Omcan MX-CN-0020-G User manual

Revised - 06/07/2021
Toll Free: 1-800-465-0234
Fax: [phone]
Email: [email protected]
www.omcan.com
Baking Mixers
Models MX-CN-0020-G, 0020-T, 0030-G, 0030-T, 0010-G
Items 20467, 20441, 17835, 20442, 17836
Instruction Manual

2
Page
---------------------------------------------------------------------------------- 3 - 4
--------------------------------------------------------------------------------- 4 - 5
---------------------------------------------------------------------------- 5 - 6
-------------------------------------------------------------------------------------------------- 7
--------------------------------------------------------------------------------------------- 7 - 12
---------------------------------------------------------------------------------------------- 12
------------------------------------------------------------------------------------ 12 - 13
----------------------------------------------------------------------------------- 14
---------------------------------------------------------------------------------- 15 - 20
---------------------------------------------------------------------------- 21 - 25
------------------------------------------------------------------------------------------------------- 26
---------------------------------------------------------------------------------- 27
Table of Contents
Section
General Information
Safety and Warranty
Technical Specications
Installation
Operation
Maintenance
Troubleshooting
Mixer Capacity Chart
Parts Breakdown
Electrical Schematics
Notes
Warranty Registration
Model MX-CN-0010-G / Model MX-CN-0020-G / Model MX-CN-0020-T
Model MX-CN-0030-G / Model MX-CN-0030-T

3
General Information
Omcan Manufacturing and Distributing Company Inc., Food Machinery of America, Inc. dba Omcan
and Omcan Inc. are not responsible for any harm or injury caused due to any person’s improper or
negligent use of this equipment. The product shall only be operated by someone over the age of 18, of
sound mind, and not under the inuence of any drugs or alcohol, who has been trained in the correct
operation of this machine, and is wearing authorized, proper safety clothing. Any modication to the
machine voids any warranty, and may cause harm to individuals using the machine or in the vicinity of
the machine while in operation.
CHECK PACKAGE UPON ARRIVAL
Upon receipt of an Omcan shipment please inspect for external damage. If no damage is evident on the
external packaging, open carton to ensure all ordered items are within the box, and there is no concealed
damage to the machine. If the package has suffered rough handling, bumps or damage (visible or concealed),
please note it on the bill of lading before accepting the delivery and contact Omcan within 24 hours, so we may
initiate a claim with the carrier. A detailed report on the extent of the damage caused to the machine must be
lled out within three days, from the delivery date shown in the shipping documents. Omcan has no recourse
for damaged products that were shipped collect or third party.
Before operating any equipment, always read and familiarize yourself with all operation and safety
instructions.
Omcan would like to thank you for purchasing this machine. It’s of the utmost importance to save
these instructions for future reference. Also save the original box and packaging for shipping the
equipment if servicing or returning of the machine is required.
---------------------------------------------------------------------------------------------------------------------------------------------------
Omcan Fabrication et distribution Companie Limité et Food Machinery d’Amerique, dba Omcan et
Omcan Inc. ne sont pas responsables de tout dommage ou blessure causé du fait que toute personne
ait utilisé cet équipement de façon irrégulière. Le produit ne doit être exploité que par quelqu’un de
plus de 18 ans, saine d’esprit, et pas sous l’inuence d’une drogue ou d’acohol, qui a été formé pour
utiliser cette machine correctement, et est vêtu de vêtements de sécurité approprié. Toute modication
de la machine annule toute garantie, et peut causer un préjudice à des personnes utilisant la machine
ou des personnes à proximité de la machine pendant son fonctionnement.
VÉRIFIEZ LE COLIS DÈS RÉCEPTION
Dès réception d’une expédition d’Omcan veuillez inspecter pour dommages externes. Si aucun dommage
n’est visible sur l’emballage externe, ouvrez le carton an de s’assurer que tous les éléments commandés
sont dans la boîte, et il n’y a aucun dommage dissimulé à la machine. Si le colis n’a subi aucune mauvaises
manipulations, de bosses ou de dommages (visible ou cachée), notez-le sur le bond de livraison avant
d’accepter la livraison et contactez Omcan dans les 24 heures qui suivent, pour que nous puissions engager
une réclamation auprès du transporteur. Un rapport détaillé sur l’étendue des dommages causés à la machine
doit être rempli dans un délai de trois jours, à compter de la date de livraison indiquée dans les documents
d’expédition. Omcan n’a aucun droit de recours pour les produits endommagés qui ont été expédiées ou cueilli
par un tiers transporteur.

4
General Information
Avant d’utiliser n’importe quel équipement, toujours lire et vous familiariser avec toutes les opérations
et les consignes de sécurité.
Omcan voudrais vous remercier d’avoir choisi cette machine. Il est primordial de conserver ces
instructions pour une référence ultérieure. Également conservez la boîte originale et l’emballage pour
l’expédition de l’équipement si l’entretien ou le retour de la machine est nécessaire.
---------------------------------------------------------------------------------------------------------------------------------------------------
Omcan Empresa De Fabricacion Y Distribucion Inc. Y Maquinaria De Alimentos De America, Inc. dba
Omcan y Omcan Inc. no son responsables de ningun daño o perjuicío causado por cualquier persona
inadecuada o el uso descuidado de este equipo. El producto solo podra ser operado por una persona
mayor de 18 años, en su sano juicio y no bajo alguna inuencia de droga o alcohol, y que este ha sido
entrenado en el correcto funcionamiento de esta máquina, y ésta usando ropa apropiada y autorizada.
Cualquier modicación a la máquina anúla la garantía y puede causar daños a las personas usando la
máquina mientras esta en el funcionamiento.
REVISE EL PAQUETE A SU LLEGADA
Tras la recepcion de un envio Omcan favor inspeccionar daños externos. Si no hay daños evidentes en el
empaque exterior, Habra el carton para asegurararse que todos los articulos solicitados ésten dentro de la
caja y no encuentre daños ocultos en la máquina. Si el paquete ha sufrido un manejo de poco cuidado, golpes
o daños (visible o oculto) por favor anote en la factura antes de aceptar la entrega y contacte Omcan dentro
de las 24 horas, de modo que podamos iniciar una reclamación con la compañia. Un informe detallado sobre
los daños causados a la máquina debe ser llenado en el plazo de tres días, desde la fecha de entrega que se
muestra en los documentos de envío. Omcan no tiene ningun recurso por productos dañados que se enviaron
a recoger por terceros.
Antes de utilizar cualquier equipo, siempre lea y familiarizarse con todas las instrucciones de
funcionamiento y seguridad.
Omcan le gustaría darle las gracias por la compra de esta máquina. Es de la mayor importancia para
salvar estas instrucciones para futuras consultas. Además, guarda la caja original y el embalaje para el
envío del equipo si servicio técnico o devolución de la máquina que se requiere.
Safety and Warranty
RESIDENTIAL USERS: Vendor assumes no liability for parts or labor coverage for component failure
or other damages resulting from installation in non-commercial or residential applications. The right
is reserved to deny shipment for residential usage; if this occurs, you will be notied as soon as
possible.
1 YEAR PARTS AND LABOUR WARRANTY

5
Technical Specications
Safety and Warranty
1. Gear change hand lever.
2. Planetary Shaft.
3. Mixer Attachment.
4. Stainless bowl.
5. Power switch.
6. Bowl lift handle.
7. Safety guard.
8. Support Frame.
9. #12 Hub
10. Internal Safety Switch
11. Safety Switch
12. Overload Reset Button
Within the warranty period, contact Omcan Inc. at 1-800-465-0234 to schedule an Omcan authorized
service technician to repair the equipment locally.
Unauthorized maintenance will void the warranty. Warranty covers electrical and part failures, not
improper use.
Please see https://omcan.com/disclaimer for complete info.
WARNING:
The packaging components are classied as normal solid urban waste and can therefore be disposed of
without difculty.
In any case, for suitable recycling, we suggest disposing of the products separately (differentiated
waste) according to the current norms.
DO NOT DISCARD ANY PACKAGING MATERIALS IN THE ENVIRONMENT!

6
Technical Specications
10 QT MIXERS
Model MX-CN-0010-G
Power 0.67 HP / 0.5 kW
Shaft RPM 108 1st | 195 2nd | 355 3rd
Capacity 9.5 L / 10 QT
Timer No
Guard Yes
Electrical 110V / 60Hz / 1
Packaging Weight 181 lbs. / 82.1 kgs.
Dimensions 20” x 15.5” x 24.5” / 508 x 394 x 622mm
Packaging Dimensions 22” x 18” x 29” / 559 x 457 x 737mm
Item Number 20467
20 QT MIXERS
Model MX-CN-0020-G MX-CN-0020-T
Power 1.5 HP / 1.12 kW
Shaft RPM 108 1st | 195 2nd | 355 3rd
Capacity 18.9 L / 20 QT
Timer No Yes
Guard Yes
Electrical 110V / 60Hz / 1
Packaging Weight 262 lbs. / 118.8 kgs.
Dimensions 21.5” x 16” x 30.5” / 546 x 406 x 775mm
Packaging Dimensions 25” x 22” x 35” / 635 x 559 x 889mm
Item Number 20441 17835
30 QT MIXERS
Model MX-CN-0030-G MX-CN-0030-T
Power 2 HP / 1.5 kW
Shaft RPM 91 1st | 166 2nd | 282 3rd
Capacity 29.4 L / 30 QT
Timer No Yes
Guard Yes
Electrical 110V / 60Hz / 1
Packaging Weight 433 lbs. / 196.8 kgs.
Dimensions 23.5” x 21” x 44.5” / 597 x 533 x 1130mm
Packaging Dimensions 29” x 26” x 50” / 737 x 660 x 1270mm
Item Number 20442 17836

7
Installation
UNCRATING
Immediately after uncrating the mixer, check for possible shipping damage. If the machine is found to be
damaged after uncrating, save all packaging materials and contact the carrier within 3 days of delivery. Failure
to contact the carrier or supplier in a timely fashion may cause you a loss.
LOCATION
Prior to installation, test the electrical service to assure that it agrees with the specications on the machine’s
rating plate. Place the mixer on a sturdy and level surface. There should be adequate space around the mixer
for the user to operate the controls and to install and remove the bowls. Holes are located in the base to
permanently secure the mixer, although this is not necessary in normal installations.
ELECTRICAL CONNECTIONS
The electrical cords on these machines are equipped with a three-pronged grounding plug, which must be
connected to a properly grounded receptacle. If the receptacle is not properly grounded, contact an electrician.
DO NOT remove the grounding prong from the plug. Electrical and grounding connections must comply with
the applicable regulations and local electrical codes.
Check Initial Operation
1. Install the bowl and raise into the mix position, with the bowl support up and bowl safety guard closed.
2. Apply power to the mixer by inserting the cord plug into a properly grounded outlet.
3. Turn the Speed Lever to position 1.
4. Run the machine by pushing the START and then the STOP buttons.
Operation
WARNING
Moving agitator in bowl. Keep hands, clothing and utensils out of bowl while in operation. Do not use
without interlocked safety guard.
WARNING: DO NOT SWITCH GEARS DURING USAGE.
The Omcan mixers are equipped with Standard Safety features. Refer to the diagram on page 3 for an
explanation of their functions. The bowl safety guard must be in the closed position or the mixer will not
operate. The bowl must be raised and remain in mixing position on bowl support or the mixer will not operate.
1. Standard power supply 110V / 60Hz AC. (Please use a plug with 3 wide contacts and good grounding.)
2. Speed transformation: if you want to change the speed, please turn off the power switch (5) rst, and then

8
Operation
pull the gear change hand lever (1) to the position required.
3. Shutting down: when the operation is completed, turn off the power switch (5) rst, then pull the gear
change hand lever (1) to position 1, and lower bowl to load position (6), and nally disconnect the power
supply.
NOTES
• The power socket must be provided with a good ground wire to guarantee the mixer is grounded properly.
There will be an electric shock if there is no ground wire or if it is improperly mounted. Never connect the
ground wire to gas pipes, water pipes, lightning rods or telephone lines. Electric leakage should be checked
after installation. If the power line is damaged, it must be replaced by the a Service Company.
• Do not put your hand into the stirring barrel during operation. Disconnect the power supply before the
installation of the mixer.
• Do not operate the mixer beyond the time limit to prevent reduction of its service life.
• The mixer should be mounted on a stable and clean place, keep it away from heat sources and wet places,
and away from equipment with strong electromagnetic properties.
• Keep the machine clean constantly. Disconnect power supply before maintenance. Clean machine with a
soft damp cloth. Do not clean it with water spray or use harsh detergents.
On/Off Switch - MX-CN-0010-G
Features:
1. Standard Controls
On/Off Switch - MX-CN-0020-T
Features:
1. On Button
2. Off Button
3. Countdown Timer Knob
1
1
2
3

9
Operation
On/Off Switch - MX-CN-0020-G
Features:
1. On Button
2. Off Button
On/Off Switch - MX-CN-0030-T
Features:
1. Separate On and Off Switches
2. Countdown Timer Knob
3. Speed Adjusting Lever with Handle
On/Off Switch - MX-CN-0030-G
Features:
• On Button
• Off Button
• Speed Adjusting Lever with Handle
1
2
3
1
23
1
2

10
Operation
Installing Mixer Bowls - All Models
1. Place the bowl on the two arms to keep it in place. Insert the bowl pin into pin support located on frame.
Carefully align holes on the bowl with the studs on the bowl arms. (Fig.1)
2. Once the bowl is seated properly, swing the locking levers into position. (Fig.2)
3. To remove the bowl, follow the instructions above in reverse order.
Fig.1
MX-CN-0010-G / 0020-T / 0020-G
MX-CN-0030-T / 0030-G
Fig.2

11
Operation
Installing Mixer Attachments - MX-CN-0020-T / MX-CN-0020-G
Ensure machine is off, lower bowl to loading position. Open the Guard by pulling the handle away from
the magnetic latch. (Fig.6) Raise the attachment over the shaft, keeping note of where the notch is. (Fig.7)
Guide the notch through the path until it reaches the end and locks. (Fig.8) To remove attachment, follow the
instructions above in reverse order.
Fig.6 Fig.7 Fig.8
Installing Mixer Attachments - MX-CN-0030-T / MX-CN-0030-G
Ensure machine is off, lower bowl to loading position. Open the Guard by lifting it up towards the top of the
machine until it stops. (Fig.9) Raise the attachment through the shaft, keeping note of where the notch is.
(Fig.7) Guide the notch through the path until it reaches the end and locks. (Fig.8) To remove attachment,
follow the instructions above in reverse order.
Installing Mixer Attachments - MX-CN-0010-G
Ensure machine is off, lower bowl to loading position. Keep note of the notch on the shaft (Fig.3) and raise the
attachment over the shaft. (Fig.4) Turn the attachment to the left until you can turn no more (Fig.5) and release,
the attachment should now dip down a bit and lock in place. To Remove the attachment, follow the instructions
above in reverse order.
Fig.3 Fig.4 Fig.5

12
Fig.9
Maintenance
Operation
Clean the bowl and attachments daily or after use to maintain hygiene standards. Clean the mixer with a soft
wet cloth. The transmission gear box is greased in factory. Check the greasing each 6 months. To add or rell
grease, open the top cover, then ll grease from aperture or replace the grease directly. Ensure guide rails are
kept clean and lubricated.
Troubleshooting
Problems Causes Solutions
Planetary does not rotate after
starting the machine
Loose electric wiring Check electric wiring tighten any
loose connections. Press reset
button.
Oil leakage The seal rings are worn out Replace seal rings

13
Troubleshooting
Motor temperature raises while
reduced output speed
Too low voltage Check the power supply
Over-loaded Reduce load
The speed of mixing is too high, or
wrong attachment is being used, or
mixing too long.
Select a suitable speed and
attachment. Reduce load.
The mixing knocks with the bowl The attachment or bowl is
deformed
Repair of replace the attachment
or bowl
Abnormal noise and high
temperature from gearbox
Insufcient lubrication Add or replace the grease
Bowl lift is difcult to pull up Guide rails are not lubricated. Lubricate guide rails.
WARNING!
If the equipment is out of function, please make sure it is serviced by a professional person. Please turn to a
special service centre!
For parts or service call 1-800-465-0234.

14
Mixer Capacity Chart
AGITATORS
SUITABLE
FOR
OPERATION
ALLOWABLE
AGITATOR
SPEEDS
0010-G
0020-G 0030-G
0020-T 0030-T
PRODUCT
CAPACITY OF BOWL (QTS. LIQUID) 10 20 30
Egg Whites Whip 1, 2, 3 1 1/2 pts 1 qt 1.5 qt
Mashed Potatoes Beater 1,2 8 lbs 12 lbs 20 lbs
Mayonnaise (Qts of Oil) Whip 1, 2 4 1/2 qts 10 qts 12 qts
Meringue (Qty. of Water) Whip 1, 2, 3 1/2 pts 3/4 pts 1 qt
Wafe or Hot Cake Batter Whip 1,2 5 qts 8 qts 12 qts
Whipped Cream Whip 1, 2, 3 2 1/2 qts 4 qts 6 qts
Cake, Box or Slab Beater 1,2 8 lbs 16 lbs 22 lbs
Cake, Cup Beater 1,2 8 lbs 16 lbs 22 lbs
Cake, Layer Beater 1,2 8 lbs 16 lbs 22 lbs
Cake, Pound Beater 1,2 8 lbs 16 lbs 22 lbs
Cake, Short (Sponge) Beater 1,2 6 lbs 12 lbs 16 lbs
Cookies, Sugar Beater 1,2 8 lbs 12 lbs 16 lbs
Dough, Bread or Roll (Lt.-Med.) 60% AR Hook 1 8 lbs 16 lbs 20 lbs
Dough, Heavy Bread 55% AR ** Hook 1 6 lbs 12 lbs 16 lbs
Dough, Pie Hook 1 8 lbs 14 lbs 20 lbs
Dough, Thin Pizza 40%(max mix time is 5 min.)*** Hook 1N/R N/R 10 lbs
Dough, Med. Pizza 50% AR Hook 1N/R N/R 12 lbs
Dough, Thick Pizza 60% AR Hook 1N/R 10 lbs 14 lbs
Dough Raised Donut 65% AR Hook 1N/R 6 lbs 10 lbs
Dough, Whole Wheat 70% AR Hook 1 6 lbs 10 lbs 16 lbs
Icing, Fondant Beater 1 5 lbs 9 lbs 14 lbs
Shortening & Sugar, Creamed Beater 1 7 lbs 12 lbs 18 lbs
Pasta, Basic Egg Noodle Hook 1 1 lbs 3 lbs 6 lbs
pts - Pints (US Liquid) ● qts - Quarts (US Liquid) ● lbs - Pounds (US Weight) ●N/R - Not Recommended
The following maximum capacities are intended as a guideline only, varying factors such as the type of our
used, temperature of water used, and other conditions may require the batch to be reduced. (1 gallon of water
weighs 8.33 lbs.)
NOTE: AR% = (Absorption Ratio % - water weight divided by our weight) The mixer capacity depends on the
moisture content of the dough. The capacities mentioned above are based on our at room temperature and
70°F water temperature. If high gluten our is used, reduce above dough batch size to 10% If using chilled
our, water below 70°F, or ice, reduce batch size by 10% 2nd speed should never be used on 50% AR

15
Parts Breakdown
Model MX-CN-0010-G 20467

16
Parts Breakdown
Model MX-CN-0010-G 20467
Item No. Description Position Item No. Description Position Item No. Description Position
25061 Wire Whip for 20467 1 24985 Plug Cover (Steel) for 20467 32 25123 Gear for 20467 60
25062 Hook for 20467 2 25714 Nut 14x1.5 for 20467 33 25124 Ring for 20467 61
25063 Spring for 20467 3 25094 Control Nut for 20467 34 25125 Bearing for 20467 62
25064 Pin Shaft for 20467 4 25095 Declutch Shift Shaft for 20467 35 25126 Shaft Worm Gear for 20467 63
25065 Shifting Yoke for 20467 5 25096 Spring Washer for 20467 36 24915 Circlips for Shaft for 20467 64
25066 Flat Beater for 20467 6 25097 Gear for 20467 37 25128 Worm Gear for 20467 65
25067 Gear (Comes with Elastic Ring) for 20467 7 24893 Spring Washers for 20467 38 25125 Bearing for 20467 66
25068 Nut for 20467 8 25099 Support for 20467 39 25131 Back Guard for 20467 68
25069 Lining Ring for 20467 9 25100 Bearing for 20467 40 25132 Worm Pole for 20467 69
25070 Bearing for 20467 10 25101 Spindle Boring Cover for 20467 41 25133 Back Cover for 20467 70
24867 Speed Handle for 20467 11 25102 Big Gear for 20467 42-1 25134 Motor Box for 20467 71
25072 Handle Shaft for 20467 12 25103 Gear for 20467 42-2 25135 Crank Lever for 20467 72
25073 Bushing for 20467 13 25104 Roller for 20467 42-3 25136 Handle for 20467 73
25074 Oil Seal for 20467 14 24880 Spring for 20467 42-4 25137 Connecting Rod for 20467 74
24870 Tighten Handle for 20467 15 25106 Taper Gear Wheel 1 for 20467 43 25138 Stand Column for 20467 75
25076 Block Handle for 20467 16 25107 Motor for 20467 44 25139 Spring for 20467 76
24865 Handle Shifter Cover for 20467 17 25108 Combination of Gear for 20467 45 24939 Spacer for 20467 77
24967 Plug for 20467 18 25109 Bushing for 20467 46 24883 Nut for 20467 78
25079 Cam-Gear Shifter for 20467 19 25110 Claw Type Clutch for 20467 47 24908 Press Board for 20467 79
25080 Attachment Hub for 20467 20 25111 Inner Gear for 20467 48 25143 Brand for 20467 80
25081 Taper Gear Wheel 1 for 20467 21 25112 Gear Box for 20467 49 24922 Green Button Round for 20467 81
25082 Circlips for Shaft for 20467 22 25113 Support for 20467 50 24924 Red Button Round without Timer for
20467 82
25083 Planetary Gear for 20467 23 25114 Base for 20467 51 25146 Run Capacitor 20 UF for 20467
25084 Bearing for 20467 24 25115 Retainer-Spring for 20467 52 25147 Start Capacitor 100 UF for 20467
25085 Operating Shelf for 20467 25 24911 Nut for 20467 53 24944 Contactor-Relay for 20467
25086 Safety Guard for 20467 26 24882 Ring for 20467 54 25149 Power Cord for 20467
25087 Working Shaft for 20467 27 25118 Gear Shaft for 20467 55 25150 Reset-Overload Switch for 20467
25006 Bearing for 20467 28 25119 Key for 20467 56 25151 Safety Guard-Bowl Micro Switch for
20467
25089 Oil Seal for 20467 29 24898 Circlips for Shaft for 20467 57 25152 Timer Knob for 20467
25090 Bowl for 20467 30 25121 Gear for 20467 58
25091 Cover for 20467 31 25122 Bushing for 20467 59

17
Parts Breakdown
Model MX-CN-0020-G 20441
Model MX-CN-0020-T 17835

18
Parts Breakdown
Model MX-CN-0020-G 20441
Model MX-CN-0020-T 17835
Item No. Description Position Item No. Description Position Item No. Description Position
25153 Wire Whip for 20441, 17835 1 25070 Bearing 6204 for 20441, 17835 33 24924 Red Button Round without Timer for
20441, 17835 67
25154 Dough Hook for 20441, 17835 2 24890 Oil Seal for 20441, 17835 34 24925 Red Button with Timer for 20441, 17835 67
25155 Flat Beater for 20441, 17835 3 24891 Working Shaft for 20441, 17835 35 24926 Brand for 20441, 17835 68
25156 Safety Guard for 20441, 17835 4 24892 Retainer-Pin for 20441, 17835 36 24927 Motor Box for 20441, 17835 69
25157 Bowl for 20441, 17835 5 24893 Spring Washers for 20441, 17835 37 24928 Key for 20441, 17835 70
24957 Screw for 20441, 17835 6 24894 Pressing Plate for 20441, 17835 38 24929 Shaft Worm Gear for 20441, 17835 71
24958 Spring for 20441, 17835 7 24895 Transmission Shaft Support for 20441,
17835 39 24930 Gear for 20441, 17835 72
24959 Pin Shaft for 20441, 17835 8 25006 Bearing for 20441, 17835 40 24931 Motor for 20441, 17835 73
24862 Shifting Yoke for 20441, 17835 9 24897 Spacer-Lower for 20441, 17835 41 24932 Back Housing for 20441, 17835 74
24863 Cam-Gear Shifter for 20441, 17835 10 24898 Circlips for Shaft for 20441, 17835 42 24933 Back Cover for 20441, 17835 75
24864 Plate-Shifter Index for 20441, 17835 11 25814 Taper Gear Wheel for 20441, 17835 43 24934 Handle-Shifter for 20441, 17835 76
24865 Handle-Shifter Cover for 20441, 17835 12 24900 Gear for 20441, 17835 44 24935 Crank Lever Q for 20441, 17835 77
24866 Handle-Shifter for 20441, 17835 13 24901 Bushing for 20441, 17835 45 24936 Connecting Rod for 20441, 17835 78
24867 Speed Handle for 20441, 17835 14 24902 Sleeve for 20441, 17835 46 24937 Stand Column for 20441, 17835 79
24967 Plug for 20441, 17835 15 24903 Claw Type Gear Wheel for 20441, 17835 47 24938 Spacer for 20441, 17835 80
24869 Attachment Hub for 20441, 17835 16 24904 Gasket for 20441, 17835 48 24939 Spacer for 20441, 17835 81
24870 Tighten Handle for 20441, 17835 17 24905 Bearing for 20441, 17835 49 24940 Spring for 20441, 17835 82
24871 Ring for 20441, 17835 18 24906 Bushing for 20441, 17835 50 24941 Hood Ring for 20441, 17835 83
24872 Tapered Gear Wheel for 20441, 17835 19 24907 Oil Seal for 20441, 17835 51 16323 Run Capacitor - 40 UF for 20441, 17835
24873 Top Cover for 20441, 17835 20 24908 Press Board for 20441, 17835 52 24943 Start Capacitor - 300 UF for 20441,
17835
25714 Nut 14x1.5 for 20441, 17835 21 24909 Support for 20441, 17835 53 24944 Contactor-Relay for 20441, 17835
24875 Pressing Plate for 20441, 17835 22 24910 Base for 20441, 17835 54 24945 Power Cord for 20441, 17835
24985 Plug Cover (Steel) for 20441, 17835 23 24911 Nut for 20441, 17835 55 25204 Magnet for Safety Guard for 20441,
17835
24877 Big Gear for 20441, 17835 24-1 24912 Bearing 6201 for 20441, 17835 56 24946 Reset-Overload Switch for 20441, 17835
24878 Gear for 20441, 17835 24-2 24913 Mid-Gear Wheel for 20441, 17835 57 25202 Bowl Guard Clip Plastic for 20441,
17835
24879 Roller 8x15 for 20441, 17835 24-3 24914 Key for 20441, 17835 58 25203 Knob for 20441, 17835
24880 Spring for 20441, 17835 24-4 24915 Circlips for Shaft for 20441, 17835 59 24947 Safety Guard - Bowl Switch for 20441,
17835
24881 Declutch Shift Shaft for 20441, 17835 25 24916 Gear for 20441, 17835 60 25205 Screw for 20441, 17835
24882 Ring for 20441, 17835 26 24917 Bushing for 20441, 17835 61 25152 Timer Knob for 20441, 17835
24883 Nut for 20441, 17835 27 24918 Gear for 20441, 17835 62 64156 Locking Screws of Press Board for
20441, 17835
24884 Main Shaft for 20441, 17835 28 24919 Plug Cover for 20441, 17835 63 AC907 Bowl Locating Pin for 20441, 17835
24885 Gear Box for 20441, 17835 29 25013 Worm Wheel for 20441, 17835 64 69760 Top Cover Screw M6x30 for 20441,
17835
24886 Internal Gear for 20441, 17835 30 24921 Oil Seal for 20441, 17835 65 69761 Top Cover Screw M6x40 for 20441,
17835
24887 Gear for 20441, 17835 31 24922 Green Button Round for 20441, 17835 66
24888 Operating Shelf for 20441, 17835 32 24923 Green Button with Timer for 20441,
17835 66

19
Parts Breakdown
Model MX-CN-0030-G 20442
Model MX-CN-0030-T 17836

20
Parts Breakdown
Model MX-CN-0030-G 20442
Model MX-CN-0030-T 17836
Item No. Description Position Item No. Description Position Item No. Description Position
24951 Dough Hook for 20442, 17836 1 24987 Spacer-Lower for 20442, 17836 37 25024 Brass Gear-New Style 28 Teeth for
20442, 17836 70
24952 Beater for 20442, 17836 2 24988 Big Gear for 20442, 17836 38-1 25026 Gear for 20442, 17836 71
24953 Wire Whip for 20442, 17836 3 24989 Gear for 20442, 17836 38-2 25027 Gasket for 20442, 17836 72
24954 Safety Guard for 20442, 17836 4 24990 Roller for 20442, 17836 38-3 25028 Plug 1 for 20442, 17836 73
24955 Bowl for 20442, 17836 5 24880 Spring for 20442, 17836 38-4 25029 Nut for 20442, 17836 74
24956 Top Cover for 20442, 17836 6 24992 Gear for 20442, 17836 39 25030 Spring Washers for 20442, 17836 75
24957 Screw for 20442, 17836 7 24901 Bushing for 20442, 17836 40 25084 Bearing for 20442, 17836 76
24958 Spring for 20442, 17836 8 24994 Sleeve for 20442, 17836 41 25032 Shaft Worm Gear for 20442, 17836 77
24959 Pin Shaft for 20442, 17836 9 24995 Gear for 20442, 17836 42 25008 Key for 20442, 17836 78
24960 Shifting Yoke for 20442, 17836 10 24996 Gasket for 20442, 17836 43 25034 Circlips for Shaft for 20442, 17836 79
24863 Cam-Gear Shifter for 20442, 17836 11 24997 Bearing for 20442, 17836 44 25035 Circlips for Shaft for 20442, 17836 80
24864 Plate-Shifter Index for 20442, 17836 12 24998 Bushing for 20442, 17836 45 25036 Plug 2 for 20442, 17836 81
24963 Handle-Shifter for 20442, 17836 13 24999 Oil Seal for 20442, 17836 46 25037 Motor for 20442, 17836 82
24964 Handle Set for 20442, 17836 14 25000 Body Housing for 20442, 17836 47 25038 Rubber for 20442, 17836 83
24965 Turnset for 20442, 17836 15 25001 Bowl Holddown for 20442, 17836 48 24922 Green Button Round for 20442, 17836 84
24966 Speed Handle for 20442, 17836 16 25002 Support for 20442, 17836 49 25040 Red Stop Button without Timer CSA for
20442, 17836 85
24967 Plug for 20442, 17836 17 25003 Spacer for 20442, 17836 50 25041 On/Off Switch/Button with Timer for
20442, 17836 85
24968 Attachment Hub for 20442, 17836 18 25004 Nut for 20442, 17836 51 25042 Crank Lever for 20442, 17836 86
24870 Tighten Handle for 20442, 17836 19 25005 Base for 20442, 17836 52 25043 Handle-Shifter for 20442, 17836 87
24871 Ring for 20442, 17836 20 25006 Bearing for 20442, 17836 53 25044 Connecting Rod for 20442, 17836 88
24971 Gear for 20442, 17836 21 25007 Transmission Shaft Support for 20442,
17836 54 24938 Spacer for 20442, 17836 89
24972 Hood Ring for 20442, 17836 22 25008 Key for 20442, 17836 55 25046 Spring for 20442, 17836 90
24973 Circlips for Shaft Q for 20442, 17836 23 25009 Circlips for Shaft for 20442, 17836 56 25047 Spacer for 20442, 17836 91
24974 Planetary Gear for 20442, 17836 24 25010 Gear for 20442, 17836 57 15559 Angle Iron for 20442, 17836 92
24975 Operating Shelf for 20442, 17836 25 25011 Bushing for 20442, 17836 58 25049 Rail Guide Plater for 20442, 17836 93
24905 Bearing 6205 for 20442, 17836 26 25012 Front Housing for 20442, 17836 59 25050 Run Capacitor 60 UF - New for 20442,
17836
24977 Oil Seal for 20442, 17836 27 25013 Worm Wheel-New for 20442, 17836 60 16323 Run Capacitor 40 UF - Old for 20442,
17836
24978 Pin for 20442, 17836 28 25015 Mark for 20442, 17836 61 25052 Start Capacitor 400 UF for 20442, 17836
24979 Working Shaft for 20442, 17836 29 25016 Case for 20442, 17836 62 25053 Contactor-Relay for 20442, 17836
24980 Declutch Shift Shaft Q for 20442, 17836 30 25017 Back Cover for 20442, 17836 63 25054 Power Cord for 20442, 17836
24939 Spacer for 20442, 17836 31 25018 Internal Gear for 20442, 17836 64 25055 Reset-Overload Switch for 20442, 17836
24982 Main Shaft for 20442, 17836 32 25019 Screw for 20442, 17836 65 24950 Rear Cover Screws for 20442, 17836
24883 Nut for 20442, 17836 33 25020 Seal Up Ring for 20442, 17836 66 24947 Safety Guard-Bowl Switch for 20442,
17836
24984 Top Batter Valve Cap for 20442, 17836 34 25021 Gear Shift for 20442, 17836 67 25152 Timer Knob for 20442, 17836
24985 Plug Cover (Steel) for 20442, 17836 35 25022 Gear for 20442, 17836 68
25070 Bearing 6204 for 20442, 17836 36 25023 Bushing for 20442, 17836 69
