Omron R6 User manual

Digital Automatic Wrist Blood Pressure Monitor
Model R6
Instruction Manual
English
Français
Deutsch
Italiano
Espanõl
Nederlands
IM-HEM-6052-E-03-10/2011
5328089-1C
Check following components!
Vérifier les composants suivants !
Prüfen Sie folgende Teile des Lieferumfangs!
Controllare i componenti indicati di seguito!
¡Compruebe los siguientes componentes!
Controleer de volgende onderdelen!
Проверьте следующие компоненты!
Русский
Manufacturer OMRON HEALTHCARE Co., Ltd.
53, Kunotsubo, Terado-cho, Muko, Kyoto,
617-0002 JAPAN
OMRON HEALTHCARE EUROPE B.V.
Scorpius 33, 2132 LR Hoofddorp, THE NETHERLANDS
www.omron-healthcare.com
OMRON (DALIAN) CO., LTD.
Dalian, CHINA
OMRON HEALTHCARE UK LTD.
Opal Drive, Fox Milne, Milton Keynes, MK15 0DG, U.K.
OMRON MEDIZINTECHNIK HANDELSGESELLSCHAFT mbH
John-Deere-Str. 81a, 68163 Mannheim, GERMANY
www.omron-medizintechnik.de
OMRON SANTÉ FRANCE SAS
14, rue de Lisbonne, 93561 Rosny-sous-Bois Cedex, FRANCE
Uniquement pour le marché français: OMRON Service Après Vente
Nº Vert 0 800 91 43 14
[email protected]
www.omron-sante.fr/contact
EU-representative
Production facility
Site de production
Produktionsstätte
Stabilimento di produzione
Oficina de producción
Productiefaciliteit
Prodotto in Cina
Hergestellt in China
Geproduceerd in ChinaFabriqué en Chine
Fabricado en ChinaMade in China
Сделано в Китае
Производственное подразделение
Subsidiary
Succursale
Niederlassung
Consociata
Empresa filial
Dochteronderneming
Дочерняя компания
DigitalAutomatic Wrist Blood Pressure Monitor
ModelR6
InstructionManual
English
Français
Deutsch
Italiano
Espanõl
Nederlands
HEM-6052-E-02-06/2010
5328089-1B

Contents
Thank you for purchasing the OMRON R6 Digital Automatic Wrist Blood Pressure Monitor.
Please read this instruction manual thoroughly before using the unit.
Please keep for future reference.
For specific information about your own blood pressure, CONSULT YOUR DOCTOR.
3.3 Taking a Reading ..................................13
3.4 Using theMemory Function ..................17
4. Troubleshooting and Maintenance .......... 19
4.1 The Icons and Error Messages .............19
4.2 Troubleshooting.....................................21
4.3 Maintenance..........................................23
5. Technical Data............................................25
6. Some Useful Information about Blood Pressure ... 28
3.2 How to Sit Correctly. ..............................12
ImportantSafety Information................ ............. 1
1. Overview......... .............................................. 3
2. Preparation................................................ ... 4
2.1 Installing/Replacing the Batteries ............4
2.2 Setting the Dateand Time.......................6
2.3 Setting the A dvancedPositioning
Sensor ................................................ 7
3. Using the Unit ............................................ 11
3.1 Applying the Wrist Cuff..........................11
N
O
P
Q
R
S
J K L M
Y X W V U T
A
B
C
D
E
G
F
IH
e
f
c
d
b
a
Intended Use
This product is designed to measure the blood pressure and pulse rate of people within the range of
the designated wrist cuff, following the instructions in this instruction manual.
It is mainly designed for general household use. Please read the Important Safety Information in this
instruction manual before using the unit.
The OMRON R6 is a compact and easy to use blood pressure monitor, operating on the oscillometric
principle. This well designed wrist monitor comes with memory for two users and a easy to read
Blood pressure level indicator allowing you to easily see if your readings are with in the Guidelines
set by the World Health Organization. It measures your blood pressure and pulse rate simply and
quickly. For comfortable controlled inflation without the need of pressure pre-setting or re-inflation the
devices uses its advanced “IntelliSense” technology.

1
EN
Important Safety Information
Consult your doctor prior to using in pregnancy or if diagnosed with arrhythmia or arteriosclerosis.
Please read this section carefully before using the unit.
Warning:
• Indicates a potentially hazardous situation which, if not avoided, could result in death or serious
injury.
(General Usage)
• Always consult your doctor. Self-diagnosis of measurement results and self-treatment are
dangerous.
• People with severe blood flow problems, or blood disorders, should consult a doctor before
using the unit, as cuff inflation can cause internal bleeding.
(Battery Usage)
• If battery fluid should get in your eyes, immediately rinse with plenty of clean water. Consult a
doctor immediately.
Caution:
• Indicates a potentially hazardous situation which, if not avoided, may result in minor or
moderate injury to the user or patient or damage to the equipment or other property.
(General Usage)
• Do not leave the unit unattended with infants or persons who cannot express their consent.
• Do not use the unit for any purpose other than measuring blood pressure.
• Do not disassemble the unit or wrist cuff.
• Do not inflate the wrist cuff over 299 mmHg.
HEM-6052-E_B_M_main.book 1 ページ ２０１１年１０月１２日 水曜日 午後２時４７分

2
Important Safety Information
• Do not use a mobile phone or other devices that emit electromagnetic fields, near the unit. This
may result in incorrect operation of the unit.
• Do not operate unit in a moving vehicle (car, airplane).
(Battery Usage)
• If battery fluid should get on your skin or clothing, immediately rinse with plenty of clean water.
• Use only two “AAA” alkaline (LR03) batteries with this unit. Do not use other types of batteries.
• Do not insert the batteries with their polarities incorrectly aligned.
• Replace old batteries with new ones immediately. Replace both batteries at the same time.
• Remove the batteries if the unit will not be used for three months or more.
• Do not use new and used batteries together.
General Precautions
• Do not apply strong shocks and vibrations to or drop the unit.
• Do not take measurements after bathing, drinking alcohol, smoking, exercising or eating.
• Do not inflate the wrist cuff when it is not wrapped around your wrist.
• Do not wash the wrist cuff or immerse it in water.
• Read and follow the “Important information regarding Electro Magnetic Compatibility (EMC)” in
the Technical Data Section.
• Read and follow the “Correct Disposal of This Product” in the Technical Data Section when
disposing of the device and any used accessories or optional parts.
HEM-6052-E_B_M_main.book 2 ページ ２０１１年１０月１２日 水曜日 午後２時４７分

3
EN
1. Overview
Main unit
Display
Battery compartment cover
Wrist cuff
MEM (Memory) button
O/I START ( ) button
User ID selection switch
SET button
Date/Time setting ( ) button
Date/Time setting ( ) button
Display
Deflation symbol
Systolic blood pressure
Positioning indicator
Diastolic blood pressure
Memory symbol
Average value symbol
Irregular heartbeat symbol
Movement error symbol
User ID symbol (A or B)
Wrist (left/right) symbol
Battery low symbol
Pulse display
Heartbeat symbol
Date/Time display
Buzzer symbol
Blood pressure level indicator
Open the rear cover page to read following:
The alphabet in the rear cover page correspond to those in the body page.
A
B
C
D
E
F
G
H
I
J
K
L
M
N
O
P
Q
R
S
T
U
V
W
X
Y
HEM-6052-E_B_M_main.book 3 ページ ２０１１年１０月１２日 水曜日 午後２時４７分

4
2. Preparation
2.1 Installing/Replacing the Batteries
1. Remove the battery cover.
1) Push the hook on the bottom of the battery cover.
2) Pull the cover off the main unit.
2. Insert two 1.5V “AAA” alkaline (LR03)
batteries as indicated in the battery
compartment and set the date and
time (refer to section 2.2).
1
2
HEM-6052-E_B_M_main.book 4 ページ ２０１１年１０月１２日 水曜日 午後２時４７分

2. Preparation
EN
5
3. Replace the battery cover.
Notes:
• If the battery low symbol ( ) appears on the display, turn the unit off then replace both
batteries at the same time.
• The measurement values continue to be stored in memory even after the batteries are
replaced.
Disposal of used batteries should be carried out in accordance with the national regulations for
the disposal of batteries.
HEM-6052-E_B_M_main.book 5 ページ ２０１１年１０月１２日 水曜日 午後２時４７分

2. Preparation
6
2.2 Setting the Date and Time
1. Set the monitor to the correct date and time before taking
a measurement for the first time.
Press the button.
2. Press the O/I START button to turn the monitor off.
Notes:
• To reset the date and time, hold down the button while the power is off.
• If the batteries have been removed for 30 seconds or more, the date and time setting will
need to be reset.
1)
2)
Push the button to
change.
• Hold down to advance
the digit rapidly.
Push the button to
confirm.
Next setting appears.
Year
Month
Day
Hour
Minute
HEM-6052-E_B_M_main.book 6 ページ ２０１１年１０月１２日 水曜日 午後２時４７分

2. Preparation
EN
7
2.3 Setting the Advanced Positioning Sensor
The Advanced Positioning Sensor will assure you the unit is in the correct position level
with the user’s heart before the monitor starts to take the measurement.
Selecting the User ID
Before setting the Advanced Positioning Sensor, select your User ID.
User A User B
HEM-6052-E_B_M_main.book 7 ページ ２０１１年１０月１２日 水曜日 午後２時４７分

2. Preparation
8
Setting the Positioning Indicator
1. Push the button.
2. Push the button to
choose which mode of
Positoning indicator you
wish to have.
While setting the Positioning indicator the blue light flashes.
on1: After the Positioning indicator lights in blue for more than 2 seconds, or in orange
for more than 5 seconds, measurement starts automatically, even though the
monitor is not in proper position.
on2: The Positioning indicator lights in blue for more than 2 seconds, measurement
starts automatically. Measurement will not start if it lights in orange.
oFF: Measurement starts without the Positioning indicator.
3. Push the button to confirm your choice and move
onto the next step.
Note:
If you choose “oFF” for the Positioning indicator, the monitor will skip the process of
choosing which wrist.
HEM-6052-E_B_M_main.book 8 ページ ２０１１年１０月１２日 水曜日 午後２時４７分

2. Preparation
EN
9
Setting the Wrist for Measurement
1. Push the button to toggle between “ ” (Left) and “ ” (Right).
: Taking a reading on the left wrist.
: Taking a reading on the right wrist.
2. Push the button to confirm your choice and move onto the next step.
Setting the Buzzer
1. Push the button to
choose which mode of the
buzzer you wish to have.
If the Positioning indicator is “on1” or “on2”:
on1: The buzzer sounds only when the monitor is in proper position.
on2: The buzzer sounds a series of two short blips if your wrist is too far away from the
measuring position, and sounds slowly when your wrist is in proper position.
oFF: The buzzer will not sound.
If the Positioning indicator is “oFF”:
on: The buzzer sounds when pressing any buttons.
oFF: The buzzer will not sound.
HEM-6052-E_B_M_main.book 9 ページ ２０１１年１０月１２日 水曜日 午後２時４７分

2. Preparation
10
2. Push the button to confirm.
Blue light will flash.
3. Press the O/I START button to save settings and turn the
monitor off.
Resetting to the Default Setting
The positioning indicator is set “on1”, the wrist for measurement is set “ ”, and the buzzer is set
“on1” as default.
To reset to the default setting, press and hold down the SET button while in the setting mode,
then press the O/I START button simultaneously for more than 2 seconds.
HEM-6052-E_B_M_main.book 10 ページ ２０１１年１０月１２日 水曜日 午後２時４７分

11
EN
3. Using the Unit
3.1 Applying the Wrist Cuff
Do not apply over clothing.
1. Place the wrist cuff over your wrist.
2. Wrap the wrist cuff around your wrist.
Make sure that the wrist cuff does not cover the protruding part of the wrist bone (ulna) on the
outside of the wrist. ---
Your thumb should face upward.
Notes:
• You can take a measurement on either your left or right wrist. Refer to 2.3 about how to
modify the settings.
• Wrap the wrist cuff securely around the wrist for taking accurate measurements.
• The blood pressure can differ between the right arm and the left arm, and therefore also the
measured blood pressure values can be different. Omron recommends to always use the
same arm for measurement. If the values between the two arms differ substantially, please
check with your physician which arm to use for your measurement.
Open both the front and rear covers to read following:
The alphabet and number in the cover page correspond to those in the body page.
a
b
HEM-6052-E_B_M_main.book 11 ページ ２０１１年１０月１２日 水曜日 午後２時４７分

3. Using the Unit
12
3.2 How to Sit Correctly
To take a measurement, you need to be relaxed and comfortably seated, under comfortable room
temperature. No eating, smoking or exercising 30 minutes before taking a measurement.
• Sit on a chair with your feet flat on the floor.
• Sit upright with your back straight. ---
• The cuff should be at the same level as your heart. ---
• Relax your wrist and hand. Do not bend your wrist back, clench your fist, or bend your wrist
forward. ---
• Do not use your other hand to support the wrist cuff. This can result in inaccurate
measurement results. ---
c
d
e
f
HEM-6052-E_B_M_main.book 12 ページ ２０１１年１０月１２日 水曜日 午後２時４７分

3. Using the Unit
EN
13
3.3 Taking a Reading
Notes:
• This section is the example for the measurement with the default setting. To change the
setting refer to section 2.3.
• To cancel a measurement, press the O/I START button at any time during measurement.
• Remain still while taking a measurement.
1. Select your User ID.
Always use the same user ID when taking a measurement.
The unit stores the measurement values in the selected user ID memory.
Notes:
• If “GUEST” is selected, A or B will not be displayed.
• If “GUEST” is selected, the measurement results are not stored in the memory.
User A User B
HEM-6052-E_B_M_main.book 13 ページ ２０１１年１０月１２日 水曜日 午後２時４７分

3. Using the Unit
14
2. Press the O/I START button.
While your position is improper, the Positioning indicator lights in orange, when you are
in proper position the buzzer beeps “beep beep beep” and the Positioning indicator
turns to blue.
The wrist cuff will start to inflate automatically.
Higher than
the heart.
Lower than
the heart. Far away from the
heart.
Keep at the
center of
the chest.
The orange light The blue light
START INFLATE DEFLATE COMPLETE
Alternating date/time
display
Blinking
HEM-6052-E_B_M_main.book 14 ページ ２０１１年１０月１２日 水曜日 午後２時４７分

3. Using the Unit
EN
15
3. Undo the wrist cuff and remove the unit.
4. Press the O/I START button to turn the monitor off.
The monitor automatically stores the measurement in its memory.
It will automatically turn off after 2 minutes.
Important:
• Recent research suggests that the following values can
be used as a guide to high blood pressure for
measurements taken at home.
This criteria is for home blood pressure measurement.
For professional office blood pressure measurement
criteria, please refer to Chapter 6.
Systolic Blood Pressure Above 135 mmHg
Diastolic Blood Pressure Above 85 mmHg
HEM-6052-E_B_M_main.book 15 ページ ２０１１年１０月１２日 水曜日 午後２時４７分

3. Using the Unit
16
• Your blood pressure monitor includes an irregular heartbeat
feature. Irregular heartbeats can influence the results of the
measurement. The irregular heartbeat algorithm automatically
determines if the measurement is usable or needs to be repeated.
If the measurement results are affected by irregular heartbeats but
the result is valid, the result is shown together with the irregular
heartbeat symbol ( ). If the irregular heartbeats cause the
measurement to be invalid, no result is shown. If the irregular
heartbeat symbol ( ) is shown after you have taken a
measurement, repeat the measurement. If the irregular heartbeat
symbol ( ) is shown frequently, please make your doctor aware of it.
HEM-6052-E_B_M_main.book 16 ページ ２０１１年１０月１２日 水曜日 午後２時４７分

3. Using the Unit
EN
17
3.4 Using the Memory Function
The monitor automatically stores the result up to 90 sets each for both user A and B. It can also
calculate an average reading based on the measurements from the last three readings taken
within 10 minutes. If there are only two readings in memory for that period, the average will be
based on two readings. If there is one reading in memory for that period, the average will be
based on one reading.
Notes:
• If the memory is full, the monitor will delete the oldest readings.
Average Value
View Readings
Stored in Memory
• Hold down to view
readings rapidly.
Previous Reading
View Previous
Reading
View the Average
Value
Alternating date/time display
HEM-6052-E_B_M_main.book 17 ページ ２０１１年１０月１２日 水曜日 午後２時４７分

3. Using the Unit
18
To delete all the values stored in memory
The values stored in the memory are deleted by user ID.
You cannot partially delete values stored in the memory. All values for the user you
select will be deleted.
When the memory symbol ( ) appears, first press the MEM button. Then while
holding it down, press the O/I START button simultaneously for about 2-3 seconds.
Note:
You cannot partially delete the stored readings.
Second First
HEM-6052-E_B_M_main.book 18 ページ ２０１１年１０月１２日 水曜日 午後２時４７分
