ONEAC ONePlus Series Operator's manual

ONePlus UPS
ONePlus UPS User Instruction Manual
ONePlus Series UPS
User Instruction Manual
IMPORTANT SAFETY INSTRUCTIONS
SAVE THESE INSTRUCTIONS.
Please read and save these instructions. This manual contains important
instructions for the ONePlus UPS. Follow these instructions during the
unpacking, installation and maintenance of the ONePlus UPS. If you have a
problem with the unit, please refer to this manual before calling ONEAC
Technical Services.
Licenses andTrademarks
ONEAC, Virtual Kelvin Ground and MopUPS are all registered trademarks and
ONePlus is a trademark of ONEAC Corporation. All other trademarks, product
and corporate names are the property of their respective owners.
Entire contents copyright © 2004 ONEAC Corporation. All rights reserved. Reproduction in whole or
in part without permission is prohibited. All information subject to change without notice.
913-577 Rev. - 12/04
ONEAC USA
27944 North Bradley Road
Libertyville, IL 60048-9700
USA
ONEAC EUROPE
George Curl Way
Southampton, Hampshire SO18 2RY
United Kingdom
Telephone: [phone]
Toll Free: [phone]
Facsimile: [phone]
Telephone: [phone]
Facsimile: [phone]

ONePlus UPS User Instruction Manual i
Introduction .......................................................................................1
Registering Your ONEAC UPS .............................................................1
Technical Support ...............................................................................1
FCC Compliance ................................................................................2
Safety (English) ...................................................................................3
Sicherheitshinweise (Deutsch) .............................................................4
Mesures de sécurité (Français) ............................................................5
Seguridad (Español) ............................................................................6
Theory of Operation ...........................................................................7
AC Power Mode ..........................................................................7
Battery Backup Mode ...................................................................7
Output Overload Protection .........................................................8
Setup and Installation .........................................................................9
Installation ...................................................................................9
Long Term Storage ......................................................................9
Ventilation .................................................................................10
Grounding the Unit ....................................................................10
Connections ..............................................................................11
ONePlus Front Panel ...................................................................12
Power Switch .............................................................................13
Self-Test .....................................................................................14
Indicators and Alarms ................................................................14
Communications ........................................................................16
Features and Specifications ...............................................................19
Physical and Electrical Specifications ...........................................20
Specifications and Characteristics ...............................................21
Typical Runtimes ........................................................................23
Battery Considerations .....................................................................23
Battery Replacement Procedures ................................................24
Testing New Batteries ................................................................25
Battery Disposal .........................................................................26
UPS Disposal ....................................................................................26
Troubleshooting ...............................................................................27
Warranty ..........................................................................................30
Batteries ....................................................................................30
Limitations of Warranty ..............................................................30
Exclusive Remedies .....................................................................30
Return Procedure .......................................................................30

Introduction
ONePlus UPS User Instruction Manual 1
Introduction
Thank you for selecting this uninterruptible power
supply (UPS). ONEAC’s ONePlus UPS offers the
most reliable protection from the harmful effects of
electrical line disturbances for your computing and
communications equipment. ONEAC’s ISO 9001
certification represents our commitment to building
world-classproducts.We take pride in everyunitthat
leaves our manufacturing facility.
RegisteringYour
ONEAC UPS
To ensure that your ONePlus Series UPS model and
serial number are registered, complete and mail the
enclosed postage-paid warranty card or go on line at
www.oneac.com.
Technical
Support
ONEAC offers24-hourtechnical support.To contact
ONEAC Technical Services:
• North America: [phone], option 3
or toll free [phone], option 3.
• Europe: [phone]
• email: [email protected].
In North America, all calls received before 7 a.m.
and after 5 p.m. CST are forwarded to a cell phone.
Between5 p.m. and10p.m.CST, ONEACTechnical
Services Representatives will return your call within
one half hour (between 5 p.m. and 10 p.m.). Except
for emergencies, calls received between 10 p.m. and
7 a.m. CST will be returned during normal business
hours.
Please check with ONEAC Technical Services
before attempting to repair or return any ONEAC
product. If an ONEAC UPS needs repair or
replacement, ONEAC Technical Services will issue
a Return Material Authorization (RMA) number
along with instructions on how to return the UPS.

FCC Compliance
2 ONePlus UPS User Instruction Manual
FCC
Compliance
ATTENTION: Changes or modifications to this unit
not expressly approved by the party responsible or in
FCC compliance could void the user’s authority to
operate the equipment.
This equipment was tested and complies with the
limitsfor a ClassA digital device,pursuantto Part15
of FCC Rules. These limits are designed to provide
reasonable protection against harmful interference
when the UPS is operating in a commercial
environment. The UPS generates, uses, and can
radiateradiofrequencyenergy.Ifinstallationanduse
is not in accordance with the instruction manual, it
may cause harmful interference to radio
communications.
ATTENTION: Operation of this equipment in a
residential area may cause harmful radio
communications interference. The user is
responsible for correcting the interference.

Safety
ONePlus UPS User Instruction Manual 3
Safety
(English)
WARNING: This equipment services power from
more than one source. The output receptacles may
have voltage even when the unit is unplugged.
UPSs present a different safety issue than most
electrical equipment because unplugging the UPS
puts it into backup mode. Unplugging the UPS does
not remove the electrical charge. To ensure that the
UPS is off, turn the power switch OFF before
unplugging the UPS from the wall outlet.
CAUTION: Operating this equipment without
proper grounding may present a risk of electrical
shock.
Do not useAC adaptors with only two conductors to
connect the input line cord to the wall socket as this
will not connect the earth ground to the equipment.
WARNING: Dangerous voltages are present within
this unit! There are no user-serviceable parts inside.
Any repairs or modifications by the user may result
in out-of-warranty repair charges, unsafe electrical
conditions, or violation of electrical code.
Do not remove the cover.All repairs should be done
by qualified service personnel. Voltages inside the
UPS may be lethal. Internal components are
powered even when the UPS is turned OFF. Even
with the battery disconnected and the unit
unplugged, energy is stored in high voltage
capacitors and represents a severe shock hazard.

Sicherheitshinweise
4 ONePlus UPS User Instruction Manual
Sicherheitshinweise
(Deutsch)
ACHTUNG: Dieses Gerät erhält seinen Strom von
mehr als einer Quelle. Die Ausgangssteckdosen
führen unter Umständen Spannung, selbst wenn der
Stecker des Gerätes ausgesteckt wurde.
FürUSVsmüssenandere Sicherheitsmaßnahmenals
für die meisten Elektrogeräte ergriffen werden, da
die USV durch Ausstecken in den Reservebetrieb
gebracht wird. Wenn der Stecker der USV
abgezogen wird, wird die elektrische Ladung
hierdurch nicht entfernt. Um sicherzustellen, daß die
USV ausgeschaltet ist, muß der Netzschalter auf
AUS (OFF) gestellt werden, bevor der Stecker der
USV aus der Wandsteckdose gezogen wird.
VORSICHT: Durch Betreiben dieses Gerätes ohne
ordnungsgemäße Erdung können Elektroschocks
riskiert werden.
Keine Wechselstromadapter mit nur zwei
Stromleitern verwenden, um das Netzkabel an die
Wandsteckdose anzuschließen, weil das Gerät
hierdurch nicht an die Erde angeschlossen wird.
ACHTUNG: In diesem Gerät sind gefährliche
Spannungen vorhanden! Im Inneren dieses Gerätes
befinden sich keine vom Benutzer zu wartenden Teile.
Durch etwaige Reparaturen oder Modifikationen durch
den Benutzer können nicht von der Garantie gedeckte
Reparaturkosten,gefährlicheelektrischeZustände oder
Verstöße gegen Stromvorschriften entstehen.
Abdeckungnichtentfernen.AlleReparaturensollten
von qualifizierten Wartungstechnikern durchgeführt
werden. Die Spannungen im Inneren der USV
können tödliche Verletzungen zur Folge haben. Die
internen Komponenten führen Strom, selbst wenn
der Stromschalter aufAUS (OFF) steht. Auch wenn
die Batterie nicht angeschlossen und der Stecker des
Gerätes ausgesteckt ist, wird Energie in
Hochspannungskondensatoren gespeichert, und dies
bedeutet eine ernsthafte Elektroschockgefahr.

Mesures de sécurité
ONePlus UPS User Instruction Manual 5
Mesures de sécurité
(Français)
AVERTISSEMENT : Cet équipement est alimenté
par plus d'une source. Des tensions peuvent être
présentes aux prises de sortie, même lorsque l'unité
est débranchée.
Le problème de sécurité sur l'UPS diffère de celui de
la plupart des équipements électriques, car lorsqu'il
est débranché, il se met en mode de réserve. Son
débranchement n'élimine pas la charge électrique.
Pour s'assurer que l'UPS est hors tension, mettre
l'interrupteurd'alimentation surARRÊT(OFF) avant
de débrancher l'UPS de la prise murale.
ATTENTION : Si cet équipement fonctionne sans
être correctement mis à la terre, un risque de choc
électrique peut en résulter.
Ne pas utiliser d'adaptateurs CA n'ayant que deux
conducteurs pour brancher le cordon d'alimentation
dans la prise murale, car l'équipement ne serait pas
mis à la terre.
AVERTISSEMENT : Cet équipement renferme des
tensions dangereuses! Il ne contient aucune pièce
réparable par l'usager. Toutes réparations ou
modifications effectuées par l'usager peuvent
entraîner des frais de réparation non couverts par la
garantie, un danger électrique ou l'infraction à un
code électrique.
Ne pas enlever le couvercle. Confier toutes les
réparations à un personnel d'entretien qualifié. Les
tensions présentes dans l'UPS peuvent être
mortelles. Les composants internes de l'unité sont
sous tension, même lorsque l'interrupteur
d'alimentation est surARRÊT (OFF). Même lorsque
la batterie est déconnectée et l'unité débranchée, de
l'énergie est stockée dans des condensateurs à haute
tension et représente un grave risque d'électrocution.

Seguridad
6 ONePlus UPS User Instruction Manual
Seguridad
(Español)
ADVERTENCIA: Este equipo suministra
alimentación desde más de una fuente. Los
tomacorrientes de salida pueden tener voltaje aun
cuando la unidad esté desenchufada.
Las UPS (fuentes de alimentación ininterrumpibles)
cuentanconuna característica deseguridaddiferente
a la mayoría de los equipos eléctricos, ya que al
desenchufarse, quedan en el modo de reserva. Al
desenchufar una UPS no se elimina la carga
eléctrica. Para cerciorarse de que una UPS esté
apagada, gire el interruptor de alimentación a la
posición APAGADO (OFF) antes de desenchufar el
UPS del tomacorriente mural.
PRECAUCION: El hacer funcionar este equipo sin
la conexión a tierra adecuada representa un riesgo
de descargas eléctricas.
No utilice adaptadores de CA con sólo dos
conductores para conectar el cable de la línea de
entrada al enchufe mural debido a que éste no
conectará el equipo a tierra.
ADVERTENCIA: ¡Esta unidad tiene voltajes
peligrosos!. En su interior no hay piezas que pueda
reparar el usuario. Las reparaciones o
modificaciones hechas por el usuario pueden dar
como resultado cargos de reparación no cubiertos
por la garantía, y producir situaciones de riesgo
eléctrico o violación de los códigos eléctricos.
No retire la cubierta. Todas las reparaciones deben
ser realizadas por personal de servicio calificado.
Los voltajes del interior de las UPS pueden ser
mortales. Los componentes internos tienen
electricidad aun cuando el interruptor esté en la
posiciónAPAGADO(OFF). Inclusosila batería está
desconectada y la unidad desenchufada, se almacena
energía en capacitores de alto voltaje, lo cual
representa un peligro grave de descarga.

Theory of Operation
ONePlus UPS User Instruction Manual 7
Theory of
Operation
The ONePlus UPS has two operating modes:
Conditioned AC Power and Conditioned Battery
Backup.
AC Power Mode
When utility AC power is present and within the
correct voltage range, the UPS provides fully
conditioned power:
• Electronic equipment is protected from harmful
transient voltage spikes and other electrical
noise.
• UPS detector circuits continuously monitor the
utility power for blackout, low voltage, and
overvoltage events.
The buck and boost feature will compensate for a
wide range of voltage variations without depleting
the batteries.
Battery Backup
Mode
In an extreme over- or under-voltage situation, the
detector circuits determine that utilityAC power is
no longer in an appropriate voltage range. The UPS
switches to battery to supply continuous conditioned
power.
While in backup mode, detector circuits monitor the
return of utility AC power. The UPS synchronizes
with the utility’s frequency when utilityAC power is
available. The equipment is supplied continuously
with conditioned power even when running in
battery backup mode.

Theory of Operation
8 ONePlus UPS User Instruction Manual
If the battery becomes exhausted while maintaining
the load, battery backup terminates and the UPS
output turns off. A low battery warning is sounded
and transmitted via the communications port
approximately two minutes prior to termination of
battery backup. The UPS monitors the line and
provides output when utility power is restored to
normal operating range.
Fig. 1: ONePlus UPS Front View
Output Overload
Protection
During normal operation, electronic output overload
protection is active. If the output is loaded to more
than 105 percent of the UPS rating, battery power to
the UPS is not available. To reset, turn the UPS OFF,
removesome of theload,then turn theUPSON. (For
GS compliance: The power distribution system for
all models is type TN.)
Input Protector
A grossly overloaded UPS trips the rear panel circuit
breaker. The front panel display reads “c1.” To reset
the circuit breaker, push the button in.
• If the circuit breaker trips repeatedly following
reset,unplug the equipmentfromthe UPS output
receptacles and reset the circuit breaker once
again.
• If operation appears to be normal, check the total
equipment load. Add your equipment to the
output one device at a time. Check the front
panel display after each device is powered ON.
Output ON/OFF Switch
Front Panel Display

Setup and Installation
ONePlus UPS User Instruction Manual 9
• If the circuit breaker trips with nothing plugged
into the output receptacles, there may be an
internal problem with the UPS. Call ONEAC
Technical Services for assistance (refer to
page 1).
Setup and
Installation
Before shipment, this product was tested, inspected
and found to be free of mechanical and electrical
defects. Upon receipt of your UPS, carefully
examine the packing containers for any sign of
physical damage. Notify the carrier immediately if
damage is present. After inspecting, carefully
unpack the UPS. Retain the packaging materials for
reuseor disposeofthe materials properly, see Return
Procedure on page 30. Once unpacked, inspect and
test the unit for hidden damage that may have
occurred in transit. If damage is evident, contact
ONEAC Technical Services.
Installation
When selecting a location for your UPS, be sure that
the unit is near a properly wiredAC electrical outlet
and is easily accessible for all other connections (the
loads and/or optional communications cable). Leave
at least 2 inches of clearance on each side of the UPS
for proper ventilation.
CAUTION: Do not cover or install the UPS in a
confined or enclosed space.
Choose an area that is clean and dust-free. If the
environment is dusty, clean the outside of the unit
with a vacuum cleaner.
For optimal battery life, keep the UPS at an ambient
temperature of 25°C (77°F).
LongTerm
Storage
Improper long-term UPS storage may damage the
UPS battery and invalidate the battery warranty.
Unplugging a UPS from itsAC utility power source
for an extended period of time results in lost battery
charge. Restoration of charge to maximum capacity
requires 24 - 48 hours.
Inspection and
Unpacking

Setup and Installation
10 ONePlus UPS User Instruction Manual
To keep the battery enclosure fully charged and to
maximize the life of the battery, plug the UPS into an
outlet while it is in storage. If the UPS is stored
without power access, plug it into a power source for
24 hours at least once every 4 - 6 months.
ATTENTION: If the storage temperature is greater
than 30
° C (86 ° F) plug the UPS into a power source
for 24 hours every 2 to 3 months.
ATTENTION: The UPS should not be stored at
temperatures below -15
° C (+5 ° F).
Ventilation
The ventilation requirement for ONePlus is a
minimum of 2 inches (50 mm) of clearance on all
sides.
Grounding the
Unit
To eliminate shock hazard, connect the unit to a
properly grounded AC receptacle.
Before applying power, verify that the available line
voltage matches the voltage listed on the rear-panel
label.
CAUTION: Interruption of the protective grounding
conductor or disconnection of the protective earth
terminalpresentsa potential shock hazardthat could
result in personal injury and damage to the
equipment.
NOTE: When connecting the UPS, make sure that
the receptacle has power available and is not
controlled by a wall switch.

Setup and Installation
ONePlus UPS User Instruction Manual 11
Connections
Before beginning, shut down and unplug the
equipment to be protected. DO NOT make any
connections or attempt to use any of the equipment
until all the following connection instructions have
been reviewed and completed.
fig. 2: 250 and 400 VA ONePlus UPS Back Panels
fig. 3: 600 and 1000 VA ONePlus UPS Back Panels
fig. 4: Typical UPS Installation
Site Wiring Fault Indicator
Serial Communication Port
Four 5-15 Receptacles
USB Communication Port
Input Circuit Breaker
Ground Lug
USB Communication Port
Six
5-15 Receptacles
Serial Communication Port
USB Communication Port Serial Communication Port
600 VA ONePlus 1000 VA ONePlus
Eight 5-20
(for 5-15R or 5-20Rs)
Ground Lug
Input Circuit Breaker
Ground Lug
Input Circuit Breaker
Site Wiring
Fault Indicator
Site Wiring
Fault Indicator
Sit
e
Wi
r
i
ng
Fault Indicator
Connect communication cable
from Terminal to UPS (optional)

Setup and Installation
12 ONePlus UPS User Instruction Manual
1. Plug the ONePlus UPS into a properly wiredAC
electrical outlet.
2. Plug the equipment to be protected into the UPS.
CAUTION: Do not attach laser printers to the UPS.
A laser printer periodically draws significantly more
power during use and may overload the UPS.
3. Press the power switch ( ) on the front panel of
the UPS for 2 seconds to turn the unit ON.
The ONePlus performs a self-test when it is first
plugged in and turned on.After the self-test the unit
enters Normal-mode. If the alarm sounds or the UPS
alarm indicator stays on, see Table 4, “System Code
Status Chart,” on page 27.
NOTE: The batteries charge to 90% capacity in
approximately 3 to 6 hours. However, it is
recommended that the batteries charge for 6 - 24
hours after installation or after long-term storage. If
long term storage is necessary, the batteries should
be charged every 6 months by plugging the UPS into
a power outlet for 24 hours.
ONePlus Front Panel
The ONePlus front panel lights indicate status of the
unit and potential power problems. For alarm codes

Setup and Installation
ONePlus UPS User Instruction Manual 13
and indicators, see System Code Status Chart on
page 27.
fig. 5: ONePlus UPS Front Panel
Power Switch
With the UPS connected to a properly wiredAC
input power source, press the power switch ( ) on
the front panel for 2 seconds. Power is supplied to
the output connectors.
Turn OFF the UPS by pressing the power switch
( ) for 2 seconds. This turns the power to the
output connectors “OFF.” The internal charger will
continue to charge and maintain the battery as long
as the line cord is connected to a live inputAC power
source.
Power Switch
Audible Alarm/Load
Power
Battery
Fault
Temperature
Power Switch
Audible Alarm/Load
Power
Battery
Fault
Temperature
250-400 VA ONePlus UPS Front Panel
600-1000 VA ONePlus1

Setup and Installation
14 ONePlus UPS User Instruction Manual
Self-Test
The UPS performs a self-test when it is first plugged
in and turned ON.A green LED indicates normalAC
output. The three LEDs on the front panel will
indicatethe status.A blinking yellow LEDshowsthe
battery is being charged.The UPS will continuously
monitor the condition of the battery. If the battery
cannot be charged, is disconnected or takes too long
to charge, a code is represented in the LED Display.
NOTE: The System Code Status Chart on the back of
the UPS (and on page 27 of this manual) provides a
quickreferenceforinterpretationof the system status
LEDs.
To initiate a self-test, press and hold the button
for five seconds. If the UPS finds a problem, an LED
indicates where the problem is. For more about the
LED indicator lights, see Troubleshooting on page
28.
NOTE: Be sure the batteries are fully charged and
the UPS is not in Battery-mode before initiating the
self-test.
Indicators and
Alarms Battery-Mode
If the AC input power source to the UPS rises too
high, too low or fails, the UPS will switch to the
internal inverter to deliver power to the outlet
receptacles from the batteries. The LEDs will
indicate that the UPS is on battery (see System Code
Status Chart on page 27).An audible alarm will also
sound every minute.
Low Battery
When the battery voltage falls to a predetermined
level, the audible alarm will sound continuously and
the green and yellow LEDs will blink. If the UPS
continues to operate in this mode for two minutes or
more, the UPS will shutdown and remove power
from the output receptacles.
When AC power returns, the UPS will return to
on-lineoperationandthe batteries will automatically
recharge.

Setup and Installation
ONePlus UPS User Instruction Manual 15
Overload
If the load on the UPS exceeds its capacity, the red
and green LEDs will blink. The audible alarm will
sound once every minute.
If the UPS is heavily overloaded, the audible alarm
will sound continuously and will shut down in 4
seconds. The input circuit breaker may also trip. To
reset the breaker, turn off the UPS (press the UPS
power switch and hold for 5 seconds) remove the
load and push the breaker back into its housing.
Battery Replacement
If the UPS has determined that the battery is no
longer functional, the green and red LEDs will be on
continuously and the yellow LED will flash. The
audible alarm will sound every five minutes. See
Battery Considerations on page 23 for more
information regarding battery replacement.
Indicator Lights
The front of the UPS has four indicator lights: green,
yellow, and red.
fig. 6: Front Panel Indicator Lights
Green
Yellow
Red
Green
Power
Battery
Fault
Over Temperature

Setup and Installation
16 ONePlus UPS User Instruction Manual
The front panel indicator lights serve four functions:
1. To indicate status of the UPS, whether operating
normally or in fault condition. See System Code
Status Chart on page 27 for details.
2. To indicate % of load connected to the UPS.
To determine % load, the UPS must be on AC
power, not on battery. Press and hold the
button until the indication lights illuminate,
indicating load % as follows:
fig. 7: Percentage of Load or Percentage of Remaining Runtime
Indicators
3. To indicate % of remaining runtime.
To determine % of remaining runtime, the UPS
must be on battery, not on AC power. Press and
hold the button until the indication lights
illuminate. See fig. 7 for determining% of
remaining runtime.
4. To indicate over temperature.
When illuminated, the unit has exceeded safe
operating temperatures. See Table 5,
“Troubleshooting,” on page 28.
Communications
With a communications cable and MopUPS
®
Express installed, MopUPS Express can exchange
datawiththeUPS.Thispowermanagement software
polls the UPS for detailed information on the status
of the power environment. If a power emergency
occurs, the software initiates an orderly shutdown of
the equipment. The interface ports will send On
100%
75%
50%
25%

Setup and Installation
ONePlus UPS User Instruction Manual 17
Battery and Low Battery signals to the host
computer. The interface ports will also accept a
shutdown inverter signal to conserve battery life.
fig. 8: ONePlus Communications Ports
Installing MopUPS Express
To establishcommunicationsbetween theUPSand a
computer:
1. Connect the computer to the UPS
communications port using the supplied USB
communications cable.
NOTE: If a serial connection is required, contact the
factory to purchase optional serial cable (ONEAC
part number CA-2B10S-03).
NOTE: RS232 and USB communications ports
cannot be used simultaneously.
2. Insert the supplied software CD into the
computer’s CD-ROM drive.
3. Once the CD is inserted into the drive, an
installation wizard will appear. Follow the
installation instruction from the wizard.
Once MopUPS Express is installed and launched,
the User Manual can be accessed by clicking on the
Help button. If further assistance is needed, contact
ONEAC Technical Service at 800-327-8801, option
3 or email: [email protected].
Serial Port USB Port

Setup and Installation
18 ONePlus UPS User Instruction Manual
Table 1. Pin Signals for Supplied USB Cable
PIN # Signal Name Function Position
1 Low batt Low battery simulated contact; 20 mA, 30 VDC contact rating
Closes when low Out
2 RxD Receive from external device and shut down input In
3 TxD Transmit to external device Out
4 — No connection —
5 GND Signal common —
6 AC fail AC fail, simulated contact, open on fail; 20 mA, 20 VDC
contact rating Out
7 — No connection —
8 — No connection —
9 AC fail AC Fail, simulated contact, close on fail; 20 mA, 30 VDC
contact rating Out
