CP1L
The compact machine controller

Think big…start small…
When it comes to controllers for compact machines,
Omron’s new CP1L series offers the compactness of
a micro-PLC with the capability of a modular PLC.
But this new and exciting range is not only compact,
it is scalable, has a faster processing speed than other
controllers and is in a class of its own when it comes to
price/performance. Naturally, it is compatible with all
other devices in the Omron PLC line up.
The CP1L series not only has all the functionality you need
to control your machine, including outstanding positioning
capability, it even has a USB interface as standard for
programming and monitoring, so you can plug and play easily
and cheaply without having to buy expensive cables. As the
CP1L series shares the same architecture as the CS and CJ
series, programs are fully compatible for memory allocations
and instructions.
Removable memory unit
USB programming port
Analogue adjustment
Analogue input
Input terminal block
Plug-in option board
Expansion I/O connector
Output terminal block
Battery connection

Features at a glance
• 4 high-speed encoder inputs and 2 high-speed pulse outputs
• CPUs with AC or DC supply and 14, 20, 30 or 40 I/O built-in
• Instruction set compatible with CP1H-, CJ1-, and CS1 series PLC
• Optional RS232C and RS-422A/485 serial ports
• USB programming port
• Scaleable with a wide range of I/O units
(maximum up to 160 I/O points)
• Motion functionality
• One and the same software as other Omron controllers
All you need in one series
With the CP1L series you get all the functionality and flexibility
you need in a controller plus the added advantage of one
single platform, which means no worries about field-buses
or integration of software. And the same ‘Smart Platform’
communication routing is provided over multiple network
layers. The CP1L series… the compact range that simply meets
your needs.
…take the lead today!

Easy and familiar programming
Omron’s CX-One software offers the same easy and familiar
programming that saves you time and effort. Enabling you
to build, configure and program your networks, PLCs, HMIs,
motion-control systems, drives, temperature controllers
and sensors.
USB interface, no expensive cabling required
No need for expensive additional cables with the CP1L series
either because the USB interface enables you to simply plug
and play.
Small-scale control Large-scale control
Compact PLCs
CP series
Modular PLCs
CJ series
Rack PLCs
CS series
Same programming method
and same instruction set, including function blocks /
structured texts, for whole PLC range.
Omron’s PLC Lineup

CP1L-L
• CPU with 14 or 20 digital I/O built-in
• Expandable up to 60 I/O points (1 unit)
• USB port + 1 optional serial port
• 5 Ksteps user memory
• 0.6 μs instruction speed
• 4 encoder inputs (100 kHz)
• 2 pulse outputs (100 kHz)
CP1L-M
• CPU with 30 or 40 digital I/O built-in
• Expandable up to 160 I/O points (3 units)
• USB port + 2 optional serial ports
• 10 Ksteps user memory
• 0.6 μs instruction speed
• 4 encoder inputs (100 kHz)
• 2 pulse outputs (100 kHz)
CP1H
• CPU with 40 digital I/O and (optional)
analogue I/O (4in/2Out) built-in
• Expandable up to 320 I/O points (7 units)
• USB port + 2 optional serial ports
• 20 Ksteps user memory
• 0.1 μs instruction speed
• 4 encoder inputs (2 x 1 MHz + 2 x 100 kHz)
• 4 pulse outputs (2 x 1 MHz + 2 x 100 kHz)
Prepared for future growth
Expansion of needs
Expansion of needs

Control Systems
• Programmable logic controllers • Human-machine interfaces • Remote I/O
Motion & Drives
• Motion controllers • Servo systems • Inverters
Control Components
• Temperature controllers • Power supplies • Timers • Counters • Programmable relays
• Digital panel indicators • Electromechanical relays • Monitoring products • Solid-state relays
• Limit switches • Pushbutton switches • Low voltage switch gear
Sensing & Safety
• Photoelectric sensors • Inductive sensors • Capacitive & pressure sensors • Cable connectors
• Displacement & width-measuring sensors • Vision systems • Safety networks • Safety sensors
• Safety units/relay units • Safety door/guard lock switches
