Omega DP400TP User manual

DP400S
Strain Indicator
TM
User’s Guide
Shop online at
omega.com
e-mail: [email protected]
For latest product manuals:
www.omegamanual.info

The information contained in this document is believed to be correct, but OMEGA accepts no liability for any errors it
contains, and reserves the right to alter specifications without notice.
Servicing North America:
U.S.A. Omega Engineering, Inc.
Headquarters: Toll-Free: 1-800-826-6342 (USA & Canada only)
Customer Service: 1-800-622-2378 (USA & Canada only)
Engineering Service: 1-800-872-9436 (USA & Canada only)
Tel: [phone] Fax: [phone]
e-mail: in[email protected]
For Other Locations Visit omega.com/worldwide
omega.com [email protected]

User manual - DP400S - 3
Table ofContents
1 Model identification ..............................................................................................................6
2 Technical Data ........................................................................................................................6
2.1 General data ..............................................................................................................6
3 Hardware data........................................................................................................................6
3.1 Software data............................................................................................................7
4 Dimensions and Installation...............................................................................................8
5 Electrical wirings ....................................................................................................................8
5.1 Wiring diagram.........................................................................................................9
6 Display and Key Functions.................................................................................................12
6.1 Keys.............................................................................................................................12
6.2 Display.......................................................................................................................12
7 Controller Functions............................................................................................................14
7.1 Modifying alarm thresholds ................................................................................14
7.2 Zero function, net/gross weight .........................................................................14
7.3 Calibration function ..............................................................................................15
7.4 Digital input functions ..........................................................................................19
7.5 Peak values...............................................................................................................19
7.6 Totalizer function................................................................................................... 20
7.7 Sum function........................................................................................................... 20
7.8 Customizable linearisation of analog input .................................................. 21
8 Alarm Intervention Modes................................................................................................ 21
9 Data logger........................................................................................................................... 24
10 Serial communication ....................................................................................................... 24
11 Error messages......................................................................................................................31
12 Configuration........................................................................................................................31
12.1 Modifying configuration parameters ...............................................................31
12.2 Loading default values......................................................................................... 32
12.3 Configuration by NFC/RFID................................................................................. 32
12.4 Configuration via DP-USB-CARD ...................................................................... 33
12.5 Creation of the DP-USB-CARD ........................................................................... 33
12.6 Loading configuration from DP-USB-CARD................................................... 33
13 Table complete of configuration parameters.............................................................. 34
13.1 Analog input ........................................................................................................... 34

4 - DP400S - User manual
13.2 Weight management ........................................................................................... 37
13.3 V/I custom ................................................................................................................ 38
13.4 Dynisco MELT .......................................................................................................... 43
13.5 Alarm 1 ..................................................................................................................... 43
13.6 Alarm 2 ..................................................................................................................... 45
13.7 Display ...................................................................................................................... 47
13.8 Digital input 1......................................................................................................... 48
13.9 Digital input 2......................................................................................................... 49
13.10 Graphic ..................................................................................................................... 49
13.11 Analog output in mA ............................................................................................ 50
13.12 Serial communication.......................................................................................... 51

User manual - DP400S - 5
Introduction
Thanks for choosing an Omega device.
DP400S is an indicator/panel meter for acquisition and retransmission of
processes, also with fast transient. It is provided with relay outputs for
alarm purpose, analog output for retransmission ofprocess/setpoints and
programmable digital inputs.
Available in standard format 96 x 48 mm, the device can be configured both for
horizontal and vertical mounting.
Distinctive feature is the intuitive multilingual interface, supported by a graphic
OLED monochromatic yellow display 128 x 64 pixel.
Visualization options include bar graph and process trend with programmable
sampling time.
Software features include mathematical functions related to process value like
totalizer andsum.
Serial connectivity relies on RS485 and Modbus-RTU protocol.
Safety guide lines
Read carefully the safety guidelines and programming instructions contained in
this manual before using/connecting the device. Disconnect power supply
before proceeding to hardware settings or electrical wirings.
Only qualified personnel should be allowed to use the device and/or service it
and in accordance to technical data and environmental conditions listed in this
manual. Do not dispose electric tools together with household waste material.
In observance European Directive 2002/96/EC on waste electrical and electronic
equipment andits implementation inaccordance with national law, electric
tools that have reached the end of their life must be collected separately and
returned toanenvironmentally compatible recycling facility.

6 - DP400S - User manual
1 Model identification
Model 24..230 Vac/Vdc +/-15% 50/60 Hz – 8 VA
DP400S
2 Relays 2A + 1 output mA + 2 D.I.+ RS485 + OLED
display + RFID
2 Technical Data
2.1 General data
Display Backlighting graphic OLED 2.42’’ (DP400S)
Operating
temperature Temperature 0-40 °C - Humidity 35..95 Rh%
Sealing IP54 front panel (with gasket) - IP20 box and terminals
Material Box: Polycarbonate V0
Weigh Approx. 165 g
3 Hardware data
Power supply
Extended power supply
range 24..230 Vac/Vdc ±15%
50/60 Hz
Consumption: 8 VA.
Analog input
IN+ / IN-
Differential input,
software-configurable
- for strain-gauge (load
cells or Melt sensors), max
7,5 mV/V with 5V power
supply (max 4 cells 350 Ω in
parallel).
- for potentiometer (min. 200
Ω, 5V power supply.
Tolerance (25 °C)
+/-0.2% ±1 digit ( f.s.)
Impedance
Ri>1 MΩ
Relay outputs 2 Relays Contacts 2A - 250 Vac.
Resistive charge.
Analog output
Config. as 0..20mA or 4..20mA. Resolution 16bit +/-0.2% ( F.s.)

User manual - DP400S - 7
3.1 Software data
Alarms regulation ON/OFF with hysteresis
Alarm mode
Absolute/Threshold, Band with instantaneous/delayed/
retentive action/activation by digital input , Sensor failure /
Activation by serial line/net weight/Gross weight/Stable
weight/Sum
Sum Function By digital input or by keyboard it is possible to sum
different process measurements over time
Totalizer Function Visualization of instant process value and total value since
last reset
Trend
visualization
Trend visualization up to 59 samples, with selectable time
basis 0,1 s to 3600 s
Analog
retransmission Process values/alarm value via analog output
Digital
transmission Process values/Setpoint/Parameters via RS485
Calibration
function
Following options are available for calibration procedure:
• Calibration with 2-points sampling value
• Calibration on full-scale % value
• Calibration value mV/V.
Data logging
function
Selectable time basis 1s to 3600s, tot. memory 1K
samplings
Text menus English/Italian/Deutsch/French/Spanish
Autozero Measure reset at starting
Net / Fross Net/gross weight function by key, digital input or serial.
Stability Signaling of configurable stable weight

8 - DP400S - User manual
4 Dimensions and Installation
45 x 91 mm
Front panel cut-out
kg
96 mm
48 mm
Memory Card
48 mm 5
10
2÷15 mm Suggested thickness
USB
(optional)
DP-USB-CARD
5 Electrical wirings
Although this controller has been designed to resist noises in an industrial
environment, please notice the following safety guidelines:
• Separate control lines from the power wires.
• Avoid the proximity of remote control switches, electromagnetic meters,
powerful engines.
• Avoid the proximity of power groups, especially those with phase control.
For permanently connected equipment:
• supply wiring must be ≥18 AWG with cables suitable for temperatures > 70° C;
• for requirements about any external switch or circuit-breaker see EN 61010-1
par. 6.11.3.1 and about external overcurrent protection devices see EN
61010-1 par. 9.6.2; the switch or circuit-breaker must be near the equipment.

User manual - DP400S - 9
5.1 Wiring diagram
5.1.a Power supply
SUPPLY
24..230V
AC/DC
5
6
Switching supply, extended range 24..230 Vac/Vdc ±15%
50/60 Hz – 8 VA (galvanically isolated).
5.1.b S +IN / S -IN analog input
+-
13
7
15
14
Shield/Schermo
EXC -
EXC +
S - IN
S + IN
Strain-gauge
For strain-gauge sensors (4 wires)
• Comply with polarity.
• When shielded cable is used, it should be
connected to pin 13 (EXC-).

10 - DP400S - User manual
+-
13
7
15
14
1
2
Shield/Schermo
EXC -
EXC +
S + IN
CAL
CAL
S - IN
Strain-gauge
For strain-gauge sensors (4 wires+ 2
calibration wires) or Melt sensors
• Comply with polarity.
•
•
To perform semi-automatic calibration,
connect the 2 calibration wires to the relay
contact Q2 and set properly the parameter
for output Q2.
When shielded cable is used, it should be
connected to the pin 13 (EXC-).
13
7
15
14
S - IN
S + IN
EXC -
EXC +
Pot
Shield/Schermo
For linear potentiometers
• Use potentiometers with resistive value
greater than 200 Ω.
• When shielded cable is used, it should be
connected to pin 13 (EXC-)
5.1.c Serial input
RS485
16
17
18
Shield/Schermo
RS485 Modbus RTU communication
5.1.d Relay Q1 output
2A 230V
Resistive
1/8HP
Q1
3
4
Contacts capacity 2 A/250 Vac for resistive loads.
NB: see picture below
