Omron E3NC-LA0 User manual

E3NC-LA0
Protective Cap
©
OMRON Corporation 2013 All Rights Reserved.
SmartLaserAmplifier
E3NC-LA0
INSTRUCTION SHEET
Thank you for selecting an OMRON product. This sheet
primarily describes precautions
required in installing and operating the product.
• A specialist who has the knowledge of electricity must treat
the product.
• Please read this manual carefully, and use it correctly after
thoroughly understanding the product.
• Please keep this manual properly for future reference
whenever it is necessary.
Compatible Communication Unit (Sold Separately)
E3NW Series Communication Unit, Distribution unit E3NW-DS
Installation
1
1-1 Dimensions
1-2 Mounting the Amplier Unit
Unit: mm
Dimensions in parentheses () indicates the ones with related components.
Thecovercouldcomeoffifitistiltedby152degreesormore.
2.6
32.1 16 9.4
37
49.5
4.3
33.5
3.4
159.7
(Max. with the protective cover open)
152°
(Max. with the protective cover open)
39.5
102.4
29.9
26
30.2
5.2 4.2
27.8
10
6.9
DIN Track
Tighten the screw while pressing the End Plate.
Fiber Unit Connection Side Hook
1
2
3
45
2
1
Up to 30 Amplifier Units can be connected to
E3NW Series Communication Unit.
Under environments such as vibration, use an End Plate
even with a single amplifier unit.
■Mounting on DIN Track
(1)Let the hook on the Amplifier Unit's Sensor Head
connection side catch the track.
(2)Push the unit until the hook clicks into place.
■Removing from DIN Track
(1) Push the unit in the direction 1.
(2) Lift the unit in the direction of arrow 2 while
performing step (1).
1-3 Mounting the sensor head
Settings
2
Smart Tuning [Easy Sensitivity Setting]
2-4
2-1 Setting and Display Overview
[L/D Indicator：Orange]
Displays Light ON/Dark ON setting.
[OUT Indicator：Orange]
Turns ON when Output is ON.
[DPC Indicator：Green]
[ST Indicator：Blue]
Turns ON when Smart Tuning is in progress.
Turns ON when Dynamic Power Control is
effective.
[OUT Selection Indicators：Orange]
Green Digital Display
Threshold Level
WhiteDigital
Incident Light
Level
(2/3)
PRECAUTIONS ON SAFETY
PRECAUTIONS FOR SAFE USE
PRECAUTIONS FOR CORRECT USE
Checking the Package Content
• Amplifier Unit: 1 • Instruction Sheet (this sheet): 1 (Japanese, English and Chinese)
The following precautions must be observed to ensure safe operation of the product. Doing so may cause
damage or fire.
· Do not install the product in the following locations.
(1) Locations subject to direct sunlight
(2) Locations subject to condensation due to high humidity
(3) Locations subject to corrosive gas
(4) Locations subject to vibration or mechanical shocks exceeding the rated values
(5) Locations subject to exposure to water, oil, chemicals
(6) Locations subject to steam
(7) Locations subjected to strong magnetic field or electric field
· Do not use the product in environments subject to flammable or explosive gases.
· Do not use the product in any atmosphere or environment that exceeds the ratings.
· To secure the safety of operation and maintenance, do not install the product close to high-voltage
devices and power devices.
· Do not use the product if the case is damaged.
· Burn injury may occur. The product surface temperature rises depending on application conditions, such
as the ambient temperature and the power supply voltage. Use caution when operating or cleaning the
product.
· When setting the sensor, be sure to check safety such as by stopping the equipment.
· Be sure to turn off the power supply before connecting or disconnecting wires.
· Do not attempt to disassemble, repair, or modify the product in any way.
· When disposing of the product, treat it as industrial waste.
· Do not miswire such as the polarity of the power supply.
· Be sure to mount the unit to the DIN track until it clicks.
· To prevent electric shock or short circuit, put a protection cap on unused connection power supply
terminals.
· Do not apply excessive force (9.8N max.) such as tension, compression or torsion to the connector of the
sensor head that is fixed to the amplifier unit.
· Always keep the protective cover in place when using the product. Not doing so may cause malfunction.
· It may take time until the received light intensity and measured value become stable immediately after
the power is turned on depending on use environment.
· The product is ready to operate 200 ms after the power supply is turned ON.
· The Mobile Console E3X-MC11, E3X-MC11-SV2 and E3X-MC11-S cannot be connected.
· The mutual interference prevention function does not work when in combination with E3C/E2C/E3X.
· If the unit receives excessive sensor light, the mutual interference prevention function may not work
properly, resulting in malfunction of the unit. In such case, increase the threshold.
· Sensor communication unit E3NW can be used. E3X-DRT21-S and E3X-CRT/ECT cannot be used.
· If you notice an abnormal condition such as a strange odor, extreme heating of the unit, or smoke,
immediately stop using the product, turn off the power, and consult your dealer.
· Do not use thinner, benzine, acetone, and lamp oil for cleaning.
114
(Max. with the protective cover open)
10
5
19.2
3.9
11.5
13.8
■
Joining Amplier Units
(1)
Mount the Amplifier Units one at a time onto the DIN track.
Slide the Amplifier Unit until the communication connector is
closely attached.(Arrow 3)
(2)
Use End Plates (PFP-M: separately sold) at the both
ends of the grouped Amplifier Units to prevent them from
separating due to vibration or other cause.
(Arrow 4)
(3)
Tighten the screw on the End Plates using a driver. (Arrow 5)
Opentheprotectioncover.
FixthesensorheadwithM3screws.
Applytighteningtorqueof0.5N・mforfixing.
1.
2.
Lock Lever
Connector cover: Blue
SettingReset
KeyLock
ZeroReset
SolutionViewer
L/D
L/D
MODE
MODE
UP/DOWN
UP
＋：
Press both
Refer to " Convenient
Setting Features".
Performs tuning and [ST Indicator]
turns ON.
Sensitivity Setting
【 】
Button
S.TUNE
Minute Threshold
Adjustment
The green digital value
changes.
[UP/DOWN]Button
Output Switch
[L/D]Button
A single press switches between
Light ON/Dark ON. [L/D] Indicator
changes.
Mode/OUT Switch
[MODE]Button
Switches between SET mode and RUN mode by a
long press (3 seconds or longer) of the key. If Push
short, OUT is switched.
ForsettingswiththeCommunicationUnit,
refertotheUser'sManualthatcomeswiththeCommunicationUnit. 2-2 Switching Control Output
2-3 Sensor Head Display
Setto"DarkON"toturnONtheoutputwithoutasensingobject.
[L/D Indicator] turns ON.
[STABILITY Indicator: Green]
Turns ON when output is stable.
[OUT Indicator：Orange]
Turns ON when Output is ON.
Pressbutton.
L/D
Set to "Light ON" to turn the output ON with a workpiece in the detection area.
[L/D Indicator] turns ON.
Stable indication
(Green)
ON
OFF
ON
ON OFF
OFF ON
Operation indication (Orange)
L • ON D • ON
Stable
operation
area
Stable
operation
area
Unstable
operation
area
Operation
level
Operation
level x1.1
Operation
level x0.9
Workpiece
ON
OFF
ON
OFF
Output
for Light-on
Output
for Dark-on
Light intensity level
*
*
*
Setting to the stable area makes the operation more reliable against the
environmental changes (temperature, voltage, dust, setting deviation) after
installation. Be careful on environmental changes when using the sensor in an
application in which stable area cannot be obtained.
*
2-6 Minute Adjustment of Threshold Level
●
Smart Tuning Error
UP/DOWN
Hold the key for high-speed
level adjustment.
Press button to adjust
the threshold level.
The threshold level
becomes higher.
The threshold level
becomes lower.
Error / Display / Cause Remedy
Error Origin Tuning Type
2-point Tuning
Full Auto Tuning
Positioning Tuning
All
Otherthanmaximum
sensitivitytuning
The light level difference
between Points 1 and 2 are
extremely small.
Incident light level is too
high.
Incident light level is too low.
Near Error
Over Error
Low Error
・Changethedetectionfunctiontothemodeofslowerresponsetime.
・MovetheSensorHeadclosertothesensingobject.
・MovetheSensorHeadawayfromthesensingobject.
・MovetheSensorHeadclosertothesensingobject.
err
err
err
●2-point Tuning
Basic Setting
Workpiece is present
2-5 Output switching
9999
■OUT Selection Indicator switches to switch the settings.
Push short the [MODE] button in [Measurement Mode].
OUT Selection Indicators (Output 1/Output 2) switch.
1.
2.
OUTSelectionIndicator(Output1)
[Output1]
OUTSelectionIndicator(Output2)
Pushshortthe[MODE]buttonin[MeasurementMode].
[Output2]
●
Maximum Sensitivity Tuning
Enhancing Durability of the Head against Dust and Stain
Workpiece is absent
Workpiece is absent
●Full Auto Tuning
Setting for a Moving Workpiece
●Position Tuning
Setting to Detect by Workpiece Position
●Percentage Tuning
Detecting a Transparent or Microscopic Object
●Power Tuning
Initializing Light Intensity Changed Due to Dust or Dirt
Workpiece
is absent
Workpiece is absent
Percentagetuningsetting
ON
per
Execution can be done even if the order of workpiece
exists/not exist is reversed.
1pnt
1pnt 0 0
9999
9999
1pnt
1500
9999
5000
1500
2500
2pnt
Workpiece
Received light intensity setting: Adjust to the either higher value of Point 1 and Point 2 power tuning levels.
Threshold setting: Set to the middle between Point 1 and Point 2 received light intensity values.
Received light intensity setting: Adjust the received light amount to "0" when the button is pressed.
Threshold setting: Set the light intensity of approximately 7% when the button is pressed.
Received light intensity setting: Adjust the power tuning level to the maximum received light amount when the button is pressed.
Threshold setting: Set to the middle between the maximum and minimum received light amount values when the button is pressed.
Receiving light setting: Adjusts the receiving light amount to a half of that for the power tuning level with Desirable detection position.
Threshold setting: Set to the same value as the received light amount Desirable detection position.
Received light intensity setting: Adjust it to the received light intensity or power tuning level without detection object.
Threshold setting: Light amount without a workpiece x (1 + Percentage tuning level)
Received light intensity setting: Adjust the power tuning level to the received light amount when the button is pressed.
Threshold setting: Not changed.
When percent tuning setting is ON, only power tuning
can be performed. Other tunings cannot be performed.
L/D switching can be performed on Output 2 as well.(Refer to 2-2)
It will become susceptible to the influence of
background objects.
Desirable
detection
position
＋
Movingthefingeroffthebuttondisplays"2Pnt".
Movingthefingeroffthebuttondisplays"2Pnt".
Workpiece
Setting is Completed
Setting is Completed
Setting is Completed
Setting is Completed
Setting is Completed
Setting is Completed
Hold for 3 seconds or longer Release the button when "FULL" appears.
Hold for 7 seconds or longer
Release the button when the workpiece passed through.
Refer to " Detailed Settings".
Hold for 3 seconds or longer
Hold both for 1 sec. or longer
・Do not touch the emitter and receiver
areas of the sensor head.
A fingerprint may prevent proper
measurement.
If you accidentally touch it, use a soft
cloth to wipe it out.
・Fix the connector area so that it should
not be affected by oscillation and
impact.
Hold for 1 seconds or longer
OPTICALCOMMUNICATION
POSITION
DINTrack
SOLDSEPARATELY
PFP-□-N
Insert the sensor head, with the lock lever on
its connector area facing upward, all the way
into the connector port.
The color of the connector cover for E3NC-LH
is blue.
Make sure to avoid misconnection by
confirming the cover color in advance.
To remove it, press and hold the lock lever
then pull the sensor head out.
Meanings of Signal Words
Warning Indications
WARNING
Indicates a potentially hazardous situation which, if not avoided,
may result in minor or moderate injury or in property damage.
Do not use the product with voltage in excess of the rated voltage.
Excess voltage may result in malfunction or fire.
Never use the product with an AC power supply. Otherwise,
explosion may result.
WARNING
This product is not designed or rated for ensuring safety of persons
either directly or indirectly. Do not use it for such purpose.
*4013298-2C *
Tuning with regressive reflection is not recommended as the variation of the light values may occur, resulting in malfunction of the product.
Diffuse reflection: Perform tuning with the presence of a
sensing object.
Regressive reflection: Perform tuning without the
presence of a sensing object.
After positioning tuning performed, a sensing object must
be present for both diffuse and regressive reflections.

E3NC-LA0
Ratings and Specications
4-2
Model
Controloutput
Connectionmethod
Supportedcommunicationsunit
Powersupplyvoltage
Powerconsumption*1
Controloutput
Protectioncircuit
MaximumconnectableUnits
Numberof
unitsformutual
interference
prevention*2
Numberofbanks
Ambienttemperaturerange
Ambienthumidityrange
Insulationresistance
Dielectricstrength
Vibrationresistance
Shockresistance
Weight(packedstate/sensor)
Materials
E3NC-LA0
2
CommunicationUnitcompatiblewire-savingconnector
E3NWSeriesCommunicationUnit,E3NW-DS
Suppliedfromtheconnectorthroughthecommunicationsunits.
Powersupplyvoltage24V:
Normalmode:1560mWmax.(Powerconsumption65mAmax.)
PowersavingECO:1200mWmax.(Powerconsumption50mAmax.)
Pleaserefertothespecificationofacommunicationunit.
Powersupplyreversepolarityprotection,outputshort-circuitprotection
30units
0 Note:ThemutualinterferencepreventionfunctionsaredisablediftheSHSmodeisselectedfordetectionfunction.
2
2
4
4
Operating:1to2amplifiersconnected:0℃to55℃,3to10amplifiersconnected:0℃to50℃,
11to16amplifiersconnected:0℃to45℃,17to30amplifiersconnected:0℃to40℃
Storage:−30℃to70℃(withnoicingorcondensation)
Operatingandstorage:35%to85%RH(withnocondensation)
20MΩmin.(at500VDC)
1,000VAC,50/60Hz,1minute
10to55Hzwitha1.5-mmdoubleamplitudefor2hrseachinX,YandZdirections
150m/s2,for3timeseachinX,YandZdirections
Approx.65g/Approx.25g
Caseandcover:Polycarbonate(PC),Cablecovering:PVC
Super-high-speedmode(SHS)
High-speedmode(HS)
Standardmode(Stnd)
Gigamode(GIGA)
*1.Powerconsumption
Powersupplyvoltage10Vto30V:
Normalmode:1650mWmax.(Powersupplyvoltage30V:Powerconsumption55mAmax./Powersupplyvoltage10V:Powerconsumption105mAmax.)
PowersavingECO:1350mWmax.(Powersupplyvoltage30V:Powerconsumption45mAmax./Powersupplyvoltage10V:Powerconsumption80mAmax.)
Convenient Setting Features
3
Maintenance
4
Troubleshooting
4-1
*2.Thetuningwillnotchangethenumberofunits.
Theminimumnumberofunitsinthespecificationsisappliedtothemutualinterferencebetween
differentamplifierssuchasbetweenfiberandlaser.
Select [Setting Mode] - [OUT1 Mode] - [Area Detection Mode].
Pressingthe[MODE]buttonfor3secondsorlongerexitstheSETmode.
Pressthe[MODE]buttonin[MeasurementMode]todisplay"OUT1HIGH"and"OUT1LOW".
GreendigitalindicatorshowsHIGHandLOW.
ProvideSmartTuningtoeachofHIGH/LOWthresholdsby
pressingthe[S.TUNE]button.
1.
2.
3.
Select [Setting Mode] -> [Digital Display] to set [diSP CFdr].
Press the [MODE] button for at least 3 seconds to exit SET mode.
Before Passing Right after passing
Let the workpiece pass.
Displays the light intensity (maximum/minimum value) for 0.5 seconds when the workpiece passes.
1.
2.
3.
4.
Pressboththe[MODE]and[L/D]buttonsforatleast3seconds
tosetto[SoLUon].Toreleasethesetting,pressthe[MODE]
and[L/D]buttonsforatleast3secondstosetto[SoLUoff].
Let the workpiece pass.
Passing time and light amount difference are displayed.
1.
2.
3.
In tuning by percent, the thresholds are set as follows:
HIGH: Received light intensity in 3. + Received light intensity in 3. × Absolute value of percent tuning level
LOW: Received light intensity in 3. - Received light intensity in 3. × Absolute value of percent tuning level
User Save Function
[rst] [rst user]
User Reset Function
yes
LightamountdifferencePassingtime
(msorμs) LightamountdifferencePassingtime (msorμs)
500m
63
[rst]
MODE MODE
Enable/Cancel
(The same procedure)
[]
For Stable Detection Regardless of Received Light Intensity Changed due to Dust or Dirt
●Zero Reset Function
Returning Received Light Intensity Display to "0"
●Area Detection Mode
For Output When Received Light Intensity is Within the Area
●Change finder
Checking Received Light Intensity When Workpiece Passes at High Speed
●Solution Viewer
Determining If Workpiece is Detectable
●Setting Reset
Initializing Settings
UP/DOWN
MODE MODE
UP/DOWN
[] [ ]
UP/DOWN
MODE MODE
UP/DOWN
●Key Lock Function
Preventing Malfunction
●User Save Function/User Reset Function
Saving/Reading Settings
Initialize all settings to the factory-set defaults.
Disables all the button operations.
* Press either of UP/DOWN.
Thethresholdalsochangesaccordingly.
The lower threshold limit is -1999.
Hi
Lo
ON
OFF
ON
OFF
Controloutput
forLight-on
Controloutput
forDark-on
While pressing [S.TUNE], press and hold
the [L/D] button for 3 or more seconds.
Passingtime
Threshold
Lightamountdifference(msorμs)
Hold both for 3 sec. or longer
rst
Hold both for 3 sec. or longer
rst
Hold both for 3 sec. or longer
Hold both for 3 sec. or longer Hold both for 3 sec. or longer
Enable Cancel
0
2000 60004000
20009999 20001000
0m 0
The zero reset is cancelled
when DPC function/
smart tuning is executed.
●
Troubleshooting
Nothing is shown
on the indication.
Eco mode is ON. Turn OFF Eco mode.
No power supplied or
the cable broken.
Check the connection of the connector between the
Communication Unit and Amplifier.
Sensing/Detection
not possible despite
the minimum
threshold level.
Detection set to a small
light level mode
Dust or dirt influences.
Setting GIGA Mode increases emission power and light
intensity.
Problem Cause Remedy
The operation
indicator blinking.
Mutual interference
or other reason.
Check the Amplifier Units mounted in a group and turn
ON the power again.
Incident light level
displayed in a
negative value.
Lost tracking of
the settings made.
Reset the settings.
ｰ
Nothing is shown
on the digital indication.
The zero reset function
is enabled.
Is an LD-OFF command
sent from the
Communication Unit?
Cancel the zero reset function.
Refer to "1-2 Mounting Amplifier Unit"
Refer to " Detailed Settings".
Refer to " Detailed Settings".
Refer to " Convenient Setting Features"
Refer to " Convenient Setting Features"
Error Display
*The DPC indicator blinks.
RemedyCauseError Name / Display
The incident light
level has
deteriorated due
to dust or dirt.
Failed internal
data read/out.
The key lock
function enabled.
2000
4000
DPC Error*
Wipe the dust off the Fiber Unit detection surface or
other relevant areas and recover the original incident
light level. Then, perform Smart Tuning.
Turn ON the power again. Reset the settings if the
error is not corrected.
Cancel the key lock function.
Loadshortcircuitdetectionerror
AmpEEPROMtime-outerror
LockON
Refer to " ③Convenient Setting Features"
Failed internal
data read/out.
Turn ON the power again. Reset the settings if the
error is not corrected.
AmpEEPROMchecksumerror
Refer to " ③Convenient Setting Features"
Refer to "2-4 Smart Tuning "
Refer to " ③Convenient Setting Features"
e-st
4000
e-me
01
e-me
02
Overcurrent is carried
to the control output.
Check the connection of the connector between the
Communication Unit and Amplifier.
Overcurrentprotectionerror
e-hd cur
The judgment output
line is short circuited.
Check the connection of the connector between the
Communication Unit and Amplifier.
For information on troubleshooting with Communication Unit, refer to the User’s Manual
provided with the Communication Unit.
dpc
%n
hs
200
stnd
800 6400
shs
100
dpc
%ff
----
9999
MODE
MODE
MODE
2. Detection Function Changing Incident Light Level and Response Time
per
%ff
per
%n
3. DPC Function Stable Detection Regardless of Incident Light Level Change
4. Timer Function Setting Output Timer (Two outputs are displayed)
UP/DOWN
UP/DOWN
12.Inverted Display
Mounting Amplifier in Inverted Direction
11. Digital Display Changing Digital Display in RUN Mode for Specific Purpose
6.BANK Switching Set values are saved for each configured bank.
8.Percentage Tuning
Detecting Transparent or Small Workpiece (Two outputs are displayed)
MODE
MODE
MODE
MODE
MODE
MODE
%ff
B
UP/DOWN
UP/DOWN
UP/DOWN
UP/DOWN
(IncidentLightLevelExample)
Detailed Settings
5
dflt
MODE
1. Function Selection Enabling 6 to 14
ec%
%ff
ec%
%n
UP/DOWN
husr
12
37
husr
12
UP/DOWN
13.Eco Function Saving Power Consumption
MovetoDetectionModebyholdingthebuttonfor3secondsorlonger.
14.
Hysteresis width
Usersetting(Output2)
5. Power Tuning Level Changing the Target Incident Light Level (Power Tuning Level)
%n-d
std
A
A
p-b bar
UP/DOWN
UP/DOWN
2 3 4
hstd
STND Standard Mode
(a)Off-delay Timer
Time Off
(b)On-delay Timer (c)One shot (d)On Off-delay Timer
DPC ON
SHS Super High-speed ModeGIGA Giga Mode
HS
High-speed
Mode
DPC OFF
ptun
%n
ptun
%ff
MODE
7.Power Tuning ON/OFF Setting To Turn ON/OFF the Light Amount Adjustment at Tuning
UP/DOWN
PowertuningadjustmentOFF
Powertuning
adjustmentON
PercentagetuningON
Percentage
tuningOFF
std
9. Output 1 Mode Output mode for the output 1 is changed.
MODE
UP/DOWN
Normal
detectionmode
std
alrm
10.Output 2 Mode
Output mode for the output 2 is changed.
MODE
UP/DOWN
Alarmoutputmode
err
Erroroutputmode
Normal
detectionmode
Basicsetting
Detailedsetting
Threshold
/Receiving
light amount
Normal
Reverse
Ecofunction
OFF
EcofunctionON
Standard
setting
Usersetting
(a)
Marginofreceivinglight
amountagainstthreshold
(b)Minimumvalueofincidentlightpeak
andmaximumvalueofinterruptedlightbottom
(c) Bardisplay
(d)Peakreceivinglightamount
(e)CHnumberand
receivinglightamount
(f)Threshold/Lightintensitywhenthe
workpiecepasses
fd
f
MODE
BANK1
BANK2 BANK3 BANK4
ban
B
150p
3000
3500
9999
2000
3000
2000
8000
T
T
T
T
Off-delay Timer
Holds the output ON for
detection by PLC when
the detection time is too
short.
On-delay Timer
Delays the output ON
after detection.
No Incident Light
Incident Light
No Incident Light
Incident Light
No Incident Light
Incident Light
No Incident Light
Incident Light
ON
OFF
ON
OFF
L-ON
D-ON
ON
OFF
ON
OFF
L-ON
D-ON
Tb
Ta Tb
ON
OFF
ON
OFF
L-ON
D-ON
Ta
(a)
(b)
One-shot Timer
Keeps the output ON for
a specified time regardless
of the workpiece size
variations.
T
T
ON
OFF
ON
OFF
L-ON
D-ON
(c)
ON/OFF-delay Timer
Sets both OFF-delay Timer
and On-delay Timer.
(d)
ban ban ban
area
Areadetectionmode
per
The display reverses.
Threshold and light intensity are displayed on
green digital and white digital respectively.
The indicators (green digital and white digital) turn OFF.
They turn ON for approx. 10 seconds and then turn OFF
by button operation.
The OUT Selection Indicators show items
for Output1/Output 2 individually for each output.
A
Erroroutputmode:OutputwhenanerrorofDPC,
systemoccurs.
MODE
UP/DOWN
Hold button for 3 seconds or longer to enter SET mode.
MODE
SET mode provides the function settings described hereafter. The
initial display shown after transition from one function to another
represents the factory default.
UP/DOWN
Use button to set the power tuning level.
(100 to 9999 in 1 steps; the initial value: 9999)
UP/DOWN
use button to set the power tuning level.
(1 to 9999ms in 1ms steps; the initial value: 10ms)
Function Selection: [ ]
Function Selection: [ ]
Press button in [ ] menu, then use
button to set the percentage tuning level.
(-99% to 99% in 1% steps; the initial value: -6%)
MODE
UP/DOWN
func
func
Detectionfunction
Responsetime
Lightquantity
HS
250μs 1ms 16ms 80μs
x2
STND
x8
GIGA
x64
SHS
x1
Alarm Output Mode: After pressing the button,
press the button to set alarm output level.
(0 to 100p in 1p steps; the initial value: 50p)
On-delayof300msisapplied.
(a)
(b)
(c)
(d)
(e)
(f)
cfdr
MODE
After pressing the button,
The DPC indicator turns ON
when the DPC function is
effective.
●DPC Function
Time
内部受光量
Internal Incident Light Level
Incident Light
Level
Displayed Incident Light Level
Threshold
Level
Stabilizes the displayed
incident level by
correcting internal
incident level changes.
Smart
Tuning
SET
mode
Run Select
DPC Function
ON
Refer to "
②
Settings".
UseoftheDPCfunctionwiththrough-beammodel
orregressivereflectionmodelisrecommended.
Whensmarttuningisinerror/
maximumsensitivitytuningisexecuted/
the1stpointofthepositiontuningissmaller/
areadetectionmode,theDPCfunctionisdisabled.
Laser is not emitted.
[ ] appears
in the display.
Check whether the LD-OFF command is sent from the
Communication Unit.
ch
Themaximumvalueand
minimumvaluearedisplayed
withLight-ONandDark-ON
respectively.
(Referencevalue)
2000
Set the hysteresis width by initial value. Hysteresis width is provided for
threshold to prevent the judgment output from becoming unstable
near the boundaries.
Besuretocheckthestabilityofoutputs
asthereisapossibilityofchattering.
Thehysteresiswidthcanbesetbypressingthebuttoninthemenu
of"husr"andthenpressingthebutton.(0to9999,incrementsof1)
MODE
UP/DOWN
Suitability for Use
r
Omron Companies shall not be responsible for conformity with any standards,
codes or regulations which apply to the combination of the Product in the
Buyer’s application or use of the Product. At Buyer’s request, Omron will
provide applicable third party certification documents identifying ratings and
limitations of use which apply to the Product. This information by itself is not
sufficient for a complete determination of the suitability of the Product in
combination with the end product, machine, system, or other application or
use. Buyer shall be solely responsible for determining appropriateness of the
particular Product with respect to Buyer’s application, product or system.
Buyer shall take application responsibility in all cases.
NEVER USE THE PRODUCT FORAN APPLICATION INVOLVING
SERIOUS RISK TO LIFE OR PROPERTY WITHOUTENSURING THAT THE
SYSTEM ASA WHOLE HAS BEEN DESIGNED TO ADDRESSTHE RISKS,
AND THAT THE OMRON PRODUCT(S) IS PROPERLY RATEDAND
INSTALLED FORTHE INTENDED USE WITHIN THE OVERALL
EQUIPMENT OR SYSTEM.
See also Product catalog for Warranty and Limitation of Liability.
Sep, 2013
D
OMRON Corporation Industrial Automation Company
Contact: www.ia.omron.com
Tokyo, JAPAN
OMRON ELECTRONICS LLC
One Commerce Drive Schaumburg,
IL 60173-5302 U.S.A.
Tel: [phone]/Fax: [phone]
OMRON ASIA PACIFIC PTE. LTD.
No. 438AAlexandra Road # 05-05/08 (Lobby 2),
Alexandra Technopark,
Singapore 119967
Tel: [phone]/Fax: [phone]
OMRON (CHINA) CO., LTD.
Room 2211, Bank of China Tower,
200 Yin Cheng Zhong Road,
PuDong New Area, Shanghai, 200120, China
Tel: [phone]/Fax: [phone]
OMRON EUROPE B.V.
Sensor Business Unit
Carl-Benz-Str. 4, D-71154 Nufringen, Germany
Tel: [phone]/Fax: [phone]
Regional Headquarters
