Omcan MM-IT-0180 User manual

Revised - 07/13/2021
Toll Free: 1-800-465-0234
Fax: [phone]
Email: [email protected]
www.omcan.com
Meat Mixer
Model MM-IT-0180
Item 46149
Instruction Manual

2
Page
--------------------------------------------------------------------------- 3 - 4
--------------------------------------------------------------------------- 4 - 7
-------------------------------------------------------------------------- 8
--------------------------------------------------------------------------------------- 8 - 9
--------------------------------------------------------------------------------------- 9 - 11
--------------------------------------------------------------------------------- 11 - 14
----------------------------------------------------------------------------------- 14
----------------------------------------------------------------------------------- 15
---------------------------------------------------------------------------- 16 - 17
---------------------------------------------------------------------------- 18
---------------------------------------------------------------------------- 19
Table of Contents
Section
General Information
Safety and Warranty
Technical Specications
Installation
Operation
Maintenance
Troubleshooting
Figure Drawings
Parts Breakdown
Electrical Schematics
Warranty Registration
Model MM-IT-0180

3
General Information
Omcan Manufacturing and Distributing Company Inc., Food Machinery of America, Inc. dba Omcan
and Omcan Inc. are not responsible for any harm or injury caused due to any person’s improper or
negligent use of this equipment. The product shall only be operated by someone over the age of 18, of
sound mind, and not under the inuence of any drugs or alcohol, who has been trained in the correct
operation of this machine, and is wearing authorized, proper safety clothing. Any modication to the
machine voids any warranty, and may cause harm to individuals using the machine or in the vicinity of
the machine while in operation.
CHECK PACKAGE UPON ARRIVAL
Upon receipt of an Omcan shipment please inspect for external damage. If no damage is evident on the
external packaging, open carton to ensure all ordered items are within the box, and there is no concealed
damage to the machine. If the package has su󰀨ered rough handling, bumps or damage (visible or concealed),
please note it on the bill of lading before accepting the delivery and contact Omcan within 24 hours, so we may
initiate a claim with the carrier. A detailed report on the extent of the damage caused to the machine must be
lled out within three days, from the delivery date shown in the shipping documents. Omcan has no recourse
for damaged products that were shipped collect or third party.
Before operating any equipment, always read and familiarize yourself with all operation and safety
instructions.
Omcan would like to thank you for purchasing this machine. It’s of the utmost importance to save
these instructions for future reference. Also save the original box and packaging for shipping the
equipment if servicing or returning of the machine is required.
---------------------------------------------------------------------------------------------------------------------------------------------------
Omcan Fabrication et distribution Companie Limité et Food Machinery d’Amerique, dba Omcan et
Omcan Inc. ne sont pas responsables de tout dommage ou blessure causé du fait que toute personne
ait utilisé cet équipement de façon irrégulière. Le produit ne doit être exploité que par quelqu’un de
plus de 18 ans, saine d’esprit, et pas sous l’inuence d’une drogue ou d’acohol, qui a été formé pour
utiliser cette machine correctement, et est vêtu de vêtements de sécurité approprié. Toute modication
de la machine annule toute garantie, et peut causer un préjudice à des personnes utilisant la machine
ou des personnes à proximité de la machine pendant son fonctionnement.
VÉRIFIEZ LE COLIS DÈS RÉCEPTION
Dès réception d’une expédition d’Omcan veuillez inspecter pour dommages externes. Si aucun dommage
n’est visible sur l’emballage externe, ouvrez le carton an de s’assurer que tous les éléments commandés
sont dans la boîte, et il n’y a aucun dommage dissimulé à la machine. Si le colis n’a subi aucune mauvaises
manipulations, de bosses ou de dommages (visible ou cachée), notez-le sur le bond de livraison avant
d’accepter la livraison et contactez Omcan dans les 24 heures qui suivent, pour que nous puissions engager
une réclamation auprès du transporteur. Un rapport détaillé sur l’étendue des dommages causés à la machine
doit être rempli dans un délai de trois jours, à compter de la date de livraison indiquée dans les documents
d’expédition. Omcan n’a aucun droit de recours pour les produits endommagés qui ont été expédiées ou cueilli
par un tiers transporteur.

4
Safety and Warranty
General Information
Avant d’utiliser n’importe quel équipement, toujours lire et vous familiariser avec toutes les opérations
et les consignes de sécurité.
Omcan voudrais vous remercier d’avoir choisi cette machine. Il est primordial de conserver ces
instructions pour une référence ultérieure. Également conservez la boîte originale et l’emballage pour
l’expédition de l’équipement si l’entretien ou le retour de la machine est nécessaire.
---------------------------------------------------------------------------------------------------------------------------------------------------
Omcan Empresa De Fabricacion Y Distribucion Inc. Y Maquinaria De Alimentos De America, Inc. dba
Omcan y Omcan Inc. no son responsables de ningun daño o perjuicío causado por cualquier persona
inadecuada o el uso descuidado de este equipo. El producto solo podra ser operado por una persona
mayor de 18 años, en su sano juicio y no bajo alguna inuencia de droga o alcohol, y que este ha sido
entrenado en el correcto funcionamiento de esta máquina, y ésta usando ropa apropiada y autorizada.
Cualquier modicación a la máquina anúla la garantía y puede causar daños a las personas usando la
máquina mientras esta en el funcionamiento.
REVISE EL PAQUETE A SU LLEGADA
Tras la recepcion de un envio Omcan favor inspeccionar daños externos. Si no hay daños evidentes en el
empaque exterior, Habra el carton para asegurararse que todos los articulos solicitados ésten dentro de la
caja y no encuentre daños ocultos en la máquina. Si el paquete ha sufrido un manejo de poco cuidado, golpes
o daños (visible o oculto) por favor anote en la factura antes de aceptar la entrega y contacte Omcan dentro
de las 24 horas, de modo que podamos iniciar una reclamación con la compañia. Un informe detallado sobre
los daños causados a la máquina debe ser llenado en el plazo de tres días, desde la fecha de entrega que se
muestra en los documentos de envío. Omcan no tiene ningun recurso por productos dañados que se enviaron
a recoger por terceros.
Antes de utilizar cualquier equipo, siempre lea y familiarizarse con todas las instrucciones de
funcionamiento y seguridad.
Omcan le gustaría darle las gracias por la compra de esta máquina. Es de la mayor importancia para
salvar estas instrucciones para futuras consultas. Además, guarda la caja original y el embalaje para el
envío del equipo si servicio técnico o devolución de la máquina que se requiere.
ATTENTION!
To help give clear explanations, some of the diagrams given in this manual show the appliance or part of
it without panels or casing. Do not use the appliance in these conditions. It must only be used when all of
the safety protections are correctly mounted and functional. The manufacturer prohibits reproduction of this
manual and or part of it and the contents cannot be used otherwise than herein specically permitted. In case
of violation the manufacturer has the right to take proceedings.

5
Safety and Warranty
WARRANTY
The end user for no reason whatsoever is authorized to tamper with the appliance. If there are any problems
with the appliance, contact the manufacturer. Any attempt at dismantling, modifying or tampering with the
appliance or part of it will immediately null and void the warranty and the manufacturer will no longer be held
responsible for damage / injuries to persons or things caused by tampering. The manufacturer will not be held
responsible for the following conditions:
• Incorrect installation.
• Incorrect use of the appliance by untrained sta󰀨.
• Used not respecting the standards and laws in force of the country.
• Lack of or insu󰀩cient and incorrect maintenance.
• Use of non-original spare parts and non-specic parts for the various models.
• Total or partial non-observance of the instructions given.
This appliance is designed and manufactured for mixing meats for pre-packed food products. It is to be used in
industrial environments and by sta󰀨 who have carefully read this manual before use. As this mixer is designed
for mixing meat there are no particular environmental requirements. However, it is advisable to locate this
appliance in closed environments protecting it from the weather and sudden changes in temperature. All the
models are provided with braking wheels. The machine is designed for NON-continuous use: after every work
cycle, we recommend leaving the machine to rest for a few minutes before using it again.
ATTENTION!
The size of the pieces to be mixed must be contained in the mixing drum, must not stick out over the rim and
must never exceed 396.8 lbs. / 180 kgs.
NON-PERMITTED USES
The mixer must only be used for the uses given by the manufacturer, and in particular:
• Do Not use the appliance for mixing food other than meat.
• Do Not use the appliance if it has not been correctly installed with all the protections correctly mounted
avoiding any hazardous risk of injury.
• Do Not use nor store the machine inside a cold room: this could seriously damage the electrical
components sensitive to condensate (which forms at low temperatures) and also alter the viscosity of
the grease and/or lubricating oil in the gearboxes and cogs inside it, jeopardizing the machine’s correct
operation and causing potential failures.
• Do Not touch any of the electrical parts without having rst disconnected the appliance from the electricity
supply: there is risk of electrocution.
• Do Not mix quantities that cannot be contained in the mixing drum.
• Do Not wear clothing that does not conform with the accident prevention regulations.
Ask your employer regarding safety regulations and accident prevention clothing.
• Do Not turn on the appliance if faulty or out of service. Before using the appliance make sure any
hazardous working conditions have been eliminated. If there is a fault or problem with the appliance
immediately turn it o󰀨 and inform the maintenance team.
• Do Not permit unauthorized sta󰀨 to use the appliance. In case of an electrical accident the rst thing to do
is to pull the injured worker away from the appliance (normally in this situation the worker is unconscious).

6
Safety and Warranty
However, be very careful as this is very dangerous. The injured worker in this situation is an electricity
conductor and touching him / her means being electrocuted. It is important to disconnect the electricity
supply by disconnecting the fuse box and if this is not possible use an insulated object or material (wooden
or PVC stick, fabric, leather, etc...)to pull the injured worker away. Immediately call the nearest health and
safety associate so the injured worker is admitted to hospital for treatment.
• Do not use the appliance in environments where there is gas in the atmosphere creating a high risk of
combustion (explosion).
• Do not repair the appliance without prior authorization.
• Always respect the procedures for maintenance and technical assistance.
PROTECTIONS AND SAFETY FEATURES
ATTENTION
Before using the appliance make sure the safety protections are in their correct position and intact. Check they
function correctly before starting work (at the beginning of a new work shift). If there are problems contact the
maintenance team.
1. Rotor protection grill. This safety feature impedes incidental contact with the rotor. (Fig. 1.8.1).
2. Micro-switch (Fig. 1.8.1).
3. Knob to lock tank.
4. Ball grip for locking the rotor in position.
ATTENTION!
Do Not for any reason tamper with the safety features.
DANGER AND WARNING NOTICES
ATTENTION
When the appliance is connected to the electricity supply do not touch any of the electrical parts. There is
the risk of being electrocuted. Always respect the information given on the warning notices. Non- observance
can cause injuries or even death. Make sure the warning notices are always in their correct position and are
legible. If for some reason they are missing or are illegible x them to the appliance or replace them.
WORK POSITION
The correct work position for using the appliance is shown in Fig. 1.10.1.
ENVIRONMENT
The appliance is designed for working in the following environment:
• Minimum environment temperature: 5°C / 41°F.
• Maximum environment temperature: +40°C / 104°F.
• Humidity: 50% at 40°C / 104°F.
LIGHTING
Where the mixer is located there should be enough natural light and articial light conforming with the local
regulations. In any case, the lighting must always conform with the regulations of the country of destination and
should not create dangerous reections. The lighting must permit the worker to clearly read the control panel

7
Safety and Warranty
and clearly identify the start and stop buttons.
VIBRATIONS
The vibrations generated by the appliance are not signicant.
ACCIDENT PREVENTION PROTECTIONS
Specic equipment is not necessary. It is advisable to use suitable rubber gloves for handling food products
and that conform with the accident prevention regulations.
RESIDENTIAL USERS: Vendor assumes no liability for parts or labor coverage for component failure
or other damages resulting from installation in non-commercial or residential applications. The right
is reserved to deny shipment for residential usage; if this occurs, you will be notied as soon as
possible.
1 YEAR PARTS AND LABOUR BENCH WARRANTY
Within the warranty period, contact Omcan Inc. At 1-800-465-0234 to schedule a drop o󰀨 to either
an Omcan authorized service depot in the area, or to an Omcan Service warehouse to repair the
equipment.
Unauthorized maintenance will void the warranty. Warranty covers electrical and part failures, not
improper use.
Please see https://omcan.com/disclaimer for complete info.
WARNING:
The packaging components are classied as normal solid urban waste and can therefore be disposed of
without di󰀩culty.
In any case, for suitable recycling, we suggest disposing of the products separately (di󰀨erentiated
waste) according to the current norms.
DO NOT DISCARD ANY PACKAGING MATERIALS IN THE ENVIRONMENT!

8
Installation
ATTENTION
The work surface or area where the appliance is to be installed must be horizontal and solid guaranteeing
stability and safety. When installing the appliance bear in mind that amp space must be left around the
appliance. This space allows you to work freely with the appliance and allows easy access when servicing or
repairing it. Provide suitable lighting around the appliance for the worker using the meat mixer.
INSTALLING
To move the package use a fork-lift truck or similar means. The appliance is in a carton box and packed on a
pallet.
• Remove the two plastic straps that hold the carton box to the pallet.
• Remove the carton box.
• Remove the cellophane wrapping and any other packaging materials.
DISPOSING OF PACKAGING
Packaging materials such as carton, nylon and wood are all products considered normal urban waste. These
materials can be disposed of as per normal procedures. If the appliance is destined to countries where there
are specic waste laws, dispose of packaging conforming with the local laws in force.
HANDLING APPLIANCE
As the following have wheels they can be manually moved by pulling.
Technical Specications
Model MM-IT-0180
Power (2x) 1100 W / 0.75 HP
Electrical 220V / 60Hz / 3
Tank Dimensions 39.2” x 21.7” / 995 x 550mm
Capacity 396.8 lbs. / 180 kgs.
Dimensions 56” x 27.6” x 47.6” / 1422 x 700 x 1209mm
Maximum Overall
Height 67.6” / 1717mm
Packaging Dimensions 57.1” x 29.5” x 51.2” / 1450 x 750 x 1300mm
Packaging Weight 440.9 lbs. / 200 kgs.
Item Number 46149

9
Installation
Operation
CONNECTING TO ELECTRICITY SUPPLY
ATTENTION!
Check the electricity supply corresponds to the value given on the appliance ID plate. Electrical works can
only be carried out by specialized and authorized sta󰀨 with prior authorization by the person in charge of the
appliance. Connect the appliance to a circuit provided with an e󰀩cient earth socket. If necessary use suitable
extension leads guaranteeing safety. The section (thickness) of the extension lead must be greater than the
appliance power supply cable. This avoids any hazardous overheating. Avoid pulling or twisting the power
cable as this can damage the internal wires.
The mixer is provided with a 2.5 m power supply cable. This cable has a 4x1,5 mm section (thickness).
Connect the power cable to a three-phase electricity supply and connect a suitable thermo-magnetic
di󰀨erential switch. Always connect the ground cable.
MOUNTING UTENSILS
To mount the utensil (mixing blades) invert the procedure described in the foregoing paragraph and make sure
the mixing blades are mounted correctly. To facilitate this operation there are numbers stamped on the mixing
blades and on the pins on the inside of the bowl. The number on the blade must correspond to the number on
the pin. Once the mixing blades have been mounted close the grille.
LIST OF CONTROLS AND INDICATORS (FIG. 4.1.2)
1. Drive push-button (continuous).
In stainless steel.
Press to start the blade.
2. Stop push-button.
Press to stop the propeller transmission motor.
3. Reverse drive push-button.
In stainless steel.
Press to start the blade in opposite direction to pus-button “1”.
4. Network presence indicator light.
Signals that the machine is connected to the electrical network.
5. Drive indicator light.
Signals that the tool of the machine is in movement.
Located close to the start push-button “3” and close to the reverse drive push-button “3”.
Visible only when the control is operating.

10
Operation
TURNING THE APPLIANCE ON AND OFF
CHECKING CONNECTION TO ELECTRICITY SUPPLY (FIG. 4.1.2)
1. Switch the on/o󰀨 switch on the appliance to position “I”.
2. Press push button “1” for starting.
3. The indicator light “4” should come on.
4. Then immediately press push button “2” for stopping. This is to check that the appliance works correctly.
5. Press push button “3” for starting.
6. The indicator light “5” should come on.
7. Checking that the rotor rotates in an opposite direction to before.
8. Press push button “2” for stopping.
CHECKING PROTECTIONS AND SAFETY FEATURES AND THEIR EFFICIENCY
1. Rotor Protection grille (Fig. 5.2.1)
Visually check that the protection grille is intact.
2. Micro-switch (Fig. 5.2.1)
With the appliance running, check that it automatically stops when the protection grille is raised. If this is
not the case contact you local authorized dealer or the manufacturer.
ATTENTION!
If the previously mentioned safety protections and casing are not intact, are damaged, missing or work
incorrectly, turn the appliance o󰀨 and contact Omcan assistance to repair the appliance.
TURNING ON THE APPLIANCE (FIG. 4.1.2)
• Switch the power on/o󰀨 switch from position “0” to “I”.
• Press push button “1” for starting the rotor.
TURNING OFF THE APPLIANCE (FIG. 4.1.2)
To stop the appliance press push button “2” (stops the electric motor), the indicator light “4” will go out. Switch
the power on/o󰀨 switch to position “0” turning o󰀨 the power supply.
INVERSION (FIG. 4.1.2)
To invert rotor rotation press push button “3”.
Note: When a work shift is over always switch the on/o󰀨 power switch to position “0”.
USING THE MACHINE
RULES
ATTENTION!
Only authorized sta󰀨 can use the appliance. Before use the worker must make sure that all the protections
are in place and work correctly. If this is not the case, turn the appliance o󰀨 and contact the maintenance
team. Make sure there is su󰀩cient lighting for clear and good visibility. Carry out several practice runs, without
any food product, assisted by specialized sta󰀨 to become familiar with the appliance so as to work in safe
conditions.

11
Operation
Maintenance
HOW TO USE THE MIXER
With the on/o󰀨 switch in position “0” ll the mixer. The food product to be mixed must be contained within the
mixing drum and must not exceed the consented weight. Close the grill and start the mixer.
NOTE
To preserve the freshness and integrity of the meat, we recommend working the meat at a maximum
temperature of 7°C / 44.6°F and terminating the process within 10 minutes. Once the meat has been
processed, thoroughly clean all the machine parts. After every work cycle, we recommend leaving the mixer to
rest for a few minutes before using it again. The machine is not designed for working inside a cold room: this
could seriously damage the electrical components sensitive to condensate (which forms at low temperatures)
and also alter the viscosity of the grease and/or lubricating oil in the gearboxes and cogs inside it, jeopardizing
the machine’s correct operation and causing potential failures.
AUTOMATIC USE (FIG. 4.1.2)
AUTOMATIC MIXER
1. Press the drive push-button “1”: the blades will start turning and the indicator light “4” will go on.
2. Press the reverse drive push-button “3”: the indicator light “5” will start ashing. After 30 seconds, the
machine will automatically reverse drive. Every 30 seconds it will invert blade rotation. After 2 minutes (4
cycles) the machine will automatically stop.
AUTOMATIC SWITCH-OFF
1. Press the drive push-button “1”: the blades will start turning and the indicator light “4” will go on.
2. Press the drive push-button “1” again. After 1 minute, the machine will automatically stop. The same
sequence can be run in reverse drive.
EMPTYING AND CLEANING
EMPTYING THE MIXING BOWL
Turn o󰀨 the mixer, the on/o󰀨 switch is in position “0” unplug from main power supply. The mixing bowl is
designed to rotate to facilitate emptying.
• With the bowl in a horizontal position grip the handle on the bowl titling bar “1” Fig. 6.3.1.
• Pull the tank locking knob “2” Fig. 6.3.1.
• Once having released the mixing bowl rotate (Fig. 6.3.2) by pulling the tilting bar “1” Fig. 6.3.1.
• Open the protection grille “3” Fig. 6.3.2 and empty the bowl.
CLEANING THE MIXING BOWL
With the machine o󰀨 and switch in position “0” and with the plug removed from the socket proceed with
cleaning the bowl. Thanks to the possibility of rotating the bowl cleaning operations are facilitated.
• With the bowl in a horizontal position grip the handle on the bowl titling bar “1” Fig. 6.3.3.

12
Maintenance
• Unhook and remove the pins which lock the mixing blades “2” in position Fig. 6.3.3 and “2” Fig. 6.3.4.
• Unscrew the bowl locking knob “3” anti-clockwise Fig. 6.3.4.
• Once having released the mixing bowl rotate (Fig. 6.3.2) by pulling the tilting bar “1” Fig. 6.3.3.
• Open the grille “4” Fig. 6.3.4 and proceed with removing the mixing blades.
• Make sure the mixing blades are positioned to allow for enough space to remove them Fig. 6.3.5.
• Grip the mixing blades one at a time “5” Fig. 6.3.4 and pull outwards to remove.
• The surface is now smooth and easy to clean Fig. 6.3.6, clean the mixer thoroughly and if necessary
disinfect.
• With a sponge soaked with water and a neutral (pH 7) and non-toxic de-greaser (food grade) clean and
remove any food product left on the mixer and on the mixing blades. Do not use petrol, solvents or other
ammable liquids as detergents; only used authorised non-toxic and non-ammable solvents. Take all the
necessary precautions adopting also appropriate protections required for the cleaning product being used
when cleaning and disinfecting the mixer. Always follow the instructions provided for the cleaning product
being used.
MAINTENANCE
RULES
ATTENTION!
The mixer must always be o󰀨 and the power plug removed from the power socket when servicing and
cleaning. The maintenance area must always be clean, dry and well illuminated. Do not allow unauthorized
sta󰀨 to service the appliance. Do not put parts of your body, hands or arms into the mixer or openings not
protected where there is the risk of being injured. Always use protective clothing (suitable gloves, glasses etc.)
Do not use petrol, solvents or other inammable liquids such as detergents. Use authorised non-toxic and
non-inammable solvents. Do not compressed air to clean the appliance. If it is considered necessary to use
compressed air, use eye protection (glasses) with side protections and limit pressure to a max of 2 atm. (1,9
bar). Do not use a naked ame as lighting when servicing and repairing the appliance.
INTRODUCTION
Regular maintenance and a correct use of the appliance will guarantee a high production rate and safe working
conditions. To guarantee constant e󰀩ciency and to avoid voiding the warranty, always and only use original
spare parts.
CHECKS CARRIED OUT ON OUR PREMISES
The purchased appliance has undergone several factory tests. These tests are:
Before setting to work:
• Check operative tension in the appliance which must correspond to the customer’s requirements.
• Check that there are all the warning plates and notices and the ID plate gives all the correct information
and serial number.
• Check bolt tightening torque.
• Check that the appliance corresponds and conforms with the regulations in force and with what is given in
this manual.
With the appliance running:
• Check e󰀩ciency of all protections and safety features. When the grille is raised the appliance must
automatically stop.

13
Maintenance
• General functional check.
• Repeated tests to make sure the appliance works correctly for its use.
CHECKS AND TESTS TO BE CARRIED OUT WHEN INSTALLING
To make sure the appliance has not been damaged when delivered or when being installed, carry out the
following tests;
Before setting to work:
• Check that the power supply tension corresponds to the value given on the ID plate.
• Check that there are all the warning and ID plates and that they are not damaged.
• Check that the power supply cable is not damaged and is intact.
• Check that the safety features such as the magnetic sensors are intact and not damaged.
Functional checks with the appliance running:
• Check the e󰀩ciency of the protections and safety features. There is the possibility that during transport
these have been damaged or are out of adjustment.
• Carry out several functional tests using pieces of food that are the same size that will be used in normal
working conditions.
PERIODICAL CONTROLS
To maintain reliability and performance in time, as well as proceeding as indicated, it is necessary to carry out
regular tests and checks as follows:
Before each work shift:
• Every day check safety features and protections work correctly.
• Check the power cable is intact.
THE END OF THE WORK SHIFT:
• Carefully clean the appliance removing any traces of food.
• Remove, clean and mount rotor and blades.
CLEANING THE APPLIANCE
At the end of the work shift the appliance must be carefully cleaned and disinfected.
• Stop the appliance and switch the on/o󰀨 switch to “0” and remove the power plug.
• With a sponge soaked with water and suitable neutral de-greasers (non-toxic) remove and clean any traces
of food. Do not use petrol, solvents or other inammable liquids such as detergents. Use authorised non-
toxic and non-inammable solvents. Take suitable precautions when cleaning considering the products
being used. Always follow the instructions for use given.
ATTENTION!
These mixers are designed for mixing meat, therefore for health reasons you are obliged to use non-toxic and
neutral detergents. For hygiene purposes such detergents must be suitable for cleaning components that come
in contact with food.
LUBRICATION (FIG. 7.7.1)
Periodically grease gears “2”.
• Unplug the machine from its power source.
• Take o󰀨 the protective casing “1”.
• Grease the gears using a brush.

14
Maintenance
Troubleshooting
• Reassemble the casing and fasten the screws.
The oil in the transmission reduction gears is long-life and does not need to be ever replaced
REPLACING PARTS
• If you require spare parts contact the manufacturer. Do not use non-original parts. We would like to remind
you that these parts must be replaced and mounted by specialised sta󰀨.
Problem Possible Cause Solution
The appliance does not start. The on / o󰀨 switch is in position 0”. Turn the switch to position “1”.
The grill is raised. Lower the grill.
The microswitch mounted on the
mixing drum does not work.
Contact Omcan.
Either the electric motor or the
command circuit board is faulty.
The controls do not work or the
blades do not change direction.

15
Figure Drawings

16
Parts Breakdown
Model MM-IT-0180 46149

17
Parts Breakdown
Model MM-IT-0180 46149
Item No. Description Position Item No. Description Position Item No. Description Position
AE727 Cot Inox ME 180 Evo BIALB for 46149 1 78634 Knob for 46149 30 62643 Flat Washer DIN 125 D 6 for 46149 54
AE728 Fror Cable 4x1.50 for 46149 2 AE731 Engine Mixing kg.180 BIA HP3 380/60
for 46149 31 62644 Flat Washer DIN 125 D 8 for 46149 55
AE729 Power Cable TF TC BZ Engine for 46149 3 61590 Washer SO 1650 Inox for 46149 32 62645 Flat Washer DIN 125 D 10 for 46149 56
62602 Power Lead, Motor TF/1,5 for 46149 4 61587 Door Support for Microswitch for 46149 33 62646 Elastic Spine DIN 1481 3x18 for 46149 57
61604 Strain Relief + Nut for 46149 5, 8 61569 Boat Stops Crade for 46149 34 62647 Elastic Pin DIN 1481 5x20 for 46149 58
61603 Nut OTT.NICH.PG 11 for 46149 6 61571 Spring for 46149 35 62648 Blind Nut DIN 1587 M5 for 46149 59
62605 Plastic Cable Gland PG7 for 46149 7 61570 Pin for 46149 36 61583 Nut DIN 1587 M6 for 46149 60
62606 PG 11 Plastic Cable Gland for 46149 9 61564 Lever Rod for Container Overturning
for 46149 37 62650 P Nut DIN 1587 M8 for 46149 61
61549 Box GW 44207 for 46149 10 AE732 Shovel IX IP 180kg Double-Shaft for
46149 38 62651 Blind Nut DIN 1587 M12 for 46149 62
61608 Terminal Comb. BZ for 46149 11 AE733 Reducer MRV 063 B14 R = 49 ME for
46149 39 62652 T ES. DIN 439 M10 Basso for 46149 63
37258 Microswitch SO Inox for 46149 12 61605 Ring Gear ME 80 Evo for 46149 40 62653 Feathers DIN 6885 / A 8x7x28 for 46149 64
37260 Magnet M634 for 46149 13 61585 Shaft Support SX Evo BIALB for 46149 41 62654 Feathers DIN 6885 / AB 8x7x16 for
46149 65
AE730 Mascher. Three Puls. Acc. TC-ME H=36
for 46149 14 61588 Motor Cover ME 120 Evo BIALB for 46149 42 62655 Screw TBEI ISO 7380 M6x25 for 46149 66
60396 Stainless Steel On Button with Lamp
for 46149 15 61584 Carter Band Mot. ME 120 Evo BIALB for 46149 43 AE740 Screw Autof.TC + DIN 7981 D 3.5x16 for 46149 67
60397 Stainless Steel Off Button for 46149 16 61600 Base DX Rid. ME 120 Evo BIALB for
46149 44 62657 Screw TSPEI DIN 7991 M8x20 for 46149 68
41224 Circuit Board R3+Autom EQ for 46149 17 61599 Base SX ME 120 Evo BIALB for 46149 45 62658 Screw TSPEI DIN 7991 M8x30 for 46149 69
61586 Bearing 6205 ZZ for 46149 18 61595 Transc. Pin FEMM L=220 M and 120 Evo
for 46149 46 62659 Screw TSP TORX DIN 7991 M6x16 TX30 for 46149 70
61597 Bearing Reg. SP 7205 ME 80 Evo for
46149 19 61598 Transc. Pin MASC L=220 ME 120 Evo for 46149 47 62660 Washer F Wide DIN 9021 D 6x18 for 46149 71
61589 Cap 40/7/C Pulley 1C SO1650 for 46149 20 AE734 Flange Motorid for 46149 48 62661 Hex.Socket Head Cap Screw M6x20
for 46149 72
61596 Gasket 40-62-7 for Mincer for 46149 21 61606 Bracket Lock Gear ME 120 Evo for 46149 49 62662 Screw TE DIN 933 M8x16 T.F. for 46149 73
61610 Zinc Washer M8x30 H4 for 46149 22 62670 B Overload Protection EQ for 46149 50 62663 X.Screw DIN 933 M8x20 for 46149 74
61607 Bushing ME 80 Evo for 46149 23 AE735 Bathtub Lid ME 180 Evo BIALB for 46149 50 62664 Screw TE DIN 933 M10x20 T.F. for
46149 75
61609 Door Screw 10x6x4 ME BA Evo for
46149 24 60080 Screw Poeliers M5x12 for 46149 51 62665 Screw TE DIN 933 M12x30 T.F. for 46149 76
62621 Bush Flange JFM-1622-12 TCM-ME
for 46149 25 AE736 Union Tube Bases ME 180 Evo BIALB for 46149 51 62666 Hex.Nut DIN 934 M8 for 46149 77
66642 Handle New Style/for Side of Container
for 46149 26 60079 Self-Locking Nut ES DIN 982 M5 High for 46149 52 62667 Flathead CSK Screw DIN 963 M5x25 for 46149 78
79656 Knob for Fixing Container for 46149 27 AE737 Female Shovel ME 180 Evo BIAL for
46149 52 62668 Self-Lock Nut ES DIN 982 M6 High for 46149 79
61556 Stainless Steel Non-Swivel.Caster D.100
for 46149 28 AE738 DIN Guide Omega H.7mm L=20mm for 46149 53 62669 Poeliers M4x10 Screw for 46149 80
61579 Mobile Wheel with Brake D 100 C/Perno
for 46149 29 AE739 Male Shovel ME 180 Evo BIALB for 46149 53 60081 Screw Poeliers M6x10 for 46149 81

18
Electrical Schematics
Model MM-IT-0180 46149

19
Warranty Registration
Gracias por comprar un producto Omcan usted. Para registrar su garantía para este producto, complete la información a continuación,
cortar la tarjeta en la perforación y luego enviarlo a la dirección indicada a continuación. También puede registrarse en línea en:
Merci d’avoir acheté un produit Omcan. Pour enregistrer votre garantie pour ce produit, complétez les informations ci-dessous, détachez la
carte au niveau de la perforation, puis l’envoyer à l’adresse spécié ci-dessous. Vous pouvez également vous inscrire en ligne en visitant:
Thank you for purchasing an Omcan product. To register your warranty for this product, complete the information below, tear o󰀨 the card at
the perforation and then send to the address specied below. You can also register online by visiting:
OMCAN
PRODUCT WARRANTY REGISTRATION
3115 Pepper Mill Court,
Mississauga, Ontario
Canada, L5L 4X5
https://omcan.com/warranty-registration/
or email to: [email protected]
Purchaser’s Information
Name: Company Name:
Address:
Telephone:
City: Province or State: Postal or Zip: Email Address:
Country: Type of Company:
Restaurant Bakery Deli
Dealer from which Purchased: Butcher Supermarket Caterer
Dealer City: Dealer Province or State: Institution (specify):
Invoice: Other (specify):
Model Name: Model Number: Serial Number:
Machine Description:
Date of Purchase (MM/DD/YYYY): Date of Installation (MM/DD/YYYY):
Would you like to extend the warranty? Yes No

Por correo en Canadá
Pour postale au Canada
For mailing in Canada
Por correo en los EE.UU.
Pour di󰀨usion aux États-Unis
For mailing in the US
OMCAN
PRODUCT WARRANTY REGISTRATION
4450 Witmer Industrial Estates, Unit 4,
Niagara Falls, New York
USA, 14305
Thank you for choosing Omcan | Merci d’avoir choisi Omcan | Gracias por elegir Omcan

Since 1951 Omcan has grown to become a leading distributor of equipment and supplies to the North
American food service industry. Our success over these many years can be attributed to our commitment
to strengthen and develop new and existing relationships with our valued customers and manufacturers.
Today with partners in North America, Europe, Asia and South America, we continually work to improve
and grow the company. We strive to offer customers exceptional value through our qualied local sales
and service representatives who provide convenient access to over 5,000 globally sourced products.
Depuis 1951 Omcan a grandi pour devenir un des “leaders” de la distribution des équipements et
matériel pour l’industrie des services alimentaires en Amérique du Nord. Notre succès au cours de ces
nombreuses années peut être attribué à notre engagement à renforcer et à développer de nouvelles
et existantes relations avec nos clients et les fabricants de valeur. Aujourd’hui avec des partenaires en
Amérique du Nord, Europe, Asie et Amérique du Sud, nous travaillons continuellement à améliorer et
développer l’entreprise. Nous nous efforçons d’offrir à nos clients une valeur exceptionnelle grâce à
nos ventes locales qualiées et des représentants de service qui offrent un accès facile à plus de 5000
produits provenant du monde entier.
Desde 1951 Omcan ha crecido hasta convertirse en un líder en la distribución de equipos y suministros
de alimentos en América del Norte industria de servicios. Nuestro éxito en estos años se puede atribuir
a nuestro compromiso de fortalecer y desarrollar nuevas relaciones existentes con nuestros valiosos
clientes y fabricantes. Hoy con socios de América del Norte, Europa, Asia y América del Sur, que trabajan
continuamente para mejorar y crecer la empresa. Nos esforzamos por ofrecer a nuestros clientes valor
excepcional a través de nuestro local de ventas y representantes de los servicios que proporcionan un
fácil acceso a más de 5,000 productos con origen a nivel mundial.
