Oregon Scientific GLAZE User manual

User Manual
Thank you for purchasing Aroma Diffuser GLAZE. Be sure to read this manual thoroughly
in order to use the product properly.
Please keep this manual for reference in the event any problems or questions arise.

2
Safety Precautions (Read the following precautions carefully)
● Please follow the instruction below (to ensure proper use)
To prevent injury of user and other people or damage of property, the following indications must
be followed. Read the precautions carefully to ensure proper use.
This indicates precautions for which improper usage
“may result in death or serious injury”.
This indicates precautions for which improper usage “may result in slight
injury or damage of property”.
● The following symbols distinguish contents which should be avoided or followed.
Indicated “Prohibition -what must NOT do”.
Indicated “Compulsion -what must do”.
WARNING
Do not touch the ultrasonic vibration plate while the
product is operating. It may cause burn injury.
Keep out of reach of children or throw away the
plastic packaging bags to prevent children
suffocation.
Do not modify, repair or rebuild the product.
It may cause fire or electric shock. Do not use the
product in a way that is not described in this
manual. It may cause injury or failure.
Do not step on, drop down or strongly slap on the
product. Damage of product may cause fire or
electric shock. Stop the power supply while any
damage is found. It may cause fire and electric
shock if keep using.
Do not handle the body part of the product, DC plug
and USB plug with wet hands. It may cause failure,
fire or electric shock.
Do not allow the body part or accessories to get wet.
Do not use or keep the product in a high humid area,
such as bathroom, changing room and greenhouse.
It may cause failure, fire or electric shock. When
water spills out, turn off the power, stop using the
product. It may cause fire or electric shock if keep
using.
Place the product in somewhere out of reach and
use of toddler. Unintentional injuries may be
caused easily due to the collapse of the body part
or imporper use.
Do not intentionally breath in the mist direct
coming out from the mist outlet. It may be harmful
to health. This product is not a medical respirator.
Do not use this product out of purpose of aroma
mist or diffusion.
Do not use detergent except kitchen detergent to
clean the main body. Detergent leaving in the
water tank may cause toxic gases or failure.
Unplug the USB plug (from the USB port of
computer) before cleaning to avoid electric shock
or injury.
Warning
Caution

Do not stab or insert any sharp, metal such as
needle, pin into the product of mist outlet, air inlet
and air oulet. It may cause electric shock or injury.
Do not block the mist outlet, air inlet and air outlet.
Disturbance of normal operation may cause
malfunction, overheating or failure.
Do not touch the body part right after the operation.
Be aware of the high temperature of mist or water
in the water tank.
Do not remove the ceramic cover or the lid of the
water tank while the product is operating. Water
and essential oil may spill out, damage the
surrounding stuff and cause failure.
Exchange tap water in the water tank every day
and make sure the water tank is clean. There may
be water stains or mineral attachment if the water
tank is not cleaned properly and may cause poor
performance. Moreover, mould or bacteria may
cause stingy smell and harmful to health. Be aware
of allergies caused by mould and bacteria
3
Caution
Use tap water in room temperature. Mould or
bacteria may grow easily if mineral water,
alkaline-ion water, well water, or filtered water is
used.
Use essential oil that is 100% extracted from
plant naturally. Do not use synthetic fragrance.
Add 2-3 drops of essential oil into 80mL water, do
not add too much since it may cause failure.
Do not place the product near any electrical
compliance such as computer, TV, piano, painted
furniture and special processed wall surface.
Touching or spilling of mist or water may cause
failure or damage of properties.
Do not place anything on the product or place the
product somewhere unstable. It may fall down
and cause injury.
Drain and keep the water tank dry if water may
be frozen. Ultrasonic vibration plate may be
damaged if the internal structures get frozen.

4
Water tank lid
(※hereinafter
called lid)
Body part
Light switch Mist switch
Ceramic Cover
(※hereinafter
called cover)
Mist outlet
Water level
indicator
Drainage Direction
Drainage Direction
Drainage
DC jack
Water tank
Air outlet
Ultrasonic Vibration
Plate
• USB cable
USB plug DC plug
Air inlet
Accessories
Name of parts
Drainage Direction

5
Preparation
1.
2.
3.
Caution
·
·
·
·
cover lid
DC jack
DC plug
USB plug
ultrasonic vibration
plate cover
How to use
Remove cover and lid When using in first time
Remove the buffer material between the cover
and body part.
Make sure ultrasonic vibration plate cover is
installed
※ Mist would not generate if the ultrasonic vibration plate cover
has not been installed.
※ Place the product on a stable surface
《Using in USB port of computer》
Insert the supplied USB cable to USB port of
computer or mobile battery and connect to DC
jack on a stable surface.
※ Mist may not generate normally or power may be off
depending on different computer.
Do not connect with USB hub
USB hub cannot ensure stable power supply, the
product may not operate normally.
Place the product on a stable surface which is
not near the connected computer.
Computer failure may be caused if it exposes to mist.
Connect USB cable before adding water.
Use USB port with 1.0A output.

lid cover
6
4.
·
·
※
※
※
※
※
5. Add 2-3 drops of essential oil into the water tank
·
·
※ Essential oil is sold separately. Prepare 100% extracted
Natural Essential oil.
6.
2-3 drops of
essential oil
Water line
Do not add
water directly
under the tap
Pour 80ml tap water into the water tank.
The volume of the water tank is 80ml, do not add
water over the water level indicator.
Return the lid and the cover to their places.
Make sure there are no gap between the body part
and the lid, also between the body part and the cover.
There may be leakage between the gaps.
Do not tilt the product while adding water. It may cause
failure if water entered internal part via air outlet.
The product must be switched off when adding water.
Spilling of water may cause failure.
Do not add water when the product is operating. High
temperature vapor and water may blow out.
Remove the cover and lid before adding water with a
container. Do not add water directly into the mist outlet
without taking out the lid or place the water tank directly
under the tap. Spilling of water may cause failure.
Do not add cold water since the mist generation would be
affected.
Mist cannot generate if water is over the
water line.
Do not allow DC plug and USB cable to get wet.
Essential oil must be added when the water tank
is full (80ml).
Do not add essential oil directly onto the
ultrasonic vibration plate.
Do not add too much essential oil.
It may cause failure.
Caution
Caution
Drainage Direction
Drainage Direction
Drainage Direction

Intermittent 6hrs mode: 30 seconds on/ 30 seconds off
repetition.
Automatically power off when no water in the water tank.
When operating with mist function, the light would be off
if mist stops automatically.
The product is able to turn on the light only without mist
generation.
Press mist switch to choose the operation mode.
Press light switch to choose light mode.
Turn off the product by pressing the mist switch and
the light switch a few times.
Press mist switch to turn on the power, the first mode is
continuous 1 hour.
Different operation modes would be shifted as the
following rotation by pressing the mist switch.
Press light switch to turn on the light.
Different light modes would be shifted as the following
rotation.
1.
Continuous
1hr mode
Continuous
3hrs mode
Intermittent
6hrs mode Power OFF
※
2.
·
·
3.
Light switch Mist switch
Operation
Light on strong Light on weak Light Off
7

Turn off the power
Unplug the USB plug.
Remove DC plug.
Be aware of spilling out water from the tank. Do not allow
water to enter the air outlet while removing the DC plug.
Remove the lid and cover.
Pour out water according to the following the
Drainage direction.
Pour out water on the opposite side of the air outlet, see the
picture on the right.
When finished using the product or preferring to change
essential oil, pour out all the water in the water tank and clean it.
Press light switch/mist switch to turn the power off.
Do not allow water to get into the air outlet.
Caution
8
1.
Keep Cleaning
Read the instruction P.12 “Care”
Keep the product completely dry after using it.
6.
7.
2.
3.
4.
5.
Air outlet
Drainage
Direction
How to drain the water tank
Drainage Direction

The below instructions must be followed
・ Do not move the product when it is operating. Before moving it, switch off and drain all the
water from the water tank. Follow the Drainage Direction to pour out the water. Do not
allow the air outlet to get wet when draining. When moving the product, beware to hold the
body part and the cover to prevent dropping.
・ Do not allow essential oil to get contact to parts other than the water tank. If essential oil is
attached, wipe it off with a wet cloth immediately.
・ After the product stops automatically, do not use it for 30 mins. Overheating of the
ultrasonic vibration plate may cause failure.
・ Do not switch on the product if the water tank is empty. It may cause product damage,
failure or water leaking.
・ Do not pour water over 80ml (max. Capacity of the water tank). Mist may not be generated
normally.
・ If water level in the water tank is low, the product would stop automatically even timer is
not finished.
・ Volume of mist may be low depending on operation environment, such as water tempera-
ture or water quality. Volume of mist would become stable after few minutes.
・ It is possible that mist cannot be easily seen due to temperature, humidity or airflow, but it
is not failure.
・ There may be water drops inside the lid. Open it in a place that can get wet and use a towel
to wipe the water drops.
・ As this product is an Aroma Diffuser applying ultrasonic humidifier principle, it does not
have functions as an ordinary humidifier.
・ Floor, wall or furniture may get wet due to mist from the product if the room humidity is
high. In this case, switch off and stop using the product.
9
●
Before Use

Way of taking out
Mist may not be generated if there are bubbles attached on the Ultrasonic
Vibration Plate. If there are bubbles, switched off the product and take out the
Ultrasonic Vibration Plate Cover. Use a cotton swab to clean up the bubbles.
Pull the Ultrasonic Vibration
Plate Cover up from the body
part to take it out.
Way of installation
Match the Waist of the Ultrasonic
Vibration Plate Cover with the
Hook on the Ultrasonic Vibration
Plate to install.
10
Cover of
Ultrasonic
Vibration
Plate
Hook
Waist
About handling the Ultrasonic Vibration Plate Cover
Be aware of bubbles attached on the Ultrasonic Vibration Plate

・ Use essential oil which is 100% extracted from plant naturally in this product. Do not use
synthetic essential oil which contains impurity, solid. It may cause the damage to product.
・ Use 2~3 drops of essential Oil in 80ml of water. Using too much essential oil may cause
failure due to oil attachment on the Ultrasonic Vibration Plate. Also, do not add essential
oil into the water tank when there is no water. Essential oil may attach to the Ultrasonic
Vibration Plate and case malfunction.
・ Only the water tank and the lid are made of oil-tolerance material. Other parts may melt if
there is essential oil contact.
・ Essential Oil may leave inside the water tank, clean the water tank every day.
・ If there is smoke or burnt smell from the product, turn the power off immediately. Bring it
to the store purchased for repair.
・ Unplug the DC plug after using the product. Injury may be caused by stumbling over.
・ Do not put the product on any soft cushion or carpet with long fur. The air inlet may be
blocked and cause failure.
・ Do not put the product near curtain. The mist outlet may be blocked.
・ Do not add anything other than tap water and essential oil into the water tank. It may cause
failure.
・ Do not put the product in a high temperature area or near flame. It may cause failure or
deformation.
・ There may be individual weight, thickness or color difference of the cover.
・ Do not drag the cover on tables. It may damage the tables.
11
About the use of Essential Oil
Other points to be aware

12
1.
·
·
Ultrasonic Vibration Plate
Ultrasonic Vibration
Plate Cover
4.
Care
The water tank must be cleaned every day in order to extend the product life.
Clean the product once a day after using it. Likely, if the product has not been
used for a long period of time, clean it before using.
Switch off the product, remove the DC plug from the main body and drain the
water tank.
Refer to P.8 “How to drain the water tank”
2. Wipe the water tank gently with a cloth which contains mild detergent.
3. Clean the Ultrasonic Vibration Plate with a cotton swab which contains mild
detergent.
After washing the water tank, clean up the water inside with a soft cloth and dry
water tank completely.
Water tank must be drained according to the Drainage Direction.
Do not allow the air outlet to get wet.
Do not allow the air outlet to get wet when washing the water tank.
Mild detergent in kitchen must be used for cleaning the water tank. It is very dangerous if
hydrochloric acidic, acidic or enzymatic detergent is used and left inside the water tank as
toxic gas may be generated.
If oil is attached on the Ultrasonic Vibration Plate, the product may not operate normally.
Take out the Ultrasonic Vibration Plate Cover (P.10) and clean the plate carefully.
Caution
Caution

Confirm the followings before (asking for) repair.
13
Troubleshooting
Symptom Possible Cause Solution
No Power
No mist /
Mist volume
is low
・ Confirm connection of main body and concentric
plug. Unplug the DC plug from the main body and
re-plug it.
・ There may be no power supply if using a USB hub.
Connect the product to a USB port of a computer
(5V 1.0A).
・ Add water into the water tank.
・ Clean the Ultrasonic Vibration Plate (refer to
P.12).
・ Add water into the water tank.
・ If water level in the water tank is low, the product
would stop automatically even timer is not finished
and mist also stops at the same time.
・ If the Ultrasonic Vibration Plate Cover is not
installed properly, mist cannot be generated.
・ If water is added over the water level indicator,
mist may not generate normally. Add water
according to the water level indicator.
・ If there is dirt in the air inlet, mist may not be
generated. Clean the air inlet regularly.
・ The air inlet may be blocked, mist would not
generate and cause failure. Change the place to
put the product.
・ Mist may not be seen if placing the product in an
area with airflow.
・ If mist generates inside the water tank and the air
outlet runs normally (Motor sounds can be heard),
it is not failure.
・ Clean up the bubbles on the Ultrasonic Vibration
Plate (refer to P.10).
・ If the Mist Outlet gets wet, a layer of water would block
it, mist may not be generated. Clean up the layer.
Is USB cable plugging in properly?
Are you using a USB hub?
Is there any water in the water tank?
Is there any oil attached on the
Ultrasonic Vibration Plate?
Does the water tank become
empty?
Is the Ultrasonic Vibration Plate
Cover installed?
Is there too much water in the
water tank?
Is the air inlet dirty?
Are you using the product on a
cushion or a long fur carpet?
Are you using the product in a windy
area?
Mist may not been seen due to the
environment like temperature and
humidity.
Are there any bubbles attached on
the Ultrasonic Vibration Plate?
Is there a layer of water in the Mist
Outlet?

There is scent
other than
aroma oil
Water leakage
-
14
Symptom Possible Cause Solution
・ Do not use water other than tap water as it rots
easily and may affect the scent of aroma oil. Drain
the water tank and clean it up before using tap
water.
・ There may be detergent left inside the water tank.
Drain the water tank and clean it up before using
tap water.
・ Reinstall the cover and the lid.
Are you using water other than tap
water?
When cleaning the water tank, do
you wash it thoroughly?
Are the cover and the lid installed
properly?

Aroma Diffuser GLAZE
HWI0006
Mist Type
85(W) x 167(H) x 85(D) mm
Approx. 490g (excluding USB cable)
Approx. 80ml
Strong→Weak
Continuous 1hr → Continuous 3hrs →
Intermittent 6hrs (30sec ON/ 30sec OFF)
USB
5W
5 oC~40 oC
20%~80%
150cm
Main Body: ABS . PP Ceramic Cover: Ceramics
100% Pure Essential Oil (sold separately)
USB Cable, User Manual
Product Name
Item number
Aroma Generation Type
Dimension
Weight
Capacity of Water Tank
Light Mode
Operation Mode
Power Source
Fixed Power Consumption
Recommended Operation Temperature
Recommended Operation Humidity
Cord Length
Material
Corresponding Aroma Oil
Accessories
15
※
※
Product Specification
There is individual difference of dimension and weight.
The product specification and design may change without prior notice.

EU Declaration of Conformity
Disposal Information for Users
Hereby the manufacturer, Oregon Scientific, declares that the equipment type:
Aroma diffuser GLAZE (HWI0006) is in compliance with 2014/30/EU Directive. The full text of
the EU Declaration of Conformity is available at the following internet address:
www.oregonscientific.com
Pursuant to and in accordance with Article 14 of the Directive 2012/19/EU of the
European Parliament on waste electrical and electronic equipment (WEEE), and
pursuant to and in accordance with Article 20 of the Directive 2013/56/EU of the
European Parliament on batteries and accumulators and waste batteries.
The barred symbol of the rubbish bin shown on the equipment indicates that, at the end of its
useful life, the product must be collected separately from other waste.
Please note that the batteries/rechargeable batteries must be removed from the equipment
before it is given as waste. To remove the batteries/accumulators refer to the specifications in
the user manual. Therefore, any products that have reached the end of their useful life must be
given to waste disposal centers specializing in separate collection of waste electrical and
electronic equipment, or given back to the dealer when purchasing a new WEEE, pursuant to
and in accordance with Article 14 as implemented in the country.
The adequate separate collection for the subsequent start-up of the equipment sent to be
recycled, treated and disposal of in an environmentally compatible way contributes to prevent-
ing possible negative effects on the environment and health and optimizes the recycling and
reuse of components making up the apparatus.
Abusive disposal of the product by the user involves application of the administrative sanctions
according to the laws in force.
16

Bedienungsanleitung
Aroma Diffuser
Vielen Dank, dass Sie sich für „Aroma Diffuser GLAZE ” entschieden haben. Lesen
Sie diese Anleitung sorgfältig durch, um eine korrekte Verwendung dieses
Produktes sicherzustellen.
Bitte bewahren Sie diese Anleitung für die zukünftige Nutzung gut auf, falls es zu
Problemen oder Fragen kommen sollte.

2
Vorsichtsmaßnahmen
(Bitte sorgfältig durchlesen)
● Um Verletzungen der Benutzer und anderer Personen oder Schäden zu vermeiden, müssen die folgenden
Anweisungen befolgt werden. Lesen Sie die Vorsichtsmaßnahmen sorgfältig durch, um eine korrekte
Verwendung sicherzustellen.
Warnung Das Symbol kennzeichnet Vorsichtsmaßnahmen, die bei falscher Ausführung zum Tod
oder ernsthaften Verletzungen” führen können
Vorsicht Das Symbol kennzeichnet Vorsichtsmaßnahmen, die bei falscher Ausführung zu leichten
Verletzungen oder Schäden führen können.
● Die folgenden Symbole unterscheiden zwischen Inhalte, die vermieden oder befolgt werden müssen.
Kennzeichnet, Verbot „was nicht getan werden darf”
Kennzeichnet Anweisung, „was getan werden muss”.
Warnung
Berühren Sie nicht die Ultraschall-Vibrationsplatte,
während das Produkt sich in Betrieb befindet. Dies
könnte zu Verbrennungen führen.
Halten Sie das Gerät außerhalb der Reichweite von
Kindern und entsorgen Sie die Plastikverpackung,
um zu vermeiden, dass Kinder daran ersticken.
Dieses Produkt darf nicht modifiziert, repariert oder
umgebaut werden. Dies könnte zu Feuer oder
Stromschlag führen. Verwenden Sie das Produkt
nur, wie es in dieser Anleitung beschrieben ist.
Ansonsten könnte es zu Verletzungen oder
Versagen kommen.
Treten Sie nicht auf dieses Produkt, lassen Sie es
nicht fallen und schlagen Sie es nicht. Schäden am
Produkt könnte zu Feuer oder Stromschlag führen.
Stoppen Sie die Stromversorgung, wenn Sie
irgendwelche Schäden bemerken. Ansonsten
könnte es zu Feuer und Stromschlag kommen.
Berühren Sie den Hauptkörper des Produkts, den
Stecker und den USB-Stecker nicht mit nassen
Händen. Dies könnte zu Versagen, Feuer oder
Stromschlag führen.
Lassen Sie weder den Hauptkörper noch das
Zubehör nass werden. Benutzern und lagern Sie das
Produkt nicht in einer feuchten Umgebung, wie z.B.
ein Badezimmer, Wechselzimmer und ein
Gartenhaus. Dies könnte zu Versagen, Feuer oder
Stromschlag führen. Wenn Wasser ausläuft,
schalten Sie das Gerät aus, unterbrechen Sie die
Verwendung des Produktes. Dies könnte zu Feuer
oder Stromschlag führen.

3
Warnung
Vorsicht
Platzieren Sie das Produkt außerhalb der Reichweite
von Kleinkindern. Es könnte zu Verletzungen
kommen, wenn der Hauptkörper zusammenfällt oder
das Gerät falsch verwendet wird.
Atmen Sie den Dampf, der direkt aus dem
Dampfauslass kommt, nicht absichtlich ein. Dies
könnte gesundheitsschädlich sein. Dieses Produkt
ist kein medizinisches Atemgerät. Benutzen Sie
dieses Produkt nur für die Verteilung von Aromadüften.
Verwenden Sie zur Reinigung des Hauptkörpers nur
Küchenreinigungsmittel. Wenn Reinigungsmittel im
Wassertank zurückbleibt, könnten diese zu giftigen
Gasen oder Versagen führen.
Ziehen Sie vor der Reinigung den USB-Stecker (aus
dem USB-Port des Computers) ab, um Stromschlag
oder Verletzungen zu vermeiden.
Nicht in das Gerät stechen oder scharfe, metallische
Gegenstände, wie z.B. eine Nadel oder eine Stecknadel
hineinstecken. Dies könnte zu Verletzungen oder
Stromschlag führen.
Dampfauslass, Lufteinlass und Luftauslass nicht
blockieren. Eine Störung der normalen Funktionsweise
könnte zu Fehlfunktion, Überhitzung oder Versagen
führen.
Berühren Sie gleich nach der Benutzung nicht den
Hauptkörper. Denken Sie an die hohe Temperatur des
Dampfes oder Wassers im Wassertank. Es könnte zu
Verbrennungen kommen.
Entfernen Sie nicht die Keramikabdeckung oder den
Deckel des Wassertanks, während das Produkt in Betrieb
ist. Wasser und ätherisches Öl könnte auslaufen,
naheliegende Gegenstände beschädigen und zu
Versagen führen.
Tauschen Sie das Wasser im Wassertank täglich aus und
stellen Sie sicher, dass der Wassertank sauber ist. Es
könnte zu Wasserflecken oder Kalkablagerungen
kommen, wenn der Wassertank nicht richtig gereinigt
wird, was zu einer schlechteren Leistung führt. Außerdem
könnte Schimmel oder Bakterien zu einem stechenden
Geruch führen und gesundheitsschädlich sein. Denken
Sie an Allergien, die durch Schimmel und Bakterien
verursacht werden können.
Verwenden Sie Leitungswasser auf Zimmertemperatur.
Schimmel und Bakterien wachsen leicht, wenn
Mineralwasser, Alkali-Ion Wasser, Brunnenwasser oder
gefiltertes Wasser verwendet wird.
Verwenden Sie ätherisches Öl, das zu 100% von
natürlichen Pflanzen extrahiert wurde. Verwenden Sie
keine synthetischen Aromen. Geben Sie 2-3 Tropfen
ätherisches Öl in 80 ml Wasser. Geben Sie nicht zu viel
hinzu, ansonsten könnte es zu Versagen führen.
Platzieren Sie das Produkt nicht in der Nähe von
elektrischen Geräten, wie z.B. Computer, TV, Piano,
bemalten Möbeln und besonders verarbeiteten
Wandoberflächen. Berührungen oder das Verschütten
von Dampf oder Wasser könnte zu Versagen oder
Schäden führen.
Stellen Sie nicht auf das Produkt und platzieren Sie das
Produkt nicht auf instabilen Oberflächen. Es könnte
hinunterfallen und zu Verletzungen führen.
Trocknen Sie den Wassertank, wenn das Wasser
gefroren ist. Die Ultraschall-Vibrationsplatte könnte
beschädigt werden, wenn die interne Struktur gefriert.

4
Hauptkörper
Luftauslass
Dampfschalter
Lichtschalter
Dampfauslass
Wasserstandsanzeige
anzeige
Ablaufrichtung
Buchse
Wassertank
Ultraschall
Vibrationsplatte
Lufteinlass
• USB-Kabel
USB-Stecker
Zubehör
Stecker Keramik Abdeckung
(※hiernach Abdeckung
genannt)
Wassertank Deckel
(※hiernach Deckel
genannt)
Teilebezeichnungen
Drainage Direction
Drainage
