Omcan MS-IT-0300-A User manual

Revised - 10/05/2021
Toll Free: 1-800-465-0234
Fax: [phone]
Email: [email protected]
www.omcan.com
Belt-Driven Slicer
Model MS-IT-0300-A
Item 13654
Instruction Manual

2
Page
--------------------------------------------------------------------------- 3 - 4
--------------------------------------------------------------------------- 4 - 5
-------------------------------------------------------------------------- 6
--------------------------------------------------------------------------------------- 6 - 7
----------------------------------------------------------------------------------------- 7 - 8
----------------------------------------------------------------------------------- 8 - 11
----------------------------------------------------------------------------------- 11
---------------------------------------------------------------------------- 12 - 22
---------------------------------------------------------------------------- 23
------------------------------------------------------------------------------------------- 24 - 26
---------------------------------------------------------------------------- 27
Table of Contents
Section
General Information
Safety and Warranty
Technical Specications
Installation
Operation
Maintenance
Troubleshooting
Parts Breakdown
Electrical Schematics
Notes
Warranty Registration
Model MS-IT-0300-A

3
General Information
Omcan Manufacturing and Distributing Company Inc., Food Machinery of America, Inc. dba Omcan
and Omcan Inc. are not responsible for any harm or injury caused due to any person’s improper or
negligent use of this equipment. The product shall only be operated by someone over the age of 18, of
sound mind, and not under the inuence of any drugs or alcohol, who has been trained in the correct
operation of this machine, and is wearing authorized, proper safety clothing. Any modication to the
machine voids any warranty, and may cause harm to individuals using the machine or in the vicinity of
the machine while in operation.
CHECK PACKAGE UPON ARRIVAL
Upon receipt of an Omcan shipment please inspect for external damage. If no damage is evident on the
external packaging, open carton to ensure all ordered items are within the box, and there is no concealed
damage to the machine. If the package has suffered rough handling, bumps or damage (visible or concealed),
please note it on the bill of lading before accepting the delivery and contact Omcan within 24 hours, so we may
initiate a claim with the carrier. A detailed report on the extent of the damage caused to the machine must be
lled out within three days, from the delivery date shown in the shipping documents. Omcan has no recourse
for damaged products that were shipped collect or third party.
Before operating any equipment, always read and familiarize yourself with all operation and safety
instructions.
Omcan would like to thank you for purchasing this machine. It’s of the utmost importance to save
these instructions for future reference. Also save the original box and packaging for shipping the
equipment if servicing or returning of the machine is required.
---------------------------------------------------------------------------------------------------------------------------------------------------
Omcan Fabrication et distribution Companie Limité et Food Machinery d’Amerique, dba Omcan et
Omcan Inc. ne sont pas responsables de tout dommage ou blessure causé du fait que toute personne
ait utilisé cet équipement de façon irrégulière. Le produit ne doit être exploité que par quelqu’un de
plus de 18 ans, saine d’esprit, et pas sous l’inuence d’une drogue ou d’acohol, qui a été formé pour
utiliser cette machine correctement, et est vêtu de vêtements de sécurité approprié. Toute modication
de la machine annule toute garantie, et peut causer un préjudice à des personnes utilisant la machine
ou des personnes à proximité de la machine pendant son fonctionnement.
VÉRIFIEZ LE COLIS DÈS RÉCEPTION
Dès réception d’une expédition d’Omcan veuillez inspecter pour dommages externes. Si aucun dommage
n’est visible sur l’emballage externe, ouvrez le carton an de s’assurer que tous les éléments commandés
sont dans la boîte, et il n’y a aucun dommage dissimulé à la machine. Si le colis n’a subi aucune mauvaises
manipulations, de bosses ou de dommages (visible ou cachée), notez-le sur le bond de livraison avant
d’accepter la livraison et contactez Omcan dans les 24 heures qui suivent, pour que nous puissions engager
une réclamation auprès du transporteur. Un rapport détaillé sur l’étendue des dommages causés à la machine
doit être rempli dans un délai de trois jours, à compter de la date de livraison indiquée dans les documents
d’expédition. Omcan n’a aucun droit de recours pour les produits endommagés qui ont été expédiées ou cueilli
par un tiers transporteur.

4
General Information
Safety and Warranty
MECHANICAL SAFETY DEVICES
The slicer is manufactured according to the EEC 2006/42 Machinery Directive.
The mechanical safety devices are the following:
• Product holder removable only with the slice thickness control on zero (slice thickness plate positioned to
protect the blade). After removing the product holder the slice thickness plate is mechanically clamped.
Avant d’utiliser n’importe quel équipement, toujours lire et vous familiariser avec toutes les opérations
et les consignes de sécurité.
Omcan voudrais vous remercier d’avoir choisi cette machine. Il est primordial de conserver ces
instructions pour une référence ultérieure. Également conservez la boîte originale et l’emballage pour
l’expédition de l’équipement si l’entretien ou le retour de la machine est nécessaire.
---------------------------------------------------------------------------------------------------------------------------------------------------
Omcan Empresa De Fabricacion Y Distribucion Inc. Y Maquinaria De Alimentos De America, Inc. dba
Omcan y Omcan Inc. no son responsables de ningun daño o perjuicío causado por cualquier persona
inadecuada o el uso descuidado de este equipo. El producto solo podra ser operado por una persona
mayor de 18 años, en su sano juicio y no bajo alguna inuencia de droga o alcohol, y que este ha sido
entrenado en el correcto funcionamiento de esta máquina, y ésta usando ropa apropiada y autorizada.
Cualquier modicación a la máquina anúla la garantía y puede causar daños a las personas usando la
máquina mientras esta en el funcionamiento.
REVISE EL PAQUETE A SU LLEGADA
Tras la recepcion de un envio Omcan favor inspeccionar daños externos. Si no hay daños evidentes en el
empaque exterior, Habra el carton para asegurararse que todos los articulos solicitados ésten dentro de la
caja y no encuentre daños ocultos en la máquina. Si el paquete ha sufrido un manejo de poco cuidado, golpes
o daños (visible o oculto) por favor anote en la factura antes de aceptar la entrega y contacte Omcan dentro
de las 24 horas, de modo que podamos iniciar una reclamación con la compañia. Un informe detallado sobre
los daños causados a la máquina debe ser llenado en el plazo de tres días, desde la fecha de entrega que se
muestra en los documentos de envío. Omcan no tiene ningun recurso por productos dañados que se enviaron
a recoger por terceros.
Antes de utilizar cualquier equipo, siempre leer y familiarizarse con todas las instrucciones de
operación y seguridad.
Omcan quisiera darles las gracias por la compra de esta máquina. Es de la máxima importancia para
guardar estas instrucciones para referencias en el futuro. También guarde la caja original y el embalaje
para envío del equipo si el mantenimiento o la devolución de la máquina es necesaria.

5
Safety and Warranty
• Protection devices mounted on the product holder to prevent the operator from any accidental contact with
the blade.
• Blade guard. This xed ring protects that part of the blade which is not used for the cutting operation.
• A special mechanical safety device to sharpen the blade keeping the ngers of the operator away from the
cutting edge of the blade.
ELECTRICAL SAFETY DEVICES
The electrical safety devices in accordance with the EN 60204 standards are the following:
• Start and stop push buttons.
• Control circuit provided with electric servo-control; in any case of blade clamping the machine must be
restarted manually.
• Safety device to stop the rotation of the blade if the clamping handle of the blade guard is released.
WARNING
When the machine is not used:
• Make sure that it is off.
• Re-position the slice thickness control to zero.
Do not remove the labels placed on the machine and replace them if damaged.
RESIDENTIAL USERS: Vendor assumes no liability for parts or labor coverage for component failure
or other damages resulting from installation in non-commercial or residential applications. The right
is reserved to deny shipment for residential usage; if this occurs, you will be notied as soon as
possible.
1 YEAR PARTS AND LABOUR WARRANTY
Within the warranty period, contact Omcan Inc. at 1-800-465-0234 to schedule an Omcan authorized
service technician to repair the equipment locally.
Unauthorized maintenance will void the warranty. Warranty covers electrical and part failures, not
improper use.
Please see https://omcan.com/disclaimer for complete info.
WARNING:
The packaging components are classied as normal solid urban waste and can therefore be disposed of
without difculty.
In any case, for suitable recycling, we suggest disposing of the products separately (differentiated
waste) according to the current norms.
DO NOT DISCARD ANY PACKAGING MATERIALS IN THE ENVIRONMENT!

6
Technical Specications
Installation
The slicer must be mounted horizontally on a stable, robust and antiskid base adequate to support its weight.
The suggested height of the working table is of about 800mm. It must be checked that the product holder is not
clamped and the product to be cut can be easily loaded.
WARNING: To prevent the risk of crushing hazard, locate the machine in a manner that allows a clear space
between the moving table and any permanent structure.
PRELIMINARY CLEANING
Before connecting the plug clean off the protective oil from the machine.
WARNING
The working table must always be cleaned.
ELECTRICAL SUPPLY
The machine must be installed in the proximity of a mains socket. Check that the power supply voltage
corresponds to that described on the information label and that it is connected to an adequate earth.
1. Connect the plug.
2. Check that the blade cover fastener handle is tight screwed.
3. Check that the blade sharpener is lowered and the protective cover is closed.
Model MS-IT-0300-A
Blade Size 12” / 300mm
Power 0.5 HP / 0.37kW (x2)
Cheese Slicing*
Slicing Volume* 8 hours or more
RPM 200
Cutting Size 8.9” x 8.7” / 225 x 220mm
Cut Thickness 0” - 0.6” / 0 - 14mm
Electrical 120V / 60Hz / 1
Weight 90.2 lbs. / 41 kgs.
Packaging Weight 103.4 lbs. / 47 kgs.
Dimensions 25.2” x 21.7” x 20.9” / 640 x 550 x 530mm
Packaging Dimensions 28.3” x 25.6” x 30.1” / 720 x 650 x 765mm
Item Number 13654
*Results may vary due to product consistency and temperature

7
Installation
MANUAL FUNCTIONING
1. Press push button blade start.
AUTOMATIC FUNCTIONING
1. See manual functioning.
2. Press push button carriage start.
SLICER FUNCTIONING AND USE
The following products can be sliced: sausages, ham, cheese, bread. If large quantities of bread or cheese are
usually cut it is advisable to mount a teon coating.
WARNING
The following cannot be sliced:
• Not-eatable products.
• Foodstuffs with bones.
• Frozen products.
AUTOMATIC FUNCTIONING
Rotate the carriage release handle in a counterclockwise direction by 180°. With the automatic functioning it
is possible to change the cut stroke length to adapt it to the dimensions of the product to be cut. Rotate the
product holder stroke adjustment knob respectively in a clockwise or counterclockwise direction to lengthen
or shorten the product holder stroke. Irrespective of the selected stroke, the product holder always stops
in product load position (operator’s side) by pressing the product holder stop push button. The machine is
supplied with two self-contained motors: one for the blade and another for the product holder to better adjust its
stroke. By separating the two functions a more precise cut can be obtained.
MANUAL FUNCTIONING
Rotate the product holder release handle in a clockwise direction by 180°.
Operation
HOW TO LOAD THE PRODUCT TO BE CUT
1. Check that the slicer is off and position the slice thickness control to zero.
2. Push the product holder towards the operator.
3. Lift and rotate the product pusher: the pusher can fall back, this is normal.
4. Place the product to be cut against the wall of the product holder and the slice thickness plate.
5. Position the product pusher on the product to be cut far from the slice thickness plate. The product is fed to
the slice thickness plate by gravity making the cut easier.
6. Rotate the slice thickness control to the thickness desired.

8
Operation
Maintenance
AUTOMATIC FUNCTIONING
1. Rotate the carriage release handle in a counterclockwise direction by 180°.
2. Press push button start blade.
3. Press push button start the product holder.
4. To select the most suitable carriage stroke according to the dimensions of the product to be cut, rotate the
carriage stroke adjustment knob respectively in a clockwise or counterclockwise direction to lengthen or
shorten the stroke.
DANGER
Do not touch the carriage or the product holder when the machine is working.
After completing the cutting operation, press push button stop the product holder. The blade remains in
operation whereas the product holder is fed to the stroke end where it stops towards the operator ready to start
a new cutting cycle.
By pressing push button stop the blade, the product holder stops in its working position.
MANUAL FUNCTIONING
1. Rotate the carriage release handle in a clockwise direction by 180°.
2. Press push button to start the blade.
3. With constant speed, according to the product to be sliced features, you can push the product holder tray
to its end stroke in blade direction. You can then return in the operator position and repeat this operation.
After cutting the product, reposition the product holder towards the operator. By pressing push button stop
blade the rotation of the blade stops. Re-position the slice thickness control to zero and unload the product.
BLADE SHARPENING
Whenever the cut is not satisfactory, sharpen the blade. The time interval between a sharpening and the
following depends on the intensity of use of the slicer and on the kind of food you cut. Replace the blade when
the diameter becomes 10mm less than the nominal diameter. For the replacement, ask the assistant service
closest to you.
WARNING
The replacement of the blade is dangerous operation. Should the sharpening quality be not
satisfactory, replace the stones by contacting Omcan.

9
Maintenance
SHARPENING OPERATION
DANGER
The sharpening operation must be performed during the manual functioning.
For a correct sharpening of the blade follow these instructions:
1. Clean the blade removing any greasy residue.
2. Make sure that the machine is off.
3. Rotate the slice thickness control to zero to make sure that the blade is covered by the slice thickness
plate.
IMPORTANT
During the following operations the blade must always be covered by the removable protection.
4. Lift the sharpener cover.
5. Slip off completely the sharpener and spin it 180 degrees.
6. Replace the sharpener device.
7. Push the push button blade start to start the machine.
8. Sharpening: Press the sharpening wheel for about 10-15 seconds.
Then press simultaneously also the grinding stone for two seconds.
Contemporaneously loosen the two grind stones.
The sharpening and honing take place then simultaneously.
ATTENTION: for a suitable effect please execute sharpening for 10-15 seconds approx.
9. After sharpening press the blade stop push button.
10. Lift and rotate 180 degrees the sharpener and reallocate it into its initial position. Loosen the handle
rotating it clockwise to block the sharpener. Lower the sharpener cover.
CLEANING OF THE GRINDING WHEELS
To obtain an excellent sharpening the grinding wheel must always be clean. Remove dirt and grease with
alcohol and the supplied special brush. Be sure to clean and sanitize the blade after sharpening.
MAINTENANCE
All cleaning and maintenance operations must only be carried out with the machine disconnected and isolated
from the mains supply and the slice thickness control on zero.
CONTROL OF THE AIR GRATING
An air grating for the motors ventilation is placed in the lower side of the machine. Keep the section-holes free
and clean them with a brush at regular intervals.

10
Maintenance
CHECK OF THE ELECTRIC CABLE
It is recommended to check the wear of the electric cable at regular intervals.
SPARE PARTS
In the event that replacement parts need to be tted, request only original spare parts.
CLEANING
The machine must be cleaned once a day or more frequently if necessary. Clean all the parts using a cloth
sprinkled with water and washing up liquid (do not use strong detergents) and a brush.
WARNING
Do not use water jet
DANGER
During the cleaning operations take great care: danger of accident.
COMPONENTS REMOVAL
PRODUCT HOLDER
1. Loose the product holder by rotating the product holder clamping handle in a counterclockwise direction.
2. Position to zero the slice thickness control to remove the product holder.
3. Push the product holder towards the operator until it clicks. The click will inform the operator that the
product holder is clamped.
4. Lift the last slice device from the guide bar.
5. Lift the product holder from the carriage.
IMPORTANT
The slice thickness control is clamped on zero.
BLADE COVER
1. Rotate the slice deector and keep it away from the blade.
2. Loose the blade cover fastener handle by rotating it in a counterclockwise direction.
3. Push on the handle in the direction indicated by the arrow to lift the blade cover from the blade.
4. Lift the blade cover.
ATTENTION
Once removed the blade cover, an interlocking device stops the rotation of the blade.
DANGER
During the cleaning operations of the blade, pay attention to an accidental contact with it.
5. Press a damp cloth on the front side of the blade and move slowly from the center towards the edge in the

11
Maintenance
Troubleshooting
direction of the arrow.
6. Follow these instructions to clean the back side of the blade.
7. With a cloth dry both sides of the blade following this procedure.
8. Insert a damp cloth between the blade and the protection ring. Pull it outwards and rotate it to clean the
internal side of the protection ring.
9. After cleaning re-position the blade cover, insert the fastener and screw in a clockwise direction to clamp
the blade cover. Lower the sharpener protective cover.
IMPORTANT
Leave all the parts to soak in warm water and washing-up liquid (do not use strong detergents) and clean them
by using a brush or a cloth. Rinse them in warm water and dry them.
To assemble the machine follow the reverse procedure as described for disassembly.
GUIDES LUBRICATION
This operation must be performed after cleaning the slicer or whenever the sliding is difcult. Use food safe oil
only.
LUBRICATION OF THE GUIDE BAR OF THE LAST SLICE DEVICE
1. Drop a small amount of food grade oil on the bar.
2. Let the last slice device slide on the guide bar.
LUBRICATION OF THE GUIDE BAR OF THE PRODUCT HOLDER CARRIAGE
1. Push the product holder towards the operator.
2. Pour the food grade lubricating oil into the special carriage bar lubricator.
3. Push the product holder to and from and repeat the operation. Re-position it towards the operator.
PROBLEM CORRECTIVE ACTION
The machine vibrates, overheats
and emits a foul smell.
Stop it immediately and check that the voltage corresponds to that de-
scribed on the rating label.
The blade cannot be sharpened
any longer. The sharpening is no
regular.
Clean the grinding wheels of the sharpener and check the wear of the
blade.
On pushing the start push button
the machine does not start.
Check if power missing. Check the safety devices.
The carriage and the last slice
device run with difculty.
Lubricate the guide bars.

12
Parts Breakdown
Model MS-IT-0300-A 13654

13
Parts Breakdown
Model MS-IT-0300-A 13654

14
Parts Breakdown
Model MS-IT-0300-A 13654

15
Parts Breakdown
Model MS-IT-0300-A 13654

16
Parts Breakdown
Model MS-IT-0300-A 13654

17
Parts Breakdown
Model MS-IT-0300-A 13654

18
Parts Breakdown
Model MS-IT-0300-A 13654

19
Parts Breakdown
Model MS-IT-0300-A 13654

20
Parts Breakdown
Item No. Description Position Item No. Description Position Item No. Description Position
36533 Sharpener - Assy for 13654 A1027 19633 Hinge Motor for 13654 C3633 36663 Locknut Pacer for 13654 D577016
60813 Wheel Shaft (CE) Assy for 13654 A3103 17316 Pin 8.5mm for 13654 C4601 36666 Spacer Eccentrico for 13654 D5771
17279 Ring EL.Benzing 5 for 13654 A5403 17317 Pin.11 for 13654 C4602 36667 Spacer Ant.Anello Paralama for 13654 D5772
17280 Ring EL Benzing 5 for 13654 A5404 36601 Rivet 1.9x5 for 13654 C4640 36670 Sharpener Support Spacer for 13654 D5777
36536 Ring EL.Benzing 6 Stainless Steel for
13654 A5404X 36602 Driving Belt 330x10 for 13654 C4813 36671 Unhook Spring Spacer for 13654 D5806
19606 Ring 17 for 13654 A5446 36603 V Belt for 13654 C4814 36672 Spacer of Carriage Springs for 13654 D5819
36541 Ring EL.Seeger INT.35 for 13654 A5470 17320 Bolt for 13654 C5001 36674 Spacer Basamento for 13654 D5851
60767 Ring EL.Seeger INT.32 for 13654 A5472 36608 Capacitor 8 MF 400V for 13654 C5806A 36675 Cam Carriage for 13654 E1409A
19174 Ring for 13654 A5475 16913 Capacitor 14 MF 400V for 13654 C5812 17342 Cam 15mm for 13654 E1420
17289 Pulley Ring for 13654 A5905 60771 Motor Front Plate for 13654 C6444 17344 Cam Motor for 13654 E1457
36543 Pulley Cover Ring for 13654 A5910 60766 Motor Cover 510-85 for 13654 C6452 36678 Excentric Supp. Knife Ring Prot. for
13654 E1465
60814 Ring for Sharpener Handle for 13654 A5914 19530 Safety Guard for 13654 C6537 60763 Carriage Felt for 13654 F1610
36551 Shock Absorber Rod for 13654 B1270 36619 Belt Cover for 13654 C6583 36684 Clasp for Carriage 18x30x8 for 13654 F3019
36553 Rod.Carriage for 13654 B1317 60772 Side Plate for 13654 C6778 17349 Handle Flange for 13654 F6090
17294 Rod for 13654 B1330A 36625 Cover Lato Carriage for 13654 C6784 36689 Stainless Steel Locknut M8 for 13654 G5027
19506 Carriage Rod for 13654 B1360 17329 Pusher Cover Red (Rubber) for 13654 C6792 36691 Ring for Bushing for 13654 G5053
60760 Base for 13654 B1861 17330 Pusher Cover Green (Rubber) for 13654 C679201 36692 Ring for Cam for 13654 G5054
60773 Belt Housing for 13654 B1870 60823 Sharpening Assembly Base for 13654 C6845 36695 Ring Support Cap for 13654 G5055
36555 Belt Bracket for 13654 B5032 36629 Bearing 2Z-6003 17x35x10 for 13654 C8006 36696 Blade Guard Nut for 13654 G5058
19510 Hangover Bracket for 13654 B5033 16920 Bear.2Z-6203 17x40x12 for 13654 C8007 AI232 P.C.Board for 13654 I166309
60807 Sharpener Lever Hub for 13654 B5091 19540 Bearing 12x32x10 for 13654 C8015 17356 Fastener Handle for 13654 I1926
19618 Bushing 8x10x8 for 13654 B6009 17335 Bear.2RS-6203 17x40x12 for 13654 C8022 17357 Deector Screw for 13654 I1942
17303 Bushing DU 12x14x15 for 13654 B6052 36630 Bearing 5x16x6.5 for 13654 C8035 36705 Adjustment Knob for 13654 I1970A
17305 Bushing DU 18x20x15 for 13654 B6057 16926 Bearing 2RS-6000 (10x26x8) for 13654 C8067 36708 Assy Index Knob for 13654 I1990A
19630 Bushing Fastener for 13654 B6104B 19638 Nut M4 for 13654 D0102 18220 Knob Handling for 13654 I203576
36558 Ext.Bushing for 13654 B6144 16928 Nut U5589 M6 for 13654 D0133 17363 End Grip Handle for 13654 I2040
19631 Bushing for 13654 B6155 36636 Nut U5589 M6 Stainless Steel for 13654 D0133X 60828 Sharpener Body Handle for 13654 I2049
36561 Fastener Nut 18x62 for 13654 B617701 19639 Nut M8 for 13654 D0135 36713 Handle for Carriage for 13654 I2055
60762 Carriage Screw for 13654 B6185 36637 Nut U5589 M8 Stainless Steel for 13654 D0135X 36714 Blade Cover Handling for 13654 I2058
36562 Knife Fastener Bushing for 13654 B6192 36641 Nut for Grinder Cover Pivot for 13654 D015517 36715 Blade Cover Knob for 13654 I2066
17312 Bushing 22x25x20 for 13654 B6211 36643 Nut U5588 M5 for 13654 D0160 36717 Knob Assy for 13654 I2098
36565 Bushing Supporto Plate lg.21mm for
13654 B621415 36644 U5588 M5 Stainless Steel Nut for 13654 D016015 36718 Knife Cover Assy Knob for 13654 I2099
36568 DU Bushing 6x8x6 for 13654 B6224 19644 Nut M6 for 13654 D0163 17368 Hall Effect Switch 2P for 13654 I3646
60795 Nut for 13654 B6227 36647 Nut U5588 M8 for 13654 D0165 17369 Switch 4x20 for 13654 I3647
60832 Grinding Stone Shaft Housing for 13654 B6228 60825 Special Nut M16x1 for 13654 D0166 17372 Switch On/Off for 13654 I3670
36569 Fixing Lever Bushing for 13654 B6239 19645 Nut M10 for 13654 D0167 31213 Safety Switch for 13654 I3686
60780 All Sharpener Cover for 13654 C1618 36658 EL.Box Spacer for 13654 D5715 60775 Start/Stop Pushbutton for 13654 I3704
60764 Carriage for 13654 C181923 36659 Hand Grip-Knob Spacer for 13654 D575081 19602 Switch for 13654 I3705
36594 Cord Assy for 13654 C3229 36660 Spacer Supp.Resistenza LG.28mm for
13654 D5760 13597 Blade 40x3x245x17 for 13654 L0612
36596 Cavo Ass.Motor Lama (Fast.) for 13654 C3261 36661 Carriage Shock Absorber Spacer for
13654 D5762 36731 Lamp 220V. for 13654 L1010
Model MS-IT-0300-A 13654
