Onicon D-100 Operating instructions

D-100 FLOW DISPLAY
Johnson Controls Metasys®N2
Network Interface Installation and Operation Guide
11451 Belcher Road South, Largo, FL 33773 • USA • Tel [phone] • Fax [phone]
www.onicon.com • [email protected] 03-18
0659-6 / 18344
JCI Metasys N2

11451 Belcher Road South, Largo, FL 33773 • USA • Tel [phone] • Fax [phone] • [email protected]
D-100-N2 Network Interface Installation Guide 03/18 - 0659-6 / 18344 Page 2

11451 Belcher Road South, Largo, FL 33773 • USA • Tel [phone] • Fax [phone] • [email protected]
D-100-N2 Network Interface Installation Guide 03/18 - 0659-6 / 18344 Page 3
TABLE OF CONTENTS
1.0 INTRODUCTION ..................................................................................................5
1.1 PURPOSE OF THIS GUIDE .......................................................................5
1.2 TYPICAL D-100 NETWORK INTERFACE MODULE ...............................5
1.3 SPECIFICATIONS ......................................................................................5
1.4 NETWORK SIGNAL CONNECTIONS.......................................................6
1.4.1 RS485...............................................................................................6
1.4.2 Optional Network Interface with
Isolated Digital Pulse Input ............................................................7
1.5 RS485 BIASING AND TERMINATION...................................................10
1.5.1 Biasing and Termination...............................................................10
1.6 NETWORK ADDRESSING.......................................................................10
1.6.1 Changing the Device Address.......................................................10
2.0 POINT FILE (.ddl)...............................................................................................12
2.1 UNIDIRECTIONAL FLOW POINT INFORMATION...............................12
2.2 BIDIRECTIONAL FLOW POINT INFORMATION..................................12
2.3 VOLUME OR MASS RATE (AI2) ............................................................13
2.4 VOLUME OR MASS TOTAL (ADF2 & ADF4)........................................14
2.5 GENERIC ANALOG INPUT(S) (AI3 & AI4) ............................................15
2.6 AUXILIARY PULSE INPUT (ADFS) .......................................................16
2.7 SAMPLE .ddl FILE...................................................................................16
3.0 NETWORK TROUBLESHOOTING TIPS ...........................................................18
3.1 TROUBLESHOOTING .............................................................................18
APPENDIX
A-1 D-100 PROCESSOR BOARD

11451 Belcher Road South, Largo, FL 33773 • USA • Tel [phone] • Fax [phone] • [email protected]
D-100-N2 Network Interface Installation Guide 03/18 - 0659-6 / 18344 Page 4

11451 Belcher Road South, Largo, FL 33773 • USA • Tel [phone] • Fax [phone] • [email protected]
D-100-N2 Network Interface Installation Guide 03/18 - 0659-6 / 18344 Page 5
SECTION 1: INTRODUCTION
1.1 PURPOSE OF THIS GUIDE
The purpose of this guide is to provide installation and commissioning procedures and basic
installation and operating instructions for the ONICON D-100-N2 Display Module serial interface.
1.2 TYPICAL D-100 NETWORK INTERFACE MODULE
The D-100 is a totalizing display module that provides a local indication of liquid, gas or steam
ow rate and total data. It can also be provided with an optional Metasys®N2 serial interface to
communicate data to the building control network.
D-100
SCROLL RESET PROGRAM
ONICON
3864
Steam Building
Domestic Water Supply
Flow rate and total data to
Data Acquisition System or
Building Control System
120VAC or 24VAC
Input Voltage
1.3 SPECIFICATIONS
METASYS®N2 NETWORK INTERFACE
N2 RS485
Transceiver: 2-wire, half-duplex
Device address range: 1 – 255 (Default: 017)
Baud rate: 9600
Termination: none
Biasing: none

11451 Belcher Road South, Largo, FL 33773 • USA • Tel [phone] • Fax [phone] • [email protected]
D-100-N2 Network Interface Installation Guide 03/18 - 0659-6 / 18344 Page 6
1.4 NETWORK SIGNAL CONNECTIONS
1.4.1 RS485
N2 RS485, 2-wire (half-duplex) serial output connections are connected to
terminal as shown. Do not exceed 4.4 in-lb (0.5 Nm) of torque when tightening.
CAUTION
Only qualied service personnel should make connections between the D-100-N2 Display and
the user’s external equipment. ONICON assumes no responsibility for damage caused to the ex-
ternal equipment as a result of an improper installation.
!
CAUTION
Incoming and outgoing RS485 cable shield wires should be connected together, but must not be
connected to the D-100.
!
N2 (-)
N2 (+)

11451 Belcher Road South, Largo, FL 33773 • USA • Tel [phone] • Fax [phone] • [email protected]
D-100-N2 Network Interface Installation Guide 03/18 - 0659-6 / 18344 Page 7
1.4.2 Optional Network Interface With Isolated Digital Pulse Input (Di3)
The D-100-N2 Display can be provided with an auxiliary input pulse for totalizing pulse
outputs from external devices such as water or gas meters. Pulses are accumulated in an
internal register, and the totalized value is available on the network. This register can
be zeroed via the network. The maximum register value is 9,999,999. The register will
rollover to zero when this value is exceeded.
If the auxiliary pulse input option was ordered at the same time the display was ordered,
it will arrive fully congured and ready to use. If it was ordered after the display was
delivered and is being installed as a eld upgrade, it may be necessary to congure the
pulse input. The information is required to congure the input provided below and on the
following pages:
The input pulse must meet the following criteria:
1. Frequency input range, 50 Hz maximum
2. 10 millisecond minimum pulse duration
Input Pulse Denition:
In order to congure the communications card for an auxiliary input pulse, you must
rst determine which type of pulse your meter produces. The allowable types of input
pulses are described on the following pages. Based on the type of pulse, set the selector
switch (S1) on the communications circuit board (Fig. 1) to the correct setting.
Fig. 1 AUX PULSE INPUT (Di3)
CONNECTOR (T2)

11451 Belcher Road South, Largo, FL 33773 • USA • Tel [phone] • Fax [phone] • [email protected]
D-100-N2 Network Interface Installation Guide 03/18 - 0659-6 / 18344 Page 8
Powered Pulse:
This type of output refers to a pulse which has an associated voltage with it (see Fig. 2).
Set the selector switch, S1 to Pwrd Pulse. The allowable voltage range is 5-24 VDC. The
input impedance is set at the factory to be 11 KOHM via the impedance selector jumper
(J1, see Fig. 1). A lower impedance, 3 KOHM can be selected if required by the instrument
providing the pulse output. Consult the instrument manufacturer or ONICON if you are
uncertain as to the proper jumper selection.
Fig. 2
Open Collector (Sourcing):
This type of output refers to an open Collector Switch congured for a sourcing function
(see Fig. 3). Set the selector switch, S1 to SRC. The switch must be rated for at least 20 mA
at 20 VDC.
Fig. 3
Di3 In (+)
Di3 In (-)
Di3 In (+)
Di3 In (-)
ONICON
BTU Meter
ONICON
BTU Meter

11451 Belcher Road South, Largo, FL 33773 • USA • Tel [phone] • Fax [phone] • [email protected]
D-100-N2 Network Interface Installation Guide 03/18 - 0659-6 / 18344 Page 9
Open Collector Sinking or Dry Contact:
This type of output refers to an open collector switch congured in a current sinking
arrangement or a dry contact switch (see Fig. 4 and 5). Set the selector switch, S1 to Sink.
In either case, the switch must be rated for at least 20 mA at 20 VDC.
Fig. 4
Fig. 5
Di3 In (+)
Di3 In (-)
Di3 In (+)
Di3 In (-)
ONICON
BTU Meter
ONICON
BTU Meter

11451 Belcher Road South, Largo, FL 33773 • USA • Tel [phone] • Fax [phone] • [email protected]
D-100-N2 Network Interface Installation Guide 03/18 - 0659-6 / 18344 Page 10
1.5 RS485 BIASING AND TERMINATION
1.5.1 Biasing and Termination
The ONICON D-100-N2 does not provide biasing voltage or termination to the RS485
network. A 120Wtermination resistor should be used when the meter is installed at the
end of the line.
1.6 NETWORK ADDRESSING
Before the D-100 can communicate on the N2 network, the appropriate device address must
be programmed into the display. The N2 network address for ONICON D-100 displays may be
set to any address from 001 to 255. This address is set at the display. Section 1.6.1 details the
procedure for changing this address.
1.6.1 Changing the Device Address
Every ONICON D-100 is individually programmed at the factory with application specic
data provided by the customer during the ordering process, and this may include
network addressing information. If the device address information was provided, the
display will be programmed with that number. If no address is provided, ONICON
displays are programmed with a default address of 017. The address may be changed at
the D-100 using the procedure outlined in the table below.
STEP ACTION REACTION COMMENT
0Obtain a device address from the
network administrator.
The device address is a
three digit number between
001 - 255, excluding zero.
1
With the display running, open the
front panel and locate switch DEV
ADD/PROG ENAB. Press DEV ADD/
PROG ENAB and then release it.
None
The DEV ADD/PROG ENAB
is located in the lower left
corner of the processor
board. (See appendix page.)
2 Close the front panel.
3
Press the PROGRAM button. (If you do
not press the PROGRAM button, the
display will revert to the RUN mode
after 5 minutes.)
The D-100 changes to
PROGRAM mode and the
DEVICE ID page will appear
with the rst digit of the
address ashing.
The PROGRAM button is on
the front panel.
4
Successively press the SCROLL
button to increment the number to
the desired value from 0-9.
The number increments by
one each time you press the
button.
The SCROLL button is the
left most button on the front
panel.

11451 Belcher Road South, Largo, FL 33773 • USA • Tel [phone] • Fax [phone] • [email protected]
D-100-N2 Network Interface Installation Guide 03/18 - 0659-6 / 18344 Page 11
STEP ACTION REACTION COMMENT
5 Press the RESET button. The second character blinks. The RESET button is on the
front panel.
6
Successively press the SCROLL
button to increment the number to
the desired value from 0-9.
The number increments by
one each time you press the
button.
The SCROLL button is on the
front panel.
7 Press the RESET button. The third character blinks. The RESET button is on the
front panel
8
Successively press the SCROLL
button to increment the number to
the desired value from 0-9.
The number increments by
one each time you press the
button.
The SCROLL button is on the
front panel.
9Once the correct value has been
entered, press PROGRAM.
The FRONT PANEL RESET
page appears.
It is not necessary to change
anything on this page.
10 Press the PROGRAM button. The SAVE CHANGES page
appears.
The new device address
must be saved to take effect.
11 Press the SCROLL button. The N changes to Y on the
SAVE CHANGES page.
The Y must be selected in
order for the new address to
take effect.
12 Press the PROGRAM button.
The new address is saved
and the display reverts to
the RUN mode.
13 Open the front panel and locate the
RESET switch. Press to reset the D-100.
When polled, the D-100
will automatically begin
to communicate with the
network.
RESET is located along the
top of the processor board.
(See appendix page.)

11451 Belcher Road South, Largo, FL 33773 • USA • Tel [phone] • Fax [phone] • [email protected]
D-100-N2 Network Interface Installation Guide 03/18 - 0659-6 / 18344 Page 12
SECTION 2.0: POINT FILE (.ddl)
The D-100 Display operates in one of two operating modes, unidirectional or bidirectional ow. The
tables below contain point information for each operating mode.
The .ddl le contains the information that identies the device to the N2 supervisory controller. It also
species the variables that are available to be transmitted to and from the device on the network.
The tables below contain the .ddl information.
2.1 UNIDIRECTIONAL FLOW POINT INFORMATION
Point Type
& Address Engineering Units Point Description Range
AI2 Selectable (See volume/
mass rate table)
Volume or mass rate 0-999,999
AI3 User dened Generic analog input 0-999,999
AI4 User dened Generic analog input 0-999,999
ADF2 Selectable (See volume/
mass total table)
Volume or mass total 0-9,999,999
ADF5 User dened Auxiliary pulse input total (Di3) 0-9,999,999
BO2 None Reset total for ADF2 OVERRIDE Binary
Output, Object 2-ON
BO5 None Reset total for ADF5 OVERRIDE Binary
Output, Object 5-ON
2.2 BIDIRECTIONAL FLOW POINT INFORMATION
Point Type
& Address Engineering Units Point Description Range
AI2 Selectable (See volume/
mass rate table)
Volume or mass rate 0-999,999
AI3 User dened Generic analog input 0-999,999
AI4 User dened Generic analog input 0-999,999
ADF2 Selectable (See volume/
mass rate table)
Mode 1 volume or mass total 0-9,999,999
ADF4 Selectable (See volume/
mass rate table)
Mode 2 volume or mass total 0-9,999,999
ADF5 User dened Auxiliary pulse input total (Di3) 0-9,999,999
BI1 None Flow Direction Indication 0-Forward
1-Reverse
BO2 None Reset total for ADF2 OVERRIDE Binary
Output, Object 2-ON
BO4 None Reset total for ADF4 OVERRIDE Binary
Output, Object 2-ON
BO5 None Reset total for ADF5 OVERRIDE Binary
Output, Object 5-ON

11451 Belcher Road South, Largo, FL 33773 • USA • Tel [phone] • Fax [phone] • [email protected]
D-100-N2 Network Interface Installation Guide 03/18 - 0659-6 / 18344 Page 13
2.3 VOLUME OR MASS RATE (AI2)
VOLUME OR MASS RATE
D-100 LCD Display
Engineering Units D-100 Display Multiplier Point File Engineering Units Description
L/S (L/Sec) 1 LPS
L/S 10 10LPS
L/M (L/Min) 1 LPM
L/M 10 10LPM
L/M 100 100LPM
L/M 1,000 KLPM
L/M 10,000 10KLPM
L/M 100,000 100KLM
L/M 1,000,000 MEGLPM
L/H (L/Hr) 1 LPH
L/H 10 10LPH
L/H 100 100LPH
L/H 1,000 KLPH
L/H 10,000 10KLPH
L/H 100,000 100KLH
L/H 1,000,000 MEGLPH
M3H (M3/Hr) 1 CMH
M3H 10 10CMH
M3H 100 100CMH
GPM (Gal/Min) 1 GPM
GPM 10 10GPM
GPH (Gal/Hr) 1 GPH
GPH 10 10GPH
GPH 100 100GPH
GPH 1,000 KGPH
GPH 10,000 10KGPH
GPH 100,000 100KGH
GPH 1,000,000 MEGGPH
MGD (Million Gallons/Day) 1 MGD
CFS (Ft3/Sec) 1 CFS
CFS 10 10CFS
CFS 100 100CFS
CFS 1,000 KCFS
CFS 10,000 10KCFS
CFS 100,000 100KCS
CFS 1,000,000 MEGCFS

11451 Belcher Road South, Largo, FL 33773 • USA • Tel [phone] • Fax [phone] • [email protected]
D-100-N2 Network Interface Installation Guide 03/18 - 0659-6 / 18344 Page 14
CFM (Ft3/Min) 1 CFM
CFM 10 10CFM
CFM 100 100CFM
CFM 1,000 KCFM
CFM 10,000 10KCFM
CFM 100,000 100KCM
CFM 1,000,000 MEGCFM
PPH (Lb/Hr) 1 PPH
PPH 10 10PPH
PPH 100 100PPH
PPH 1,000 KPPH
PPH 10,000 10KPPH
PPH 100,000 100KPH
PPH 1,000,000 MEGPPH
KPH (Kg/Hr) 1 KPH
KPH 10 10KPH
KPH 100 100KPH
KPH 1,000 KKPH
KPH 10,000 10KKPH
KPH 100,000 100KKH
KPH 1,000,000 MEGKPH
2.4 VOLUME OR MASS TOTAL (ADF2 & ADF4)
VOLUME OR MASS TOTAL
D-100 LCD Display
Engineering Units D-100 Display Multiplier Point File Engineering Units Description
GALLON 1 GAL
GALLON 10 10GAL
GALLON 100 100GAL
GALLON 1,000 KGAL
GALLON 10,000 10KGAL
GALLON 100,000 100KGL
GALLON 1,000,000 MEGGAL
LITER 1 LTR
LITER 10 10LTR
LITER 100 100LTR
LITER 1,000 KLTR
LITER 10,000 10KLTR
LITER 100,000 100KLR
LITER 1,000,000 MEGKLTR

11451 Belcher Road South, Largo, FL 33773 • USA • Tel [phone] • Fax [phone] • [email protected]
D-100-N2 Network Interface Installation Guide 03/18 - 0659-6 / 18344 Page 15
MTR^3 (M3) 1 M3
MTR^3 10 10M3
MTR^3 100 100M3
MTR^3 1,000 KM3
MTR^3 10,000 10KM3
MTR^3 100,000 100KM3
MTR^3 1,000,000 MEGKM3
FT^3 (Ft3) 1 FT3
FT^3 10 10FT3
FT^3 100 100FT3
FT^3 1,000 KFT3
FT^3 10,000 10KFT3
FT^3 100,000 100KF3
FT^3 1,000,000 MEGFT3
LBMASS (Lb Mass) 1 LB
LBMASS 10 10LB
LBMASS 100 100LB
LBMASS 1,000 KLB
LBMASS 10,000 10KLB
LBMASS 100,000 100KLB
LBMASS 1,000,000 MEGLB
KIILOGM (Kilogram Mass) 1 KG
KIILOGM 10 10KG
KIILOGM 100 100KG
KIILOGM 1,000 KKG
KIILOGM 10,000 10KKG
KIILOGM 100,000 100KKG
KIILOGM 1,000,000 MEGKG
2.5 GENERIC ANALOG INPUT(S) (AI3 & AI4)
GENERIC ANALOG INPUT(S) AI3 & AI4
Analog Device Engineering
Units Multiplier Point File Engineering Units Description
Instantaneous Pressure
PSI 1 PSI
BAR 1 BAR
KILOPASCAL 1 KPASC
Instantaneous Temperature
DEG F 1 DEGF
DEG C 1 DEGC
Instantaneous Relative Humidity
% RH 1 RH

11451 Belcher Road South, Largo, FL 33773 • USA • Tel [phone] • Fax [phone] • [email protected]
D-100-N2 Network Interface Installation Guide 03/18 - 0659-6 / 18344 Page 16
Energy Rate
KBTU/H 1 KBTUH
KW 1 KW
TONS 1 TONS
Volume Rate
GPM (Gal/Min) 1 GPM
L/S (L/Sec) 1 LPS
M3H (M3/Hr) 1 M3H
CFS (Ft3/Sec) 1 CFS
CFM (Ft3/Min) 1 CFM
None (Not dened in N2)
Any Any Any
2.7 AUXILIARY PULSE (Di3) TOTAL (ADF5)
D-100 LCD Display
Engineering Units D-100 Display Multiplier Point File Engineering Units Description
User dened text entry 1 User dened text entry
2.6 SAMPLE .ddl FILES
Sample Unidirectional Mode .ddl File
*****************************************************************
* ONICON, D-100 Display: SERIAL NUMBER XXXXXX
* PROGRAM VERSION: DM2.022
* Metasys-N2 address: XXX
* Unidirectional Mode
*
* This DDL le is device specic to the above serial number
* This data is valid at time of creation (07/20/2005 05:27:42 PM) and can be rendered invalid due
* to eld programming changes to engineering units or multipliers.
*****************************************************************
@MODEL+
CSMODEL “ONICON”, “VND”
*
AITITLE “Analog Inputs”
ADTITLE “Analog Data Points”
BOTITLE “Binary Outputs”
*
* ANALOG INPUTS COS AVAILABLE
CSAI “AI2”,N,N,”VOLUMERT”,”GPM”
*
i
IMPORTANT NOTE
Auxiliary pulse input (Di3) totalizes pulses. The engineering units and multipliers associated
with the total are not dened by the D-100; they are dened by the pulse output of the meter
connected to the auxiliary pulse input.
E.g. a domestic water meter with a pulse output is connected to the auxiliary pulse input. The
water meter output is scaled to 100 gallons per pulse. ADF5 could be congured as: CSAD
“ADF5”,N,N,”WATERTOT”,” 100GAL”

11451 Belcher Road South, Largo, FL 33773 • USA • Tel [phone] • Fax [phone] • [email protected]
D-100-N2 Network Interface Installation Guide 03/18 - 0659-6 / 18344 Page 17
************* Unidirectional Mode Meters Only *********************
* N2 READS ADF2 FOR VOLUME or MASS TOTALS.
* NOTE UNITS MULTIPLIER
CSAD “ADF2”,N,N,”VOLUMTOT”,”10GAL”
*
*Reset Volume Totals with the command Override BO ON.
CSBO “BO2”,Y,N,”RST_VOL”,”n/a”,”reset”
*
***************** End Unidirectional Mode ****************************
Sample Bidirectional Mode .ddl File
*****************************************************************
* ONICON, D-100 Display: SERIAL NUMBER XXXXXX
* PROGRAM VERSION: DM2.022
* Metasys-N2 address: XXX
* Bidirectional Mode
*
* This DDL le is device specic to the above serial number
* This data is valid at time of creation (07/20/2005 05:27:42 PM) and can be rendered invalid due
* to eld programming changes to engineering units or multipliers.
*
*****************************************************************
@MODEL+
CSMODEL “ONICON”, “VND”
*
AITITLE “Analog Inputs”
BITITLE “Binary Inputs”
ADTITLE “Analog Data Points”
BOTITLE “Binary Outputs”
*
* ANALOG INPUTS COS AVAILABLE
CSAI “AI2”,N,N,”VOLUMERT”,”GPM”
*
* BINARY INPUT COS AVAILABLE
CSBI “BI1”,Y,Y, “MODEIND”, “N/A”
************* Unidirectional Mode Meters Only *********************
* N2 READS ADF2, ADF4 FOR VOLUME or MASS TOTALS.
* NOTE UNITS MULTIPLIER
CSAD “ADF2”,N,N,”M1VOLTOT”,”10GAL”
CSAD “ADF4”,N,N,”M2VOLTOT”,”10GAL”
*
*Reset Volume Totals with the command Override BO ON.
CSBO “BO2”,Y,N,”RST_VOL”,”n/a”,”reset”
*
***************** End Bidirectional Mode ****************************

11451 Belcher Road South, Largo, FL 33773 • USA • Tel [phone] • Fax [phone] • [email protected]
D-100-N2 Network Interface Installation Guide 03/18 - 0659-6 / 18344 Page 18
SECTION 3.0: NETWORK TROUBLESHOOTING TIPS
3.1 TROUBLESHOOTING
Reported Problem Possible Solutions
Device will not communicate
with the network controller.
• A unique address is required for each device on the
network. Duplicate addresses will cause some or all of the
devices on the network to quit working. (See section 1.6.1
of this manual for details.)
• The RS485 network cable connections are polarity
sensitive and must be connected the same way on every
device. (i.e. + to + and - to -). (See section 1.4.1 of this
manual for details.)
• Shield drain connections should be daisy chained in the
same manner as the signal cables for RS485. The shield
drain wire should be left unterminated at the end of the
cable and connected to earth only at the supervisory
controller. Shield wires must not be connected to the
RS485 connector on the D-100.
• The maximum number of devices allowed on a RS485
network segment without a repeater is 32. Adding more
than 32 devices to a single segment may reduce the
transceiver output voltage to a level that is too low to be
distinguished from background noise on the cable.
• RS485 cable impedance should be matched to a
termination resistor at the end of the cable. ONICON
boards do not have a resistor for termination. A resistor
should only be used if the display is the last device on
the network cable. (See section 1.5.1 of this manual for
details.)
Network communications are
disrupted when the device is
connected.
• The RS485 network cable connections are polarity
sensitive and must be connected the same way on every
device. (i.e. + to + and - to -). (See section 1.4.1 of this
manual for details.)
• A unique address is required for each device on the
network. Duplicate addresses will cause some or all of the
devices on the network to quit working. (See section 1.6.1
of this manual for details.)
• Shield drain connections should be daisy chained in the
same manner as the signal cables for RS485. The shield
drain wire should be left unterminated at the end of the
cable and connected to earth only at the network master
controller. Shield wires must not be connected to the
RS485 connector on the D-100.

11451 Belcher Road South, Largo, FL 33773 • USA • Tel [phone] • Fax [phone] • [email protected]
D-100-N2 Network Interface Installation Guide 03/18 - 0659-6 / 18344 Page A-1
D-100 PROCESSOR BOARD
Reset
Temp Test
Prog Mode
Enable
Device Address
Program Enable
Serial Comm
