Onkyo DS-A5 User manual

Dock for iPhone®/iPad®with AirPlay®
DS-A5
Instruction Manual
E n

2
Thank you for purchasing an Onkyo product. Please
read this manual carefully before making any
connections or using this product. By following these
instructions, you’ll get the best audio performance
and the most listening pleasure from your Onkyo
product. Keep this manual for future reference.
Important Safety Instructions
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with dry cloth.
7. Do not block any ventilation openings. Install in
accordance with the manufacturer’s instructions.
8. Do not install near any heat sources such as radiators,
heat registers, stoves, or other apparatus (including
amplifiers) that produce heat.
9. Do not defeat the safety purpose of the polarized or
grounding-type plug. A polarized plug has two blades
with one wider than the other. A grounding type plug
has two blades and a third grounding prong. The wide
blade or the third prong are provided for your safety. If
the provided plug does not fit into your outlet, consult
an electrician for replacement of the obsolete outlet.
10. Protect the power cord from being walked on or pinched
particularly at plugs, convenience receptacles, and the
point where they exit from the apparatus.
11. Only use attachments/accessories specified by the
manufacturer.
12. Unplug this apparatus during lightning storms or when
unused for long periods of time.
13. Refer all servicing to qualified service personnel.
Servicing is required when the apparatus has been
damaged in any way, such as power-supply cord or plug
WARNING:
TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT
EXPOSE THIS APPARATUS TO RAIN OR MOISTURE.
CAUTION:
TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE
COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
The lightning ash with arrowhead symbol, within an equilateral
triangle, is intended to alert the user to the presence of
uninsulated “dangerous voltage” within the product’s enclosure
that may be of sucient magnitude to constitute a risk of electric
shock to persons.
The exclamation point within an equilateral triangle is intended
to alert the user to the presence of important operating and
maintenance (servicing) instructions in the literature
accompanying the appliance.
WARNING
RISK OF ELECTRIC SHOCK
DO NOT OPEN
RISQUE DE CHOC ELECTRIQUE
NE PAS OUVRIR
AVIS

3
is damaged, liquid has been spilled or objects have fallen
into the apparatus, the apparatus has been exposed to
rain or moisture, does not operate normally, or has been
dropped.
14. Damage Requiring Service
Unplug the apparatus from the wall outlet and refer
servicing to qualified service personnel under the
following conditions:
A. When the power-supply cord or plug is damaged,
B. If liquid has been spilled, or objects have fallen into
the apparatus,
C. If the apparatus has been exposed to rain or water,
D. If the apparatus does not operate normally by
following the operating instructions. Adjust only
those controls that are covered by the operating
instructions as an improper adjustment of other
controls may result in damage and will often require
extensive work by a qualified technician to restore
the apparatus to its normal operation,
E. If the apparatus has been dropped or damaged in
any way, and
F. When the apparatus exhibits a distinct change in
performance this indicates a need for service.
Precautions
1. Recording Copyright—Unless it’s for personal use only,
recording copyrighted material is illegal without the
permission of the copyright holder.
2. Care—Occasionally you should dust the unit all over
with a soft cloth. For stubborn stains, use a soft cloth
dampened with a weak solution of mild detergent and
water. Dry the unit immediately afterwards with a clean
cloth. Don’t use abrasive cloths, thinners, alcohol, or
other chemical solvents, because they may damage the
finish or remove the panel lettering.
3. Never Touch this Unit with Wet Hands—Never handle
this unit or its power cord while your hands are wet or
damp. If water or any other liquid gets inside this unit,
have it checked by your Onkyo dealer.
4. Do not use other AC adapters, car power adapters, or
battery holders containing regular or rechargeable
batteries, as they may damage the product.

4
For U.S. models
FCC Statement
Federal Communication Commission Interference
Statement
This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate
radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful
interference to radio communications. However, there is no
guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference
to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to
try to correct the interference by one or more of the following
measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and
receiver.
• Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician
for help.
FCC Caution:
Any changes or modifications not expressly approved by the
grantee of this device could void the user’s authority to
operate the equipment.
RF exposure warning
This equipment must be installed and operated in accordance
with provided instructions and the antenna(s) used for this
transmitter must be installed to provide a separation distance
of at least 20 cm from all persons and must not be co-located
or operating in conjunction with any other antenna or
transmitter. End-users and installers must be provide with
antenna installation instructions and transmitter operating
conditions for satisfying RF exposure compliance.
Labeling requirements
This device complies with Part 15 of the FCC Rules. Operation
is subject to the following two conditions: (1) this device may
not cause harmful interference, and (2) this device must
accept any interference received, including interference that
may cause undesired operation.

5
For Canadian models
Canada, Industry Canada (IC) Notices
This Class B digital apparatus complies with Canadian ICES-
003 and RSS-210. Operation is subject to the following two
conditions: (1) this device may not cause interference, and (2)
this device must accept any interference, including
interference that may cause undesired operation of the
device.
Radio Frequency (RF) Exposure Information
The radiated output power of the Wireless Device is below the
Industry Canada (IC) radio frequency exposure limits. The
Wireless Device should be used in such a manner such that the
potential for human contact during normal operation is
minimized.
This device has also been evaluated and shown compliant
with the IC RF Exposure limits under mobile exposure
conditions. (antennas are greater than 20 cm from a person’s
body).
Canada’s REL (Radio Equipment List) can be found at the
following web address:
http://www.ic.gc.ca/app/sitt/reltel/srch/nwRdSrch.do?lang=e
ng
Additional Canadian information on RF exposure also can be
found at the following web address:
http://www.ic.gc.ca/eic/site/smt-gst.nsf/eng/sf08792.html
For European models
*Outdoor use limited to 10 mW eirp within the band 2454-
2483.5 MHz
AT
*
EE
IE
NL
ES
CH
BE
FI
IT
PL
SE
BG
FR
LV
PT
GB
CY
DE
LT
RO
IS
CZ
GR
LU
SK
LI
DK
HU
MT
SI
NO

6
sHereby, Onkyo Corporation, declares that this DS-A5 is in
compliance with the essential requirements and other
relevant provisions of Directive 1999/5/EC.
Снастоящето, Onkyo Corporation, декларира, че DS-A5
евсъответствие със съществените изисквания и
другитеприложими разпоредби на Директива
1999/5/EC.
Onkyo Corporation tímto prohlašuje, že DS-A5 splňuje
základní požadavky a všechna příslušná ustanoveni
Směrnice 1999/5/ES.
Undertegnede Onkyo Corporation erklærer herved, at
følgende udstyr DS-A5 overholder de væsentlige krav og
øvrige relevante krav i direktiv 1999/5/EF.
Hiermit erklärt Onkyo Corporation, dass sich das Gerät
DS-A5 in Übereinstimmung mit den grundlegenden
Anforderungen und den übrigen einschlägigen
Bestimmungen der Richtlinie 1999/5/EG befindet.
Käesolevaga kinnitab Onkyo Corporation seadme DS-A5
vastavust direktiivi 1999/5/EÜ põhinõuetele ja nimetatud
direktiivist tulenevatele teistele asjakohastele sätetele.
ΜΕ ΤΗΝ ΠΑΡΟΥΣΑ ΟΚΑΤΑΣΚΕΥΑΣΤΗΣ Onkyo
Corporation ∆ΗΛΩΝΕΙ ΟΤΙ DS-A5 ΣΥΜΜΟΡΦΩΝΕΤΑΙ
ΠΡΟΣ ΤΙΣ ΟΥΣΙΩ∆ΕΙΣ ΑΠΑΙΤΗΣΕΙΣ ΚΑΙ ΤΙΣ ΛΟΙΠΕΣ
ΣΧΕΤΙΚΕΣ ∆ΙΑΤΑΞΕΙΣ ΤΗΣ Ο∆ΗΓΙΑΣ 1999/5/ΕΚ
Por la presente, Onkyo Corporation, declara que este
DS-A5 cumple con los requisitos esenciales y otras
exigencias relevantes de la Directiva 1999/5/EC.
Par la présente, Onkyo Corporation déclare que l’appareil
DS-A5 est conforme aux exigences essentielles et aux
autres dispositions pertinentes de la directive 1999/5/CE.
Austria AT Netherlands NL
Belgium BE Poland PL
Bulgaria BG Portugal PT
Cyprus CY Romania RO
Czech Republic CZ Slovakia SK
Denmark DK Slovenia SI
Estonia EE Spain ES
Finland FI Sweden SE
France FR United Kingdom GB
Germany DE Iceland IS
Greece GR Liechtenstein LI
Hungary HU Norway NO
Ireland IE Switzerland CH
Italy IT
Latvia LV
Lithuania LT
Luxembourg LU
Malta MT

7
Con la presente Onkyo Corporation dichiara che questo
DS-A5 è conforme ai requisiti essenziali ed alle altre
disposizioni pertinenti stabilite dalla direttiva 1999/5/CE.
Ar šo Onkyo Corporation deklarē, ka DS-A5 atbilst Direktīvas
1999/5/EK būtiskajām prasībām un citiem ar to saistītajiem
noteikumiem.
Šiuo Onkyo Corporation deklaruoja, kad šis DS-A5 atitinka
esminius reikalavimus ir kitas 1999/5/EB Direktyvos
nuostatas.
A Onkyo Corporation ezzennel kijelenti, hogy a DS-A5
típusú beren-dezés teljesíti az alapvetőkövetelményeket
és más 1999/5/EK irányelvben meghatározott vonatkozó
rendelkezéseket.
Hierbij verklaart Onkyo Corporation dat het toestel l DS-A5
in overeenstemming is met de essentiële eisen en de
andere relevante bepalin-gen van richtlijn 1999/5/EG.
Niniejszym Onkyo Corporation deklaruje że DS-A5 jest
zgodny z zasadniczymi wymaganiami i innymi właściwymi
postanowieniami Dyrektywy 1999/5/EC.
Eu, Onkyo Corporation, declaro que o DS-A5 cumpre os
requisitos essenciais e outras provisões relevantes da
Directiva 1999/5/EC.
Prin prezenta, Onkyo Corporation, declarăcăaparatul
DS-A5 este în conformitate cu cerinţele esenţiale şi cu alte
prevederi pertinente ale Directivei 1999/5/CE.
Onkyo Corporation týmto vyhlasuje, že DS-A5 a spĺňa
základné požiadavky a všetky príslušné ustanovenia
Smernice 1999/5/ES.
Onkyo Corporation izjavlja, da je ta DS-A5 v skladu z
bistvenimi zahtevami in drugimi relevantnimi določili
direktive 1999/5/ES.
Onkyo Corporation vakuuttaa täten että DS-A5 tyyppinen
laite on direktiivin 1999/5/EY oleellisten vaatimusten ja sitä
koskevien direktiivin muiden ehtojen mukainen.
Härmed förklarar Onkyo Corporation att denna DS-A5
följer de väsentliga kraven och andra relevanta stadgar i
Direktiv 1999/5/EC.
Hér með lýsir Onkyo Corporation því yfir að varan DS-A5
er í samræmi við grunnkröfur og aðrar kröfur sem gerðar
eru í tilskipun 1999/5/EC.
Onkyo Corporation erklærer herved at denne DS-A5 er i
overensstemmelse med vesentlige krav og andre
relevante bestemmelser i direktiv 1999/5/EC.

8
Supplied Accessories
Make sure you have the following accessories.
*A Lithium Coin Battery CR2025 is loaded on the remote
control at the factory.
*In catalogs and on packaging, the letter at the end of the
product name indicates the color. Specifications and
operations are the same regardless of color.
For some models
Before use, connect the appropriate AC plug adapter
to the AC adapter.
The type of plug adapter depends on the place of
purchase.
Note
• The AC adapter supplied with the DS-A5 is
designed exclusively for use with the DS-A5. Do not
use it with any another device. Likewise, do not use
any other AC adapter with the DS-A5. Doing so may
damage the DS-A5.
• AC adapter • AV cable
• ucable • Remote controller
Detach Attach
Push

9
Using the DS-A5
With the Onkyo DS-A5, you can easily play the music
stored on your Apple iPod/iPhone/iPad through your
Onkyo amp or AV receiver and enjoy great sound,
and watch iPod/iPhone/iPad slideshows and videos
on your TV. With the supplied remote controller, you
can control your iPod/iPhone/iPad from the comfort
of your sofa.
The DS-A5 is equipped with ETHERNET port and Wi-Fi,
so that you can enjoy music from music library of iOS
devices or iTunes wirelessly by using AirPlay
developed by Apple Inc. You can also set wireless
settings by Wi-Fi network login sharing of iOS 5.
By connecting the DS-A5 and Onkyo amp or AV
receiver equipped with ujack by an ucable and an
analog audio cable, you can control playback/pause/
fast forward/fast reverse/previous/next, etc. with the
remote controller that came with your amp or AV
receiver.
■Compatible iPod/iPhone/iPad models
Made for:
• iPod touch (1st, 2nd, 3rd and 4th generation)
• iPod nano (2nd, 3rd, 4th, 5th and 6th generation)
• iPhone 4S, iPhone 4, iPhone 3GS, iPhone 3G,
iPhone
• iPad (3rd generation), iPad 2, iPad
Note
• The DS-A5 does not handle video output from
iPod nano 5th generation.
• To use AirPlay, you will need one of the following
equipments.
– iPod touch, iPhone, iPad with iOS 4.3.3 or greater.
– A personal computer with iTunes 10.2.2 (or
greater) installed.
Tip
• For optimal performance, we recommend you
always use the latest version of iOS and iTunes. For
details on AirPlay or how to obtain the latest
version for your software, please visit Apple web
site.
About DS-A5

10
AirPlay, the AirPlay logo, iPad, iPhone, iPod,
iPod classic, iPod nano, iPod shuffle, and iPod touch
are trademarks of Apple Inc., registered in the U.S.
and other countries.
“Made for iPod” , “Made for iPhone” and “Made for
iPad” mean that an electronic accessory has been
designed to connect specifically to iPod, iPhone or
iPad, respectively, and has been certified by the
developer to meet Apple performance standards.
Apple is not responsible for the operation of this
device or its compliance with safety and regulatory
standards. Please note that the use of this accessory
with iPod, iPhone, or iPad may affect wireless
performance.
The Wi-Fi CERTIFIED Logo is a certification mark of the
Wi-Fi Alliance.

11
aRemote control sensor
Receives control signals from the remote
controller.
bSTATUS LED
Lights up/blinks depending on the status of your
DS-A5. See page 29 for details.
cDock connector
Connects to your iPod/iPhone/iPad.
dWireless antenna
This is the antenna for transmitting and receiving
wireless signals.
eDC IN 5V 3A jack
This is the jack for connecting the supplied AC
adapter.
Part Names
c
a
b
d
efgh i j
k
Bottom

12
fETHERNET port
This is the port for connecting to network. You
can connect this to a router or a hub.
gAUDIO OUT L/R jacks
These are the analog audio output jacks.
hVIDEO OUT jack
This is the analog video output jack.
iujack
This is the jack for linked operation with Onkyo
amp or AV receiver equipped with ujack.
Connection only by ucable cannot perform
linked operation. Appropriate connection by
analog audio cable is also required.
jOPTICAL AUDIO OUT jack
This is the optical audio output jack.
kRI MODE switch
Sets RI MODE switch to match your amp or AV
receiver’s input display (see below).
TAPE
TAPE DOCK
DOCK
Amp or AV receiver’s
input display
RI MODE switch
See your amp or AV receiver’s instruction manual
for details on changing the input display.
To control your
iPod/iPhone/iPad with
your amp or AV
receiver’s remote
controller, select the
matching remote
control mode.
Amp or AV receiver’s
remote control mode

13
You can use the following buttons to control your
iPod/iPhone/iPad.
a8button
Sets the DS-A5 to on or standby.
bMENU button
Returns to the previous menu.
cq/wand ENTER buttons
These buttons navigate through the menus.
d7button
Selects the beginning of the current song.
Pressing this button twice selects the previous
song.
Press and hold to fast rewind.
eRepeat button
Press this button repeatedly to cycle through the
repeat modes.
f1/3button
Starts or pauses playback.
gMute button
Mutes audio output. To unmute, press this
button again or adjust the volume.
hVOL +/– buttons
Adjust the volume. The volume levels of the
DS-A5 and iPod/iPhone/iPad are linked together.
i6button
Selects the next song.
Press and hold to fast forward.
jShuffle button
Performs shuffle playback.
Note
• Actual operation may vary depending on your
iPod/iPhone/iPad model, its generation, and
firmware version.
Remote Controller
a
g
i
j
b
c
d
e
f
h

14
Some of the iPod/iPhone/iPad functions that you
can control with this remote controller can also be
controlled with the remote controller that came
with your amp or AV receiver. Refer to the
instruction manual that came with your amp or AV
receiver for details.

15
Point the supplied remote controller toward the
DS-A5’s remote control sensor, as shown.
.
Note
• The remote controller may not work reliably if the
DS-A5 is subjected to bright light, such as direct
sunlight or inverter-type fluorescent lights.
Relocate if necessary.
• If another remote controller of the same type is
used in the same room, or the DS-A5 is installed
close to equipment that uses infrared rays, the
remote controller may not work reliably.
• Don’t put anything on top of the remote controller,
such as a book or magazine, because a button may
be pressed continuously, thereby draining the
battery.
• The remote controller may not work reliably if the
DS-A5 is installed in a rack behind colored glass
doors.
• The remote controller will not work if there’s an
obstacle between it and the DS-A5’s remote
control sensor.
Aiming the Remote Controller
Remove the battery-protect tab before use.
Approx.5 m
(16 ft.)
Remote control sensor DS-A5

16
The supplied remote controller uses a CR2025 type
battery. Always use with the same type.
Note
• If the remote controller doesn’t work reliably, try
replacing the battery.
• If you intend not to use the remote controller for a
long time, remove the battery to prevent damage
from leakage or corrosion.
• An expired battery should be removed as soon as
possible to prevent damage from leakage or
corrosion.
• Misuse of lithium batteries may cause a fire or
chemical burn. Always keep out of reach of
children. Never disassemble, charge, heat above
100°C, or incinerate.
Caution
• Danger of explosion if battery is incorrectly
replaced. Replace only with the same or equivalent
type.
Replacing the Battery
1
Squeeze and pull to
release the battery
cover latch. You can
remove the battery
door with your
fingernails by using the
spaces set back in wall.
2Match the polarity on
the Lithium Cell with a
plus sign (+) on the
battery tray.
3
Slide the tray with new
battery into the battery
compartment until you
hear a click sound.
Positive (+) side

17
Connect the DS-A5 to your Onkyo amp, AV receiver,
etc. as shown below.
Connecting the DS-A5
OPTICAL
AUDIO INPUT
VIDEO
INPUT
L
R
AUDIO
INPUT
LAN
Wireless signals
Supplied ucable
White
Red
Yellow
White
Red
Yellow
Optical digital audio
cable
Onkyo amp or AV receiver
Wall outlet
Amp or AV receiver
Router
Ethernet cable
Amp, AV receiver or TV
Amp or AV receiver
AC adapter
Wi-Fi router
Supplied AV cable

18
Note
• Do not place the DS-A5 on top of a component that
gets warm or one with has air vents on top, as it
may interfere with that component’s cooling or
cause the component or DS-A5 to overheat. Place it
next to the component, use an audio rack, etc.
Caution
• Connect the supplied ucable to only ujacks.
Do not connect headphones to the ujack, as it
will damage your equipment.
■Inserting Your iPod/iPhone/iPad into the
DS-A5
Insert your iPod/iPhone/iPad into the DS-A5 as
shown below.
Now, you can enjoy music/video from
iPod/iPhone/iPad.
Note
• To prevent dock connector damage, don’t twist
your iPod/iPhone/iPad when inserting or removing
it, and be careful not to knock your
iPod/iPhone/iPad while it’s inserted.
• Don’t use your iPod/iPhone/iPad with any other
accessories, such as FM transmitters and
microphones, because they may cause a
malfunction.
1Using the supplied AV cable, connect the
DS-A5’s AUDIO OUT L/R jacks to a audio input
on your Onkyo amp or AV receiver. And if your
iPod/iPhone/iPad supports TV out, connect
the DS-A5’s VIDEO OUT jack to a composite
video input on your Onkyo amp, AV receiver
or TV.
2Using the supplied ucable, connect the
DS-A5’s ujack to an ujack on your Onkyo
amp or AV receiver.
3Connect the supplied AC adapter to the
DS-A5’s DC IN 5V 3A jack, and plug the AC
adapter into a suitable wall outlet.
iPod/iPhone/iPad

19
Follow either of the procedures below to perform
your network connection.
Wireless connection
■Using Wi-Fi Network Login Sharing
Note
• To use this function, iOS version 5 or greater is
required on the following devices.
– iPod touch (3rd and 4th generation)
– iPhone 4S, iPhone 4, iPhone 3GS
– iPad (3rd generation), iPad 2, iPad
Network Setup 1Confirm that LED lights up in green.
LED lighting in blue indicates that connection to
network has been completed.
Note
• If Ethernet cable is being connected to the
DS-A5, pull the Ethernet cable out after turning
the power of DS-A5 off, and turn the power on
again and make the settings.
2Connect the iOS device connected to Wi-Fi
router (wireless access point) to the DS-A5.
3Press the ENTER button on the remote
controller for five seconds.
Connected
Wi-Fi router

20
Wired connection (Ethernet cable)
4Press the Accept button after a confirmation
screen appears on your iOS device.
LED blinks in blue.
Wireless settings of the DS-A5 are set to the same
as that of iOS device. This allows connecting to
the same access point.
LED lights up in blue once the connection
completes.
Connected
Connect
Wi-Fi router
Wireless settings
1Connect the DS-A5 to your router with an
Ethernet cable.
2Set the DS-A5 power to on.
