Omcan MS-IT-0300-H User manual

Revised - 11/10/2016
Toll Free: 1-800-465-0234
Fax: [phone]
Email: [email protected]
www.omcan.com
Horizontal Gear-Driven Slicers
Model MS-IT-0300-H, 0330-H, 0350-PM
Items 13655, 13656, 13657
Instruction Manual

2
Page
--------------------------------------------------------------------------- 3 - 4
-------------------------------------------------------------------------- 4 - 5
-------------------------------------------------------------------------- 6
--------------------------------------------------------------------------------------- 6 - 7
--------------------------------------------------------------------------------------------- 7
------------------------------------------------------------------------------------ 7 - 9
------------------------------------------------------------------------------ 10
---------------------------------------------------------------------------- 11 - 19
---------------------------------------------------------------------------- 20
------------------------------------------------------------------------------------------- 21 - 22
---------------------------------------------------------------------------- 23
Table of Contents
Section
General Information
Safety and Warranty
Technical Specications
Installation
Operation
Maintenance
Illustrated Drawings
Parts Breakdown
Electrical Schematics
Notes
Warranty Registration
Model MS-IT-0300-H / Model MS-IT-0330-H / Model MS-IT-0350-PM

3
General Information
Omcan Manufacturing and Distributing Company Inc., Food Machinery of America, Inc. dba Omcan
and Omcan Inc. are not responsible for any harm or injury caused due to any person’s improper or
negligent use of this equipment. The product shall only be operated by someone over the age of 18, of
sound mind, and not under the inuence of any drugs or alcohol, who has been trained in the correct
operation of this machine, and is wearing authorized, proper safety clothing. Any modication to the
machine voids any warranty, and may cause harm to individuals using the machine or in the vicinity of
the machine while in operation.
CHECK PACKAGE UPON ARRIVAL
Upon receipt of an Omcan shipment please inspect for external damage. If no damage is evident on the
external packaging, open carton to ensure all ordered items are within the box, and there is no concealed
damage to the machine. If the package has suffered rough handling, bumps or damage (visible or concealed),
please note it on the bill of lading before accepting the delivery and contact Omcan within 24 hours, so we may
initiate a claim with the carrier. A detailed report on the extent of the damage caused to the machine must be
lled out within three days, from the delivery date shown in the shipping documents. Omcan has no recourse
for damaged products that were shipped collect or third party.
Before operating any equipment, always read and familiarize yourself with all operation and safety
instructions.
Omcan would like to thank you for purchasing this machine. It’s of the utmost importance to save
these instructions for future reference. Also save the original box and packaging for shipping the
equipment if servicing or returning of the machine is required.
---------------------------------------------------------------------------------------------------------------------------------------------------
Omcan Fabrication et distribution Companie Limité et Food Machinery d’Amerique, dba Omcan et
Omcan Inc. ne sont pas responsables de tout dommage ou blessure causé du fait que toute personne
ait utilisé cet équipement de façon irrégulière. Le produit ne doit être exploité que par quelqu’un de
plus de 18 ans, saine d’esprit, et pas sous l’inuence d’une drogue ou d’acohol, qui a été formé pour
utiliser cette machine correctement, et est vêtu de vêtements de sécurité approprié. Toute modication
de la machine annule toute garantie, et peut causer un préjudice à des personnes utilisant la machine
ou des personnes à proximité de la machine pendant son fonctionnement.
VÉRIFIEZ LE COLIS DÈS RÉCEPTION
Dès réception d’une expédition d’Omcan veuillez inspecter pour dommages externes. Si aucun dommage
n’est visible sur l’emballage externe, ouvrez le carton an de s’assurer que tous les éléments commandés
sont dans la boîte, et il n’y a aucun dommage dissimulé à la machine. Si le colis n’a subi aucune mauvaises
manipulations, de bosses ou de dommages (visible ou cachée), notez-le sur le bond de livraison avant
d’accepter la livraison et contactez Omcan dans les 24 heures qui suivent, pour que nous puissions engager
une réclamation auprès du transporteur. Un rapport détaillé sur l’étendue des dommages causés à la machine
doit être rempli dans un délai de trois jours, à compter de la date de livraison indiquée dans les documents
d’expédition. Omcan n’a aucun droit de recours pour les produits endommagés qui ont été expédiées ou cueilli
par un tiers transporteur.

4
General Information
Safety and Warranty
GENERAL SAFETY REGULATIONS
The slicer must be used only by suitably trained personnel. Furthermore, this personnel must have read this
manual carefully. In particular, please comply to the following instructions:
• Install the machine according to the instructions contained in the “Installation” section.
• Do not remove the transparent protections, and do not modify nor exclude the mechanical and electrical
Avant d’utiliser n’importe quel équipement, toujours lire et vous familiariser avec toutes les opérations
et les consignes de sécurité.
Omcan voudrais vous remercier d’avoir choisi cette machine. Il est primordial de conserver ces
instructions pour une référence ultérieure. Également conservez la boîte originale et l’emballage pour
l’expédition de l’équipement si l’entretien ou le retour de la machine est nécessaire.
---------------------------------------------------------------------------------------------------------------------------------------------------
Omcan Empresa De Fabricacion Y Distribucion Inc. Y Maquinaria De Alimentos De America, Inc. dba
Omcan y Omcan Inc. no son responsables de ningun daño o perjuicío causado por cualquier persona
inadecuada o el uso descuidado de este equipo. El producto solo podra ser operado por una persona
mayor de 18 años, en su sano juicio y no bajo alguna inuencia de droga o alcohol, y que este ha sido
entrenado en el correcto funcionamiento de esta máquina, y ésta usando ropa apropiada y autorizada.
Cualquier modicación a la máquina anúla la garantía y puede causar daños a las personas usando la
máquina mientras esta en el funcionamiento.
REVISE EL PAQUETE A SU LLEGADA
Tras la recepcion de un envio Omcan favor inspeccionar daños externos. Si no hay daños evidentes en el
empaque exterior, Habra el carton para asegurararse que todos los articulos solicitados ésten dentro de la
caja y no encuentre daños ocultos en la máquina. Si el paquete ha sufrido un manejo de poco cuidado, golpes
o daños (visible o oculto) por favor anote en la factura antes de aceptar la entrega y contacte Omcan dentro
de las 24 horas, de modo que podamos iniciar una reclamación con la compañia. Un informe detallado sobre
los daños causados a la máquina debe ser llenado en el plazo de tres días, desde la fecha de entrega que se
muestra en los documentos de envío. Omcan no tiene ningun recurso por productos dañados que se enviaron
a recoger por terceros.
Antes de utilizar cualquier equipo, siempre leer y familiarizarse con todas las instrucciones de
operación y seguridad.
Omcan quisiera darles las gracias por la compra de esta máquina. Es de la máxima importancia para
guardar estas instrucciones para referencias en el futuro. También guarde la caja original y el embalaje
para envío del equipo si el mantenimiento o la devolución de la máquina es necesaria.

5
Safety and Warranty
safety devices.
• Do not use the machine with improvised connections, or provisional or non insulated cables.
• Check the power cable and gland plate on the machine body regularly and, when necessary, have them
replaced by qualied personnel.
• In case of anomalies, defective operation, incorrect movement, and/or unusual noise, stop the machine
immediately.
• Before cleaning or servicing, disconnect the machine from the mains.
• Always use protection gloves during cleaning or maintenance.
• Lay or remove the goods to be sliced on the sliding plate only when the latter is completely pushed back
and the thickness control knob positioned to 0.
• To move the carriage tray when slicing, use the handle or the product grip handle.
• For extraordinary maintenance (to replace the sharpener wheels, the blade, etc), please contact the
manufacturer or qualied and duly authorized personnel.
• Avoid running the slicers with no product on it.
• The slicers are equipped with a ventilated motor. Extended continual use is not recommended. Let the
motor cool down after 30 minutes of use.
1 YEAR PARTS AND BENCH WARRANTY
Within the warranty period, contact Omcan Inc. at 1-800-465-0234 to schedule a drop off to either
an Omcan authorized service depot in the area, or to an Omcan Service warehouse to repair the
equipment.
Unauthorized maintenance will void the warranty. Warranty covers electrical and part failures, not
improper use.
Please see www.omcan.com/warranty.html for complete info.
WARNING:
The packaging components are classied as normal solid urban waste and can therefore be disposed of
without difculty.
In any case, for suitable recycling, we suggest disposing of the products separately (differentiated
waste) according to the current norms.
DO NOT DISCARD ANY PACKAGING MATERIALS IN THE ENVIRONMENT!

6
Technical Specications
Installation
UNPACKING
Immediately after unpacking the slicer, check it for possible shipping damage. If this machine is found
to be damaged after unpacking, save the packing material and contact the carrier within 15 days of delivery.
Prior to installation, test the electrical service to assure that it agrees with the specications on the machine
data plate.
ELECTRICAL
WARNING: It must be connected to properly grounding plug, grounded outlet. If the receptacle is not the
proper grounding type, contact an electrician.
CLEANING
This machine must be thoroughly cleaned and sanitized after installation and before being put into service.
SAFETY
Safety devices incorporated in this slicer must be in their correct operating positions anytime the slicer is in
Model MS-IT-0300-H MS-IT-0330-H MS-IT-0350-PM
Blade Size 12” / 300 mm 13” / 330 mm 14” / 350 mm
Power 0.35 HP / 0.26 kW 0.35 HP / 0.26 kW 0.35 HP / 0.26 kW
Cheese Slicing*
Slicing Volume* 8 hours or more 8 hours or more 8 hours or more
RPM 250 250 250
Cutting Size 11” x 9”
279 x 229 mm
11.81” x 9.84”
300 x 250 mm
12.20” x 10.63”
310 x 270 mm
Cut Thickness 0-25mm 0-25mm 0-15mm
Electrical 110V / 60 Hz / 1 Ph 110V / 60 Hz / 1 Ph 110V / 60 Hz / 1 Ph
Weight 95 lbs. / 43 kg. 99 lbs. / 45 kg. 110 lbs. / 50 kg.
Dimensions
(WDH)
30” x 25.6” 18.5”
762 x 650 x 470 mm
30” x 25.6” x 19”
762 x 650 x 483 mm
32.25” x 27” x 20.25”
819 x 686 x 514 mm
Item Number 13655 13656 13657
*Results may vary due to product consistency and temperature

7
Installation
use.
• The blade cover (6) must be in position over the knife and secured by tightening the hand knob (7).
• The Iast slice device (4) must be used when slicing it keep your hands away from the knife. When the slicer
is not running, the slicer thickness control (2) must be set to zero (fully clockwise) to prevent the blade edge
from being exposed.
• Always UNPLUG the power cord before cleaning or moving the slicer.
Operation
• Pull the product holder (3) towards you until it stops and place the product
to be sliced on the product holder tray.
• Set the last slice device against the product and switch on the slicer by
pressing the on-off switch (9).
• Adjust the slice thickness by turning the slice thickness control.
• The numbers on the slice thickness control do not indicate actual
measurements but may be used for reference to duplicate slice thickness.
• Using the last slice device (4), push the product holder (3) back and forth
to slice.
• Always switch-off the slicer and turn the slice thickness control clockwise
to zero when not slicing.
10
14 4
38
2
9
6
Maintenance
CLEANING
This machine must be thoroughly cleaned after each day’s operation
or anytime it will not be used for an extended period of time.
WARNING: Unplug machine power cord and turn the index knob fully
clockwise before cleaning the slicer.
• Turn the slice deector (12) for easy cleaning back of the blade.
• The product holder can be removed for an easy cleaning by
rotating its handle counterclockwise (8).
• Using a mild soap, hot water solution, and a clean cloth, wipe all
surfaces of the slicer.
• Thoroughiy rinse it with another clean cloth and fresh water.
• Remove the blade cover by removing the hand knob (7).
11
1
7
12

8
Maintenance
• With the hand knob removed, grasp the edge of the blade cover and carefully lift it straight off the knife.
WARNING: The slicer blade is very sharp. Use extreme caution when working near the blade.
• CAREFULLY wash both sides of the blade with the slice thickness control turned fully clockwise.
• Wash the blade by wiping outward from the center.
• ALWAYS rinse the blade thoroughly using fresh water and a clean cloth. Never use steel pads to clean the
blade. Wash and thoroughly rinse the removed components prior to reassembling them.
• DO NOT wash any slicer components in a dishwasher.
BLADE SHARPENING
Attention: Use protection gloves
Your slicer blade will provide long service in normal deli, food store, or commercial kitchen use. However, in
high volume applications where it is a practice to sharpen the blade frequently or even daily, the blade will be
expended in a shorter time.
• Before using the sharpener, make sure that the front and back side of the knife edge is clean and free of
grease.
• To sharpen knife:
a) Be sure that the slicer has been switched off.
b) Rotate the slice thickness control (4) into “O” position, so that the thickness plate (5) protects the knife.
(Fig. 2)
• Lift up the sharpener cover (1). (Fig. 2)
• Disengage the pin (7) and rotate the sharpener (3). (Fig. 3)
• The sharpener, then, goes into its sharpening position. (Fig. 4)
• To sharpen, turn the switch rst in the ON position, so that the knife turns. Then, slowly rotate the lever
which lets both stones go in contact with the knife; sharpening and trimming are made at the same time.
(Fig. 5)
• Replace the sharpener to normal horizontal position by lifting the pin (7) and close the cover. (Fig. 6)
• The grinding stone (6), tted on its pin, can be easily removed by just drawing it. (Fig. 7) To get a nice
sharpening, the grinding stone must be clean and free of grease.
• The sharpening time depends on the wear of the knife. To get a good result, the time needed is 10 to 15
seconds. A longer sharpening reduce the duration of the knife and gives no advantage.
• Wipe the slicer with a clean damp cloth to remove any grinding particles.
LUBRICATION
• The rod on which the product holder slides, which is underneath the slicer, should be lubricated weekly with
several drops of oil. Stop the carriage at the end of the stroke nearest the operator and pour the lubricant
into the special oiler. DO NOT use vegetable oil.
• Occasionally, the slice thickness plate slide rod should be coated lightly with lubricant.
• Turn the slice thickness control fully counterclockwise when lubricating this slide rod and then turn it fully
clockwise when nished. DO NOT lubricate the rod on which the last slice device slides. It must be kept
clean but not lubricated. The motor has sealed bearings and requires no lubrication maintenance.

9
Maintenance
WEAR ADJUSTMENT
After several, years of operation and many sharpening of the blade it may become necessary to have the slice
thickness plate (14) adjusted closer to the blade.
REFERENCE
Item Number Model Number Description Manufacturer Model Number
13655 MS-IT-0300-H
Meat Slicer Gear Driven Horizontal
12” / 300mm Blade 0.35 HP / 261 W
110V/60/1 NSF cETL cULus
H300
13656 MS-IT-0330-H
Meat Slicer Gear Driven Horizontal
13” / 330mm Blade 0.35 HP / 261 W
110V/60/1 NSF cETL cULus
H330
13657 MS-IT-0350-PM
Meat Slicer Gear Driven Horizontal
14” / 350mm Blade 0.35 HP / 261 W
110V/60/1 NSF cETL cULus
H350

10
Illustrated Drawings
1
4
2
5
1
3
7
45
7
1
6
6
7

11
Parts Breakdown
Model MS-IT-0300-H 13655
Model MS-IT-0330-H 13656
Model MS-IT-0350-PM 13657

12
Parts Breakdown
Model MS-IT-0300-H 13655
Model MS-IT-0330-H 13656
Model MS-IT-0350-PM 13657

13
Parts Breakdown
Model MS-IT-0300-H 13655
Model MS-IT-0330-H 13656
Model MS-IT-0350-PM 13657

14
Parts Breakdown
Model MS-IT-0300-H 13655
Model MS-IT-0330-H 13656
Model MS-IT-0350-PM 13657

15
Parts Breakdown
Model MS-IT-0300-H 13655
Model MS-IT-0330-H 13656
Model MS-IT-0350-PM 13657

16
Parts Breakdown
Model MS-IT-0300-H 13655
Model MS-IT-0330-H 13656
Model MS-IT-0350-PM 13657

17
Parts Breakdown
Model MS-IT-0300-H 13655
Model MS-IT-0330-H 13656
Model MS-IT-0350-PM 13657
Item No. Description Position Item No. Description Position Item No. Description Position
17272 Sharpening Assembly (Support & Stones)
for H300, H330, H350 A1003 78265 Bushing, Funnel H-L-C (OMAS) for H300, H330, H350 B6110 19645 Nut M10 for H300, H330, H350 D0167
16899 Sharpening Assembly for H300, H330,
H350 A1006 17312 Bushing 22 x 25 x 20 for H300, H330, H350 B6211 19547 Nut for H300, H330, H350 D0190
78234 Sharpening Assembly (Support & Stones)
(OMAS) for H300, H330, H350 A1021 36566 Bushing to hold Carriage Springs for H300, H330, H350 B6221 19648 Knife Spacer for H300, H330, H350 D5602
17279 Ring EL.Benzing 5 for H300, H330, H350 A5403 17313 Bushing DU 14 x 15 x 16 for H300,
H330, H350 B6244 17341 Spacer D.10.5 x 14 H.9 for H300, H330, H350 D5643
17280 Ring EL.Benzing 5 for H300, H330, H350 A5404 36571 Bushing Pivot Afl. H-L-P-M-C (CE) for
H300, H330, H350 B6248 19553 Meat Grip Spacer H for H300, H330, H350 D5685
16902 Ring EL.Benzing 8 for H300, H330, H350 A5406 36577 Meat Grip Arm H250 for H300, H330,
H350 B7803A 39410 Space Aluminum for H370 for H300, H330, H350 D5690
17281 Ring EL.Seeger Ext.25 for H300, H330,
H350 A5453 16909 Sharpener Cover H-L-C for H300, H330, H350 C1603 36661 Carriage Shock Absorber Spacer for H300, H330, H350 D5762
19484 Ring 52 for H300, H330, H350 A5485 36590 AG35-C-H Carriage for H300, H330,
H350 C1854 30459 E1406 Stop Cam for H350 for H300, H330, H350 E1406
19612 Ring 33 for H300, H330, H350 A5495 20423 Pin for H300, H330, H350 C4620 17342 CAM 15 mm for H300, H330, H350 E1420
17283 Oil Seal 25 x 52 x 10 for H300, H330,
H350 A5809 36601 Rivet 1.9 x 5 for H300, H330, H350 C4640 19559 CAM 25 mm for H300, H330, H350 E1422
17287 O-Ring 123 17.86 x 2.62 for H300,
H330, H350 A5852 17325 Capacitor VS for H300, H330, H350 C5806 17345 CAM Bearing H300 for H300, H330, H350 E1458
36544 Carriage Rod H-L-C300/330/350 for
H300, H330, H350 B1010A 19534 Housing Sharpener H for H300, H330, H350 C6807 36680 Carriage Felt C Matic for H300, H330, H350 F1606
19496 Carriage Rod C-H for H300, H330, H350 B1095 19535 Rack H300/330 for H300, H330, H350 C7241 36681 Cord Holder H-L-C for H300, H330,
H350 F2809A
36548 Shock Absorber Bar 12 x 170 for H300,
H330, H350 B1251 24607 Bearing 2Z-6205 25 x 252 x 15 for C300 for H300, H330, H350 C8011 17347 Knife Support Flange H-L for H300, H330, H350 F6033
19507 Carriage Rod A310 for H300, H330,
H350 B1372A 19637 Nut M3 for H300, H330, H350 D0101 17349 Handle Flange for H300, H330, H350 F6090
17296 Tray Rod H300/330 for H300, H330,
H350 B1399 36634 Nut U5587 M3.5 for H300, H330, H350 D0104 17351 Locknut H-L-C for H300, H330, H350 G5018
16904 Bushing Sharpener H-L-C for H300,
H330, H350 B6048 16928 Nut U5589 M6 for H300, H330, H350 D0133 36688 Locknut H-L300/330 for H300, H330, H350 G5022
16905 Bushing DU 16 x 18 x 15 for H300,
H330, H350 B6053 19639 Nut M8 for H300, H330, H350 D0135 17355 Handle for H300, H330, H350 I1911
17304 Bushing for H300, H330, H350 B6056 17337 Nut U5589 M10 6S for H300, H330, H350 D0137 19587 Sharpener Knob for H300, H330, H350 I1957A
17305 Bushing DU 18 x 20 x 15 for H300,
H330, H350 B6057 36640 Stainless Steel Domed Nut U5721 M6 for H300, H330, H350 D0153X 36707 Switch Handle for H300, H330, H350 I1980
19514 Bushing Guard A310 for H300, H330,
H350 B6061 19643 Nut M10 for H300, H330, H350 D0157X 18222 Rod Meat Grip Handle H for H300, H330, H350 I1984
16906 Bush Sharpening H-L-C for H300, H330,
H350 B6075 19644 Nut M6 for H300, H330, H350 D0163 17364 Nylon Gear H300/H330 DP 56, 80, Z29 for H300, H330, H350 I2404
16907 Bush Sharpening H-L-C for H300, H330,
H350 B6076 36646 Stainless Steel Nut U5588 M6 for H300, H330, H350 D0163X 78585 Switch 380/50/3 for H300, H330, H350 I3610
17307 Bushing Sharpener H-L-C for H300,
H330, H350 B6083 36647 Nut U5588 M8 for H300, H330, H350 D0165 16938 Switch and Knob HL C GF 310 for H300, H330, H350 I3611

18
Parts Breakdown
Model MS-IT-0300-H 13655
Model MS-IT-0330-H 13656
Model MS-IT-0350-PM 13657
Item No. Description Position Item No. Description Position Item No. Description Position
17369 Switch 4 x 20 for H300, H330, H350 I3647 17402 Deector HM-HP for H300, H330, H350 P1130 19831 Gauge Plate Flat Bar VS for H300,
H330, H350 P4621
36723 Switch 4 x 25 for H300, H330, H350 I3678 19805 Deector HLC 330 for H300, H330, H350 P1150 19832 Flat Bar H-L for H300, H330, H350 P4651
78577 Knife 300 mm; Hole 57 mm for H300,
H330, H350 L0606 17406 Ring Deector for H300, H330, H350 P1183 18221 Slide Rail Flat 20 x 400 for H300, H330, H350 P4815
13568 Knife 330 mm for H300, H330, H350 L0608 36764 Slice Deector H-L-P 330 for H300,
H330, H350 P133321 16961 Foot H/C/L VS/GL/GF for H300, H330, H350 P5008
36731 Lamp 220V. for H300, H330, H350 L1010 17410 Blade Guard Cover C300 for H300,
H330, H350 P1532 36844 End Grip Assembly H300/330 for H300, H330, H350 P6717
36733 Magnet 8 x 10 for H300, H330, H350 M0803 17412 Knife Guard H-L-C330 for H300, H330,
H350 P1550 19655 Meat Grip Stud H for H300, H330, H350 P7420
36734 Magnet 12 x 6 for H300, H330, H350 M0804 17415 Strain Relief for H300, H330, H350 P2008 16964 Stud Guard Knife C for H300, H330,
H350 P7425
14787 Grinding Stone C (OMAS) for H300,
H330, H350 M6602 74413 Cable Sheath Cavoex CM 60 for BG80E for H300, H330, H350 P2011 17444 Stud Carriage H-L-C for H300, H330, H350 P7431
36741 Stainless Steel Spring 2.9 x 4 x 12 for
H300, H330, H350 M7001 19811 Pin Sharpener HLC 300/330 for H300, H330, H350 P3205 36854 Thumb Protection H300 for H300, H330, H350 P7854
17377 Stainless Steel Spring 8.5 x 1.0 x 25 for
H300, H330, H350 M7013 17416 Pin Sharpener C350/370 for H300, H330, H350 P3207 24030 HLC Sharpener Operating Handle for H300, H330, H350 P8625
17379 Stainless Steel Spring 11.9 x0.7 x 27 for
H300, H330, H350 M7029 16959 Pin Grinding H-L-C for H300, H330, H350 P3225 19657 Washer 4 for H300, H330, H350 R6003
17380 Stainless Steel Spring 13.4 x 1.3 x 30 for
H300, H330, H350 M7030 17419 Pin Truing H-L-C for H300, H330, H350 P322601 19661 Washer 8 for H300, H330, H350 R6030
19776 Spring 14 x 1.5 x 60 for H300, H330,
H350 M7032 17422 Pin Deector H-L-C for H300, H330, H350 P3269 36876 Stainless Steel Washer 6.2 x 12.5 x 0.7 for H300, H330, H350 R6204X
17381 Spring 22 5x1 8x18 for H300, H330,
H350 M7052 19822 Pin Handle Meat Grip for H300, H330, H350 P3288A 19666 Washer for H300, H330, H350 R6280
19248 Spring 15.6*20*2.2 for H300, H330, H350 M7120 19824 Pin Guard Knife HL for H300, H330, H350 P3377 36880 Washer U6592 3 for H300, H330, H350 R6504
20459 Terminal Strip for H300, H330, H350 M8005 78584 Assembly Honing Stone Pin H-L-C for
H300, H330, H350 P3380 16967 Washer U65926 for H300, H330, H350 R6512
17385 Motor 120//60 H for H300, H330, H350 M8429 17427 Assembly Grinding Stone Pin H-L-C for
H300, H330, H350 P3381 17457 Stainless Steel Washer U6592 6 for H300, H330, H350 R6512X
19791 Oiler H-L-C for H300, H330, H350 O4040 78233 Pin Sharpener HLC 250/275 (OMAS) for
H300, H330, H350 P3387 19668 Washer 10 for H300, H330, H350 R6530
17390 Rubber Shock Abs. 16 x 22 x 2.5 for
H300, H330, H350 P1019 19825 Pin Support Meat Grip for H300, H330, H350 P3394 17458 Contact Washer for H300, H330, H350 R6806
19796 Plastic Shock for H300, H330, H350 P1031 36801 Pivot Sgancio Sharpener H/L-C for H300,
H330, H350 P3525 36889 Washer 10.5 x 16 x 1 for H300, H330, H350 R6816
17392 Pl.Shock Absorb. 8.5 x 20 for H300,
H330, H350 P1034 36808 Tray H300/330 for H300, H330, H350 P4420A 16969 Washer 18.2 x 25 x 0.5 for H300, H330, H350 R6840
36761 Shock Absorber for H300, H330, H350 P103401 36811 Tray H300/330 for H300, H330, H350 P4441A 17460 Washer 34.2 x 46 x 0.5 for H300, H330,
H350 R6846
16955 Shock Absorber H-L-C for H300, H330,
H350 P1059 36823 Tray Assembly H300/330 for H300, H330, H350 P4559 77595 Washer 44.5 x 51.5 x 0.2 (OMAS) for H300, H330, H350 R6848
17395 Shock Absorber H-L-C for H300, H330,
H350 P1081 36824 EL. Box Flat Bar for H300, H330, H350 P4618 77596 Switch Washer A310 (OMAS) for H300, H330, H350 R6864

19
Parts Breakdown
Model MS-IT-0300-H 13655
Model MS-IT-0330-H 13656
Model MS-IT-0350-PM 13657
Item No. Description Position Item No. Description Position Item No. Description Position
36892 Washer 17 x 30 x 4 for H300, H330,
H350 R6874 19877 Rubber Cap for H300, H330, H350 T1001 37047 Screw TC AUT.D7971 2.9 x 13 for H300, H330, H350 V6276
16972 Washer 5.5 x 19 x 2.5 for H300, H330,
H350 R6884 20265 Tierod H-L for H300, H330, H350 T5004 19913 Screw M8x45 for H300, H330, H350 V6331
78576 Washer for H300, H330, H350 R6931 17491 Knife Shaft Assembly H370 for H300,
H330, H350 T8024 37061 Screw TE U5739 M8x35 Inox for H300, H330, H350 V6411X
16973 Plate Wheel D. 25 x 9.5 for H300, H330,
H350 R8520 24033 Bracket for H300/330 for H300, H330, H350 T8510 37070 Stainless Steel Screw TE U5739 M6x20 for H300, H330, H350 V6449X
19680 Ball 3 17 for H300, H330, H350 S3005 78586 Plastic Bar lg.200 for H300, H330, H350 T9603 37076 Screw TE TRIL.D7976 M6x15 for H300,
H330, H350 V6496
17465 Ball 4.76 for H300, H330, H350 S3015 37004 Gauge Plate H-L300 for H300, H330,
H350 V3032 37078 S/S Screw TSP U6109 M5x12 for H300, H330, H350 V7013X
36924 Pin M.E. U6875 6 x 30 for H300, H330,
H350 S7546 37006 Gauge Plate H/L330 for H300, H330, H350 V3050 17498 Screw TSPEI U5933 M4x10 for H300, H330, H350 V7043
19688 Pin 2*12 for H300, H330, H350 S7552 37017 Screw STTC U6113 M4x30 for H300,
H330, H350 V6009 19713 Screw Sharpener for H300, H330, H350 V7710
17475 Pin 8 x 42 for H300, H330, H350 S7583 37023 Screw STEI U5929 M5x5 for H300,
H330, H350 V6065 37091 Screw H for H300, H330, H350 V7730
17476 Foot Support Pin D.10 M8 L.37 for H300,
H330, H350 S7595 19691 Grub Screw M6*6 for H300, H330, H350 V6066 17503 Screw M5x13 for H300, H330, H350 V7908
19871 Bracket Sharpener HLC for H300, H330,
H350 S8809 19692 Screw M6*8 for H300, H330, H350 V6067 19715 Screw Sharpener for H300, H330, H350 V7910
36936 Bracket Tray H/L30-33-35 for H300,
H330, H350 S8813 23648 Screw For H350 for H300, H330, H350 V6073 17504 Screw H/L-C for H300, H330, H350 V7915
36937 Bracket for H Series Plate Rod for H300,
H330, H350 S8818C 37032 Screw TC 6107 M3x20 for H300, H330, H350 V6201 19717 Screw M6*50 for H300, H330, H350 V7917
19873 EL Box Bracket for H300, H330, H350 S8901 19696 Screw M3.5*12 for H300, H330, H350 V6204 19720 Screw M6 for H300, H330, H350 V7934
36952 Magnet Support for H300, H330, H350 S8991 19699 Screw M4*25 for H300, H330, H350 V6231 19917 Screw BS for H300, H330, H350 V7960
77597 Washer Bracket A310 (OMAS) for H300,
H330, H350 S9009 37037 Screw TCEI U5931 M6x16 for H300, H330, H350 V6240X 19724 Screw H for H300, H330, H350 V8001
36955 Discontinued - Switch Support for H300,
H330, H350 S9056 19702 Screw M6*25 for H300, H330, H350 V6246 37098 Screw M10x40 for H300, H330, H350 V8012
24158 Pusher Rod Support for H330 for H300,
H330, H350 S9226 19704 Screw M10*16 for H300, H330, H350 V6262 19920 Screw M8x30 for H300, H330, H350 V8036

20
Electrical Schematics
Position Description
C1 Capacitor 14µF 450V
C1 Capacitor 20µF 450V (C-120V/60Hz)
I1 Switch
MR1 Terminal Board
M1 Motor
marrone / brown
rosso / red
azzurro / blue
nero / black
viola / violet
bianco / white
rosa / pink
grigjo / grey
giallo / yellow
1 = primary
2 = secondary
Model MS-IT-0300-H 13655
Model MS-IT-0330-H 13656
Model MS-IT-0350-PM 13657
