iConverter 2FXM Plug-in Module QUICK START GUIDE
TheOmnitroniConverter®2FXMNetworkInterfaceDevice(NID)
with integrated management provides Fast Ethernet
(100BASE-FX) fiber-to-fiber media conversion.
The 2FXM conforms to Ethernet in the First Mile (EFM) fiber
standards to support Fiber-to-the-X (FTTX) Metropolitan and
Enterprise LAN networks. Built-in Operation, Administration
and Maintenance (OAM) functionality enables the 2FXM to
operate as a managed demarcation point at the customer
premises and network edge, offering service provisioning
functions, such as Quality of Service and Bandwidth Control
(rate-limiting) capabilities.
The2FXMmodulecanbemanagedusingOmnitron’sNetOutlookTMSNMPManagement
Software, 3rd Party SNMP Client, Telnet or the Command Line Interface (CLI).
Formoreinformation,including the complete User Manual on the2FXMPlug-inmodule,
access Omnitron’s documentation download web page to view all relevant documents:
http://www.omnitron-systems.com/downloads.php
INSTALLATION PROCEDURE
1) Configure DIP-Switches
2) Install Module in Chassis and Connect Cables
3) Configure Module via Command Line Interface
4) Verify Operation
1) CONFIGURE DIP-SWITCHES
DIP-SWITCH BANK 1
SW1 - PAUSE ENABLE
When the Pause Enable DIP-switch is in the
LEFT “Off” position (factory default), the 2FXM
disables the fiber ports’ ability to send and
receive Pause frames during network
congestion. Setting this DIP-switch to the
RIGHT “On” position, enables the 2FXM to
receive Pause frames from its link partner. This
enables the 2FXM to stop transmitting traffic to
its link partner and store incoming frames from
the other port in the internal buffer until the
congestion clears. If the internal buffer of the
2FXM becomes congested, it will transmit a
Pause frame to its link partner.
SW2 - FIBER PORT 1 FULL/HALF DUPLEX
Setting this DIP-switch to Half-Duplex “HDX” facilitates a connection that supports Half-
Duplex. Setting this DIP-switch to Full-Duplex “FDX” facilitates a connection that
supports Full-Duplex operation.
Management Options iConverter, Serial Agent
Network Management
1: Chassis and Module Management
2: Set Module Name Preferences
Management Module Preferences
3: IP and Control Preferences
4: SNMP Preferences
5: Abandon Preference Changes
6: Save Preference Changes
7: Restore Factory Defaults
8: Restart Management Module
9: Other Networking Features
Management Module Maintenance
10: Firmware Update
11: Set Date/Time
IP Address = 192.168.1.220
Chassis Number = 1
Enter Choice, <H>elp, E<x>it >
Figure D: Command Line Interface Menu Options
TheCLIinterfaceallows for the detailedconfigurationofthe module. It is recommended
to configure the module with an IP address associated with the attached network.
Also, SNMP traphost address should be configured if the module is managed with an
SNMP-based Management System. See the 2FXM User Manual for complete
information.
4) VERIFY OPERATION
Once the module has been
installed and configured per
steps 1 - 3, verify the module
is operational by viewing the
LED indicators.
The Power LED indicates the
module is receiving power
from the chassis.
The Fiber Optic link LEDs
indicate the fiber optic
connections have been
established. Verify the Link
Mode selection is set to Link
Segment (LS). Until a stable
link is established, leave the
Link Mode configured for LS.
After a Link presence is established, the Link Mode selection can be modified.
Switch 1
Switch 8
LEFT
Switch 1
Switch 8
Bank 2
Bank 1
RIGHT
Figure A: DIP-Switch Locations
LED Function
"Legend" Color Off State On / Blinking State
Power "Pwr" Amber No power On: Module has power
Power Supply Status
#X Amber Chassis Power
Supply not installed
On: Power available from
installed Power Supply #X
Blinking: No power available
from installed Power Supply#X
Port 1
Fiber Link Activity
"P1" Green No Fiber Link On: Fiber link is active
Blinking: Fiber Data Activity
Port 1
Half/Full Duplex
"FDX" Green Half-Duplex On: Full-Duplex
Chassis Management
Master/Slave
"Msr/Slv" Green Chassis Slave
Mode
On: Chassis Master
Blinking: Operating in OAM
Mode
Port 2
Fiber Link Activity
"P2" Green No Fiber Link On: Fiber link is active
Blinking: Fiber Data Activity
Port 2
Half/Full Duplex
"FDX" Green Half-Duplex On: Full-Duplex
Figure E: LED Indicators
Form 040-08940-002 D 12/07
Omnitron Systems Technology * 140 Technology Dr. #500 * Irvine, CA 92618
949.250.6510 tel * 949.250.6514 fax * www.omnitron-systems.com

installed management modules to the RIGHT “SL” position to enable Slave-Only
mode.
SW5, SW6, SW7, SW8 - RESERVED
These DIP-switches are for factory use only and must always remain in the LEFT
position (factory default).
2) INSTALL MODULE IN CHASSIS AND CONNECT CABLES
a. Carefully slide the module into an open slot in the chassis. Align the module with
the installation guides and ensure that the module is firmly seated against the
backplane. Secure the module by fastening the front panel thumbscrew (push in
and turn clockwise to tighten) to the chassis front. Verify the “Pwr” LED is ON
(indicating the chassis is powered).
b. Insert the SFP Fiber transceivers into the Port 1 and Port 2 SFPreceptacles on the
2FXM.
NOTE: The release latch of the SFP Fiber transceiver must be in the closed
position before insertion.
d. Connect an appropriate multimode or single-mode fiber cable to the SFP fiber
ports of the installed module. It is important to ensure that the transmit (TX) is
attached to the receive side of the device at the other end and the receive (RX) is
attached to the transmit side. Single-fiber (SF) media converter models operate in
pairs. The TX wavelength must match the RX wavelength at the other end and the
RX wavelength must match the TX wavelength at the other end.
NOTE: In order to support Remote OAM Management Mode, Port 1 of the
2FXM must be connected to the Port 1 on the 2FXM or link partner.
3) CONFIGURE MODULE VIA COMMAND LINE INTERFACE
To access the Command Line Interface (CLI), connect the 2FXM RS-232 Console Port
to the COM port of a computer equipped with terminal emulation software such as
HyperTerminal. The Console Port (DCE) is a mini DIN-6 female connector which can
be changed to a DB-9 connector with the included adapter. The 2FXM Console Port is
a standard asynchronous serial interface.
Start HyperTerminal and select the correct COM Port in the HyperTerminal “Connect
To:” window. Set the serial port to the following:
Bits Per Second 57,600
Stop Bits 1
Data Bits 8
Parity NONE
Hardware Flow Control NONE
Once connected, press <ENTER> to bring up a command line prompt on the attached
PC. A new 2FXM module does not have a password, and will skip the Password
Entry screen and go straight to the Management Options screen. If a password has
been set, the Password Entry screen will be displayed. Type the password and press
<ENTER>, the 2FXM will respond with the Management Options screen:
SW3 AND SW4 - RESERVED
These DIP-switches are for factory use only and must always remain in the LEFT
(factory default) position.
SW5 - FIBER PORT 2 FULL/HALF DUPLEX
Setting this DIP-switch to Half-Duplex “HDX” facilitates a connection that supports
Half-Duplex. Setting this DIP-switch to Full-Duplex “FDX” facilitates a connection that
supports Full-Duplex operation.
SW6, SW7, SW8 - LINK MODES
Themodulesupportsmultiplelinkmodesfor fault detection and isolation. Link Segment
should be used for the initial installation of the module. Once installed and operational,
the link mode can be modified.
Switch Left
(Factory Default) Right SW6 SW7 SW8 Link Mode Selection
SW1 Off:
Pause Disable PAUS: Pause Enable Left Left Left Link Segment (LS) (Factory Default)
SW2 FDX:
Fiber Port 1Full-Duplex HDX: Fiber Port 1Half-Duplex Right Left Left Link Propagate (LP)
SW3 Reserved Reserved Left Right Left Remote Fault Detect + Link
Segment (RFD + LS)
SW4 Reserved Reserved Right Right Left Remote Fault Detect + Link
Propagate (RFD + LP)
SW5 FDX:
Fiber Port 2 Full-Duplex HDX: Fiber Port 2Half-Duplex Left Left Right Symmetrical Fault Detect (SFD)
SW6
See Link Mode Selection
Right Left Right Illegal Setting
SW7 Left Right Right Illegal Setting
SW8 Right Right Right Illegal Setting
Figure B: DIP-Switch Bank 1
DIP-SWITCH BANK 2
SW1, SW2 - BACKPLANE ENABLE
When the DIP-switch is in the LEFT “DS” position (factory default), the Backplane Port
of the 2FXM is isolated from the chassis’ Ethernet Backplane. When the DIP-switch
is in the RIGHT “EN” position, the Backplane Port is enabled. This allows Ethernet
Backplane connectivity to an adjacent module via the chassis Backplane Link “A” or
“B” depending on the switch setting.
SW4 - MASTER/SLAVE
When the 2FXM module is installed
in a chassis with an iConverter
Network Management Module
(NMM), set DIP-switch to the LEFT
“M/SL” position (factory default).
The assignment of mastership is
automatically negotiated by the
installed management modules. To
designate the 2FXM module as the
master of the chassis, set the DIP-
switch to the LEFT “M/SL” position,
and set the DIP-switch of the other
Switch Left
(Factory Default) Right
SW1 A-DS: Disabled
Backplane Port A A-EN: Enabled Backplane Port A
SW2 B-DS: Disabled
Backplane Port B B-EN: Enabled Backplane Port B
SW3 Reserved Reserved
SW4 M/SL:
Auto Select SL: Slave-Mode Only
SW5 - SW8 Reserved Reserved
Figure C: DIP-Switch Bank 2
