Digital Temperature Controller
E5CC/E5EC
The new standard in temperature control is
higher in every respect
E5CC (48 × 48 mm) / E5EC (48 × 96 mm)
Large White PV Display That's Easier to Read.
Easy to Use, from Model Selection to
Setup and Operation.
A Complete Range of I/O Capacities,
Functions, and Performance.
Handles More Applications.
48 × 48 mm 48 × 96 mm
E5CC E5EC

2
Digital Temperature Controller
E5CC (48 ×48 mm)
Large White PV Display That’s Easier to Read.
Easy to Use, from Model Selection to
Setup and Operation.
A Complete Range of I/O Capacities,
Functions, and Performance.
Handles More Applications.
• The white PV display with a height of 15.2 mm improves visibility.
• Easy setup with the CX-Thermo (sold separately).
• Only 48 ×48 mm (C size) and provides five keys.
As easy to operate as 48 ×96 mm (E size) models.
• High-speed sampling at 50 ms.
• Models with up to 3 auxiliary outputs, 4 event inputs, a transfer
output, and remote SP input added to the lineup. Complete
selection of I/O capacities.
• Short body with depth of only 60 mm.
• Easily connect the CX-Thermo (sold separately) through a USB-Serial Conversion Cable (sold separately) to a
Setup Tool port on the top panel or on the front panel. The Digital Temperature Controller receives the power
required for setup from the computer through the USB bus power source.
Main I/O Functions
48 ×48 mm
E5CC
Refer to Safety Precautions on page 32.
Sensor Input
Dual displays: PV/SV4-digit displays
E5CC
•Thermocouple
•Pt
•Universal analog
current/voltage input
Indication Accuracy
•Thermocouple input:
±0.3% of PV
•Pt input: ±0.2% of PV
•Analog input:
±0.2% of FS
Sampling Period
•50 ms
Event Inputs
•None
•2
•4
Remote SP Input
•None
•1
Control Output 1
•Relay output
•Voltage output (for driving SSR)
•Current output
Control Output 2
•None
•Voltage output (for driving SSR)
Transfer Output
•None
•1
•PF (shift) Key
•Temperature status display
•Simple programming
•Independent heating and
cooling PID control
•Changed parameter display
•Display brightness setting
Auxiliary Outputs
•3
This datasheet is provided as a guideline for selecting products.
Be sure to refer to the following manuals for application precautions and other information required for operation before attempting
to use the product.
E5CC/E5EC Digital Controllers User’s Manual (Cat. No. H174)
E5CC/E5EC Digital Controllers Communications Manual (Cat. No. H175)

E5CC
3
Model Number Legend and Standard Models
Model Number Legend
E5CC-@@ @@@@-@@@ (Example: E5CC-RX3A5M-000)
−− − −− − −−−
ABCDEF
*1. Options with HB and HS alarms (001 and 003) cannot be selected if a current output is selected for the control output.
*2. The control output cannot be used as a transfer output.
*3. Option 004 can be selected only when "CX"is selected for the control outputs.
Heating and Cooling Control
●Using Heating and Cooling Control
AControl Output Assignment
If there is no control output 2, an auxiliary output is used as the cooling control output.
If there is a control output 2, the two control outputs are used for heating and cooling.
(It does not matter which output is used for heating and which output is used for cooling.)
BControl
If PID control is used, youcan set PID control separately for heating and cooling.
This allows youto handle control systems with different heating and cooling response characteristics.
Model
A BCDEF
Meaning
Control outputs
1 and 2
No. of
auxiliary
outputs
Power
supply
voltage
Terminal
type
Input
type Options
E5CC 48×48mm
Control output 1 Control output 2
RX Relay output None
QX Voltage output
(for driving SSR) None
*1 *3 CX Linear current output *2 None
QQ Voltage output
(for driving SSR)
Voltage output
(for driving SSR)
3 3 (one common)
A 100 to 240 VAC
D 24 VAC/DC
5 Screw terminals (with cover)
MUniversalinput
HB alarm and
HS alarm
Communications
Event
inputs
Remote
SP Input
Transfer
output
000 --- --- --- --- ---
*1 001 1 --- 2 --- ---
*1 003
2
(for 3-phase
heaters)
RS-485 --- --- ---
*3 004 --- RS-485 2 --- ---
005 --- --- 4 --- ---
006 --- --- 2 Provided.
007 --- --- 2 Provided. ---

E5CC
4
Optional Products (Order Separately)
USB-Serial Conversion Cable
Terminal Covers
Note: The E53-COV10 cannot be used.
Refer to page 11 for the mounted dimensions.
Waterproof Packing
Note: This Waterproof Packing is provided with the Digital
Temperature Controller.
Current Transformers (CTs)
Adapter
Note: Use this Adapter when the panel has already been prepared for
an E5B@Controller.
Waterproof Cover
Note: This Cover complies with IP66 and NEMA 4X waterproofing.
Front panel: IP66 protection.
Mounting Adapter
Note: This Mounting Adapter is provided with the Digital Temperature
Controller.
DIN Track Mounting Adapter
Front Covers
CX-Thermo Support Software
Note: CX-Thermo version 4.4 or higher is required for the E5CC.
Model
E58-CIFQ2
Model
E53-COV17
E53-COV23
Model
Y92S-P8
Hole diameter Model
5.8mm E54-CT1
12.0 mm E54-CT3
Model
Y92F-45
Model
Y92A-48N
Model
Y92F-49
Model
Y92F-52
Type Model
Hard Front Cover Y92A-48H
Soft Front Cover Y92A-48D
Model
EST2-2C-MV4

E5CC
5
Specifications
Ratings
*Youcannot select a relay output or current output for control output 2.
Power supply voltage A in model number: 100 to 240 VAC, 50/60 Hz
D in model number: 24 VAC, 50/60 Hz; 24 VDC
Operating voltage range 85%to 110%of rated supply voltage
Power consumption
Models with option selection of 000:5.2 VA max. at 100 to 240 VAC, and 3.1 VA max. at 24 VDC or
1.6 Wmax. at 24 VDC
All other models: 6.5 VA max. at 100 to 240 VAC, and 4.1 VA max. at 24 VDC or 2.3 Wmax. at 24 VDC
Sensor input
Models with temperature inputs
Thermocouple: K, J, T, E, L, U, N, R, S, B, W, or PL II
Platinum resistance thermometer: Pt100 or JPt100
Infrared temperature sensor (ES1B): 10 to 70°C, 60 to 120°C, 115 to 165°C, or 140 to 260°C
Analog input
Current input: 4 to 20 mA or 0 to 20 mA
Voltage input: 1 to 5 V, 0 to 5 V, or 0 to 10 V
Input impedance Current input: 150 Ωmax., Voltage input: 1 MΩmin.
(Use a 1:1 connection when connecting the ES2-HB/THB.)
Control method ON/OFF control or 2-PID control (with auto-tuning)
Control
output
Relay output SPST-NO, 250 VAC, 3 A (resistive load), electrical life: 100,000 operations,
minimum applicable load: 5 V, 10 mA *
Voltage output
(for driving SSR) Output voltage: 12 VDC ±20%(PNP), max. load current: 21 mA, with short-circuit protection circuit
Current output 4 to 20 mA DC/0 to 20 mA DC, load: 500 Ωmax., resolution: approx. 10,000
Auxiliary
output
Number of outputs 3
Output specifications N.O. relay outputs, 250 VAC, Models with 3 outputs: 2 A (resistive load),
Electrical life: 100,000 operations, Minimum applicable load: 10 mA at 5 V
Event input
Number of inputs 2 or 4 (depends on model)
External contact input
specifications
Contact input: ON: 1 kΩmax., OFF: 100 kΩmin.
Non-contact input: ON: Residual voltage: 1.5 Vmax., OFF: Leakage current: 0.1 mA max.
Current flow: Approx. 7 mA per contact
Transfer
output
Number of outputs 1 (only on models with a transfer output)
Output specifications Contact output: 4 to 20 mA DC, load: 500 Ωmax., resolution: approx. 10,000
Linear voltage output: 1 to 5 VDC, load: 1 kΩmax, resolution: Approx. 10,000
Setting method Digital setting using front panel keys
Remote SP input Current input: 4 to 20 mA DC or 0 to 20 mA DC (input impedance: 150 Ωmax.)
Voltage input: 1 to 5 V, 0 to 5 V, or 0 to 10 V(input impedance: 1 MΩmin.)
Indication method 11-segment digital display and individual indicators
Character height: PV: 15.2 mm, SV: 7.1 mm
Multi SP Up to eight set points (SP0 to SP7) can be saved and selected using event inputs, key operations, or
serial communications.
Other functions
Manual output, heating/cooling control, loop burnout alarm, SP ramp, other alarm functions, heater
burnout (HB) alarm (including SSR failure (HS) alarm), 40%AT, 100%AT, MVlimiter, input digital
filter, self tuning, robust tuning, PVinput shift, run/stop, protection functions, extraction of square root,
MVchange rate limit, simple calculations, temperature status display, simple programming, moving
average of input value, and display brightness setting
Ambient operating temperature -10 to 55°C (with no condensation or icing),
for 3-year warranty: -10 to 50°C (with no condensation or icing)
Ambient operating humidity 25%to 85%
Storage temperature -25 to 65°C (with no condensation or icing)

E5CC
6
Input Ranges
●Thermocouple/Platinum Resistance Thermometer (Universal inputs)
Shaded settings are the default settings.
The applicable standards for the input types are as follows:
K, J, T, E, N, R, S, B: JIS C 1602-1995, IEC 60584-1 JPt100: JIS C 1604-1989, JIS C 1606-1989
L: Fe-CuNi, DIN 43710-1985 Pt100: JIS C 1604-1997, IEC 60751
U: Cu-CuNi, DIN 43710-1985 PL II: According to Platinel II electromotive force charts from BASF (previously Engelhard)
W: W5Re/W26Re, ASTM E988-1990
●Analog input
Input type Platinum resistance
thermometer Thermocouple Infrared temperature sensor
Name Pt100 JPt100 K J T E L U N R S B W PLII
10 to
70°C
60 to
120°C
115 to
165°C
140 to
260°C
2300
1800
1700
1600
1500
1400
1300
1200
1100
1000
900
800
700
600
500
400
300
200
100
0
-100
-200
2300
1800
1700 1700
1300 1300 1300
850 850 850
600
500.0 500.0 500.0
400.0
400 400.0 400 400.0
260
120 165
100.0 100.0 90
100
0.0 0.0 00 000000
-20.0 -100 -20.0 -100
-200
-199.9 199.9 -200 -200 -199.9 -200 -200 -199.9 -200
Setting
number 0123456789 10111213141516171819 20 21 22 23 24
Input type Current Voltage
Input
specification
4 to 20 mA 0 to 20 mA 1 to 5 V0 to 5 V0 to 10 V
Setting range
Usable in the following ranges by scaling:
-1999 to 9999, -199.9 to 999.9,
-19.99 to 99.99 or -1.999 to 9.999
Setting number 25 26 27 2829
Temperature range (°C)

E5CC
7
Alarm Outputs
Each alarm can be independently set to one of the following 19 alarm types. The default is 2: Upper limit. (see note.)
Auxiliary outputs are allocated for alarms. ON delays and OFF delays (0 to 999 s) can also be specified.
Note: In the default settings for models with HB or HS alarms, alarm 1 is set to a heater alarm (HA) and the Alarm Type 1 parameter is not displayed.
To use alarm 1, set the output assignment to alarm 1.
*1 With set values 1, 4 and 5, the upper and lower limit values can be set
ndependently for each alarm type, and are expressed as “L” and “H.”
*2 Set value: 1, Upper- and lower-limit alarm
*3 Set value: 4, Upper- and lower-limit range
*4 Set value: 5, Upper- and lower-limit with standby sequence
For Upper- and Lower-Limit Alarm Described Above *2
• Case 1 and 2
Always OFF when the upper-limit and lower-limit hysteresis overlaps.
• Case 3: Always OFF
*5. Set value: 5, Upper- and lower-limit with standby sequence
Always OFF when the upper-limit and lower-limit hysteresis overlaps.
*6 Refer to the E5CC/E5EC Digital Controllers User's Manual (Cat. No. H174)
for information on the operation of the standby sequence.
*7 Refer to the E5CC/E5EC Digital Controllers User's Manual (Cat. No.H174)
for information on the loop burnout alarm (LBA).
*8Refer to the E5CC/E5EC Digital Controllers User's Manual (Cat. No. H174)
for information on the PVchange rate alarm.
*9 When heating/cooling control is performed, the MVabsolute upper limit
alarm functions only for the heating operation and the MVabsolute lower
limit alarm functions only for the cooling operation.
*10 This value is displayed only when a remote SP input is used. It functions in
both Local SP Mode and Remote SP Mode.
Set
value
Alarm type
Alarm output operation
Description of function
When alarm value
X is positive
When alarm value
X is negative
0Alarmfunction OFF Output OFF No alarm
1 Upper- and lower-limit *1 *2
Set the deviation in the set point by setting the alarm upper
limit (H) and alarm lower limit (L). The alarm is ON when the
PVis outside this deviation range.
2 Upper-limit
Set the upward deviation in the set point by setting the alarm
value (X). The alarm is ON when the PVis higher than the SP
by the deviation or more.
3 Lower-limit
Set the downward deviation in the set point by setting the
alarm value (X). The alarm is ON when the PVis lower than
the SP by the deviation or more.
4Upper- and lower-limit
range *1 *3
Set the deviation in the set point by setting the alarm upper
limit (H) and alarm lower limit (L). The alarm is ON when the
PVis inside this deviation range.
5Upper- and lower-limit with
standby sequence *1 *4 A standby sequence is added to the upper- and lower-limit
alarm (1). *6
6Upper-limit with standby
sequence A standby sequence is added to the upper-limit alarm (2). *6
7Lower-limit with standby
sequence A standby sequence is added to the lower-limit alarm (3). *6
8Absolute-value upper-limit The alarm will turn ON if the process value is larger than the
alarm value (X) regardless of the set point.
9 Absolute-value lower-limit The alarm will turn ON if the process value is smaller than the
alarm value (X) regardless of the set point.
10 Absolute-value upper-limit
with standby sequence
A standby sequence is added to the absolute-value upper-lim-
it alarm (8). *6
11 Absolute-value lower-limit
with standby sequence
A standby sequence is added to the absolute-value lower-limit
alarm (9). *6
12
LBA (alarm 1 type only) -*7
13 PVchange rate alarm - *8
14 SP absolute value
upper limit
This alarm type turns ON the alarm when the set point (SP) is
higher than the alarm value (X).
15 SP absolute value
lower limit
This alarm type turns ON the alarm when the set point (SP) is
smaller than the alarm value (X).
16 MVabsolute value
upper limit *9
This alarm type turns ON the alarm when the manipulated
variable (MV) is higher than the alarm value (X).
17 MVabsolute value
lower limit *9
This alarm type turns ON the alarm when the manipulated
variable (MV) is smaller than the alarm value (X).
18RSP absolute value
upper limit *10
The alarm will turn ON when the remote SP (RSP) is larger
than the alarm value (X).
19 RSP absolute value
lower limit *10
The alarm will turn ON when the remote SP (RSP) is smaller
than the alarm value (X).
ON
OFF PV
SP
LH
SP
X
ON
OFF PV SP
X
ON
OFF PV
SP
X
ON
OFF PV SP
X
ON
OFF PV
SP
LH
ON
OFF PV
SP
LH
ON
OFF PV
*5
SP
X
ON
OFF PV SP
X
ON
OFF PV
SP
X
ON
OFF PV SP
X
ON
OFF PV
0
X
ON
OFF PV 0
X
ON
OFF PV
0
X
ON
OFF PV 0
X
ON
OFF PV
0
X
ON
OFF PV 0
X
ON
OFF PV
0
X
ON
OFF PV 0
X
ON
OFF PV
0
X
ON
OFF SP 0
X
ON
OFF SP
0
X
ON
OFF SP 0
X
ON
OFF SP
0
X
ON
OFF MV 0
X
ON
OFF MV
0
X
ON
OFF MV 0
X
ON
OFF MV
0
X
ON
OFF RSP 0
X
ON
OFF RSP
0
X
ON
OFF RSP 0
X
ON
OFF RSP
LH
H<0, L>0
|H| < |L|
SP
Case 1
LH
H>0, L<0
|H| > |L|
SP
Case 2
LH
H<0, L<0
SP
LH
H<0, L>0
|H| ≥ |L|
SP
LH
H>0, L<0
|H| ≤ |L|
SP
Case 3 (Always ON)
LH
H<0, L>0
|H| < |L|
SP
Case 1
LH
H>0, L<0
|H| > |L|
SP
Case 2
LH
H<0, L<0
SP
L
L
H
H<0, L>0
|H| ≥ |L|
SP
H
H>0, L<0
|H| ≤ |L|
SP
Case 3 (Always OFF)

E5CC
8
Characteristics
*1 The indication accuracy of K thermocouples in the -200 to 1300°C range, T and N thermocouples at a temperature of -100°C max., and U and
L thermocouples at any temperatures is ±2°C ±1 digit max. The indication accuracy of the B thermocouple at a temperature of 400°Cmax. is
not specified. The indication accuracy of B thermocouples in the 400 to 800°Crange is ±3°C max. The indication accuracy of the R and S
thermocouples at a temperature of 200°C max. is ±3°C ±1 digit max. The indication accuracy of Wthermocouples is ±0.3 of PVor ±3°C,
whichever is greater, ±1 digit max. The indication accuracy of PL II thermocouples is ±0.3 of PVor ±2°C, whichever is greater, ±1 digit max.
*2 Ambient temperature: -10°C to 23°C to 55°C, Voltage range: -15%to 10%of rated voltage
*3 K thermocouple at -100°C max.: ±10°C max.
*4 “EU” stands for Engineering Unit and is used as the unit after scaling. For a temperature sensor, the EU is °C or °F.
*5 The unit is determined by the setting of the Integral/Derivative Time Unit parameter.
*6 External communications (RS-485) and USB-serial conversion cable communications can be used at the same time.
*7 Access the following website for information on certified models. http://www.ia.omron.com/support/models/index.html
*8Refer to information on maritime standards in Shipping Standards on page 34 for compliance with Lloyd's Standards.
Indication accuracy
(at the ambient temperature of 23°C)
Thermocouple: (±0.3%of indicated value or ±1°C, whichever is greater) ±1 digit max. *1
Platinum resistance thermometer: (±0.2%of indicated value or ±0.8°C, whichever is greater) ±1 digit
Analog input: ± 0.2%FS ± 1 digit max.
CT input: ±5%FS ±1 digit max.
Transfer output accuracy ±0.3%FS max.
Remote SP Input Type ±0.2%FS ±1 digit max.
Influence of temperature *2 Thermocouple input (R, S, B, W, PL II): (±1%of PVor ±10°C, whichever is greater) ±1 digit max.
Other thermocouple input: (±1%of PVor ±4°C, whichever is greater) ±1 digit max. *3
Platinum resistance thermometer: (±1%of PVor ±2°C, whichever is greater) ±1 digit max.
Analog input: (±1%FS) ±1 digit max.
CT input: (±5%FS) ±1 digit max.
Remote SP input: (±1%FS) ±1 digit max.
Influence of voltage *2
Input sampling period 50 ms
Hysteresis Temperature input: 0.1 to 999.9°C or °F (in units of 0.1°C or °F) *4
Analog input: 0.01%to 99.99%FS (in units of 0.01%FS)
Proportional band (P) Temperature input: 0.1 to 999.9°C or °F (in units of 0.1°C or °F) *4
Analog input: 0.1%to 999.9%FS (in units of 0.1%FS)
Integral time (I) 0 to 9999 s (in units of 1 s), 0.0 to 999.9 s (in units of 0.1 s) *5
Derivative time (D) 0 to 9999 s (in units of 1 s), 0.0 to 999.9 s (in units of 0.1 s) *5
Proportional band (P) for cooling Temperature input: 0.1 to 999.9°C or °F (in units of 0.1°C or °F) *4
Analog input: 0.1%to 999.9%FS (in units of 0.1%FS)
Integral time (I) for cooling 0 to 9999 s (in units of 1 s), 0.0 to 999.9 s (in units of 0.1 s) *5
Derivative time (D) for cooling 0 to 9999 s (in units of 1 s), 0.0 to 999.9 s (in units of 0.1 s) *5
Control period 0.1, 0.2, 0.5, 1 to 99 s (in units of 1 s)
Manual reset value 0.0 to 100.0%(in units of 0.1%)
Alarm setting range -1999 to 9999 (decimal point position depends on input type)
Affect of signal source resistance Thermocouple: 0.1°C/Ωmax. (100 Ωmax.)
Platinum resistance thermometer: 0.1°C/Ωmax. (10 Ωmax.)
Insulation resistance 20 MΩmin. (at 500 VDC)
Dielectric strength 2,300 VAC, 50 or 60 Hz for 1 min (between terminals with different charge)
Vibration resistance 10 to 55 Hz, 20 m/s2for 10 min each in X, Y, and Z directions
Malfunction 10 to 55 Hz, 20 m/s2for 2 hrs each in X, Y, and Z directions
Destruction
Shock resistance 100 m/s2, 3 times each in X, Y, and Z directions
Malfunction 300 m/s2, 3 times each in X, Y, and Z directions
Weight Controller: Approx. 120 g, Mounting Bracket: Approx. 10 g
Degree of protection Front panel: IP66, Rear case: IP20, Terminals: IP00
Memory protection Non-volatile memory (number of writes: 1,000,000 times)
Setup Tool CX-Thermo version 4.4 or higher
Setup Tool port E5CC top panel: An E58-CIFQ2 USB-Serial Conversion Cable is used to connect a USB port on the
computer with the port on the top panel of the E5CC. *6
Standards Approved standards UL 61010-1, CSA C22.2 No. 611010-1 (evaluated by UL), KOSHA certified (some models) *7, Korean
Radio Waves Act (Act 10564)
Conformed standards EN 61010-1 (IEC 61010-1): Pollution level 2, overcurrent category II, Lloyd's standards *8
EMC
EMI: EN61326
Radiated Interference Electromagnetic Field Strength: EN 55011 Group 1, class A
Noise Terminal Voltage: EN 55011 Group 1, class A
EMS: EN 61326
ESD Immunity: EN 61000-4-2
Electromagnetic Field Immunity: EN 61000-4-3
Burst Noise Immunity: EN 61000-4-4
Conducted Disturbance Immunity: EN 61000-4-6
Surge Immunity: EN 61000-4-5
Voltage Dip/Interrupting Immunity: EN 61000-4-11

E5CC
9
USB-Serial Conversion Cable
* Use a high-power port for the USB port.
Note: A driver must be installed in the personal computer. Refer to
installation information in the operation manual for the
Conversion Cable.
Communications Specifications
* The baud rate, data bit length, stop bit length, and vertical parity can
be individually set using the Communications Setting Level.
Current Transformer (Order Separately)
Ratings
Heater Burnout Alarms and SSR Failure
Alarms
*1 For heater burnout alarms, the heater current will be measured
when the control output is ON, and the output will turn ON if the
heater current is lower than the set value (i.e., heater burnout
detection current value).
*2 For SSR failure alarms, the heater current will be measured when
the control output is OFF, and the output will turn ON if the heater
current is higher than the set value (i.e., SSR failure detection
current value).
*3 The value is 30 ms for a control period of 0.1 s or 0.2 s.
*4 The value is 35 ms for a control period of 0.1 s or 0.2 s.
Electrical Life Expectancy Curve for
Relays (Reference Values)
Applicable OS Windows 2000, XP, Vista, or 7
Applicable software CX-Thermo version 4.4 or higher
Applicable models E5CC/E5EC and E5CB
USB interface
standard Conforms to USB Specification 1.1.
DTE speed 38400 bps
Connector
specifications
Computer: USB (type A plug)
Digital Temperature Controller:
Setup Tool port
Power supply Bus power (Supplied from USB host con-
troller.)*
Power supply
voltage 5 VDC
Current
consumption 450 mA max.
Output voltage
4.7±0.2 VDC
(Supplied from USB-Serial Conversion
Cable to the Digital Temperature Controller.)
Output current
250 mA max.
(Supplied from USB-Serial Conversion
Cable to the Digital Temperature Controller.)
Ambient operating
temperature 0 to 55°C (with no condensation or icing)
Ambient operating
humidity 10%to 80%
Storage temperature -20 to 60°C (with no condensation or icing)
Storage humidity 10%to 80%
Altitude 2,000 m max.
Weight Approx. 120 g
Transmission line
connection method RS-485: Multipoint
Communications RS-485 (two-wire, half duplex)
Synchronization
method Start-stop synchronization
Protocol CompoWay/F, or Modbus
Baud rate 19200, 38400, or 57600 bps
Transmission code ASCII
Data bit length* 7 or 8bits
Stop bit length* 1 or 2 bits
Error detection
Vertical parity (none, even, odd)
Block check character (BCC) with
CompoWay/F or CRC-16 Modbus
Flow control None
Interface RS-485
Retry function None
Communications
buffer 217 bytes
Communications
response wait time
0 to 99 ms
Default: 20 ms
Dielectric strength 1,000 VAC for 1 min
Vibration resistance 50 Hz, 98m/s2
Weight
E54-CT1: Approx. 11.5 g,
E54-CT3: Approx. 50 g
Accessories
(E54-CT3 only)
Armatures (2)
Plugs (2)
CT input (for heater
current detection)
Models with detection for singlephase
heaters: One input
Models with detection for singlephase or
three-phase heaters: Two inputs
Maximum heater
current 50 A AC
Input current
indication accuracy ±5%FS ±1 digit max.
Heater burnout
alarm setting range
*1
0.1 to 49.9 A (in units of 0.1 A)
Minimum detection ON time: 100 ms *3
SSR failure alarm
setting range *2
0.1 to 49.9 A (in units of 0.1 A)
Minimum detection OFF time: 100 ms *4
500
300
100
50
30
10
5
3
1
0123456
Switching current (A)
E5CC
250 VAC, 30 VDC
(resistive load)
cosφ = 1
Life (× 104operations)

E5CC
10
External Connections
E5CC
Note: 1. The application of the terminals depends on the model.
2. Do not wire the terminals that are shown with a gray background.
3. When complying with EMC standards, the cable that connects the sensor must be 30 m or less.
If the cable length exceeds 30 m, compliance with EMC standards will not be possible.
4. Connect M3 crimped terminals.
Isolation/Insulation Block Diagrams
Models with 3 Auxiliary Outputs
Voltage output
(for driving SSR)
12 VDC, 21 mA
Control output 2
The E5CC is set for a K-type thermocouple (input type = 5) by
default. An input error (s.err) will occur if the input type setting does
not agree with the temperature sensor. Check the input type.
Control output 1
Relay output
250 VAC, 3A
(resistive load)
Voltage output
(for driving SSR)
12 VDC, 21 mA
Current output
0 to 20 mA DC
4 to 20 mA DC
Load: 500 Ω max.
Relay outputs
Models with 3 auxiliary
outputs: 250 VAC, 2 A
(resistive load)
17
18 12
15
16
1
2
13
14
3
11
4
6
7
8
9
10
5
6
4
5
6
5
6
Pt
A
B
B
+
-
m
A
-
+
5
4
V
-5
V6
+
4
TC
4
I
(no polarity)
11
12
11
12
100 to 240 VAC 24 VAC/VDC
Auxiliary outputs 1, 2, 3
7
8
9
10 ●●
Auxiliary output 2
Auxiliary output 3
Auxiliary output 1
18
++
-
+
+
-
13
16
17
16
17
18
13
16
17
18
13
14
15
13
14
15
16
18
13
14
15
16
17
18
16
17
005
Event Inputs
1 to 4
004
Communications
(RS-485), and
Event Inputs 3 and 4
13
007
Event Inputs
1 and 2, and
Remote SP Input
006
Event Inputs
1 and 2, and
Transfer Output
001
Event Inputs 1
and 2, and CT1
17
18
V
I
V
m
A
003
Communications
(RS-485), CT1,
and CT2
14
15
14
15
14
15
EV1
EV2
EV1
EV2
EV1
EV2
EV1
EV2
EV3
EV4
EV3
EV4
CT1
B(+)
A(-)
RS-485
B(+)
A(-)
RS-485
CT2
COM
CT1
(2) Auxiliary Outputs
(3) Input Power Supply
(5) Sensor (Temperature/Analog) Input
(6) Options
+-
3
1
2
3
1
2-
Models with
1 Current
Output
Models with
1 Relay
Output
3+Q
1+
2-
3
Models with 2
Voltage Outputs
(for Driving SSR)
(1) Control outputs 1, 2
Q
OUT1
C
OUT1
OUT1
OUT2
Q
OUT1
R
1
2
Models with 1
Voltage Output
(for Driving SSR)
+
RX QX CX QQ
Auxiliary outputs 1 to 3
E5CC-@@ 3@ 5 M -@@@
(1) (2) (3) (4) (5) (6)
↑
Terminal type
Sensor input, CT inputs, and remote SP input
Communications and event inputs
Voltage output (for driving SSR),
current output, and transfer output
Relay output
Auxiliary outputs 1, 2, 3
: Reinforced insulation
: Functional isolation
Power
supply
Note: Auxiliary outputs 1 to 3 are not isolated.

E5CC
11
Nomenclature
Dimensions (Unit: mm)
Controllers
Accessories (Order Separately)
E5CC
Top View
Level key
Temperature unit
No.1 display
No. 2 display
Setup Tool port
on top panel
Up key
Mode key Shift (PF) key Down key
Operation
indicators
45+0.6
0
45+0.6
0
45+0.6
0
60 min.
(48 × number of units - 2.5)+1.0
0
Group mounting does
not allow waterproofing.
Panel Cutout
Mounted Separately Group Mounted
48 × 48
4
1
73.1
60
Mounting Adapter
(Accessory) Terminal Cover
(E53-COV17)
(Sold separately)
5848.8
Waterproof Packing
(Accessory)
44.8 × 44.8
E5
CC
• Recommended panel thickness is 1 to 5 mm.
•Group mounting is not possible in the vertical direction. (Maintain
the specified mounting space between Controllers.)
•Tomount the Controller so that it is waterproof, insert the
waterproof packing onto the Controller.
•When two or more Controllers are mounted, make sure that the
surrounding temperature does not exceed the allowable operating
temperature specified in the specifications.
• To attach the USB-Serial Conversion Cable to the control panel,
use a panel thickness of 1 to 2.5 mm.
The Setup Tool port is on the top of the Temperature Controller.
It is used to connect the Temperature Controller to the computer
to use the Setup Tool.
The E58-CIFQ2 USB-Serial Conversion Cable is required to
make the connection.
Refer to the instructions that are provided with the USB-Serial
Conversion Cable for the connection procedure.
Note: Do not leave the USB-Serial Conversion Cable
connected when youuse the Temperature Controller.
(2,109.1)
(87)250 1,740
(13)
(250)
(5) (15)
USB connector (type A plug)
Serial connecto
r
LED (SD)
LED (PWR)
LED (RD)
●U
S
B-
S
erial
C
onversion
C
able
E58-CIFQ2
48
48.8
22
9.1
10
44.8
2 3.8
Terminal Cover
(E53-COV23)
●Terminal Covers
E53-COV17
●Terminal Covers
E53-COV23 (Three Covers provided.)

E5CC
12
●Current Transformers
●Waterproof Packing
Y92S-P8(for DIN 48×48)
The Waterproof Packing is provided with the Temperature Controller.
Order the Waterproof Packing separately if it becomes lost or damaged.
The Waterproof Packing can be used to achieve an IP66 degree of protection.
(Deterioration, shrinking, or hardening of the waterproof packing may occur depending on the
operating environment. Therefore, periodic replacement is recommended to ensure the level of
waterproofing specified in IP66. The time for periodic replacement depends on the operating
environment. Be sure to confirm this point at your site.
Consider three years a rough standard. OMRON shall not be liable for the level of water resistance
if the customer does not perform periodic replacement.)
The Waterproof Packing does not need to be attached if a waterproof structure is not required.
E54-CT3 Accessory
• Armature
30
21
15 5.8 dia.
25 3
40
10.5
2.8
7.5
10
Two, 3.5 dia.
40 × 40
30
12 dia.
9
2.36 dia.
15
30
Two, M3 (depth: 4)
A
pprox. 3 dia.
18
(22)
A
pprox. 6 dia.
Plug
Armature
Lead
E54-CT1
E54-CT3
Connection Example
•Plug
Thru-current (Io) vs. Output Voltage (Eo)
(Reference Values)
E54-CT1
Maximum continuous heater current: 50 A (50/60 Hz)
Number of windings: 400±2
Winding resistance: 18±2 Ω
Thru-current (Io) A (r.m.s.)
1 10 100mA 1 10 100
1,000A
100V
Frequency: 50 Hz
Distortion
factor
10%
3%
1%
100Ω
RL=10Ω
∞
10
1
100mV
10
1
100μV
10
1kΩ
Output voltage (Eo) V (r.m.s.)
Thru-current (Io) vs. Output Voltage (Eo)
(Reference Values)
E54-CT3
Maximum continuous heater current: 120 A (50/60 Hz)
(Maximum continuous heater current for an OMRON
Digital Temperature Controller is 50 A.)
Number of windings: 400±2
Winding resistance: 8±0.8Ω
Thru-current (Io) A (r.m.s.)
1 10 100mA 1 10 100
1,000A
100V
Frequency: 50 Hz
Distortion
factor
10%
3%
1%
1kΩ
100Ω
50Ω
RL=10Ω
500Ω
∞
10
1
100mV
10
1
100μV
10
Output voltage (Eo) V (r.m.s.)

E5CC
13
●Adapter
●DIN Track Mounting Adapter
Fixture (Accessory)
69.6 to 77.6
8767 × 67
72 × 72
76
4.7
72 × 72
48 × 48
Panel (1 to 8 mm) Mounting Adapter
Y92F-30
(Accessory)
62.8
To back of the E5CC
2.2 4.7
Y92F-45
Mounted to E5CC
Note: 1. Use this Adapter when the Front Panel has already been prepared for the E5B@.
2. Only black is available.
3. You cannot use the E58-CIFQ2 USB-Serial Conversion Cable if you use the Y92F-45 Adapter. To use the USB-Serial
Conversion Cable to make the settings, do so before you mount the Temperature Controller in the panel.
50
61
3.5
38
48
80.5
(Mounted to E5CC)
Note: This Adapter cannot be used together with the Terminal Cover.
Remove the Terminal Cover to use the Adapter.
Y92F-52

E5CC
14
●Watertight Cover
Y92A-48N
●Mounting Adapter
Y92F-49
●Protective Cover
Y92A-48D
●Protective Cover
Y92A-48H
67.6
69
12
21.9 14
(2)
79.2
87.7
The Mounting Adapter is provided with the
Temperature Controller.
Order this Adapter separately if it becomes
lost or damaged.
This Protective Cover is soft type.
It is able to operate the controller with using
this cover.
This Protective Cover is hard type.
Please use it for the mis-operation
prevention etc.

MEMO
15

16
Digital Temperature Controller
E5EC (48 ×96 mm)
Large White PV Display That’s Easier to Read.
Easy to Use, from Model Selection to
Setup and Operation.
A Complete Range of I/O Capacities,
Functions, and Performance.
Handles More Applications.
• A white LCD PV display with a height of approx. 18 mm
improves visibility.
• Easily connect the CX-Thermo (sold separately) through a
USB-Serial Conversion Cable (sold separately) to a Setup Tool
port on the top panel or on the front panel. The Digital
Temperature Controller receives the power required for setup
from the computer through the USB bus power source.
Settings can be made from CX-Thermo or the front panel of the
Digital Temperature Controller without wiring the power supply.
• High-speed sampling at 50 ms.
• Models with up to 4 auxiliary outputs, 6 event inputs, a transfer
output, and remote SP input added to the lineup. Complete selection
of I/O capacities.
• Short body with depth of only 60 mm.
Main I/O Functions
48 ×96 mm
E5EC
Refer to Safety Precautions on page 32.
E5E
C
4-digit displays
Sensor Input
•Thermocouple
•Pt
•Universal analog
current/voltage input
Indication Accuracy
•Thermocouple input:
±0.3% of PV
•Pt input: ±0.2% of PV
•Analog input: ±0.2% of FS
Sampling Period
•50 ms
Event Inputs
•None
•2
•4
•6
Remote SP Input
•None
•1
Control Output 1
•Relay output
•Voltage output (for driving SSR)
•Current output
Control Output 2
•Voltage output (for driving SSR)
•Relay output
•Current output
Auxiliary Outputs
•4
Transfer Output
•None
•1
•PF (shift) Key
•Setup Tool port on front panel
•Temperature status display
•Simple programming
•Independent heating and
cooling PID control
•Changed parameter display
•Display brightness setting
Three-level Display
PV, SV, and MVdisplayed
at the same time.
This datasheet is provided as a guideline for selecting products.
Be sure to refer to the following manuals for application precautions and other information required for operation before attempting
to use the product.
E5CC/E5EC Digital Controllers User’s Manual (Cat. No. H174)
E5CC/E5EC Digital Controllers Communications Manual (Cat. No. H175)

E5EC
17
Model Number Legend and Standard Models
Model Number Legend
E5EC-@@ @@@@-@@@ (Example: E5EC-RX4A5M-000)
−− − −− − −−−
ABCDEF
*1. The options that can be selected depend on the type of control output.
*2. The control output cannot be used as a transfer output.
*3. A model with four auxiliary outputs must be selected.
Heating and Cooling Control
l Using Heating and Cooling Control
AControl Output Assignment
If there is no control output 2, an auxiliary output is used as the cooling control output.
If there is a control output 2, the two control outputs are used for heating and cooling.
(It does not matter which output is used for heating and which output is used for cooling.)
BControl
If PID control is used, youcan set PID control separately for heating and cooling.
This allows youto handle control systems with different heating and cooling response characteristics.
Model
A BCDEF
Meaning
Control outputs
1 and 2
No. of
auxiliary
outputs
Power
supply
voltage
Terminal
type
Input
type Options
E5EC 48×96 mm
Control output 1 Control output 2
*1 RX Relay output None
*1 QX Voltage output
(for driving SSR) None
*1, *2 CX Linear current output None
*1 QQ Voltage output
(for driving SSR)
Voltage output
(for driving SSR)
*1 QR Voltage output
(for driving SSR) Relay output
*1 RR Relay output Relay output
*1, *2 CC Linear current outputLinear current out-
put
*3 44 (auxiliary outputs 1 and 2 with same common and auxiliary
outputs 3 and 4 with same common)
A 100 to 240 VAC
D 24 VAC/DC
Control outputs 1 and 2 5 Screw terminals (with cover)
Option
selection
conditions
*1
For RX,
QX, QQ,
QR, or RR
For CX or
CC
MUniversalinput
HB alarm and
HS alarm
Communications
Event
inputs
Remote
SP Input
Transfer
output
Selectable Selectable 000 --- --- --- --- ---
Selectable 004 --- RS-485 2 --- ---
Selectable 005 --- --- 4 --- ---
Selectable 009
2
(for 3-phase
heaters)
RS-485 2 --- ---
Selectable 010 1 --- 4 --- ---
Selectable 011 1 --- 6 Provided. Provided.
Selectable 013 --- --- 6 Provided. Provided.
Selectable 014 --- RS-485 4 Provided. Provided.

E5EC
18
Optional Products (Order Separately)
USB-Serial Conversion Cable
Communications Conversion Cable
Note: Always use this product together with the E58-CIFQ2.
Terminal Covers
Waterproof Packing
Note: This Waterproof Packing is provided with the Digital
Temperature Controller.
Waterproof Cover
Note: This Cover complies with IP66 and NEMA 4X waterproofing.
Front panel: IP66 protection.
Front Port Cover
Note: This Front Port Cover is provided with the Digital Temperature
Controller.
Mounting Adapter
Note: This Mounting Adapter is provided with the Digital Temperature
Controller.
Current Transformers (CTs)
CX-Thermo Support Software
Note: CX-Thermo version 4.4 or higher is required for the E5EC.
Model
E58-CIFQ2
Model
E58-CIFQ2-E
Model
E53-COV24
Model
Y92S-P9
Model
Y92A-49N
Model
Y92S-P7
Model
Y92F-51
(Two Adapters are included.)
Hole diameter Model
5.8mm E54-CT1
12.0 mm E54-CT3
Model
EST2-2C-MV4

E5EC
19
Specifications
Ratings
Power supply voltage A in model number: 100 to 240 VAC, 50/60 Hz
D in model number: 24 VAC, 50/60 Hz; 24 VDC
Operating voltage range 85%to 110%of rated supply voltage
Power consumption
Models with option selection of 000:6.6 VA max. at 100 to 240 VAC, and 4.1 VA max. at 24 VDC or
2.3 Wmax. at 24 VDC
All other models: 8.3 VA max. at 100 to 240 VAC, and 5.5 VA max. at 24 VDC or 3.2 Wmax. at 24 VDC
Sensor input
Models with temperature inputs
Thermocouple: K, J, T, E, L, U, N, R, S, B, W, or PL II
Platinum resistance thermometer: Pt100 or JPt100
Infrared temperature sensor (ES1B): 10 to 70°C, 60 to 120°C, 115 to 165°C, or 140 to 260°C
Analog input
Current input: 4 to 20 mA or 0 to 20 mA
Voltage input: 1 to 5 V, 0 to 5 V, or 0 to 10 V
Input impedance Current input: 150 Ωmax., Voltage input: 1 MΩmin.
(Use a 1:1 connection when connecting the ES2-HB/THB.)
Control method ON/OFF or 2-PID (with autotuning) control
Control
output
Relay output SPST-NO, 250 VAC, 5 A (resistive load), electrical life: 100,000 operations,
minimum applicable load: 5 V, 10 mA
Voltage output
(for driving SSR)
Output voltage: 12 VDC ±20%(PNP), max. load current: 40 mA, with short-circuit protection circuit
(The maximum load current is 21 mA for models with two control outputs.)
Current output 4 to 20 mA DC/0 to 20 mA DC, load: 500 Ωmax., resolution: approx. 10,000
Auxiliary
output
Number of outputs 4
Output specifications N.O. relay outputs, 250 VAC, Models with 4 outputs: 2 A (resistive load),
Electrical life: 100,000 operations, Minimum applicable load: 10 mA at 5 V
Event input
Number of inputs 2, 4 or 6 (depends on model)
External contact input
specifications
Contact input: ON: 1 kΩmax., OFF: 100 kΩmin.
Non-contact input: ON: Residual voltage: 1.5 Vmax., OFF: Leakage current: 0.1 mA max.
Current flow: Approx. 7 mA per contact
Transfer
output
Number of outputs 1 (only on models with a transfer output)
Output specifications Current output: 4 to 20 mA DC, Load: 500 Ωmax., Resolution: Approx. 10,000
Linear voltage output: 1 to 5 VDC, load: 1 Ωmax, Resolution: Approx. 10,000
Remote SP input Current input: 4 to 20 mA DC or 0 to 20 mA DC (input impedance: 150 Ωmax.)
Voltage input: 1 to 5 V, 0 to 5 V, or 0 to 10 V(input impedance: 1 MΩmin.)
Setting method Digital setting using front panel keys
Indication method
11-segment digital display and individual indicators
Character height: PV: 18.0 mm, SV: 11.0 mm, MV: 7.8mm
Three displays Contents: PV/SV/MV, PV/SV/Multi-SP, or PV/SV/Remaining soak time
Numbers of digits: 4 digits each for PM, SV, and MVdisplays
Multi SP Up to eight set points (SP0 to SP7) can be saved and selected using event inputs, key operations, or
serial communications.
Bank switching None
Other functions
Manual output, heating/cooling control, loop burnout alarm, SP ramp, other alarm functions, heater
burnout (HB) alarm (including SSR failure (HS) alarm), 40%AT, 100%AT, MVlimiter, input digital
filter, self tuning, robust tuning, PVinput shift, run/stop, protection functions, extraction of square root,
MVchange rate limit, simple calculations, temperature status display, simple programming, moving
average of input value, and display brightness setting
Ambient operating temperature -10 to 55°C (with no condensation or icing),
for 3-year warranty: -10 to 50°C (with no condensation or icing)
Ambient operating humidity 25%to 85%
Storage temperature -25 to 65°C (with no condensation or icing)

E5EC
20
Input Ranges
●Thermocouple/Platinum Resistance Thermometer (Universal inputs)
Shaded settings are the default settings.
The applicable standards for the input types are as follows:
K, J, T, E, N, R, S, B: JIS C 1602-1995, IEC 60584-1 JPt100: JIS C 1604-1989, JIS C 1606-1989
L: Fe-CuNi, DIN 43710-1985 Pt100: JIS C 1604-1997, IEC 60751
U: Cu-CuNi, DIN 43710-1985 PL II: According to Platinel II electromotive force charts from BASF (previously Engelhard)
W: W5Re/W26Re, ASTM E988-1990
●Analog input
Input type Platinum resistance
thermometer Thermocouple Infrared temperature sensor
Name Pt100 JPt100 K J T E L U N R S B W PLII
10 to
70°C
60 to
120°C
115 to
165°C
140 to
260°C
2300
1800
1700
1600
1500
1400
1300
1200
1100
1000
900
800
700
600
500
400
300
200
100
-100
-200
2300
1800
1700 1700
1300 1300 1300
850 850 850
600
500.0 500.0 500.0
400.0 400 400.0 400 400.0
260
120 165
100.0 100.0 90
100
0.0 0.0 00 000000
-20.0 -100 -20.0 -100
-200 -199.9 -199.9 -200 -200 -199.9 -200 -200 -199.9 -200
Setting
range 0123456789 10111213141516171819 20 21 22 23 24
Input type Current Voltage
Input
specification 4 to 20 mA 0 to 20 mA 1 to 5 V0 to 5 V0 to 10 V
Setting range
Usable in the following ranges by scaling:
-1999 to 9999, -199.9 to 999.9,
-19.99 to 99.99 or -1.999 to 9.999
Setting number 25 26 27 2829
Temperature range (°C)
