Omega OM-EL-WiFi-TP User manual

e-mail: [email protected]
For latest product manuals:
omegamanual.info
OM-EL-WiFi-TH
Temperature/ Humidity
Data Logger
Extended Warranty
Program
SM
Shop online at
omega.com
User’s Guide
Temperature Data Logger
OM-EL-WiFi-TP

OM-EL-WiFi-TP
WiFi Temperature & Humidity
Data Logging Sensor
ORDERING INFORMATION
WiFi Temperature &
Humidity Data Logging
Sensor
OM-EL-WiFi-TP
Specications liable to change without prior warning Data Sheet - Issue 01 09/2012 S.T.L Applies to OM-EL-WiFi-TP Page 1 of 3
www.omega.com
The OM-EL-WiFi-TP sensor measures the temperature of the environment in which the probe is situated. Data is transmitted wirelessly
via a WiFi network to a PC and viewed using a free software package. During conguration the sensor will search for an existing wireless
network whilst physically connected to the PC. It can then be placed anywhere within range of the network. If the sensor temporarily loses
connectivity with the network, it will log readings until it is able to communicate again with the PC application (max 120 days at 10 second
sample interval). The range of the sensor can be increased by using WiFi extenders.
The probe can be used in a wide range of temperature situations e.g. manufacturing processes, cold storage and hot storage.
This OM-EL-WiFi-TP is a low powered battery device. When congured using typical sampling periods (e.g. once every 60 seconds) the
sensor will operate for over one year. The battery can then be recharged via a PC or USB +5V wall adapter using the USB lead provided.
The software installed on the PC will allow set-up, data logging and data review. Set-up features will include sensor name, °C/°F, sample
rate, and high/low alarms. Once congured, historic data can be viewed via the graphing tool or exported to Excel. This software will be
available for free from www.omega.com.
FEATURES
• Temperature data logging sensor with thermister probe
• WiFi capability and integrated display
• Wireless connectivity to PC via WiFi
• Easy sensor set-up using free PC software
• View and analyse multiple sensors using the PC application, including
immediate graphing of historic data
• Measurement range -40 to +125°C (-40 to +257°F)
• 802.11b compliant
• Capable of logging greater than 1 million data entries
• Sensor memory stores all data even if WiFi is temporarily disconnected
• Main unit IP55, probe IP67
• Rechargeable internal lithium polymer battery
• Congurable high and low alarms with indicator
• Max & Min readings
• Low battery indicator
• WiFi connection indicator
• USB port used for recharging
• Supplied with removable thermister probe, micro USB lead & wall bracket

www.omega.com
Specications liable to change without prior warning Data Sheet - Issue 01 09/2012 S.T.L Applies to OM-EL-WiFi-TP Page 2 of 3
Specications Minimum Typical Maximum Unit
Battery life >1* Year
USB supply voltage 4.5v 5.5v V d.c.
Probe temperature measurement range -40 (-40) +125 (+257) °C (°F)
Internal resolution +/- 0.1 °C
Probe temperature accuracy (overall error) +/- 0.5 +/- 2.0 °C
Probe clip operating temperature range -40 (-40) +100 (212) °C (°F)
Logging rate (user congurable) Every 10s 30 seconds Every 12hrs Transmisson rate
Unit operating temperature range -20 (-4) +60 (+140) °C (°F)
* Typical but could be less if frequent transmissions
Warning - do not exceed operating temperatures
EXAMPLE OF UNIT WHILST PHYSICALLY CONNECTED TO PC DURING SET-UP
HARDWARE
• Battery: Rechargeable via USB connection
• Microcontroller: ARM MCU
• 1x micro USB Type B (bottom of unit) for connection of unit to PC via USB cable supplied.
• Removable probe: 50cm, 304 stainless steel end cap, high temperature exible cable with tight bend radius
This sensor stands alone by itself on a horizontal surface and comes with a wall bracket that can be screwed onto a wall or at surface.
The sensor clips into the bracket.
The sensor is supplied with a thermister probe with an attachment so that the probe can be securely xed to at surfaces.
The probe is removable so alternative probes can also be used to meet specic requirements providing they operate within the same
temperature range.
All OM-EL-WiFi-TP sensors are thoroughly tested pre-release but the sensor may experience compatibility issues with certain WiFi networks.
In this instance we recommend the use of network accessories available on the Omega website.

www.omega.com
Specications liable to change without prior warning Data Sheet - Issue 01 09/2012 S.T.L Applies to OM-EL-WiFi-TP Page 3 of 3
PHYSICAL DIMENSIONS
All dimensions in millimetres (mm)
LCD SCREEN SHOTS
ADDITIONAL FUNCTIONALITY
When the user cycles through to the Recieved Signal Strength Indicator (RSSI) screen the unit automatically transmits a dummy message
every 2 seconds to enable an RSSI reading to be displayed. If there is any outstanding data waiting to be transmitted, this data will be
sent at the same time but if not it’ll just send the dummy message and the next data package will be sent as per the unit conguration.
When on Max or Min screen, holding the button for 3 seconds will clear the stored values.
The sensor can be restarted by holding the button for 10 seconds until the screen blanks and LOW is shown ashing in the top right hand
corner of the display. The sensor will retain all settings but will lose any data that has not been transferred to the PC. The sensor can be
reset to factory state by holding the button for 20 seconds but this will delete all settings and stored data.
Note: neither the restart or the reset will delete data already transferred to your PC.
