OPTO-EDU A13.1005-B User manual

To ensure the safety and obtain satisfactory performance, please study this
instruction manual thoroughly before start to use your instrument.
A13.1005
Metallurgical Microscope, Bright
Field/Dark Field
Instruction Manual

1
Contents A13.1005
User Notice „„„„„„„„„„„„„„„„„„„„„„„„ „2
1 Component Names „„„„„„„„„„„„„„„„„„„„„„ 4
2 Assembly „„„„ „„„„„„„„„„„„„„„„„„„„„ 5
2-1Assembly diagrams„„„„„„„„„„„„„„„„„„„„„ 5
2-2Assembly steps
2-2-1 install L-plate„„„„„„„„„„„„„„„„„„„„„6
2-2-2 Install supporting component„„„„ „„„„„„„„„„6
2-2-3 Install fine-coarse movement component „„„„„„„„„6
2-2-4Install connecting plate„„„„„„„„„„„„„„„ „„7
2-2-5 Install converter and objective„„„„„„„„„„„„„„7
2-2-6 Install metallographic device„„„„„„„„„„„„„„„7
2-2-7Install viewing head„„„„„„„„„„„„„„„„„„„8
3 Adjustment and Operation
3-1 Connect power source and regulate light„„„„„ „„„„„„„9
3-2 Sample placement„„„„„„„ „„„„„„„„„„„„„„„9
3-3Adjustment of coarse focus hand wheel„„„„„„„„„„„„„10
3-4Adjustment of pupil distance„„„ „„„„„„„„„„„„„„10
3-5 Visibility adjustment„„„„„„„„„„„„„„„„„„„„„10
3-6 3-gear light path switch„„„„„„„„„„„„„„„„„„„„11
3-7 Usage of color filter„„ „„„„„„„„„„„„„„„„„„„12
3-8 Usage of extension function board„„„„„„„„„„ „„„„„12
4 Components Size„„„„ „„„ „„„„„„„„„„„„„„13
5Technical Specification„„„„„„„„„„„„„„„„„„„„„14
6 Trouble Shooting„„„„„„„„„„„„„„„„„ „„„„„15

2
User A13.1005
1. Safety Symbols
symbol
explanation
Indicates that the surface becomes hot, and should not be touched with bare
hands。
Before use, carefully read the user manual .Improper use could result in
personal injury to the user and/or damage to the equipment.
Indicates that the main switch is ON.
Indicates that the main switch is OFF.
2. Safety Precautions
1. Be careful when opening box to keep objectives from dropping and damage, avoid
objectives from sweat and fingerprints.
2. Do keep the metallographic device out of direct sunlight, high temperature or humidity,
dusty and easy shaking environment. Make sure the stage is smooth, horizontal and firm
enough.
3. When moving the instrument, grip two sides of the bottom of the microscope with your
two hands.
★DO NOT hold the coarse-fine movement hand wheel or the lamp house or the
microscope may be damaged.
4. Please ensure enough cooling room for power box and keep away from power wires.
5. When running, the lamp house and nearby parts will be very hot. Please ensure 10cm
cooling room for them.
6. Make sure the instrument is earthed, to avoid lighting strike
7. For safety, be sure the main switch is in “O”(off) state and cut off the power supply
before replacing the bulb or the fuse. If you replace the bulb during use or right after use,
allow the lamp bulb and the lamp house to cool completely before touching.
8. Use the dedicate power wires。
9. When camera or TV lens is needed, make sure the adding weight is less than 2.8kg.

3
A13.1005
3. Maintenance and Care
1. All the lenses have been adjusted properly; do not dismount them by yourself please.
2. The nosepiece and coarse and fine focusing parts are so delicate that it is forbidden to
disassemble them carelessly by yourself.
3. Keep the instrument clean ,and do not pollute the optical element when wiping away the dust
on the instrument.
4. The contaminations on the prism, like fingerprints and oil smudges, could be gently wiped
with a piece of soft cloth or tissue paper, gauze which has been immersed in pure alcohol or
ether. (Note that the alcohol and ether are highly flammable, do keep them away from
the fire or potential sources of electrical sparks, and use them in a drafty room as
possible as you can.)
5. Do not attempt to use organic solvents to clean the microscope components other than the
glass components. To clean them, use a lint-free, soft cloth slightly moistened with a diluted
neutral detergent.
6. When using, if the microscope is splashed by liquid, cut off the power at once, and wipe away
the splash.
7. Do not disassemble any parts of the microscope, as this will affect the function or reduce the
performance of the microscope.
8. Place the instrument in a cool, dry position.After using the microscope, remember to cover it

4
1. Component Names A13.1005
Power box

5
2．Assembly A13.1005
2-1Assembly Diagram
The following picture shows the sequence of the modules in which the number stand for the
steps of assemble.
Before assembling, make sure that every module is free of dusts and dirt. Do not scratch
any modules or glass surfaces.
Keep the provided hexagon screwdriver as you may need it when changing modules.
○
2
○
4
○
1
○
3
○
6
○
5
○
5
○
7
○
8
○
9
○
8
○
9

6
2-2Assembly Steps A13.1005
2-2-1 Install L-plate（pic.1）
Fix the L-plate and the fine-coarse
movement component together by 4
matched bolts and washers.
2-2-2 Install supporting component
（pic.2）
Insert the supporting component to the
corresponding holes on the L-plate and
fix it on the fine-coarse movement
component by 4 matched bolts and
washers.
2-2-3 Install fine-coarse movement
component（pic.3）
Stack the fine-coarse movement
component on the column of the
platform and screw the fixing bolt ○ 1 .
If the specimen is too high, we can
stack the locking collar ○ 2 on the
column before the install of
fine-coarse movement component.
Pic.1
Pic.2
Pic.3
○
1
○
2

7
A13.1005
2-2-4 Install connecting plate（pic.4）
Put the connecting plate on the L-plate
and fix it by 4 matched bolts. Make sure the
locating surface ○ 1 is adjacent with the
surface ○ 2 of the L-plate
2-2-5 Install converter and objective
（pic.5）
1. Insert the converter to the socket on the
connecting plate by path shown in pic.5
and tighten the bolt○ 1 by a hexagon
screwdriver to fix it.
2. Screw the objectives to the holes on the
converter in sequences.
2-2-6 Install metallographic device
（pic.6）
★put the swallow tail of the metallographic
device in the corresponding holes on the
connecting plate and tighten the bolt○ 2 in
pic.5.
★If it is a bright and dark field
metallographic, we should insert the
lamp house into the back of the
metallographic device and tighten
bolt○ 1 to fix it.
Pic.4
○
1
○
2
Pic.5
Pic.6
○
1
○
2
○
1

8
A13.1005
2-2-7 Install viewing head（pic.7）
1. Put trinocular viewing head onto the
swallow-tail of the connecting-plate and
screw bolt○ 1 to fix the viewing head.
2. Insert the eyepiece to the lens cone of the
viewing head.
Pic.7
○
1

9
3. Adjustment and Operation A13.1005
3-1Connect power source and regulate
light（pic.1,pic.2）
1. Connect the air plug of halogen lamp
house with the aerial socket○
1of the
power box, plug one head of power line to
socket○
2and the other head to the power
supply. Toggle the converter switch○
3to
proper position according the power
demand of location.
2. Make sure the light adjust knob○
5in a
minimum position and toggle the main
switch○
4in the front of power box to the
“－” position. (It’s only need to plug
the adapter to the socket when using
LED house)
3. Turn the knob○
5to the MAX position to
increase the voltage and the brightness of
lamp house.
3-2 Sample placement（pic.3）
Place the sample○
1on platform○ 2.
○sample should be plat or parallel.
Besides, reflected light should not
entrance the objective otherwise the
observation will fail.
Be careful when convert objectives. The
objective may touch the sample when
converting objective after using a short
working distance objective.
Pic.1
Pic.2
Pic.3
○
1
○
2
○
4
○
5
○
1
○
3
○
2

10
A13.1005
3-3 Adjustment of coarse focus hand
wheel（pic.4）
The loose condition of coarse focus hand
wheel can be adjusted by turning the adjusting
ring○ 1 .
The coarse focus hand wheel is in a loose
state when delivered, a heavy force is needed
to rotate the hand wheel.
3-4Adjustment of pupil distance（pic.5）
The range of pupil distance is 47mm～78mm.
when observing with both eyes, hold and
rotate the prism table to adjust the pupil
distance until the left and right field of view
coincided.
3-5 Visibility adjustment（pic.6）
1. Observing with right eye, rotate the focus hand
wheel until the sample is imaged clearly
within the eyepiece.
2. Use left eye to observe, adjust the visibility
ring○ 1 until the sample is imaged clearly
within the left eyepiece.
Pic.6
○
1
Pic.4
Pic.5
○
1

11
A13.1005
3-6 3-gear light path switch（pic.7）
1. When not using cameras, totally push in the
light path switch rod and observing by
eyepiece. Use the 10×objective to focus, first
descend the focusing component and find the
image in the 10×eyepiece, then turn the fine
focusing hand wheel until clearly imaged.
Convert the objective will not touch and
damage the sample because of the par
2.
3. focalizition.
4. When using cameras, totally push in the light
path switch rod and pull it out after get a
clear image. Observing through videos.
Icons
Operation(
switch
rod)
Brightness ratio
of eyepiece and
camera
Totally
pushed in
100：0
middle
20：80
Totally
pulled out
0：100
调焦上限位
锁定手轮
Pic.7
○
1

12
A13.1005
3-7 Usage of color filter（pic.8,pic.9）
Plug needed color filter in position1
(position 2 when use LED), make sure the
filter is well settled.
Color filters
Function
Ground glass
Adjust the brightness
of the light
Green filter
Increase the contrast
when single color
observing
Yellow filter
Increase the contrast
when observing
semiconductors
Blue filter
Used in normal
observe and camera
observe
Matte filter
Smooth light
3-8 Usage of extension function
board（pic.10）
A socket to settle an extension function
board is preserved and it’s occupied by a
normal bright and dark field board when
the microscope is delivered. If you want
to use other function board, just loosen
bolt②and pull out the bright and dark
field board and then tighten bolt②after
plug the extension board in.
①
④
③
Pic.8
Pic.9
○
2
○
1
Pic.10
○
1
○
2

13
4.Main Component Size A13.1005
1. Size of the focusing components
2. Focusing component and L-plate

14
5．Technical specification A13.1005
1. Main technical specification
2. Electrical parameters
A. halogen lamp parameters：
1) Input voltage: VAC100-240V 50/60 Hz
2) Fuse: TAL250V
3) Illumination: 24V 100W
B.SLED parameters：
1) Input voltage: VAC100-240V 50/60 Hz
2) Fuse: T500mAL250V
3) Illumination: S- LED W3
Optical
systems
infinity optical system
A13.1005-B
A13.1005-BD
Viewing head
Hinge type trinocular (big
aperture),30°tilt,pupil distance 47-78mm
●
Hinge type trinocular,30°tilt,pupil distance
47-78mm
78mm
●
eyepiece
Huge FOV eyepiece EW10X/25,lens cone
Φ30
●
10×/18eyepiece
●
Objective
converter
5-hole converter（W26*1/36’）
●
5-hole converter（4/5’*1/36’）
●
Objective
Infinity bright and dark field objective 2.5
×,10×,20×,50×,100×
●
Infinity plan objective 4×,10×,20×,40
×
●
Focusing
device
Coaxial coarse and fine focusing device,
focusing accuracy 0.002mm
●
Metallograph
ic device
Bright and dark field metallographic
device
●
Bright field metallographic device
●
Illumination
24V 100W halogen lamp
●
3W SLED
●
图27
④

15
6．Trouble Shooting A13.1005
6.1 Optical system
Problem
Cause
Solution
The edge of the field
of view has shadow
or not evenly
illuminated
The nosepiece is not located in the
required position
Adjust it into the right position
The filament is not in center
Make it in center
There are stains on the lens
Clean it
Find dust and stain
in the field of view
There are stains on the lens
Clean it
There are stains on the glass
Clean it
There are stains on the lens
Clean it
Aperture diaphragm is too big
Narrow it properly
There are stains on the lens cone
glass
Clean it
Aperture diaphragm is too small
wide it properly
The converter is not located in the
required position
Adjust it into the right position
The sample is in float state
Reliably solidify it
The image moves
when focusing
Sample is floated in the surface of
platform
Place it stable
The converter is not located in the
required position
Adjust it into the right position
Brightness is not
enough
Aperture diaphragm is too small
Re-adjust it
Kohler illumination is not in the
center of view field
Adjust it into the center by
Kohler illumination center bolt
6.2 Mechanical System
Problem
Cause
Solution
The sample moves not
smoothly
Slide is not tighten reliable
Tighten it reliable
The left and right fields of
view is not coincided
The interpupillary distance
is not correct
Adjust the interpupillary distance
correctly
The eyes are uncomfortable
and tired
The diopter is not right
Adjust the diopter according your
sight
Brightness is not suitable
Adjust the voltage of the bulb

16
A13.1005
6.3 Electrical System
Problem
Cause
Solution
The lamp can’t
light
No power supply
Check the power cord, and
connect them exactly
the installation of the bulb is
wrong
Install the bulb correctly
The bulb burned out
Replace with a new bulb
The bulb burn out in
frequently
Not use the specified lamp
Use the required lamp. If it’s still
not working ,contact the repair
department
The brightness is not
enough
Not use the specified lamp
Use the required lamp
Voltage is too low
Increase the voltage
The light glimpses
The bulb is going to spoil
Change the bulb
The power cord has a poor
contact
Check the power cord, and
connect them exactly
