Omnitron Systems Technology miConverter User manual

Page 2 Page 3
Page 6
Page 4
Page 5 Page 7 Page 8
back of the miConverter. Conrm that the module has
powered up properly by checking the power status LED
located on the top of the module.
To power the module using the AC/DC adapter, connect
the AC/DC adapter to the AC outlet. Then connect the
barrel connector at the end of the cable to the back of
the miConverter. Conrm that the module has powered
up properly by checking the power status LED located
on the top of the module.
To power the unit using a DC power source, prepare a
power cable using a two-conductor insulated wire (not
supplied) with a 14 AWG gauge minimum. Cut the
power cable to the length required. Strip approximately
3/8 of an inch of insulation from the power cable wires.
Connect the power cables to the GX/T unit by fastening
the stripped ends to the DC power connector.
Connect the power wires to the DC power source. The
Power LED should indicate the presence of power.
WARNING: Note the wire colors used in making
the positive and negative connections. Use the
same color assignment for the connection at the
DC power source.
INSTALLATION PROCEDURE
Configure the appropriate miConverter GX/T
DIP-Switch settings.
Connect the UTP port via a Category 5 or better cable
to a 10BASE-T, 100BASE-TX or 1000BASE-T Ethernet
device.
DESCRIPTION
The miConverter GX/T is a 10/100/1000BASE-T UTP
to 1000BASE-X ber media converter that supports
jumbo frames up to 10,240 bytes. The GX/T features
xed ber and Small Form Pluggable (SFP) transceivers
that support multimode, single-mode and single-mode
single-ber options.
Both the ber port and the UTP port support auto-
negotiation, an IEEE standard which denes how all
the communicating devices automatically perform their
conguration functions.
The auto-negotiation feature can be disabled on both
ports (for manual conguration) using DIP-switches
on the product. This is useful in a situation where the
GX/T is connected to a non-negotiating device and the
conguration parameters must be set manually.
POWERING OPTIONS
-1 Barrel Connector and US Power Adapter,
100 - 120VAC, 60Hz
-2 Barrel Connector and Universal Power Adapter,
100-240VAC, 50-60Hz (requires AC power cord)
-3 Barrel Connector and European Power Adapter,
100-240VAC, 50-60Hz
-4 Barrel Connector and UK Power Adapter,
100-240VAC, 50-60Hz
-5 Barrel Connector and Australian Power Adapter,
100-240VAC, 50-60Hz
-6 USB Power Adapter Cable
-8 Barrel Connector and US/Japan Power Adapter,
100-240VAC, 50-60Hz
-9 2-Pin DC Terminal Connector (non-isolated)
POWER MODES
AC power adapter is available in US, Universal and
Country/Region specific models. Country/Region
specific models feature optional interchangeable
connectors, allowing for compatibility with electrical
outlet types found around the world.
This product should only be used with Omnitron
Supplied Power Unit.
To power the module using the USB cable, connect the
USB Standard Type A connector to a USB port on the
computer. Then connect the connector at the other end
of the cable (barrel connector) to the connector on the
miConverter™GX/T Media Converter
User Manual
When connecting the dual-ber models, the miConverter
transmitter (Tx) must attach to the receiver side of its link
partner; the receiver (Rx) must attach to the transmitter.
When using single-ber (SF) media converter models,
the Tx wavelength on one end has to match the Rx
wavelength on the other. Based on this guideline, the
SF media converter models must be used in pairs, such
as the 1230-1 matched with the 1231-1.
When using a GX/T SFP model, insert the SFP Fiber
transceiver into the Port 1 SFP receptacle on the GX/T.
NOTE: The release latch of the SFP Fiber transceiver
must be in the closed (up) position before insertion.
Mount the miConverter GX/T using the included
Velcro® strips or optional wall-mounting bracket kit
(P/N 1091-0).
DIP-SWITCH SETTINGS
Link Propagate “LP”
UTP Mode 1
F/O Auto-negotiate “AN”
UTP Mode 2
UTP Mode 1
F/O Manual Negotiate “Man”
UTP Mode 2
Link Segment “LS”
UP
DOWN
Fig. 1 DIP-switches
Unit shown with optional wall-mounting bracket kit
Link Segment/Link Propagate “LS/LP” DIP-switch
Setting the DIP-switch to LS (Link Segment), a port
transmits a Link signal independently of any received
Link at any other port. For example, the UTP transmits
a Link regardless of the ber receiving a Link [Fig.
2(a) & (b)].
Setting the DIP-switch to LP (Link Propagate), a port
transmits a Link signal only when receiving a Link at
its other port. For example, the UTP transmits a Link
only when receiving a Link at the ber port [Fig. 2(c)].
Switch 1 Converter A Converter B Switch 2
LS
Fiber UTP
UTP
UTP
UTP Fiber
LS
Switch 1 Converter A Converter B Switch 2
LS LS
Switch 1 Converter A Converter B Switch 2
LP
LP
LED Lit LED OffLED Lit
(A)
(B)
(C)
Fig. 2 Link Modes
UTP Mode Conguration DIP-Switches
When congured for auto-negotiation, Pause is always
advertised. Each port will resolve Pause capability
independently during auto-negotiation. If NO Pause
is resolved, the port will not send or respond to Pause
frames.
UTP
Mode 1
UTP
Mode 2
UTP Mode of Operation
Down Down
Congured for Auto Negotiation
(1000F, 1000H, 100F, 100H,
10F, 10H and Pause Capable)
Down Up Manual 10M FDX
Up Down Manual 100M HDX
Up Up Manual 100M FDX
When the module is congured for auto-negotiation,
the module will advertise in the order shown in the
parenthesis.
F/O Manual/Auto “Man/AN” DIP-Switch
Setting this DIP-Switch to Auto-Negotiate “AN” (factory
setting) enables the ber port to determine duplex mode
automatically. If a connection can not be established,
the ber port will automatically attempt to connect to the
device by reconguring to manual mode.
If the connected device cannot provide the proper signal
to indicate its own mode of operation or the ber port can
establish a link after attempting a manual connection,
Page 1
Fiber
Type
and
Distance
Connector Types Tx
Lambda
(nm)
Rx
Lambda
(nm)
ST SC
MM/DF/220m 1220-0-x 1222-0-x 850 850
SM/DF/12km 1221-1-x 1223-1-x 1310 1310
SM/DF/34km - 1223-2-x 1310 1310
SM/DF/80km - 1223-3-x 1550 1550
SM/DF/110km - 1223-4-x 1550 1550
SM/DF/140km - 1223-5-x 1550 1550
MM/SF/550m - 1230-0-x 1310 1550
MM/SF/550m - 1231-0-x 1550 1310
SM/SF/20km - 1230-1-x 1310 1550
SM/SF/20km - 1231-1-x 1550 1310
SM/SF/40km - 1230-2-x 1310 1550
SM/SF/40km - 1231-2-x 1550 1310
SFP Version: 1239-0-x
WARNING!
Before inserting the Power Adapter, verify
that the power on the adapter is appropriate
for your AC line voltage source.
this DIP-Switch should be set to Manual “Man.” This
feature allows connections with legacy devices that do
not support auto-negotiation.
NOTE: When the ber port is congured for Manual
Mode, a link may not occur with the connected
device. Congure both devices to Manual mode
to establish a link.

Page 15
Page 10 Page 11 Page 12
Page 9
Page 14 Page 16
SPECIFICATIONS
Standard
Compliances IEEE 802.3
Regulatory
Compliances UL, CE, FCC Class A, RoHS2 (6/6), WEEE, REACH
Frame Size Up to 10,240 bytes
Port Types
Copper:
Fiber:
10/100/1000BASE-T (RJ-45)
1000BASE-X (ST, SC, SFP)
1000BASE-BX (SC Single-Fiber,
SFP)
Cable Types
Copper:
Fiber:
EIA/TIA 568A/B, Cat 5 UTP and
higher
Multimode: 50/125µm, 62.5/125µm
Single-mode: 9/125µm
AC Power
Requirements
AC Adapter:
(US)
100 - 120VAC/60Hz
0.02A @ 120VAC (max)
AC Adapter:
(Universal)
100 - 240VAC/50 - 60Hz
0.02A @ 120VAC (max)
DC Power
Requirements
DC Input:
(AC
Adapter)
5.0 to 12.0VDC
0.35A @ 5VDC
2.5mm Barrel Connector
DC Input:
(Terminal
Block)
5.0 to 12.0VDC
0.35A @ 5VDC
2-Pin Terminal (non-isolated)
Dimensions W: 1.71" x D: 4.10" x H: 0.84"
L: 43.4 mm x B: 104.1 mm x H: 21.3 mm
Form: 040-12200-001C 12/16
General and Copyright Notice
This publication is protected by U.S. and international
copyright laws. All rights reserved. The whole or
any part of this publication may not be reproduced,
stored in a retrieval system, translated, transcribed,
or transmitted, in any form, or by any means, manual,
electric, electronic, electromagnetic, mechanical,
chemical, optical or otherwise, without prior explicit
written permission of Omnitron Systems Technology,
Inc.
The following trademarks are owned by Omnitron
Systems Technology, Inc.: FlexPointTM, HybridNID®,
iConverter®, miConverterTM, NetOutlook®, OmniLightTM,
OmniConverterTM, Omnitron Systems Technology, Inc.
TM, OSTTM and the Omnitron logo.
All other company or product names may be
trademarks of their respective owners.
The information contained in this publication is
subject to change without notice. Omnitron Systems
Technology, Inc. is not responsible for any inadvertent
errors.
Warranty
This product is warranted to the original purchaser
against defects in material and workmanship for a
period of two (2) years from the date of shipment. A
LIFETIME warranty may be obtained by the original
purchaser by registering this product within ninety
(90) days from the date of shipment at www.omnitron-
systems.com/support. During the warranty period,
Omnitron will, at its option, repair or replace a product
which is proven to be defective with the same product
or with a product with at least the same functionality.
For warranty service, the product must be sent to
an Omnitron designated facility, at Buyer’s expense.
Omnitron will pay the shipping charge to return the
product to Buyer’s designated US address using
Omnitron’s standard shipping method.
TECHNICAL SUPPORT:
For help with this product, contact Omnitron’s Tech.
Support:
Phone: [phone]
Fax: [phone]
Address: Omnitron Systems
38 Tesla
Irvine, CA 92618 USA
E-mail: [email protected]
URL: http://www.omnitron-systems.com
Page 13
LED INDICATORS
LED Function
“Legend”
Color
Off On
Power “Pwr”
Green
No power Power applied
Fiber Link “F/O”
Green
No ber link ON: Fiber link at 1000Mbps
Blinking (10Hz): Data activity
Blinking (1Hz): Energy detected
Fiber
Negotiation “AN”
Green
Manual Mode ON: Auto-negotiation mode
Blinking (1Hz): Congured as AN
but linked in manual mode
Error Condition
“F/O” + “AN”
Green
N/A Synchronized Blinking (1Hz):
AN error or Remote Fault
detected
RJ-45 Link
“100”
Green
No UTP link ON: UTP link at 100Mbps
Blinking (10Hz): Data activity
RJ-45 Link
“1000”
Green
No UTP link ON: UTP link at 1000Mbps
Blinking (10Hz): Data activity
RJ-45 Link
“100” + “1000”
Green
No UTP link ON: UTP link at 10Mbps
Blinking (10Hz): Data activity
Weight
Without AC
Adapter:
With AC
Adapter:
4 oz. (113.4 grams)
12 oz. (340.2 grams)
Temperature
Commercial:
Wide:
Extended:
Industrial:
Storage:
0 to 50°C
-40 to 60°C
-40 to 75°C
-40 to 85°C
-50 to 85°C
Humidity 5 to 95% (non-condensing)
Altitude -100m to 4,000m
MTBF (hrs)
Without AC Adapter:
With US AC Adapter:
With Universal AC
Adapter:
878,000
250,000
100,000
Warranty Lifetime warranty with 24/7/365 free Technical Support
Limitation of Warranty
The foregoing warranty shall not apply to defects
resulting from improper or inadequate use and/
or maintenance of the equipment by Buyer, Buyer-
supplied equipment, Buyer-supplied interfacing,
unauthorized modications or tampering with
equipment (including removal of equipment cover
by personnel not specically authorized and certied
by Omnitron), or misuse, or operating outside the
environmental specication of the product (including
but not limited to voltage, ambient temperature,
radiation, unusual dust, etc.), or improper site
preparation or maintenance.
No other warranty is expressed or implied. Omnitron
specically disclaims the implied warranties of
merchantability and tness for any particular purpose.
The remedies provided herein are the Buyer’s sole
and exclusive remedies. Omnitron shall not be
liable for any direct, indirect, special, incidental, or
consequential damages, whether based on contract,
tort, or any legal theory.
Environmental Notices
The equipment covered by this manual must be
disposed of in accordance with Directive 2002/96/
EC of the European Parliament and of the council of
27 January 2003 on waste electrical and electronic
equipment (WEEE). Such disposal must follow national
legislation for IT and Telecommunication equipment
in accordance with the WEEE directive: (a) Do not
dispose waste equipment with unsorted municipal
and household waste. (b) Collect equipment waste
separately. (c) Return equipment using collection
method agreed with Omnitron.
The equipment is marked with the WEEE symbol to
indicate that it must be collected separately from other
types of waste. In case of small items the symbol may
be printed only on the packaging or in this manual. If
you have questions regarding the correct disposal of
equipment go to www.omniton-systems.com/support
or e-mail to Omnitron at intlinfo@omnitron-systems.
com.
