Omron V320-F Series Instruction Manual

Z414-E1-01
Programmable Controller CJ-series
Serial (RS-232C) Communications
Connection Guide
OMRON Corporation
Auto Focus Multi Code Reader
V320-F / V420-F / V430-F-series

About Copyrights and Trademarks
Microsoft product screen shots used with permission from Microsoft.
Windows is a registered trademark of Microsoft Corporation in the USA and other countries.
Sysmac and SYSMAC are trademarks or registered trademarks of OMRON Corporation in
Japan and other countries for OMRON factory automation products.
Company names and product names in this document are th
e trademarks or registered
trademarks of their respective companies.

Contents
1. Related Manuals ........................................................................................ 1
2. Terms and Definitions ............................................................................... 2
3. Restrictions and Precautions................................................................... 3
4. Overview .................................................................................................... 4
5. Applicable Devices and Support Tools ................................................... 5
5.1. Applicable Devices............................................................................. 5
5.2. Device Configuration.......................................................................... 6
6. Serial Communications Settings ........................................................... 12
6.1. Serial Communications Settings ...................................................... 12
6.2. Cable Wiring Diagram ...................................................................... 13
6.3. Example of Connection Check for Communications ........................ 15
7. Connection Procedure ............................................................................ 16
7.1. Operation Flow................................................................................. 16
7.2. Code Reader Setup ......................................................................... 17
7.3. PLC Setup........................................................................................ 22
7.4. Checking That Serial Communications Work ................................... 42
8. Initializing the System............................................................................. 49
8.1. Initializing the PLC ........................................................................... 49
8.2. Initializing the Code Reader ............................................................. 51
9. Program.................................................................................................... 52
9.1. Overview .......................................................................................... 52
9.2. Communications Sequence ............................................................. 56
9.3. Error Judgment Processing.............................................................. 57
9.4. Memory Map .................................................................................... 58
9.5. Ladder Program ............................................................................... 61
9.6. Protocol Macro Data ........................................................................ 67
9.7. Timing Chart..................................................................................... 74
9.8. Error Processing .............................................................................. 75
10.Revision History .................................................................................. 76

1. Related Manuals
1
1. Related Manuals
The following manuals are related to this document.
To ensure system safety, make sure to always read and follow the information provided in all
Safety Precautions and Precautions for Safe Use in the manuals for each device which is
used in the system.
Cat. No. Model Manual name
W472 CJ2H-CPU6□-EIP
CJ2H-CPU6□
CJ2M-CPU□□
CJ-series
CJ2 CPU Unit
Hardware User’s Manual
W473 CJ2H-CPU6□-EIP
CJ2H-CPU6□
CJ2M-CPU□□
CJ-series
CJ2 CPU Unit
Software User’s Manual
W336 CJ1W-SCU□1-V1
CJ1W-SCU□2
CJ-series
Serial Communications Boards/Units
Operation Manual
W446 CXONE-AL□□C-
V4 /
AL□□D-V4
CX-Programmer Operation Manual
W344 CXONE-AL□□C-
V4 /
AL□□D-V4
CX-Protocol Operation Manual
W474 CJ2□-CPU□□ CJ-series
Instructions Reference Manual
Z432 V320-F/V330-F/V420-F/
V430-F Series
MicroHAWK V320-F/V330-F/V420-F/V430-F
Series Barcode Reader User Manual
Z407
V320-F/V330-F/V420-F/
V430-F Series
Autofocus Multicode Reader MicroHAWK
V320-F/V330-F/V420-F/V430-
F Series User
Manual for Communication Settings

2. Terms and Definitions
2
2. Terms and Definitions
Term Description/Definition
Protocol Macro This function enables data send/receive with general-
purpose external
devices by storing the data send/receive procedure (Protocol) used with
the general-purpose external devices in the Serial Communication Board
or Unit and executing the PMCR instruction in the CPU Unit.
Protocol The unit that comprises an independent communication processing for a
specific general-purpose external device as a data send/receive procedure
is called a “Protocol”. A “protocol” consists of two or more sequences.
Sequence
A unit of independent communication processing that can be activated
from the PMCR instruction on the ladder program. When activated, the
steps in the sequence are executed sequentially.
Step A unit to execute processing, which is send message, receive message,
send and receive message, clear receive buffer, or step queuing. Up to 15
steps can be set in a sequence.
Send Message A communication frame (command) sent to a general-purpose external
device. It is called from a step in a sequence and sent to a general-purpose
external device.
Receive Message A communication frame (response) sent from a general-purpose external
device. It is called from a step in a sequence and compared with data
received from the general-purpose external device.
Reception Matrix
A reception matrix is used when it is impossible to uniquely identify
communication frames (responses) sent from a general-purpose external
device. In a reception matrix, more than one communication frame can be
registered.
Case
A unit for registering multiple communication frames (responses) in a
reception matrix. One communication frame is registered as one case. Up
to 15 cases can be registered in a reception matrix.

3. Restrictions and Precautions
3
3. Restrictions and Precautions
(1) Before building a system, understand the specifications of devices which are used in the
system. Allow some margin for ratings and performance, and provide safety measures
such as installing a safety circuit in order to minimize the risk in case of failure.
(2) To ensure system safety, make sure to read and follow the information provided in all
Safety Precautions and Precautions for Safe Use in the manuals for each device which is
used in the system.
(3) The user is encouraged to confirm the standards and regulations that the system must
conform to.
(4) It is prohibited to copy, to reproduce, and to distribute a part or the whole of this
document without the permission of OMRON Corporation.
(5) The information contained in this document is current as of February 2023.
It is subject to change for improvement without notice.
The following notations are used in this document.
Indicates a potentially hazardous situation which, if not avoided,
may result in minor or moderate injury, or may result in serious
injury or death. Addition
ally, there may be severe property
damage.
Indicates a potentially hazardous situation which, if not avoided,
may result in minor or moderate injury, or property damage.
Precautions for Safe Use
Precautions on what to do and what not to do to ensure safe usage of the product.
Precautions for Correct Use
Precautions on what to do and what not to do to ensure proper operation and performance.
Note
Additional information to read as required.
This information is provided to increase understanding or make operation easier.
Symbols
The filled circle symbol indicates operations that you must do.
The specific operation is shown in the circle and explained in text.
This example shows a general precaution for something that you must do.

4. Overview
4
4. Overview
This document describes the procedures for connecting the OMRON code reader products
(V320-F/V420-F/V430-F Series) to a CJ Series Programmable Controller with a Serial
Communications Unit (hereinafter referred to as PLC) via serial communications and for
checking their connections.
Refer to Section 6. Serial Communication Settings and Section 7. Connection Procedure to
understand the setting procedures and key points of setup to establish a serial
communications connection.
Using the user program in the “CX-Programmer Project File” and the protocol data in the
“CX-Protocol Project File” prepared in advance, use the “Read trigger” command for the code
reader to check the serial communications connection.
Obtain the latest versions of the CX-Programmer Project File and CX-Protocol Project File in
advance. Contact OMRON for information on how to obtain these files.
Name Filename Version
CX-
Programmer Project
File (Extension: cxp)
OMRON_V320_V420_V430_PMCR232C_V
100.cxp
Ver. 1.00
CX-Protocol Proj
ect File
(Extension: psw)
OMRON_V320_V420_V430_PMCR_V100.p
sw
Ver. 1.00
* Hereinafter, the CX-Programmer Project File is called “project file”.
The user program in a project file is called “ladder program” or “program”.
The CX-Protocol Project File is called “protocol macro data”.
The purpose of this document is to describe the wiring methods, communication
settings, and setting procedures re
quired to establish a connection for
communications with applicable devices. In addition, the program used in th
is
document is designed to check that the connection has been correctly
performed (connection check). Since the program is not intended for perm
anent
use on-
site, full consideration is not given to functionality and performance.
When configuring an actual
system, please refer to the wiring methods,
communication settings, and setting procedures described in this document to
design and create a program that meets your purpose.

5. Applicable Devices and Support Tools
5
5. Applicable Devices and Support Tools
5.1. Applicable Devices
The applicable devices that can be connected are as follows:
Manufact
urer
Name Model Version
OMRON
CJ2 CPU Unit
CJ2□-CPU□□
Same or
later
version as
indicated in
section
5.2.
OMRON Serial Communications Unit
CJ1W-SCU□1-V1
CJ1W-SCU□2
OMRON Code reader V320-F□□□□□□□-□□□
V420-F□□□□□□□-□□□
V430-F□□□□□□□-□□□
Note
From among the above applicable devices, this document uses the devices listed in section
5.2 for the connection check. When using devices that are not described in section 5.2, check
the connection according to this document.
Note
This document describes the procedures for establishing the communication connection of
the device, and does not describe the operation, installation and wiring method of the device.
For details on the above products (other than communication connection procedures), please
refer to the instruction manual for the product or contact OMRON.
Precautions for Correct Use
The connection and connection check procedures described in this document use the
devices listed in section 5.2, from among the above applicable devices.
You cannot use devices with versions earlier than the versions listed in section 5.2.
To use models that are not listed in section 5.2. or versions that are later than those listed in
section 5.2., check the differences in the specifications according to their instruction manuals
before operating the devices.

5. Applicable Devices and Support Tools
6
5.2. Device Configuration
The system components required for reproducing the connection procedures described in this
document are as follows.
・Configuration with V320-F
Manufact
urer
Name Model Version
OMRON
CPU Unit
CJ2M-CPU11
Ver. 2.0
OMRON
Serial Communications Unit
CJ1W-SCU22
Ver. 2.0
OMRON
Power Supply Unit
CJ1W-PA202
OMRON
CX-One
CXONE-AL□□C-V4
/AL□□D-V4
Ver. 4.□□
OMRON
CX-Programmer
(Included with CX-One)
Ver. 9.66
OMRON
CX-Protocol
(Included with CX-One)
Ver. 1.993
OMRON
CX-Programmer Project File (Ladder
Program)
OMRON_V320_V420_V
430_PMCR232C_V100.
cxp
Ver. 1.00
OMRON
CX-Protocol Project File
(Protocol macro data)
OMRON_V320_V420_V
430_PMCR_V100.psw
Ver. 1.00
PC (OS: Windows 10)
USB cable
(USB 2.0-compliant B-type connector)
OMRON
Code reader
V320-F000M12M-SRX
Ver. 2.1.0
OMRON
RJ50 to RS-232 and external power
supply,
straight
V320-WRX-2M
OMRON
OMRON Programmable Controller
(CS/CJ/NJ) RS-232C cable
V430-WPLC-2M*1
OMRON
Power supply
97-900006-01
AC power supply
*1. Refer to 6.2. Cable Wiring Diagram for how to prepare the RS-232C cable yourself.
CJ2M-CPU11
CJ1W-SCU22
PC
(OS: Windows 10,
CX-One Installed)
USB cable
V430-WPLC-2M*1
RJ50 to RS-232 and external
power supply,
straight
V320-WRX-2M
AC power
V320-F000M12M-SRX
97-900006-01

5. Applicable Devices and Support Tools
7
WebLink cannot be used for RS-232C connection.
To use WebLink, the following system components for USB connection are required.
Manufact
urer
Name Model Version
PC (OS: Windows 10)
OMRON
Code reader
V320-F000M12M-SRX
Ver. 2.1.0
OMRON
V/F320-F adapter for all V420-F cable
accessories, RJ50 to DB-15
V320-WR-1M
OMRON
USB breakout cable
V420-WUB-1M
V320-F000M12M-SRX
V/F320-F adapter for all
V420-F cable accessories,
RJ50 to DB-15
V320-WR-1M
USB breakout cable
V420-WUB-1M
PC
(OS: Windows 10)

5. Applicable Devices and Support Tools
8
・Configuration with V420-F
Manufact
urer
Name Model Version
OMRON
CPU Unit
CJ2M-CPU11
Ver. 2.0
OMRON
Serial Communications Unit
CJ1W-SCU22
Ver. 2.0
OMRON
Power Supply Unit
CJ1W-PA202
OMRON
CX-One
CXONE-AL□□C-V4
/AL□□D-V4
Ver. 4.□□
OMRON
CX-Programmer
(Included with CX-One)
Ver. 9.66
OMRON
CX-Protocol
(Included with CX-One)
Ver. 1.993
OMRON
CX-Programmer Project File (Ladder
Program)
OMRON_V320_V420_V
430_PMCR232C_V100.
cxp
Ver. 1.00
OMRON
CX-Protocol Project File
(Protocol macro data)
OMRON_V320_V420_V
430_PMCR_V100.psw
Ver. 1.00
PC (OS: Windows 10)
USB cable
(USB 2.0-compliant B-type connector)
OMRON
Code reader
V420-F000M12M-SRX
Ver. 2.1.0
OMRON
Cable (RS-232 breakout (DB-15)
and external power supply input)
V420-WRX-1M
OMRON
OMRON Programmable Controller
(CS/CJ/NJ) RS-232C cable
V430-WPLC-2M*1
OMRON
Power supply
97-900006-01
AC power supply
*1. Refer to 6.2. Cable Wiring Diagram for how to prepare the RS-232C cable yourself.
CJ2M-CPU11
CJ1W-SCU22
PC
(OS: Windows 10,
CX-One Installed)
USB cable
V430-WPLC-2M*1
Cable (RS-232 breakout
(DB-15)
and external power supply
input)
V420-WRX-1M
AC power
V420-F000M12M-SRX
97-900006-01

5. Applicable Devices and Support Tools
9
WebLink cannot be used for RS-232C connection.
To use WebLink, the following system components for USB connection are required.
Manufact
urer
Name Model Version
PC (OS: Windows 10)
OMRON
Code reader
V420-F000M12M-SRX
Ver. 2.1.0
OMRON
USB breakout cable
V420-WUB-1M
V420-F000M12M-SRX
USB breakout cable
V420-WUB-1M
PC
(OS: Windows 10)

5. Applicable Devices and Support Tools
10
・Configuration with V430-F
Manufact
urer
Name Model Version
OMRON
CPU Unit
CJ2M-CPU11
Ver. 2.0
OMRON
Serial Communications Unit
CJ1W-SCU22
Ver. 2.0
OMRON
Power Supply Unit
CJ1W-PA202
OMRON
CX-One
CXONE-AL□□C-V4
/AL□□D-V4
Ver. 4.□□
OMRON
CX-Programmer
(Included with CX-One)
Ver. 9.66
OMRON
CX-Protocol
(Included with CX-One)
Ver. 1.993
OMRON
CX-Programmer Project File (Ladder
Program)
OMRON_V430_PMCR2
32C_V100.cxp
Ver. 1.00
OMRON
CX-Protocol Project File
(Protocol macro data)
OMRON_V430_PMCR_
V100.psw
Ver. 1.00
PC (OS: Windows 10)
USB cable
(USB 2.0-compliant B-type connector)
OMRON
Code reader
V430-F000M12M-SRX
Ver. 2.1.0
OMRON
RS-232C-to-I/O two-way cable
V430-WQR-3M
OMRON
OMRON Programmable Controller
(CS/CJ/NJ) RS-232C cable
V430-WPLC-2M*1
OMRON
I/O Cable
V430-W8-3M
OMRON
Ethernet cable
V430-WE-3M
24 VDC power supply
*1. Refer to 6.2. Cable Wiring Diagram for how to prepare the RS-232C cable yourself.
Precautions for Correct Use
Obtain the latest versions of the project file and protocol macro data in advance.
Contact OMRON for information on how to obtain these files.
I/O Cable
V430-W8-3M
CJ2M-CPU11
CJ1W-SCU22
PC
(OS: Windows 10,
CX-One Installed)
USB cable
V430-WPLC-2M*1
Ethernet cable
V430-WE-3M
RS-232C-to-I/O
two-way cable
V430-WQR-3M
24 VDC
V430-F000M12M-SRX

5. Applicable Devices and Support Tools
11
Precautions for Correct Use
Ensure that the CX-Programmer and CX-Protocol are updated to the versions specified in
this section or higher. If you use a version other than the version specified in this section,
there may be differences in the procedures in Section 7 and later. In that case, refer to the
CX-Programmer Operation Manual (Cat. No. W446) or CX-Protocol Operation Manual (Cat.
No. W344) to perform the equivalent procedures.
Note
The configuration may not be reproduced if the system component models or versions differ.
Check your configuration and, if there is any difference in the models or versions, contact
OMRON.
Note
This document assumes that the USB is used to connect the PLC. For information on how to
install the USB driver, refer to the CX-Programmer Operation Manual (Cat. No. W446).
Note
Refer to the Industrial Switching Hub W4S1 Series User Manual (0969584-
7) for power
supply specifications that can be used for 24 VDC power supply (for the switching hub).
Note
Refer to the MicroHAWK V320-F/V330-F/V420-F/V430-
F Series Barcode Reader User
Manual (Cat. No. Z432) for the power supply specifications that can be used for 24 VDC
power supply (for the code reader).

6. Serial Communications Settings
12
6. Serial Communications Settings
This section shows the specifications of the communication parameter settings, cable wiring,
and other information provided in this document.
Note
You need to modify the program to use communication settings that are not described in this
section. For more information on the program, please refer to Section 9. Program.
6.1. Serial Communications Settings
The serial communications settings are as follows.
Parameter name SCU Unit*Code reader
Unit number 0 ---
Communications
(connection) port
Port 2 (RS-232C) ---
Serial communications mode Protocol macro ---
Data length 8 bits 8 bits (default)
Stop bit 1 bit 1 bit (default)
Parity None None (default)
Baud rate 9,600 bps (default) 9,600 bps
Protocol macro transmission
method
Full-duplex ---
Header --- None (default)
Footer --- <CR+LF> (default)
Host port protocol --- Point-to-point (default)
* SCU Unit: Serial Communications Unit
Precautions for Correct Use
It is assumed that the CJ1W-
SCU22 Serial Communications Unit is used with the unit
number is 0and the communications (connection) port Port 2. If using other conditions to
connect the Unit, refer to Section 9. Program and create a program by modifying the control
data in the CIO Area and PMCR Instruction.

6. Serial Communications Settings
13
6.2. Cable Wiring Diagram
For details on cable wiring, refer to Section 3 Installation and Connection in the CJ-series
Serial Communications Boards/Units Operation Manual (Cat. No. W336).
Check the connector shape and signal lines (pin assignment) before you prepare the cable.
■ Connector Shape and Signal Lines (Pin Assignment)
Applicable connector for CJ1W-SCU22: D-SUB 9-pin (Connector shape on CJ1W-SCU22
side: Female)
Pin No.
Abbreviation
Signal name
I/O
1
FG
Shield
---
2
SD
Send data
Output
3
RD
Receive data
Input
4
RS
Request to send
Output
5
CS
Clear to send
Input
6
5V
Power supply
---
7
DR
Data set ready
Input
8
ER
Data terminal ready
Output
9
SG
Signal ground
---
Shell
FG
Shield
---
Applicable connector for V Series RS-232C cable: D-SUB 9-pin (Connector on V Series side:
Female)
Pin No.
Signal name
Pin assignment

6. Serial Communications Settings
14
■ RS-232C Cable Pin Assignment
Prepare the RS-232C cable with reference to the following wiring diagram.
Serial Communications Unit
(CJ1W-SCU22) side
RS-232C-to-I/O two-way cable (V
Series) side
RS-232C
interface
Signal
name
Pin No. Pin No.
Signal
name
RS-232C
interface
FG
1
1
NC
SD
2
2
SD
RD
3
3
RD
RS
4
4
NC
CS
5
5
0V
5V
6
6
NC
DR
7
7
NC
ER
8
8
NC
SG
9
9
NC
FG
Shell
Shell
FG
D-SUB 9-pin
Cable connector shape: Male
D-SUB 9-pin
Cable connector shape: Male
For V430-F
CJ2M-CPU11
CJ1W-SCU22
RS-232C cable
RS-232C-to-I/O two-way
cable
V430-WQR-3M
I/O Cable
V430-W8-3M
V430-F00M12M
24 VDC

6. Serial Communications Settings
15
6.3. Example of Connection Check for Communications
In this document, an example of sending and receiving messages between the controller and
the code reader using a ladder program and protocol macro data is given.
Between the PLC and the code reader, the “Execute Read (Sequence No. 900)” message is
sent and received. An overview of the sequence operation is shown below.
● Sequence Operation Overview
(1) In the ladder program, the PROTOCOL MACRO instruction (PMCR instruction) is
executed with sequence No. 900 of the protocol macro data specified.
(2) “Read trigger” command is selected from sequence No. 900 of the protocol macro data
and sent to the code reader.
(3) The code reader executes the command according to the data sent from the PLC.
(4) The PLC receives the execution result of the command from the code reader and stores
it in the specified memory address.
PLC
RS-232C Code reader
CPU Unit
Serial Communications Unit
Project file
Ladder program
PMCR
Send data
Receive data
(2) Read Trigger
(Sequence No. 900)
Protocol macro data
Sequence No. 1
Sequence No. 2
Sequence No. 900
Words starting
from 5501
Receive data
storage area
(1) PROTOCOL MACRO
instruction execution
(with sequence No. 900
specified)
(3) Command execution
(4) Execution result of
command is
received and stored
in specified memory
address

7. Connection Procedure
16
7. Connection Procedure
This section describes the procedures for connecting the code reader to the PLC for serial
communications.
In this document, it is assumed that the PLC and the code reader use the factory default
settings. For how to initialize the devices, refer to Section 8. Initializing the System.
7.1. Operation Flow
Use the following procedures to connect the code reader to the PLC for serial
communications.
7.2. Code Reader Setup
Set up the code reader.
▼
7.2.1. Setting the Parameters
Set the parameters for the code reader.
▽
7.3. PLC Setup
Set up the PLC.
▼
7.3.1. Setting the Hardware
Set the hardware switch on the Serial
Communications Unit.
▼
7.3.2. Loading the Project File and
Going Online with the PLC
Start the CX-Programmer, load the project file, and go
online with the PLC.
▼
7.3.3. Creating the I/O Table
Create the I/O table for the PLC.
▼
7.3.4. Setting the Parameters
Set the parameters for the Serial Communications
Unit.
▼
7.3.5. Transferring the Project Data
Transfer the project data to the PLC.
▼
7.3.6. Starting the CX-Protocol and
Loading the Prot
ocol Macro
Data
Start the CX-Protocol and load the protocol macro
data.
▼
7.3.7 Going Online and Transferring
the Protocol Macro Data
Go online with the CX-Protocol and transfer the
protocol macro data to the Serial Communications
Unit.
▽
7.4. Checking That Serial
Communications Work
Execute the program to check that serial
communications work correctly.
▼
7.4.1. Starting a Trace
Start a trace in the CX-Protocol.
▼
7.4.2. Executing the Program
Execute the program in the CX-Programmer.
▼
7.4.3. Checking the Trace Data
Using the trace data of the CX-Protocol, check that
the correct data is sent and received.
▼

7. Connection Procedure
17
7.4.4. Checking the Receive Data
In the CX-Programmer, check that the correct data is
written to the I/O memory of the PLC.
7.2. Code Reader Setup
Set up the code reader.
Precautions for Correct Use
Use a PC (personal computer) to set the parameters for the code reader.
Note that you may need to change the PC settings depending on the condition of your PC.
7.2.1. Setting the Parameters
Set the parameters for the code reader.
Set the IP address of your PC to 192.168.188.101 and its subnet mask to 255.255.0.0.
1
[Using V320-F/V420-F]
Establish a USB connection between the V320/V420 and the PC according the configuration
shown on page 7 or page 9.
Once the connection is established, start the procedure from step 4.
* To use V320/V420, you need to install the driver. For how to install the driver, refer to 2-2-3
Connect to WebLink in the MicroHAWK V320-F/V330-F/V420-F/V430-F
Series Barcode
Reader User Manual (Cat. No. Z432).
[Using V430-F]
Connect the RS-232C-to-I/O
two-way cable V430-WQR-3M
to the I/O connector.
Then, connect the I/O connector
of V430-WQR-
3M to the I/O
cable V430-W8-3M.
Connect the 24V and 0V wires
of W430-W8-
3M to a 24 VDC
power supply.
* In this document, only the
power supply wires of the
I/O cable are connected
and checked. Be careful not
to short-circuit any other
wires.
* Ground the shield wire as
needed. For more information
on grounding, please refer to
Grounding in Appendices of
the MicroHAWK
V320-F/V330-F/V420-F/V430
-F Series Barcode Reader
User Manual (Cat. No. Z432).
24 VDC
power
supply
I/O
Connector
I/O Cable
V430-W8-3M
D-SUB
9-pin
RS-232C-to-I/O
two-way cable
Red Striped
Gray Striped
