Section 1 - Introduction
The low cost OS101 mini-infrared transmitter provides non-contact
temperature measurement for industrial applications. The unit measures a
temperature range of -18 to 538°C (0-1000°F) and provides a linear analog
output of either 4-20 mA, 0-5 VDC, K type TC, 1 mV/°C, or 1 mV/°F.
The new OS102 mini-infrared transmitter has all the functions of OS101
plus a built-in LED display that shows the measured temperature in
degrees F or degrees C which is switchable in the field.
The miniature sensor head design 2.5 cm dia. x 6.3 cm Length (1" x 2.5") is
ideal for measuring temperature in confined, and hard to reach places.
The aluminum sensor head as well as the rugged electronic housing (Die
cast Aluminum) are NEMA-4 rated.
The sensor head is connected to the electronic housing via a 1.82 m (6 feet)
shielded cable as standard. The unit provides field adjustable alarm
output.
Section 2 - Installation
2.1 Unpacking
Remove the packing list and verify that you have received all your
equipment. If you have any questions about the shipment, please call
Customer Service at:
1-800-622-2378 or 203-359-1660. We can also be reached on the internet:
omega.com e-mail: [email protected]
When you receive the shipment, inspect the container and equipment for
any signs of damage. Note any evidence of rough handling in transit.
Immediately report any damage to the shipping agent.
The carrier will not honor any damage claims unless all the shipping materials are saved for
inspection. After examination and removing contents, save packing material and carton in the
event reshipment is necessary.
The following items are supplied in the box:
• The infrared transmitter including the sensor head and the 1.82 m
(6 feet) shielded cable
• User's Manual
• Mounting Nut
OS100 Series - Introduction 1
1-1
NOTE:

OS100 Series - Installation
2
The following describes the ordering information:
OS102 or OS101 - MA - *, **, where
The following optional accessories are available:
Here are the Features of OS101 and OS102 infrared transmitters:
2.2 Electrical Connection
Sensor Head Cable - The Sensor head is pre-wired to a 1.8 m (6 feet)
shielded cable. Plug & lock-in the male connector to the mating female
connector on the aluminum housing.
Power & Output Connection - Open the cover of the main aluminum
housing. Slide the cable through the strain relief and connect the wires to
the terminal block on the board as shown in Fig. 2-1. For Alarm output
connection, refer to Fig. 2-2.
2-1
Model No. Description
OS100-MB Mounting Bracket
OS100-DR DIN Rail Mounting adapter
OS100-WC Water Cooling jacket
OS100-AP Air purge collar
OS100-LS Laser Sighting
OS100-CA15FT Sensor Head Extension Cable (4.6 m, 15")
OS100-CA25FT Sensor Head Extension Cable (7.6 m, 25')
TX8-100 8 Conductor stranded Shielded cable (30 m, 100')
PSU-93 Unregulated 16-24 VDC Power Supply
CAL3-IR NIST Traceable Calibration
Features OS101 OS102
Accuracy 2% Rdg or 4°F (2.2°C)
Temp Range 0-1000°F (-18 to 538°C)
Emissivity 0.1 to 0.99 Adj.
Field of View 6 to 1
Alarm Output Standard
1mV/Deg. Output Standard
4-20mA Output Standard
0/5 VDC Output Standard
K Type T/C Std. ––
LED Display –– Std.
Main Housing 65.5 x 30.5 x 115.3 mm 65.5 x 55.9 x 115.3 mm
(2.58" x 1.2" x 4.54") 2.58" x 2.2" x 4.54"
MA - 4/20 mA output
V1 - 0 to 5 VDC output
K - Thermocouple output, K type
MV - Millivolt output
C - 1 mV/°C output
F - 1 mV/°F output
HT- High
temperature
sensor head

OS100 Series - Operation 3
3-1
Figure 2-1. Power Supply & Analog Output Connections
Figure 2-2. Alarm Output Connection
Section 3 - Operation
3-1 Main Board
The Main Board is shown in Fig. 3-1. Here are the important components
on the board:
(1) - Terminal Block for Power & Output connections
(2) - Single Turn Potentiometer to adjust Emissivity in tenths (0.x_)
(3) - Single Turn Potentiometer to adjust Emissivity in hundreds (0._x)
(4) - Slide switch to select between real time (Normal Operation) and alarm
set point
(5) - Alarm set point adjust, P4
(6) - Sensor Head connection
(7) - Input Zero adjust, P3
(8) - Input Span adjust, P2
(9) - Output Zero adjust, P5
(10) - Output Span adjust, P6
ANALOG
OUTPUTS
K
4/20mA
+
+
1mV/Deg
0-5VDC
T/C
A
V
+
--
+
POWER
SUPPLY
12-24VDC
CHASSIS 6
5
4
3
2
1
5-24VDC+
CHASSIS
POWER
SUPPLY
12-24VDC
--
+
6
5
4
3
2
1

Figure 3-1. Main PC Board
3.2 Ambient Temperature
The Sensing head can operate in an ambient temperature of 0 to 70°C (32
to 158°F). The Sensing head in the high temperature model (-HT) can
operate in an ambient temperature of 0 to 85°C (32 to 185°F) without any
cooling required. The Sensing head can operate up to 200°C (392°F) using
the water cool jacket accessory OS100-WC (See Fig. 3-6).
There is a warm up period of 3 minutes after power up. After the warm
up period, temperature measurement can be made.
When the ambient temperature around the sensor head changes abruptly,
the sensor head goes through thermal shock. It takes a certain amount of
time for the sensor head to stabilize to the new ambient temperature. For
example, it takes about 30 minutes for the sensor head to stabilize going
from 25°C to 50°C (77 to 122°F) ambient temperature.
The sensor head dimensions are shown in Fig. 3-2.
Figure 3-2. Sensor Housing
OS100 Series - Operation
3
3-2
3/4-16 UNF
25
(1.0)
20
(0.8)
63.5
(2.5)
Dimensions mm (in.)
SW1 P6
P2P3
P5
P4
REAL
TIME
E=0.95
10
9
8
7
6
5
4
3
2
J2
ALARM
ADJUST
1
ALARM
9
8
7
6
5
4
3
2
109
8
7
6
5
4
3
2
10
6
5
43
2
1
