Meat Mixer
Model MM-BR-0050
Item 13153
Instruction Manual

2
Page
--------------------------------------------------------------------------- 3 - 4
--------------------------------------------------------------------------- 4 - 5
---------------------------------------------------------------------- 5 - 6
-------------------------------------------------------------------------------------------- 6
----------------------------------------------------------------------------------------- 6 - 7
------------------------------------------------------------------------------------- 7 - 8
----------------------------------------------------------------------------- 9 - 13
---------------------------------------------------------------------------- 13
------------------------------------------------------------------------------------------------ 14
---------------------------------------------------------------------------- 15
Table of Contents
Section
General Information
Safety and Warranty
Technical Specications
Installation
Operation
Maintenance
Parts Breakdown
Electrical Schematics
Notes
Warranty Registration
Model MM-BR-0050

3
General Information
Omcan Manufacturing and Distributing Company Inc., Food Machinery of America, Inc. dba Omcan
and Omcan Inc. are not responsible for any harm or injury caused due to any person’s improper or
negligent use of this equipment. The product shall only be operated by someone over the age of 18, of
sound mind, and not under the inuence of any drugs or alcohol, who has been trained in the correct
operation of this machine, and is wearing authorized, proper safety clothing. Any modication to the
machine voids any warranty, and may cause harm to individuals using the machine or in the vicinity of
the machine while in operation.
CHECK PACKAGE UPON ARRIVAL
Upon receipt of an Omcan shipment please inspect for external damage. If no damage is evident on the
external packaging, open carton to ensure all ordered items are within the box, and there is no concealed
damage to the machine. If the package has suffered rough handling, bumps or damage (visible or concealed),
please note it on the bill of lading before accepting the delivery and contact Omcan within 24 hours, so we may
initiate a claim with the carrier. A detailed report on the extent of the damage caused to the machine must be
lled out within three days, from the delivery date shown in the shipping documents. Omcan has no recourse
for damaged products that were shipped collect or third party.
Before operating any equipment, always read and familiarize yourself with all operation and safety
instructions.
Omcan would like to thank you for purchasing this machine. It’s of the utmost importance to save
these instructions for future reference. Also save the original box and packaging for shipping the
equipment if servicing or returning of the machine is required.
---------------------------------------------------------------------------------------------------------------------------------------------------
Omcan Fabrication et distribution Companie Limité et Food Machinery d’Amerique, dba Omcan et
Omcan Inc. ne sont pas responsables de tout dommage ou blessure causé du fait que toute personne
ait utilisé cet équipement de façon irrégulière. Le produit ne doit être exploité que par quelqu’un de
plus de 18 ans, saine d’esprit, et pas sous l’inuence d’une drogue ou d’acohol, qui a été formé pour
utiliser cette machine correctement, et est vêtu de vêtements de sécurité approprié. Toute modication
de la machine annule toute garantie, et peut causer un préjudice à des personnes utilisant la machine
ou des personnes à proximité de la machine pendant son fonctionnement.
VÉRIFIEZ LE COLIS DÈS RÉCEPTION
Dès réception d’une expédition d’Omcan veuillez inspecter pour dommages externes. Si aucun dommage
n’est visible sur l’emballage externe, ouvrez le carton an de s’assurer que tous les éléments commandés
sont dans la boîte, et il n’y a aucun dommage dissimulé à la machine. Si le colis n’a subi aucune mauvaises
manipulations, de bosses ou de dommages (visible ou cachée), notez-le sur le bond de livraison avant
d’accepter la livraison et contactez Omcan dans les 24 heures qui suivent, pour que nous puissions engager
une réclamation auprès du transporteur. Un rapport détaillé sur l’étendue des dommages causés à la machine
doit être rempli dans un délai de trois jours, à compter de la date de livraison indiquée dans les documents
d’expédition. Omcan n’a aucun droit de recours pour les produits endommagés qui ont été expédiées ou cueilli
par un tiers transporteur.

4
Safety and Warranty
General Information
• The MM-BR-0050 must be handled by trained or experienced operators.
• ALWAYS turn off, unplug the machine from the power source BEFORE cleaning and servicing.
• NEVER use tools not belonging to the machine to help operation.
• NEVER put hands or any other objects into the meat tank during operation.
• NEVER lift up the cover before being sure mixing tools are completely still.
• KEEP your working area clean and dry to prevent it from becoming slippery.
• DO NOT wear loose clothing during operation.
Avant d’utiliser n’importe quel équipement, toujours lire et vous familiariser avec toutes les opérations
et les consignes de sécurité.
Omcan voudrais vous remercier d’avoir choisi cette machine. Il est primordial de conserver ces
instructions pour une référence ultérieure. Également conservez la boîte originale et l’emballage pour
l’expédition de l’équipement si l’entretien ou le retour de la machine est nécessaire.
---------------------------------------------------------------------------------------------------------------------------------------------------
Omcan Empresa De Fabricacion Y Distribucion Inc. Y Maquinaria De Alimentos De America, Inc. dba
Omcan y Omcan Inc. no son responsables de ningun daño o perjuicío causado por cualquier persona
inadecuada o el uso descuidado de este equipo. El producto solo podra ser operado por una persona
mayor de 18 años, en su sano juicio y no bajo alguna inuencia de droga o alcohol, y que este ha sido
entrenado en el correcto funcionamiento de esta máquina, y ésta usando ropa apropiada y autorizada.
Cualquier modicación a la máquina anúla la garantía y puede causar daños a las personas usando la
máquina mientras esta en el funcionamiento.
REVISE EL PAQUETE A SU LLEGADA
Tras la recepcion de un envio Omcan favor inspeccionar daños externos. Si no hay daños evidentes en el
empaque exterior, Habra el carton para asegurararse que todos los articulos solicitados ésten dentro de la
caja y no encuentre daños ocultos en la máquina. Si el paquete ha sufrido un manejo de poco cuidado, golpes
o daños (visible o oculto) por favor anote en la factura antes de aceptar la entrega y contacte Omcan dentro
de las 24 horas, de modo que podamos iniciar una reclamación con la compañia. Un informe detallado sobre
los daños causados a la máquina debe ser llenado en el plazo de tres días, desde la fecha de entrega que se
muestra en los documentos de envío. Omcan no tiene ningun recurso por productos dañados que se enviaron
a recoger por terceros.
Antes de utilizar cualquier equipo, siempre lea y familiarizarse con todas las instrucciones de
funcionamiento y seguridad.
Omcan le gustaría darle las gracias por la compra de esta máquina. Es de la mayor importancia para
salvar estas instrucciones para futuras consultas. Además, guarda la caja original y el embalaje para el
envío del equipo si servicio técnico o devolución de la máquina que se requiere.

5
Technical Specications
Safety and Warranty
Picture 1
1. Lid.
2. Bowl.
3. Tilting Gutter.
4. Motor Housing.
5. Right Frame.
6. Left Frame.
7. On/Off Switch.
• NEVER spray water or other liquid substances directly onto the motor, power switch, or any other electrical
components.
• ALWAYS install equipment in working area with adequate light and space away from CHILDREN and
VISITORS.
• NEVER operate without all warning labels attached and instruction manual available to the operator.
• NEVER leave unattended while operating.
• ALWAYS ground the machine properly.
• IF CORD BECOMES DAMAGED, have it replaced by a qualied specialist, or contact your distributor.
• STOP THE MACHINE immediately if you hear abnormal noises or fear of injury.
• ONLY use the recommended lubrication oil or one of similar characteristics.
1 YEAR PARTS AND LABOUR WARRANTY
Within the warranty period, contact Omcan Inc. at 1-800-465-0234 to schedule an Omcan authorized
service technician to repair the equipment locally.
Unauthorized maintenance will void the warranty. Warranty covers electrical and part failures, not
improper use.
Please see www.omcan.com/warranty.html for complete info.
WARNING:
The packaging components are classied as normal solid urban waste and can therefore be disposed of
without difculty.
In any case, for suitable recycling, we suggest disposing of the products separately (differentiated
waste) according to the current norms.
DO NOT DISCARD ANY PACKAGING MATERIALS IN THE ENVIRONMENT!

6
Installation
Operation
The MM-BR-0050 must be installed on a at, non-skid surface. Check the voltage of the machine. The unit
voltage must be the same as the power source voltage. The machine must be properly grounded. Trained
personnel must install the unit according to building codes. Contact Omcan if you have any questions of
problems with the installation or operation of this machine at 1-800-465-0324.
CAUTION
Under no circumstances put hands or any other tool into the meat tank during operation.
Put the product to be processed into the meat tank and lower the cover. Then start the machine by turning the
switch to the “ON” position.
CAUTION: Always load the machine with the motor turned OFF.
DISCHARGING THE PROCESSED PRODUCT
Turn the machine OFF and wait for the mixing tools to be completely stopped. Hold the handle (Pic. 2, #2) that
is xed on the right side of the meat tank (Pic. 2, #1) and pull out the locking knob (Pic. 2, #3) to release the
meat tank. Open the cover and turn the meat tank to the front of the machine until it gets locked by the locking
knob in the tilting position. Turn the machine ON and OFF as many times as needed to help discharge all the
processed meat from the meat tank. To place the meat tank in the upright position, release the meat tank again
and turn it up, holding the handle.
Technical Specications
Model MM-BR-0050
Power 0.5 HP / 0.37 kW
RPM 50
Bowl Capacity 110 lbs. / 50 kgs.
Weight 200 lbs. / 90.7 kgs.
Dimension (DWH) 37” x 16.5” x 39.3” / 940 x 420 x 1092mm
Item Number 13153

7
Picture 2
Operation
Maintenance
WARNING
Always disconnect the machine from the power source before cleaning. Always make sure the mixing tools
are completely stopped before opening the cover. It is recommended that the machine be carefully cleaning
before it is rst used, after use, several times a day if it is very dirty and after long periods during which it has
remained off. Clean the machine with rags and sponges. Wipe dry. Only use soaps and detergents suitable for
kitchenware.
CAUTION
The machine cannot be cleaned with water jets. DO NOT clean it with steam jets or high pressure jets or
similar methods as this may result in short circuiting or serious damage to the machine.
ALWAYS turn the machine off before cleaning and maintenance.
• PROVIDE enough space around the machine to avoid damage.
• ALWAYS keep the oor dry. Wet oors may cause slips.
• ALWAYS turn the machine off in case of power supply problems.
• NEVER let dust or water get into the electrical or mechanical components of the machine.
• DO NOT modify the original features of the machine.
• DO NOT take out or tamper any safety identication labels.

8
Maintenance
ROUTINE INSPECTION
After 200 hours or 30 days of use, inset NON-TOXIC HORRAL-300 white synthetic grease through the right
and left grease inlet pin using a grease gun. To have access to the left grease inlet pin, remove the left side by
unscrewing the screws with a 7/16” service key. The right grease inlet is readily accessible.
WARNING
Always disconnect the machine from the power source before cleaning. Always make sure the mixing tools
are completely stopped before opening the cover. It is recommended that the machine be carefully cleaning
before it is rst used, after use, several times a day if it is very dirty and after long periods during which it has
remained off. Clean the machine with rags and sponges. Wipe dry. Only use soaps and detergents suitable for
kitchenware.
CAUTION
The machine cannot be cleaned with water jets. DO NOT clean it with steam jets or high pressure jets or
similar methods as this may result in short circuiting or serious damage to the machine.
REFERENCE
Item Number Model Number Description Manufacturer Model Number
13153 MM-BR-0050 Meat Mixer 110 LB / 50 KG
0.5 HP / 373 W 110V/60/1 MMS501

9
Parts Breakdown
Model MM-BR-0050 13153

10
Parts Breakdown
Model MM-BR-0050 13153

11
Parts Breakdown
Model MM-BR-0050 13153
08262.7
08263.5
08264.3
09962.7
04214.5

12
Parts Breakdown
Model MM-BR-0050 13153
Item No. Description Position Item No. Description Position Item No. Description Position
38323 Right Mixing Arm for MMS501 03880.6 38352 Screw for MMS501 14334.0 78223 Switch Protector for MMS501 10601.1
38324 Central Mixing Arm for MMS501 03881.4 38353 Sphere with Thread 3/8” for MMS501 01643.8 38374 Retainer 00463BR for MMS501 00547.9
38325 Left Mixing Arm for MMS501 03879.2 38354 Right Side Leg for MMS501 03875.0 38375 Lock Assembly for MMS501 08262.7
38326 Threaded Screw UNC 5/16” x 5/8” for
MMS501 04396.6 38355 Closing Plate for MMS501 40233.8 16405 Lock Bearing for MMS501 03888.1
38327 O-Ring 39x27x6mm for MMS501 19531.6 78211 Pressure Rivet AD-423-S for MMS501 00045.0 38376 Lock Pin for MMS501 03887.3
38328 Screw for MMS501 30475.1 38356 Maintenance Labels for MMS501 37370.2 38377 Latch Spring for MMS501 03889.0
78206 Washer for MMS501 03213.1 78212 Cover for MMS501 29538.8 38378 Tank Complete Left Bearing for MMS501 08263.5
38329 Rotating Axis of the Tank for MMS501 03865.2 38357 Frame Housing for MMS501 40234.6 18947 Bearing for MMS501 03138.0
38330 Screw M5x10 DIN 963 S/S for MMS501 13841.0 78213 Logo for MMS501 00167.8 38379 Straight Fitting Pin M6 for MMS501 03913.6
38331 2” Hinge for MMS501 02933.5 38358 Motor Support for MMS501 03878.4 20015 Complete Ball Bearing 1205 for MMS501 03911.0
38332 Nut M5 DIN 934 S/S for MMS501 10471.0 38359 Attention Label for MMS501 12339.0 38380 Tank Complete Right Bearing for
MMS501 08264.3
38333 Chain for MMS501 01270.0 38360 Screw M4x30 DN 7985 ZB for MMS501 04909.3 38381 Cover for MMS501 01340.4
38334 Screw PFS ACC UNC 1/4” x 7/8” RTF
for MMS501 00091.4 78214 Screw M6x12 DIN 933 INOX for MMS501 12384.6 38382 Bowl Lever for MMS501 04214.5
38335 Moving Gear Z-57 for MMS501 03862.8 38362 Micro Support for MMS501 21511.2 38383 Complete Cable PMC M8 for MMS501 04579.9
38336 Closing Side for MMS501 10229.6 78215 Washer A6.4 DIN 125 INOX for MMS501 12442.7 38384 Screw Nut M8 934 INOX for MMS501 12445.1
18948 Belt A 561 for MMS501 01247.5 38363 Nut M6 DIN 934 INOX for MMS501 12448.6 38385 Complete Tank Lid for MMS501 09962.7
38337 Gear for MMS501 03893.8 78216 Motor ID Label for MMS501 10204.0 38386 Lid for MMS501 09963.5
38338 Screw UNIC 5/16x5/8 RTZB for MMS501 01044.8 78155 Wire Passer Molde 0922231 for MMS501 00218.6 38387 Cover Handle for MMS501 10124.9
38339 Moving Pulley for MMS501 03217.4 78217 Washer L A8.4 Stainless Steel for
MMS501 12460.5 38389 Screw 1/4” x 5/8” for MMS501 13238.1
38340 Fiber Washer 1mm for MMS501 00277.1 16422 Screw M8x20 DIN 933 S/S for MMS501 12455.9 38390 Rivet for MMS501 00505.4
78207 Washer L 5/16” ZB for MMS501 00119.8 38364 Side Housing for MMS501 40231.1 78224 Screw 1/4”x5/8” for MMS501 00544.4
38341 Washer 1/4 x 5/8 x 1.2mm Stainless
Steel for MMS501 19384.4 38365 Reinforced Handle M8 FR.1500 for MMS501 17449.1 78225 Insulating Terminal EF-4228 for MMS501 01213.0
38342 Screw UNC 1/4” x 5/8” for MMS501 30473.5 38366 Preisolated Terminal for MMS501 04285.4 78226 Danger Plate for MMS501 01790.6
38343 Bearing for MMS501 03229.8 78218 MB for MMS501 05504.2 78227 ON/OFF Label for MMS501 01844.9
38344 Screw PFS M4x8 DIN 933 Inox for
MMS501 28253.7 78219 Nylon Cover CN-4478 for MMS501 03678.1 38392 Screw Nut DIN 934 for MMS501 02729.4
38345 Nut W 1/5” Stainless Steel for MMS501 13772.3 78220 Internal Wire 2x1.5x2000mm for MMS501 01834.1 78228 Washer L.A8.4 ZB for MMS501 02730.8
38346 Calha Basculante for MMS501 03895.4 38369 Limit Switch for MMS501 21161.3 38393 Screw Nut M3 DIN 934 ZB for MMS501 03088.0
38347 Support Pin 1/2x115mm W/Z for MMS501 03876.8 78152 Positive Terminal Lock 0.5A1.5 for
MMS501 17581.1 38394 PFS M4x20 DIN 7985 ZB for MMS501 03140.2
38348 Motor Support Shaft for MMS501 38212.4 78153 Terminal Cover for MMS501 17582.0 38395 PFS M8x10 DIN 933 ZB for MMS501 03196.8
38349 Left Side Leg for MMS501 03874.1 38371 Electric Key 14227 A1B1E3Q with Cover
for MMS501 10561.9 78229 Nut UNC 1/4” ZB for MMS501 00037.0
78208 Threaded Nut 1/4” Stainless Steel for
MMS501 143359. 78221 Switch 14123 - A1B1E3Q for MMS501 00086.8 38396 Tank for MMS501 03869.5
78209 Screw PFS UNC 1/4”x3/4” RTZB for
MMS501 00030.2 78222 Contactor for MMS501 18450.0 38397 Motor Support for MMS501 03877.6
38350 Washer L.A15 DIN 125ZB for MMS501 05629.4 38372 Screw ASC UNC 1/4” x 1/2” for MMS501 00290.9 38398 Cabinet for MMS501 03897.0
38351 Engine Mount for MMS501 38223.0 38373 Motor Pulley for MMS501 03926.8 16406 Side Cabinet for MMS501 03901.2
78210 Tank for MMS501 10607.0 38388 PFS Screw UNC 1/4” x 1” RTZB for
MMS501 00035.3 38399 Handle for MMS501 03904.7

13
Parts Breakdown
Model MM-BR-0050 13153
Item No. Description Position Item No. Description Position Item No. Description Position
38400 Cabinet Reinforcement for MMS501 03910.1 38406 Plate Protection Key for MMS501 10018.8 38412 PFS M4x5 DIN 7985 INOX for MMS501 23932.1
38401 Motor 0.5HP 60Hz for MMS501 04261.7 38407 Switch MG-2607IR/E3 for MMS501 10058.7 38413 Motor for MMS501 28699.0
78230 Screw M8x20 DIN 933 ZB for MMS501 04474.1 16414 Electronic Switch 14227 A1B1E3Q for
MMS501 10602.0 38414 Support Selector Switch for MMS501 30156.6
38402 Cable 3x1mm2 for MMS501 04697.3 38408 Key L/D MG-2607IR for MMS501 10640.2 77232 Washer L 1/4” x 1.6” ZB for MMS501 00100.7
78231 Cable 3x0.75mm for MMS501 09103.0 38409 Side Housing for MMS501 17450.5 78025 Washer L 3/8” ZB for MMS501 00101.5
38403 Washer L 1/2” ZB for MMS501 00038.8 38387 Screw M8x16 DIN 933 ZB for MMS501 19059.4 38415 PCA Secrew UNC 5/16” ZB for MMS501 00107.4
38404 Nut M4 DIn 934 for MMS501 09205.3 38410 PFS M3x20 DIN 7985 ZB for MMS501 20422.6 38416 PFS Screw 3/8”x1 1/4” RTZB for
MMS501 00122.8
38405 Motor ID Label for MMS501 09637.7 38411 PCA Screw W 1/2” ZB for MMS501 00051.5 38417 Hinges 2” for MMS501 00419.7
Electrical Schematics
Model MM-BR-0050 13153

14
Notes
________________________________________________________________________________________
________________________________________________________________________________________
________________________________________________________________________________________
________________________________________________________________________________________
________________________________________________________________________________________
________________________________________________________________________________________
________________________________________________________________________________________
________________________________________________________________________________________
________________________________________________________________________________________
________________________________________________________________________________________
________________________________________________________________________________________
________________________________________________________________________________________
________________________________________________________________________________________
________________________________________________________________________________________
________________________________________________________________________________________
________________________________________________________________________________________
________________________________________________________________________________________
________________________________________________________________________________________
________________________________________________________________________________________
________________________________________________________________________________________
________________________________________________________________________________________
________________________________________________________________________________________
________________________________________________________________________________________
________________________________________________________________________________________

15
Warranty Registration
Gracias por comprar un producto Omcan usted. Para registrar su garantía para este producto, complete la información a continuación,
cortar la tarjeta en la perforación y luego enviarlo a la dirección indicada a continuación. También puede registrarse en línea en:
Merci d’avoir acheté un produit Omcan. Pour enregistrer votre garantie pour ce produit, complétez les informations ci-dessous, détachez la
carte au niveau de la perforation, puis l’envoyer à l’adresse spécié ci-dessous. Vous pouvez également vous inscrire en ligne en visitant:
Thank you for purchasing an Omcan product. To register your warranty for this product, complete the information below, tear off the card at
the perforation and then send to the address specied below. You can also register online by visiting:
OMCAN
PRODUCT WARRANTY REGISTRATION
3115 Pepper Mill Court,
Mississauga, Ontario
Canada, L5L 4X5
www.omcan.com/warrantyregistration.html
or email to: [email protected]
Purchaser’s Information
Name: Company Name:
Address:
Telephone:
City: Province or State: Postal or Zip: Email Address:
Country: Type of Company:
Restaurant Bakery Deli
Dealer from which Purchased: Butcher Supermarket Caterer
Dealer City: Dealer Province or State: Institution (specify):
Invoice: Other (specify):
Model Name: Model Number: Serial Number:
Machine Description:
Date of Purchase (MM/DD/YYYY): Date of Installation (MM/DD/YYYY):
Would you like to extend the warranty? Yes No

Por correo en Canadá
Pour postale au Canada
For mailing in Canada
Por correo en los EE.UU.
Pour diffusion aux États-Unis
For mailing in the US
OMCAN
PRODUCT WARRANTY REGISTRATION
4450 Witmer Industrial Estates, Unit 4,
Niagara Falls, New York
USA, 14305
Thank you for choosing Omcan | Merci d’avoir choisi Omcan | Gracias por elegir Omcan

Since 1951 Omcan has grown to become a leading distributor of equipment and supplies to the North
American food service industry. Our success over these many years can be attributed to our commitment
to strengthen and develop new and existing relationships with our valued customers and manufacturers.
Today with partners in North America, Europe, Asia and South America, we continually work to improve
and grow the company. We strive to offer customers exceptional value through our qualied local sales
and service representatives who provide convenient access to over 3,500 globally sourced products.
Depuis 1951 Omcan a grandi pour devenir un des “leaders” de la distribution des équipements et
matériel pour l’industrie des services alimentaires en Amérique du Nord. Notre succès au cours de ces
nombreuses années peut être attribué à notre engagement à renforcer et à développer de nouvelles
et existantes relations avec nos clients et les fabricants de valeur. Aujourd’hui avec des partenaires en
Amérique du Nord, Europe, Asie et Amérique du Sud, nous travaillons continuellement à améliorer et
développer l’entreprise. Nous nous efforçons d’offrir à nos clients une valeur exceptionnelle grâce à
nos ventes locales qualiées et des représentants de service qui offrent un accès facile à plus de 3500
produits provenant du monde entier.
Desde 1951 Omcan ha crecido hasta convertirse en un líder en la distribución de equipos y suministros
de alimentos en América del Norte industria de servicios. Nuestro éxito en estos años se puede atribuir
a nuestro compromiso de fortalecer y desarrollar nuevas relaciones existentes con nuestros valiosos
clientes y fabricantes. Hoy con socios de América del Norte, Europa, Asia y América del Sur, que trabajan
continuamente para mejorar y crecer la empresa. Nos esforzamos por ofrecer a nuestros clientes valor
excepcional a través de nuestro local de ventas y representantes de los servicios que proporcionan un
fácil acceso a más de 3,500 productos con origen a nivel mundial.
