Instruction Manual
Automatic Digital
Blood Pressure Monitor
Model HEM-703CP
HEM-703CP-xxxx 0692581-7 A

1
Important
CONTENTS
Important  1
Name and Function of Each Part         2
Preparations for Use                  3
Instructions for Use                   8
When Error Indication Symbols Appear   10
Specications  11
Thank you for purchasing our Digital Blood
Pressure & Pulse Monitoring Kit Please care-
fully read this instruction manual before use
and keep it with your portion of the enclosed
warranty card
PLEASE NOTE:
1 Allow 3 to 5 minutes between blood pres-
sure readings on same arm Repeated
mea-surement results in inaccurate
readings
2 Keep in mind only a physician can ac-
curately determine safe or unsafe limits
of blood pressure This instrument should
be used by non-professional persons only
to determine measurement of blood pres-
sure, not to make any medical judgement
Remember, blood pressure varies during
the day
3 This unit is a precision instrument − avoid
rough handling, direct sunlight, high tem-
perature/humidity and magnetic eld
Fold-ing or bending cuff may result in
damage to cuff
4 Do not inate cuff above 280 mmHg
5 Do not take unit apart You cannot
calibrate unit If you have any difculties
or problems with unit, contact our Service
Center 1-800-634-4350

2
Name and Function of Each Part
Air Jack
Systolic Bood Pressure Display
Diastolic Blood Pressure and Pulse Display
Printing Paper
Paper Cutter
SPHYG/CLOCK Button
START Button
PRINT / PAPER FEED Button
SET Button
Tab
Air Plug
Air Tube
MODE Selector Button
Main Unit
Cuff

3
Preparations for Use
1 How to insert the batteries
Battery Cover
1 Take off the battery cover at the back of
the main unit by sliding it in the direction
indicated by the arrow symbol
Replacement
• When the “Replace Batteries” symbol
( ) ashes during measurement,
please replace the batteries with the
new ones
• When the batteries have run down,
random numbers may be displayed
Points to be careful about whan using
the batteries
• When replacing the batteries please
replace all four batteries at once
• Use the same kind of batteries
• Take out weak batteries quickly so as to
avoid causing damage to the machine
• Remove the batteries when the unit is
not used for extended periods
2 Install 4 “AA” size batteries attached so
that the + and - polarities on the
batteries correctly match the polarities in
the battery compartment
3 Replace the cover

4
Preparations for Use
2 How to Set Time and Date 3 Plug in and Turn on
1 When batteries are installed, the display
shows PM 12:00
1 Insert the air plug into the air jack on the
left side of the main unit correctly
2 When the SPHYG/CLOCK button is
changed to the sphygmomanometer mode,
all the LCD symbols are momentarily
displayed This happens because the unit
is running a check on the display and this
state lasts for approximately one second
3 Once the LCD symbols vanish, the air
release indication symbol (  ) starts
ashing Please wait until the (  ) symbol
goes out
4 When the preparations necessary before
measurement have been completed, the
unit emits a series of beeps and nally the
“Ready to Measure” symbol ( ♥ ) will be
displayed
2 When the MODE button is pressed
down, the “month” sign is displayed
When the SET button is pressed down,
the gure for the month increases Adjust
the “month”
3 When the MODE button is pressed
down after the “month” has been adjusted,
the “day” sign is displayed Adjust the
“day” in the same way as the “month”
4 In the same manner select the “hour” and
“min” with the MODE button and set
each value with the SET button  AM and
PM signs are switched in accordance with
the “hour” adjsutment
5 Press the MODE button for the last time
and return the screen to normal time (hour,
min) display
Initial Display
“Ready to Measure”
Display
Air release
indication symbol

5
Preparations for Use
4 How to Set the Printing Paper
Please be sure not to print without inserting
printing paper as it will shorten the life span
of the printer head
1 Slide the plastic printer cover in the
direction indicated by the arrow symbol
and remove it from the main unit
4 Insert the printing paper in the installation
section, and then attach the cover back to
the main unit in such a way that the edge
of the paper protrudes from the cover
5 When the PRINT/PAPER FEED button
is pressed while the results of the
measurement are shown on the digital
display, these results, together with the
date and time of measurement are printed
out
6 When purchasing printing paper, ask at the
shop where you purchased the main unit
for further supply Other brands of paper
may be used providing the dimensions are
smaller than 38mm wide and 20mm in di-
ameter However the printing quality may
differ a little
2 Peel off the glued edge of the prontlng
paper included with the unit, and cut it off
to about 2 inches with a pair of scissors,
and then shape and cut the edge for easy
insertion to the printer as shown in the
gure
3 Press the PRINT/PAPER FEED button
while inserting the edge of the printing
paper to the paper feeding slit When the
edge of the paper protrudes sufciently,
release the button and stop feeding
Inserting Direction
Reverse
Front

6
Preparations for Use
5 Changing the Printer Ink
Though not originally equipped with an ink
roller, the HEM-703CP digital blood pressure
monitor contains enough printer ink to last
about two years when used once a day at
normal room temperature
When the ink on the print out becomes light
and hard to read, purchase a replacement ink
roller from your retailer and install as fol-lows
1 Remove the printer cover
3 Insert the supplement ink roller into the
allotted space next to the printer
4 Replace the printer cover
NOTE: The supplement ink roller should
last about two years, however, if you
need to replace the supplement ink
roller, simply grasp the top of the ink
roller and turn itslightlycounterc1ock-
wise before lifting the roller from the
printer
Supplement ink roller
2 Removethe ink, which came with the
unit when you bought it, from the allotted
space

7
about 1 inch
Artery
no space
Preparations for Use
6 Attach the Cuff
This cuff has eliminated the need for a
microphone thereby lessening possible
interference from vibrations and noise Fitting
also has been made much easier through the
widening of the artery oscillation detection
area
1 Place the cuff on the left arm so that the air
tube lies across the center of the arm
3 Place your arm on a table or a support with
the palm facing upward so that the cuff is
placed at the same level as the heart
2 Wrap the cuff pulling in a diagonal angle
securely so that the cuff tab is positioned
about one inch above the elbow joint of the
inner your left upper arm (Over the brachi-
al artery)
There should be no space between the
cuff and your arm
NOTE: If you have any difculties wrap-ping
cuff by yourself, we recom-mend that
you ask someone to wrap the cuff for
you

8
Preparations for Use
7 Apply Pressure to the Cuff
1 When you press the start button, the pump
operates and pressure is applied When
the pressure reaches 170mmHg, the
pump stops automatically
2 When the appropriate pressure has been
reached, the air is automatically released
and the value on the display window
starts to decrease After a while when the
artery oscillations are detected, the ( ♥ )
symbol starts ashing and the unit emits
a beep-ing sound simultaneously The
value shown on the display will continue
to fall
* During measurement, do not shake
the cuff or the air tube
Depress the START
button continuously
untill the cuff is inated
up to the targeted
pressure
After the cuff has
been inated,
release the START
button
Notes:
* If your systolic blood pressure is higher
than 140mmHg, the pump starts again and
the cuff will be inated up to 210mmHg
* If your systolic blood pressure is higher
than 180mmHg, sufcient ination will
not be applied to the cuff by automatic
reination In this case, inate up to
30mmHg higher than your expected
systolic blood pressure by pressing the
start button continuously While press-ing
the start button, the cuff can be in-ated
continuously, and when the start button
is released, the pump stops and the cuff
is no longer inated When the pressure
reaches 300mmHg, the cuff deates
rapidly
* When you want to stop measurememt,
press SPHYG/CLOCK button The pres-
sure will stop and the air is deated rapidly
Pressure being applied
Targetted Blood
Pressure Reached
Indicated Value Drops
Measuring

9
Measurement
Completed
Alternate Display
Blood Pressure
Reading Display
(for approx 3
seconds)
Pulse Reading
Display
(for approx 15
seconds)
*P: Stands for PULSE
Preparations for Use
8 Blood Pressure and Pulse are displayed
When the deation symbol begins to ash,
the residual pressure in the cuff is then
rapidly released
1 When the unit has continued to deate
to a point when the artery oscillations are
no longer detected, the unit will display
the systolic and diastolic blood pressure
values, along with a long beep, and causes
the deation indication symbol (  ) to start
ashing After this, blood pressure and the
pulse readings are displayed alter-nately
* When you wish to stop measuring during
operation, press the SPHYGICLOCK
button The pump will stop and all the cuff
pressure will be released rapidly
* When the PRINT button is pressed while
the results of the measurement are shown
on the digital display, the results will be
printed
3 Measurement of the blood pressure is
now complete The results will remain
displayed even after the cuff is taken
off If you wish to carry out repeated
measurements, repeat the operation from
Step 6
* The arm gradually becomes congested
when measurements are repeatedly
taken If you wish to take consecutive
measurements, take off the cuff and
wait at least 3 to 5 minutes between
measurements
4 When measurement is completed press
the SPHYG/CLOCK button to return to the
time display If you should forget to press
this button, the display will return to time
display mode automatically after about 5
minutes
2 Upon total cuff deation, a series of
beeps are emitted and the ( ♥ ) symbol is
displayed

10
When Error Indication Symbols Appear
The following special error symbols will appear in the display if the unit is being used incorrectly:
ERROR SYMBOL CAUSE CORRECTION
1 Cuff underinated 1) Release air pressure in cuff
2) Wait 10 minutes before taking
another reading
3) Repeat “Instructions for Use”
steps except inate cuff 30
mmHg higher than previous
ination value
2 Movement during
measurement
Residual air pressure
in cuff
1) Release air pressure in cuff
2) Wait 10 minutes before taking
another reading
3) Repeat “Instructions for Use”
steps
Cuff overinated (more
than 300 mmHg)
No pulse or blood
pressure reading due to:
1) Motion
2) Very weak artery
oscillation

11
Specications
Power Source: Battery (four type “AA” dry cell batteries) 6V 4W
Measurement Method: Oscillometric Method
Display: Liquid Crystal Digital Display
Measurement Range: Pressure: 0 ~ 280mmHg
Pulse: 40 ~ 200/minute
Accuracy: Pressure: within ± 3 mmHg
Pulse: within ± 5% reading
Pressure Detection: Capacitive Pressure Sensor
Ination: Automatic Pressure Application by a Pump
Deation and Rapid Air Release: Automatic pressure release valve
Automatic-shut-off System When the internal pressure in the unit continues
at less than 20mmHg for about 5 ~ 8 minutes, the
mode changes automatically to clock
Printer: Serial static impact printer
Operating/Temperature, Humidity: +500F to +104°F (+100C to +40 0C) 30-85% RH
StorageiTemperature, Humidity: -4°F to 140°F (-20°C to + 600C) 10-95% RH
Dimensions (Approx): Main Unit: 82/4” (w) X 51/8” (d) x 23/5” (h) (215
x 130x 66 mm)
Cuff: 51/2 “(w) x 184/5”(1) (140x 480 mm)
Cuff Range: For arms 9” to 13” in circumference
Weight: Main Unit: approx 201/2 oz (580 g)including
batteries
Cuff: approx 42/5 oz (125 g)
Accessories: Cuff, instruction manual,
Printing paper: 2 rolls
Optional parts: AC Adaptor
Specications subject to change without notice

12
This equipment generates and used radio frequency energy and if not installed and used properly,
that is, in strict accordance with the manufacturer’s instructions, may cause interference to radio
and television reception It has been type tested and found to comply with the limits for a Class
B computing device in accordance with the specications in Subpart J of Part 15 of FCC Rules,
which are designed to provide reasonable protection against such interference in a residential
installation However, there is no guarantee that interference will not occur in a particular
installation If this equipment does cause interference to radio or television reception, which can
be determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
- reorient the receiving antenna
- relocate the computer with respect to the receiver
- move the computer away from the receiver
- plug the computer into a different outlet so that computer and receiver are on different
branch circuits
If necessary, the user should consult the dealer or an experienced radio/television technician
for additional suggestions The user may nd the following booklet prepared by the Fedral
Communications Commision helpful:
“How to Identify and Resolve Radio-TV Interference Problems” This booklet is available from
the US Government Printing Ofce, Washington, DC, 20402, Stock No 004-000-00345-4
LICENSED UNDER U S PAT
48294194942516489626045311324825364,46866224121284
43969764371923447138541205834435732,46724574739396
CUSTOMER SERVICE
TOLL FREE: 1-800-634-4350

13
Limited One Year Warranty
YOUR OMRON MODEL HEM-713C Digital Blood Pressure Monitor is warranted to be free from manufacturing
defects for a period of one year under normal use This warranty extends only to the original retail purchaser
Should repair be needed, within the warranty period, ship the unit and receipt as proof of purchase prepaid to
OMRON HEALTHCARE, INC, 300 Lakeview Parkway, Vernon Hills, Illinois 60061, together with $500 for return
shipping and insurance
We will either repair or at our option replace free of charge any parts necessary to correct defects in material
or workmanship The above warranty is complete ad exclusive The warrantor expressly disclaims liability for
incidental, special or consequential damages of any nature (Some status do not allow the exclusion or limitation of
incidental or consequential damages so the above limitation or exclusion may not apply to you)
Any implied warranties arising by operation of law shall be limited in duration to the term of this warranty (Some
states do not allow limitations on how long an implied warranty lasts, so the above limitation may not apply to you)
This warranty gives you specic legal rights, and you may have other rights which vary from state to state As
condition to operation of your warranty, the enclosed registration card must be completed and sent to us within 10
days from the date of purchase
Caution
Changes or modications not expressively approved by OMRON HEALTH CARE, INC could void the user’s
authority to operate this product
Note
Potential For RadiofTelevision Interference (for USA only)
This product has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15
of the FCC rules
These limits are designed to provide reasonable protection against harmful interference in a residential installation
The product generates, uses and can radiate radio frequency energy and, if not installed and used in accordance
with the instructions, may cause harmful interference to radio communications However there is no guarantee
that interierence will not occur in a particular installation If the product does cause harmful interference to radio or
television reception, which can be determined by turning the product off and on, the user is encouraged to try to
correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna
• Increase the separation between the product and receiver
• Connect the product into an outlet on a circuit different from that to which the receiver is connected
• Consult the dealer or an experienced radiofTV technician for help
Potential For RadiofTelevision Interference (for Canada only)
This digital apparatus does not exceed the Class B limits for radio noise emissions from digital apparatus as
set out in the interferencEH:ausing equipment standard entitled “Digital Apparatus”, ICES’{)03 of the Canadian
Department of Communications
Cet appareil numerique respecte les limites de bruits radioelectriques applicables aux appareils numeriques de
Classe B prescrites dans la norme sur Ie materiel brouilleur “Appareils Numeriques”, NMB{J03 ildictee par Ie
ministre des communications
OMRON uses recycled paper to help preserve our natural recources
Distributed by
OMRON HEALTHCARE,INC.
300 Lakeview Parkway
Vernon Hills, Illinois 60061
0692581-7 A
