PR2000
PR2000
Pressure Data Logger with LCD
Product User Guide

PR2000
2
Table of Contents
To view the full MadgeTech product line, visit our website at madgetech.com.
Quick Start Steps ........................................................ 3
Product Overview ....................................................... 4
Software Installation ..................................................... 5
Device Operation.......................................................... 5
Computer Interface ...................................................... 6
Front Panel Overview.................................................... 7
Screen Descriptions ................................................... 8-9
Maintenance ............................................................. 10
General Specifications................................................ 11

Product User Guide
3
Quick Start Steps
Please refer to the PR2000 Product Manual for full product details by going to
madgetech.com/product-documentation.
1. Install the MadgeTech 4 Software and USB Drivers onto a Windows PC.
2. Wire the data logger with the desired probes.
3. Connect the data logger to the Windows PC with the IFC200 (sold separately).
4. Launch the MadgeTech 4 Software. The pHTemp2000 will appear in the Connected
Devices window indicating the device has been recognized.
5. Select the start method, reading rate and any other parameters appropriate for the
desired data logging application. Once configured, click the Start icon and deploy the
data logger
6. To download data, connect the data logger to the windows PC with the IFC200, select
the device in the list, click the Stop icon, and then click the Download icon. A graph will
automatically display the data.

PR2000
4
Display Overview
Product Overview
The PR2000 is a pressure data logger with LCD display. The device features an IP rating
of 65, which means it is dust proof, and splash proof making it available to be used
outdoors. The convenient LCD provides access to the current pressure reading, as well as
minimum, maximum and average statistics. A trending graph is also displayed of the last
100 readings.
Please refer to the PR2000 Product Manual for full product details by going to
madgetech.com/product-documentation.
LED
Indicators
LCD Screen
Pressure Sensor Power Jack
Communication
Jack
Up Key
Okay Key
Down Key
Cancel Key
Function Keys
Battery Power (Full, Half-full, Empty)
Memory Remaining (Empty, Half-full, Full)
Device is running
Device is stopped
Status Indicators
Delay Start
Wait Icon (device is busy)
Device reset has occurred
External power present

Product User Guide
5
Software Installation
Installing the MadgeTech 4 Software
The MadgeTech 4 Software makes the process of downloading and reviewing data quick
and easy, and is free to download from the MadgeTech website.
1. Download the MadgeTech 4 Software on a Windows PC by going to:
madgetech.com/software-download.
2. Locate and unzip the downloaded file (typically you can do this by right clicking on the
file and selecting Extract).
3. Open the MTInstaller.exe file.
4. You will be prompted to select a language, then follow the instructions provided in the
MadgeTech 4 Setup Wizard to finish the MadgeTech 4 Software installation.
Device Operation
Connecting and Starting the data logger
- Once the software is installed and running, plug the interface cable into the data logger.
- Connect the USB end of the interface cable into an open USB port on the computer.
- The device will appear in the Connected Devices list, highlight the desired data logger.
- For most applications, select “Custom Start” from the menu bar and choose the desired
start method, reading rate and other parameters appropriate for the data logging
application and click “Start”. (“Quick Start” applies the most recent custom start options,
“Batch Start” is used for managing multiple loggers at once, “Real Time Start” stores the
dataset as it records while connected to the logger.)
- The status of the device will change to “Running” or “Waiting to Start” depending
upon your start method.
- Disconnect the data logger from the interface cable and place it in the environment to
measure.
Note: The device will stop recording data when the end of memory is reached or the device is stopped. At this point the
device cannot be restarted until it has been re-armed by the computer.
Downloading data from a data logger
- Connect the logger to the interface cable.
- Highlight the data logger in the Connected Devices list. Click “Stop” on the menu bar.
- Once the data logger is stopped, with the logger highlighted, click “Download”. You will
be prompted to name your report.
- Downloading will offload and save all the recorded data to the PC

PR2000
6
Computer Interface
Fully insert the male connector of the IFC200 interface cable into the female receptacle of
the data logger. Fully insert the female USB connector into the USB. (Please see the Data
Logger Software manual for further information.)
*WARNING: Install driver before connecting a device using a USB for the first time. See the
Software manual for further information.

Product User Guide
7
Front Panel Overview
Changing the display units
The PR2000 comes with factory default display units of PSI for pressure and the real-time
pressure graphing feature. These units can be easily changed by pressing the F3 button
in the main screen and then selecting F1 for pressure or F2 for the pressure graph. After
selecting the channel, the available units can be scrolled through by either pressing the
channel’s function key repeatedly or using the UP and DOWN keys
Button pressing chain: Main Screen -> F3 -> F1 (pressure) or F2 (pressure graph) ->
function key repeatedly or UP and DOWN
Checking the memory status
A status icon appears on all screens representing memory, but further information includ-
ing percent memory left and number of readings taken can also be viewed. From the Main
Screen press the F1 key to enter the Status screens then press F2 to view memory status
information.
Button pressing chain: Main Screen -> F1 -> F2
Checking power status
A battery status and external power status (if available) icon appear on all screens, but per-
cent battery power remaining and external power presence as well as battery type, current
battery voltage, and current external voltage can also be viewed. From the Main Screen
press F4 to view the Device Configuration Menu, F2 to access the power options, then F4
twice to view the Power Status screen, including battery power percent remaining and the
presence of external power. Battery type and battery voltage are also displayed, as well as
external power voltage (if connected).
Button pressing chain: Main Screen -> F4 -> F2 -> F4 -> F4
Changing the Contrast
The PR2000’s LCD screen contrast values can be changed in two ways. One method is
outlined in the Function Reference Guide. A faster, simpler way involves simultaneously
pressing the CANCEL and UP or DOWN button in any screen.
Button pressing chain: CANCEL + UP (to increase) or DOWN (to decrease)

PR2000
8
Screen Descriptions
Main Screen
Displays last measured values
Statistics
Status Screens
Run Parameters
Statistics Menu Screen: Displays options
available within the statistics menu
Type Statistics: Displays statistics from the
pressure channel
Memory Status
Channel Statistics: Displays statistics
Statistics Information Screen: Displays
current statistics information
Date and Time

Product User Guide
9
Device Configuration Menu
Displays options available within the device configuration menu
F1 = DISPLAY: enters Adjust Visibility screen
F2 = POWER: enters Power Modes screen
F3 = INFO: goes to Device Information screens
F4 = EXIT: returns to main screen
CANCEL = returns to main screen
OK = returns to main screen
UP = no function
Down = no function
Device Reset
This device include two reset options, Hardware and Power Interruption
Power Interruption: Displayed as notification when power is interrupted during device
operation.
F1 = OK: accepts notification and displays main screen
F2 = no function
F3 = no function
F4 = no function
CANCEL = no function
OK = accepts notification and displays main screen
UP = no function
DOWN = no function
Hardware Reset: Displayed as notification when a hardware reset has occurred.
F1 = OK: accepts notification and displays main screen
F2 = no function
F3 = no function
F4 = no function
CANCEL = no function
OK = accepts notification and displays main screen
UP = no function
DOWN = no function

PR2000
10
Recalibration
The PR2000 standard calibration is dependent upon the range.
Additional:
Custom calibration and verification point options available, please call for pricing.
Call for custom calibration options to accommodate specific application needs.
Prices and specifications subject to change. See MadgeTech’s terms and conditions at madgetech.com
To send devices to MadgeTech for calibration, service or repair, please use the MadgeTech RMA Process by visiting
madgetech.com, then under the services tab, select RMA Process.
Device Maintenance
Materials: 3/32” HEX Driver (Allen Key) and Replacement Batteries (6AA)
- Remove the back cover from the device by unscrewing the four screws.
- Remove the battery from its compartment and unsnap it from the connector.
- Snap the new battery into the terminals and verify it is secure.
- Replace the cover taking care not to pinch the wires. Screw the enclosure back together.
Note: Be sure not to over tighten the screws or strip the threads.
For any other maintenance or calibration issues, we recommend the unit be returned to the
factory for service. Before returning the device, you must obtain an RMA from the factory.
Battery Replacement
This product does not have any user-serviceable parts except the battery which should be
replaced periodically. The battery life is affected by battery type, ambient temperature,
sample rate, sensor selection, off-loads and LCD usage. The device has a battery status indi-
cator on the LCD. If the battery indication is low, or if the device seems to be inoperable, it
is recommended that the battery be replaced.
