Omron IntelliSense HEM-907XL User manual

Product Specifications
HEM-907XL
Accessories:
Professional Digital Blood Pressure Monitor
Accuracy counts, Trust Omron
HEM-907XL
www.omronhealthcare.com
Name: OMRON Digital Automatic Blood Pressure Monitor
Model: HEM-907XL
Display: Digital display
Measurement: Oscillometric method
Measurement Range: Pressure; 0 to 299 mmHg
Pulse rate; 30 to 199 beats/min
Accuracy: Pressure; Within ±3 mmHg or 2%
Pulse rate; Within ±5% of reading
Inflation: Automatic inflation with pumping
Deflation: Automatic deflation by electromagnetic control valve
Air Release: Automatic rapid air release by electromagnetic control valve
Pressure Detection: Electrostatic capacity semi-conductor pressure sensor
Power supply: AC adapter (120 VAC, 60 Hz, 13 VA) or
(120VAC, 50/60Hz, 0.2A) Battery pack (4.8 VDC, 6W)
Electric Shock Protection Method: Class II B type
Operating Temperature 50°F to 104°F (10 to 40°C), 30 to 85% RH, IPX 0 Rating
and Humidity:
Weight of Main Unit: Approx. 32 oz (910 g)
External Dimensions: Approx.5 1/2” (W) x 8”(H) x 5 1/6”(D)
139 (W) x 203 (H) x 131 (D) mm
Complies with: IEC 60601-1:1998+A1:1991+A2:1995
General requirements for safety
IEC 60601-1-2:1993
Electromagnetic compatibility - Requirements and tests
AAMI SP10:1992
Manual, Electronic or Automated Sphygmomanometers
Package Contents: Blood Pressure Monitor, Cuffs (Extra Large, Large,
Medium, and Small) and Bladder Set, 1.3m Air Tube,
AC Adapter, and Battery Pack
HEM-907-CS19 Cuff and Bladder Set, Small, 17-22 cm circumference
HEM-907-CR19 Cuff and Bladder Set, Medium, 22-32 cm circumference
HEM-907-CL19 Cuff and Bladder Set, Large, 32-42 cm circumference
HEM-907-CX19 Cuff and Bladder Set, Extra Large, 42-50 cm
circumference with integrated air tube
HEM-TUBE-130 Air Tube, 1.3 m Working Length for small, medium,
and large cuffs
HEM-907-STAND Stand
HEM-907-WKIT Wall Mounting Kit
HEM-907-PKIT Pole Mounting Kit
HEM-907-PBAT Battery Pack
HEM-ADPT-907 AC Adapter
© 2010 Omron Healthcare, Inc.
907XLSS REV.
HEM-907XL
with stand option
1
Pickering, et al. Recommendations for blood pressure measurements in humans and experimental animals,
Circulation 2005, 111(5):697-716.
2
New England Journal of Medicine 2008; 358: 2545-59.
3
The Journal of Clinical Hypertension Vol 11 No. 10 Oct 2009 p. 542
4
Am J Emerg Med 1995; 13:204-210. Copyright © 1995 by W.B. Saunders Company

Accuracy Healthcare Professionals Trust
The HEM-907XL Professional Blood Pressure Monitor is designed for clinical use in
professional settings, including physicians’ offices, hospitals and other point of care environments.
Because hypertension affects nearly one in three Americans1, it is vitally important
to have a reliable instrument to help accurately diagnose this condition.
Gold Standard Accuracy
F Pressure; within ± 3mmHg or 2%
F Pulse rate; within ± 5% of reading
F Utilized in large scale national clinical trials
F ACCORD2 and SANDS3
Validated According to Internationally
Accepted Protocols
F Association for the Advancement of Medical
Instrumentation (AAMI)
F British Hypertension Society (BHS)
F European Society of Hypertension-International
Protocol (ESH-IP)
Accurate Clinically Validated
Versatility Healthcare Professionals Expect
The HEM-907XL Professional Blood Pressure Monitor provides unique features
to meet your individual patient needs giving you the flexibility
to efficiently customize your diagnostic approach.
HEM-907XL
4 Cuffs Included
F Cuff sizes covering a range of 17-50 cm (7” to 20”)
to accommodate most users
F 4 cuffs included with the unit (small, medium,
large, extra large)
F Enables accurate readings on virtually all patients
Ease of Use
F One button operation
F Battery or AC adapter
F Large and easy to read display
F Automatic-off (after 5 minutes of inactivity)
Easy to Use Versatile
The most frequent error in measuring blood pressure in
the outpatient clinic is “miscuffing,” with undercuffing large
arms being the major problem4
IntelliSense® Technology
F Uses IntelliSense® technology to automatically
determine the correct amount of pressure,
resulting in a faster and more comfortable
blood pressure measurement for your patients
Irregular Pulse Indicator
F Indicates a difference in rhythm that is more than
25% slower or faster from the average
F Displays the number of irregular pulse waves
F Helps identify changes in heart rate, rhythm,
or pulse which may be caused by heart disease
or other serious health issues3
3 Modes of Operation
F Single Mode takes one-time measurement
automatically
F Average Mode takes 2 or 3 readings and calculates
the average automatically and provides the patient’s
most accurate measurement
F Auscultation (Manual) Mode enables the use of
auscultation technique (using a stethoscope) with
added benefits of automatic inflation/deflation
with digital display
5 Year Limited Warranty
HEM-907XL with wall mount option
Small, 17-22 cm
Medium, 22-32 cm
Large, 32-42 cm
Extra Large, 42-50 cm

Accuracy Healthcare Professionals Trust
The HEM-907XL Professional Blood Pressure Monitor is designed for clinical use in
professional settings, including physicians’ offices, hospitals and other point of care environments.
Because hypertension affects nearly one in three Americans1, it is vitally important
to have a reliable instrument to help accurately diagnose this condition.
Gold Standard Accuracy
F Pressure; within ± 3mmHg or 2%
F Pulse rate; within ± 5% of reading
F Utilized in large scale national clinical trials
F ACCORD2 and SANDS3
Validated According to Internationally
Accepted Protocols
F Association for the Advancement of Medical
Instrumentation (AAMI)
F British Hypertension Society (BHS)
F European Society of Hypertension-International
Protocol (ESH-IP)
Accurate Clinically Validated
Versatility Healthcare Professionals Expect
The HEM-907XL Professional Blood Pressure Monitor provides unique features
to meet your individual patient needs giving you the flexibility
to efficiently customize your diagnostic approach.
HEM-907XL
4 Cuffs Included
F Cuff sizes covering a range of 17-50 cm (7” to 20”)
to accommodate most users
F 4 cuffs included with the unit (small, medium,
large, extra large)
F Enables accurate readings on virtually all patients
Ease of Use
F One button operation
F Battery or AC adapter
F Large and easy to read display
F Automatic-off (after 5 minutes of inactivity)
Easy to Use Versatile
The most frequent error in measuring blood pressure in
the outpatient clinic is “miscuffing,” with undercuffing large
arms being the major problem4
IntelliSense® Technology
F Uses IntelliSense® technology to automatically
determine the correct amount of pressure,
resulting in a faster and more comfortable
blood pressure measurement for your patients
Irregular Pulse Indicator
F Indicates a difference in rhythm that is more than
25% slower or faster from the average
F Displays the number of irregular pulse waves
F Helps identify changes in heart rate, rhythm,
or pulse which may be caused by heart disease
or other serious health issues3
3 Modes of Operation
F Single Mode takes one-time measurement
automatically
F Average Mode takes 2 or 3 readings and calculates
the average automatically and provides the patient’s
most accurate measurement
F Auscultation (Manual) Mode enables the use of
auscultation technique (using a stethoscope) with
added benefits of automatic inflation/deflation
with digital display
5 Year Limited Warranty
HEM-907XL with wall mount option
Small, 17-22 cm
Medium, 22-32 cm
Large, 32-42 cm
Extra Large, 42-50 cm

Product Specifications
HEM-907XL
Accessories:
Professional Digital Blood Pressure Monitor
Accuracy counts, Trust Omron
HEM-907XL
www.omronhealthcare.com
Name: OMRON Digital Automatic Blood Pressure Monitor
Model: HEM-907XL
Display: Digital display
Measurement: Oscillometric method
Measurement Range: Pressure; 0 to 299 mmHg
Pulse rate; 30 to 199 beats/min
Accuracy: Pressure; Within ±3 mmHg or 2%
Pulse rate; Within ±5% of reading
Inflation: Automatic inflation with pumping
Deflation: Automatic deflation by electromagnetic control valve
Air Release: Automatic rapid air release by electromagnetic control valve
Pressure Detection: Electrostatic capacity semi-conductor pressure sensor
Power supply: AC adapter (120 VAC, 60 Hz, 13 VA) or
(120VAC, 50/60Hz, 0.2A) Battery pack (4.8 VDC, 6W)
Electric Shock Protection Method: Class II B type
Operating Temperature 50°F to 104°F (10 to 40°C), 30 to 85% RH, IPX 0 Rating
and Humidity:
Weight of Main Unit: Approx. 32 oz (910 g)
External Dimensions: Approx.5 1/2” (W) x 8”(H) x 5 1/6”(D)
139 (W) x 203 (H) x 131 (D) mm
Complies with: IEC 60601-1:1998+A1:1991+A2:1995
General requirements for safety
IEC 60601-1-2:1993
Electromagnetic compatibility - Requirements and tests
AAMI SP10:1992
Manual, Electronic or Automated Sphygmomanometers
Package Contents: Blood Pressure Monitor, Cuffs (Extra Large, Large,
Medium, and Small) and Bladder Set, 1.3m Air Tube,
AC Adapter, and Battery Pack
HEM-907-CS19 Cuff and Bladder Set, Small, 17-22 cm circumference
HEM-907-CR19 Cuff and Bladder Set, Medium, 22-32 cm circumference
HEM-907-CL19 Cuff and Bladder Set, Large, 32-42 cm circumference
HEM-907-CX19 Cuff and Bladder Set, Extra Large, 42-50 cm
circumference with integrated air tube
HEM-TUBE-130 Air Tube, 1.3 m Working Length for small, medium,
and large cuffs
HEM-907-STAND Stand
HEM-907-WKIT Wall Mounting Kit
HEM-907-PKIT Pole Mounting Kit
HEM-907-PBAT Battery Pack
HEM-ADPT-907 AC Adapter
© 2010 Omron Healthcare, Inc.
907XLSS REV.
HEM-907XL
with stand option
1
Pickering, et al. Recommendations for blood pressure measurements in humans and experimental animals,
Circulation 2005, 111(5):697-716.
2
New England Journal of Medicine 2008; 358: 2545-59.
3
The Journal of Clinical Hypertension Vol 11 No. 10 Oct 2009 p. 542
4
Am J Emerg Med 1995; 13:204-210. Copyright © 1995 by W.B. Saunders Company
