Oransi OVHPRO201 User manual

OVHPRO201
V-hepa Pro Air Purifier
The complete air purifier

Table of Contents:
Safety Instructions 1
Control Panel and LCD Display 2
Know Your Air Purifier 4
Operating Instructions 6
Safety Instructions:
WARNING: RISK OF ELECTRICAL SHOCK
Safety precautions should always be used when operating this or
any electrical appliance.
Decrease the risk of electrocution, electric shock, injury or fire by
reading and following all of the warnings below.
To reduce the risk of electric shock, do not attempt to service the
air purifier in any way other than to replace or clean the air filter.
Read all instructions before operating the air purifier.
This product operates at 115V AC, 60Hz only.
Do not run the power cord under carpets, and do not cover with
throw rugs.
This product is not intended to filter oil or grease from air.
Always unplug the power cord from the electrical outlet when the
air purifier is not in use or when changing the filter.
Never run the air purifier unless it is fully assembled.
Do not alter the plug in any way.
Always turn the manual control knob to the off position before
unplugging the air purifier from outlet.
Do not place the cord near a heated surface.
Never operate the air purifier if the plug or cord is damaged or
appears
damaged. Only qualified service personnel should ever replace or
attempt to replace a damaged power cord.
Never use the power cord to pick up, carry, drag, pull, or lift the air
purifier. Do not pull the cord against or around sharp corners and
edges. Always remove the plug from its power outlet by holding
onto the plug itself
and pulling gently.
Never pull on the cord itself to unplug it from its power outlet.
Use care when operating the air purifier by keeping all foreign
objects, fingers, body parts, hair, loose clothing and jewelry away
from openings.
Never touch the air purifier or its plug when your hands are wet.

Control Panel and LCD Display:
Speed Setting Timer Setting ION/UV
Switch
Reset
UV
HEPA Change
or Clean
ION
ON/OFF
Switch
1.Before operating theair purifier,make sure theair filters
inside the airpurifier are notwrapped in plastic. When the
air purifier isplugged in youshould hear abeep. Press the
Power button toturn it on. If the air purifierdoes not power
on, ensure thefront cover is installed correctly. See the How
to Use section for more information.
2.The v-hepa Pro air purifier has 3 fan speeds and auto mode.
The fan speeds are represented by Roman numerals (I, II, III).
By pressing themode button youwill cycle throughthe fan
speeds and automode as follows: I II III Auto.
3. Press the Timer button to initiate the count down timer.
Pressing the timer button will cycle through the countdown timer
settings (in hours). The settings are 1 hour, 2 hours, 4 hours,6
hours, 8 hours, off.
4. When theair purifier isturned on, theUV lamp and negative
ionizer will be on and the LCD display will show movement in
the UV and ion sections. Press the Ion/UV button to turn this f
eature off. If the Ion/UV display is showing with no movement
on the LCD, it is an indication that the UV lamp requires
replacement or adjustment.
5. When the air purifier is in the Auto mode, the fan speed of the
air purifier will be automatically controlled depending upon the
reading of the API. The API shows the air quality in your room
based upon a reading from the dust sensor that is located on the
left side of the air purifier. The API will display more bars to
indicate higher particle levels. Higher readings in the API will
result in the air purifier operating at a higher fan speed.
6. Reset operation. The v-hepa Pro has a filter replacement
indicator to remind you when it is time to check and/or replace
the HEPA filter. When you see displayed beneath the
HEPA label on the LCD display it is time to check the filter. To
reset the filter replacement indicator, press the Reset button
with a paperclip or safety pin.

Functions:
4.Control key
5.LCD display
7.Built-in ionzer
Front case
9.UV lamp
1.Pre-filter+HEPA Filter
2.Carbon filter
3.Photocatalyst filter
Remote control
Control panel
Receiver
1. Washable pre-filter to capture large particles such as
dust. HEPA filter to remove microscopic particles down
to 0.3 microns in size such as fine dust, smoke, pollen,
bacteria and mold.
2. The activated carbon filter consists of a vast system of
highly adsorbent molecular sized pores to remove
gases, odors and VOC s(volatile organic compounds).
3. Photocatalyst filter (TiO2): Photocatalytic oxidation is
achieved when you combine UV rays with a Titanium
Dioxide (TiO2) coated filter. This process creates
hydroxyl radicals that remove harmful gases and VOC s
(volatile organic compounds) such as formaldehyde,
ammonia and many other common contaminants that
are released by building materials, household cleaners,
particle boards and carpeting.
4. Control key: User interface for Fan speed, Timer UV/Ion,
and power.
5. LCD display that shows the settings of the air purifier.
6. Remote control and remote control storage.
7. Low level and ozone safe negative ionizer to freshen and
balance the air(ie neutralize a surplus of positive charges
from TV s and computer monitors).
8. Air quality indicator: LED light that changes color
depending upon air quality in your room. Blue is best,
Green means a higher level of particles and Red means a
high level of particles.
9. UV-C lamp. Ultraviolet light possesses just the right
amount of energy to break organic molecular bonds. As
microorganisms pass by the UV rays this bond breakage
translates into cellular or genetic damage to micro-
organisms such as germs, viruses and mold resulting in
their destruction.

Easy operating instructions:
1.Plug it in
2.Turn it on (be sure to remove any bags from the filters
inside the air purifier)
3.Breathe easier
Note: If the air purifier does not turn on when the knob is
turned check to make sure:
1.You have power to your electrical outlet.
2.The filter is installed and the front cover of the air
purifier is correctly installed. There is a safety
mechanism that prevents the air purifier from powering
on if the either the filter or cover are not properly installed.
Assembly and Maintenance:
1.The washable pre-filter can be separated from the
HEPA filter and cleaned with water or a low level suction
vacuum cleaner. This is suggested every couple months
if you have pet hair or above average dust levels.
2.The HEPA filter and the carbon filter cannot be washed
and the filters will be damaged if they become wet.
3.If the air purifier begins to make a noise like the motor
is straining due to increased air flow resistance it is best
to replace the HEPA filter since the air flow through the
air purifier is being greatly reduced.
How to Remove the Cover:
1.Make sure the air purifier is turned off and unplugged.
2.There is a plastic latch on both sides of the cover near
the bottom that locks the cover to the air purifier. Grab
the cover at the plastic latch and pull out and then
toward you as shown below. It may help to look for the
black latch as it is easier to open when you pull from
that location. Once the lower section is unlatched,
push the cover up to remove it from the air purifier.
2
1

Filter Position Sequence (from the bottom up):
Photocatalyst filter Carbon filter HEPA filter Pre-
filter. The good news here is that there is only one way to
put each of these filters into the air purifier since there is
an opening sized for each.
Pre-filter
HEPA filter
Carbon filter
Photocatalyst filter
Filter Lock: After all of the filters have been installed,
turn the filter lock to secure them in place. Ensure the
black pre-filter is the top filter.
How to attach the cover:
Insert the knob on either side of the front cover into the
notches that are in the top of the air purifier as shown below.
Then swing the bottom of cover toward the air purifier until
the latches on either side lock into place.
2
1
UV Lamp
1.Caution do not touch the glass part of the lamp. Oil from
fingertips will decrease the effectiveness of the lamp.
2.To remove the lamp, ensure the air purifier is unplugged and
the UV lamp has been off for at least 15 minutes. Remove
the front cover and all of the filters. Hold the white ceramic
ends of the UV lamp and turn 90 degrees counter clockwise.
3.To install the lamp, hold the white ceramic ends, insert the
copper pins into the UV lamp assembly and turn 90 degrees
clockwise. Reinstall the filters and close the front cover.
Remove the UV Lamp
Assemble the UV Lamp
