Omron Xpectia-FZ3 Series User manual

Xpectia-FZ3 Series
Vision System
SHORT OPERATION MANUAL
Cat.No. Q29E-EN-01

Vision System
Xpectia-FZ3 Series
Short Operation Manual

1
TABLE OF CONTENTS
SECTION 1
Before Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
1-1 Getting Start . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
1-1-1 Basic Configuration of FZ3 Series . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
1-2 Preparing Controllers and Cameras . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
1-2-1 Preparing Controllers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
1-2-2 Adjusting Cameras . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
1-3 Software Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
SECTION 2
Basic Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
2-1 What is a Scene . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
2-1-1 Scene Examples . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
2-1-2 Switching Scenes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
2-2 Create a Scene . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
2-2-1 Property window of Processing items . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
2-3 Processing Item Guideline . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
2-3-1 Position Compensation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
2-3-2 Locating (Measurement Objects Not Inclined) . . . . . . . . . . . . . . . . . . . . . . . . . . 14
2-3-3 Locating (Measurement Objects Inclined) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
2-3-4 Internal and External Inspection. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
2-3-5 Presence Inspection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
2-3-6 Dimension Inspection/Measurement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
2-3-7 Burr Inspection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
2-3-8 Text Comparison/Inspection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
2-3-9 Defect/Contamination Inspection. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
2-3-10 Quantity Inspection/Measurement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
2-3-11 Inspection for Presence of Different Objects . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
2-3-12 Hole Position Measurement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
2-3-13 Selecting Measurement Processing Items According to the
Measurement Method and Purpose . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

2
TABLE OF CONTENTS
SECTION 3
Processing Item Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
3-1 Search . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
3-2 Flexible Search . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
3-2-1 Model Registration (Flexible Search) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
3-3 Sensitive Search . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
3-4 ECM Search . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
3-5 EC Circle Search . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
3-5-1 Measurement Parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
3-6 Classification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
3-6-1 Model Registration (Classification) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
3-7 Edge Position . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
3-8 Edge Pitch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
3-9 Scan Edge Position . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
3-9-1 Judgment Conditions (Scan Edge Position) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
3-10 Scan Edge Width . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
3-11 Color Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
3-11-1 For Monochrome Cameras: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
3-12 Gravity and Area . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
3-13 Labeling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
3-14 Label Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
3-15 Defect . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
3-15-1 Region Setting (Defect) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
3-16 Precise Defect . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
3-17 Fine Matching . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
3-18 Circle Angle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
3-19 Model Dictionary . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
3-19-1 Model Automatic Registration (Model Dictionary). . . . . . . . . . . . . . . . . . . . . . . 44
3-20 Character Inspection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
3-21 Date Verification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
SECTION 4
Support measurement functions . . . . . . . . . . . . . . . . . . . . . . 49
4-1 Image Logging . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
4-1-1 Logging Conditions (Image Logging) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
SECTION 5
Output result . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
5-1 Data Output . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
5-1-1 Settings (Data Output) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
SECTION 6
Compensate image . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
6-1 Position Compensation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .53
Revision history . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54

3
SECTION 1
Before Operation
1-1 Getting Start
This product is a vision sensor for performing image processing measurement
through a controller of objects photographed using a camera.By connecting
an external device such as a PC, measurement commands can be input and
measurement results can be output from the external device.
1-1-1 Basic Configuration of FZ3 Series
*1: The touch pen is an accessory of a controller.
*2: FZ-SC2M and FZ-S2M cannot be connected with the FZ3-3 /FZ3-H3 controllers.
*3: Lenses for small-size cameras are required for small-size 300,000-pixel cameras.
*4: FZ-SC5M and FZ-S5M can only be connected with the FZ3-70 /FZ3-H70 controllers.

4
Preparing Controllers and Cameras Section 1-2
1-2 Preparing Controllers and Cameras
1-2-1 Preparing Controllers
Please check that the controller is switched on and that the Main screen is
displayed.
The first time the program is started up, the Language Setting window is dis-
played, so select the language.
1-2-2 Adjusting Cameras
1. Tap [] of „Image mode“ in [Image display] of the Main screen Control ar-
ea, and select „Through“.
The through images captured from the camera are viewed in the Image
Display area.
Note The same operation is available by tapping [View] - [Image mode] - [Through].
2. Adjust the position of measurement objects so that they display at the cen-
ter of the monitor.
3. Adjust the focal distance of the lens.
When using an auto-focus camera or an intelligent camera, focus and the
iris can be automatically adjusted.
Note If a camera is used together with a lens, turn the focus ring of the lens to
adjust the focus.
The light intensity of an intelligent camera can be adjusted from the controller.
Important When using a small-size digital camera, check that the model and serial num-
ber of the camera head and camera amplifier match.When a camera head
and camera amplifier of different models and serial numbers are connected,
they may not operate correctly.

5
Software Overview Section 1-3
1-3 Software Overview
Application-oriented measurement can be configured by combining process-
ing items or changing the settings of processing items.

6
Software Overview Section 1-3

7
SECTION 2
Basic Operation
2-1 What is a Scene
A combination of processing items is called a „scene“ and scenes can be eas-
ily created by combining processing items that are suited to the measurement
purpose from the list of processing items provided.

8
What is a Scene Section 2-1
2-1-1 Scene Examples
2-1-2 Switching Scenes
1. Tap „Scene switch“ in the toolbar on the Main screen.
The Switch Scene window is displayed.
Note The same operation is available by tapping [Scene] menu - [Scene switch].
2. Tap [ ] to select the scene to switch.
To switch a scene group, tap [Switch], then tap [ ] in the displayed win-
dow to select the scene group to switch.
3. Tap [OK].
The scene switches.

9
Create a Scene Section 2-2
2-2 Create a Scene
In the Edit Flow window, editing buttons in the window can be used to change
the order of processing units within the scene or to delete processing units.
Specifying the position for a processing unit
and adding it ( ) ( )
Moving a processing unit ( ) ( )
Copying and pasting a processing unit ( ) ( )
Deleting a processing unit ( )
Changing the name of a processing unit ( )
Setting details of a processing unit ( )

10
Create a Scene Section 2-2
2-2-1 Property window of Processing items
This window is used for detailed setting of measurement parameters and
judgement conditions for processing items. All of Processing items have simi-
lar layout.
a) Item Tab Area
Displays the settings items for the processing unit currently being set.
Perform settings starting with the item on the left.
b) Detail Area
Set detailed items.
c) Image Display Area
Displays camera images, figures, and coordinates.
d) Zoom Browser Area
Zooms in and out from the displayed image.

11
Processing Item Guideline Section 2-3
2-3 Processing Item Guideline
Define and perform measurement with display of the results.
1. Tap [Edit flow] in Toolbar.
The Edit Flow window is displayed.
2. Select a processing item to be added from the processing item tree.
3. Tap [Append].
4. To continue to add processing units. Repeat step 3.

12
Processing Item Guideline Section 2-3
5. Either tap the icon of the processing unit to be set or tap the Set button.
The property setting window is displayed.Set detailed conditions. The dis-
played contents vary depending on the processing item.
6. Set conditions.
The displayed contents vary depending on the processing item.

13
Processing Item Guideline Section 2-3
2-3-1 Position Compensation

14
Processing Item Guideline Section 2-3
2-3-2 Locating (Measurement Objects Not Inclined)

15
Processing Item Guideline Section 2-3
2-3-3 Locating (Measurement Objects Inclined)
2-3-4 Internal and External Inspection

16
Processing Item Guideline Section 2-3
2-3-5 Presence Inspection
2-3-6 Dimension Inspection/Measurement
