1Xpectia
Performance in touch with simplicity
Xpectia
• True real colour system
• Intelligent and high resolution
cameras
• Touch screen for easy operation
• Customization –
open & programmable
• Industry grade PC platform
Basic Configuration
Controllers
Proc'Item
rade
igh
G
H
Our lineup includestop-of-the-line modelsdesigned for high-speed processing of itemsrequiring outstanding problem-
solving capability as well as modelswith standard functions.
Controller integrated with LCD
Box-type Controller
FZ3 featuresaset of "High Grade" processing items
that solvesinspection/measurement challenges
requiring difficult setting and many man-hours. Youcan
find solutionsto seemingly impossible problemsby
combining our hardware units(such as the 5 million-
pixel camera, small cameraand high-speed CPU) and
60 processing itemsin various ways.
Cutting-edge Image Processing
High Grade Processing Items
Optimum performance for each application
Panorama+
• Halation cut+
• Stripe Removal Filter+
• Shape search+
• Labeling+
• Calibration+
• 2DC+
• Barcode+
CameraImage input HDR+ Trapezoidal Correction+

2Vision Sensor
Top-of-the-line
High Grade, High Speed Controllers
With the industry's fastest CPU, the controllers promptly pro-
cesse cutting-edge, high grade processing items.Not only a
2 million-pixel camera but also a 5 million-pixel-camera can
also be connected the controllers.
Fastest in the industry
High speed controllers
High-resolution 5 million-pixel-cameras can be connected to
the controllers with the industry's fastest CPU. They are ideal
for high speed processing of standard inspection items.
High problem solvingcapability
High grade controllers
These standard controllers feature our cutting-edge High
Grade algorithm. They allow flexible problem solving capabil-
ity and high speed processing at the same time.
Featuringall important basic functions
Standard controllers
They cover all standard functions and processing items. Their
performance is more than adequate.
Controller
integrated
with LCD
Two-camera controllers FZ3-H700 (NPN)
FZ3-H705 (PNP)
Four-camera controllers FZ3-H700-10 (NPN)
FZ3-H705-10 (PNP)
Box-type
Controller
Two-camera controllers FZ3-H750 (NPN)
FZ3-H755 (PNP)
Four-camera controllers FZ3-H750-10 (NPN)
FZ3-H755-10 (PNP)
Controller
integrated
with LCD
Two-camera controllers FZ3-700 (NPN)
FZ3-705(PNP)
Four-camera controllers FZ3-700-10(NPN)
FZ3-705-10(PNP)
Box-type
Controller
Two-camera controllers FZ3-750(NPN)
FZ3-755(PNP)
Four-camera controllers FZ3-750-10(NPN)
FZ3-755-10(PNP)
RG
B
Proc'Item
rade
igh
G
H
CPU
The Industry's
Fastest
RG
B
CPU
The Industry's
Fastest
Controller
integrated
with LCD
Two-camera controllers FZ3-H300(NPN)
FZ3-H305(PNP)
Four-camera controllers FZ3-H300-10(NPN)
FZ3-H305-10(PNP)
Box-type
Controller
Two-camera controllers FZ3-H350 (NPN)
FZ3-H355(PNP)
Four-camera controllers FZ3-H350-10(NPN)
FZ3-H355-10(PNP)
Controller
integrated
with LCD
Two-camera controllers FZ3-300(NPN)
FZ3-305(PNP)
Four-camera controllers FZ3-300-10(NPN)
FZ3-305-10(PNP)
Box-type
Controller
Two-camera controllers FZ3-350(NPN)
FZ3-355(PNP)
Four-camera controllers FZ3-350-10(NPN)
FZ3-355-10(PNP)
RG
B
Proc'Item
rade
igh
G
H
RG
B

3Xpectia
Cameras and Accessories
Peripheral devices
Digital cameras Small digital cameras
5 million-pixel 2 million-pixel 300,000-pixel 300,000-pixel pen type300,000-pixel flat type
Color
FZ-SC5M
Color
FZ-SC2M
Color
FZ-SC Color
FZ-SFC
Color
FZ-SPC
Black & White
FZ-S5M
Black & White
FZ-S2M
Black & White
FZ-S
Black & White
FZ-SF
Black & White
FZ-SP
Intelligent camera Autofocus camera Cable extension unit Strobe controller
Intelligent camera diffusion plate
FZ-SLC15 FZ-SZC15
FZ-SLC100 FZ-SZC100
Cable extension unit
FZ-VSJ
FZ-SLC15-DL
FZ-SLC-100-DL
Narrow field of vision Narrow field of vision
Wide field of vision Wide field of vision
Narrow field of vision
Wide field of vision
Strobe controller
designed specifically for
FZ Series
3Z4S-LT MLEK-C100E1TS2
Manufactured by MORITEX Corporation
Camera CablesLenses
CameraCables
FZ-VS
Bend resistant cameracables
FZ-VSB
High-resolution,
low-distortion lenses
FZ-LEH Series
Right-angle cameracable
FZ-VSL
Long-distance cameracable
FZ-VS2
Long-distance right-angle cameracable
FZ-VSL2
CCTV lens
3Z4S-LE Series
Small lens
FZ-LES Series
LCD monitor
FZ-M08
Monitor cable
FZ-VM
Parallel cable
FZ-VP
USB memory
FZ-MEM1G
VESA attachment
FZ-VESA
Desktop controller stand
FZ-DS

4Vision Sensor
Ordering Information
FZ3Series
Item Descriptions Model Remarks
Controllers
High grade,
high speed
controllers
Controller integrated
with LCD
Two-camera
controllers
NPN FZ3-H700 With touch pen
PNP FZ3-H705
Four-camera
controllers
NPN FZ3-H700-10
PNP FZ3-H705-10
Box-type Controller Two-camera
controllers
NPN FZ3-H750 ---
PNP FZ3-H755
Four-camera
controllers
NPN FZ3-H750-10
PNP FZ3-H755-10
High grade
controllers
Controller integrated
with LCD
Two-camera
controllers
NPN FZ3-H300 With touch pen
PNP FZ3-H305
Four-camera
controllers
NPN FZ3-H300-10
PNP FZ3-H305-10
Box-type Controller Two-camera
controllers
NPN FZ3-H350 ---
PNP FZ3-H355
Four-camera
controllers
NPN FZ3-H350-10
PNP FZ3-H355-10
High speed
controllers
Controller integrated
with LCD
Two-camera
controllers
NPN FZ3-700 With touch pen
PNP FZ3-705
Four-camera
controllers
NPN FZ3-700-10
PNP FZ3-705-10
Box-type Controller Two-camera
controllers
NPN FZ3-750 ---
PNP FZ3-755
Four-camera
controllers
NPN FZ3-750-10
PNP FZ3-755-10
Standard con-
trollers
Controller integrated
with LCD
Two-camera
controllers
NPN FZ3-300 With touch pen
PNP FZ3-305
Four-camera
controllers
NPN FZ3-300-10
PNP FZ3-305-10
Box-type Controller Two-camera
controllers
NPN FZ3-350 ---
PNP FZ3-355
Four-camera
controllers
NPN FZ3-350-10
PNP FZ3-355-10
Cameras
Intelligent
cameras
Wide field of vision Color FZ-SLC100 Camera + Zoom, Autofocus Lens + Intelligent Lighting
Narrow field of vision Color FZ-SLC15
Autofocus
cameras
Wide field of vision Color FZ-SZC100 Camera + Zoom, Autofocus Lens
Narrow field of vision Color FZ-SZC15
Digital camer-
as
300,000 Pixels Monochrome FZ-SLens required
Color FZ-SC
2 million pixels Monochrome FZ-S2M
Color FZ-SC2M
5 million pixels Monochrome FZ-S5M
Color FZ-SC5M
Small digital
cameras
300,000-pixel
flat type
Monochrome FZ-SFCCTVlensrequired
Color FZ-SFC
300,000-pixel
pen type
Monochrome FZ-SP
Color FZ-SPC
Cameras, peripheral devices
Intelligent camera diffusion plate Wide field of vision FZ-SLC100-DL ---
Narrow field of vision FZ-SLC15-DL ---
CCTV Lenses 3Z4S-LE Series ---
Extension Tubes
Low-distortion Lenses FZ-LEH5/LEH8/LEH12/LEH16/LEH25/
LEH35/LEH50/LEH75/LEH100
Low distortion lens for 2-million pixel cameras and 5 mil-
lion-pixel cameras
Lenses for small camera FZ-LES3/LES6/LES16/LES30 Lens for 300,000-pixel small cameras
Extension Tubes for small camera FZ-LESR Extension Tubes for 300,000-pixel small cameras
Cables
Camera Cable FZ-VSCable length: 2 m, 5 m, or 10 m *1
Bend resistant Camera Cables FZ-VSB Cable length: 2 m, 5 m, or 10 m *2
Right-angle Camera Cable *3FZ-VSL Cable length: 2 m, 5 m, or 10 m *1
Long-distance camera cable FZ-VS2 Cable length: 15 m *4
Long-distance right-angle camera cable FZ-VSL2 Cable length: 15 m *4
Cable extension unit FZ-VSJ Up to two Extension Units and three Cables can be con-
nected.(Maximum cable length: 45 m *5)
Monitor cable FZ-VM Cable length: 2 m or 5 m
Parallel cable FZ-VP Cable length: 2 m or 5 m
Peripheral
devices
LCD monitor FZ-M08For Box-type Controllers
USB memory 1GB FZ-MEM1G Capacity: 1 GB
VESA attachment FZ-VESA For installing the LCD integrated-type controller
Desktop controller stand FZ-DSFor installing the LCD integrated-type controller
Mouse --- Recommended Products (Optical Mouse)
• Microsoft Corporation: Compact Optical Mouse, U81
Series

5Xpectia
Camera connection
Cameras/cables connection
External Lighting 3Z4S-LT Series ---
Strobe Controller (for FZ Series Vision Sensors) Manufactured by MORITEX Corporation
3Z4S-LT MLEK-C100E1TS2
Required to control external lighting from a Controller
Adapter for the strobe controller designed specifically for the 5 mil-
lion-pixel camera
Manufactured by MORITEX Corporation
3Z4S-LT LBK-003
Required to mount a strobe controller on a 5 million-pixel
camera
*1. The 10-m cable cannot be used for the intelligent camera, autofocus camera and 5 million-pixel camera.
*2. The 10-m cable cannot be used for the intelligent camera, autofocus camera 2 million-pixel camera and 5 million-pixel camera.
*3. This Cable has an L-shaped connector on the Camera end.
*4. The 15-m cable cannot be used for the intelligent camera, autofocus camera and 5 million-pixel camera.
*5. The maximum cable length depends on the Camera being connected, and the model and length of the Cable being used.For further information, please refer to
the "Cameras/cables connection" table in page 5.
Type of
camera
Model Resolution Standard controllers
(FZ3-3, FZ3-3-10)
High grade controllers
(FZ3-H3, FZ3-H3-10)
High speed controllers
(FZ3-7, FZ3-7 -10)
High grade, high speed controllers
(FZ3-H7,FZ3-H7 -10)
Intelligent
cameras
FZ-SLC100 300,000 Pixels OOO O
FZ-SLC15 300,000 Pixels OOO O
Autofocus
cameras
FZ-SZC100 300,000 Pixels OOO O
FZ-SZC15 300,000 Pixels OOO O
Digital cam-
eras
FZ-SC300,000 Pixels OOO O
FZ-S 300,000 Pixels OOO O
FZ-SC2M 2 million pixels XXO O
FZ-S2M 2 million pixels XXO O
FZ-SC5M 5 million pixels XXO
*1
*1. When connecting 5 million-pixel cameras, up to two cameras can be connected.
O*1
FZ-S5M 5 million pixels XXO
*1 O*1
Small digital
cameras
FZ-SFC 300,000 Pixels OOO O
FZ-SF300,000 Pixels OOO O
FZ-SPC 300,000 Pixels OOO O
FZ-SP300,000 Pixels OOO O
Type of camera Model Cable
length
Intelligent cameras
Autofocus cameras
Digital cameras Small digital cameras
300,000-pixel 2 million-pixel 5 million-pixel Pen type / flat type
Camera Cables
Right-angle camera cables
FZ-VS
FZ-VSL
2m OOOOO
5m OOOOO
10m XOOXO
Bend resistant camera cables FZ-VSB2m OOOOO
5m OOOOO
10m XOXXO
Long-distance camera cable
Long-distance right-angle
camera cable
FZ-VS2
FZ-VSL2
15m
XOOXO
Item Descriptions Model Remarks

6Vision Sensor
Ratings and Specifications
Controllers
High grade, high speed controller, High speed controller
Note: Do not install the firmware for FZ2 in any High Grade High Speed or High Grade controller of the FZ3series. It will lead to the failure of the controller. For software
download, please contact your Omron representative.
High grade controllers, Standard controllers
Model NPN Output FZ3-700 FZ3-700-10 FZ3-H700 FZ3-H700-10 FZ3-750 FZ3-750-10 FZ3-H750 FZ3-H750-10
PNP Output FZ3-705 FZ3-705-10 FZ3-H705 FZ3-H705-10 FZ3-755 FZ3-755-10 FZ3-H755 FZ3-H755-10
Connected Camera Please refer to the "Camera connection" table in page 5.
No. of Cameras*1
*1. When connecting 5 million-pixel cameras, up to two cameras can be connected.
24 2 4 24 2 4
Processing
resolution
When connected to a 300,000-pixel camera 640(H)×480(V)
When connected to a 2 million-pixel camera 1600(H)×1200(V)
When connected to a 5 million-pixel camera 2448(H)×2044(V)
No. of scenes 32
Number of
logged im-
ages*2
*2. The number of logged images will vary when connecting multiple Cameras with different models.
When connect-
ed to a 300,000-
pixel camera
Connected to 1 camera Color camera: 250, Monochrome Camera: 252
Connected to 2 cameras Color camera: 125, Monochrome Camera: 126
Connected to 3cameras Color camera: 83, Monochrome Camera: 84
Connected to 4 cameras Color camera: 62, Monochrome Camera: 63
When connect-
ed to a 2 million-
pixel camera
Connected to 1 camera Color camera: 40, Monochrome Camera: 40
Connected to 2 cameras Color camera: 20, Monochrome Camera: 20
Connected to 3cameras Color camera: 13, Monochrome Camera: 13
Connected to 4 cameras Color camera: 10, Monochrome Camera: 10
When connect-
ed to a 5 million-
pixel camera
Connected to 1 camera Color camera: 11, Monochrome Camera: 11
Connected to 2 cameras Color camera: 5, Monochrome Camera: 5
Codes that can be read with FZ3< Bar Codes > JAN/EAN/UPC (including add-on codes), Code 39, Codabar (NW-7), ITF (Interleaved 2
of 5), Code 93, Code 128, GS1-128, GS1 DataBar (RSS-14 / RSS Limited / RSS Expanded)
< 2D Codes > Data Matrix (ECC200), QR Code
Operation Touch pen, mouse, etc. Mouse or similar device
Settings Create series of processing steps by editing the flowchart (Help messages provided).
Serial communications RS-232C/422A:1CH
Network communications Ethernet 100BASE-TX/10BASE-T
Parallel I/O 11 inputs (RESET, STEP, DSA, and DI 0 to 7), 26 outputs (RUN, BUSY, GATE, OR, READY, ERROR,
STGOUT 0 to 3, and DO 0 to 15)
Monitor interface Integrated Controller and LCD 12.1 inch TFT color
LCD (Resolution: XGA 1,024 × 768dots)
Analog RGB video output, 1 channel
(Resolution: XGA 1,024 × 768dots)
USB interface 4 channels (supports USB 1.1 and 2.0)
Power supply voltage 20.4 to 26.4 VDC
Current
consump-
tion*3
*3. When the strobe controller is connected to the lights, the controller uses power as much as it does when connected to the intelligent camera.
When connected to a intelligent or autofo-
cus camera
5 A max. 7.5 A max. 5 A max. 7.5 A max. 5 A max. 7.5 A max. 5 A max. 7.5 A max.
When connected to a 300,000-pixel camera 3.7 A
max.
4.9 A max. 3.7 A max. 4.9 A max. 3.7 A
max.
4.9 A max. 3.7 A max. 4.9 A max.
When connected to a 2 million-pixel camera
When connected to a 5 million-pixel camera
Ambient temperature range Operating: 0 to 45°C, 0 to 50°C *4, Storage: 20 to 65°C (with no icing or condensation)
*4. The operating mode can be switched from the Controller Menu settings.
Ambient humidity range Operating and storage: 35% to 85% (with no condensation)
Weight Approx.
3.2 kg
Approx.
3.4 kg
Approx.
3.2 kg
Approx.
3.4 kg
Approx.
1.8kg
Approx.
1.9 kg
Approx.
1.8kg
Approx.
1.9 kg
Accessories Touch pen (one, inside the front panel), Please
Read First, Instruction Manual (Setup), 6 mounting
brackets
Please Read First, Instruction Manual (Setup)
Model NPN Output FZ3-300 FZ3-300-10 FZ3-H300 FZ3-H300-10 FZ3-350 FZ3-350-10 FZ3-H350 FZ3-H350-10
PNP Output FZ3-305 FZ3-305-10 FZ3-H305 FZ3-H305-10 FZ3-355 FZ3-355-10 FZ3-H355 FZ3-H355-10
Connected Camera Please refer to the "Camera connection" table in page 5.
No. of Cameras 2 4 2 4 2 4 2 4
Processing resolution 640(H)×480(V)
No. of scenes 32
Number of
logged im-
ages*1
When connect-
ed to a 300,000-
pixel camera
Connected to 1 camera Color camera: 250, Monochrome Camera: 252
Connected to 2 cameras Color camera: 125, Monochrome Camera: 126
Connected to 3cameras Color camera: 83, Monochrome Camera: 84
Connected to 4 cameras Color camera: 62, Monochrome Camera: 63
Operation Touch pen, mouse, etc. Mouse or similar device
Settings Create series of processing steps by editing the flowchart (Help messages provided).
Serial communications RS-232C/422A:1CH

7Xpectia
System configuration
Network communications Ethernet 100BASE-TX/10BASE-T
Parallel I/O 11 inputs (RESET, STEP, DSA, and DI 0 to 7), 26 outputs
(RUN, BUSY, GATE, OR, READY, ERROR, STGOUT 0 to 3, and DO 0 to 15)
Monitor interface Integrated Controller and LCD 12.1 inch TFT color
LCD (Resolution: XGA 1,024 × 768dots)
Analog RGB video output, 1 channel
(Resolution: XGA 1,024 × 768dots)
USB interface 4 channels (supports USB 1.1 and 2.0)
Power supply voltage 20.4 to 26.4 VDC
Current consumption*2 When connected to a in-
telligent or autofocus
camera
5 A max. 7.5 A max. 5 A max. 7.5 A max. 5 A max. 7.5 A max. 5 A max. 7.5 A max.
When connected to a
300,000-pixel camera
3.7 A
max.
4.9 A max. 3.7 A max. 4.9 A max. 3.7 A
max.
4.9 A max. 3.7 A max. 4.9 A max.
Ambient temperature range Operating: 0 to 45°C, 0 to 50°C *3, Storage: 20 to 65°C (with no icing or condensation)
Ambient humidity range Operating and storage: 35% to 85% (with no condensation)
Weight Approx.
3.2 kg
Approx.
3.4 kg
Approx.
3.2 kg
Approx.
3.4 kg
Approx.
1.8kg
Approx.
1.9 kg
Approx.
1.8kg
Approx.
1.9 kg
Accessories Touch pen (one, inside the front panel), Please
Read First, Instruction Manual (Setup), 6 mounting
brackets
Please Read First, Instruction Manual (Setup)
*1. The number of logged images will vary when connecting multiple Cameras with different models.
*2. When the strobe controller is connected to the lights, the controller uses power as much as it does when connected to the intelligent camera.
*3. The operating mode can be switched from the Controller Menu settings.
Model NPN Output FZ3-300 FZ3-300-10 FZ3-H300 FZ3-H300-10 FZ3-350 FZ3-350-10 FZ3-H350 FZ3-H350-10
PNP Output FZ3-305 FZ3-305-10 FZ3-H305 FZ3-H305-10 FZ3-355 FZ3-355-10 FZ3-H355 FZ3-H355-10
Controller integrated with LCD
Cameraconnecter
USB connection
USB connection
To uch pen (accessory attached)
RGB monitor
PLC
RS-232C connected
Parallel I/O
Ethernet
Analogue RGB
PC
Mouse
Mouse
Input device Input device
Box-type Controller
Cameraconnected
USB connection
RGB monitor
PC
PLC
RS-232C connected
Parallel I/O
Ethernet
Analogue RGB
Input device
Mouse

8Vision Sensor
Cameras
Intelligent camera, autofocus camera
Digital cameras
Small digital cameras
FZ-SLC100 FZ-SLC15 FZ-SZC100 FZ-SZC15
Image elements Interline transfer reading all pixels, 1/3-inch CCD image elements
Color/Monochrome Color
Effective pixels 640(H)×480(V)
Pixel size 7.4×7.4 µm
Shutter function Electronic shutter; select shutter speeds from 1/10 to 1/50,000 s
Partial function 12 to 480 lines
Frame rate (image
read time)
80 fps(12.5 ms)
Field of vision*1
*1. The length of the visual field is the lengths along the Y axis.
13to 100 mm*2
*2. Tolerance: ±5% max.
2.9 to 14.9 mm*2 13to 100 mm*2 2.9 to 14.9 mm*2
Installation distance 70 to 190 mm*2 35 to 55 mm*2 77.5 to 197.5 mm*2 47.5 to 67.5 mm
LED class*3(lighting)
*3. Applicable standards: IEC 60825-1: 1993+ A1: 1997 + A2-2001, EN 60825-1: 1994 + A1: 2002 + A2: 2001
Class 2 ---
Ambient temperature
range
Operating: 0 to 50°C
Storage: 25 to 65°C (with no icing or condensation)
Ambient humidity
range
Operating and storage: 35% to 85% (with no condensation)
Weight Approx. 670 g Approx. 700 g Approx. 500 g
Accessories Instruction Sheet and hexagonal wrench
FZ-SFZ-SCFZ-S2M FZ-SC2M FZ-S5M FZ-SC5M
Image elements Interline transfer reading all pixels,
1/3-inch CCD image elements
Interline transfer reading all pixels,
1/1.8-inch CCD image elements
Interline transfer reading all pixels,
2/3-inch CCD image elements
Color/Monochrome Monochrome Color Monochrome Color Monochrome Color
Effective pixels 640(H)×480(V) 1600(H)×1200(V) 2448(H)×2044(V)
Pixel size 7.4×7.4 µm 4.4×4.4 µm 3.45×3.45 µm
Shutter function Electronic shutter;
select shutter speeds from 1/10 to 1/50,000 s
Electronic shutter;
select shutter speeds from 1/10 to 1/50,000 s
Electronic shutter;
select shutter speeds from 1/10 to 1/50,000 s
Partial function 12 to 480 lines 12 to 1200 lines 12 to 2044 lines
Frame rate (image
read time)
80 fps(12.5 ms) 30fps(33.3ms) 16 fps(62.5 ms)
Field of vision,
installation distance
Selecting a lens according to the field of vision and installation distance
Ambient temperature
range
Operating: 0 to 50°C
Storage: 25 to 65°C (with no icing or conden-
sation)
Operating: 0 to 40°C
Storage: 25 to 65°C (with no icing or conden-
sation)
Operating: 0 to 40°C
Storage: 25 to 65°C (with no icing or conden-
sation)
Ambient humidity
range
Operating and storage: 35% to 85% (with no condensation)
Weight Approx.55 g Approx. 76 g Approx.140 g
Accessories Instruction manual
FZ-SFFZ-SFC FZ-SPFZ-SPC
Image elements Interline transfer reading all pixels, 1/3-inch CCD image elements
Color/Monochrome Monochrome Color Monochrome Color
Effective pixels 640(H)×480(V)
Pixel size 7.4×7.4 µm
Shutter function Electronic shutter; select shutter speeds from 1/10 to 1/50,000 s
Partial function 12 to 480 lines
Frame rate
(image read time)
80 fps(12.5 ms)
Field of vision, instal-
lation distance
Selecting a lens according to the field of vision and installation distance
Ambient temperature
range
Operating: 0 to 50°C (camera amp)
0 to 45°C (camera head)
Storage: 25 to 65°C (with no icing or condensation)
Operating: 0 to 50°C (camera amp)
0 to 45°C (camera head)
Storage: 25 to 65°C (with no icing or condensation)
Ambient humidity
range
Operating and storage: 35% to 85% (with no condensation) Operating and storage: 35% to 85% (with no condensation)
Weight Approx.150 g Approx.150 g
Accessories Instruction manual, installation bracket, Four mounting brackets(M2) Instruction manual

9Xpectia
LCD Monitor, cable
LCD Monitor
Camera cables
Monitor cable
Cable extension unit
Long-distance camera cables
Parallel cable
FZ-M08
Size 8.4 inches
Type Liquid crystal color TFT
Resolution 1,024×768dots
Input signal Analog RGB video input, 1 channel
Power supply voltage 21.6 to 26.4 VDC
Current consumption Approx. 0.7 A max.
Ambient temperature
range
Operating: 0 to 50°C
Storage: 25 to 65°C (with no icing or condensation)
Ambient humidity range Operating and storage: 35% to 85%
(with no condensation)
Weight Approx. 1.2 kg
Accessories Instruction Sheet and 4 mounting brackets
Item FZ-VS(2m) FZ-VSB(2m) FZ-VSL(2m)
Shock resistiveness (du-
rability)
10 to 150 Hz single amplitude 0.15 mm 3direc-
tions, 8strokes, 4 times
Ambient temperature
range
Operation and storage: 0 to +65°C
(with no icing or condensation)
Ambient humidity range Operation and storage: 40 to 70%RH
(with no condensation)
Ambient atmosphere No corrosive gases
Material Cable sheath, connector: PVC
Minimum bending radius 69 mm 81mm 69mm
Weight approx.170 g approx.220 g approx.170 g
Item FZ-VM
Vibration resistiveness 10 to 150 Hz single amplitude 0.15 mm 3direc-
tions, 8strokes, 4 times
Ambient temperature
range
Operation: 0 to +50°C; Storage: 20 to +65°C
(with no icing or condensation)
Ambient humidity range Operation and storage: 35 to 85%RH
(with no condensation)
Ambient atmosphere No corrosive gases
Material Cable sheath: heat-resistant PVC Connector: PVC
Minimum bending radius 75 mm
Weight approx.170 g
FZ-VSJ
Power supply voltage*1
*1. A power supply must be connected to the Strobe Controller and Camera
when connecting a FZ-SLC100/SLC15/SZC100/SZC15 and using a Strobe
Controller (3Z4S-LT MLEK-C100E1TS2.)
11.5 to 13.5 VDC
Current consumption*2
*2. The current consumption is when every Camera and Strobe Controller is
connected to a power supply.
1.5 A max.
Ambient temperature
range
Operating: 0 to 50°C
Storage: 25 to 65°C (with no icing or condensation)
Ambient humidity range Operating and storage: 35% to 85%
(with no condensation)
Maximum Units connect-
able
2 Units per Camera
Weight Approx. 240 g
Accessories Instruction Sheet and 4 mounting screws
Item FZ-VS2 (15 m) FZ-VSL2(15 m)
Shock resistiveness (du-
rability)
10 to 150 Hz single amplitude 0.15 mm 3direc-
tions, 8strokes, 4 times
Ambient temperature
range
Operation and storage: 0 to +65°C
(with no icing or condensation)
Ambient humidity range Operation and storage: 40 to 70%RH
(with no condensation)
Ambient atmosphere No corrosive gases
Material Cable sheath, connector: PVC
Minimum bending radius 93mm
Weight approx.1600 g
Item FZ-VP
Vibration resistiveness 10 to 150 Hz single amplitude 0.15 mm 3direc-
tions, 8strokes, 4 times
Ambient temperature
range
Operation: 0 to +50°C; Storage: 20 to +65°C
(with no icing or condensation)
Ambient humidity range Operation and storage: 35 to 85%RH
(with no condensation)
Ambient atmosphere No corrosive gases
Material Cable sheath: heat-resistant PVC Connector: resin
Minimum bending radius 75 mm
Weight approx.160 g

10 Vision Sensor
Lenses, tubes
High-resolution, Low-distortion lenses
CCTV Lenses
Lenses for small camera
Extension tubes
Extension tubes for small camera
Precautions
• Do not use the 0.5-mm, 1.0-mm, and 2.0-mm Extension
Tubes attached to each other. Since these Extension Tubes
are placed over the threaded section of the Lens or other
Extension Tube, the connection may loosen when more
than one 0.5-mm, 1.0-mm or 2.0-mm Extension Tube are
used together.
• Reinforcement may be required for combinations of Exten-
sion Tubes exceeding 30 mm if the Camera is subject
to vibration.
Lens model FZ-LEH5 FZ-LEH8FZ-LEH12 FZ-LEH16 FZ-LEH25 FZ-LEH35 FZ-LEH50 FZ-LEH75 FZ-LEH100
Appearance
Focal length 5 mm 8mm 12.5 mm 16 mm 25 mm 35 mm 50 mm 75 mm 100 mm
Brightness F2.8F1.4 F1.4 F1.4 F1.4 F2 F2.8F2.5 F2.8
Filter size M40.5 P0.5 M27.0 P0.5 M27.0 P0.5 M27.0 P0.5 M27.0 P0.5 M27.0 P0.5 M27.0 P0.5 M34.0 P0.5 M40.5 P0.5
Lens model 3Z4S-LE
ML-0614
3Z4S-LE
ML-0813
3Z4S-LE
ML-1214
3Z4S-LE
ML-1614
3Z4S-LE
ML-2514
3Z4S-LE
ML-3519
3Z4S-LE
ML-5018
3Z4S-LE
ML-7527
3Z4S-LE
ML-10035
Appearance
Focal length 6 mm 8mm 12 mm 16 mm 25 mm 35 mm 50 mm 75 mm 100 mm
Brightness F1.4 F1.3F1.4 F1.4 F1.4 F1.9 F1.8F2.7 F3.5
Filter size M27 P0.5 M25.5 P0.5 M27 P0.5 M27 P0.5 M27 P0.5 M27 P0.5 M30.5 P0.5 M30.5 P0.5 M30.5 P0.5
42 dia.38.7 34 dia.41.6 34 dia.37.0 33 dia.36.5 33 dia.39.5 34 dia.36.5 34 dia.55.0 36 dia.51.0 42 dia.70.0
30
30 dia.34.5
30 dia.34.5
30 dia.24.5
30 dia.24.5
30 dia.29
30 dia.37
32 dia.42.5
32 dia.
3
2 dia.43.9
Lens model FZ-LES3 FZ-LES6 FZ-LES16 FZ-LES30
Appearance
Focal length 3mm 6 mm 16 mm 30 mm
Brightness F2.0 F2.0 F3.4 F3.4
Model 3Z4S-LE-ML-EXR
Contents Set of 7 tubes (40 mm, 20 mm, 10 mm, 5 mm, 2.0 mm,
1.0 mm, and 0.5 mm)
Maximum outer diameter: 30 mm dia.
12 dia.
16.4 12 dia.19.7 12 dia.23.1 12 dia.
25.5
Model FZ-LESR
Contents Set of 3tubes (15 mm, 10 mm, and 5 mm)
Maximum outer diameter: 12 mm dia.

11Xpectia
External Dimensions (Unit: mm)
FZ2-series Controllers
Cameras
FZ3-30_/FZ3-30_-10
FZ3-70_/FZ3-70_-10
FZ3-H30_/FZ3-H30_-10
FZ3-H70_/FZ3-H70_-10
FZ3-35_/FZ3-35_-10
FZ3-75_/FZ3-75_-10
FZ3-H35_/FZ3-H35_-10
FZ3-H75_/FZ3-H75_-10
LCD-integrated type Box-type
165
90
190
8
11 126
17 80
33
(6.8)
11.5
80 17
11 126
(15.45)
(68) (68)
100
64
26
Four, 20 dia.
13
18
54
(39)
246
296
130
110
7
6
68
(7)
(6)
+
-
12.8 (28.4)10
33
(163.5)
104
20
120 120
20
120 120
308
260
The size of the 2-camera
type is83.
Four, M3 mounting holeswith
adepth of 6 mm Four, M4 mounting
holeswith adepth
of 6 mm
Four, M4 mounting holeswith a
depth of 6 mm
The 2-cameratype has only two
cameraconnectorson itsright side.
Four, M4 mounting
holeswith adepth
of 6 mm
Intelligent cameraAuto focus camera
Digital cameras
300,000-pixel camera2 million-pixel camera5 million-pixel camera
FZ-SLC100 FZ-SZC15
FZ-SZC100
100
100
2
28 (47)
37.5
27.5
68
28
101.5 40
87.4
73.2
(5.2)
53 Two, M4 mounting holeswith adepth of 8.0 mm
1/4-20UNC with adepth of 8.0 mm
7.4
10 ± 0.1 20 ± 0.1
50
50
134
40
7
73.5
45.2
59.4
66.5
25
45.2
20±0.1
46.9
10
10.5
72.2
68
93
89.5
M39X0.5
35
30
28
1/4-20UNC with adepth of 8.0 mm
95
45
90
28
106.5
(5.2)
33 78.2
92.4
2
37.5
27.5
(47)
68
58
20±0.1
1/4-20UNC with adepth of 8.0 mm
Two, M4 mounting holeswith adepth of 8.0 mm
10±0.1
40
Two, M4 mounting
holeswith adepth
of 8.0 mm
FZ-S
FZ-SC
6.5 28
28
10.5
40
12
14.5 22
46.5
12
14.5
22
24
5.5
33.5
10.5
9.5±0.1 9.5±0.1
C mount
14
Three, M2 mounting
holeswith adepth of
3.0 mm
Three, M2 mounting
holeswith adepth of
3.0 mm
Two, M4 mounting
holeswith adepth
of 5.5 mm
1/4” 20UNC with a
depth of 5.5 mm
FZ-S2M
FZ-SC2M
FZ-SLC15
29
14.5
12
53.5
47
29
14.5
10.5
12
9.5 9.5
10.5
5.5 40.5
28
28
6.5
24
C mount
Three, M2 mounting
holeswith adepth
of 3.0 mm
Three, M2 mounting
holeswith adepth of
3.0 mm
Two, M4 mounting
holeswith adepth
of 5.5 mm
Two, M4 mounting
holeswith adepth
of 5.5 mm
1/4” 20UNC
with adepth
of 5.5 mm
Two-4.3dia.
3dia.
4-4.3dia.
16pin round connector
9.2
(From ccd
surface)
9.2
(From ccd surface)
12.5dia.
Four, M1.7 mounting holes
with adepth of 1.5 mm
Eight, M1.7 mounting holes
with adepth of 1.5 mm
Two, M3 mounting holes
with adepth of 4 mm
1/4” 20UNC with adepth of 5.5 mm
(8.8dia.)
Three, M2 mounting
holeswith adepth of 3.0 mm
Three, M2 mounting
holeswith adepth of 3.0 mm
8
17
16.9
34
26
13.5
3
3.4
26
17
M10.5
3
22
12
4.5
5.5
10
3000
43
FZ-SF
FZ-SFC
Flat camera
Camerahead
Small digital cameras
Can be used for both flat cameras and pen-shaped cameras
FZ-SP
FZ-SPC
Pen-shaped camera
11.5 22
43.5
28
24
37 (6.5)
(6.5)
11.5
7.5
7.5 9.5 9.5
2.5 33.5
22
12
12
28
6.5
(8.5)
(20.7)
Cameraamplifier
9.5 16
44
12.7
7.5 20
9.6
33
11.5
3000
43
16
12
9
9
3dia.
12.5dia.
M10.5
612
16pin round connector
FZ-S5M
FZ-SC5M
44 (55)
47
13.5
11.5
25.5
6.5
3410.5
Four M3 mounting
holeswith adepth
of 5mm
1Eight M3 mounting
holeswith adepth of 5 mm
Two M4 mounting
holeswith adepth of 6mm
1/4” 20UNC with adepth of 8 mm
22
33 10.5 34
41.5
6.8
18
9.5 9.5
1”-32UN-2A
(C mount)
44
22
25
10
25

12 Vision Sensor
Cable
LCD Monitor
Lens for small camera
Camera cable extension unit
Extension tubes for small camera
CameraCable (Model FZ-VS)
Parallel Cable(Model FZ-VP) Monitor Cable(Model FZ-VM)
CameraCable
Long-distance CameraCable (Model FZ-VS2)
Long-distance Right-angle CameraCable (Model FZ-VSL2)
Bend resistant Cable (Model FZ-VSB)
Right-angle CameraCable (Model FZ-VSL)
[Note1]:cable isavailable in 2m/5m/10m.
[Note2]:Each cameracableshas polarity.
Please ensure that the name plate side of the cable isconnected to the controller.
[Note3]:cable isavailable in 15m.
[Note1]: cable isavailable in 2m/5m.
(100)
(24.4)
(33.5)
(18.2) (32)
(75)
(24.4)
(12)
(100)(30)
(10)
35
35.4
200±10
50±10
50-pin square connector
[Note1]:cable isavailable in 2m/5m.
(100)
(32)
(75)
(24.4)
(12)
29.8
15.6
33.7
30±530±5
2 to 15-pin square connector
(33.5) (32)
(12)
(75)
(18.2)
(100)
(24.4)
(24.4)
(32)
(75)
(12) (100)
(24.4)
(32)
(75) (100)
(24.4)
L[Note 1]
2 to 26-pin square connector
6.9dia.
[Note 2]
(2)
2 to 26-pin square connector
[Note 2]
L[Note 1]
8.1dia.
26-pin square connector 26-pin square connector
[Note 2]
L[Note 1]
6.9dia.
2 to 26-pin square connector
L[Note 3]
[Note 2]
9.3dia.
26-pin square connector
26-pin square connector
9.3dia.
L[Note 3]
[Note 2]
L[Note 1]
(19.2dia.)
5dia.
L[Note 1]
6.9dia.
FZ-M08
(103.5)
220
(130)
(90)
75 Four, M4
(31.5)
40
Mountable plate thickness:
1.6 to 5.0 mm
(172)
230
(85.5)
(38)
(12.5)
(129.4)
(173.4)
(185)
171
75
26
161
(6)
FZ-LES Series
LDiaphragm
adjustment knob
Diaphragm look screw(M1.4)
12dia.4
Lenses-
Model
Focal
length
Brightness Maximum
outside
diameter
Overall
length
FZ-LES3 3mm F2.0 12 dia. 16.4 mm
FZ-LES6 6mm F2.0 12 dia. 19.7 mm
FZ-LES16 16mm F3.4 12 dia. 23.1 mm
FZ-LES3030mm F3.4 12 dia. 25.5 mm
FZ-VSJ
83
65
60
Four, 3.4 dia.
3.2
3.2
14
9
9.1
27.5
4
CameraCable Connector (Controller side)
Power supply
terminal block
15
9
9.1
14.9
CameraCable Connector
(Cameraside)
POWER Indicator
93.8 4.85
4.65
FZ-LESR
Extension tubes
5 mm
35
12 dia.
M10.5
310 3 15
12 dia.
M10.5 M10.5
Extension tubes
10 mm
Extension tubes
15 mm
12 dia.

13Xpectia
Optical Chart
5 million-pixel digital camera FZ-S_5M
Two-million-pixel digital camera FZ-S_2M
30
100
1000
10000
107 100 1000
t1.5
t0
t2
t0
t5
t0
t10
t10
t10
t5
t5
t2
t1
t0
t15 t10
t5
t5 t1
t20
t2 t1
t0
t30 t25 t20 t15 t10
t5
t0
t40 t35 t30 t20
t1
t50 t45 t40 t25 t20
t5
t1
t15
t1
t1
t0.5
t0.5
t1
t2
t2
t2
t2
t0
t0
t0
t10
t10
t15
t15
t25
t30
t35
t5
Cameradistance (mm)
FZ-LEH5
FZ-LEH8
FZ-LEH12
FZ-LEH16
FZ-LEH25
FZ-LEH35
FZ-LEH50
FZ-LEH75
FZ-LEH100
The 5-mm Extension Tubes(3Z4S-LE ML-EXR) cannot be used with FZ-LEH25 Lenses.
Field of vision (mm)
Cameradistance (mm)
t10
t10
t10
t10
t5
t5 t2
t2
t 0.5
t1
t1
t 1.5
10 100 10005
100
1000
10000
30
t0
t0
t0
t0
t0
t35
t2
t40
t30 t25 t20 t15
t5
t10
t5
t 5
t0.5
t45t40
t25
t30
t15
t 1
t 2
t 1
t15
t20
t20
t1
t50
t 10
The 5-mm Extension Tubes(3Z4S-LE ML-EXR) cannot be used with FZ-LEH25 Lenses.
t 5
t2
t0
t0
t0
t0
t1
t35 t30
t25
t20
t2
t5
t1
t10
t15
t1
Field of vision (mm)
FZ-LEH5
FZ-LEH8
FZ-LEH12
FZ-LEH16
FZ-LEH25
FZ-LEH35
FZ-LEH50
FZ-LEH75
FZ-LEH100

14 Vision Sensor
300,000-pixel digital camera FZ-S_
300,000-pixel small digital cameras FZ-SF_, FZ-SP_
Cameradistance (mm)
30
100
1000
10000
3 10 100 1000
Field of vision (mm)
ML-0614
3Z4S-LE
ML-0813
ML-1214
ML-1614
ML-2514
ML-3519
ML-5018
ML-7527
ML-10035
t0
t0
t0.5
t1.5
t0.5
t1
t1.5
t5
t0
t0.5
t5
t5
t2
t10
t10
t0
t0.5
t1
t1.5
t30
t1.5
t5
t20
t0
t0.5
t1
t2
t40
t10
t2
t20
t15
t10
t0.5
t1
t2
t35
t5
t15
t25
t40
t0
t1.5
t0.5
t1.5
t20
t30
t15
t50
t45
t5
t2
t1
t20
t25
t15
t40
t35
t45
t50
t60
t1
t35
t0
t0
t2
t10
t25
t0
t1
t30
t25
t20
t15
t10
t2
Note1: The vertical axisrepresentsWD, not installation distance.
1
t20
t20
t15
t25
t15
t10
t30
t40
t45
t50
t55
t60
t35
t10
t5
t5 t0
t0
t0
t0
10 100 1000
10
100
1000
10000
Field of vision (mm)
FZ-LES30
FZ-LES16
FZ-LES6
FZ-LES3
(mm)
WD [Note1]
197.5
(190)
0
77.5
(70)
0
Field of vision (mm)
12.6 29 52 100
Field of vision (mm)
47.5
(35)
67.5
(55)
02.9 3.1 13.8 14.9
*Be sure to check the Instruction Sheet packed with
the product before using an Intelligent Cameraor
Autofocus Camera.
*The value in parenthesesisfor the camera
installation distance when using an Intelligent
Camera.
*The value in parenthesesisfor the camera
installation distance when using an Intelligent
Camera.
Cameradistance (mm)
Cameradistance (mm)
Meaning of Optical Chart
The X axisof the optical chart showsthe field of vision (mm)(Note1),
and the Y axisof the optical chart showsthe camerainstallation
distance (mm)(Note2).
Y
X
Field of vision (mm)
Extension Tube thickness: t (mm)
Camera
Lens
Camera
distance (mm)
Field of
vision
Note1:The lengthsof the fieldsof vision given in the
optical chartsare the lengthsof the Y axis.
2:The vertical axisrepresentsWD for small
cameras.
WD
(mm)
Intelligent camera, autofocus camera
with wide field of vision
FZ-S C100
with narrow field of vision
FZ-S C15

15Xpectia

16 Vision Sensor
In the interest of product improvement, specificationsare subject to change without notice.Cat. No. Q21E-EN-02
OMRON EUROPE B.V.
Wegalaan 67-69,
NL-2132 JD, Hoofddorp,
The Netherlands
Phone: [phone]
Fax: [phone]
www.industrial.omron.eu
