Omron V670-CF01 User manual

Electromagnetic Inductive RFID System
V670 Series
User's Manual
Cat. No. ntlp-E1-01
CF Reader/Writer
V670-CF01
ID Tag
V670-D13F03
V670-D13F01
V670-D13F01H

はじめに 第 1 章 第 2 章 第 3 章 第 4 章I
ntroduction SECTION 1 SECTION 2 SECTION 3 SECTION 4 SECTION 5 SECTION 6
Introduction
SECTION 1
SECTION 2
SECTION 3
SECTION 4
SECTION 5
SECTION 6
Standard Conformity
Product Outline
Communications Preparations
Functions
Commands
Troubleshooting
Appendices (Specifications and Dimensions, Characteristics Data Based on
Operating Conditions, Memory Map, Maintenance and Inspection, Table of
JIS8 Unit Code (ASCII), Degree of Protection)
Electromagnetic Inductive RFID System
V670-CF01 CF Reader/Writer
V670-D13F03 ID Tag
V670-D13F01 ID Tag
V670-D13F01H ID Tag
User's Manual

2
Introduction
Introduction
Electromagnetic Inductive RFID System
User's Manual
Introduction
Introduction
OMRON products are manufactured for use according to proper procedures by a qualified operator and only for the
purposes described in this manual. Observe the following precautions when using a V670-series Electromagnetic
Inductive RFID System.
•Read and understand this manual before attempting to use the product and use the product correctly.
•Keep this manual in a safe but accessible location so that it can be used as reference when required.
Read and Understand this User’s Manual
Please read and understand this instruction manual before storing, installing, programming, operating, maintaining, or
disposing of the products. Please consult your OMRON representative if you have any questions or comments.
Warranty and Limitations of Liability
WARRANTY
OMRON's exclusive warranty is that the products are free from defects in materials and workmanship for a period of one
year (or other period if specified) from date of sale by OMRON.
OMRON MAKES NO WARRANTY OR REPRESENTATION, EXPRESS OR IMPLIED, REGARDING NON-INFRINGE-
MENT, MERCHANTABILITY, OR FITNESS FOR PARTICULAR PURPOSE OF THE PRODUCTS. ANY BUYER OR
USER ACKNOWLEDGES THAT THE BUYER OR USER ALONE HAS DETERMINED THAT THE PRODUCTS WILL
SUITABLY MEET THE REQUIREMENTS OF THEIR INTENDED USE. OMRON DISCLAIMS ALL OTHER WARRAN-
TIES, EXPRESS OR IMPLIED.
LIMITATIONS OF LIABILITY
OMRON SHALL NOT BE RESPONSIBLE FOR SPECIAL, INDIRECT, OR CONSEQUENTIAL DAMAGES, LOSS OF
PROFITS OR COMMERCIAL LOSS IN ANY WAY CONNECTED WITH THE PRODUCTS, WHETHER SUCH CLAIM IS
BASED ON CONTRACT, WARRANTY, NEGLIGENCE, OR STRICT LIABILITY.
In no event shall the responsibility of OMRON for any act exceed the individual price of the product on which liability is
asserted.
IN NO EVENT SHALL OMRON BE RESPONSIBLE FOR WARRANTY, REPAIR, OR OTHER CLAIMS REGARDING
THE PRODUCTS UNLESS OMRON'S ANALYSIS CONFIRMS THAT THE PRODUCTS WERE PROPERLY HANDLED,
STORED, INSTALLED, AND MAINTAINED AND NOT SUBJECT TO CONTAMINATION, ABUSE, MISUSE, OR INAP-
PROPRIATE MODIFICATION OR REPAIR.

3
Electromagnetic Inductive RFID System
User's Manual
Introduction
Introduction
Introduction
Application Considerations
SUITABILITY FOR USE
OMRON shall not be responsible for conformity with any standards, codes, or regulations that apply to the combination of
products in the customer's application or use of the products.
At the customer's request, OMRON will provide applicable third party certification documents identifying ratings and limi-
tations of use that apply to the products. This information by itself is not sufficient for a complete determination of the suit-
ability of the products in combination with the end product, machine, system, or other application or use.
The following are some examples of applications for which particular attention must be given. This is not intended to be
an exhaustive list of all possible uses of the products, nor is it intended to imply that the uses listed may be suitable for
the
products:
• Outdoor use, uses involving potential chemical contamination or electrical interference, or conditions or uses not
described in this instruction manual.
• Nuclear energy control systems, combustion systems, railroad systems, aviation systems, medical equipment, amuse-
ment machines, vehicles, safety equipment, and installations subject to separate industry or government regulations.
• Systems, machines, and equipment that could present a risk to life or property.
Please know and observe all prohibitions of use applicable to the products.
NEVER USE THE PRODUCTS FOR AN APPLICATION INVOLVING SERIOUS RISK TO LIFE OR PROPERTY WITH-
OUT ENSURING THAT THE SYSTEM AS A WHOLE HAS BEEN DESIGNED TO ADDRESS THE RISKS, AND THAT
THE OMRON PRODUCTS ARE PROPERLY RATED AND INSTALLED FOR THE INTENDED USE WITHIN THE OVER-
ALL EQUIPMENT OR SYSTEM.
PROGRAMMABLE PRODUCTS
OMRON shall not be responsible for the user's programming of a programmable product, or any consequence thereof.
Disclaimers
PERFORMANCE DATA
Performance data given in this manual is provided as a guide for the user in determining suitability and does not consti-
tute a warranty. It may represent the result of OMRON’s test conditions, and the users must correlate it to actual applica-
tion requirements. Actual performance is subject to the OMRON Warranty and Limitations of Liability.
CHANGE IN SPECIFICATIONS
Product specifications and accessories may be changed at any time based on improvements and other reasons.
It is our practice to change model numbers when published ratings or features are changed, or when significant construc-
tion changes are made. However, some specifications of the products may be changed without any notice. When in
doubt, special model numbers may be assigned to fix or establish key specifications for your application on your request.
Please consult with your OMRON representative at any time to confirm actual specifications of purchased products.
DIMENSIONS AND WEIGHTS
Dimensions and weights are nominal and are not to be used for manufacturing purposes, even when tolerances are
shown.
ERRORS AND OMISSIONS
The information in this instruction manual has been carefully checked and is believed to be accurate; however, no
responsibility is assumed for clerical, typographical, or proofreading errors, or omissions.

4
Introduction
Standard Conformity
Electromagnetic Inductive RFID System
User's Manual
Introduction
Standard Conformity
1. Radio Law in Japan
This product is covered by the following portions of the Radio Law in Japan (frequency of 13.56 MHz with an electrical
field strength of 500 µV/m or less at a distance of 3 m). Accordingly, the product is classified as a communications
device not requiring a license.
Radio Law Article 100 Item 1 Paragraph 1 (Industrial Facilities Emitting Radio Waves)
Radio Law Implementation Regulations Article 44 Item 1 Paragraph 3 (2) (Inductive Reading/Writing Facilities)
2. FCC Rules (Federal Communications Commission)
This Product complies with Part 15 Subpart C of the FCC Rules.
FCC ID: E4E 6CY CIDV6700104
FCC NOTICE
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference.
(2) This device must accept any interference received, including interference that may cause undesired operation.
FCC WARNING
Changes or modifications not expressly approved by the party responsible for compliance could void the user's author-
ity to operate the equipment.
3. EC Declaration of Conformity
Hereby, OMRON Corporation declares that this RFID System and all of it’s components are in compliance with essen-
tial requirements and other relevant provisions of the Radio and Telecommunications Terminal Equipment Directive
1995/5/EC, and satisfy tests for the appropriate requirements of the following relevant standards.
Radio: EN 300 330-2V1.1.1 (06-2001)
EN 300 330-1V1.3.1 (06-2001)
EMC: EN 301 489-3V1.4.1 (08-2002)
EN 301 489-1V1.4.1 (08-2002)
Safety: EN 61010-1: 2001 (2nd Edition)
For safety, be sure to observe the following precautions:
1. Do not operate this device in any flammable, explosive or corrosive gas environment.
2. Do not disassemble, repair, or modify this device.
3. Use only the recommended Handy Terminals. Proper operation many not be possible if any other Handy Terminal is
used.
p.12
4. Insert the CF Reader/Writer into the CF card slot with the indicator on the CF Reader/Writer facing upward.
5. Be sure to attach the Protective Covers to the Handy Terminal. Be sure to tighten the mounting screws securely. The
Protective Covers are not designed to withstand dropping.
6. If the system gives out a foul smell or if the CF Reader/Writer becomes abnormally hot, emits smoke, or exhibits any
other abnormal condition, immediately stop using the system, turn OFF the power, and contact your OMRON repre-
sentative.
7. Dispose of this product as industrial waste.
Precautions for Safe Use

5
Electromagnetic Inductive RFID System
User's Manual
Introduction
Standard Conformity
Introduction
Please observe the following precautions to prevent failure to operate, malfunctions, or undesirable effects on product per-
formance.
1. Installation Site
Do not install the product in the following locations
• Where it is exposed to direct sunlight
• Where it is exposed to corrosive gases, dust, metal chips, or salt
• Where the operating temperature exceeds the range given in the specifications
• Where there are sudden changes in temperature (including locations subject to condensation)
• Where the humidity exceeds the range given in the specifications
• Where vibration or shock exceeding the values given in the specifications is imposed directly on the product.
• Where the product is subject to splashing water, oil, or chemicals
2. Installation
• This device uses the frequency band 13.56 MHz to communicate with Tags. This frequency band is also used as the
ISM band (one of frequencies assigned to medical or industrial heaters). These heaters may affect communications
with a Tag or may damage the Tag if the heater is located near this device. Do not install ID Tags near devices that
use the frequency band 13.56 MHz.
• To minimize general influence of noise, ground any metallic object located around this device according to 100 Ωor
less.
• When using more than one CF Reader/Writer, communications performance may be adversely affected by mutual
interference. Refer to information on mutual interference when installing the system.
p.79
3. Power Supply
• Use the power supply specified in this manual.
p.68
4. Wiring
• Always turn OFF the power supply to the Handy Terminal before inserting or removing the CF Reader/Writer.
• To protect the system from damage due to static electricity, use a wrist strap or other means of preventing static dis-
charge when touching signal wires for terminals or connectors.
5. Cleaning
• Do not use any thinner. Resin material and case paint are dissolved by thinner.
6. Communications
• Power is supplied when opening the COM port on the CF Reader/Writer. Wait for at least 500 ms after opening the
COM port before starting communications.
Precautions for Correct Use

6
Introduction
About this Manual
Electromagnetic Inductive RFID System
User's Manual
Introduction
About this Manual
Meaning of Visual Guides
Indicates precautions to be observed in operating the Product, advise on operating methods, and important information for main-
taining Product performance.
Indicates the pages numbers where related information can be found.
Indicates information related to troubleshooting.

7
Electromagnetic Inductive RFID System
User's Manual
Introduction
Introduction
CONTENTS
Introduction 2
Standard Conformity 4
About this Manual 6
SECTION 1 Product Outline 9
Features 10
Part Names and Functions 11
System Configuration 12
Application Flowchart 13
SECTION 2 Communications Preparations 15
Connection 16
Tags 17
Protective Covers 21
Setting Handy Terminal Communications Conditions 25
Communications Test 26
SECTION 3 Functions 29
Communications Designation Function 30
Setting Operating Parameters 31
Memory Check Function 32
Write Protection 33

8Electromagnetic Inductive RFID System
User's Manual
Introduction
Introduction
SECTION 4 Commands 35
CF Reader/Writer Operation Status 36
Command Response Format 37
Command Response Flow 40
Command List 41
Communications Designations 43
Communications Commands 44
Communications Subcommand 52
Controller Control Commands 53
Host Commands 55
Appraisal Commands 56
End Code List 59
SECTION 5 Troubleshooting 61
Diagnosis Function 62
Errors and Countermeasures 63
SECTION 6 Appendices 67
Specifications and Dimensions 68
Characteristics Data Based on Operating Conditions 79
Memory Map 83
Maintenance and Inspection 84
Table of JIS8 Unit Code (ASCII) 85
Degree of Protection 86
Manual Revision History 90

SECTION 1
Product Outline
9
Electromagnetic Inductive RFID System
User's Manual
SECTION 1
Product Outline
Features 10
Part Names and Functions 11
System Configuration 12
Application Flowchart 13

10
SECTION 1
Features
Electromagnetic Inductive RFID System
User's Manual
SECTION 1
Product Outline
Features
The V670-CF01 CF Reader/Writer combines the V670-series Antenna and Controller into a single unit with a
CF interface. It has superior portability and operability because it can be by slotting it into a CF card slot (Type
II) on a Handy Terminal. Tag data can be read and written using serial communications from the Handy
Te r m i n a l.
Refer to Ta g s for detailed Tag specifications.
p.70
Ferroelectric memory (FeRAM) is a type of non-volatile memory that can write data much faster than previous types of memory,
such as EEPROM and flash ROM, and it has a semipermanent writing life. Furthermore, the previous types of memory could no
longer hold data if nothing had been written to the memory for a certain period (approximately 10 years). FeRAM, on the other
hand, is far better for data storage because it can hold data as long as data is read or written within a specific period of time.
The following three types of ID Tags (“Tags”) can be used with the CF Reader/Writer.
Model Description
V670-D13F03 The V670-D13F03 ID Tag has a memory capacity of 128 bytes. It is a 40 ×
40 mm square tag with water-resistant properties. It also uses a highly effi-
cient, non-volatile ferroelectric memory, called FeRAM, as internal mem-
ory. FeRAM has a semipermanent life (i.e., it can be accessed 1 billion
times).
V670-D13F01 The V670-D13F01 ID Tag is a 8 ×16 mm rectangular tag. It is highly
chemical resistant because a PPS case and highly chemical-resistant
epoxy resin is used on the exterior. It has the same memory capacity and
performance as the V670-D13F03.
V670-D13F01H The V670-D13F01H ID Tag has the same performance and construction
as the V670-D13F01. It has holes for easy mounting.
CF Reader/Writer
V670-CF01
Handy Terminal
RZ-N155S (Manufactured by Sharp)
PDT8046 (Manufactured by Symbol Technology)
Protective Cover
V670-A75SH155S
V670-A75SY8046

11
Electromagnetic Inductive RFID System
User's Manual
SECTION 1
Part Names and Functions
SECTION 1
Product Outline
Part Names and Functions
* When a CPU error occurs, the indicator will remain lit until the power supply is turned OFF.
p.62 Diagnosis Function
Name Details
Antenna The Antenna is brought close to the Tags in order to communicate with them.
CF card section
(Type II)
The interface for connection with a Handy Terminal. Conforms to the CF Card specification: Compact Flash
Specification Revision 2.0.
Indicator Status Description Lit time and number of
flashes
Green, lit Command received from Handy Terminal 3 s
Communications with Tag ended normally 5 s
When the result is “A” (low noise level) for the Noise Mea-
surement command (NS)
5 s
When the result is “0” (normal) for the Error Noise Detec-
tion command (EN)
5 s
When the result is “A” (excellent) for the Stability Evalua-
tion command (SF)
5 s
Green, flashing After completing initialization when power is turned ON 6 times
During communications with a Tag Until communications end
When the result is “B” (good) for the Stability Evaluation
command (SF)
8 times
Red, lit* When an error occurs in communications with a Tag 5 s
When a CPU error occurs Until power is turned OFF
Red, flashing When an error occurs because there is no Tag 10 times
When an error occurs in communications with the Handy
Terminal
5 times
When the result is “B” (high noise level) for the Noise
Measurement command (NS)
15 times
When the result is “1” (error) for the Error Noise Detection
command (EN)
15 times
When the result is “C” (No good) for the Stability Evalua-
tion command (SF)
15 times
CF card section
(Type II)
Indicator
Antenna

12
SECTION 1
System Configuration
Electromagnetic Inductive RFID System
User's Manual
SECTION 1
Product Outline
System Configuration
The CF Reader/Writer is inserted into a Handy Terminal CF card slot (Type II) and it controls communications
with Tags using serial communications from the Handy Terminal.
* The Handy Terminal manufactured by Symbol Technology is recommended for use in the USA, Canada,
Europe, and China. Contact your local Symbol Technology representative for further information.
http://www.symbol.com/index.htm
Use one of the recommended Handy Terminals listed in the above table. The CF Reader/Writer may not operate correctly if any
other Handy Terminal is used. For Handy Terminal operating procedures, refer to the operating instructions provided by the man-
ufacturer.
Recommended Handy Terminals
Manufacturer Symbol Technology* SHARP
Model PDT8046 RZ-N155S
OS PocketPC2002 Windows CE.NET4.2
V670-CF01
V670-D13F01V670-D13F03 V670-D13F01H
CF card slot
•Manufactured by Symbol
Technology
PDT8046
•Manufactured
by Sharp
RZ-N155S
Recommended Handy Terminals
Protective Cover
•V670-A75SH155S (Manufactured by Sharp)
•V670-A75SY8046 (Manufactured by Symbol
Technology)

13
Electromagnetic Inductive RFID System
User's Manual
SECTION 1
Application Flowchart
SECTION 1
Product Outline
Application Flowchart
p.16
Connect the CF Reader/Writer.
p.25
Set the Handy Terminal communications conditions.
Preparation
Communications preparation
Trial operation
p.27
Test communications between the Handy Terminal and CF Reader/
Writer.
p.27
Test communications between Tags and the CF Reader/Writer.
p.79
Check the ambient environment.
p.35
Actual communications using commands.
Communications

14
SECTION 1
Application Flowchart
Electromagnetic Inductive RFID System
User's Manual
SECTION 1
Product Outline
MEMO

SECTION 2
Communications Preparations
15
Electromagnetic Inductive RFID System
User's Manual
SECTION 2
Communications Preparations
Connection 16
Tags 17
Protective Covers 21
Setting Handy Terminal Communications Conditions 25
Communications Test 26

16
SECTION 2
Connection
Electromagnetic Inductive RFID System
User's Manual
SECTION 2
Communications Preparations
Connection
1. Turn OFF the power supply to the Handy Terminal.
Always turn OFF the power supply to the Handy Terminal before connecting or disconnecting the CF Reader/Writer. For
Handy Terminal operating procedures, refer to the operating instructions provided by the manufacturer.
2. Attach the Protective Cover to the end of the Handy Terminal.
Refer to Protective Covers for the attachment method for the Protective Cover.
p.21 Protective Covers
3. Insert the CF Reader/Writer into the Handy Terminal CF card slot.
Insert the CF Reader/Writer into the CF card slot as shown above. Insert it completely to the back of the CF card slot.
4. After the CF Reader/Writer has been inserted, turn ON the power supply to the Handy Terminal.
The indicator on the CF Reader/Writer will flash after the Handy Terminal power has been turned ON.

17
Electromagnetic Inductive RFID System
User's Manual
SECTION 2
Tags
SECTION 2
Communications Preparations
Tags
Installation Environment
Do not use Tags in the following locations.
•Locations with corrosive gases, flammable gases, or dust
•Locations with an ambient temperature not between −10 and 70°C and locations subject to sudden
temperature fluctuations that may cause condensation
•Inside microwave ovens
Mounting Method
Observe the following precautions when mounting Tags.
•Do not chip or make holes in Tags.
•Do not apply excessive force to Tags.
•Do not mount Tags side-by-side or close to metallic objects.
* Tags may warp if used in an environment subject to repeated high and low temperatures, but this will
not affect Tag functions.
■V370-D13F01(H)
•Mounting Direction
•Mounting Example
Use two M3 screws to mount a Tag.
Marking surface
Mount section
20.5±0.1
Two, M3 holes
(Unit: mm)
Mounting Hole Dimensions

18
SECTION 2
Tags
Electromagnetic Inductive RFID System
User's Manual
SECTION 2
Communications Preparations
* Tags must be mounted on flat surfaces. Do not mount Tags on curved surfaces.
The Tag may be damaged due to tightening stress if it is mounted on a curved surface.
Tighten the M3 screws to a torque of 5 N·m or less.
