olympic Drive to mounting ring using ½” x 1 ½” N.C. grade 8 cap screws
with flat and lock washers. Tighten them evenly to prevent distortion to drive
flange to a torque of 80 to 85 ft. lbs.

Olympic Drives & Equipment Sales Ltd.
3
2.0INPUT SHAFT
2.1 Input shaft must only rotate clockwise (when views towards the input coupling
side of the drive); driving shaft or flywheel must rotate counterclockwise (when
viewed towards driving shaft).
2.2 Install a Splicer series 1480 drive shaft (not supplied with the drive) between
drive coupling and engine clutch. The Olympic Drive input coupling is equipped
with a standard S.A.E. flange. This drive line must be equipped with a slip joint
which should be located at engine end of shaft. It is important that the universal
drive shaft angle not exceed 5 degrees and that both PTO and Olympic Drive
shafts be parallel to one another.
Note 1: Refer to attached drawing (B-0440) on drive shaft alignment.
Note 2: Your local universal joint specialist will be able to give you advice
in selecting the right series 1480 Spicer universal joints, drive
tube and slip joint, to adapt the Olympic Drive to your engine
clutch output shaft. The shaft assembly number most common
used on the west coast is No. 908048 (length number). Your
universal joint specialist will also be able to dynamically balance
shaft assembly before you install it.
3.0Lube Oil System:
3.1 Install an 4 liter or larger lube oil reservoir tank (not supplied with the drive) in an
easily accessible location above the Olympic Drive so that working oil level in the
tank will provide 1-2 P.S.I more oil pressure at the propeller shaft seal relative to
outside water pressure. For example, if your propeller shaft is 4 feet below the
water line your reservoir oil level should be 3 to 5 feet above the water line.
Note 1: Refer to attached piping drawing.
Note 2: A low oil level alarm (not supplied with drive) is highly
recommended. It can be easily tied in with your engine alarm
system.
3.2 Plumb in lube oil reservoir tank using #12 single wire braid hose for vent line
connecting ¾” port on top of drive to the top of reservoir tank and #12 single wire
braid hose for oil line connecting the ¾” port on top of drive to bottom of the

Olympic Drives & Equipment Sales Ltd.
4
reservoir tank. These two hoses should be installed with an even slope upwards
to the reservoir thank so that air trapped in system can easily pass up to tank.
Note 1: Refer to attached piping drawing
3.3 Mount a standard 0-200 P.S.I. lube oil pressure gauge (not supplied with drive)
in wheelhouse control console and connect it to ¼” ‘T’ fitting on left side (when
facing the input coupling) of drive.
Note 1: Refer to attached piping drawing
3.4 Fill drive and reservoir tank with S.A.E. 80-90 w gear oil or synthetic 50 w gear
oil. System capacity is 25 liters for Olympic Drive plus extra for reservoir tank and
connecting hoses.
Note: It is extremely important when running drive for first time, after
filling system with new lube oil, to continuously check oil level in
reservoir tank and top it up until all trapped air has been circulated
out of system. Lube oil pressure should be 140-180 P.S.I. when
cold and 10-20 P.S.I. when hot with the engine running at 1800
RPM.
4.0Steering Hydraulics for Engine Driven Pumps
4.1 Mount Vickers hydraulic pump on engine auxiliary drive.
4.2 Install hydraulic steering oil reservoir tank and oil filter in an easily accessible
location. Max operating Steering Oil temp 160° F (71° C).
Note: The oil filter is directional and must be mounted the right way.
4.3 Fabricate a suitable oil cooler to be installed in hydraulic steering oil return line,
between drive and oil filter. Whether this oil cooler is built outside the hull using
steel channels or pipes or inside hull using hull plate as a heat exchanger it must
have a minimum of 150 sq. inches of surface area (Canada & Northern USA)
directly exposed to sea water. In warmer water conditions add additional
channel lengths to maintain an oil temp below 160° F (71° C).
Note: Refer to attached piping drawing (B-0318A)

Olympic Drives & Equipment Sales Ltd.
5
4.5 Plumb in steering hydraulic system using a good grade of pipe tube suitable for a
1750 PSI system. Ensure system is well flushed and clean before filling with
hydraulic oil.
Note: Refer to attached piping drawing (B-0318A)
4.6 Fill steering system with ISO 32 Hydraulic oil
4.7 When running system for the first time after filling with new oil, check the
reservoir tank oil level and top it up until all air has been bled out of system.
Note: The hydraulic pressure relief settings of the Vickers hydraulic
pumps supplied by Olympic Drives are as follows:
HD3 Olympic Drive (V20F pump) …….1750 PSI
SD1 & UD2 Drives (V10F pump) …….1200 PSI
5.0Steering Hydraulics, Power Unit
5.1 Mount hydraulic power unit in an easily accessible protected location near the
Olympic Drive. Ensure there is adequate air circulation for cooling of the oil
reservoir. Max operating Steering Oil temp 160° F (71° C).
5.2 Plumb in steering hydraulic system using a good grade of pipe tube suitable for a
2500 PSI system. Ensure system is well flushed and clean before filling with
hydraulic oil.
Note: Refer to attached hydraulic schematic
5.4 Fill steering system with ISO 32 Hydraulic oil.
5.5 Mount the motor starter panel near the power unit. Connect the motor starter to
the power unit following the attached motor starter instructions (A308614-01).
5.6 Connect temperature and low-level alarm to motor starter and alarm system.
5.6 When running system for the first time after filling with new oil, check the
reservoir tank oil level and top it up until all air has been bled out of system.
Note:

Olympic Drives & Equipment Sales Ltd.
6
The hydraulic pressure relief settings of the Power Unit supplied
by Olympic Drives is 1600 PSI unless otherwise stated.
6.0Remote Steering Control, Mechanical Linkage System
6.1 Mechanical remote control (only). Connect remote mechanical steering system
(not supplied with drive) to steering stub shaft on top of drive, (or gear box if
supplied). This stub shaft, which controls the built in hydraulic steering system,
requires very little force to turn; about the same as an automobile power steering
wheel. For every 360 degree turn of steering stub shaft the lower drive housing
will also rotate 360 degrees. Maximum rate of steering speed is approximately
one turn in 3 seconds using the Vickers pumps mentioned in 4.7.
7.0 Remote Steering Control, Electrical Control System
7.1 See PMC Steering Control Manual if applicable.
8.0Propeller
8.1 The propeller must have four blades and be right hand (RH) rotation
8.2 Propeller hub must be machined to fit inside rope cutter guard that protects
propeller shaft seal. Propeller suppliers in the Pacific North West and BC
Canada, where there is a large population of Olympic Drives, are familiar with
this machine hub.
8.3 Fit propeller using standard marine practice. Ensure that it is not riding the key
during installation and remember it is good practice to use ‘never seize’ on
threads before fitting nut.
8.4 When removing propeller always use a wheel puller with a little heat applied to
hub if it resists.

Olympic Drives & Equipment Sales Ltd.
7
HD3_Mounting_Dimensions_D-0071A_Model

Olympic Drives & Equipment Sales Ltd.
8
Olympic_Mounting_Ring_B-0441_Layout

Olympic Drives & Equipment Sales Ltd.
9
Olympic Drive Installation Drawing B-0440

Olympic Drives & Equipment Sales Ltd.
10
HD3 Piping Drawing

Olympic Drives & Equipment Sales Ltd.
11
SD1 Piping Drawing

Olympic Drives & Equipment Sales Ltd.
12
HD3 Mounting Dimensions

Olympic Drives & Equipment Sales Ltd.
13
Maintenance Schedule
Daily Operations:
1. Check Z-Drive oil level (Header Tank).
2. Monitor lubrication oil pressure gauge.
Every Month or 200 Hours:
1. Inspect power steering motor for wear or leakage.
2. Inspect all hydraulic lines and fittings; tighten or replace as required.
Every Six Months or 1000 Hours: (whichever comes first)
3. Monthly inspection plus below;
4. Drain and replace lube oil and filter (if applicable). Maintain oil level 3 inches (7.6 cm)
from the top of the tank.
5. Inspect zinc anodes and replace as required.
Every 5 years or 6000 Hours: (whichever comes first)
1. Overhaul the Z-Drive replacing all bearings and seals.
2. Inspect all components for wear and replace as required.
3. Flush lube and steering oil systems.
The oil changes are dependent on the type of oil used, so check with the oil for recommendation.
