Omron CS2 Small Cuff User manual

Small cuff Kleine Manschette Petit brassard
Bracciale piccolo Manguito pequeño
Kleine manchet Малая м
анжета
IM-HEM-CS24-E-04-07/2014
5329313-6E
t*OTUSVDUJPOTGPSVTF 2
t.PEFEFNQMPJ 4
t
(FCSBVDITBOXFJTVOH 6
t*TUSV[JPOJQFSMVTP 8
t
*OTUSVDDJPOFTEFVTP 10
t(FCSVJLTBBOXJK[JOH 12
tɂɧɫɬɪɭɤɰɢɹɞɥɹɩɨɥɶɡɨɜɚɬɟɥɹ 14
EN
FR
DE
IT
ES
NL
RU
CS2 Small Cuff

CS2 Small cuff (HEM-CS24)
*OTUSVDUJPOTGPSVTF Instruction Manual for Small Cuff
Thank you for purchasing the OMRON Small Cuff.
Arm circumference for this cuff is 17 to 22 centi-
meters. OMRON Small Cuff can be connected to
various OMRON Blood Pressure Monitors. Please
refer to the original instruction manual of your Blood
Pressure Monitor.
Please check your present product as to which plug
you must use. Note that two plugs are extremely
similar, connect the correct air plug to the air tube.
Using the wrong plug may cause air leakage and
incorrect readings.
Applying the Arm Cuff
1.Put your left arm through the cuff loop.
Note: If the cuff is not assembled, pass the end
of the cuff furthest from the tubing through
the metal D-ring to form a loop. The smooth
cloth should be on the inside of the cuff loop.
2.Position the arm correctly.
1)The air tube should run down the inside of your
forearm and be in line with your middle finger.
2)The bottom of the cuff should be approximately
1 to 2 cm above your elbow.
3)Apply the cuff to your upper arm so that the
marker (arrow under tube) is centered on the
middle of your inner arm and points down the
inside of the arm.
2
Pile side material
Sewn hook material
D-ring
1 – 2 cm
Green Mark Cuff
Air Plug (connects to Air Jack)
Air Tube
Pile side material
Sewn hook material
D-ring
1 – 2 cm
Please read this instruction manual thoroughly before using the unit.
Please keep for future reference.

3
)JOUT
.BJOUFOBODF
Taking measurements on the right arm
Apply the cuff so that the air tube is at the side of
your elbow.
t #FDBSFGVMOPUUPSFTUZPVSBSNPOUIFBJSUVCFPS
otherwise restrict the flow of air to the cuff.
t 5IFDVGGTIPVMECFUPDNBCPWFUIFFMCPX
3.When the cuff is positioned correctly, close the
fabric fastener FIRMLY.
t %POPUQMBDFUIFDVGGPWFSUIJDLDMPUIFTBOEEPOPU
roll up your sleeve if it is too tight.
t "MJHOUIFDVGGXJUIUIFIFJHIUPGZPVSIFBSUCSFBTU
height). If necessary use a pillow or cushion.
t 4UBJOTPOUIFDVGGDBOCFDBSFGVMMZSFNPWFEVTJOHB
moist cloth and soapy water.
Do not wash the cuff or make it wet!
t %POPUGPMEUIFDVGGPSBJSUVCFUPHFUIFSUPPUJHIUMZ
and do not crease them.
t %POPUTUPSFUIFDVGGJOUIFGPMMPXJOHTJUVBUJPOT
- If the cuff is wet.
- Locations exposed to extreme temperatures, hu-
midity, direct sunlight, dust or corrosive vapours.
- Locations exposed to vibrations, shocks or where
it will be at an angle.
This cuff fulfils the previsions of EC directive 93/42/EEC (Medical Device Directive).
Manufacturer OMRON HEALTHCARE Co., Ltd.
53, Kunotsubo, Terado-cho, Muko, KYOTO,
617-0002 JAPAN
EU-representative OMRON HEALTHCARE EUROPE B.V.
Scorpius 33, 2132 LR Hoofddorp, THE NETHERLANDS
www.omron-healthcare.com
Production facility
OMRON DALIAN Co., Ltd.
No. 3, Song Jiang Road,
Economic and Technical Development Zone,
Dalian 116600, China
Subsidiaries
OMRON HEALTHCARE UK LTD.
Opal Drive, Fox Milne, Milton Keynes, MK15 0DG, UK
www.omron-healthcare.co.uk
OMRON MEDIZINTECHNIK HANDELSGESELLSCHAFT mbH
Gottlieb-Daimler-Strasse 10, 68165 Mannheim, GERMANY
www.omron-healthcare.de
OMRON SANTÉ FRANCE SAS
14, rue de Lisbonne, 93561 Rosny-sous-Bois Cedex, FRANCE
www.omron-healthcare.fr
Made in China
EN
Right hand measurement
This OMRON product is produced under the strict quality system of OMRON Healthcare Co. Ltd., Japan.
