Opticon OPH 1004 User manual

OPH1004
Beyond Stylish. It’s Solid.
Ideal tool for:
Retail
Healthcare
Market Research
Warehouse Management Scan Communicate

OPH1004
Beyond Stylish. It’s Solid.
DURABILITY
The housing of the OPH1004 is sealed up to IP 54 standards
holding up well in environments where water and dust resistance
are required. The scanner withstands multiple drops up to 1.5
meters (5 feet) onto concrete.
CHARGING AND COMMUNICATION
The terminal transmits data via IrDA (batch method), usually by a dedicated
cradle. These cradles are charging and communication devices especially
developed for the OPH1004.
3 types of cradles are available:
CRD1001: for Serial connection (RS232, USB)
CRD1002: for Modem connection
CRD1003: for GSM connection
CRD1001
CRD1002
CRD1003
The OPH1004 is an elegant and reliable portable terminal.
For data collection, the terminal comes with 16MB memory,
accommodating regular inventories. The elegant design with
soft side grips provides the user comfort when handling this
lightweight scanner.
FAST AND AGGRESSIVE SCANNING PERFORMANCE
SCANNING
The high performance laser scanner provides a fast and accurate scan and is immediately ready for
the next scan even when the barcodes are printed with low contrast or high density.
MEMORY
The on-board memory of 16MB provides enough space to run business applications and store collected
data without the need to worry about the storage capacity. In case of sudden battery exhaustion, the
back-up function prevents loss of data.

OPH1004
Beyond Stylish. It’s Solid.
SOFTWARE DEVELOPMENT KIT
Customized business applications can be developed using the SDK (free downloadable). Supporting
C-language, a versatile amount of functionalities can be programmed.
Applications
- Price checking
- Loss prevention
- Accident/theft reporting
- Stock management
- Merchandise control
- Order entry
Retail
Applications
- Article registration
- Price capturing
- Automated questioning
- Stimulus response survey
- Creating shopping reports
Market Research
Applications
- Intramural care efficiency
- Prescription tracking
- Laboratory surveys
- Medication dispensing
- Bedside scanning
- Pharmacy management
- Patient record tracking
Healthcare
Applications
- Shelf replenishment
- Inventory management
- Storage locations
- Bulk supplies
- Floor materials
Warehouse Management
Work on the spot and connect later to the central Point of
Sale server. With this barcode scanning and data collection
terminal all kinds of transactions as encountered on the
shop floor or anywhere else can be updated. Looking
up extended article information, expected lead times or
updating quantities can be done with ease.
Barcodes and barcode scanners bring information to care
professionals and healthcare information providers in order
to improve patient safety. Barcodes can also be a reference
in generating reports of the entire care process including
treatments, instrument checks, prescription orders
and bedside scanning. The OPH1004 provides efficient
administration and error free care.
Getting insight in your target market requires extensive
information about consumer shopping behavior. The OPH1004
enables quick key operation for automated questioning
and incentive research. Consumer panels can easily upload
questionnaires and collect information by scanning a barcode
on a product. Additionally a menu can guide the consumer
through the questions. All collected information is sent to
the central server at once where it can be used by market
researchers in order to optimize the decision making process.
Barcodes on the shelf provide reliable and fast tracking. This
simple-to-use terminal scans and stores all stock and order
details. Overstocks and wrong pickings can be minimized,
while managing additional data by keypad entry can be
maximized. All participants in the supply chain, from logistic
services and distribution centers to stock rooms, can profit
from this effective collection tool.

Basic Product Specifications
WWW . O P T I C ON. C O M
Copyright Opticon. All rights reserved. This information is subject to change without prior notice. For availability, contact your local representative.
- The Netherlands: Hoofddorp
- France: Issy Les Moulineaux
- Germany: Dietzenbach
- Italy: Castel Maggiore (BO)
- Spain: Valencia
- Sweden: Järfälla
- United Kingdom: Luton, Bedfordshire
- U.S.A.: Renton, WA
- Japan: Warabi City
- Taiwan: Taipei
- P.R.China: Shanghai
- Australia: Kariong
- Brazil: São Paulo
Opticon Sensors Europe B.V
European headquarters
Opaallaan 35
2132 XV Hoofddorp
The Netherlands
phone: [phone]
fax: [phone]
email: [email protected]
internet: www.opticon.com
SALESGUIDE_OPH1004_003
Operation
CPU: ARM7 32-bit•
O/S: Proprietary•
Software: Programmable in C-language. Software•
development kit with WinARM compiler free
downloadable
RTC: Supports year, month, day, hour, minute,•
second (leap year supported)
Memory
FlashROM: 4 MB•
NAND Flah: 64 MB•
RAM: 16 MB RAM•
Display
Size: 128 x 128 pixels•
Font size: 6x6 / 6x12 / 8x8 / 8x16 / 12x24 dots•
Operating indicators
Visual: Dual-color scanning indication (red/green)•
Non-visual: Buzzer•
Operating keys
Entry options: 23 keys total,•
12 key (alpha)numeric keypad,
2 navigation keys,
4 function keys,
3 control keys,
1 power key,
2 hot keys,
1 scan key
Communication
IrDA: Ver. 1.2, baudrate 9600 bps - 115.2 kbps, FiR•
ready
Power
Rechargeable battery: Lithium-Ion 3.7V 1100mAh•
Backup battery: Lithium (CR2032)•
Operating time: Ca. 80 hours (1 scan / 5 sec)•
Data retention time: More than 7 days•
Charging method: Separate cradle CRD1000 series•
with spare battery bay
Barcode scanner Optics
Light source: 650 nm visible laser diode•
Scan method: Vibrating mirror•
Scan rate: 100 scans/sec•
Reading pitch angle: -35 to 0º, 0 to +35º•
Reading skew angle: -50 to -8°, +8 to +50°•
Reading tilt angle: -20° to 0º, 0 to +20º•
Curvature: R>15 (EAN8), R>20 (EAN13)•
Min. PCS value: 0.45•
Depth of field: At PCS 0.9, Code 39•
70 - 450 mm / 2.76 - 17.72 in (1.0 mm / 39 mil),
50 - 320 mm / 1.97 - 12.60 in (0.5 mm / 20 mil),
50 - 200 mm / 1.97 - 7.87 in (0.25 mm / 10 mil),
55 - 120 mm / 2.17 - 4.72 in (0.15 mm / 6 mil)
Supported Symbologies
Barcode (1D): JAN/UPC/EAN incl. add on, Codabar/•
NW-7, Code 11, Code 39, Code 93, Code 128, GS1-128
(EAN-128), GS1 DataBar (RSS), IATA, Industrial 2of5,
Interleaved 2of5, ISBN-ISMN-ISSN, Matrix 2of5, MSI/
Plessey, S-Code, Telepen, Tri-Optic, UK/Plessey
Postal code: Chinese Post, Korean Postal Authority•
code
2D code: Composite Codes, MicroPDF417, PDF417•
Durability
Temperature in operation: -10 to 50 °C / 14 to 122 °F•
Temperature in storage: -10 to 60 °C / 14 to 140 °F•
Ambient light immunity: White 4,000 lx max,•
Fluorescent 4,000 lx max, Direct sun 80,000 lx max
Drop test: 1.5 m / 5 ft drop onto concrete surface•
Protection rate: IP 54•
Physical
Dimensions (w x h x d):•
55 x 136 x 23 mm / 2.17 x 5.35 x 0.91 in
Weight body: Ca. 140 g / 4.9 oz (incl. Lithium-Ion•
battery)
Case: ABS, Black•
Regulatory & Safety
Product compliance: CE, FCC, VCCI, RoHS,•
JIS-C-6802 Class 2, IEC 60825-1 Class 2, FDA CDRH
Class II
Enclosed items
Rechargeable battery•
Hand strap•
Sold separately
CRD1001 Cradle: Serial communication, charging•
CRD1002 Cradle: Modem communication, charging•
CRD1003 Cradle: GSM/GPRS communication,•
charging
