DS327
DLP®Projector Ultimate Big
Screen Viewing
Experience
BRIGHTNESS WHERE IT MATTERS
You can project even if there is ambient light in
the room. The SVGA resolution DS327 delivers an
impressive 2600L, ensuring that even during the day
everyone can clearly see the projected image.
COST SAVING – LONG LAMP LIFE
Reduce the number of lamp changes with lamp life
of up to 6000 hours2.
The lamp is conveniently located so that it can be
changed without removing the projector from a ceiling
mount – saving you time and money.
CLEAR, FOCUSED PROJECTION
High contrast ratio, 4000:1 for a crystal clear viewing
experience. Ensure you have your audience’s attention
during a presentation with crisp whites and ultra-rich
blacks making text and graphs easier to read. Bring
images and video alive on the big screen for a fantastic
viewing experience.
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
PROJECTION THAT LASTS
Optoma 5 year colour and imager guarantee means you
can rest assured that the image performance will not
degrade compared to other leading technologies.
Enjoy lasting projection year after year!
FUTURE PROOF TECHNOLOGY
Using the inherent speed of DLP®technology, Optoma
3D Ready projectors can output video and images
at an astonishing rate of 120Hz, allowing you to show
full screen, full colour, stereoscopic 3D from
a compatible computer.
AUDIO PERFORMANCE
Convenient audio from the built-in 2W speaker,
or connect to an external audio system with the
dedicated audio output.
5
5

DS327 SPECIFICATIONS
Native Resolution SVGA 800 x 600
Max Supported Resolution UXGA (1600 x 1200)
Display Technology Single 0.55” SVGA DC3 DMD chip DLP®Technology
by Texas Instruments
Brightness - BRIGHT mode12600 ANSI Lumens
Contrast Ratio 4000:1
Lamp Life26000/5000 (ECO/BRIGHT mode)
Noise Level 28dB (ECO mode)
Weight / Dimensions (W x D x H) 2.2 kg / 280 x 230 x 77mm
Inputs 2 x 15 Pin D-Sub VGA Component via adaptor
S-Video 4 Pin Mini Din
Composite RCA
3.5mm Audio Mini Jack
USB (remote mouse)
Control RS232 - 9 Pin D-sub
OUTPUT 15 Pin D-Sub VGA
3.5mm Audio Mini Jack
Audio 2W Speaker
Aspect Ratio 4:3 Native, 16:9 Compatible
On Screen Display 18 Languages: English, German, French, Italian, Spanish,
Portuguese, Polish, Dutch, Russian, Finnish, Swedish,
Greek, Norwegian/Danish, Hungarian, Czech, Turkish,
Arabic & Farsi
Video Compatibility PAL SECAM 576i/p, NTSC 480i/p, HD 720p/1080i/1080p
Uniformity 85%
Displayable Colours 1073.4 Million
Horizontal Scan Rate 15.3 - 91.1kHz
Vertical Scan Rate 24 - 85Hz
Projection Lens F/2.51~2.69; f=21.95~24.18mm, 1.1x Manual Zoom
Projection Distance 1.2 - 12m
Image Size 0.69 – 7.62m (27.24” to 300.04”) Diagonal 4:3
Throw Ratio 1.97 - 2.17:1 (Projection Distance:Image Width)
Keystone Correction ± 40° Vertical
Operating Conditions Operating: 5 - 40˚C, 85% Humidity (Max), 3000m Altitude
(Max)
Power Supply 100 - 240V, 50 - 60Hz
Power Consumption 233W BRIGHT mode < 0.5W Standby mode
207W ECO mode < 0.5 Standby mode
Security Security Bar, Kensington Lock Port, Password Protection
Standard Accessories AC Power Cord, VGA Cable, Full Function Remote,
Batteries x 2, Quick Start Guide, CD User Manual,
Warranty Card
RoHS Compliant
Lamp Warranty 6 months or 1000 hours - whichever comes sooner
Warranty Warranty may vary by country. Please see
www.optomaeurope.com or ask your local supplier
for details
Colour Guarantee35 Years
Imager Guarantee45 Years
3D Support 120Hz frame sequential 3D for resolutions up to 720p.
60Hz field sequential 3D for resolutions up to 480i
3D Viewing Requires Optoma DLP®Link™ ZD201 glasses
– sold separately
3D Compatibility The 3D features of Optoma projectors can only be used
with compatible 3D content from a computer.
Optoma Europe Ltd.
42 Caxton Way, Watford Business Park, Watford, Hertfordshire, UK. WD18 8QZ
www.optoma.co.uk
1Brightness and lamp lifetime will vary depending on selected projector mode, environmental conditions and usage.As is common with all lamp based projectors, brightness will decrease over the lamp lifetime. 2Typical lamp life achieved through testing.Will vary
according to operational use and environmental conditions. 3Optoma guarantees that in normal use, Optoma DLP®colour quality will be indistinguishable from when new. Exclusions: (a) Guarantee is voided if the projector is subject to damage through misuse.
(b) Guarantee may be void in industrial or commercial entertainment environments where dust or smoke is excessive (c) Guarantee will not apply if lamp brightness is below 50% due to wear or if the projector is not working due to other faults. (d) Over time worn
lamps within all projector types will show a slight colour variance. 4Optoma guarantees that in normal use, the DLP®imager will retain image quality for at least 5 years and provide consistent pixel performance. Exclusions: (a) Guarantee is voided if the projector
is subject to damage through misuse. (b) Guarantee may be void in industrial or commercial environments where dust or smoke is excessive. Copyright © 2011, Optoma Europe Ltd.All other product names and company names used herein are for identification
purposes only and may be trademarks or registered trademarks of their respective owners. Errors and omissions excepted, all specifications are subject to change without notice. DLP®, BrilliantColor™ and the DLP logo are registered trademarks
of TexasInstruments. Some images may be simulated.
DS327
DS327 Remote Control
1Power
2Enable Mouse Control
3Mouse Control
4Vertical Keystone Correction
5Volume Control
6Direct Input Source Selection
7Freeze
8AV Mute
9Page Up/Down Control
10 3D Control
DS327 Connections
11 Audio In
12 S-Video
13 VGA 1 - Component
14 RS232
15 USB (Remote Mouse)
16 Audio Out
17 Video
18 VGA 2
19 VGA Out
20 Kensington™ Lock
EASY TO USE REMOTE CONTROL
1
V1 - 13/09/11
Exceptional Connectivity /
Multiple Terminals
11 12 13
16
14 15
17 18 19 20
2
3
54
8
7
6
9
10
lens center
diagonal image size
screen width
screen height
projection distance
image offset
DS327 Projection Distance 1.2 - 12m (4:3 Aspect Ratio)
Projection Distance (m) Max Screen Width (m) Min Screen Width (m) Max. Screen Height (m) Min. Screen Height (m) Min Diagonal Image
Size (m)
Max Diagonal Image
Size (m)
Min Diagonal Image
Size (inch)
Max Diagonal Image
Size (inch) Max. Image Offset (m)
1.20
2.00
2.50
3.00
4.00
5.00
6.00
7.00
8.00
9.00
10.00
11.00
12.00
0.61
1.02
1.27
1.52
2.03
2.54
3.05
3.55
4.06
4.57
5.08
5.58
6.09
0.55
0.92
1.15
1.38
1.84
2.30
2.76
3.23
3.69
4.15
4.61
5.07
5.53
0.46
0.76
0.95
1.14
1.53
1.91
2.29
2.67
3.05
3.43
3.82
4.20
4.58
0.42
0.69
0.87
1.04
1.39
1.73
2.08
2.43
2.77
3.12
3.46
3.81
4.16
0.69
1.15
1.44
1.73
2.31
2.88
3.46
4.04
4.61
5.19
5.77
6.34
6.92
0.76
1.27
1.59
1.91
2.54
3.18
3.81
4.45
5.08
5.72
6.35
6.99
7.62
27.24
45.40
56.75
68.10
90.80
113.50
136.19
158.89
181.59
204.29
226.99
249.69
272.39
30.00
50.01
62.51
75.01
100.01
125.02
150.02
175.03
200.03
225.03
250.04
275.04
300.04
0.07
0.11
0.14
0.17
0.23
0.29
0.34
0.40
0.46
0.52
0.57
0.63
0.69
For guide purposes only
